Intel W2600CR2 User Manual

Revision 1.3

May 2012

Enterprise Platforms and Services Marketing

Intel® Workstation Board W2600CR2, W2600CR2L

Intel® Workstation System Family P4000CR2

Spares/Accessories List and Configuration Guide

A reference guide to assist customers in ordering the necessary components to
configure the Intel® Workstation Board W2600CR2 and the 4U Intel® Workstation Chassis.

Revision History

Jan ’12 – Rev 1.0 - Updated descriptions, images, sales ordering details. Posted to CDI.
Feb ‘12 – Rev 1.1 – Updated Software sections and added “Lite” SKU.

Apr ’12 – Rev 1.2 – Updated description details. Posted to CDI.

INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTION WITH INTEL® PRODUCTS.
NO LICENSE, EXPRESS OR IMPLIED, BY ESTOPPEL OR OTHERWISE, TO ANY INTELLECTUAL
PROPERTY RIGHTS IS GRANTED BY THIS DOCUMENT. EXCEPT AS PROVIDED IN INTEL'S
TERMS AND CONDITIONS OF SALE FOR SUCH PRODUCTS, INTEL ASSUMES NO LIABILITY
WHATSOEVER, AND INTEL DISCLAIMS ANY EXPRESS OR IMPLIED WARRANTY, RELATING TO
SALE AND/OR USE OF INTEL PRODUCTS INCLUDING LIABILITY OR WARRANTIES RELATING TO
FITNESS FOR A PARTICULAR PURPOSE, MERCHANTABILITY, OR INFRINGEMENT OF ANY
PATENT, COPYRIGHT OR OTHER INTELLECTUAL PROPERTY RIGHT.

Intel products are not intended for use in medical, life saving, life sustaining applications. Intel may make
changes to specifications and product descriptions at any time, without notice.

Intel server boards, server chassis, and processors may contain design defects or errors known as
errata, which may cause the product to deviate from published specifications. Current characterized
errata are available on request.

Intel, Intel Xeon, Pentium, and the Intel logo are trademarks or registered trademarks of Intel Corporation
or its subsidiaries in the United States and other countries.

*Other names and brands may be claimed as the property of others.
Copyright © 2012, Intel Corporation

2

Table of Contents:

1. SYSTEM PRODUCT ORDER CODES ........................................................................................................................... 4

1.1 PRODUCT DESCRIPTIONS – OVERVIEW ....................................................................................................................... 4

1.2 SUMMARY TABLE .......................................................................................................................................................... 4

1.3 AVAILABLE PRODUCTION BOARD ORDER CODE FOR W2600CR2 ............................................................................ 4

1.4 AVAILABLE PRODUCTION SYSTEM ORDER CODES FOR P4000CR2 FAMILY ............................................................. 5

2. SPARES AND ACCESSORIES ORDER CODES ........................................................................................................ 7

2.1 GENERAL SPARES AND ACCESSORIES ................................................................ ................................ ........................ 7

2.2 DRIVE/STORAGE SUBSYSTEM SPARES AND ACCESSORIES.......................................................................................... 9

2.3 EXPANSION MODULES: IO MODULE, SAS MODULE, RMM4, TPM ......................................................................... 10

2.4 VMWARE VSPHERE* AND VCENTER* SERVER SKUS ............................................................................................... 14

2.5 SYMANTEC BACKUP EXEC 2010 SKUS .................................................................................................................... 16

3

1. System Product Order Codes

Product Code

FF

HDD

# of

HDD

Power supply

Rails

RAID

Storage

Activation

Expander

Available

P4304CR2LFJNL*

4U

3.5”

Fixed

4

1x1200W

None

1,0,10+

None

No

Q1’12

P4304CR2LFKN

4U

3.5”

Fixed

4

1x1600W

None

1,0,10+

None

No

Q3’12

P4304CR2LFJN

4U

3.5”

Fixed

4

1x1200W

None

1,0,10+

None

No

Q2’12

P4304CR2LFGN

4U

3.5”

Fixed

4

1x750W

None

1,0,10+

None

No

Q2’12


Product Code

MM
UPC
EAN

MOQ

Description

W2600CR2

916028

735858239301

5032037034074

1

W2600CR2 Spare Board with Dual NIC, Single Pack

 Supports Dual Intel® Xeon E5-2600 processors 150W max

 Intel® C600 series chipset

 16 DDR3 DIMM slots

 8 PCIe slots:

Slot1: PCIe3 x16 electrical (x16 slot), FL, DW
Slot2/4/6: PCIe3 x8 or x0 electrical (x8 slot), FL
Slot3/5/7: PCIe3 x8 or x16 electrical (x16 slot), FL, DW

 x16 mode requires PCIe Gen3 x8 MUX
 x16 mode borrows x8 from adjacent Slot

Slot8: PCIe2 x4 electrical (x8 slot): HL

 Intel® SAS ROC Mezz slot

 Intel® IO Module Mezz slot supports Gen 1 speed.

1.1 Product Descriptions – Overview

The Intel® Workstation Board W2600CR2 is an Expert Workstation supporting two E5-2600 processors.
It will be offered fully integrated in a 4U pedestal chassis. The chassis is not sold separately.

The Intel® Workstation Board W2600CR2L is a “Lite” SKU, similar to the W2600CR2 except that it does
not have the rear IO connector for IO mezzanine modules. This board will be available in an integrated
system for a limited time only. It will be discontinued within 90 days from launch and replaced with the
Intel® Workstation Board W2600CR2.

1.2 Summary Table

For a quick overview, all configuration options described in this document are summarized in the table
below. For more details such as MM numbers and product order codes, please refer to the other
sections in this document.

*Note: This SKU will be available TTM for a limited time only. It will be discontinued within 90 days from launch and
replaced with P4304CR2LFJN.

1.3 Available Production Board Order Code for W2600CR2

4

 8 SCU SATA/SAS ports (4 ports functional w/ no storage

keys and 4 ports require storage keys)

 2 SATA 6G AHCI ports

 Intel® Dual Gigabit Ethernet with Intel® Virtualization

Technology

 Integrated Baseboard Management Controller with IPMI 2.0

 Option for advanced management functions with KVM and

dedicated NIC for remote management

 Onboard HD audio support

 USB3.0 support

 Firewire 1394b support

 eSATA support

Target availability: Q2’12

W2600CR2L

921559

735858247184

5032037042147

1

W2600CR2L Spare Board with Dual NIC, Single Pack

 Same functionality as W2600CR2 with the exception

of the IO Module Mezzanine slot.

This board will be available for a limited time only.
It will be discontinued within 90 days from launch and

replaced with W2600CR2.
Target availability: Q1’12


Product Code

MM
UPC
EAN

MOQ

Description

*Demonstration only,
see description for
configuration details.

P4304CR2LFJNL*

921563

735858247214

5032037042178

1

Integrated Intel® Server System
W2600CR2L board in Intel “Union Peak L-WS” 4U

pedestal chassis

 Supports up to 4x3.5'' Fixed HDD

 Power distribution board (FUPPDBHC)

 Two CPU heat sinks (AUPSRCBTA)

 Four 3.5" drive carriers

 Control panel

 Front Bezel (FUPBEZELFIX)

 Fixed System fans included (FUPNHFANCPU)

 Processor/memory air duct

 One 1200W PSU, Platinum level efficiency

This system will be available for a limited time only.

1.4 Available Production System Order Codes for P4000CR2 Family

The systems described in this section are pre-integrated at the factory. The chassis is not sold
separately.

EPSD Romley Chassis and Systems shipped to the US & Canada will contain North American power
cords. North American customers no longer need to order skus ending in “NA” to receive power cords
on Romley products.

5

It will be discontinued within 90 days from launch and
replaced with P4304CR2LFJN.

Target availability: Q1’12

*Demonstration only,
see description for
configuration details.

P4304CR2LFJN

916047

735858239233

5032037034005

1

Integrated Intel® Server System
W2600CR2 board in Intel “Union Peak L-WS” 4U

pedestal chassis

 Supports up to 4x3.5'' Fixed HDD

 Power distribution board

 Two CPU heat sinks (AUPSRCBTA)

 Four 3.5" drive carriers

 Control panel

 Front Bezel

 Fixed System fan included

 Processor/memory air duct

 One 1200W PSU, Platinum level efficiency

Target availability: Early Q2’12

*Demonstration only,
see description for
configuration details.

P4304CR2LFGN

916048

735858239240

5032037034012

1

Integrated Intel® Server System
W2600CR2 board in Intel “Union Peak L-WS” 4U

pedestal chassis

 Supports up to 4x3.5'' Fixed HDD

 Power distribution board

 Two CPU heat sinks (AUPSRCBTA)

 Four 3.5" drive carriers

 Control panel

 Front Bezel

 Fixed System fan included

 Processor/memory air duct

 One 750W PSU, Platinum level efficiency

Target availability: Early Q2’12

.
*Demonstration only,
see description for
configuration details.

P4304CR2LFKN

916046

735858248624

5032037043366

1

Integrated Intel® Workstation System
W2600CR2 board in Intel “Union Peak L-WS” 4U pedestal
chassis

 Supports up to 4x3.5'' Fixed HDD

 Power distribution board

 Two CPU heat sinks (AUPSRCBTA)

 Four 3.5" drive carriers

 Control panel

 Front Bezel

 Fixed System fan included

 Processor/memory air duct

 One 1600W PSU, Platinum level efficiency

Target availability: Q3’12.
