Invacare 6302G User Manual
Invacare
®
TheraPure™Supine Whirlpool Tubs
Model 6302G
Model 6302GADH
User Manual EN
This manual MUST be given to the user of the product.
BEFORE using this product, read this manual and save for future reference.
CONTENTS
1 GENERAL 4
Symbols .................................................................................................................................................................................................................................................4
Limited Warranty ............................................................................................................................................................................................................................... 5
2SAFETY 6
General Guidelines ............................................................................................................................................................................................................................. 6
Important Safety Information...........................................................................................................................................................................................................6
3OVERVIEW 8
Features................................................................................................................................................................................................................................................. 8
Product Labeling.................................................................................................................................................................................................................................. 10
Typical Product Parameters ............................................................................................................................................................................................................. 11
Minimum Floor Space and Clearance Requirements..................................................................................................................................................................13
4INSTALLATION 14
Preparing the Work Area................................................................................................................................................................................................................. 14
Tub Dimensions and Connection Details ..................................................................................................................................................................................... 15
Securing the Tub ................................................................................................................................................................................................................................. 16
Leveling the Tub..................................................................................................................................................................................................................................16
Electrical Installation........................................................................................................................................................................................................................... 17
Plumbing Connection Details...........................................................................................................................................................................................................18
Plumbing Installation...........................................................................................................................................................................................................................18
Post Installation Checklist.................................................................................................................................................................................................................20
Invacare
®
TheraPure™Supine Whirlpool Tubs 2 Part No. 1167456
CONTENTS
5OPERATION 21
Overview .............................................................................................................................................................................................................................................. 21
Cleaning and Disinfecting.................................................................................................................................................................................................................. 23
Water Temperature Setting.............................................................................................................................................................................................................26
Filling the Tub ......................................................................................................................................................................................................................................27
Using the Shower/Massage Wand................................................................................................................................................................................................... 27
Using the Whirlpool Function ......................................................................................................................................................................................................... 28
Adjusting the Tub Height - 6302GADH Only .............................................................................................................................................................................28
6 INSPECTION, MAINTENANCE AND TROUBLESHOOTING 29
Safety Inspection Checklists .............................................................................................................................................................................................................29
Maintenance for 6302GADH Adjustable Height Rub Panels and Glide Pads.......................................................................................................................30
Troubleshooting..................................................................................................................................................................................................................................30
Maintenance Record...........................................................................................................................................................................................................................31
Part No. 1167456
3 Invacare
®
TheraPure™Supine Whirlpool Tubs
1 GENERAL
1 General
1.1 Symbols
Warnings
Signal words are used in this manual and apply to hazards or unsafe practices which could result in personal injury or property damage. See the
information below for definitions of the signal words.
DANGER
Danger indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury.
WARNING
Warning indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.
CAUTION
Caution indicates a potentially hazardous situation which, if not avoided, may result in property damage or minor injury or
both.
!
Invacare
IMPORTANT
Indicates a hazardous situation that could result in damage to property if it is not avoided.
Gives useful tips, recommendations and information for efficient, trouble-free use.
®
TheraPure™Supine Whirlpool Tubs 4 Part No. 1167456
1.2 Limited Warranty
1 GENERAL
This warranty is extended only to the original purchaser/user of our products.
This warranty gives you specific legal rights and you may also have other legal rights which vary from state to state.
Invacare Continuing Care, Inc. (ICC1) warrants its bathing/whirlpool products to be free from defects in materials and workmanship for a period of three
years from the date of purchase. Warranty obligation is limited to parts replacement only. Warranty replacement parts are only covered for the duration of
the warranty period. All purchased replacement parts will carry a 30-day warranty from the date of shipment. If within such warranty period any such
product shall be proven to be defective, such product shall be repaired or replaced, at ICCI's option. This warranty does not include any labor or shipping
charges incurred in replacement part installation or repair of any such product. ICCI's sole obligation and your exclusive remedy under this warranty shall be
limited to such repair and/or replacement.
For warranty service, please contact the dealer from whom you purchased your ICCI product. In the event you do not receive satisfactory warranty service,
please write directly to ICCI at the address below. Provide dealer's name, address, model number, date of purchase, indicate nature of the defect and, if the
product is serialized, indicate the serial number.
ICCI will issue a return authorization. The defective unit or parts must be returned for warranty inspection using the serial number, when applicable, as
identification within thirty days of return authorization date. DO NOT return products to our factory without our prior consent. C.O.D. shipments will be
refused; please prepay shipping charges.
LIMITATIONS AND EXCLUSIONS: THE WARRANTY SHALL NOT APPLY TO PROBLEMS ARISING FROM NORMAL WEAR OR FAILURE TO
ADHERE TO THE ENCLOSED INSTRUCTIONS. LABOR; EXPENDABLE ITEMS, I.E. SHOWER HOSES, VALVES, “O” RINGS, SEALS; PARTS BROKEN
DUE TO ABUSE OR IMPROPER USE; ITEMS THAT BECOME INOPERABLE DUE TO LACK OF MAINTENANCE, OR NON COMPATIBLE
CHEMICALS; STAINS DUE TO HARD WATER, IODINE SOLUTIONS, OR OTHER UNAPPROVED CHEMICALS; “SPIDER” CRACKS OR
“CRACKING” DUE TO MISHANDLING OR ABUSE. IN ADDITION, THE FOREGOING WARRANTY SHALL NOT APPLY TO SERIAL NUMBERED
PRODUCTS IF THE SERIAL NUMBER HAS BEEN REMOVED OR DEFACED; PRODUCTS SUBJECTED TO NEGLIGENCE, ACCIDENT, IMPROPER
OPERATION, MAINTENANCE OR STORAGE; OR PRODUCTS MODIFIED WITHOUT ICCI'S EXPRESS WRITTEN CONSENT INCLUDING, BUT
NOT LIMITED TO: MODIFICATION THROUGH THE USE OF UNAUTHORIZED PARTS OR ATTACHMENTS: PRODUCTS DAMAGED BY
REASON OF REPAIRS MADE TO ANY COMPONENT WITHOUT THE SPECIFIC CONSENT OF ICCI; PRODUCTS DAMAGED BY
CIRCUMSTANCES BEYOND ICCI'S CONTROL; PRODUCTS REPAIRED BY ANYONE OTHER THAN AN ICCI DEALER, SUCH EVALUATION
SHALL BE SOLELY DETERMINED BY ICCI.
THE FOREGOING EXPRESS WARRANTY IS EXCLUSIVE AND IN LIEU OF ANY OTHER WARRANTIES WHATSOEVER, WHETHER EXPRESS OR
IMPLIED, INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, AND THE SOLE
REMEDY FOR VIOLATIONS OF ANY WARRANTY WHATSOEVER, SHALL BE LIMITED TO REPAIR OR REPLACEMENT OF THE DEFECTIVE
PRODUCT PURSUANT TO THE TERMS CONTAINED HEREIN. THE APPLICATION OF ANY IMPLIED WARRANTY WHATSOEVER SHALL NOT
EXTEND BEYOND THE DURATION OF THE EXPRESS WARRANTY PROVIDED HEREIN. THE MANUFACTURER SHALL NOT BE LIABLE FOR
ANY CONSEQUENTIAL OR INCIDENTAL DAMAGES WHATSOEVER.
THIS WARRANTY SHALL BE EXTENDED TO COMPLY WITH STATE/PROVINCIAL LAWS AND REQUIREMENTS.
Part No. 1167456
PLEASE NOTE: THE WARRANTY BELOW HAS BEEN DRAFTED TO COMPLY WITH FEDERAL LAW
APPLICABLE TO PRODUCTS MANUFACTURED AFTER JULY 4, 1975.
5 Invacare
®
TheraPure™Supine Whirlpool Tubs
2 SAFETY
2 Safety
The Safety section contains important information for the safe operation and use of this product.
2.1 General Guidelines
WARNING
!
2.2 Important Safety Information
DO NOT use this product or any available optional equipment without first completely reading and understanding these
instructions and any additional instructional material such as owner’s manuals, service manuals or instruction sheets supplied with
this product or optional equipment. If you are unable to understand the warnings, cautions or instructions, contact a healthcare
professional, dealer or technical personnel before attempting to use this equipment - otherwise, injury or damage may occur.
ACCESSORIES WARNING
Invacare products are specifically designed and manufactured for use in conjunction with Invacare accessories. Accessories
designed by other manufacturers have not been tested by Invacare and are not recommended for use with Invacare products.
NOTICE
THE INFORMATION CONTAINED IN THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE.
DANGERS - ELECTRICAL SHOCK HAZARD
Grounding is required.
The installation and maintenance of the tub MUST be done by a qualified technician, certified electrician or plumber.
Disconnect electrical supply or turn off circuit breaker before installing or performing any maintenance on the tub.
The unit MUST be connected only to a supply circuit that is protected by a ground fault circuit-interrupter (GFCI).
Be certain ALL electrical work is performed by a qualified electrician and is in compliance with local electrical codes.
ALL electrical connections are to be water resistant
DANGER - RISK OF SCALDING
The hot water supply to the tub MUST not exceed 110°F (43° C) to protect the user from scalding.
Invacare
®
TheraPure™Supine Whirlpool Tubs 6 Part No. 1167456
2 SAFETY
WARNING - PLUMBING
Be certain all plumbing work is performed by a qualified plumber and is in compliance with local codes.
WARNING - FLOOR LOAD CAPACITY
The installation area MUST be able to support 66 pounds per square inch (45 n/cm²) load capacity of the tub. Otherwise, damage
may occur.
WARNINGS - SAFE USE
Use this unit only for its intended use as described in this manual.
If any part of the system is not functioning properly, DO NOT use the tub.
NEVER drop or insert any object into any opening.
DO NOT operate the tub without the jet assemblies installed.
The tub MUST be cleaned and disinfected after each use. Refer to Cleaning and Disinfecting
Keep hair and body away from the jet assemblies when pump is running.
Hyperthermia occurs when the internal temperature of the body reaches a level several degrees above the normal body
temperature of 98.6° F. The symptoms of hyperthermia include an increase of the internal temperature of the body, dizziness,
lethargy, drowsiness, and fainting.
The tub is specifically designed to be used with a bath lift. ICCI recommends use of the Stretcher Lift Model 1200 ONLY. Bath lifts
designed by other manufacturers are NOT to be used with the tub. Use the Stretcher Lift Model 1200 to maintain resident safety
and product utility. Refer to the lift owner’s manual for complete lift operating and safety instructions.
To reduce the risk of injury, DO NOT permit children or infirm persons to use this tub UNLESS THEY ARE SUPERVISED AT
ALL TIMES.
Recommended length of time spent in a bath is 5 to 10 minutes. However, if you or the person you are caring for becomes
nauseated or dizzy or the person develops a headache, get out of the tub at once and safely bring the body temperature back to
normal (98.6°F).
Seek medical attention if symptoms or sickness persist. Check with the physician BEFORE using the tub again.
Anyone under a doctor’s supervision, pregnant, or with poor health should check with a physician BEFORE using this tub.
on page 23.
Part No. 1167456
7 Invacare
®
TheraPure™Supine Whirlpool Tubs
3 OVERVIEW
Whirlpool ON/OFF Button
Fill Button
(Push-in once to auto-fill,
push-in and hold to add
additional water to tub)
Water Temperature Thermometer
Water Temperature Control
Tub Raise and Lower Buttons (Model 6302GADH ONLY)
3 Overview
3.1 Features
Invacare
®
TheraPure™Supine Whirlpool Tubs 8 Part No. 1167456
Whirlpool Jet
Overflow
Fill Spout
Shower/Massage Wand
Shower/Massage ON/OFF Button
Flow Control
Valve
Shower Spray
Adjustment
3 OVERVIEW
Part No. 1167456
9 Invacare
®
TheraPure™Supine Whirlpool Tubs
3 OVERVIEW
Labels located inside the Service Access Door
Label located on Interior Hardware
3.2 Product Labeling
Invacare
®
TheraPure™Supine Whirlpool Tubs 10 Part No. 1167456
