Intermetro 9992DB General Manual
Item# _______________________________________________
Job _________________________________________________
End- and Side-Load Wire Bun Pan Racks
InterMetro Industries Corporation
North Washington Street
Wilkes-Barre, PA 18705
www.metro.com
13.42
METRO MOBILE
END- AND SIDE-LOAD
WIRE BUN PAN RACKS
• Cost Effective: Metro’s Bun Pan Racks
offer an economical solution for sturdy,
dependable storage and transport of bun
pans.
• Two Styles Available: End-load models
allow for optimum floor space utilization,
while side-load models offer a larger tray
landing area. Both styles can be loaded
on one side and unloaded from the other
for maximum efficiency and convenience.
• Choice of Slide Spacing: Each style is
available with a choice of slide spacings
— 1
1
/2" (38mm), which has a 38 pan
capacity, and 3" (76mm), which has a 20
pan capacity.
• UPS Shippable in one box for lower
freight costs.
• Quick, Secure Assembly: Units
assemble quick and easy without special
tools.
• Lightweight, Maneuverable: 5" (127mm)
swivel casters promote ease of mobility.
• Super Erecta Brite™Finish
Copyright © 1999 InterMetro Industries Corporation
Job____________________________________________
METRO MOBILE
END- AND SIDE-LOAD
WIRE BUN PAN RACKS
InterMetro Industries Corporation
North Washington Street
Wilkes-Barre, PA 18705
www.metro.com
L02-074
5/99 BJ
Printed in U.S.A.
Information and specifications are subject to change
without notice. Please confirm at time of order.
End- and Side-Load Wire Bun Pan Racks
13.42
SPECIFICATIONS:
• Slides, Frame, Posts: Super
Erecta Brite™finish with
Metrolac protective coating.
• Casters: 5" (127mm)
stem/swivel casters with
resilient tread.
DIMENSIONS:
Approx.
Height Width Length Slide Spacing Pan Capacity Pkd. Wt.
Model No. Description (in.) (mm) (in.) (mm) (in.) (mm) (in.) (mm) No. Size (in.) (lbs.) (kg)
RE1 End-Load 69 1750 213/
4
550 27 685 11/
2
40 38 18x26 61 28
RE3 End-Load 69 1750 213/
4
550 27 685 3 75 20 18x26 70 32
RS1 Side-Load 69 1750 191/
2
490 30 760 11/
2
40 38 18x26 61 28
RS3 Side-Load 69 1750 191/
2
490 30 760 3 75 20 18x26 70 32
Manufactured by:
InterMetro Industries Corp. Phone 570-825-2741
North Washington Street FAX 570-825-2852
Wilkes-Barre, PA 18705 For Product Information, call 1-800-433-2232
www.metro.com For Customer Service, call 1-800-992-1776
ACCESSORIES:
Model No.
9992DB 31/2" (90mm) Diameter Rubber Donut Bumper
9992N 51/2" (140mm) Diameter Rubber Donut Bumper
