OWNER’S MANUAL
(105) MODEL 637R FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 11/14/2011
English 105
IMPORTANT
SAFETY RULES
Read, understand, and follow all instructions carefully before installing and using this product.
Krystal Clear™
Model 637R
Filter Pump
For illustrative purposes only.
Don’t forget to try these other fine Intex products: pools, pool accessories, inflatable pools and in-home toys, airbeds and boats available at fine retailers or visit our website.
IMPORTANT!
DO NOT RETURN PRODUCT TO STORE
To purchase parts and accessories or to obtain non-technical assistance,
Visit www.intexcorp.com
For technical assistance and missing parts call us toll-free (for U.S. and Canadian Residents):
1-800-234-6839
Monday through Friday, 8:30am to 5:00pm Pacific Time |
105-***-R1-1211 |
(105) MODEL 637R FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 11/14/2011
English 105
Warnings.......................................................................... |
3 |
Parts List & Reference.................................................... |
4-5 |
Setup Instructions......................................................... |
6-7 |
Maintenance..................................................................... |
7-8 |
Pool Care and Chemicals............................................... |
8 |
Long Term Storage.......................................................... |
8 |
Troubleshooting Guide................................................... |
9 |
Common Pool Problems................................................. |
10 |
General Aquatic Safety................................................... |
11 |
Limited Warranty............................................................. |
12 |
Intex Service Center Locations...................................... |
13 |
TABLE OF CONTENTS
SAVE THESE INSTRUCTIONS
Page 2
(105) MODEL 637R FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 11/14/2011
English 105
IMPORTANT SAFETY RULES
Read, Understand and Follow All Instructions Carefully Before Installing and Using this Product.
READ AND FOLLOW ALL INSTRUCTIONS
WARNING
•To reduce the risk of injury, do not permit children to use this product. Always supervise children and those with disabilities.
•Children must stay away from this product and electrical cord(s).
•Assembly and disassembly by adults only.
•Risk of electric shock. Connect only to a grounding type receptacle, this product is provided with a ground-fault circuit interrupter. If replacement of the plug or cord is needed, use only identical replacement parts.
•Always unplug this product from the electrical outlet before removing, cleaning, servicing or making any adjustment to the product.
•The unit is provided with a ground-fault circuit interrupter (GFCI). To test the GFCI, push the test button. The GFCI should interrupt power. Push the reset button, power should be restored. If the GFCI fails to operate in this manner. The GFCI is defective. If the GFCI interrupts power to the pump without the test button being pushed, a ground current is flowing, indicating the possibility of an electric shock. Do not use this pump. Disconnect the pump and have the problem corrected by a qualified service representative before using.
•Do not bury the electrical cord. Locate the cord where it will not be damaged by lawn mowers, hedge trimmers and other equipment.
•To reduce the risk of electric shock, the supply cord cannot be replaced. If the cord is damaged, the appliance should be replaced immediately.
•To reduce the risk of electric shock, do not use extension cords, timers, plug adaptors or converter plugs to connect unit to electric supply; provide a properly located outlet.
•Do not attempt to plug in or unplug this product while standing in water or when your hands are wet.
•Do not use an appliance leakage current interrupter (ALCI) in place of a GFCI since the ALCI will not protect people.
•Position this product away from the pool, so as to prevent children from climbing on it and accessing the pool.
•Do not operate this product when pool is occupied.
•This product is intended to be used only for the purposes described in the manual!
FAILURE TO FOLLOW THESE WARNINGS MAY RESULT IN PROPERTY DAMAGE, ELECTRIC SHOCK, ENTANGLEMENT OR OTHER SERIOUS INJURY OR DEATH.
CAUTION
This product is for use with storable pools only. Donot use with permanently-installed pools. A storable pool is constructed so that it is capable of being readily disassembled for storage and reassembled to its original integrity. A permanently-installed pool is constructed in or on the ground or in a buildingsuch that it cannot be readily disassembled for storage.
These product warnings, instructions and safety rules provided with the product represent some common risks of water recreation devices and do not cover all instances of risk and danger. Please use common sense and good judgement when enjoying any water activity.
SAFETY RULES
SAVE THESE INSTRUCTIONS
Page 3
(105) MODEL 637R FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 11/14/2011
English 105
PARTS LIST
1 |
2 |
3 |
4 |
5 |
6 |
7 |
8 |
9 |
10 |
11 |
NOTE: Drawings for illustration purpose only. Actual product may vary. Not to scale.
Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
This equipment has been tested and found to comply with the limits for Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and the receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
PARTS LIST
SAVE THESE INSTRUCTIONS
Page 4
(105) MODEL 637R FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 11/14/2011
English 105
PARTS REFERENCE
Before assembling your product, please take a few minutes to check the contents and become familiar with all the parts.
1
2
3
4
5
6 |
7 |
8 |
|
9 |
10 |
|
|||
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
9 |
11 |
NOTE: Drawings for illustration purpose only. Actual product may vary. Not to |
||||
scale. |
|
|
|
|
|
|
|
|
|
REF. NO. |
DESCRIPTION |
QTY. |
PARES PART NO. |
|
1 |
AIR RELEASE VALVE |
1 |
|
10460 |
|
|
|
|
|
2 |
VALVE O-RING |
1 |
|
10264 |
|
|
|
|
|
3 |
THREADED COVER |
1 |
|
10459 |
4 |
COVER SEAL |
1 |
|
10325 |
|
|
|
|
|
5 |
FILTER CARTRIDGE (59900) |
1 |
|
|
|
|
|
|
|
6 |
HOSE SEAL |
2 |
|
10134 |
7 |
HOSE CLAMP |
4 |
|
10122 |
|
|
|
|
|
8 |
HOSE |
2 |
|
10116 |
9 |
STRAINER CONNECTOR |
2 |
|
11070 |
10 |
POOL INLET NOZZLE |
1 |
|
11071 |
11 |
STRAINER GRID |
1 |
|
11072 |
When ordering parts, be sure to quote the model number and part numbers.
PARTS REFERENCE
SAVE THESE INSTRUCTIONS
Page 5
