Invacare HCPCS E1038 User Manual

INVACARE

Standard Manual

Wheelchairs

INVACARE®

Standard Manual Wheelchairs

For over 30 years, Invacare has set the standard for manual wheelchairs by empowering people with disabilities to achieve their goals. Invacare’s programs and services have helped providers operate more successfully and efﬁciently while meeting their clients’ needs. The “can-do” attitude and commitment to quality from Invacare is represented in the full product line of standard manual wheelchairs. Today Invacare continues to work on design improvements while maintaining the characteristics that have become tradition: durability, interchangeability and value.

Invacare Customer Service (800) 333-6900 www.invacare.com

Why Invacare® Standard Manual Wheelchairs?

As the premier brand in the home health care industry, Invacare continues to be committed to meeting both the needs of customers and consumers worldwide with standard wheelchair products.

• Low-maintenance designs that meet RESNA standards for manual wheelchair performance.

• Many models available as ready to ship for quick delivery.

• Consumer custom configurability available.

• Full assortment of bariatric manual wheelchair solutions.

Table of Contents

Transport Chair 4

Lightweight Aluminum Transport 5

Heavy-Duty Transport 6

Invacare

Invacare Customer Service (800) 333-6900 www.invacare.com

LOGO LOOK-OUT!

Veranda™ Wheelchair 7

Tracer® EX2 Wheelchair 8

Tracer® SX5 Wheelchair 9

Tracer® SX5 Recliner 10

9000 SL Wheelchair 11

9000 XT Wheelchair 12

9000 XT Recliner 14

Invacare® Insignia® Wheelchair 15

Invacare

Patriot™ Wheelchair 16

Tracer® IV Wheelchair 17

9000 XDT Wheelchair 18

9000 Topaz™ Wheelchair 19

9000 Jymni™ Wheelchair 20

9000 Jymni™ Recliner 21

Backs & Cushions 22-23

Accessories 24-25

Ramps, CLD & Color Guide 26

Bariatric/Heavy-Duty Designation

Invacare products with the Bariatric/Heavy-Duty icon are designed for your bariatric patients whose height and weight require the use of a heavy-duty model. These products provide the same quality that all Invacare products possess. They also demonstrate Invacare's commitment to this product category.

Seating Options

Invacare general use seat cushions and backs are available without a qualifying diagnosis.* Invacare products with the cushion logo are available to be purchased with a seat cushion or back to provide maximum comfort.

*Providers are responsible for determining the appropriate billing codes when submitting to the Medicare Program and should consult an attorney or

other advisor to discuss specific situations in further detail. This information is subject to change without notice.

Builder Chair

Invacare products with the configurable logo are available as stock models and are also able to be custom configured. Select from many options to personalize a chair to a user's specific wants and needs.

People with disabilities want more than wheelchair mobility.

What they really want is access, integration, and jobs - they want to do all the same

things able-bodied people want to do.

Invacare Customer Service (800) 333-6900 www.invacare.com

E1038

Invacare® Transport Chair

FEATURES

• Stylish, Silver Vein, powder-coated carbon steel frame

• Footrests are included with the chair and match frame finish

• Black nylon upholstery is flame retardant and bacteria resistant

• Full-length arms are padded for comfort

• Carry straps on seat allow for ease of folding and lifting

• Fold-down back makes transport and storage easy

SPECIFICATIONS

Model Numbers TRAN17FR TRAN19FR HCPCS E1038 E1038 Chair Dimensions

Seat width 17" 19"

Seat depth 16" 16"

Back height 19" fold-down 19" fold-down

Seat-to-floor height 19" 19"

Overall Dimensions

Overall width 19" 21"

Folded width 7.25" 7.75"

Overall depth w/o Riggings 27" 27"

Overall height 39" 39"

Weight w/o riggings 24.5 lb. 25 lb.

Weight capacity 250 lb. 250 lb.

Limited warranty (mo.) 12 months 12 months

Casters and Wheels

Caster height 8" 8"

Wheel height 8" 8"

Shipping

Box weight 34" 34"

Box dimensions (LxWxH) 23"x12"x31" 25"x12"x32"

Note: All specifications are approximate

Invacare® Transport chair is designed

for safe and efficient patient transport. The

Transport chair has the added advantage of

sharing interchangeable parts with the other

chairs in the transport series. The Transport

chair is compact and lightweight.

Invacare Customer Service (800) 333-6900 www.invacare.com

Invacare® Lightweight Aluminum Transport Chair

FEATURES

• Black nylon upholstery is flame retardant and bacteria resistant

• Full-length arms are padded for comfort

• Carry straps on seat allow for ease of folding and lifting

• Footrest painted to match frame finish

• Fold-down back makes transport and storage easy

• Weighs 19 lb. (w/o riggings)

E1038

SPECIFICATIONS

ALR19HBFR LTTR19FR Model numbers ALB19HBFR LTTB19FR LTTB17FR

HCPCS E1038 E1038 E1038 Chair Dimensions

Seat width 17", 19" 19" 17"

Seat depth 15.5", 16" 15.5" 15.5"

Back height 17.5" 17.5" 17.5"

Seat-to-floor height 19.25" 19.25" 19.25"

Overall Dimensions

Overall width 23.5" 21.5" 23.5"

Folded width 8.5" 8.5" 7.75"

Overall depth w/o riggings 24.25" 24.25" 24.25"

Overall height 37.5" 36.5" 36.5"

Weight w/o riggings 19 lb. 19 lb. 19 lb.

Weight capacity 250 lb. 250 lb. 250 lb.

Limited warranty (mo.) 13 months 13 months 13 months

Casters and Wheels

Caster height 8" 8" 8"

Wheel height 12" 8" 8"

Shipping

Box weight 30 lb. 27 lb. 27 lb.

Box dimensions (LxWxH) 27"x10"x 31" 26" x10" x 32" 26"x 10"x 31"

Note: All specifications are approximate

Invacare® Lightweight Aluminum Transport chairs are designed for safety,

ease and comfortable patient transport. The

lightweight frames weigh only 19 lb. and

incorporate a fold-down back, making these

chairs easy to transport and store.

ALR19HBFR Lightweight Aluminum Transport Chair in red.

Invacare Customer Service (800) 333-6900 www.invacare.com

E1039

Invacare® Heavy-Duty Transport Chair

FEATURES

• Removable padded desk arms

• Carbon steel frame with dual crossbraces

• Swingaway footrest with aluminum footplates

SPECIFICATIONS

Model Numbers TRHD22FR HCPCS E1039 Chair Dimensions

Seat width 22"

Seat depth 18"

Back height 20"

Seat-to-floor height 19.5"

Overall Dimensions

Overall width 28"

Folded width —

Overall depth w/o riggings 36.5"

Overall height —

Weight w/o riggings —

Weight capacity 400 lb.

Limited warranty (mo.) 13 months

Casters and Wheels

Caster height 8"

Wheel height 12"

Shipping

Box weight 51lb.

Box dimensions (LxWxH) 29" x 11" x 33"

Note: All specifications are approximate

Invacare® Heavy-Duty Transport chair

is designed for safe and efficient patient

transport. The Transport chair has the added

advantage of sharing interchangeable

parts with the other chairs in the transport

series. The Transport chair is compact and

lightweight.

Invacare Customer Service (800) 333-6900 www.invacare.com

Invacare® Veranda™ Wheelchair

FEATURES

• Stylish powder-coated frame includes front riggings

- Footrests match chair

- Legrests are chrome

• Carry pocket on back

• Large step-tube end cap

• Padded nylon upholstery

• Comfortable padded arms

K0001/ K0002

SPECIFICATIONS

Model numbers V16, V18, V20 HCPCS K0001/K0002 Chair Dimensions

Seat width 16", 18", 20"

Seat depth 16", 18"

Back height 18"

Seat-to-floor height 19.25"

Overall Dimensions

Overall width 23", 25", 27"

Folded width 14"

Overall depth w/o riggings 30"

Overall height 36"

Weight w/o riggings —

Weight capacity 250 lb.

Limited warranty (mo.) 12 months

Casters and Wheels

Caster height 8"

Wheel height 24"

Shipping

Box weight 54 lb.

Box dimensions (LxWxH) 33" x 12" x 36"

Note: All specifications are approximate

Invacare® Veranda™ wheelchair provides

comfort and mobility in an economical package.

Complete with front riggings packaged with the

chair, the Invacare Veranda wheelchair combines

style and durability at an affordable price.

Invacare Customer Service (800) 333-6900 www.invacare.com

K0001/K0002

Invacare® Tracer® EX2 Wheelchair

FEATURES

• Durable, low-maintenance, triple chrome-plated carbon steel

frame is long-lasting

• Dual axle positions allow variation of seat-to-floor heights

• Offset permanent arms available in 16", 18" and 20" widths

• 14-gauge crossbraces add strength and durability

• Urethane rear tires mounted on “no flex“ wheels offer superior

performance

• Low-maintenance, dual-sealed precision bearings

• Heavy-duty inner liners keep seat and back from stretching

• Upholstery is dual-embossed

• Meets RESNA standards for manual wheelchairs in product

performance

SPECIFICATIONS

Model Numbers TREX20, TREX26, TREX28 HCPCS K0001/K0002 Chair Dimensions

Seat width 16",18",20"

Seat depth 16"

Back height 16"

Seat-to-floor height 17.5", 19.5"

Overall Dimensions

Overall width 23.25", 24.25", 25.25", 26.25", 27.25", 28.25

Folded width 13"

Overall depth w/o riggings 31.88"

Overall height 34"

Weight w/o riggings 36 lb.

Weight capacity 250 lb.

Limited warranty (mo.) 60 months

Casters and Wheels

Caster height 8"

Wheel height 24"

Shipping

Box weight 43 lb.

Box dimensions (LxWxH) 32" x 13" x 38"

Note: All specifications are approximate

Invacare® Tracer® EX2 wheelchair sets

the benchmark in manual wheelchairs. A true

dual axle position allows for repositioning the

24" rear wheels and 8" casters for adult and

hemi seat-to-floor heights. Offset permanent

arms offer full seat width up to 20" with a

permanent arm, hemi-spaced footrest and full

range of accessories. Incorporating the design

and technology of the Invacare 9000 series,

the Tracer EX2 wheelchair has interchangeable

components with the 9000 series chairs.

Invacare Customer Service (800) 333-6900 www.invacare.com

Invacare® Tracer® SX5 Wheelchair

FEATURES

• Durable, low-maintenance, triple chrome-plated carbon steel

frame is long-lasting

• Dual axle positions allow variation of seat-to-floor heights

• 14-gauge crossbraces add strength and durability

• Urethane rear tires mounted on “no flex” wheels offer superior

performance

• Sectional back available in 16" and 18" back heights

• Low-maintenance, dual-sealed precision bearings

• Heavy-duty inner liners keep seat and back from stretching

• Meets RESNA standards for manual wheelchairs in product

performance

K0003/K0006

SPECIFICATIONS

Model Numbers TRSX50, TRSX52, TRSX56, TRSX58 HCPCS K0003/K0006 Chair Dimensions

Seat width 14", 16", 18", 20", 22"

Seat depth 16"

Back height 16", 18"

Seat-to-floor height 17.5", 19.5"

Overall Dimensions

Overall width 22.5", 24.5", 26.5", 28.5", 30.5"

Folded width

Overall depth w/o riggings 34"

Overall height

Weight w/o riggings 36 lb.

Weight capacity 250 lb., 300 lb.

Limited warranty (mo.) 60 months

Casters and Wheels

Caster height 6", 8"

Wheel height 20", 22", 24"

Shipping

Box weight 43 lb.

Box dimensions (LxWxH) 32" x 13" x 37"

Note: All specifications are approximate

Invacare® Tracer® SX5 wheelchair's

lightweight frame, weighing less than 36 lb.,

makes this chair perfect for rental and long- or

short-term use. This wheelchair offers multiple

seat widths, arm styles, sectional back and seat-

to-floor heights by utilizing the dual axle position

frame base. The 20" and 22" widths include

a semi-pneumatic caster to accommodate a

weight capacity of 300 lb. Combining the design

and technology of the Invacare

9000 series

wheelchairs makes it possible to interchange

components with the Tracer SX5 wheelchair.

Invacare Customer Service (800) 333-6900 www.invacare.com
