Page 1

Parts Catalog

Formula™ TRE Powered Seating

Front Riggings & MK5 Electronics

Issued: May 27, 2008

TDX®

Powered Wheelchairs

Yes, you can. ™

Page 2

Throughout this catalog you will notice letters to draw your attention to specific footnotes which are located at the bottom of the page or below specified charts.

Parts Catalog Usage Guide

To order call toll free 1-800-333-6900, or www.invacare.com

The information contained in this document is subject to change without notice. This catalog contains service parts for Form No. 06-102. If you have any questions regarding this catalog, please contact one of our Customer Service Representatives.

For Customer Service Support Call:

1-800-333-6900

For Faxed In Orders Call:

1-800-678-4682 or

1-440-366-0709

For Technical Service Call:

1-800-832-4707

Literature Can Be Found at:

www.invacare.com or

1-800-828-6272

SYMBOL DEFINITION

Examples:

A,B,C etc. NOTE: NLA

= Special Comments = General information pertaining to that specific page = No Longer Available

HARDWARE MEASUREMENTS

The measurements for the hardware will be listed as follows:

Screws, Bolts Washers Spacers

For your convenience, we have supplied an area for you to list your Invacare Representatives.

Formula, Contoura, Personal Back 10, DualFlex, MKIV, MK5, EX, and TCD are trademarks of Invacare Corporation.

Otto Bock is a registered trademark owned by Otto Bock Orthopaedische Industrie GMBH & Co.. JAY Back is a registered trademark of Sunrise Medical

Diameter X Thread Count/Pitch X Length Inside Diameter X Outside Diameter X Thickness Inside Diameter X Outside Diameter X Length

Name Phone Numbers

HHG, Inc. Corporation

Form No.

06-102

Page 3

Electronics, ESC Elevating Seat Control Toggle Switch, Elevate Only For ASBA/ADJASBA Seating

Electronics, MK5 SAC and Shroud Cover, Conventional Tilt & Tilt w/ BPO Option 4/15/05-10/19/05

Electronics, MK5 TAC & Mercury Switches, Contoura Recline Only & Contoura Tilt Only After 1/5/06

Electronics, MK5 TAC & Mercury Switches, Conventional Tilt & Tilt w/ BPO Option 1/6/06-1/25/06

Electronics, MK5 TAC, Shroud Cover & Mercury Switches, Conv. Recline & Recline w/ BPO Option After 1/5/06

Electronics, MK5 TAC, Shroud Cover & Mercury Switches, Conventional Tilt & Tilt w/ BPO Option After 1/25/06

Electronics, MK5 TRECM & Mercury Switches, Conventional Tilt & Tilt w/ BPO Option 1/17/05-4/14/05

Electronics, MK5 TRECM & Mercury Switches, Conventional Tilt & Tilt w/ BPO Option 10/20/05-1/25/06

Electronics, MK5 TRECM & Mercury Switches, Conventional Tilt & Tilt w/ BPO Option Before 1/17/05

TABLE of CONTENTS

Page

Number

To order call toll free 1-800-333-6900, or www.invacare.com

Form No.

06-102

Description

A: READ THIS FIRST (THIS CATALOG IS DIFFERENT!) ...................................................... 6

Electronics - MK6i ~PLEASE READ FIRST ............................................................................. 80

Electronics, 4-Way Switch and Quad Push Button (QPB) Switch and Mounting Hardware .... 120

Electronics, Dual Legs Integrated Actuator Module (DLIAM) MK6i For ELRPW Front Riggings 81

Electronics, MK5 SAC, Contoura Recline Only & Contoura Tilt Only Before 1/6/06 ................ 115

Electronics, MK5 SAC, Conventional Recline & Recline w/ BPO Option Before 1/6/06 .......... 110

Electronics, MK5 SAC, Conventional Tilt & Tilt w/ BPO Option 1/17/05-4/14/05 ..................... 95

Electronics, MK5 SAC, Conventional Tilt & Tilt w/ BPO Option 10/20/05-1/5/06 ..................... 101

Electronics, MK5 SAC, Conventional Tilt & Tilt w/ BPO Option Before 1/17/05 ....................... 93

Electronics, MK5 SAC-E and (MK6i) Elevate Integrated Actuator Module (EIAM) .................. 91

117

103

112

106

Electronics, MK5 TRECM & Mercury Switches, Contoura Tilt, Recline & Tilt/Recline ............. 139

Electronics, MK5 TRECM & Mercury Switches, Conv. Recline & Tilt/Recline Before 5/19/05 . 135

124

130

122

Page 4

Electronics, MK5 TRECM, Shroud Cover & Mercury Switches, Conv. Recline & Tilt/Recline After 5/18/05

Electronics, MK5 TRECM, Shroud Cover & Mercury Switches, Conventional Tilt & Tilt w/ BPO Option After 1/25/06

Electronics, MK5 TRECM, Shroud Cover, Mercury Switches, Conv. Tilt & Tilt w/ BPO Option 4/15/05-10/19/05

Front Rigging - Center Mount Rigging (CTMT-F/CTMT-FL with FBCTMT One PC Flip-Up Footboard)

Front Rigging - Ctr. Mt. Rigging KIT, CTMT-F/CTMT-FL/CTMT-FJ, (Elev. Only-ADJASBA Stg. After 7/4/05), Conv./Contoura Stg.

Front Rigging - Ctr. Mt. Rigging Mtg. Hdwr., CTMT/CTMT-L/CTMTJ, Elev. Only For ASBA Stg. (Before 7/5/05)

Front Rigging - Ctr. Mt. Rigging Mtg. Hdwr., CTMT-F/CTMT-FL/CTMT-FJ, Conventional & Contoura Seating

Front Rigging - Ctr. Mt. Rigging Mtg. Hdwr., CTMT-F/CTMT-FL/CTMT-FJ, Elev. Only For ADJASBA Stg. (After 7/4/05)

TABLE of CONTENTS

Page

Number

To order call toll free 1-800-333-6900, or www.invacare.com

Form No.

06-102

Description

137

132

126

Electronics, Quad Link (QLA) After 10/30/05 ........................................................................... 145

Electronics, Quad Link Before 10/31/05 ................................................................................... 141

Electronics, TRSS Toggle, Contoura Tilt .................................................................................. 89

Electronics, TRSS Toggle, Conventional Tilt & Tilt w/ BPO Option After 1/16/05 .................... 87

Electronics, TRSS Toggle, Conventional Tilt & Tilt w/ BPO Option Before 1/17/05 ................. 85

Frame Finishes, Touch-Up Paints and Upholstery Options ..................................................... 7

Front Rigging - Adjustable Angle Footplates, AT5543 ............................................................. 42

Front Rigging - Calf Pads and Attaching Hardware ................................................................. 37

Front Rigging - Center Mount Rigging (CTMT/CTMT-F/CTMT-L/CTMT-FL) ........................... 50

Front Rigging - Center Mount Rigging (CTMTJ/CTMT-FJ) ...................................................... 47

Front Rigging - Center Mount Rigging KIT, CTMT/CTMT-L, Elevate Only For ASBA Seating 70

Front Rigging - Center Mount Rigging KIT, CTMTJ, Elevate Only For ASBA Seating ............. 68

Front Rigging - Footrest and Legrest Accessories ................................................................... 44

Page 5

Front Rigging - Front Rigging Hanger Hardware, Sector Style, Conventional & Contoura Seating

Front Rigging - Front Rigging Hanger Hdwr., Pin & Sector Style, Elev. Only For ADJASBA Stg. (After 7/4/05)

Front Rigging - Front Rigging Hanger Hdwr., Pin & Sector Style, Elev. Only For ASBA Stg. (Before 7/5/05)

Front Rigging - Front Rigging Non Hanger Hardware, PCTMT, Conventional & Contoura Seating

Front Rigging - Front Rigging Non Hanger Hdwr., Rigging Is Excluded From Chair, Conv. & Contoura Stg.

Front Rigging - Power Center Mount Rigging (PCTMT/PCTMT-L with FBCTMT One PC Flip-Up Footboard)

TABLE of CONTENTS

Page

Number

To order call toll free 1-800-333-6900, or www.invacare.com

Form No.

06-102

Description

Front Rigging - Footrest Support Assemblies, Sector Style ..................................................... 28

Front Rigging - Footrest Supports, Hemi PHW93 .................................................................... 30

Front Rigging - Front Rigging Hanger Hardware, Pin Style, Conventional & Contoura Seating 20

Front Rigging - Legrest Supports, Articulating (Hemi) - PHAL4A ............................................. 34

Front Rigging - Legrest Supports, AT5544 ............................................................................... 32

Front Rigging - Pivot/Slide Tube and 1650, 1350 Aluminum Footplates .................................. 41

Front Rigging - Pivot/Slide Tube and 1651 Composite Footplates .......................................... 39

Front Rigging - Power Articulating Legrest, ELRPW/ELRPW22 .............................................. 75

Front Rigging - Power Articulating Legrest, ELRPW/ELRPW22 Harness & Hardware ............ 78

Front Rigging - Power Center Mount Rigging (PCTMT/PCTMT-L) .......................................... 55

Front Rigging - Power Center Mount Rigging Mtg. Hdwr., PCTMT/PCTMT-L ......................... 66

Front Rigging - Reference Chart, 70STAPER .......................................................................... 15

Front Rigging - Reference Chart, AT5544, 70NHD, PHW93 ................................................... 13

Front Rigging - Reference Chart, PHAL4A .............................................................................. 14

Label Locations For TRBKTS Option ....................................................................................... 11

Page 6

TABLE of CONTENTS

Page

Number

To order call toll free 1-800-333-6900, or www.invacare.com

Form No.

06-102

Description

Packaging and Literature ......................................................................................................... 9

TRBKTS Option Clarification Reference .................................................................................. 12

Page 7

A: READ THIS FIRST (THIS CATALOG IS DIFFERENT!)

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 8

Frame Finishes and Touch-Up Paint

Color Number Part Number Bottle Size Frame Finish

Deep Purple.6 oz.103145608P

Cobalt Blue.6 oz.104631917P

Anthracite.6 oz.103337622P Wet Black.6 oz.103145024P

Red.6 oz.103145533P

Flat Black.6 oz.104632734P

Electric Red.6 oz.104632161P

Electric Blue.6 oz.104632062P

Electric Purple.6 oz.104632266P

Teflon Black.6 oz.1101320-NLA69P

Silver VeinN/AN/A71P

Lavender.6 oz.107389684P

Jeweled Green.6 oz.1101325101P

Denim Blue.6 oz.1101327102P

Electric Teal.6 oz.1101316104P

MIdnight Blue.6 oz.1101326105P

Black PrismN/AN/A115P

Sunkissed OrangeN/AN/A116P

Tangerine RedN/AN/A117P

Fruit FusionN/AN/A118P

Bubblegum PinkN/AN/A119P

Grape MadnessN/AN/A120P

Lolly Pop BlueN/AN/A121P

Cosmic BlueN/AN/A122P

Celestial PurpleN/AN/A123P

Vivid VioletN/AN/A124P

Emerald GreenN/AN/A125P

Shamrock GreenN/AN/A126P

Grasshopper GreenN/AN/A127P

Frame Finishes, Touch-Up Paints and Upholstery Options

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 9

Frame Finishes, Touch-Up Paints and Upholstery Options

Sparkle Frame Finishes

Color Number Frame Finish

Wet Black with Twilight Sparkle88P

Upholstery Options For A.S.B.A. Seating

Nylon Color

U240 Black

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 10

Packaging and Literature

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 11

Packaging and Literature

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

1036028 Carton, Cover 1 11 40131X161 Insert, Plain Pad 1 22 40131X011 Carton, Front Riggings 1 13

1015592 Bag, Poly (72" L x 35" W x 19" D) 1 14

1043198-NLA Tube, Paper 1 15

1012001 Carton, Joystick 1 16

1036027 Carton, Tray 1 27

1129590 Carton, Corner Reinforcement 1 48 00077X031 Warranty Card 1 1A

1114809 Manual, Owner's TDX w/ MK5 Electronics 1 1A

A - Not Shown

Whe

n adjusting or replacing parts, please refer to your Owner's Manual for assistance.

NOTE:

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 12

Label Locations For TRBKTS Option

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 13

TRBKTS Option Clarification Reference

TRBKTS Option was introduced 12/19/05 as an On-Chair option only.

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 14

NOTE: Calf pads with attaching hardware not included on legrest.

NOTE: Pivot/Slide tube attaching hardware not included.

NOTE: Pivot/Slide tube and footplates do not include heel loops. See footrest and legrest accessories.

1651 = Composite footplate with 9-7/8" curved pivot/slide tube.

AT5543 = Adjustable angle footplate with 9-7/8" straight pivot/slide tube.

1350 = Extra large footplate with "L" style pivot/slide tube.

Support Assemblies - AT5544, 70NHD, PHW93

Rigging Type AT5544 70NHD PHW93

8881126089

8881053149

8881045291

Right

See Note(s) A See Note(s) A See Note(s) A

8881126090

8881053148

8881045292

Left

See Note(s) A See Note(s) A See Note(s) A

A - Specify frame color when ordering, see page titled "Frame Finishes and Touch-Up Paints". NOTE:

Pivot/Slide Tube and Footplates For AT5544, 70NHD, PHW93

Footplate

Type

1651

16" W

1651

17-24" W

1350

17-24" W

AT5543

16-24" W

1062756102639510578791057869Right 1062757102639610578801057870Left 1062760108651510578811057871Right 2" Longer 1062761108651710578821057872Left 2" Longer 1121140108651610584231058421Right 4" Longer 1121141108651810584241058422Left 4" Longer

Front Riggings Reference Chart

For AT5544, 70NHD, PHW93

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 15

NOTE: Calf pads with attaching hardware not included on legrest.

NOTE: Pivot/Slide tube attaching hardware not included.

NOTE: Pivot/Slide tube and footplates do not include heel loops. See footrest and legrest accessories.

1650 = Aluminum footplate with "L" style pivot/slide tube.

1350 = Extra large footplate with "L" style pivot/slide tube.

AT5543 = Adjustable angle footplate with 13-7/8" straight pivot/slide tube.

Support Assembly - PHAL4A

Rigging

Type

PHAL4A (Chrome Only)

1031437Right 1031438Left

Pivot/Slide Tube and Footplates For PHAL4A

Footplate

Type

1650

16-24" W

1350

17-24" W

AT5543

16-24" W

109177710354561023907Right 109177810354571023908Left

Front Riggings Reference Chart

For PHAL4A

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 16

NOTE: Pivot/Slide tube attaching hardware not included.

NOTE: Pivot/Slide tube and footplates do not include heel loops. See footrest and legrest accessories.

1651 = Composite footplate with 9-7/8" curved pivot/slide tube.

Support Assemblies - 70STAPER

Rigging

Type

70STAPER

8881026996

Right

See Note(s) A

8881026997

Left

See Note(s) A

A - Specify frame color when ordering, see page titled "Frame Finishes and Touch-Up Paints". NOTE:

Pivot/Slide Tube and Footplates For 70ST TAPER

Footplate

Type

1651

16-17" W

1651

18-19" W

1651

20-24" W

105787910578691057859Right 105788010578701057860Left

105788110578711057861

Right

2" Longer

105788210578721057862

Left

2" Longer

Front Riggings Reference Chart

70STAPER

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 17

Front Rigging Hanger Hardware, Pin and Sector Style

Elevate Only For ASBA Seating (Before 7/5/05)

NOTE: Front rigging hangers and seat pans share the same mounting hardware, see Seat Pan and

Mounting Hardware page.

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 18

Front Rigging Hanger Hardware, Pin and Sector Style

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

1068435 Front Rigging Hanger Assembly,

Sector Style (12-21" Deep) - Right

1 11 A

1068436 Front Rigging Hanger Assembly,

Sector Style (12-21" Deep) - Left

1 11 A

1068437 Front Rigging Hanger Assembly,

Sector Style (22" Deep) - Right

1 11 A

1068438 Front Rigging Hanger Assembly,

Sector Style (22" Deep) - Left

1 11 A

1114766 Front Rigging Hanger Pin Style with Plug Button

(Hemi) (12-21" Deep) - Right

1 11

1114767 Front Rigging Hanger Pin Style with Plug Button

(Hemi) (12-21" Deep) - Left

1 11

1132339 Front Rigging Hanger

Pin Style with Plug Button (Hemi) 22" Deep - Right

1 11

1132340 Front Rigging Hanger

Pin Style with Plug Button (Hemi) 22" Deep - Left

1 11

1054571 Kit, Sector Block - Right 1 12 B

1054572 Kit, Sector Block - Left 1 12 B

1026907 Washer (1/4 x 1/2 x 1/16") 1 13

1052957 Screw, Hex Head (1/4-20 x 2") 1 14

1027097 Plug Button, Black (3/4") 1 15

A - Includes item 2

B - Includes items 3-4

NOTE:

Elevate Only For ASBA Seating (Before 7/5/05)

NOTE: Front rigging hangers and seat pans share the same mounting hardware, see Seat Pan and

Mounting Hardware page.

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 19

Front Rigging Hangers and Hardware

Pin & Sector Style For ADJASBA Seating (After 7/4/05)

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 20

Front Rigging Hangers and Hardware

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

1124723 Kit, Side Rail Cap Hardware (Pair) 1 11 A

Screw, Socket Head Cap w/ Patch (1/4-20 x 1-1/2") 1 42 Spacer (1/4 x 3/8 x 29/32") 1 43 Cap, Side Rail End 1 24 Plug Button, Black (1") 1 25 Block, Threaded 1 26

1125726 Kit, Front Rigging Hanger Mounting Hardware (Pair) 1 17 B

Screw, Socket Head Cap w/ Patch (1/4-20 x 1-1/2") 1 48 Spacer (1/4 x 3/8 x 3/16") 1 49 Cap, Side Rail End 1 210

Block, Threaded 1 211 1122602 Front Rigging Hanger Asbly., Sector Style - Right 1 112 C 1122603 Front Rigging Hanger Asbly., Sector Style - Left 1 112 C 1054571 Kit, Sector Block - Right 1 113 D 1054572 Kit, Sector Block - Left 1 113 D 1124401 Front Rigging Hanger

Pin Style with Plug Button (Hemi) - Right

1 114

1124402 Front Rigging Hanger

Pin Style with Plug Button (Hemi) - Left

1 114

1134426 Package, Plug Buttons, Black (3/4") 10 115

A - Includes items 2-6

B - Includes items 8-11

C - Includes item 13

D - Includes Sector Block, Screw and Washer

NOTE:

Pin & Sector Style For ADJASBA Seating (After 7/4/05)

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 21

Front Rigging Hanger Hardware, Pin Style

Conventional and Contoura Seating

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 22

Front Rigging Hanger Hardware, Pin Style

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

1124401 Front Rigging Hanger

Pin Style with Plug Button (Hemi) - Right

1 11

1124402 Front Rigging Hanger

Pin Style with Plug Button (Hemi) - Left

1 11

1125726 Kit, Front Rigging Hanger Mounting Hardware (Pair) 1 12 A

Screw, Socket Head Cap w/ Patch (1/4-20 x 1-1/2") 1 43

Spacer (1/4 x 3/8 x 3/16") 1 44

Cap, Side Rail End 1 25

Block, Threaded 1 26

A - Includes items 3-6

NOTE:

Conventional and Contoura Seating

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 23

Front Rigging Hanger Hardware, Sector Style

Conventional and Contoura Seating

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 24

Front Rigging Hanger Hardware, Sector Style

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

1122602 Front Rigging Hanger Asbly., Sector Style - Right 1 11 1122603 Front Rigging Hanger Asbly., Sector Style - Left 1 11 1125726 Kit, Front Rigging Hanger Mounting Hardware (Pair) 1 12 A

Screw, Socket Head Cap w/ Patch (1/4-20 x 1-1/2") 1 43

Spacer (1/4 x 3/8 x 3/16") 1 44

Cap, Side Rail End 1 25

Block, Threaded 1 26 1054571 Kit, Sector Block - Right 1 17 B 1054572 Kit, Sector Block - Left 1 17 B

A - Includes items 3-6

B - Kit includes sector block, screw and washer

NOTE:

Conventional and Contoura Seating

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 25

Power Center Mount Rigging, PCTMT

Non Hanger Hardware

Conventional and Contoura Seating

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 26

Power Center Mount Rigging, PCTMT

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

1125651 Kit, Side Rail Cap Hardware 2 11 A

Screw, Socket Head (1/4-20 x 1-1/2") 1 22

Spacer (1/4 x 3/8 x 29/32") 1 23

Cap, Side Rail End 1 24

Plug Button, Black (1") 1 25

Locknut (1/4-20) 1 26

A - Includes items 2-6

NOTE:

Non Hanger Hardware

Conventional and Contoura Seating

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 27

Front Rigging Non Hanger Hardware

When Front Rigging Is Excluded From Chair

Conventional and Contoura Seating

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 28

Front Rigging Non Hanger Hardware

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

1124723 Kit, Side Rail Cap Hardware (Pair) 2 11 A

Screw, Socket Head Cap w/ Patch (1/4-20 x 1-1/2") 1 42

Spacer (1/4 x 3/8 x 29/32") 1 43

Cap, Side Rail End 1 24

Plug Button, Black (1") 1 25

Block, Threaded 1 26

A - Includes items 2-6

NOTE:

When Front Rigging Is Excluded From Chair

Conventional and Contoura Seating

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 29

Footrest Support Assemblies

Sector Style

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 30

Footrest Support Assemblies

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

8881053149 Footrest Support Assembly, 70° Non-Tapered

Heavy Duty, Sector, Color - Right

1 11 A,C

8881053148 Footrest Support Assembly, 70° Non-Tapered

Heavy Duty, Sector, Color - Left

1 11 A,C

8881026996 Footrest Support Assembly, 70° Tapered, Sector,

Color - Right

1 11 A,D

8881026997 Footrest Support Assembly, 70° Tapered, Sector,

Color - Left

1 11 A,D

7930321 Screw, Socket Button Head (1/4-20 x 1-7/8") 25 12 1029501 Plug Button, Black (1") 1 13 1017148 Plug, Pivot 1 14 7930333 Locknut (1/4-20) 25 15 1025451 Screw, Slotted Hex Washer Head (#10-32 x 5/8") 1 26 7930314 Screw, Slotted Hex Head (#10-32 x 1/2") 25 17 1025454 Latch Housing - Right 1 18 1025455 Latch Housing - Left 1 18 1026124 Anti-Rattle Collar 1 19 1045267 Screw, Hex Head (1/4-20 x 3/4") 1 110 1026099 Spacer, Coved (1/4 x 11/16 x 1/2") 1 211 B 1020534 Insert, Threaded 1 112 1070759 Screw, Hex Head (1/4-20 x 1-1/2") 1 113 7930338 Nut, Acorn (1/4-20) 25 114 1026703 Kit, Pivot/Slide Tube Mounting Hardware (Pair) 2 115 1057846 Kit, Pivot/Slide Tube Mounting Hardware (Pair) 2 116 1026987 Impact Guard, 8" Long 1 1E

A - Specify frame color when ordering. See page titled "Frame Finishes and Touch-Up Paints."

B - Item 16 takes 4

C - See Image "A"

D - See Image "B"

E - Not Shown

NOTE:

Sector Style

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 31

PHW93 Hemi Footrest Supports

Color (Pin Style)

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 32

PHW93 Hemi Footrest Supports

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

1020719 Anti-Rattle, Black 1 11 1025716 Screw, Phillips Pan Head (#10-32 x 11/16") 1 12

47565X057 Bushing (7/32 x 3/8 x 11/32") 1 13

1025735 Locknut (#10-32) 1 14 1026114 Screw, Phillips Pan Head (#10-32 x 1/2") 1 15 1114749 Release Handle (Black) - Right 1 16 A 1114750 Release Handle (Black) - Left 1 16 A 1028846 Rivnut (#10-32) 1 17 1028707 Spring, Release - Right 1 18 1028708 Spring, Release - Left 1 18 1006490 Tip, Plastic, Black 1 19

15680X012 Collar, Anti-Rattle (7/8") 1 110

1070759 Screw, Hex Head (1/4-20 x 1-1/2") 1 111 1026099 Spacer, Coved (1/4 x 11/16 x 1/2") 1 212 1044214 Nut, Hex with Nylon Cap (1/4-20) 1 113 1020534 Insert, Threaded 1 114 1074143 Kit, Slide Tube Mounting Hardware 1 115

8881126089 Footrest Support Assembly, Hemi, Color - Right 1 1B 8881126090 Footrest Support Assembly, Hemi, Color - Left 1 1B

A - Includes items 2-4

B - Specify frame color when ordering, see page titled "Frame Finishes and Touch-Up Paints".

NOTE:

Color (Pin Style)

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 33

AT5544 Legrest Supports

Color (Sector Style)

16"-24" Wide Chairs

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 34

AT5544 Legrest Supports

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

1017187 Cover, Top 1 11 1028529 Screw, Phillips Pan Head (#8-32 x 3/8") 1 22

40363X000 Hex Nut (3/8"-16) 1 13

1058636 Washer, Nylon (25/64 x 7/8 x 1/32") 1 24

11919X000 Screw, Truss Head (3/8-16 x 1-1/2") 1 15

7930330 Locknut (5/16-24) 25 36 1026030 Screw, Lug (5/16-24 x 1-3/8") 1 17 1043556 Tube, Elevating Support (Black) - Right 1 18 1043557 Tube, Elevating Support (Black) - Left 1 18

8881048851 Tube, Elevating Support (Color) - Right 1 18 A 8881048852 Tube, Elevating Support (Color) - Left 1 18 A

1032266 Bracket, Legrest Pad Mounting 1 19

04528X002 Bracket, Release (Chrome) 1 110

1025451 Screw, Slotted Hex Washer Head (#10-32 x 5/8") 1 211 1025454 Latch Housing - Right 1 112 1025455 Latch Housing - Left 1 112 7930314 Screw, Slotted Hex Head (#10-32 x 1/2") 25 113

42326X001 Bar, Ratchet 1 114

7930336 Nut, Acorn (5/16-24) 25 115 1017148 Plug, Pivot 1 116 1029501 Plug Button, Black (1") 1 117 7930301 Package, Button Head Cap Screws (1/4-20 x 1-3/4") 25 118

8881045289 Bracket, Legrest Support - Right 1 119 A 8881045290 Bracket, Legrest Support - Left 1 119 A

1040831 Snap Ring 1 120 7930310 Washer, Nylon (5/16 x 11/16 x 1/16") 25 121 1040060 Tip, Black Plastic 1 122 1037485 Spring, Release 1 123 1037125 Cam, Legrest 1 124 1037126 Handle, Release 1 125 1096974 Kit, Ratchet Elevating Legrest 2 126 B 1096943 Instruction Sheet, Ratchet Kit 1 1C

8881045291 Legrest Support Assembly, Sector, Color - Right 1 1A,C 8881045292 Legrest Support Assembly, Sector, Color - Left 1 1A,C

A - Specify frame color when ordering. See page titled "Frame Finishes and Touch-Up Paints".

B - Includes items 10, 14, 15 and 20-25

C - Not Shown

NOTE:

Color (Sector Style)

16"-24" Wide Chairs

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 35

PHAL4A (Hemi) Articulating Legrest Supports

Chrome

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 36

PHAL4A (Hemi) Articulating Legrest Supports

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

1030979 Screw, Phillips Pan Head Tap (#10-32 x 3/4") 1 11 1022874 Bumper 1 12 1023428 Handle, Release, Chrome - Right 1 13 D 1023431 Handle, Release, Chrome - Left 1 13 D

47565X057 Bushing (7/32 x 3/8 x 11/32") 1 14 60279X003 Locknut (#10-32) 1 15 40163X008 Screw, Phillips Pan Head (#10-32 x 11/16") 1 16

1008935 Spring, Release - Right 1 17 1008936 Spring, Release - Left 1 17

67005X000 Rivnut (#10-32) 1 18 40163X002 Screw, Phillips Round Head (#10-32 x 1/2") 1 19

1023092 Legrest Support with Handle and Bumper (Chrome)

- Right

1 110 C,C1

1023093 Legrest Support with Handle and Bumper (Chrome)

- Left

1 110 C,C1

1027097 Plug Button, Black (3/4") 1 111 1006490 Tip, Plastic, Black 1 112 1040060 Tip, Black Plastic 1 113 1037126 Handle, Release 1 114 1049527 Washer, Nylon (3/8 x 3/4 x 1/16") 1 215 1022866 Screw, Socket Button Head (3/8-16 x 3/4") 1 216

40363X000 Hex Nut (3/8"-16) 1 317

1022846 Bar, Link, Chrome 1 118 1022877 Tube Support and Drive Link - Right 1 119 1022878 Tube Support and Drive Link - Left 1 119 1022854 Screw, Slotted Head Shoulder (1/2 x 1-1/8") 1 120

10261X000 Acorn Nut (5/16"-24) 1 121 04528X002 Bracket, Release (Chrome) 1 122

1040831 Snap Ring 1 123

47328X003 Bushing, Pivot (5/16 x 7/16 x 7/8") 1 124 42326X004 Bar, Ratchet - Right/Left 1 125

1037485 Spring, Release 1 126 1037125 Cam, Legrest 1 127 1013519 Washer, Nylon (5/16 x 11/16 x 1/16") 1 128 1024911 Decal, Smartleg 1 129 1014807 Screw, Hex Head (5/16-24 x 3-1/4") 1 130

48823X008 Spring, Leaf 1 131 47328X003 Bushing, Pivot (5/16 x 7/16 x 7/8") 1 132

1025133 Spacer, Legrest Pad 1 133

04526X019 Plate, Legrest Pad 1 134 60264X001 Locknut (5/16-24) 1 135

1025104 Bracket, Legrest (Chrome) 1 136

11232X009 Screw, Lug (5/16-24 x 1-3/8") 1 137

1022848 Slide Tube, Articulating (Chrome) - Right 1 138

Chrome

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 37

PHAL4A (Hemi) Articulating Legrest Supports

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

1022849 Slide Tube, Articulating (Chrome) - Left 1 138 1027377 Washer (#20) 1 139 1107321 Nut, Low Cap (5/16"-24) 1 140 1031437 Legrest Support Assembly, Articulating, Hemi,

Chrome - Right

1 141 C,C1,B

1031438 Legrest Support Assembly, Articulating, Hemi,

Chrome - Left

1 141 C,C1,B

8881091764 Pad, Legrest Vinyl - Right/Left 1 142 A

1068649 Screws, Phillips Head (#10-32 x 11/16") 2 143

A - Specify upholstery color U67 black when ordering.

B - Includes items 1-40

C - Release Handle revised 10/25/06. When a complete Legrest Assembly item #41 or a Legrest Support Tube Assembly

item #10 is ordered for chairs manufactured before 10/25/06, order the opposite side "Release Handle" item #3 to match.

C1 - Both Release Handles pictured to identify the difference. Release Handle after 10/24/06 does not require a rubber tip

D - Release Handle revised 10/25/06. For chairs manufactured before 10/25/06, order in pairs to match.

NOTE:

Chrome

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 38

Calf Pads and Attaching Hardware

NOTE: For replacement calf pads for Power Articulating Legrest, see Power Articulating Legrest page.

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 39

Calf Pads and Attaching Hardware

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

8881091759 Pad w/Cover and Screws, Legrest Vinyl (Pair) 2 11 A 8881091764 Pad, Legrest Vinyl - Right/Left 1 11 A

04526X019 Plate, Legrest Pad 1 12

7930330 Locknut (5/16-24) 25 13 1025133 Spacer, Legrest Pad 1 14 1032267 Spacer, Legrest Pad Mounting 1 15 1037110 Screw, Hex Head (5/16-24 x 3-1/2") 1 16 1028514 Screw, Hex Head (5/16-24 x 1-1/2") 1 17 1066591 Screws, Phillips Head (#10-32 x 11/16") 2 18

48823X008 Spring, Leaf 1 19

7930363 Package, Locknut (5/16"-24) 25 210 1025104 Bracket, Legrest (Chrome) 1 111 1014807 Screw, Hex Head (5/16-24 x 3-1/4") 1 112 1032266 Bracket, Legrest Pad Mounting 1 113

A - Specify upholstery color. See page titled "Frame Finishes, Touch-Up Paints and Upholstery Options".

NOTE:

NOTE: For replacement calf pads for Power Articulating Legrest, see Power Articulating Legrest page.

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 40

Pivot/Slide Tube and 1651 Composite Footplates

NOTE: Heel Loops are not included. See Footrest and Legrest Accessories.

NOTE: For complete pivot/slide tube and footplate assemblies, see Front Riggings Reference Charts

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 41

Pivot/Slide Tube and 1651 Composite Footplates

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

1057852 Pivot/Slide Tube, Curved End (9-7/8") (Steel) 1 11 1057854 Pivot/Slide Tube, Curved End 2" Longer (Steel) 1 11 1058418 Pivot/Slide Tube, Curved End 4" Longer (Steel) 1 11 1025457 Spacer, Coved (1/4 x 3/4 x 11/32") 1 22 1027097 Plug Button, Black (3/4") 1 13 7930323 Package, Locknut (1/4-20) 25 14 7930366 Screw, Socket Head Cap (1/4-20 x 2-1/4") 25 15 1026880 Footplate, Composite - Medium (7" W x 6" L) 1 16 A 1026881 Footplate, Composite - Large (8" W x 6" L) 1 16 B 1026879 Footplate, Composite - Small (6" W x 6" L) 1 16 C 1026880 Footplate, Composite - Medium (7" W x 6" L) 1 16 D 1026881 Footplate, Composite - Large (8" W x 6" L) 1 16 E

A - 16" Wide

B - 17" and Wider

C - 16"-17" Wide Tapered

D - 18"-19" Wide Tapered

E - 20" and Wider Tapered

NOTE:

NOTE: Heel Loops are not included. See Footrest and Legrest Accessories.

NOTE: For complete pivot/slide tube and footplate assemblies, see Front Riggings Reference Charts

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 42

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

1027097 Plug Button, Black (3/4") 1 11 1048834 Pivot/Slide Tube with Plug Button 1 12 A 1098906 Pivot/Slide Tube with Plug Button - 2" Longer 1 12 A 1086482 Pivot/Slide Tube with Plug Button - 4" Longer 1 12 A 1041526 Pivot/Slide Tube with Plug Button (Steel) 1 12 B 1041526 Pivot/Slide Tube with Plug Button (Steel) 1 12 C

44200X027 Footplate, Aluminum - Medium (7-3/4" W x 6" L) 1 13 44200X025 Footplate, Aluminum - Extra Large (8" W x 8-1/2" L)

- Right

1 13

44200X026 Footplate, Aluminum - Extra Large (8" W x 8-1/2" L)

- Left

1 13

1016346 Cap, Tube End (7/8") 1 14 D 1027095 Plug Button, Black (7/8") 1 14 E 1006981 Spring, Leaf 1 25 D 1036123 Spring, Leaf 1 15 E 7930354 Package, Phillips Head Screw (#8-32 x 3/8") 25 26 1070168 Push Plug, Footplate 1 17

A - Extra Large footplate for AT5544, 70, PHW93,

B - Extra Large footplate for PHAL4A

C - Standard Aluminum footplate for PHAL4

D - For Standard Aluminum footplate

E - For Extra Large footplate

NOTE:

Pivot/Slide Tube and 1650, 1350 Aluminum Footplates

NOTE: Heel Loops are not included. See Footrest and Legrest Accessories

NOTE: For complete pivot/slide tube and footplate assemblies, see Front Riggings Reference Charts.

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 43

AT5543 Adjustable Angle Footplates

70deg, 70deg MFX, PHW93, 90DEG, AT5544, PHAL4A Swingaway Supports

NOTE: Heel loops are not included. See Footrest and Legrest Accessories.

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 44

AT5543 Adjustable Angle Footplates

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

1062569 Footplate, Adjustable Angle - X-Large

(6-1/4" W x 8" L)

1 11

1029545 Screw, Socket Head Cap (1/4-20 x 3/4") 1 22 1058517 Clamp, Footplate 1 13 1082686 Nut, Hex Head (1/4-20 x 11/16") 1 24 7930333 Locknut (1/4-20) 25 15 1026907 Washer (1/4 x 1/2 x 1/16") 1 16 1048816 Screw, Nylon Adjustment (1/2-13 x 7/8") 1 17 1052102 Hinge, Footplate - Right 1 18 1052103 Hinge, Footplate - Left 1 18 7930321 Screw, Socket Button Head (1/4-20 x 1-7/8") 25 19 1026900 Washer (1/4 x 23/32 x 1/16") 1 110 1057855 Pivot/Slide Tube, Straight (9-7/8" Long - Steel) 1 111 1057856 Pivot/Slide Tube, Straight (11-7/8" Long - Steel) 1 111 1121135 Pivot/Slide Tube, Straight (13-7/8" Long - Steel) 1 111 1091745 Pivot/Slide Tube, Straight (13-7/8" Long - Steel) 1 111 A 7930313 Washer, Nylon (5/16 x 7/8 x 1/8") 25 112 1025457 Spacer, Coved (1/4 x 3/4 x 11/32") 1 113

See Chart #14 Pivot/Slide Tubes with Footplates 1 114

A - For PHAL4A only

NOTE:

#14 Pivot/ Slide Tube with Footplate Assemblies

Rigging Type Side

16" and Wider

6-1/4" X-Large

Footplate

1062756Right70, PHW93, AT5544 1062757Left

1062760Right

70, PHW93, AT5544,

2" Longer Slide Tube

1062761Left 1121140Right

70, PHW93, AT5544,

4" Longer Slide Tube

1121141Left 1091777RightPHAL4A 1091778Left

70deg, 70deg MFX, PHW93, 90DEG, AT5544, PHAL4A Swingaway Supports

NOTE: Heel loops are not included. See Footrest and Legrest Accessories.

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 45

Footplate

Type

Heel Loop w/

Ankle Strap

Pair #

Attaching Hardware

Pair #

Chair

Width

Heel Loop

Single #

Heel Loop

Pair #

Heel Loop w/

Ankle Strap Single # Rt.

Heel Loop w/

Ankle Strap

Single # Lt.

103593110359061035909103590810359121028412

16-17" W

Tapered

Composite

Small

(1651)

103593110359181035920103591910359171017621

16" W

18-19" W

Tapered

Composite

Medium

(1651)

103593110359301035933103593210359171017621

17-24" W

20-24" W

Tapered

Composite

Large

(1651)

10359071035918103592010359191035917101762116-24" W

Standard

Aluminum

(1650)

10552411035918103592010359191035917101762116-24" W

X-Large

Aluminum

(1350)

Attaching Hardware Part Numbers (Less AT5543)

Footplate Type Part Number Part Number Consists of

2 each Screw, PPH

(1/4-20 x 2-1/4")

2 each Spacer

(1/4 x 11/32 x 1-3/4")

2 each Locknut (1/4-20)

1035931Composite (1651)

2 each Screw, PPH

(1/4-20 x 2-1/2")

2 each Spacer

(1/4 x 11/32 x 1-3/4")

2 each Locknut (1/4-20)

1035907Standard Aluminum (1650)

2 each Screw, PPH

(1/4-20 x 2-1/4")

2 each Spacer

(1/4 x 11/32 x 1-3/4")

2 each Locknut (1/4-20)

1055241X-Large Aluminum (1350)

Footrest and Legrest Accessories

NOTE: Heel loops for Power Articulating Legrest located on Power Articulating Legrest page.

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 46

Footrest and Legrest Accessories

Heel Loops/Heel Loops w/ Ankle Straps and Hardware (For AT5543)

Footplate Type Part Number Part Number Consists of

2 each Heel Loops

4 each Screw, SHC

(10-32 x 1-1/2")

4 each Spacer

(1/4 x 5/16 x 1-3/32")

4 each Washer

(3/16 x 7/16 x 1/16")

1038245

Heel Loops w/ Hardware

Adjustable Angle Footplate (Pair)

AT5543 Adj. Angle

2 each Heel Loops

w/ Ankle Straps

4 each Screw, SHC

(10-32 x 1-1/2")

4 each Spacer

(1/4 x 5/16 x 1-3/32")

4 each Washer

(3/16 x 7/16 x 1/16")

1038246

Heel Loops w/ Ankle Straps &

Hardware

Adjustable Angle Footplate (Pair)

AT5543 Adj. Angle

Toe Loops (1345) and Attaching Hardware

Footplate

Type

Toe Loop

w/o Hardware

Single #

Toe Loop

w/o Hardware

Pair #

Attaching

Hardware

Part Number

Attaching Hardware

Consists of

4 each Screw, PPH

(10-32 x 7/8")

4 each Washer

(1/4 x 3/4 x 3/32")

4 each Locknut

(10-32)

1037089103708704572X025

1651, 1650, 1350,

Footplates

4 each Screw, PPH

(10-32 x 1/2")

4 each Washer

(1/4 x 3/4 x 3/32")

1104749103708704572X025

AT5543

Footplates

NOTE: Heel loops for Power Articulating Legrest located on Power Articulating Legrest page.

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 47

Footrest and Legrest Accessories

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

See Chart Heel Loops and Hardware (Less AT5543) 1 1A See Chart Attaching Hardware Part Numbers 1 1A See Chart Heel Loops/Heel Loops w/ Ankle Straps and

Hardware AT5543

1 1A

See Chart Toe Loops and Hardware 1 1A

1032243 Calf Strap w/ Hook and Loop (36" Long) 1 1A 1032215 H-Strap, 26" Long 1 1A,C 1032216 H-Strap, 31" Long 1 1A,D 1026987 Impact Guard, 8" Long 1 2A

A - Not Shown

C - For 16-18" wide seats

D - For 19" and wider seats

NOTE:

NOTE: Heel loops for Power Articulating Legrest located on Power Articulating Legrest page.

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 48

Front Rigging - Center Mount Rigging CTMTJ/CTMT-FJ

(CTMTJ/CTMT-FJ = 9-1/4" - 12" Range)

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 49

Front Rigging - Center Mount Rigging CTMTJ/CTMT-FJ

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

1121990 Center Mount Rigging Assembly, Junior

(CTMTJ/CTMT-FJ) ASBA/ADJASBA (9-1/4 - 12"

Range)

1 11 A

1123021 Legrest Support Assembly, Center Mount, Junior,

Black

1 12 B

1113376 Ring, Retainer (1/4 x 1/2 x 1/64") 1 23 1113373 Pin, Angle Adjustable A.S.B.A. 1 14 1110669 Bearing, Flanged (1/2 x 13/16 x 1/2") 1 25 1121984 Support, Junior Legrest (CTMTJ/CTMT-FJ) 1 16 1113372 Rack, Center Mount Rigging Angle Adjustable 1 17 1021344 Screw, Socket Head Cap (5/16-18 x 1-1/2") 1 48 1123042 Extension Tube and Footplate Assembly

w/ Heel Loop, Junior - Right

1 19 C

1123043 Extension Tube and Footplate Assembly

w/ Heel Loop, Junior - Left

1 19 C

1123044 Extension Tube, Footrest Short

(CTMTJ/CTMT-FJ = 9-1/4" - 12" Range)

(CTMT/CTMT-F = 12-1/4" - 15" Range) (PCTMT =

10" - 13" Range)

1 110

1021421 Screw, Phillips Pan Head (1/4-20 x 2-1/4") 1 211 1006477 Spacer (1/4 x 11/32 x 1-3/4") 1 212 1121996 Heel Loop, Center Mount Rigging 1 213 1078214 Screw, Hex Head Cap w/ Patch (1/4-20 x 1/2") 1 214 1025195 Locknut (1/4-20) 1 215 1121988 Footplate CTMTJ/CTMT-FJ (5-1/4" W x 8-13/16" L)

- Right

1 116 E

1121989 Footplate CTMTJ/CTMT-FJ (5-1/4" W x 8-13/16" L)

- Left

1 116 E

1120345 Center Mount Rigging Footplate Mounting Hardware

- Right

1 117 D

1121123 Center Mount Rigging Footplate Mounting Hardware

- Left

1 117 D

1021343 Screw, Socket Head Cap (5/16-18 x 1-1/4") 1 218 1113384 Hinge, Adjustable Angle - Right 1 119 1113385 Hinge, Adjustable Angle - Left 1 119 1047449 Spacer (1/4 x 3/8 x 3/16") 1 120 1065362 Locknut (1/4-28) 1 121 1096810 Screw, Socket Head (1/4-28 x 1-3/4") 1 122 1108122 Locknut (5/16-18) 1 223 1113530 Hinge Attachment 1 124 1021343 Screw, Socket Head Cap (5/16-18 x 1-1/4") 1 125

(CTMTJ/CTMT-FJ = 9-1/4" - 12" Range)

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 50

Front Rigging - Center Mount Rigging CTMTJ/CTMT-FJ

A - Includes items 2, 8 & 9

B - Includes items 3-7

C - Includes items 10-16 & 17

D - Includes items 18-25

E - Item #16 - Footplate design revised 2/28/07 to accommodate items 18 & 23. Replace footplates in pairs and order new

footplate hardware for chairs mfg. before 2/28/07.

NOTE:

(CTMTJ/CTMT-FJ = 9-1/4" - 12" Range)

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 51

Front Rigging - Center Mount Rigging

(CTMT/CTMT-F/CTMT-L/CTMT-FL)

(CTMT/CTMT-F = 12-1/4" - 15" Range) & (CTMT-L/CTMT-FL = 16" - 18-3/4"

Range)

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 52

Front Rigging - Center Mount Rigging

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

1117262 Center Mount Rigging Assembly (CTMT) (CTMT-F),

ASBA/ADJASBA (12-1/4 - 15" Range)

1 11 A

1117263 Center Mount Rigging (CTMT-L) (CTMT-FL),

ASBA/ADJASBA

(16" - 18-3/4" Range)

1 11 A

1120346 Legrest Support Assembly, Center Mount, Black 1 12 B 1113376 Ring, Retainer (1/4 x 1/2 x 1/64") 1 23 1113373 Pin, Angle Adjustable A.S.B.A. 1 14 1110669 Bearing, Flanged (1/2 x 13/16 x 1/2") 1 25 1113609 Support, Center Mount Rigging Legrest 1 16 1113372 Rack, Center Mount Rigging Angle Adjustable 1 17 1021344 Screw, Socket Head Cap (5/16-18 x 1-1/2") 1 48 1123034 Extension Tube and Footplate Assembly

with Heel Loop, Short - Right

1 19 C

1123035 Extension Tube and Footplate Assembly

with Heel Loop, Short - Left

1 19 C

1123036 Extension Tube and Footplate Assembly

with Heel Loop, Long - Right

1 19 C

1123037 Extension Tube and Footplate Assembly

with Heel Loop, Long - Left

1 19 C

1123044 Extension Tube, Footrest Short

(CTMTJ/CTMT-FJ = 9-1/4" - 12" Range)

(CTMT/CTMT-F = 12-1/4" - 15" Range) (PCTMT =

10" - 13" Range)

1 110

1123045 Extension Tube, Footrest Long

(CTMT-L/CTMT-FL = 16" - 18-3/4" Range)

(PCTMT-L = 14" - 17" Range)

1 110

(5-1/4" W x 9-5/8" L)

1 116 E

1113607 Footplate, Center Mount Rigging - Left

(5-1/4" W x 9-5/8" L)

1 116 E

1120345 Center Mount Rigging Footplate Mounting Hardware

- Right

1 117 D

1121123 Center Mount Rigging Footplate Mounting Hardware

- Left

1 117 D

1021343 Screw, Socket Head Cap (5/16-18 x 1-1/4") 1 218 1113384 Hinge, Adjustable Angle - Right 1 119 1113385 Hinge, Adjustable Angle - Left 1 119

(CTMT/CTMT-F/CTMT-L/CTMT-FL)

(CTMT/CTMT-F = 12-1/4" - 15" Range) & (CTMT-L/CTMT-FL = 16" - 18-3/4"

Range)

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 53

Front Rigging - Center Mount Rigging

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

1047449 Spacer (1/4 x 3/8 x 3/16") 1 120 1065362 Locknut (1/4-28) 1 121 1096810 Screw, Socket Head (1/4-28 x 1-3/4") 1 122 1108122 Locknut (5/16-18) 1 223 1113530 Hinge Attachment 1 124 1021343 Screw, Socket Head Cap (5/16-18 x 1-1/4") 1 125

A - Includes items 2, 8 & 9

B - Includes items 3-7

C - Includes items 10-16 & 17

D - Includes items 18-25

E - Item #16 - Footplate design revised 2/28/07 to accommodate items 18 & 23. Replace footplates in pairs and order new

footplate hardware for chairs mfg. before 2/28/07.

NOTE:

(CTMT/CTMT-F/CTMT-L/CTMT-FL)

(CTMT/CTMT-F = 12-1/4" - 15" Range) & (CTMT-L/CTMT-FL = 16" - 18-3/4"

Range)

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 54

Front Rigging - Center Mount Rigging (CTMT-F/CTMT-FL

with FBCTMT One PC Flip-Up Footboard)

(CTMT-F = 12-1/4" - 15" Range) & (CTMT-FL = 16" - 18-3/4" Range)

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 55

Front Rigging - Center Mount Rigging (CTMT-F/CTMT-FL

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

1148725 Legrest Support Assembly, Center Mount Rigging 1 11 A

Ring, Retainer (1/4 x 1/2 x 1/64") 1 22

Pin, Angle Adjustable A.S.B.A. 1 13

Bearing, Flanged (1/2 x 13/16 x 1/2") 1 24

Support, Center Mount Rigging Legrest 1 15

Rack, Center Mount Rigging Angle Adjustable 1 16

Screw, Socket Head Cap (5/16-18 x 1-1/2") 1 47 1021344 Screw, Socket Head Cap (5/16-18 x 1-1/2") 1 47 1148722 Footboard Assembly, FBCTMT (For CTMT-F

12-1/4" - 15" Range & PCTMT 10"-13" Range)

1 18 B

1148724 Footboard Assembly Long, FBCTMT (For CTMT-FL

16" - 18-3/4" Range & PCTMT-L 14"-17" Range)

1 18 B

1144608 Kit, Heel Stop and Extension Tube Mounting

Hardware

1 19 C

Locknut (5/16-18) 1 210

Bushing, Actuator Motor (3/8 x 3/4 x 5/32") 1 411

Screw, Hex Head (5/16-18 x 4") 1 212 1153789 Bracket, Heel Stop 1 213 F 1148711 Tube, Extension - Short (For CTMT-F 12-1/4" - 15"

Range & PCTMT 10"-13" Range)

1 214 G

1148721 Tube, Extension - Long (For CTMT-FL 16" - 18-3/4"

Range & PCTMT-L 14"-17" Range)

1 214 G

1144607 Tube, Vertical Support w/ Caps 1 115 D 1144609 Package, End Caps (1" Square) 10 116 1147134 Kit, Footboard Mounting Hardware 1 117 E

Screw, Socket Head (3/8-16 x 2-1/2") 1 118

Washer, Flat (3/8 x 11/16 x 1/16") 1 119

Washer, Nylon (3/8 x 3/4 x 1/16") 1 220

Bushing (3/8 x 5/8 x 1/2") 1 121

Locknut, Low Profile (3/8-16) 1 122

Screw, Socket Set Flat (5/16-18 x 1") 1 123

Locknut (5/16-18) 1 124 1114311 Footboard w/ Cover (11-1/4" Wide x 11-1/2" Long) 1 125

A - Includes items 2-7

B - Includes items 9, 13, 14, 15, 17 and 25

C - Includes items 10-12

D - Extension Tube and Vertical Support Tube includes Tube Caps at both ends

E - Includes items 18-24

F - Heel Stop Bracket was revised 2/6/08. It is recommended to order in pairs to match for chairs manufactured before 2/6/08.

G - End Caps are no longer used or required for the extension tube as of 4/9/08

NOTE:

with FBCTMT One PC Flip-Up Footboard)

(CTMT-F = 12-1/4" - 15" Range) & (CTMT-FL = 16" - 18-3/4" Range)

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 56

Power Center Mount Rigging, PCTMT/PCTMT-L

(PCTMT = 10"-13" Range) & (PCTMT-L = 14"-17" Range)

Conventional and Contoura Seating

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 57

Power Center Mount Rigging, PCTMT/PCTMT-L

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

1125683 Bottom Pulley Center Carriage Assembly 1 11 1124754 Bracket, Calf Pad Mounting 1 22 1134086 Screw, Socket Button Head w/ Patch (#10-32 x

1/2")

1 43

1078214 Screw, Hex Head Cap w/ Patch (1/4-20 x 1/2") 1 44

8881091764 Pad, Legrest Vinyl - Right/Left 1 25

1125628 Carriage, Footplate 1 16 1025195 Locknut (1/4-20) 1 37 1027097 Plug Button, Black (3/4") 1 38 1021344 Screw, Socket Head Cap (5/16-18 x 1-1/2") 1 49 1096795 Plug Button, Square, Black (1") 1 210 1123034 Extension Tube and Footplate Assembly

with Heel Loop, Short - Right

1 111 A,C

1123035 Extension Tube and Footplate Assembly

with Heel Loop, Short - Left

1 111 A,C

1123036 Extension Tube and Footplate Assembly

with Heel Loop, Long - Right

1 111 A,C

1123037 Extension Tube and Footplate Assembly

with Heel Loop, Long - Left

1 111 A,C

1123044 Extension Tube, Footrest Short

(CTMTJ/CTMT-FJ = 9-1/4" - 12" Range)

(CTMT/CTMT-F = 12-1/4" - 15" Range) (PCTMT =

10" - 13" Range)

1 112

1123045 Extension Tube, Footrest Long

(CTMT-L/CTMT-FL = 16" - 18-3/4" Range)

(PCTMT-L = 14" - 17" Range)

1 112

1021421 Screw, Phillips Pan Head (1/4-20 x 2-1/4") 1 213 1006477 Spacer (1/4 x 11/32 x 1-3/4") 1 214 1078214 Screw, Hex Head Cap w/ Patch (1/4-20 x 1/2") 1 215 1121996 Heel Loop, Center Mount Rigging 1 216 1047449 Spacer (1/4 x 3/8 x 3/16") 1 217 1065362 Locknut (1/4-28) 1 218 1113606 Footplate, Center Mount Rigging - Right

(5-1/4" W x 9-5/8" L)

1 119

1113607 Footplate, Center Mount Rigging - Left

(5-1/4" W x 9-5/8" L)

1 119

1025195 Locknut (1/4-20) 1 120 1120345 Center Mount Rigging Footplate Mounting Hardware

- Right

1 121 B

1121123 Center Mount Rigging Footplate Mounting Hardware

- Left

1 121 B

1113384 Hinge, Adjustable Angle - Right 1 122 1113385 Hinge, Adjustable Angle - Left 1 122

(PCTMT = 10"-13" Range) & (PCTMT-L = 14"-17" Range)

Conventional and Contoura Seating

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 58

Power Center Mount Rigging, PCTMT/PCTMT-L

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

1096810 Screw, Socket Head (1/4-28 x 1-3/4") 1 223 1021343 Screw, Socket Head Cap (5/16-18 x 1-1/4") 1 224 1113530 Hinge Attachment 1 225 1021343 Screw, Socket Head Cap (5/16-18 x 1-1/4") 1 226 1108122 Locknut (5/16-18) 1 227

A - Includes items 12-21

B - Includes items 22-27

C - Item #11 - Footplate design revised 2/28/07 to accommodate items 24 & 27. Replace footplates in pairs and order new

footplate hardware for chairs mfg. before 2/28/07.

NOTE:

(PCTMT = 10"-13" Range) & (PCTMT-L = 14"-17" Range)

Conventional and Contoura Seating

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 59

Front Rigging - Power Center Mount Rigging

(PCTMT/PCTMT-L with FBCTMT One PC Flip-Up

Footboard)

(PCTMT = 10"-13" Range) & (PCTMT-L = 14"-17" Range)

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 60

Front Rigging - Power Center Mount Rigging

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

1125683 Bottom Pulley Center Carriage Assembly 1 11 1124754 Bracket, Calf Pad Mounting 1 22 1134086 Screw, Socket Button Head w/ Patch (#10-32 x

1/2")

1 23

1078214 Screw, Hex Head Cap w/ Patch (1/4-20 x 1/2") 1 24

8881091764 Pad, Legrest Vinyl - Right/Left 1 25

1125628 Carriage, Footplate 1 16 1025195 Locknut (1/4-20) 1 37 1027097 Plug Button, Black (3/4") 1 38 1021344 Screw, Socket Head Cap (5/16-18 x 1-1/2") 1 49 1148722 Footboard Assembly, FBCTMT (For CTMT-F

12-1/4" - 15" Range & PCTMT 10"-13" Range)

1 110 A

1148724 Footboard Assembly Long, FBCTMT (For CTMT-FL

16" - 18-3/4" Range & PCTMT-L 14"-17" Range)

1 110 A

1144608 Kit, Heel Stop and Extension Tube Mounting

Hardware

1 111 B

Locknut (5/16-18) 1 212

Bushing, Actuator Motor (3/8 x 3/4 x 5/32") 1 413

Screw, Hex Head (5/16-18 x 4") 1 214 1153789 Bracket, Heel Stop 1 215 E 1148711 Tube, Extension - Short (For CTMT-F 12-1/4" - 15"

Range & PCTMT 10"-13" Range)

1 216 F

1148721 Tube, Extension - Long (For CTMT-FL 16" - 18-3/4"

Range & PCTMT-L 14"-17" Range)

1 216 F

1144607 Tube, Vertical Support w/ Caps 1 117 C 1144609 Package, End Caps (1" Square) 10 118 1147134 Kit, Footboard Mounting Hardware 1 119 D

Screw, Socket Head (3/8-16 x 2-1/2") 1 120

Washer, Flat (3/8 x 11/16 x 1/16") 1 121

Washer, Nylon (3/8 x 3/4 x 1/16") 1 222

Bushing (3/8 x 5/8 x 1/2") 1 123

Locknut, Low Profile (3/8-16) 1 124

Screw, Socket Set Flat (5/16-18 x 1") 1 125

Locknut (5/16-18) 1 126 1114311 Footboard w/ Cover (11-1/4" Wide x 11-1/2" Long) 1 127

A - Includes items 11, 15, 16, 17, 19 and 27

B - Includes items 12-14

C - Extension Tubes and Vertical Support Tube includes Tube Caps at both ends

D - Includes items 20-26

E - Heel Stop Bracket was revised 2/6/08. It is recommended to order in pairs to match for chairs manufactured before 2/6/08.

F - End Caps are no longer used or required for the extension tube as of 4/9/08

NOTE:

(PCTMT/PCTMT-L with FBCTMT One PC Flip-Up

Footboard)

(PCTMT = 10"-13" Range) & (PCTMT-L = 14"-17" Range)

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 61

Center Mount Rigging Mounting Hardware

CTMT/CTMT-L and CTMTJ

Elevate Only For ASBA Seating (Before 7/5/05)

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 62

Center Mount Rigging Mounting Hardware

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

1117264 Kit, Center Mount Rigging Mounting Hardware 1 11 A

Cable/Brake Assembly 1 12

Nut, Square (#10-32) 1 13

Spacer (5/16 x 3/16 x 3/4") 1 14

Pin, Quick Release (5" Long) 1 15

Screw, Socket Head (#10-32 x 1-1/4") 1 16

Cable Tie (11-1/2" Long) 1 27

Screw, Socket Head Shoulder (5/16 x 1-5/8") 1 18

Screw, Phillips Pan Head (#10-32 x 11/16") 1 29

Washer, Lock (3/16 x 5/16 x 1/16") 1 210

Locknut (1/4-20) 1 111

Housing, Ratchet 1 112

Bearing, Glide 1 213 1121079 Cable/Brake Assembly with Ratchet Housing and

Glide Bearing

1 114 B

A - Includes items 2-13

B - Includes items 2, 9, 10, 12 and 13

NOTE:

CTMT/CTMT-L and CTMTJ

Elevate Only For ASBA Seating (Before 7/5/05)

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 63

Center Mount Rigging Mounting Hardware

(CTMT-F/CTMT-FL) and (CTMT-FJ)

Elevate Only For ADJASBA Seating (After 7/4/05)

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 64

Center Mount Rigging Mounting Hardware

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

1124701 Kit, CTMT-F/CTMT-FL/CTMT-FJ Center Mount

Riggings Mounting Hardware

1 11 A

Cable Tie (11-1/2" Long) 1 22

Screw, Hex Head (5/16-18 x 5/8") 1 43

Spacer (5/16 x 7/16 x 3/8") 1 24

Block, Threaded 1 25

Screw, Socket Head Cap w/ Patch (1/4-20 x 1-1/2") 1 46

Spacer (1/4 x 3/8 x 29/32") 1 47

Cap, Side Rail End 1 28

Plug Button, Black (1") 1 29

T-Nut (5/16-18) 1 110

Screw, Socket Head (#10-32 x 1/2") 1 111

Bracket, Release Handle Mounting 1 112

Screw, Hex Head Cap w/ Patch (5/16-18 x 1/2") 1 113

Nut, Square (#10-32) 1 114

Pin, Quick Release (5" Long) 1 116

Locknut (1/4-20) 1 117

Screw, Socket Head Shoulder (5/16 x 1-5/8") 1 118

Cable/Brake Assembly 1 120

Screw, Phillips Pan Head (#10-32 x 11/16") 1 221

Washer, Lock (3/16 x 5/16 x 1/32") 1 222

Housing, Ratchet 1 123

Bearing, Glide 1 124

Screw, Socket Button Head (1/4-20 x 1-1/2") 1 125

Locknut (1/4-20) 1 126 1122675 Support, Center Mount Rigging (16"-19" Seat

Depths)

1 115 C

1136001 Support, Center Mount Rigging (Long) (19"-22" Seat

Depths)

1 115 D

1121079 Cable/Brake Assembly with Ratchet Housing and

Glide Bearing

1 119 B

1113622 Cable/Brake Assembly 1 120

40163X008 Screw, Phillips Pan Head (#10-32 x 11/16") 1 221

1028527 Washer, Lock (3/16 x 5/16 x 1/32") 1 222 1113389 Housing, Ratchet 1 123 1113383 Bearing, Glide 1 124

A - Includes items 2-14, 16-18 and 20-26

B - Includes items 20-24

C - Support used for 16"-19" deep seats

D - Support used for 19"-22" deep seats

NOTE:

(CTMT-F/CTMT-FL) and (CTMT-FJ)

Elevate Only For ADJASBA Seating (After 7/4/05)

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 65

Center Mount Rigging Mounting Hardware

CTMT-F/CTMT-FL and CTMT-FJ

Conventional and Contoura Seating

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 66

Center Mount Rigging Mounting Hardware

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

1124701 Kit, CTMT-F/CTMT-FL/CTMT-FJ Center Mount

Riggings Mounting Hardware

1 11 A

Cable Tie (11-1/2" Long) 1 22

Screw, Hex Head (5/16-18 x 5/8") 1 43

Spacer (5/16 x 7/16 x 3/8") 1 24

Block, Threaded 1 25

Screw, Socket Head Cap w/ Patch (1/4-20 x 1-1/2") 1 46

Spacer (1/4 x 3/8 x 29/32") 1 47

Cap, Side Rail End 1 28

Plug Button, Black (1") 1 29

T-Nut (5/16-18) 1 110

Screw, Socket Head (#10-32 x 1/2") 1 111

Bracket, Release Handle Mounting 1 112

Screw, Hex Head Cap w/ Patch (5/16-18 x 1/2") 1 113

Nut, Square (#10-32) 1 114

Pin, Quick Release (5" Long) 1 116

Locknut (1/4-20) 1 117

Screw, Socket Head Shoulder (5/16 x 1-5/8") 1 118

Cable/Brake Assembly 1 120

Screw, Phillips Pan Head (#10-32 x 11/16") 1 221

Washer, Lock (3/16 x 5/16 x 1/32") 1 222

Housing, Ratchet 1 123

Bearing, Glide 1 124

Screw, Socket Button Head (1/4-20 x 1-1/2") 1 125

Locknut (1/4-20) 1 126 1122675 Support, Center Mount Rigging (16"-19" Seat

Depths)

1 115

1136001 Support, Center Mount Rigging (Long) (19"-22" Seat

Depths)

1 115

1121079 Cable/Brake Assembly with Ratchet Housing and

Glide Bearing

1 119 B

1113622 Cable/Brake Assembly 1 120

40163X008 Screw, Phillips Pan Head (#10-32 x 11/16") 1 221

1028527 Washer, Lock (3/16 x 5/16 x 1/32") 1 222 1113389 Housing, Ratchet 1 123 1113383 Bearing, Glide 1 124

A - Includes items 2-14, 16-18 and 20-26

B - Includes items 20-24

NOTE:

CTMT-F/CTMT-FL and CTMT-FJ

Conventional and Contoura Seating

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 67

Power Center Mount Rigging Mounting Hardware,

PCTMT/PCTMT-L

Conventional and Contoura Seating

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 68

Power Center Mount Rigging Mounting Hardware,

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

1125783 Harness, PCTMT Actuator Extension

To TRECM

1 11

1125699 Motor, PCTMT Actuator 1 12 D 1146352 Motor, PCTMT Actuator (MK6i) 1 12 C,C1,D 1128351 Kit, PCTMT Actuator Motor Mounting Hardware 1 13 A

Screw, Socket Head Shoulder (3/8 x 2") 1 24

Locknut (5/16-18) 1 55

Stand-Off, Actuator Motor 1 16

Screw, Hex Head (5/16-18 x 5/8") 1 27

Bracket, PCTMT Mounting 1 18

Spacer 1 19

Link, Plate 1 110

Locknut (1/4-20) 1 111

Bushing (3/8 x 1/2 x 1-7/16") 1 112

Screw, Socket Head Shoulder (3/8 x 1-1/2") 1 113

Screw, Socket Head Shoulder (5/16 x 2-1/4") 1 114

Screw, Socket Head Shoulder (5/16 x 1-1/2") 1 115

Adjustable Clevis Rigging Assembly 1 116 1124706 Support, PCTMT Rigging 16"-19" Deep 1 117 1125675 Support, PCTMT Rigging 20"-22" Deep 1 117 1125629 Plate, Link 16"-19" Deep 1 118 1125659 Plate, Link 20"-22"" Deep 1 118 1128352 Kit, PCTMT Rigging Mounting Hardware 1 119 B

Screw, Hex Head (5/16-18 x 5/8") 1 320

Locknut (1/4-20) 1 121

Pin, Quick Release (1-3/4" Long) 1 122

Spacer (5/16 x 7/16 x 3/8") 1 123

Pin, Quick Release (2-1/2" Long) 1 124

Tube, Drive Link 1 125

Pin, Quick Release (5" Long) 1 126

A - Includes items 4-16

B - Includes items 20-26

C - For MK6i Electronics only. Includes the Actuator Motor, Bushings and the Integrated Actuator Module (IAM) attached to

the motor. The IAM is not available separately. NOTE: Part # 1140035 referenced on the motor is not available, refer to

part # 1146352.

C1 - The Actuator Motor does not require the Actuator Extension Harness item #1

D - Includes the Actuator Motor and Bushings. NOTE: Part # 1125698 referenced on the motor is not available, refer to part #

1125699.

NOTE:

PCTMT/PCTMT-L

Conventional and Contoura Seating

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 69

Center Mount Rigging KIT CTMTJ

Elevate Only For ASBA Seating

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 70

Center Mount Rigging KIT CTMTJ

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

1123022 Kit, Adjustable Length Junior Center Mount Rigging

(9-1/4"-12")

1 11 A,B

Cable Tie (11-1/2" Long) 1 22

Screw, Socket Head (#10-32 x 1-1/4") 1 13

Spacer (5/16 x 3/16 x 3/4") 1 14

Nut, Square (#10-32) 1 15

Pin, Quick Release (5" Long) 1 16

Cable/Brake Assembly with Ratchet Housing and

Glide Bearing

1 17

Screw, Socket Head Shoulder (5/16 x 1-5/8") 1 18

Locknut (1/4-20) 1 19

Center Mount Rigging Assembly, Junior

(CTMTJ/CTMT-FJ) ASBA/ADJASBA (9-1/4 - 12"

Range)

1 110

Instruction Sheet, Center Mount Rigging Kit 1 1

A - Includes items 2-10 and instruction sheet

B - Instruction Sheet Not Shown

NOTE:

Elevate Only For ASBA Seating

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 71

Center Mount Rigging KIT, CTMT/CTMT-L

Elevate Only For ASBA Seating

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 72

Center Mount Rigging KIT, CTMT/CTMT-L

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

1121009 Kit, Adjustable Length Center Mount Rigging

A.S.B.A. Short (12-1/4"-15")

1 11 B,C

Cable Tie (11-1/2" Long) 1 22

Screw, Socket Head (#10-32 x 1-1/4") 1 13

Spacer (5/16 x 3/16 x 3/4") 1 14

Nut, Square (#10-32) 1 15

Pin, Quick Release (5" Long) 1 16

Cable/Brake Assembly with Ratchet Housing and

Glide Bearing

1 17

Screw, Socket Head Shoulder (5/16 x 1-5/8") 1 18

Locknut (1/4-20) 1 19

Center Mount Rigging Assembly (CTMT) (CTMT-F),

ASBA/ADJASBA (12-1/4 - 15" Range)

1 110

Instruction Sheet, Center Mount Rigging Kit 1 1 1121010 Kit, Adjustable Length Center Mount Rigging

A.S.B.A. Long (16"-18-3/4")

1 11 A,B,C

Cable Tie (11-1/2" Long) 1 22

Screw, Socket Head (#10-32 x 1-1/4") 1 13

Spacer (5/16 x 3/16 x 3/4") 1 14

Nut, Square (#10-32) 1 15

Pin, Quick Release (5" Long) 1 16

Cable/Brake Assembly with Ratchet Housing and

Glide Bearing

1 17

Screw, Socket Head Shoulder (5/16 x 1-5/8") 1 18

Locknut (1/4-20) 1 19

Center Mount Rigging (CTMT-L) (CTMT-FL),

ASBA/ADJASBA

(16" - 18-3/4" Range)

1 110

Instruction Sheet, Center Mount Rigging Kit 1 1

A - Not available for low seat-to-floor models

B - Includes items 2-10 and instruction sheet

C - Instruction Sheet Not Shown

NOTE:

Elevate Only For ASBA Seating

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 73

Center Mount Rigging KIT, CTMT-F/CTMT-FL/CTMT-FJ

(Elevate Only For ADJASBA Stg. After 7/4/05), Conventional & Contoura

Seating

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 74

Center Mount Rigging KIT, CTMT-F/CTMT-FL/CTMT-FJ

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

1129453 Kit, Center Mount Rigging (CTMT-F 12-1/4"-15"

Range & 16"-19" Seat Depths)

1 11 A

1129454 Kit, Center Mount Rigging (CTMT-FL 16"-18-3/4"

Range & 16"-19" Seat Depths)

1 11 A

1129455 Kit, Center Mount Rigging (CTMT-FJ 9-1/4"-12"

Range & 16"-19" Seat Depths)

1 11 A

1134118 Kit, Center Mount Rigging (CTMT-F 12-1/4"-15"

Range & 19"-22" Seat Depths)

1 11 A

1134119 Kit, Center Mount Rigging (CTMT-FL 16"-18-3/4"

Range & 19"-22" Seat Depths)

1 11 A

1134120 Kit, Center Mount Rigging (CTMT-FJ 9-1/4"-12"

Range & 19"-22" Seat Depths)

1 11 A

1129451 Kit, CTMT-F/CTMT-FL/CTMT-FJ Center Mount

Riggings Mounting Hardware

1 12 B

Cable Tie (11-1/2" Long) 1 23

Screw, Hex Head (5/16-18 x 5/8") 1 44

Spacer (5/16 x 7/16 x 3/8") 1 25

Screw, Socket Button Head (1/4-20 x 1-1/2") 1 16

Locknut (1/4-20) 1 17

T-Nut (5/16-18) 1 18

Screw, Socket Head (#10-32 x 1/2") 1 19

Bracket, Release Handle Mounting 1 110

Screw, Hex Head Cap w/ Patch (5/16-18 x 1/2") 1 111

Nut, Square (#10-32) 1 112

Plug Button, Black (1") 1 213

Locknut (1/4-20) 1 114

Screw, Socket Head Shoulder (5/16 x 1-5/8") 1 115

Pin, Quick Release (5" Long) 1 116 1121079 Cable/Brake Assembly with Ratchet Housing and

Glide Bearing

1 117

1122675 Support, Center Mount Rigging (16"-19" Seat

Depths)

1 118

1136001 Support, Center Mount Rigging (Long) (19"-22" Seat

Depths)

1 118

1117262 Center Mount Rigging Assembly (CTMT) (CTMT-F),

ASBA/ADJASBA (12-1/4 - 15" Range)

1 119

1117263 Center Mount Rigging (CTMT-L) (CTMT-FL),

ASBA/ADJASBA

(16" - 18-3/4" Range)

1 119

1121990 Center Mount Rigging Assembly, Junior

(CTMTJ/CTMT-FJ) ASBA/ADJASBA (9-1/4 - 12"

Range)

1 119

1129450 Instruction Sheet, Center Mount Rigging Kit For

ADJASBA Seats

1 1C

(Elevate Only For ADJASBA Stg. After 7/4/05), Conventional & Contoura

Seating

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 75

Center Mount Rigging KIT, CTMT-F/CTMT-FL/CTMT-FJ

A - Includes items 1, 2, 17-19 and the Instruction Sheet

B - Includes items 3-16

C - Not Shown

NOTE:

(Elevate Only For ADJASBA Stg. After 7/4/05), Conventional & Contoura

Seating

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 76

Power Articulating Legrest ELRPW/ELRPW22

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 77

Power Articulating Legrest ELRPW/ELRPW22

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

1125436 Legrest Support Assembly, Sector, Black - Right 1 11 A 1125437 Legrest Support Assembly, Sector, Black - Left 1 11 A 1025454 Latch Housing - Right 1 12 1025455 Latch Housing - Left 1 12 1017423 Screw, Slotted Hex Washer Head (#10-32 x 1/2") 1 13 1025451 Screw, Slotted Hex Washer Head (#10-32 x 5/8") 1 24 1079203 Decal, Warning Pinch Point 1 15 1099685 Plug, Pivot 1 16 1091870 Screw, Socket Button Head w/ Patch

(1/4-20 x 3/4")

1 17

1125433 Cushion Pad - Right 1 18 1125434 Cushion Pad - Left 1 18 1025351 Screw, Socket Head Shoulder (5/16 x 1-1/4") 1 29 1025736 Locknut (1/4-20) 1 510 1025704 Washer, Flat (5/16 x 5/8 x 1/16") 1 111 1099671 Bearing, Flange (1/4 x 5/16" Long) 1 212 1026907 Washer (1/4 x 1/2 x 1/16") 1 1213 1012371 Washer, Nylon (3/8 x 7/8 x 1/16") 1 114 1125424 Plate, Pivot 1 115 1110746 Cover, Legrest Support - Right 1 116 1110747 Cover, Legrest Support - Left 1 116 1009837 Screw, Socket Button Head (1/4-20 x 1") 1 117 1091870 Screw, Socket Button Head w/ Patch

(1/4-20 x 3/4")

1 118

1101883 Glide 1 219 0175600 Spacer, Coved (5/16 x 3/4 x 3/8") 1 220 1110741 Extrusion, Internal Slide (14-1/4" Long) 1 121 1099702 Glide, Internal 1 122 1018846 Screw, Socket Button Head (#10-24 x 3/4") 1 123 1110972 Actuator Bracket Assembly 1 124 B 1082699 T-Nut (1/4-20) 1 1125 1100023 Screw, Button Head w/Patch (1/4-20 x 1/2") 1 1026 1087417 Screw, Socket Head Shoulder (5/16 x 1") 1 127 1110724 Motor, Actuator - Right 1 128 1110725 Motor, Actuator - Left 1 128

8881110977 Calf Pad Assembly with Mounting Hardware - Right 1 129 C

8881111715 Calf Pad Assembly with Mounting Hardware - Left 1 129 C 88804529X003 Pad, Legrest Vinyl - Right 1 130 88804529X004 Pad, Legrest Vinyl - Left 1 130

1110748 Hardware, Calf Pad Bracket 1 1D,F 1026033 Washer, Nylon (1/4 x 1/2 x 1/16") 1 431 1099700 Bracket, Calf Pad 1 132 1026114 Screw, Phillips Pan Head (#10-32 x 1/2") 1 233 1025765 Locknut (1/4-28) 1 134 1074191 Screw, Socket Countersunk Head (1/4-28 x 1/2") 1 135

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 78

Power Articulating Legrest ELRPW/ELRPW22

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

1099690 Block, Calf Pad 1 136 1111716 Bracket, Calf Pad Mounting - Right 1 137 1111717 Bracket, Calf Pad Mounting - Left 1 137 1078214 Screw, Hex Head Cap w/ Patch (1/4-20 x 1/2") 1 238 1110742 Bushing, Sleeve 1 139 1079151 Pin, Roll (5/64 x 5/8") 1 140 1121026 Extrusion, External (12-1/2" Long)

(ELRPW22 Before 7/22/04) and (ELRPW20 After 7/21/04)

1 141

1125435 Extrusion, External (14-1/2" Long) ELRPW22 1 141 1101114 Footplate Assembly - Right 1 142 E 1101115 Footplate Assembly - Left 1 142 E 1023965 Screw, Socket Head Cap (#10-32 x 1-1/2") 1 243 1028516 Washer (3/16 x 7/16 x 1/16") 1 244 1015629 Bushing 1 245 1101268 Heel Loop Assembly - Right 1 146 1101269 Heel Loop Assembly - Left 1 146 1060427 Footplate, Adjustable Angle - Large

(5-1/4" W x 8" L)

1 147

1029545 Screw, Socket Head Cap (1/4-20 x 3/4") 1 248 1008495 Screw, Socket Button Head (1/4-20 x 1-1/2") 1 149 1082686 Nut, Hex Head (1/4-20 x 11/16") 1 250 1052102 Hinge, Footplate - Right 1 151 1052103 Hinge, Footplate - Left 1 151 1048816 Screw, Nylon Adjustment (1/2-13 x 7/8") 1 152 1016301 Washer, Nylon (5/16 x 7/8 x 1/8") 1 253 1099678 Extrusion, Footplate Adapter 1 154 1126091 Legrest, Power Articulating (13"-20" Range) - Right

ELRPW

1 155

1126092 Legrest, Power Articulating (13"-20" Range) - Left

ELRPW

1 155

1126093 Legrest, Power Articulating (15"-22" Range) - Right

ELRPW22

1 155

1126094 Legrest, Power Articulating (15"-22" Range) - Left

ELRPW22

1 155

A - Includes items 2-7

B - Includes items 13, 25 and 26

C - Includes Items 25, 26 and 30-38

D - Includes Items 25, 26, 31-36, 38

E - Includes Items 10, 13, 25, 26 and 43-54

F - Not Shown

NOTE:

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 79

Power Articulating Legrest ELRPW/ELRPW22

Harnesses and Hardware

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 80

Power Articulating Legrest ELRPW/ELRPW22

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

1125679 Kit, ELRPW Power Articulating Legrest Harnesses

and Mounting Hardware

2 11 A,B

Screw, Socket Head Cap (#8-32 x 5/8") 1 42 Locknut (#8-32) 1 43 T-Nut (5/16-18) 1 24 Bracket, Wire Harness 1 45 Washer, Flat (5/16 x 5/8 x 1/16") 1 26 Screw, Hex Head Cap w/ Patch (5/16-18 x 1/2") 1 27 Cable Tie (5-5/8" Long) 1 28 Harness, ELRPW Power Legrest - Right 1 19 Harness, ELRPW Power Legrest - Left 1 19

A - Includes items 2-9

B - On 2/28/07 the Dual Leg Actuator Module (DLIAM) harness cable that plugs into item #9 ELRPW Power Legrest Harness

Assembly was lengthened from approximately 3" to 20" long to eliminate the need for the ELRPW Power Legrest Harness

Assemblies

NOTE:

Harnesses and Hardware

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 81

MK6i Electronics

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 82

Dual Legs Integrated Actuator Module (DLIAM) MK6i

For ELRPW Front Riggings

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 83

Dual Legs Integrated Actuator Module (DLIAM) MK6i

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

1140032 Module, Dual Legs Integrated Actuator (DLIAM)

MK6i

1 11 A

1021742 Screw, Phillips Pan Head (#4-40 x 1/2") 1 22

A - On 2/28/07 the Dual Leg Actuator Module (DLIAM) harness cable lengthened from approximately 3" to 20" long to

eliminate the need for the ELRPW Power Legrest Harness Assembly part numbers 1125656 RT and 1125657 LT

NOTE:

For ELRPW Front Riggings

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 84

ESC Elevating Seat Control Toggle Switch and

Mounting Hardware

Elevate Only For ASBA/ADJASBA Seating

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 85

ESC Elevating Seat Control Toggle Switch and

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

1126185 Switch, ESC Elevating Seat Control Toggle

For Formula ASBA/ADJASBA Seat

1 11 B

1125722 Toggle Switch Mounting Bracket Assembly 1 12 A 1091497 Kit, Quad Link Toggle Switch Mounting Hardware 1 13 C

Screw, Hex Head Cap w/ Patch (1/4-20 x 1/2") 1 44 Bracket, Toggle Switch Mounting 1 15 Bracket, Quad Link Toggle Switch Mounting 1 16 Screw, Phillips Pan Head (#10-32 x 1-3/8") 1 27 Locknut (1/4-20) 1 28 Locknut (#10-32) 1 29

1139684 Kit, Quad Link Toggle Switch Mounting Hardware 1 110 D

Locknut (#10-32) 1 211 Screw, Hex Head Cap w/ Patch (1/4-20 x 1/2") 1 212 Bracket, Toggle Switch Mounting 1 113 Screw, Phillips Pan Head w/Patch (#10-32 x 7/8") 1 214

A - Includes Bracket, Half Clamps and Screws. Individual components are not sold separately

B - ESC toggle switch connects directly into the Proximity Switch Sensor located on the "Battery Wire Harnesses, Sensor

Proximity Switch, Extension Cables and Energy Chain" page

C - Before 10/31/05 and includes items 4-9

D - After 10/30/05 and includes items 11-14

NOTE:

Mounting Hardware

Elevate Only For ASBA/ADJASBA Seating

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 86

TRSS Toggle and Mounting Hardware

Conventional Tilt and Tilt w/ BPO Option Before 1/17/05

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 87

TRSS Toggle and Mounting Hardware

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

1089384 Switch, Toggle Tilt Recline Single (TRSS) 1 11 1125722 Toggle Switch Mounting Bracket Assembly 1 12 A 1126179 Harness, Actuator Extension

To SAC or TRSS

1 13

1080635 Harness, Recline/Tilt Mercury Switch 1 14 1128350 Kit, Mercury Switch Brackets with Hardware

For Conventional Tilt Only with TRSS

1 15 B

Screw, Hex Head Cap w/ Patch (1/4-20 x 1/2") 1 26 Bracket, Mercury Switch 1 17 Washer (1/4 x 1/2 x 1/16") 1 28 Locknut (1/4-20) 1 29 Bracket, Drive Lockout 1 110 Screw, Hex Head (1/4-20 x 1-3/8") 1 211 Spacer, Coved (1/4 x 7/8 x 7/16") 1 212 Locknut (1/4-20) 1 213 Screw, Phillips Pan Head Tap (#10-32 x 1/2") 1 414 Bracket, Seat Pan Wiring 1 215

1091497 Kit, Quad Link Toggle Switch Mounting Hardware 1 116 C

Screw, Hex Head Cap w/ Patch (1/4-20 x 1/2") 1 417 Bracket, Toggle Switch Mounting 1 118 Bracket, Quad Link Toggle Switch Mounting 1 119 Screw, Phillips Pan Head (#10-32 x 1-3/8") 1 220 Locknut (1/4-20) 1 221 Locknut (#10-32) 1 222

1139684 Kit, Quad Link Toggle Switch Mounting Hardware 1 123 D

Locknut (#10-32) 1 224 Screw, Hex Head Cap w/ Patch (1/4-20 x 1/2") 1 225 Bracket, Toggle Switch Mounting 1 126 Screw, Phillips Pan Head w/Patch (#10-32 x 7/8") 1 227

A - Includes Bracket, Half Clamps and Screws. Individual components are not sold separately

B - Includes items 6-15

C - Before 10/31/05 and includes items 17-22

D - After 10/30/05 and includes items 24-27

NOTE:

Conventional Tilt and Tilt w/ BPO Option Before 1/17/05

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 88

TRSS Toggle and Mounting Hardware

Conventional Tilt & Tilt w/ BPO Option After 1/16/05

Mounting hardware after 1/16/05 will now accommodate the Personal Back 10 and DualFlex Backs from

Invacare.

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 89

TRSS Toggle and Mounting Hardware

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

1128357 Kit, Mercury Switch Brackets with Hardware

For Conventional Tilt Only with TRSS

1 11 A

Screw, Hex Head Cap w/ Patch (1/4-20 x 1/2") 1 23 Bracket, Mercury Switch 1 14 Washer (1/4 x 1/2 x 1/16") 1 25 Locknut (1/4-20) 1 26 Bracket, Drive Lockout 1 17 Screw, Hex Head (1/4-20 x 1-1/8") 1 28 Half Clamp, Non-Threaded Holes 1 19 Half Clamp, Threaded Holes 1 110 Bracket, Seat Pan Wiring 1 211

Screw, Phillips Pan Head Tap (#10-32 x 1/2") 1 412 1080635 Harness, Recline/Tilt Mercury Switch 1 113 1126179 Harness, Actuator Extension

To SAC or TRSS

1 114

1125722 Toggle Switch Mounting Bracket Assembly 1 115 C 1089384 Switch, Toggle Tilt Recline Single (TRSS) 1 116 1125770 Kit, Mercury Switch Mounting Hardware 1 12 B

Screw, Hex Head Cap w/ Patch (1/4-20 x 1/2") 1 23

Bracket, Mercury Switch 1 14

Washer (1/4 x 1/2 x 1/16") 1 25

Locknut (1/4-20) 1 26 1091497 Kit, Quad Link Toggle Switch Mounting Hardware 1 117 D

Screw, Hex Head Cap w/ Patch (1/4-20 x 1/2") 1 418

Bracket, Toggle Switch Mounting 1 119

Bracket, Quad Link Toggle Switch Mounting 1 120

Screw, Phillips Pan Head (#10-32 x 1-3/8") 1 221

Locknut (1/4-20) 1 222

Locknut (#10-32) 1 223 1139684 Kit, Quad Link Toggle Switch Mounting Hardware 1 124 E

Locknut (#10-32) 1 225

Screw, Hex Head Cap w/ Patch (1/4-20 x 1/2") 1 226

Bracket, Toggle Switch Mounting 1 127

Screw, Phillips Pan Head w/Patch (#10-32 x 7/8") 1 228

A - Includes items 3-12

B - Includes items 3-6

C - Includes Bracket, Half Clamps and Screws. Individual components are not sold separately

D - Before 10/31/05 and includes items 18-23

E - After 10/30/05 and includes items 25-28

NOTE:

Conventional Tilt & Tilt w/ BPO Option After 1/16/05

Mounting hardware after 1/16/05 will now accommodate the Personal Back 10 and DualFlex Backs from

Invacare.

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 90

TRSS Toggle and Mounting Hardware

Contoura Tilt

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 91

TRSS Toggle and Mounting Hardware

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

1089384 Switch, Toggle Tilt Recline Single (TRSS) 1 11 1125722 Toggle Switch Mounting Bracket Assembly 1 12 A 1126179 Harness, Actuator Extension

To SAC or TRSS

1 13

1080635 Harness, Recline/Tilt Mercury Switch 1 14 1128349 Kit, Mercury Switch Brackets with Hardware

For Contoura Tilt Only with TRSS

1 15 B

Screw, Hex Head Cap w/ Patch (1/4-20 x 1/2") 1 26

Bracket, Mercury Switch 1 17

Washer (1/4 x 1/2 x 1/16") 1 28

Locknut (1/4-20) 1 29

Bracket, Drive Lockout 1 110

Screw, Hex Head Cap w/ Patch (1/4-20 x 1/2") 1 211

Washer (1/4 x 1/2 x 1/16") 1 212

T-Nut (1/4-20) 1 213

Bracket, Seat Pan Wiring 1 214

Screw, Phillips Pan Head Tap (#10-32 x 1/2") 1 415 1091497 Kit, Quad Link Toggle Switch Mounting Hardware 1 116 C

Screw, Hex Head Cap w/ Patch (1/4-20 x 1/2") 1 417

Bracket, Toggle Switch Mounting 1 118

Bracket, Quad Link Toggle Switch Mounting 1 119

Screw, Phillips Pan Head (#10-32 x 1-3/8") 1 220

Locknut (1/4-20) 1 221

Locknut (#10-32) 1 222 1139684 Kit, Quad Link Toggle Switch Mounting Hardware 1 123 D

Locknut (#10-32) 1 224

Screw, Hex Head Cap w/ Patch (1/4-20 x 1/2") 1 225

Bracket, Toggle Switch Mounting 1 126

Screw, Phillips Pan Head w/Patch (#10-32 x 7/8") 1 227

A - Includes Bracket, Half Clamps and Screws. Individual components are not sold separately

B - Includes items 6-15

C - Before 10/31/05 and includes items 17-22

D - After 10/30/05 and includes items 24-27

NOTE:

Contoura Tilt

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 92

MK5 SAC-E and (MK6i) Elevate Integrated Actuator Module

(EIAM)

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 93

MK5 SAC-E and (MK6i) Elevate Integrated Actuator Module

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

1126033 Control, MK5 SAC-E 1 11 1140036 Module, Elevate Integrated Actuator (EIAM) MK6i 1 11 1125685 Kit, MK5 SAC-E/ MK6i EIAM Mounting Hardware 1 12 A

Screw, Phillips Pan Head Tap (#10-32 x 1/2") 1 23

Bracket, MK5 SAC-E/ EIAM MK6i Mounting 1 14

Stud Plate, Quad Link 1 25 1119418 Cable, Auxiliary Power 1 16 B

A - Includes items 3-5

B - Auxiliary Power cable not used with MK6i electronics

NOTE:

(EIAM)

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 94

MK5 SAC and Mounting Hardware

Conventional Tilt and Tilt w/ BPO Option Before 1/17/05

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 95

MK5 SAC and Mounting Hardware

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

1119458-NLA Control, MK5 SAC 1 11 C

1080635 Harness, Recline/Tilt Mercury Switch 1 12 1125772 Kit, SAC/Mercury Switch Mounting Hardware

For Conventional Tilt Only

1 13 A

Screw, Hex Head Cap w/ Patch (1/4-20 x 1/2") 1 25

Bracket, Mercury Switch 1 16

Washer (1/4 x 1/2 x 1/16") 1 27

Locknut (1/4-20) 1 28

Screw, Hex Head (1/4-20 x 1-3/8") 1 29

Washer (1/4 x 1/2 x 1/16") 1 210

Bracket, MK5 SAC Mounting 1 111

Screw, Phillips Pan Head (#4-40 x 3/8") 1 212

Bracket, Seat Pan Wiring 1 213

Screw, Phillips Pan Head Tap (#10-32 x 1/2") 1 414

Spacer, Coved (1/4 x 7/8 x 7/16") 1 215

Locknut (1/4-20) 1 216 1125770 Kit, Mercury Switch Mounting Hardware 1 14 B

Screw, Hex Head Cap w/ Patch (1/4-20 x 1/2") 1 25

Bracket, Mercury Switch 1 16

Washer (1/4 x 1/2 x 1/16") 1 27

Locknut (1/4-20) 1 28 1126179 Harness, Actuator Extension

To SAC or TRSS

1 117

1119418 Cable, Auxiliary Power 1 118

A - Includes items 5-16

B - Includes items 5-8

C - MK5 SAC was discontinued and replaced with a MK5 TAC. See page titled "MK5 TAC and Mounting Hardware" dated

01/06/06-01/25/06

NOTE:

Conventional Tilt and Tilt w/ BPO Option Before 1/17/05

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 96

MK5 SAC and Mounting Hardware

Conventional Tilt & Tilt w/ BPO Option 1/17/05-4/14/05

Mounting hardware after 1/16/05 will now accommodate the Personal Back 10 and DualFlex Backs from

Invacare.

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 97

MK5 SAC and Mounting Hardware

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

1128358 Kit, SAC/Mercury Switch Mounting Hardware

For Conventional Tilt Only

1 11 A

Screw, Hex Head Cap w/ Patch (1/4-20 x 1/2") 1 23

Bracket, Mercury Switch 1 14

Washer (1/4 x 1/2 x 1/16") 1 25

Locknut (1/4-20) 1 26

Screw, Hex Head Cap w/ Patch (1/4-20 x 1/2") 1 67

Bracket, Mercury Switch Mounting 1 18

Bracket, Controller 1 19

Screw, Phillips Pan Head (#4-40 x 3/8") 1 410

Washer (1/4 x 1/2 x 1/16") 1 611

Locknut (1/4-20) 1 612

Bracket, Standoff 1 213

Screw, Hex Head (1/4-20 x 1-1/8") 1 414

Half Clamp, Non-Threaded Holes 1 215

Half Clamp, Threaded Holes 1 216

Screw, Phillips Pan Head Tap (#10-32 x 1/2") 1 417

Bracket, Seat Pan Wiring 1 218 1123268 Harness, Tilt Mercury Switch 1 119

1119458-NLA Control, MK5 SAC 1 120 C

1126179 Harness, Actuator Extension

To SAC or TRSS

1 121

1119418 Cable, Auxiliary Power 1 122 1125770 Kit, Mercury Switch Mounting Hardware 1 12 B

Screw, Hex Head Cap w/ Patch (1/4-20 x 1/2") 1 23

Bracket, Mercury Switch 1 14

Washer (1/4 x 1/2 x 1/16") 1 25

Locknut (1/4-20) 1 26

A - Includes items 3-18

B - Includes items 3-6

C - MK5 SAC was discontinued and replaced with a MK5 TAC. See page titled "MK5 TAC and Mounting Hardware" dated

01/06/06-01/25/06

NOTE:

Conventional Tilt & Tilt w/ BPO Option 1/17/05-4/14/05

Mounting hardware after 1/16/05 will now accommodate the Personal Back 10 and DualFlex Backs from

Invacare.

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 98

MK5 SAC, Shroud Cover and Mounting Hardware

Conventional Tilt & Tilt w/ BPO Option 4/15/05-10/19/05

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 99

MK5 SAC, Shroud Cover and Mounting Hardware

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

1119458-NLA Control, MK5 SAC 1 11 E

1052041 Screw, Phillips Pan Head (#4-40 x 3/8") 1 42 1123268 Harness, Tilt Mercury Switch 1 13 1125770 Kit, Mercury Switch Mounting Hardware 1 14 A

Locknut (1/4-20) 1 25

Washer (1/4 x 1/2 x 1/16") 1 26

Bracket, Mercury Switch 1 17

Screw, Hex Head Cap w/ Patch (1/4-20 x 1/2") 1 28 1128362 Kit, TRECM/SAC Mounting Hardware 16-20" Wide

For Conventional Tilt Only

1 19 B,D

Screw, Phillips Pan Head (#10-32 x 3/8") 1 22

Screw, Phillips Pan Head (#4-40 x 3/8") 1 42

Bracket, Spreader Bar - Right 1 110

Bracket, Spreader Bar - Left 1 110

Half Clamp, Threaded Holes 1 211

Half Clamp, Non-Threaded Holes 1 212

Tube, Spreader Bar 16-20" Wide 1 113

Collar, Anti-Rattle (7/8") 1 214

Spacer, Coved (1/4 x 11/16 x 1/2") 1 415

Locknut (1/4-20) 1 216

Screw, Hex Head (1/4-20 x 1-3/8") 1 217

Screw, Hex Head (1/4-20 x 1-1/4") 1 418

TRECM/SAC/TAC/MK6i Connector Shroud

Mounting Tray Assembly

1 119

1128361 Kit, TRECM/SAC Mounting Hardware 20-24" Wide

For Conventional Tilt Only

1 19 B,D

Screw, Phillips Pan Head (#10-32 x 3/8") 1 22

Screw, Phillips Pan Head (#4-40 x 3/8") 1 42

Bracket, Spreader Bar - Right 1 110

Bracket, Spreader Bar - Left 1 110

Half Clamp, Threaded Holes 1 211

Half Clamp, Non-Threaded Holes 1 212

Tube, Spreader Bar 20-24" Wide 1 113

Collar, Anti-Rattle (7/8") 1 214

Spacer, Coved (1/4 x 11/16 x 1/2") 1 415

Locknut (1/4-20) 1 216

Screw, Hex Head (1/4-20 x 1-3/8") 1 217

Screw, Hex Head (1/4-20 x 1-1/4") 1 418

TRECM/SAC/TAC/MK6i Connector Shroud

Mounting Tray Assembly

1 119

1133807-NLA Kit, SAC Shrouds and Mounting Hardware 16-20"

Wide For Conventional Tilt Only

1 120 C,D,F,

Screw, Phillips Pan Head (#4-40 x 3/8") 1 42

Bracket, Spreader Bar - Right 1 110

Conventional Tilt & Tilt w/ BPO Option 4/15/05-10/19/05

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Page 100

MK5 SAC, Shroud Cover and Mounting Hardware

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

Bracket, Spreader Bar - Left 1 110

Half Clamp, Threaded Holes 1 211

Half Clamp, Non-Threaded Holes 1 212

Tube, Spreader Bar 16-20" Wide 1 113

Collar, Anti-Rattle (7/8") 1 214

Spacer, Coved (1/4 x 11/16 x 1/2") 1 415

Locknut (1/4-20) 1 216

Screw, Hex Head (1/4-20 x 1-3/8") 1 217

Screw, Hex Head (1/4-20 x 1-1/4") 1 418

TRECM/SAC/TAC/MK6i Connector Shroud

Mounting Tray Assembly

1 119

Screw, Thumb (#10-32 x 1/2") 1 121

Shroud, SAC Cover 1 122

Shroud, Back 1 123

Screw, Phillips Pan Head Tap (#10-32 x 1/2") 1 424

1133836-NLA Kit, SAC Shrouds and Mounting Hardware 20-24"

Wide For Conventional Tilt Only

1 120 C,D,F,

Screw, Phillips Pan Head (#4-40 x 3/8") 1 42

Bracket, Spreader Bar - Right 1 110

Bracket, Spreader Bar - Left 1 110

Half Clamp, Threaded Holes 1 211

Half Clamp, Non-Threaded Holes 1 212

Tube, Spreader Bar 20-24" Wide 1 113

Collar, Anti-Rattle (7/8") 1 214

Spacer, Coved (1/4 x 11/16 x 1/2") 1 415

Locknut (1/4-20) 1 216

Screw, Hex Head (1/4-20 x 1-3/8") 1 217

Screw, Hex Head (1/4-20 x 1-1/4") 1 418

TRECM/SAC/TAC/MK6i Connector Shroud

Mounting Tray Assembly

1 119

Screw, Thumb (#10-32 x 1/2") 1 121

Shroud, SAC Cover 1 122

Shroud, Back 1 123

Screw, Phillips Pan Head Tap (#10-32 x 1/2") 1 424 1119418 Cable, Auxiliary Power 1 125 1126179 Harness, Actuator Extension

To SAC or TRSS

1 126

Conventional Tilt & Tilt w/ BPO Option 4/15/05-10/19/05

Form No.

06-102

To order call toll free 1-800-333-6900, or www.invacare.com

Invacare Formula TRE User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
