Revision 1.1
June, 2012
Enterprise Platforms and Services Division - Marketing
Intel® Server Board S2600IP and
Intel® Workstation Board W2600CR
Technical Product Specification
Intel order number G34153-003
Revision History Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS
ii
Date
Revision
Number
Modifications
February, 2012
1.0
Initial release.
June, 2012
1.1
Updated thermal management and environmental summary.
Updated onboard power connectors information.
Revision History
Disclaimers
Information in this document is provided in connection with Intel® products. No license, express or implied, by
estoppel or otherwise, to any intellectual property rights is granted by this document. Except as provided in Intel's
Terms and Conditions of Sale for such products, Intel assumes no liability whatsoever, and Intel disclaims any
express or implied warranty, relating to sale and/or use of Intel products including liability or warranties relating to
fitness for a particular purpose, merchantability, or infringement of any patent, copyright or other intellectual property
right. Intel products are not intended for use in medical, lifesaving, or life sustaining applications. Intel may make
changes to specifications and product descriptions at any time, without notice.
Designers must not rely on the absence or characteristics of any features or instructions marked "reserved" or
"undefined." Intel reserves these for future definition and shall have no responsibility whatsoever for conflicts or
incompatibilities arising from future changes to them.
This document contains information on products in the design phase of development. Do not finalize a design with
this information. Revised information will be published when the product is available. Verify with your local sales office
that you have the latest datasheet before finalizing a design.
The Intel® Server Board S2600IP and Intel® Workstation Board W2600CR may contain design defects or errors
known as errata which may cause the product to deviate from published specifications. Current characterized errata
are available on request.
This document and the software described in it is furnished under license and may only be used or copied in
accordance with the terms of the license. The information in this manual is furnished for informational use only, is
subject to change without notice, and should not be construed as a commitment by Intel Corporation. Intel
Corporation assumes no responsibility or liability for any errors or inaccuracies that may appear in this document or
any software that may be provided in association with this document.
Except as permitted by such license, no part of this document may be reproduced, stored in a retrieval system, or
transmitted in any form or by any means without the express written consent of Intel Corporation.
Intel, Pentium, Itanium, and Xeon are trademarks or registered trademarks of Intel Corporation.
*Other brands and names may be claimed as the property of others.
Copyright © 2012 Intel Corporation
Revision 1.1
Intel order number G34153-003
Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS Table of Contents
iii
Table of Contents
1. Introduction ........................................................................................................................ 1
1.1 Chapter Outline ...................................................................................................... 1
1.2 Server Board Use Disclaimer ................................................................................. 1
2. Product Overview ............................................................................................................... 2
2.1 Product Feature Set ............................................................................................... 3
2.1.1 Main Board Connector and Component Layout ...................................................... 5
2.1.2 Main Board Rear I/O Layout ................................................................................... 8
2.1.3 Server Board Mechanical Drawings ..................................................................... 10
3. Functional Architecture ................................................................................................... 19
3.1 Processor Support ............................................................................................... 20
3.1.1 Processor Socket Assembly ................................................................................. 20
3.1.2 Processor Population Rules ................................................................................. 22
3.1.3 Processor Initialization Error Summary................................................................. 22
3.2 Processor Functions Overview ................................................................ ............. 25
3.2.1 Intel® QuickPath Interconnect ............................................................................... 25
3.2.2 Integrated Memory Controller (IMC) and Memory Subsystem .............................. 26
3.2.3 Processor Integrated I/O Module (IIO) .................................................................. 32
3.3 Intel® C600-A Chipset Functional overview .......................................................... 33
3.3.1 Digital Media Interface (DMI) ................................................................................ 34
3.3.2 PCI Express* Interface ......................................................................................... 34
3.3.3 Serial ATA (SATA) Controller ............................................................................... 34
3.3.4 Serial Attached SCSI (SAS)/SATA (SCU) Controller ............................................ 35
3.3.5 AHCI ................................................................................................ .................... 35
3.3.6 Rapid Storage Technology ................................................................................... 35
3.3.7 PCI Interface ........................................................................................................ 36
3.3.8 Low Pin Count (LPC) Interface ............................................................................. 36
3.3.9 Serial Peripheral Interface (SPI) ........................................................................... 36
3.3.10 Compatibility Modules (DMA Controller, Timer/Counters, Interrupt Controller) ..... 36
3.3.11 Advanced Programmable Interrupt Controller (APIC) ........................................... 36
3.3.12 Universal Serial Bus (USB) Controllers ................................................................ 36
3.3.13 Gigabit Ethernet Controller ................................................................................... 37
3.3.14 RTC ..................................................................................................................... 37
3.3.15 GPIO .................................................................................................................... 37
3.3.16 Enhanced Power Management ............................................................................ 37
3.3.17 Manageability ....................................................................................................... 37
3.3.18 System Management Bus (SMBus* 2.0) .............................................................. 37
3.3.19 Integrated NVSRAM controller ............................................................................. 38
3.3.20 Virtualization Technology for Directed I/O (Intel® VT-d) ........................................ 38
3.3.21 JTAG Boundary-Scan .......................................................................................... 38
Revision 1.1
Intel order number G34153-003
Table of Contents Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS
iv
3.3.22 KVM/Serial Over Lan (SOL) Function ................................................................... 38
3.3.23 On-board SAS/SATA Support and Options .......................................................... 38
3.4 PCI Subsystem .................................................................................................... 39
3.5 Network Interface Controller ................................................................................. 40
3.5.1 Network Interface ................................................................................................. 40
3.6 I/O Module Support (not avaiable for Intel® Server Board S2600IP4L and Intel®
Workstation Board W2600CR2L) ........................................................................................... 41
3.7 SAS ROC Module Support ................................................................................... 42
3.8 HD Audio Support (Intel® Workstation Board W2600CR Only) ............................. 43
3.9 USB3.0 Support (Intel® Workstation Board W2600CR Only) ................................ 44
3.10 IEEE1394b Support (Intel® Workstation Board W2600CR Only) .......................... 45
4. Platform Management Overview ..................................................................................... 46
4.1 Server Management Function Architecture .......................................................... 46
4.1.1 Feature Support ................................................................................................... 46
4.1.2 Basic and Advanced Features .............................................................................. 48
4.1.3 Integrated BMC Hardware: Emulex* Pilot III ......................................................... 49
4.2 Server Management Functional Specifications ................................ ..................... 51
4.2.1 BMC Internal Timestamp Clock ............................................................................ 51
4.2.2 System Event Log (SEL) ...................................................................................... 52
4.2.3 Sensor Data Record (SDR) Repository ................................................................ 52
4.2.4 Field Replaceable Unit (FRU) Inventory Device ................................................... 52
4.2.5 BMC Beep Codes ................................................................................................ 52
4.2.6 Diagnostic Interrupt (NMI) Button ......................................................................... 53
4.2.7 BMC Watchdog .................................................................................................... 53
4.3 Sensor Monitoring ................................................................................................ 54
4.3.1 Overview .............................................................................................................. 54
4.3.2 Core Sensor List for EPSD Platforms Based on Intel® Xeon® Processor E5
4600/2600/2400/1600/1400 Product Families ..................................................................... 54
4.3.3 BMC System Management Health Monitoring ...................................................... 56
4.3.4 Processor Sensors ............................................................................................... 56
4.4 Thermal and Acoustic Management ..................................................................... 60
4.4.1 Set Throttling Mode .............................................................................................. 60
4.4.2 Altitude ................................................................................................................. 60
4.4.3 Set Fan Profile ..................................................................................................... 60
4.4.4 Fan PWM Offset ................................................................................................... 61
4.4.5 Quiet Fan Idle Mode ............................................................................................. 61
4.4.6 Thermal Sensor Input for Fan Speed Control ....................................................... 61
4.4.7 Power Supply Status\Health Sensors ................................................................... 62
4.4.8 System Event Sensor ........................................................................................... 63
4.5 Platform Management Interface ........................................................................... 65
4.5.1 Channel Management .......................................................................................... 65
Revision 1.1
Intel order number G34153-003
Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS Table of Contents
v
4.5.2 User Model ........................................................................................................... 65
4.5.3 LAN Interface ....................................................................................................... 66
4.6 BMC Firmware Update ................................................................ ......................... 76
4.6.1 The BMC firmware release Number ..................................................................... 76
4.6.2 Boot Recovery Mode ............................................................................................ 76
4.6.3 Force Firmware Update Jumper ........................................................................... 77
4.6.4 Fast Firmware Update over USB .......................................................................... 77
4.7 Advanced Management Feature Support ............................................................. 78
4.7.1 Enabling Advanced Management Features .......................................................... 78
4.7.2 Keyboard, Video, Mouse (KVM) Redirection ........................................................ 78
4.7.3 Media Redirection ................................................................................................ 79
4.8 Intel® Intelligent Power Node Manager (NM) ........................................................ 81
4.8.1 Overview .............................................................................................................. 81
4.9 EU Lot 6 Mode ..................................................................................................... 82
5. System Security ................................................................................................................ 84
5.1 BIOS Password Protection ................................................................................... 84
5.2 Trusted Platform Module (TPM) Support .............................................................. 85
5.2.1 TPM security BIOS ............................................................................................... 85
5.2.2 Physical Presence ................................................................................................ 86
5.2.3 TPM Security Setup Options ................................................................................ 86
5.3 Intel® Trusted Execution Technology .................................................................... 88
6. Connector/Header Locations and Pin-outs .................................................................... 90
6.1 Power Connectors ................................................................................................ 90
6.1.1 Main Power Connector ......................................................................................... 90
6.1.2 CPU Power Connectors ....................................................................................... 90
6.1.3 Add-in Card Power Connectors ............................................................................ 90
6.2 Front Panel Header and Connectors .................................................................... 91
6.2.1 Front Panel Header .............................................................................................. 91
6.2.2 Front Panel USB Connector ................................................................................. 92
6.2.3 Local Control Panel Connector ............................................................................. 92
6.3 On Board Storage Connectors ............................................................................. 92
6.3.1 SATA Connectors: 6Gbps .................................................................................... 92
6.3.2 Multiport Mini-SAS/SATA Connectors .................................................................. 93
6.3.3 Intel® RAID C600 Upgrade Key Connector ........................................................... 94
6.3.4 HSBP_I2C Header ................................................................ ............................... 94
6.3.5 HDD LED Header ................................................................................................. 94
6.3.6 Internal Type- A USB Connector .......................................................................... 94
6.3.7 Internal eUSB SSD Header .................................................................................. 95
6.4 Management and Security Connectors ................................................................ 95
6.4.1 RMM4_Lite Connector ................................................................ ......................... 95
6.4.2 RMM4_NIC Connector ......................................................................................... 95
Revision 1.1
Intel order number G34153-003
Table of Contents Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS
vi
6.4.3 TPM Connector .................................................................................................... 96
6.4.4 PMBus* Connector ............................................................................................... 96
6.4.5 Chassis Intrusion Header ..................................................................................... 96
6.4.6 IPMB Connector ................................................................................................... 96
6.5 FAN Connectors ................................................................................................... 96
6.5.1 System FAN Connectors ...................................................................................... 97
6.5.2 CPU FAN Connector ............................................................................................ 97
6.6 Serial Port and Video Connectors ........................................................................ 97
6.6.1 Serial Port A Connector (DB9, for Intel® Server Board S2600IP only) .................. 97
6.6.2 Serial Port B Connector ........................................................................................ 98
6.6.3 Video Connector (For Intel® Server Board S2600IP only) ..................................... 98
6.6.4 Internal Video header (For Intel® Workstation Board W2600CR only) .................. 99
7. Jumper Blocks ................................................................................................................ 100
7.1 BIOS Default and Password Reset Usage Procedure ........................................ 101
7.1.1 Set BIOS to default (Clearing the CMOS) ........................................................... 101
7.1.2 Clearing the Password ....................................................................................... 101
7.2 Force BMC Update Procedure ........................................................................... 102
7.3 BIOS Recovery Jumper ...................................................................................... 102
7.4 ME Force Update Jumper .................................................................................. 103
8. Intel® Light Guided Diagnostics .................................................................................... 105
8.1 5-volt Stand-by LED ........................................................................................... 105
8.2 Fan Fault LED .................................................................................................... 105
8.3 CPU Fault LED ................................................................................................... 105
8.4 DIMM Fault LEDs ............................................................................................... 107
8.5 System ID LED, System Status LED and POST Code Diagnostic LEDs ............ 107
8.5.1 System ID LED ................................................................................................... 108
8.5.2 System Status LED ............................................................................................ 109
8.5.3 POST Code Diagnostic LEDs ............................................................................. 110
9. Design and Environmental Specifications .................................................................... 111
9.1 Products Design Specifications .......................................................................... 111
9.2 MTBF ................................................................................................................. 111
9.3 Server Board Power Requirements .................................................................... 114
9.3.1 Processor Power Support................................................................................... 115
9.4 Power Supply Output Requirements .................................................................. 115
9.4.1 Output Power/Currents ....................................................................................... 115
9.4.2 Cross Loading .................................................................................................... 115
9.4.3 Standby Output .................................................................................................. 116
9.4.4 Voltage Regulation ............................................................................................. 116
9.4.5 Dynamic Loading ............................................................................................... 116
9.4.6 Capacitive Loading ............................................................................................. 117
9.4.7 Grounding .......................................................................................................... 117
Revision 1.1
Intel order number G34153-003
Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS Table of Contents
vii
9.4.8 Closed loop stability ........................................................................................... 117
9.4.9 Residual Voltage Immunity in Standby mode ..................................................... 117
9.4.10 Common Mode Noise ......................................................................................... 117
9.4.11 Soft Starting ....................................................................................................... 118
9.4.12 Zero Load Stability Requirements ...................................................................... 118
9.4.13 Ripple/Noise ....................................................................................................... 118
9.4.14 Timing Requirements ......................................................................................... 118
Appendix A: Integration and Usage Tips ............................................................................ 121
Appendix B: BMC Sensor Tables ......................................................................................... 122
Appendix C: Platform Specific BMC Appendix ................................................................... 147
Introduction
Product ID
....................................................................................................................... 147
........................................................................................................................ 147
IPMI Channel ID Assignments .......................................................................................... 147
ACPI S3 Sleep State Support
Processor Support for Intel® Server Board S2600IP
Supported Chassis
........................................................................................................... 147
Chassis-specific sensors
Hot-plug fan support
......................................................................................................... 148
Fan redundancy support
Fan domain definition
HSC Availability
....................................................................................................... 149
................................................................................................................ 151
........................................................................................... 147
......................................................... 147
.................................................................................................. 148
................................................................................................... 148
Power unit support ............................................................................................................ 152
Redundant Fans only for Intel® Server Chassis ................................................................ 152
Fan Fault LED support...................................................................................................... 152
Memory Throttling support ................................................................................................ 153
Introduction
Product ID
....................................................................................................................... 153
........................................................................................................................ 153
IPMI Channel ID Assignments .......................................................................................... 153
ACPI S3 Sleep State Support
Processor Support for Intel® Server Board W2600CR
Supported Chassis
........................................................................................................... 154
Chassis-specific sensors
Hot-plug fan support
......................................................................................................... 154
Fan redundancy support
Board specific feature
Fan domain definition
HSC Availability
....................................................................................................... 154
....................................................................................................... 154
................................................................................................................ 155
........................................................................................... 153
...................................................... 154
.................................................................................................. 154
................................................................................................... 154
Revision 1.1
Intel order number G34153-003
Table of Contents Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS
viii
Power unit support ............................................................................................................ 155
Redundant Fans only for Intel® Server Chassis ................................................................ 155
Fan Fault LED support...................................................................................................... 155
Memory Throttling support ................................................................................................ 155
Appendix D: POST Code Diagnostic LED Decoder ............................................................ 156
Appendix E: POST Error Messages and Handling.............................................................. 162
Glossary ................................................................................................................................ 169
Reference Documents .......................................................................................................... 172
Revision 1.1
Intel order number G34153-003
Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS List of Figures
ix
List of Figures
Figure 1. Intel® Server Board S2600IP ........................................................................................ 2
Figure 2. Intel® Workstation Board W2600CR ............................................................................. 2
Figure 3. Intel® Server Board S2600IP Major Components ................................ ......................... 6
Figure 4. Intel® Server Board S2600IP Rear I/O Layout .............................................................. 8
Figure 5. Intel® Workstation Board W2600CR Rear I/O Layout ................................................... 9
Figure 6. Mounting Hole Locations (1 of 2) ................................................................................ 10
Figure 7. Mounting Hole Locations (2 of 2) ................................................................................ 11
Figure 8. Major Connector Pin-1 Locations (1 of 3) ................................ ................................... 12
Figure 9. Major Connector Pin-1 Locations (2 of 3) ................................ ................................... 13
Figure 10. Major Connector Pin-1 Locations (3 of 3) ................................................................. 14
Figure 11. Primary Side Keep-out Zone .................................................................................... 16
Figure 12. Primary Side Card-Side Keep-out Zone ................................................................... 17
Figure 13. Second Side Keep-out Zone .................................................................................... 18
Figure 14. Intel® Server Board S2600IP Functional Block Diagram ........................................... 19
Figure 15. Intel® Workstation Board W2600CR Functional Block Diagram ................................ 20
Figure 16. Processor Socket Assembly ..................................................................................... 21
Figure 17. Processor Socket ILM .............................................................................................. 21
Figure 18. Integrated Memory Controller Functional Block Diagram .......................................... 26
Figure 19. DIMM Slot Layout ..................................................................................................... 30
Figure 20. External RJ45 NIC Port LED Definition .................................................................... 41
Figure 21. Supported I/O Module Options ................................................................................. 42
Figure 22. USB3.0 Discrete Host Controller Block Diagram ...................................................... 44
Figure 23. IEEE 1394b Discrete Host Controller Block Diagram ............................................... 45
Figure 24. Integrated BMC Hardware ........................................................................................ 51
Figure 25. High-level Fan Speed Control Process ..................................................................... 62
Figure 26. Setup Utility – TPM Configuration Screen ................................................................ 87
Figure 27. Video Connector Pin-out .......................................................................................... 98
Figure 28. Jumper Blocks (J1C3, J1F1, J1F2, J2F3, J2F2) ..................................................... 100
Figure 29. Stand by LED, Fan Fault LED and CPU Fault LED Location .................................. 106
Figure 30. DIMM Fault LED’s Location .................................................................................... 107
Figure 31. Location of System Status, System ID and POST Code Diagnostic LEDs.............. 108
Figure 32. Power Distribution Block Diagram .......................................................................... 114
Figure 33. Differential Noise test setup ................................................................................... 118
Figure 34. Output Voltage Timing ........................................................................................... 119
Figure 35. Turn On/Off Timing (Power Supply Signals) ........................................................... 120
Figure 36. POST Code Diagnostic LED Decoder .................................................................... 156
Revision 1.1
Intel order number G34153-003
List of Tables Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS
x
List of Tables
Table 1. Product Feature Set ...................................................................................................... 3
Table 2. Mixed Processor Configurations Error Summary. ........................................................ 23
Table 3. UDIMM Support Guidelines ......................................................................................... 27
Table 4. RDIMM Support Guidelines ......................................................................................... 28
Table 5. LRDIMM Support Guidelines ....................................................................................... 28
Table 6. DIMM Nomenclature ................................................................................................... 29
Table 7. Intel® RAID C600 Upgrade Key Options ...................................................................... 35
Table 8. Intel® Server Board S2600IP/Workstation Board W2600CR PCI Bus Segment
Characteristics .................................................................................................................... 40
Table 9. Supported Intel® Integrated RAID Modules .................................................................. 43
Table 10. Standard Speaker Channels ..................................................................................... 44
Table 11. Basic and Advanced Features ................................................................................... 49
Table 12. BMC Beep Codes...................................................................................................... 52
Table 13. NMI Signal Generation and Event Logging ................................................................ 53
Table 14. Supported BMC FW Health Sensor Offsets ............................................................... 56
Table 15. Processor Sensors .................................................................................................... 56
Table 16. Processor Status Sensor Implementation .................................................................. 57
Table 17. Supported ERR2 Timeout Sensor Offsets ................................................................. 58
Table 18. Supported CATERR Sensor Offsets .......................................................................... 59
Table 19. Support MSID Mismatch Sensor Offsets ................................................................... 60
Table 20. Supported Power Supply Status Sensor Offsets........................................................ 62
Table 21. Support System Event Sensor Offsets ...................................................................... 64
Table 22. Supported Firmware Update Status Sensor Offsets .................................................. 64
Table 23. Standard Channel Assignments ................................................................................ 65
Table 24. Supported RMCP+ Cipher Suites .............................................................................. 66
Table 25. Supported RMCP+ Payload Types ............................................................................ 67
Table 26. Factory Configured PEF Table Entries ...................................................................... 71
Table 27. Enabling Advanced Management Features ............................................................... 78
Table 28. TSetup Utility – Security Configuration Screen Fields ................................................ 88
Table 29. Main Power Connector Pin-out .................................................................................. 90
Table 30. CPU_1 Power Connector Pin-out .............................................................................. 90
Table 31. CPU_2 Power Connector Pin-out .............................................................................. 90
Table 32. Add-in Slot Power Pin-input ("OPT_12V_PWR") ....................................................... 91
Table 33. Front Panel Header Pin-out ....................................................................................... 91
Table 34. Front Panel USB Connector Pin-out .......................................................................... 92
Table 35. Local Front Panel Connector Pin-out ......................................................................... 92
Table 36. SATA 6Gbps Connector Pin-out ................................................................................ 92
Revision 1.1
Intel order number G34153-003
Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS List of Tables
xi
Table 37. Multiport SAS/SATA Connector Pin-out ("SCU_0 (0-3)") ........................................... 93
Table 38. Multiport SAS/SATA Connector Pin-out ("SCU_1 (4-7)") ........................................... 93
Table 39. Intel® RAID C600 Upgrade Key Connector Pin-out .................................................... 94
Table 40. HSBP_I2C Header Pin-out ........................................................................................ 94
Table 41. HDD LED Header Pin-out .......................................................................................... 94
Table 42. Type-A USB Connector Pin-out ................................................................................. 94
Table 43. eUSB SSD Header Pin-out ........................................................................................ 95
Table 44. RMM4_Lite Connector Pin-out .................................................................................. 95
Table 45. RMM4_NIC Connector Pin-out .................................................................................. 95
Table 46. TPM Connector Pin-out ............................................................................................. 96
Table 47. PMBus* Connector Pin-out ........................................................................................ 96
Table 48. Chassis Intrusion Header Pin-out .............................................................................. 96
Table 49. IPMB Connector Pin-out ............................................................................................ 96
Table 50. 6-pin System FAN Connector Pin-out ........................................................................ 97
Table 51. 4-pin System FAN Connector Pin-out ........................................................................ 97
Table 52. CPU FAN Connector Pin-out ..................................................................................... 97
Table 53. Serial Port A Connector Pin-out ................................................................................. 97
Table 54. Serial Port B Connector Pin-out ................................................................................. 98
Table 55. Video Connector Pin-out details ................................................................................ 98
Table 56. Server Board Jumpers (J1C3, J1F1, J1F2, J2F3, J2F2) .......................................... 100
Table 57. System Status LED ................................................................................................. 109
Table 58. POST Code Diagnostic LEDs .................................................................................. 110
Table 59. Server Board Design Specifications ........................................................................ 111
Table 60. Intel® Server Board S2600IP MTBF Estimate ................................ .......................... 112
Table 61. Intel® Workstation Board W2600CR MTBF Estimate ............................................... 112
Table 62. Intel® Xeon® Processor Dual Processor TDP profile ................................................ 115
Table 63. Minimum Load Ratings ............................................................................................ 115
Table 64. Loading Conditions .................................................................................................. 116
Table 65.Voltage Regulation Limits ......................................................................................... 116
Table 66. Transient Load Requirements ................................................................................. 116
Table 67. Capacitive Loading Conditions ................................................................................ 117
Table 68. Ripples and Noise ................................................................................................... 118
Table 69. Output Voltage Timing ............................................................................................. 119
Table 70. Turn On/Off Timing .................................................................................................. 119
Table 71. Integrated BMC Core Sensors................................................................................. 124
Table 72. Intel® Server Board S2600IP - BMC Channel Assignments ..................................... 147
Table 73. Intel® Server Board S2600IP - Chassis-specific Sensors ......................................... 148
Table 74. Intel® Server Board S2600IP - Fan Domain Definition ............................................. 149
Table 75. Intel® Server Chassis P4208/P4216/P4224/P4308 (UPL) Power support ................ 152
Table 76. Intel® Server Chassis R2208/R2216/R2224/R2308/R2312 (BHP) Power support ... 152
Table 77. Intel® Workstation Board W2600CR - BMC Channel Assignments .......................... 153
Revision 1.1
Intel order number G34153-003
List of Tables Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS
xii
Table 78. Intel® Workstation Board W2600CR - Chassis-specific sensors .............................. 154
Table 79. Intel® Workstation Board W2600CR - Fan domain definition ................................... 154
Table 80. Intel® Server Chassis P4304 (UPL) Power support ................................................. 155
Table 81. POST Progress Code LED Example ....................................................................... 157
Table 82. POST Progress Codes ............................................................................................ 157
Table 83. MRC Progress Codes ............................................................................................. 159
Table 84. MRC Fatal Error Codes ........................................................................................... 160
Table 85. POST Error Codes and Messages .......................................................................... 162
Table 86. POST Error Beep Codes ......................................................................................... 167
Table 87. Integrated BMC Beep Codes ................................................................................... 168
Revision 1.1
Intel order number G34153-003
Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS List of Tables
xiii
<This page is intentionally left blank.>
Revision 1.1
Intel order number G34153-003
Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS Introduction
1. Introduction
This Technical Product Specification (TPS) provides board-specific information detailing the
features, functionality, and high-level architecture of the Intel® Server Board S2600IP and Intel
Workstation Board W2600CR.
In addition, you can obtain design-level information for a given subsystem by ordering the
External Product Specifications (EPS) for the specific subsystem. EPS documents are not
publicly available and you must order them through your local Intel representative.
1.1 Chapter Outline
This document is divided into the following chapters:
Chapter 1 – Introduction
Chapter 2 – Product Overview
Chapter 3 – Functional Architecture
Chapter 4 – Platform Management Overview
Chapter 5 – System Security
Chapter 6 – Connector/Header Locations and Pin-outs
Chapter 7 – Jumper Blocks
Chapter 8 – Intel
Chapter 9 – Design and Environmental Specifications
Appendix A: Integration and Usage Tips
Appendix B: BMC Sensor Tables
Appendix C: Platform Specific BMC Appendix
Appendix D: POST Code Diagnostic LED Decoder
Appendix E: POST Error Messages and Handling
Glossary
Reference Documents
®
Light Guided Diagnostics
®
1.2 Server Board Use Disclaimer
Intel® Server Boards contain a number of high-density VLSI (Very-large-scale integration) and
power delivery components that require adequate airflow for cooling. Intel ensures through its
own chassis development and testing that when Intel® server building blocks are used together,
the fully integrated system meets the intended thermal requirements of these components. It is
the responsibility of the system integrator who chooses not to use Intel developed server
building blocks to consult vendor datasheets and operating parameters to determine the amount
of airflow required for their specific application and environmental conditions. Intel Corporation
cannot be held responsible if components fail or the server board does not operate correctly
when used outside any of the published operating or non-operating limits.
Revision 1.1 1
Intel order number G34153-003
Product Overview Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS
2. Product Overview
The Intel® Server Board S2600IP and Intel® Workstation Board W2600CR are Enterprise I/O
Rich platforms for Pedestal and Rack Server and workstation market.
Figure 1. Intel® Server Board S2600IP
Figure 2. Intel® Workstation Board W2600CR
2 Revision 1.1
Intel order number G34153-003
Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS Product Overview
Board Name
Intel® Server Board S2600IP
Intel® Workstation Board W2600CR
Processors
Support for one or two Intel® Xeon® E5-
2600 Processor(s)
8 GT/s Intel® Quick Path Interconnect
(Intel® QPI)
LGA 2011 Socket
Thermal Design Power up to 135 W
Support for one or two Intel® Xeon® E5-
2600 Processor(s)
8 GT/s Intel® Quick Path Interconnect (Intel®
QPI)
LGA 2011 Socket
Thermal Design Power up to 150 W
Chipset
Intel® C600-A chipset with support for optional Intel® C600 RAID Upgrade Keys
Memory
16 DDR3 DIMMs with 800MT/s, 1067MT/s, 1333MT/s,1600MT/s
Eight memory channels (four channels for each processor socket)
Channels A, B, C, D, E, F, G and H
Support for 800/1066/1333/1600 MHz/s Registered DDR3 Memory (RDIMM),
Unbuffered DDR3 memory ((UDIMM) and Load Reduced DDR3 memory (LRDIMM)
DDR3 standard I/O voltage of 1.5V and DDR3 Low Voltage of 1.35V
Slots
Slot 1: PCIe Gen3 x16, connector from first processor.
Slot 2: PCIe Gen3 x8, connector from first processor.
Slot 3: PCIe Gen3 x16, connector from first processor.
Slot 4: PCIe Gen3 x8, connector from second processor.
Slot 5: PCIe Gen3 x16, connector from second processor.
Slot 6: PCIe Gen3 x8, connector, from second processor
Slot 7: PCIe Gen3 x16,connector, from second processor
Slot 8: PCIe Gen2 x4 electrical with x8 physical connector, from second processor
IOM Connector: I/O Module (optional with Flex Cable*)
Notes: The IOM connector is not available for all boards and only supports PCIe Gen1 Speed
SM Conn: SAS Module (optional)
6Gbps or 12Gbps SAS ROC module Options
Ethernet
Intel® I350 Quad 1GbE fully integrated GbE
MAC and PHY Network Controller
Intel® I350 Dual 1GbE fully integrated GbE MAC
and PHY Controller
On-board storage
controllers and
options
One eUSB 2x5 pin connector to support 2mm low-profile eUSB solid state devices
Two 7-pin single port AHCI SATA connectors capable of supporting up to 6 GB/sec
Two SCU 4-port mini-SAS connectors capable of supporting up to 3 GB/sec SAS/SATA
Intel® Integrated RAID module support (Optional)
Intel® RAID C600 Upgrade Key support providing optional expanded SATA/SAS RAID
capabilities
Video
Integrated Matrox* G200 2D Video
Graphics controller
1 Rear VGA port
Integrated Matrox* G200 2D Video
Graphics controller
1 Internal VGA connector
2.1 Product Feature Set
Table 1. Product Feature Set
Revision 1.1 3
Intel order number G34153-003
Product Overview Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS
Board Name
Intel® Server Board S2600IP
Intel® Workstation Board W2600CR
Audio
None
ALC889 HD Audio (7.1 + S/PDIF Out)
I/O
4 Rear USB2.0 1 Rear Serial A
2 Type A USB2.0 Connectors
1 Internal Serial B
4 Rear USB2.0 2 Rear USB3.0
2 Type A USB2.0 Connector
1 1394b Connector
1 Internal Serial B
Server
Management
Onboard Server Engines* LLC Pilot III* Controller
Support for Intel® Remote Management Module 4 solutions
Intel® Light-Guided Diagnostics on field replaceable units
Support for Intel® System Management Software
Support for Intel® Intelligent Power Node Manager (Need PMBus*-compliant power supply)
Security
Intel® Trusted Platform Module (TPM) - AXXTPME5 (accessory option)
Power-Supply
750W/1200W/1600W Common Redundant Power-Supply with PMBus* Support
Suspend to RAM
(S3)
None
Supported
Form Factor
Custom 14.2'' W x 15.0'' D
Chassis
Pedestal: P4000L chassis
2U Rack: R2000 chassis
Pedestal: P4000L WS chassis
4 Revision 1.1
Intel order number G34153-003
Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS Product Overview
Callout
Description
Callout
Description
A
Slot 1, PCI Express* Gen3
AD
DIMM C1/C2/D1/D2
B
RMM4 lite module connector
AE
System Fan connector 1/2/3/4/5/6
C
Slot 2, PCI Express* Gen3
AF
Type A USB connector
D
TPM
AG
Type A USB connector
E
Slot 3, PCI Express* Gen3
AH
ROC Module connector
F
Slot 4, PCI Express* Gen3
AI
LCP connector
G
RMM4 Connector
AJ
Front Panel connector
H
Slot 5, PCI Express* Gen3
AK
Front Panel USB connector
I
Battery
AL
Main Power 4-pin connector
J
Slot 6, PCI Express* Gen3
AM
MinISAS Port B(4-7)
K
Slot 7, PCI Express* Gen3
AN
MiniSAS Port A(0-3)
2.1.1 Main Board Connector and Component Layout
The following figure shows the layout of the server board. Each connector and major component
is identified by a number or letter, and a description is given below the figure.
Revision 1.1 5
Intel order number G34153-003
Product Overview Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS
Callout
Description
Callout
Description
L
Slot 8, PCI Express* Gen2
AO
SATA Port 1
M
DIMM E1/E2/F1/F2
AP
SATA Port 0
N
Status LED
AQ
CPLD Update
O
ID LED
AR
IPMB
P
Diagnostic LED
AS
HDD LED
Q
NIC 3/4 (S2600IP only)
AT
ME FRC UPDT
R
USB 2/3, NIC 2
AU
CMOS CLR
S
USB 0/1, NIC 1
AV
BIOS RCVRY
T
VGA Port (S2600IP only)
AW
PASSWD CLR
U
Serial Port A (S2600IP only)
AX
Storage Upgrade Key
V
Processor 2 Power connector
AY
eUSB SSD
W
Processor 2 Fan connector
AZ
HSBP connector
X
DIMM H2/H1/G2/G1
BA
Chassis intrusion
Y
PMBus* connector
BB
Serial B connector
Z
Main Power connector
BC
BMC Force Update
AA
Processor 1 Power connector
BD
I/O Module connector (not available
for S2600IP4L)
AB
DIMM B2/B1/A2/A1
BE
System Fan connector 7
AC
Processor 1 Fan connector
Figure 3. Intel® Server Board S2600IP Major Components
6 Revision 1.1
Intel order number G34153-003
Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS Product Overview
Callout
Description
Callout
Description
A
Slot 1, PCI Express* Gen3
AE
DIMM C1/C2/D1/D2
B
RMM4 Lite module
AF
System Fan connector 1/2/3/4/5/6
C
Slot 2, PCI Express* Gen3
AG
Type A USB connector
D
TPM
AH
Type A USB connector
E
Slot 3, PCI Express* Gen3
AI
ROC Module connector
F
Slot 4, PCI Express* Gen3
AJ
LCP connector
G
RMM4 Connector
AK
Front Panel connector
H
Slot 5, PCI Express* Gen3
AL
Front Panel USB connector
I
Battery
AM
Main Power 4-pin connector
J
Slot 6, PCI Express* Gen3
AN
1394b connector(W2600CR only)
K
Slot 7, PCI Express* Gen3
AO
MiniSAS Port B(4-7)
L
Slot 8, PCI Express* Gen2
AP
MiniSAS Port A(0-3)
M
DIMM E1/E2/F1/F2
AQ
SATA Port 1
N
Status LED
AR
SATA Port 0
O
ID LED
AS
CPLD Update
P
Diagnostic LED
AT
IPMB
Revision 1.1 7
Intel order number G34153-003
Product Overview Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS
Callout
Description
Callout
Description
Q
SPDIF connector
AU
HDD LED
R
USB 2/3, NIC 2
AV
ME FRC UPDT
S
USB 0/1, NIC 1
AW
CMOS CLR
T
USB3.0 0/1(W2600CR only)
AX
BIOS RCVRY
U
HD Audio (W2600CR only)
AY
PASSWD CLR
V
Processor 2 Power connector
AZ
Storage Upgrade Key
W
Front Audio connector
BA
eUSB SSD
X
Processor 2 Fan connector
BB
HSBP connector
Y
DIMM H2/H1/G2/G1
BC
Chassis intrusion
Z
PMBus* connector
BD
Serial B connector
AA
Main Power connector
BE
BMC Force Update
AB
Processor 1 Power connector
BF
I/O Module connector (not available
for W2600CR2L)
AC
DIMM B2/B1/A2/A1
BG
Internal video connector
AD
Processor 1 Fan connector
BH
System Fan connector 7
Callout
Description
Callout
Description
A
Serial Port A
E
NIC Port 3(top) and 4(bottom)
B
Video Port
F
Diagnostics LED’s
C
NIC Port 1, USB Port 0 (bottom) and 1
(top)
G
ID LED
D
NIC Port 2, USB Port 2 (bottom) and 3
(top)
H
Status LED
Figure 3. Intel® Workstation Board W2600CR Major Components
2.1.2 Main Board Rear I/O Layout
The following drawing shows the layout of the rear I/O components for the server boards.
Figure 4. Intel® Server Board S2600IP Rear I/O Layout
8 Revision 1.1
Intel order number G34153-003
Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS Product Overview
Callout
Description
Callout
Description
A
7.1 Channel HD Audio Jack Connector
E
Diagnostics LED’s
B
USB3.0 Port 0(bottom) and 1(top)
F
ID LED
C
NIC Port 1, USB Port 0 (bottom) and 1
(top)
G
Status LED
D
NIC Port 2, USB Port 2 (bottom) and 3
(top)
Figure 5. Intel® Workstation Board W2600CR Rear I/O Layout
Revision 1.1 9
Intel order number G34153-003
Product Overview Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS
2.1.3 Server Board Mechanical Drawings
10 Revision 1.1
Figure 6. Mounting Hole Locations (1 of 2)
Intel order number G34153-003
Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS Product Overview
Revision 1.1 11
Figure 7. Mounting Hole Locations (2 of 2)
Intel order number G34153-003
Product Overview Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS
Figure 8. Major Connector Pin-1 Locations (1 of 3)
12 Revision 1.1
Intel order number G34153-003
Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS Product Overview
Figure 9. Major Connector Pin-1 Locations (2 of 3)
Revision 1.1 13
Intel order number G34153-003
Product Overview Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS
Figure 10. Major Connector Pin-1 Locations (3 of 3)
14 Revision 1.1
Intel order number G34153-003
Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS Product Overview
Revision 1.1 15
Intel order number G34153-003
Product Overview Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS
Figure 11. Primary Side Keep-out Zone
16 Revision 1.1
Intel order number G34153-003
Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS Product Overview
Figure 12. Primary Side Card-Side Keep-out Zone
Revision 1.1 17
Intel order number G34153-003
Product Overview Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS
Figure 13. Second Side Keep-out Zone
18 Revision 1.1
Intel order number G34153-003
Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS Functional Architecture
3. Functional Architecture
The architecture and design of the Intel® Server Board S2600IP and Intel® Workstation Board
W2600CR is based on the Intel® C600-A chipset. The chipset is designed for systems based on
the Intel® Xeon® Sandy Bridge-EP Processor series in an LGA 2011 Socket with Intel® Quick
Path Interconnect (Intel® QPI) speed at 8GT/s.
This chapter provides a high-level description of the functionality associated with each chipset
component and the architectural blocks that make up the server boards.
Figure 14. Intel® Server Board S2600IP Functional Block Diagram
Revision 1.1 19
Intel order number G34153-003
Functional Architecture Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS
Figure 15. Intel® Workstation Board W2600CR Functional Block Diagram
3.1 Processor Support
The server board includes two Socket-R (LGA2011) processor sockets and can support one or
two of the following processors - Intel® Xeon® processor E5-2600 product family with a Thermal
Design Power (TDP) of up to 150W.
Note: The 150w TDP processors only supported on Intel® Workstation Board W2600CR and
Intel® Server Board S2600IP only support update to 135w TDP processors. Previous generation
Intel® Xeon® processors are not supported on the Intel server boards described in this document.
For a complete updated list of supported processors, please visit the support website.
3.1.1 Processor Socket Assembly
Each processor socket of the server board is pre-assembled with an Independent Latching
Mechanism (ILM) and Back Plate which allow for secure placement of the processor and
processor heat to the server board. The illustration below identifies each sub-assembly
component.
20 Revision 1.1
Intel order number G34153-003
Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS Functional Architecture
Heat Sink
Server Board
Independent Latching
Mechanism (ILM)
Back Plate
80mm
80mm
Figure 16. Processor Socket Assembly
Figure 17. Processor Socket ILM
The square ILM has an 80x80mm heat sink mounting hole pattern and is used on the Intel®
Server Board S2600IP and Intel® Workstation Board W2600CR.
Note: Processor Thermal solutions for the Intel® Workstation Board W2600CR are NOT the
same with Intel® Server Board S2600IP when install 150W TDP Processors.
Revision 1.1 21
Intel order number G34153-003
Functional Architecture Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS
3.1.2 Processor Population Rules
Note: Although the server board does support dual-processor configurations consisting of
different processors that meet the defined criteria below, Intel does not perform validation
testing of this configuration. For optimal system performance in dual-processor configurations,
Intel recommends that identical processors be installed.
When using a single processor configuration, the processor must be installed into the processor
socket labeled “CPU_1”.
When two processors are installed, the following population rules apply:
Both processors must be of the same processor family.
Both processors must have the same number of cores.
Both processors must have the same cache sizes for all levels of processor cache
memory.
Processors with different core frequencies can be mixed in a system, given the prior
rules are met. If this condition is detected, all processor core frequencies are set to the
lowest common denominator (highest common speed) and an error is reported.
Processors which have different QPI link frequencies may operate together if they are
otherwise compatible and if a common link frequency can be selected. The common link
frequency would be the highest link frequency that all installed processors can achieve.
Processor stepping within a common processor family can be mixed as long as it is
listed in the processor specification updates published by Intel Corporation.
3.1.3 Processor Initialization Error Summary
The following table describes mixed processor conditions and recommended actions for all
®
Intel
server boards and Intel server systems designed around the Intel® Xeon® processor E5-
2600 product family and Intel
of the following three categories:
Fatal: If the system can boot, it pauses at a blank screen with the text “Unrecoverable
fatal error found. System will not boot until the error is resolved” and “Press <F2>
to enter setup”, regardless of whether the “Post Error Pause” setup option is enabled or
disabled.
When the operator presses the <F2> key on the keyboard, the error message is
displayed on the Error Manager screen, and an error is logged to the System Event Log
(SEL) with the POST Error Code.
The system cannot boot unless the error is resolved. The user needs to replace the
faulty part and restart the system.
For Fatal Errors during processor initialization, the System Status LED will be set to a
steady Amber color, indicating an unrecoverable system failure condition.
Major: If the “Post Error Pause” setup option is enabled, the system goes directly to the
Error Manager to display the error, and logs the POST Error Code to SEL. Operator
®
C600 chipset product family architecture. The errors fall into one
22 Revision 1.1
Intel order number G34153-003
Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS Functional Architecture
Error
Severity
System Action
Processor family not Identical
Fatal
The BIOS detects the error condition and responds as follows:
Logs the POST Error Code into the System Event Log (SEL).
Alerts the BMC to set the System Status LED to steady Amber.
Displays “0194: Processor family mismatch detected”
message in the Error Manager.
Takes Fatal Error action (see above) and will not boot until the
fault condition is remedied.
Processor model not Identical
Fatal
The BIOS detects the error condition and responds as follows:
Logs the POST Error Code into the System Event Log (SEL).
Alerts the BMC to set the System Status LED to steady Amber.
Displays “0196: Processor model mismatch detected”
message in the Error Manager.
Takes Fatal Error action (see above) and will not boot until the
fault condition is remedied.
Processor cores/threads not identical
Fatal
The BIOS detects the error condition and responds as follows:
Logs the POST Error Code into the SEL.
Alerts the BMC to set the System Status LED to steady Amber.
Displays “0191: Processor core/thread count mismatch
detected” message in the Error Manager.
Takes Fatal Error action (see above) and will not boot until the fault
condition is remedied.
Processor cache not identical
Fatal
The BIOS detects the error condition and responds as follows:
Logs the POST Error Code into the SEL.
Alerts the BMC to set the System Status LED to steady Amber.
Displays “0192: Processor cache size mismatch detected
message in the Error Manager.
Takes Fatal Error action (see above) and will not boot until the
fault condition is remedied.
intervention is required to continue booting the system.
Otherwise, if “POST Error Pause” is disabled, the system continues to boot and no
prompt is given for the error, although the Post Error Code is logged to the Error
Manager and in a SEL message.
Minor: The message is displayed on the screen or on the Error Manager screen, and
the POST Error Code is logged to the SEL. The system continues booting in a degraded
state. The user may want to replace the erroneous unit. The POST Error Pause option
setting in the BIOS setup does not have any effect on this error.
Table 2. Mixed Processor Configurations Error Summary.
Revision 1.1 23
Intel order number G34153-003
Functional Architecture Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS
Error
Severity
System Action
Processor frequency (speed) not
identical
Fatal
The BIOS detects the processor frequency difference, and responds
as follows:
Adjusts all processor frequencies to the highest common
frequency.
No error is generated – this is not an error condition.
Continues to boot the system successfully.
If the frequencies for all processors cannot be adjusted to be the
same, then this is an error, and the BIOS responds as follows:
Logs the POST Error Code into the SEL.
Alerts the BMC to set the System Status LED to steady Amber.
Does not disable the processor.
Displays “0197: Processor speeds unable to synchronize”
message in the Error Manager.
Takes Fatal Error action (see above) and will not boot until the
fault condition is remedied.
Processor Intel® QuickPath
Interconnect link frequencies not
identical
Fatal
The BIOS detects the QPI link frequencies and responds as follows:
Adjusts all QPI interconnect link frequencies to highest common
frequency.
No error is generated – this is not an error condition.
Continues to boot the system successfully.
If the link frequencies for all QPI links cannot be adjusted to be the
same, then this is an error, and the BIOS responds as follows:
Logs the POST Error Code into the SEL.
Alerts the BMC to set the System Status LED to steady Amber.
Displays “0195: Processor Intel(R) QPI link frequencies
unable to synchronize” message in the Error Manager.
Does not disable the processor.
Takes Fatal Error action (see above) and will not boot until the
fault condition is remedied.
Processor microcode update missing
Minor
The BIOS detects the error condition and responds as follows:
Logs the POST Error Code into the SEL.
Displays “818x: Processor 0x microcode update not found”
message in the Error Manager or on the screen.
The system continues to boot in a degraded state, regardless of
the setting of POST Error Pause in the Setup.
Processor microcode update failed
Major
The BIOS detects the error condition and responds as follows:
Logs the POST Error Code into the SEL.
Displays “816x: Processor 0x unable to apply microcode
update” message in the Error Manager or on the screen.
Takes Major Error action. The system may continue to boot in a
degraded state, depending on the setting of POST Error Pause in
Setup, or may halt with the POST Error Code in the Error Manager
waiting for operator intervention.
24 Revision 1.1
Intel order number G34153-003
Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS Functional Architecture
3.2 Processor Functions Overview
With the release of the Intel® Xeon® processor E5-2600 product family, several key system
components, including the CPU, Integrated Memory Controller (IMC), and Integrated IO Module
(IIO), have been combined into a single processor package and feature per socket; two Intel®
QuickPath Interconnect point-to-point links capable of up to 8.0 GT/s, up to 40 lanes of Gen 3
PCI Express* links capable of 8.0 GT/s, and 4 lanes of DMI2/PCI Express* Gen 2 interface with
a peak transfer rate of 5.0 GT/s. The processor supports up to 46 bits of physical address space
and 48-bit of virtual address space.
The following sections will provide an overview of the key processor features and functions that
help to define the performance and architecture of the server board. For more comprehensive
processor specific information, refer to the Intel® Xeon® processor E5-2600 product family
documents listed in the Reference Document list.
Processor Feature Details:
Up to eight execution cores
Each core supports two threads (Intel
per socket
46-bit physical addressing and 48-bit virtual addressing
1 GB large page support for server applications
A 32-KB instruction and 32-KB data first-level cache (L1) for each core
A 256-KB shared instruction/data mid-level (L2) cache for each core
Up to 20 MB last level cache (LLC): up to 2.5 MB per core instruction/data last level
cache (LLC), shared among all cores
Supported Technologies:
Intel
Intel
Intel
Intel
Intel
Intel
Intel
Intel
Intel
Execute Disable Bit
Intel
Intel
Enhanced Intel
®
Virtualization Technology (Intel® VT)
®
Virtualization Technology for Directed I/O (Intel® VT-d)
®
Virtualization Technology “Sandy Bridge” Processor Extensions
®
Trusted Execution Technology (Intel® TXT)
®
64 Architecture
®
Streaming SIMD Extensions 4.1 (Intel® SSE4.1)
®
Streaming SIMD Extensions 4.2 (Intel® SSE4.2)
®
Advanced Vector Extensions (Intel® AVX)
®
Hyper-Threading Technology
®
Turbo Boost Technology
®
Intelligent Power Technology
®
SpeedStep Technology
®
Hyper-Threading Technology), up to 16 threads
3.2.1 Intel® QuickPath Interconnect
The Intel® QuickPath Interconnect is a high speed, packetized, point-to-point interconnect used
in the processor. The narrow high-speed links stitch together processors in distributed shared
memory and integrated I/O platform architecture. It offers much higher bandwidth with low
latency. The Intel® QuickPath Interconnect has an
Revision 1.1 25
efficient architecture
Intel order number G34153-003
allowing more
Functional Architecture Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS
CPU 2
CPU 1
2 DIMMs/Ch
2 DIMMs/Ch
Figure 18. Integrated Memory Controller Functional Block Diagram
interconnect performance to be achieved in real systems. It has a snoop protocol optimized for
low latency and high scalability, as well as packet and lane structures enabling quick
completions of transactions. Reliability, availability, and serviceability features (RAS) are built into
the architecture.
The physical connectivity of each interconnect link is made up of twenty differential signal pairs
plus a differential forwarded clock. Each port supports a link pair consisting of two unidirectional
links to complete the connection between two components. This supports traffic in both
directions simultaneously. To facilitate flexibility and longevity, the interconnect is defined as
having five layers: Physical, Link, Routing, Transport, and Protocol.
The Intel® QuickPath Interconnect includes a cache coherency protocol to keep the distributed
memory and caching structures coherent during system operation. It supports both low-latency
source snooping and a scalable home snoop behavior. The coherency protocol provides for
direct cache-to-cache transfers for optimal latency.
3.2.2 Integrated Memory Controller (IMC) and Memory Subsystem
Integrated into the processor is a memory controller. Each processor provides four DDR3
channels that support the following:
Unbuffered DDR3 and registered DDR3 DIMMs
LR DIMM (Load Reduced DIMM) for buffered memory solutions demanding higher
capacity memory subsystems
Independent channel mode or lockstep mode
Data burst length of eight cycles for all memory organization modes
Memory DDR3 data transfer rates of 800, 1066, 1333, and 1600 MT/s
64-bit wide channels plus 8-bits of ECC support for each channel
DDR3 standard I/O Voltage of 1.5 V and DDR3 Low Voltage of 1.35 V
1-Gb, 2-Gb, and 4-Gb DDR3 DRAM technologies supported for these devices:
o UDIMM DDR3 – SR x8 and x16 data widths, DR – x8 data width
o RDIMM DDR3 – SR,DR, and QR – x4 and x8 data widths
o LRDIMM DDR3 – QR – x4 and x8 data widths with direct map or with rank multiplication
Up to 8 ranks supported per memory channel, 1, 2 or 4 ranks per DIMM
Open with adaptive idle page close timer or closed page policy
Per channel memory test and initialization engine can initialize DRAM to all logical zeros
with valid ECC (with or without data scrambler) or a predefined test pattern
Isochronous access support for Quality of Service (QoS)
26 Revision 1.1
Intel order number G34153-003
Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS Functional Architecture
Ranks
Per
DIMM
and
Data
Width
Memory Capacity Per
DIMM1
Speed (MT/s) and Voltage Validated by
Slot per Channel (SPC) and DIMM Per Channel (DPC)
2,3
2 Slots per Channel
1DPC
2DPC
1.35V
1.5V
1.35V
1.5V
SRx8
NonECC
1GB
2GB
4GB
n/a
1066, 1333
n/a
1066, 1333
DRx8
NonECC
2GB
4GB
8GB
n/a
1066, 1333
n/a
1066, 1333
SRx16
NonECC
512MB
1GB
2GB
n/a
1066, 1333
n/a
1066, 1333
SRx8
ECC
1GB
2GB
4GB
1066,1333
1066, 1333
1066
1066, 1333
DRx8
ECC
2GB
4GB
8GB
1066,1333
1066, 1333
1066
1066, 1333
Supported and Validated
Supported but not Validate
Minimum memory configuration: independent channel support with 1 DIMM populated
Integrated dual SMBus* master controllers
Command launch modes of 1n/2n
RAS Support:
o Rank Level Sparing and Device Tagging
o Demand and Patrol Scrubbing
o DRAM Single Device Data Correction (SDDC) for any single x4 or x8 DRAM device.
Independent channel mode supports x4 SDDC. x8 SDDC requires lockstep mode
o Lockstep mode where channels 0 and 1 and channels 2 and 3 are operated in
lockstep mode
o Data scrambling with address to ease detection of write errors to an incorrect
address.
o Error reporting from Machine Check Architecture
o Read Retry during CRC error handling checks by iMC
o Channel mirroring within a socket
CPU1 Channel Mirror Pairs (A,B) and (C,D)
CPU2 Channel Mirror Pairs (E,F) and (G,H)
o Error Containment Recovery
Improved Thermal Throttling with dynamic Closed Loop Thermal Throttling (CLTT)
Memory thermal monitoring support for DIMM temperature
3.2.2.1 Supported Memory
Table 3. UDIMM Support Guidelines
Notes:
1. Supported DRAM Densities are 1Gb, 2Gb and 4Gb. Only 2Gb and 4Gb are validated by Intel.
2. Command Address Timing is 1N for 1DPC and 2N for 2DPC.
Revision 1.1 27
Intel order number G34153-003
Functional Architecture Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS
Ranks Per
DIMM and
Data Width
Memory Capacity Per
DIMM1
Speed (MT/s) and Voltage Validated by
Slot per Channel (SPC) and DIMM Per Channel (DPC)
2
2 Slots per Channel
1DPC
2DPC
1.35V
1.5V
1.35V
1.5V
SRx8
1GB
2GB
4GB
1066 1333
1066 1333 1600
1066 1333
1066 1333 1600
DRx8
2GB
4GB
8GB
1066 1333
1066 1333 1600
1066 1333
1066 1333 1600
SRx4
2GB
4GB
8GB
1066 1333
1066 1333 1600
1066 1333
1066 1333 1600
DRx4
4GB
8GB
16GB
1066 1333
1066 1333 1600
1066 1333
1066 1333 1600
QRx4
8GB
16GB
32GB
800
1066
800
800
QRx8
4GB
8GB
16GB
800
1066
800
800
Supported and Validated
Supported but not Validate
Supported w/Limited Validation4
Ranks
Per
DIMM
and
Data
Width1
Memory
Capacity Per
DIMM2
Speed (MT/s) and Voltage Validated by
Slot per Channel (SPC) and DIMM Per Channel (DPC)
3,4
2 Slots per Channel
1DPC and 2DPC
1.35V
1.5V
QRx4
(DDP)5
16GB
32GB
1066
1066, 1333
QRx8
(P)5
8GB
16GB
1066
1066, 1333
Supported and Validated
Table 4. RDIMM Support Guidelines
Notes:
1. Supported DRAM Densities are 1Gb, 2Gb and 4Gb. Only 2Gb and 4Gb are validated by Intel®.
2. Command Address Timing is 1N.
3. QR RDIMM are supported but only validated by Intel/PMO in a homogenous environment. The coverage will
have limited system level testing, no signal integrity testing, and no interoperability testing the passing QR
RDIMMs will be web posted.
Table 5. LRDIMM Support Guidelines
Notes:
1. Physical Rank is used to calculate DIMM Capacity.
2. Supported and validated DRAM Densities are 2Gb and 4Gb.
3. Command Address Timing is 1N.
4. The speeds are estimated targets and will be verified through simulation.
5. DDP - Dual Die Package DRAM stacking. P – Planer monolithic DRAM Die.
28 Revision 1.1
Intel order number G34153-003
Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS Functional Architecture
Processor Socket 1
Processor Socket 2
(0)
Channel A
(1)
Channel B
(2)
Channel C
(3)
Channel D
(0)
Channel E
(1)
Channel F
(2)
Channel G
(3)
Channel H
A1
A2
B1
B2
C1
C2
D1
D2
E1
E2
F1
F2
G1
G2
H1
H2
3.2.2.2 Memory Population Rules
Note: Although mixed DIMM configurations are supported, Intel only performs platform
validation on systems that are configured with identical DIMMs installed.
Each processor provides four banks of memory, each capable of supporting up to 2 DIMMs.
DIMMs are organized into physical slots on DDR3 memory channels that belong to
processor sockets.
The memory channels from processor socket 1 are identified as Channel A, B, C and D.
The memory channels from processor socket 2 are identified as Channel E, F, G, and H.
The silk screened DIMM slot identifiers on the board provide information about the
channel, and therefore the processor to which they belong. For example, DIMM_A1 is
the first slot on Channel A on processor 1; DIMM_E1 is the first DIMM socket on
Channel E on processor 2.
The memory slots associated with a given processor are unavailable if the
corresponding processor socket is not populated.
A processor may be installed without populating the associated memory slots provided a
second processor is installed with associated memory. In this case, the memory is
shared by the processors. However, the platform suffers performance degradation and
latency due to the remote memory.
Processor sockets are self-contained and autonomous. However, all memory subsystem
support (such as Memory RAS, Error Management,) in the BIOS setup are applied
commonly across processor sockets.
On the Intel® Server Board S2600IP and Intel® Workstation Board W2600CR a total of 16 DIMM
slots is provided (2 CPUs – 4 Channels/CPU, 2 DIMMs/Channel). The nomenclature for DIMM
sockets is detailed in the following table:
Table 6. DIMM Nomenclature
Revision 1.1 29
Intel order number G34153-003
Functional Architecture Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS
Figure 19. DIMM Slot Layout
The following are generic DIMM population requirements that generally apply to both the Intel®
Server Board S2600IP and Intel® Workstation Board W2600CR.
DIMM slots on any memory channel must be filled following the “farthest fill first” rule.
A maximum of 8 ranks can be installed on any one channel, counting all ranks in each
DIMM on the channel.
DIMM types (UDIMM, RDIMM, LRDIMM) must not be mixed within or across processor
sockets.
Mixing ECC with non-ECC DIMMs (UDIMMs) is not supported within or across
processor sockets.
Mixing Low Voltage (1.35V) DIMMs with Standard Voltage (1.5V) DIMMs is not
supported within or across processor sockets.
Mixing DIMMs of different frequencies and latencies is not supported within or across
processor sockets.
LRDIMM Rank Multiplication Mode and Direct Map Mode must not be mixed within or
across processor sockets.
Only ECC UDIMMs support Low Voltage 1.35V operation.
30 Revision 1.1
Intel order number G34153-003
Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS Functional Architecture
QR RDIMMs may only be installed in DIMM Slot 1 or 2 on a channel.
2 DPC QR Low Voltage RDIMMs are not supported.
In order to install 3 QR LRDIMMs on the same channel, they must be operated with
Rank Multiplication as RM = 2.
RAS Modes Lockstep, Rank Sparing, and Mirroring are mutually exclusive in this BIOS.
Only one operating mode may be selected, and it will be applied to the entire system.
If a RAS Mode has been configured, and the memory population will not support it
during boot, the system will fall back to Independent Channel Mode and log and display
errors
Rank Sparing Mode is only possible when all channels that are populated with memory
meet the requirement of having at least 2 SR or DR DIMM installed, or at least one QR
DIMM installed, on each populated channel.
Lockstep or Mirroring Modes require that for any channel pair that is populated with
memory, the memory population on both channels of the pair must be identically sized.
DIMM population rules require that DIMMs within a channel be populated starting with the BLUE
DIMM slot or DIMM farthest from the processor in a “fill-farthest” approach. In addition, when
populating a Quad-rank DIMM with a Single- or Dual-rank DIMM in the same channel, the
Quad-rank DIMM must be populated farthest from the processor. Note that Quad-rand DIMMs
and UDIMMs are not allowed in three slots populated configurations. Intel MRC will check for
correct DIMM placement.
3.2.2.3 Publishing System Memory
The BIOS displays the “Total Memory” of the system during POST if Display Logo is
disabled in the BIOS setup. This is the total size of memory discovered by the BIOS
during POST, and is the sum of the individual sizes of installed DDR3 DIMMs in the
system.
The BIOS displays the “Effective Memory” of the system in the BIOS setup. The term
Effective Memory refers to the total size of all DDR3 DIMMs that are active (not
disabled) and not used as redundant units.
The BIOS provides the total memory of the system in the main page of the BIOS setup.
This total is the same as the amount described by the first bullet above.
If Quite Boot is disabled, the BIOS displays the total system memory on the diagnostic screen at
the end of POST. This total is the same as the amount described by the first bullet above.
3.2.2.4 RAS Features
The server board supports the following memory RAS modes:
Independent Channel Mode
Rank Sparing Mode
Mirrored Channel Mode
Lockstep Channel Mode
Regardless of RAS mode, the requirements for populating within a channel given in the section
3.2.2.2 must be met at all times. Note that support of RAS modes that require matching DIMM
Revision 1.1 31
Intel order number G34153-003
Functional Architecture Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS
population between channels (Mirrored and Lockstep) require that ECC DIMMs be populated.
Independent Channel Mode is the only mode that supports non-ECC DIMMs in addition to ECC
DIMMs.
For RAS modes that require matching populations, the same slot positions across channels
must hold the same DIMM type with regards to size and organization. DIMM timings do not
have to match but timings will be set to support all DIMMs populated (that is, DIMMs with slower
timings will force faster DIMMs to the slower common timing modes).
3.2.2.4.1 Independent Channel Mode
Channels can be populated in any order in Independent Channel Mode. All four channels may
be populated in any order and have no matching requirements. All channels must run at the
same interface frequency but individual channels may run at different DIMM timings (RAS
latency, CAS Latency, and so forth).
3.2.2.4.2 Rank Sparing Mode
In Rank Sparing Mode, one rank is a spare of the other ranks on the same channel. The spare
rank is held in reserve and is not available as system memory. The spare rank must have
identical or larger memory capacity than all the other ranks (sparing source ranks) on the same
channel. After sparing, the sparing source rank will be lost.
3.2.2.4.3 Mirrored Channel Mode
In Mirrored Channel Mode, the memory contents are mirrored between Channel 0 and Channel 2
and also between Channel 1 and Channel 3. As a result of the mirroring, the total physical
memory available to the system is half of what is populated. Mirrored Channel Mode requires
that Channel 0 and Channel 2, and Channel 1 and Channel 3 must be populated identically with
regards to size and organization. DIMM slot populations within a channel do not have to be
identical but the same DIMM slot location across Channel 0 and Channel 2 and across Channel
1 and Channel 3 must be populated the same.
3.2.2.4.4 Lockstep Channel Mode
In Lockstep Channel Mode, each memory access is a 128-bit data access that spans Channel 0
and Channel 1, and Channel 2 and Channel 3. Lockstep Channel mode is the only RAS mode
that allows SDDC for x8 devices. Lockstep Channel Mode requires that Channel 0 and Channel
1, and Channel 2 and Channel 3 must be populated identically with regards to size and
organization. DIMM slot populations within a channel do not have to be identical but the same
DIMM slot location across Channel 0 and Channel 1 and across Channel 2 and Channel 3 must
be populated the same.
3.2.3 Processor Integrated I/O Module (IIO)
The processor’s integrated I/O module provides features traditionally supported through chipset
components. The integrated I/O module provides the following features:
3.2.3.1 PCI Express* Interfaces
The integrated I/O module incorporates the PCI Express* interface and supports up to 40 lanes
of PCI Express*. Following are key attributes of the PCI Express* interface:
32 Revision 1.1
Intel order number G34153-003
Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS Functional Architecture
®
Intel
Server Board S2600IP and Intel
®
Workstation Board W2600CR supports PCI-e slots from two
processors:
From first processor:
Slot 1: PCIe Gen3 x16 connector
Slot 2: PCIe Gen3 x8 connector
Slot 3: PCIe Gen3 x16 connector
From second processor:
Slot 4: PCIe Gen3 x8 connector
Slot 5: PCIe Gen3 x16 connector
Slot 6: PCIe Gen3 x8 connector
Slot 7: PCIe Gen3 x16 connector
Slot 8: PCIe Gen2 x4 electrical with x8 physical connector.
Note: System will have video output on PCIe slots from first processor by default. If need add-in
video card output on slots from second processor, please refer System Service guide to change
Bios setup.
3.2.3.2 4.2.3.1.2 DMI2 Interface to the PCH
The platform requires an interface to the legacy Southbridge (PCH) which provides basic legacy
functions required for the server platform and operating systems. Since only one PCH is required
and allowed for the system, any sockets which do not connect to PCH would use this port as a
standard x4 PCI Express* 2.0 interface.
3.2.3.3 4.2.3.1.3 Integrated IOAPIC
Provides support for PCI Express* devices implementing legacy interrupt messages without
interrupt sharing.
3.2.3.4 4.2.3.1.4 Non Transparent Bridge
PCI Express* non-transparent bridge (NTB) acts as a gateway that enables high performance,
low overhead communication between two intelligent subsystems; the local and the remote
subsystems. The NTB allows a local processor to independently configure and control the local
subsystem, provides isolation of the local host memory domain from the remote host memory
domain while enabling status and data exchange between the two domains.
3.2.3.5 4.2.3.1.5 Intel® QuickData Technology
Used for efficient, high bandwidth data movement between two locations in memory or from
memory to I/O.
3.3 Intel® C600-A Chipset Functional overview
The Intel® C600-A Chipset in the Intel® Server Board S2600IP and Intel® Workstation Board
W2600CR provide a connection point between various I/O components and Intel® Xeon Sandy
Bridge-EP processors, which includes the following core platform functions:
Revision 1.1 33
Intel order number G34153-003
Functional Architecture Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS
Digital Media Interface (DMI)
PCI Express* Interface
Serial ATA (SATA) Controller
Serial Attached SCSI (SAS)/SATA Controller
AHCI
Rapid Storage Technology
PCI Interface
Low Pin Count (LPC) Interface
Serial Peripheral Interface (SPI)
Compatibility Modules (DMA Controller, Timer/Counters, Interrupt Controller)
Advanced Programmable Interrupt Controller (APIC)
Universal Serial Bus (USB) Controllers
Gigabit Ethernet Controller
RTC
GPIO
Enhanced Power Management
Intel
Manageability
System Management Bus (SMBus* 2.0)
Integrated NVSRAM controller
Virtualization Technology for Directed I/O (Intel
JTAG Boundary-Scan
KVM/Serial Over LAN (SOL) Function
®
Active Management Technology (Intel® AMT)
®
VT-d)
3.3.1 Digital Media Interface (DMI)
Digital Media Interface (DMI) is the chip-to-chip connection between the processor and The
Intel® C600-A Chipset. This high-speed interface integrates advanced priority-based servicing
allowing for concurrent traffic and true isochronous transfer capabilities. Base functionality is
completely software-transparent, permitting current and legacy software to operate normally.
3.3.2 PCI Express* Interface
The Intel® C600-A Chipset provides up to 8 PCI Express* Root Ports, supporting the PCI
Express* Base Specification, Revision 2.0. Each Root Port x1 lane supports up to 5 Gb/s
bandwidth in each direction (10 Gb/s concurrent). PCI Express* Root Ports 1-4 or Ports 5-8 can
independently be configured to support four x1s, two x2s, one x2 and two x1s, or one x4 port
widths.
3.3.3 Serial ATA (SATA) Controller
The Intel® C600-A Chipset has two integrated SATA host controllers that support independent
DMA operation on up to six ports and supports data transfer rates of up to 6.0 Gb/s (600 MB/s)
on up to two ports (Port 0 and 1 Only) while all ports support rates up to 3.0 Gb/s (300 MB/s)
and up to 1.5 Gb/s (150 MB/s). The SATA controller contains two modes of operation – a legacy
mode using I/O space, and an AHCI mode using memory space. Software that uses legacy
mode will not have AHCI capabilities.
34 Revision 1.1
Intel order number G34153-003
Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS Functional Architecture
Intel® RAID C600 Upgrade Key
Options (Product Codes)
Key Color
Description
Default – No option key installed
N/A
4 Port SATA with Intel® ESRT RAID 0,1,10 and Intel®
RSTe RAID 0,1,5,10
RKSATA4R5
Black
4 Port SATA with Intel® ESRT2 RAID 0,1, 5, 10 and Intel®
RSTe RAID 0,1,5,10
RKSATA8
Blue
8 Port SATA with Intel® ESRT2 RAID 0,1, 10 and Intel®
RSTe RAID 0,1,5,10
RKSATA8R5
White
8 Port SATA with Intel® ESRT2 RAID 0,1, 5, 10 and Intel®
RSTe RAID 0,1,5,10
RKSAS4
Green
4 Port SAS with Intel® ESRT2 RAID 0,1, 10 and Intel®
RSTe RAID 0,1,10
RKSAS4R5
Yellow
4 Port SAS with Intel® ESRT2 RAID 0,1, 5, 10 and Intel®
RSTe RAID 0,1,10
RKSAS8
Orange
8 Port SAS with Intel® ESRT2 RAID 0,1, 10 and Intel®
RSTe RAID 0,1,10
RKSAS8R5
Purple
8 Port SAS with Intel® ESRT2 RAID 0,1, 5, 10 and Intel®
RSTe RAID 0,1,10
The Intel® C600-A Chipset chipset supports the Serial ATA Specification, Revision 3.0. The
Intel® C600-A Chipset also supports several optional sections of the Serial ATA II: Extensions to
Serial ATA 1.0 Specification, Revision 1.0 (AHCI support is required for some elements).
3.3.4 Serial Attached SCSI (SAS)/SATA (SCU) Controller
The Intel® C600-A Chipset supports up to 8 SAS ports that are compliant with SAS 2.0
Specification and all ports support rates up to 3.0 Gb/s. All 8 ports are also independently
configurable and compliant with SATA Gen2 and support data transfer rates of up to 3.0 Gb/s.
SAS/SATA controller is only available on specific Intel® C600-A Chipset SKUs with optional
RAID C600 Upgrade key. Certain SKUs are also limited to support 4 of 8 SAS/SATA ports only.
Please refer details below:
Note: SAS/SATA (SCU) port 0-3 is by default enabled while port 4-7 is disabled.
Table 7. Intel® RAID C600 Upgrade Key Options
Additional information for the on-board RAID features and functionality can be found in the Intel®
RAID Software User’s Guide (Intel Document Number D29305-019).
3.3.5 AHCI
The Intel® C600-A Chipset provides hardware support for Advanced Host Controller Interface
(AHCI), a standardized programming interface for SATA host controllers. Platforms supporting
AHCI may take advantage of performance features. AHCI also provides usability enhancements
such as Hot-Plug. AHCI requires appropriate software support (for example, an AHCI driver)
and for some features, hardware support in the SATA device or additional platform hardware.
3.3.6 Rapid Storage Technology
The Intel® C600-A Chipset provides support for Intel® Rapid Storage Technology, providing both
AHCI and integrated RAID functionality. The RAID capability provides high-performance RAID
0, 1, 5, and 10 functionality on the Intel® C600-A chipset. Matrix RAID support is provided to
allow multiple RAID levels to be combined on a single set of hard drives, such as RAID 0 and
RAID 1 on two disks. Other RAID features include hot-spare support, SMART alerting, and
RAID 0 auto replace.
Revision 1.1 35
Intel order number G34153-003
Functional Architecture Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS
3.3.7 PCI Interface
The Intel® C600-A chipset PCI interface provides a 33 MHz, Revision 2.3 implementation. The
Intel® C600-A chipset integrates a PCI arbiter that supports up to four external PCI bus masters
in addition to the internal Intel® C600-A chipset requests. This allows for combinations of up to
four PCI down devices and PCI slots.
3.3.8 Low Pin Count (LPC) Interface
The Intel® C600-A chipset implements an LPC Interface as described in the LPC 1.1
Specification. The Low Pin Count (LPC) bridge function of the Intel® C600-A resides in PCI
Device 31: Function 0. In addition to the LPC bridge interface function, D31:F0 contains other
functional units including DMA, interrupt controllers, timers, power management, system
management, GPIO, and RTC.
3.3.9 Serial Peripheral Interface (SPI)
The Intel® C600-A chipset implements an SPI Interface as an alternative interface for the BIOS
flash device. The SPI flash is required to support Gigabit Ethernet and Intel® Active
Management Technology. The Intel® C600-A chipset supports up to two SPI flash devices with
speeds up to 50 MHz.
3.3.10 Compatibility Modules (DMA Controller, Timer/Counters, Interrupt
Controller)
The DMA controller incorporates the logic of two 82C37 DMA controllers, with seven
independently programmable channels. The Intel® C600-A chipset supports LPC DMA through
the Intel® C600-A chipset’s DMA controller.
The timer/counter block contains three counters that are equivalent in function to those found in
one 82C54 programmable interval timer. These three counters are combined to provide the
system timer function, and speaker tone.
The Intel® C600-A chipset provides an ISA-Compatible Programmable Interrupt Controller (PIC)
that incorporates the functionality of two 82C59 interrupt controllers. In addition, the Intel® C600A chipset supports a serial interrupt scheme.
All of the registers in these modules can be read and restored. This is required to save and
restore system state after power has been removed and restored to the platform.
3.3.11 Advanced Programmable Interrupt Controller (APIC)
In addition to the standard ISA compatible Programmable Interrupt controller (PIC) described in
the previous section, the Intel® C600-A incorporates the Advanced Programmable Interrupt
Controller (APIC).
3.3.12 Universal Serial Bus (USB) Controllers
The Intel® C600-A chipset has up to two Enhanced Host Controller Interface (EHCI) host
controllers that support USB high-speed signaling. High-speed USB 2.0 allows data transfers up
to 480 Mb/s which is 40 times faster than full-speed USB. The Intel® C600-A chipset supports
up to fourteen USB 2.0 ports. All fourteen ports are high-speed, full-speed, and low-speed
capable.
36 Revision 1.1
Intel order number G34153-003
Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS Functional Architecture
3.3.13 Gigabit Ethernet Controller
The Gigabit Ethernet Controller provides a system interface using a PCI function. The controller
provides a full memory-mapped or IO mapped interface along with a 64 bit address master
support for systems using more than 4 GB of physical memory and DMA (Direct Memory
Addressing) mechanisms for high performance data transfers. Its bus master capabilities enable
the component to process high-level commands and perform multiple operations; this lowers
processor utilization by off-loading communication tasks from the processor. Two large
configurable transmit and receive FIFOs (up to 20 KB each) help prevent data underruns and
overruns while waiting for bus accesses. This enables the integrated LAN controller to transmit
data with minimum interframe spacing (IFS).
The LAN controller can operate at multiple speeds (10/100/1000 MB/s) and in either full duplex
or half duplex mode. In full duplex mode the LAN controller adheres with the IEEE 802.3x Flow
Control Specification. Half duplex performance is enhanced by a proprietary collision reduction
mechanism.
3.3.14 RTC
The Intel® C600-A chipset contains a real-time clock with 256 bytes of battery-backed RAM. The
real-time clock performs two key functions: keeping track of the time of day and storing system
data. The RTC operates on a 32.768 KHz crystal and a 3 V battery.
3.3.15 GPIO
Various general purpose inputs and outputs are provided for custom system design. The
number of inputs and outputs varies depending on the Intel® C600-A chipset configuration.
3.3.16 Enhanced Power Management
The Intel® C600-A chipset’s power management functions include enhanced clock control and
various low-power (suspend) states (for example, Suspend-to-RAM and Suspend-to-Disk). A
hardware-based thermal management circuit permits software-independent entrance to lowpower states. The Intel® C600-A chipset contains full support for the Advanced Configuration
and Power Interface (ACPI) Specification, Revision 4.0a.
3.3.17 Manageability
In addition to Intel AMT the Intel® C600-A chipset integrates several functions designed to
manage the system and lower the total cost of ownership (TCO) of the system. These system
management functions are designed to report errors, diagnose the system, and recover from
system lockups without the aid of an external microcontroller.
3.3.18 System Management Bus (SMBus* 2.0)
The Intel® C600-A chipset contains a SMBus* Host interface that allows the processor to
communicate with SMBus* slaves. This interface is compatible with most I2C devices. Special
I2C commands are implemented.
The Intel® C600-A chipset’s SMBus* host controller provides a mechanism for the processor to
initiate communications with SMBus* peripherals (slaves). Also, the Intel® C600-A chipset
supports slave functionality, including the Host Notify protocol. Hence, the host controller
supports eight command protocols of the SMBus* interface (see System Management Bus
(SMBus*) Specification, Version 2.0): Quick Command, Send Byte, Receive Byte, Write
Byte/Word, Read Byte/Word, Process Call, Block Read/Write, and Host Notify.
Revision 1.1 37
Intel order number G34153-003
Functional Architecture Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS
The Intel® C600-A chipset’s SMBus* also implements hardware-based Packet Error Checking
for data robustness and the Address Resolution Protocol (ARP) to dynamically provide address
to all SMBus* devices.
3.3.19 Integrated NVSRAM controller
The Intel® C600-A chipset has an integrated NVSRAM controller that supports up to 32KB
external device. The host processor can read and write data to the NVSRAM component.
3.3.20 Virtualization Technology for Directed I/O (Intel® VT-d)
The Intel® C600-A chipset provides hardware support for implementation of Intel® Virtualization
Technology with Directed I/O (Intel® VT-d). Intel VT-d consists of technology components that
support the virtualization of platforms based on Intel® Architecture Processors. Intel VT-d
Technology enables multiple operating systems and applications to run in independent
partitions. A partition behaves like a virtual machine (VM) and provides isolation and protection
across partitions. Each partition is allocated its own subset of host physical memory.
3.3.21 JTAG Boundary-Scan
The Intel® C600-A chipset adds the industry standard JTAG interface and enables BoundaryScan in place of the XOR chains used in previous generations of chipsets. Boundary-Scan can
be used to ensure device connectivity during the board manufacturing process. The JTAG
interface allows system manufacturers to improve efficiency by using industry available tools to
test the Intel® C600-A chipset on an assembled board. Since JTAG is a serial interface, it
eliminates the need to create probe points for every pin in an XOR chain. This eases pin
breakout and trace routing and simplifies the interface between the system and a bed-of-nails
tester.
3.3.22 KVM/Serial Over Lan (SOL) Function
These functions support redirection of keyboard, mouse, and text screen to a terminal window
on a remote console. The keyboard, mouse, and text redirection enables the control of the client
machine through the network. Text, mouse, and keyboard redirection allows the remote
machine to control and configure the client by entering BIOS setup. The KVM/SOL function
emulates a standard PCI serial port and redirects the data from the serial port to the
management console using LAN. KVM has additional requirements of internal graphics and
SOL may be used when KVM is not supported.
3.3.23 On-board SAS/SATA Support and Options
The Intel
By default the server board will support up to 10 SATA ports: Two white 6Gb/sec SATA ports
from the AHCI controller labeled as “SATA_0” and “SATA_1” and two MINISAS 3Gb/sec SATA/SAS
ports routed from the SCU controller labeled as “SCU0 (PORT0-3) and “SCU1(PORT4-7).
The SCU Port can be configured with the two embedded software RAID options:
3.3.23.1 Intel® Embedded Server RAID Technology 2 (ESRT2)
Features of the embedded software RAID option Intel® Embedded Server RAID Technology 2
®
C600 chipset provides storage support by two integrated controllers: AHCI and SCU.
Intel
®
Embedded Server RAID Technology 2 (ESRT2) based on LSI* MegaRAID SW
RAID technology supporting RAID levels 0,1, and 10.
Intel
®
Rapid Storage Technology (RSTe) supporting RAID levels 0, 1, 5, and 10.
38 Revision 1.1
Intel order number G34153-003
Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS Functional Architecture
(ESRT2) include the following:
Based on LSI* MegaRAID Software Stack
Software RAID with system providing memory and CPU utilization
Supported RAID Levels – 0,1,5,10
4 and 8 Port SATA RAID 5 support provided with appropriate Intel
®
RAID C600
Upgrade Key
4 and 8 Port SAS RAID 5 support provided with appropriate Intel
®
RAID C600
Upgrade Key
Maximum drive support = 8
Open Source Compliance = Binary Driver (includes Partial Source files) or Open Source
using MDRAID layer in Linux.
OS Support = Windows 7*, Windows 2008*, Windows 2003*, RHEL*, SLES, other Linux*
variants using partial source builds.
Utilities = Windows* GUI and CLI, Linux GUI and CLI, DOS CLI, and EFI CLI
3.3.23.2 Intel® Rapid Storage Technology (RSTe)
Features of the embedded software RAID option Intel® Rapid Storage Technology (RSTe)
include the following:
Software RAID with system providing memory and CPU utilization
Supported RAID Levels – 0,1,5,10
o 4 Port SATA RAID 5 available standard (no option key required)
o 8 Port SATA RAID 5 support provided with appropriate Intel® RAID C600 Upgrade
Key
o No SAS RAID 5 support
Maximum drive support = 32 (in arrays with 8 port SAS), 16 (in arrays with 4 port SAS),
128 (JBOD)
Open Source Compliance = Yes (uses MDRAID)
OS Support = Windows 7*, Windows 2008*, Windows 2003*, RHEL* 6.2 and later,
SLES* 11 w/SP2 and later, VMWare* 5.x.
Utilities = Windows* GUI and CLI, Linux CLI, DOS CLI, and EFI CLI
Uses Matrix Storage Manager for Windows*
MDRAID supported in Linux* (does not require a driver)
Note: No boot drive support to targets attached through SAS expander card
3.4 PCI Subsystem
The primary I/O buses for the Intel® Server Board S2600IP and Intel® Workstation Board
W2600CR are PCI Express* Gen3 with six independent PCI bus segments. The following tables
list the characteristics of the PCI bus segments.
Revision 1.1 39
Intel order number G34153-003
Functional Architecture Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS
Voltage
Width
Speed
Type
PCI I/O Card Slots
3.3 V
x16
32 GB/S
PCI
Express*
Gen3
X16 PCI Express* Gen3 throughput
to Slot1 (x16 mechanically)
3.3 V
X8 or none
(with mux)
16 GB/S or
none
PCI
Express*
Gen3
x8 PCI Express* Gen3 throughput
to Slot 2 (x8 mechanically)
3.3 V
x16 or x8(with
mux)
32 GB/S or
16 GB/S
PCI
Express*
Gen3
x16 PCI Express* Gen3 throughput
to Slot 3 (x16 mechanically)
3.3 V
X8 or none
(with mux)
16 GB/S or
none
PCI
Express*
Gen3
x8 PCI Express* Gen3 throughput
to Slot 4 (x8 mechanically, NonPersistent)
3.3 V
x16 or x8(with
mux)
32 GB/S or
16 GB/S
PCI
Express*
Gen3
X16 PCI Express* Gen3 throughput
to Slot 5 (x16 mechanically, NonPersistent)
3.3 V
X8 or none
(with mux)
16 GB/S or
none
PCI
Express*
Gen3
x8 PCI Express* Gen3 throughput
to Slot 6 (x8 mechanically, NonPersistent)
3.3 V
x16 or x8(with
mux)
32 GB/S or
16 GB/S
PCI
Express*
Gen3
X16 PCI Express* Gen3 throughput
to Slot 7 (x16 mechanically, NonPersistent)
3.3 V
X4
4 GB/S
PCI
Express*
Gen2
X4 PCI Express* Gen2 throughput
to Slot 8 (x8 mechanically, NonPersistent)
Table 8. Intel® Server Board S2600IP/Workstation Board W2600CR PCI Bus Segment
Characteristics
3.5 Network Interface Controller
The Intel® Server Board S2600IP and Workstation Board S2600CR has a Intel® Ethernet
Controller I350 GbE Controller. The controller supports PCI Express* PCIe v2.0 (5GT/s and
2.5GT/s). The controller enables four-port or two-port 1000BASE-T implementations using
integrated PHY’s. The controller supports VMDq, SR-IOV, EEE, and DMA Coalescing.
3.5.1 Network Interface
Network connectivity is provided by means of an onboard Intel® Ethernet Controller 1350-AM4
providing up to four 10/100/1000 Mb Ethernet ports.
On the Intel® Server Board S2600IP, four external 10/100/1000 Mb RJ45 Ethernet ports are
provided. On the Intel® Workstation Board W2600CR, two external 10/100/1000 Mb RJ45
Ethernet ports are provided. Each Ethernet port drives two LEDs located on each network
interface connector. The LED at the right of the connector is the link/activity LED and indicates
network connection when on, and transmit/receive activity when blinking. The LED at the left of
the connector indicates link speed as defined in the following table.
40 Revision 1.1
Intel order number G34153-003
Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS Functional Architecture
LED Color
LED State
NIC State
Green/Amber (Right)
Off
10 Mbps
Amber
100 Mbps
Green
1000 Mbps
Green (Left)
On
Active Connection
Blinking
Transmit/Receive activity
Figure 20. External RJ45 NIC Port LED Definition
3.6 I/O Module Support (not avaiable for Intel® Server Board
S2600IP4L and Intel® Workstation Board W2600CR2L)
To broaden the standard on-board feature set, the server board supports the option of adding a
single I/O module providing external ports for a variety of networking interfaces. The I/O module
attaches to a high density 80-pin connector on the server board labeled “IO_Module”.
Supported I/O modules include:
Revision 1.1 41
Intel order number G34153-003
Functional Architecture Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS
Product Code and iPN
Description
AXX10GBNIAIOM
MM# 917905
Dual SFP+ port 10GbE IO Module based on Intel® 82599 10GbE Ethernet Controller
AXX10GBTWLIOM
MM# 917907
Dual RJ45 Port, 10GBASE-T IO Module, based on Intel® I350 Ethernet chipset
AXX1FDRIBIOM
MM# 918607
Single Port, FDR speed Infiniband* module, with QSFP connector.
AXX4P1GBPWLIOM
MM# 917911
Quad Port 1GbE 1o Module based on Intel® Ethernet Controller I350
AXXIOMKIT
MM# 920852
I/O Module Cable and Brackets
Figure 21. Supported I/O Module Options
Notes:
1. I/O Module cable and Brackets accessory is necessary to support I/O module on Intel® Server Board
S2600IP.
2. IOM connector only supports PCIe Gen1 Speed
3.7 SAS ROC Module Support
The system provides support for Intel® Integrated RAID mezzanine modules that utilize a high
density 80-pin connector (labeled “SAS_MOD”) on the server board.
42 Revision 1.1
Intel order number G34153-003
Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS Functional Architecture
External Name
Description
Product Code
Intel® Integrated RAID Module
RMS25CB080
8 Port SAS-2.1, Full HW RAID, 1GB, Mezz Slot
RAID Levels 0,1,10, 5, 50, 6, 60
RMS25CB080
Intel® Integrated RAID Module
RMS25CB040
4 Port SAS-2.1, Full HW RAID, 1GB, Mezz Slot
RAID Levels 0,1,10, 5, 50, 6, 60
RMS25CB040
Intel® Integrated RAID Module
RMT3CB080
8 Port SATA-3, Full HW RAID, 512MB, Mezz
Slot
RAID Levels 0,1,10, 5, 50, 6, 60
RMT3CB080
Intel® Integrated RAID Module
RMS25KB080
8 Port SAS-2.1, Entry-level HW RAID, Mezz Slot
RAID Levels 0,1,1E
RMS25KB080
Intel® Integrated RAID Module
RMS25KB040
4 Port SAS-2.1, Entry-level HW RAID, Mezz Slot
RAID Levels 0,1,1E
RMS25KB040
Features of this option include:
Does not utilize a PCIe slot
SKU options to support full or entry level hardware RAID
4 or 8 port and SAS/SATA or SATA –only ROC options
SKU options to support 512MB or 1GB embedded memory
Intel designed flash + optional support for super-cap backup (Maintenance Free Back
Up) or improved Lithium Polymer battery
Table 9. Supported Intel® Integrated RAID Modules
For additional product information, please refer the following Intel® document:
Intel® Integrated RAID Module RMS25PB080, RMS25PB040, RMS25CB080, and
RMS25CB040 Hardware User’s Guide – Intel Order Number G37519-003.
3.8 HD Audio Support (Intel® Workstation Board W2600CR Only)
The Intel® Workstation Board W2600CR support 7.1 HD Audio through the High Definition
Audio Codec Realtek* ALC889. The ALC889 provides ten DAC channels that simultaneously
support 7.1 sound playback, plus two channels of independent stereo sound output (multiple
streaming) through the front panel stereo outputs. Also supports two channels of S/PDIF In/Out
Revision 1.1 43
Intel order number G34153-003
Functional Architecture Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS
Channel name
Identifier
1.0
Mono
2.0
Stereo
5.1
Surround
7.1
Surround
Front Left
SPEAKER_FRONT_LEFT
No
Yes
Yes
Yes
Front Right
SPEAKER_FRONT_RIGHT
No
Yes
Yes
Yes
Front Center
SPEAKER_FRONT_CENTER
Yes
No
Yes
Yes
Low Frequency (Subwoofer)
SPEAKER_LOW_FREQUENCY
No
No
Yes
Yes
Back Left
SPEAKER_BACK_LEFT
No
No
Yes
Yes
Back Right
SPEAKER_BACK_RIGHT
No
No
Yes
Yes
Side Left
SPEAKER_SIDE_LEFT
No
No
No
Yes
Side Right
SPEAKER_SIDE_RIGHT
No
No
No
Yes
(W2600CR only supports 1 S/PDIF Out port) and two channels of Microphone In (Front/Rear).
The ALC889 is driven by the Intel® HD Audio Interface (Azalia) from Intel® C600-A chipset.
Table 10. Standard Speaker Channels
3.9 USB3.0 Support (Intel® Workstation Board W2600CR Only)
The Intel® Workstation Board W2600CR supports two USB3.0 SuperSpeed* ports, which is
required as a standard Workstation feature. The TI 2 port USB3.0 discrete host controller
TUSB7320 is used to meet this requirement. The TUSB7320 USB3.0 host controller complies
with Universal Serial Bus 3.0 Specification and Intel’s eXtensible Host Controller Interface
(xHCI).
Figure 22. USB3.0 Discrete Host Controller Block Diagram
44 Revision 1.1
Intel order number G34153-003
Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS Functional Architecture
3.10 IEEE1394b Support (Intel® Workstation Board W2600CR Only)
Intel® Workstation Board W2600CR offers one front panel IEEE 1394b port from a discrete
controller (Texas Instruments XIO2221).The XIO2221 uses a PCIe x1 Gen 1 upstream interface
from Intel® C600-A chipset. When connected to 1394b compliant devices, the XIO2221 can
transfer data at speeds of up to 800 Mbps. The Intel® Workstation Board W2600CR includes an
internal 1394b connector that allows for a front panel 1394b cable attach.
Figure 23. IEEE 1394b Discrete Host Controller Block Diagram
Revision 1.1 45
Intel order number G34153-003
Platform Management OverviewIntel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS
4. Platform Management Overview
4.1 Server Management Function Architecture
4.1.1 Feature Support
4.1.1.1 IPMI 2.0 Features
The IPMI 2.0 features are as follows:
1. Baseboard management controller (BMC)
2. IPMI Watchdog timer
3. Messaging support, including command bridging and user/session support
4. Chassis device functionality, including power/reset control and BIOS boot flags support
5. Event receiver device: The BMC receives and processes events from other platform
subsystems.
6. Field Replaceable Unit (FRU) inventory device functionality: The BMC supports access to
system FRU devices using IPMI FRU commands.
7. System Event Log (SEL) device functionality: The BMC supports and provides access to a
SEL.
8. Sensor Data Record (SDR) repository device functionality: The BMC supports storage and
access of system SDRs.
9. Sensor device and sensor scanning/monitoring: The BMC provides IPMI management of
sensors. It polls sensors to monitor and report system health.
10. IPMI interfaces
11. Host interfaces include system management software (SMS) with receive message queue
support, and server management mode (SMM)
12. IPMB interface
13. LAN interface that supports the IPMI-over-LAN protocol Remote Management Control
Protocol (RMCP, RMCP+)
14. Serial-over-LAN (SOL)
15. ACPI state synchronization: The BMC tracks ACPI state changes that are provided by the
BIOS.
16. BMC self test: The BMC performs initialization and run-time self-tests and makes results
available to external entities.
See also the Intelligent Platform Management Interface Specification Second Generation,
Version 2.0.
4.1.1.2 Non IPMI features
The BMC supports the following non-IPMI features. This list does not preclude support for future
enhancements or additions.
In-circuit BMC firmware update
46 Revision 1.1
Intel order number G34153-003
Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPSPlatform Management Overview
Fault resilient booting (FRB): FRB2 is supported by the watchdog timer functionality.
Chassis intrusion detection (dependent on platform support)
Basic fan control using Control version 2 SDRs
Fan redundancy monitoring and support
Power supply redundancy monitoring and support
Hot-swap fan support
Acoustic management: Support for multiple fan profiles
Signal testing support: The BMC provides test commands for setting and getting
platform signal states.
The BMC generates diagnostic beep codes for fault conditions.
System GUID storage and retrieval
Front panel management: The BMC controls the system status LED and chassis ID
LED. It supports secure lockout of certain front panel functionality and monitors button
presses. The chassis ID LED is turned on using a front panel button or a command.
Power state retention
Power fault analysis
Intel
Power unit management: Support for power unit sensor. The BMC handles power-
®
Light-Guided Diagnostics
good dropout conditions.
DIMM temperature monitoring: New sensors and improved acoustic management
using closed-loop fan control algorithm taking into account DIMM temperature
readings.
Address Resolution Protocol (ARP): The BMC sends and responds to ARPs
(supported on embedded NICs).
Dynamic Host Configuration Protocol (DHCP): The BMC performs DHCP (supported
on embedded NICs).
Platform environment control interface (PECI) thermal management support
E-mail alerting
Embedded web server
Integrated KVM.
Integrated Remote Media Redirection
Lightweight Directory Access Protocol (LDAP) support
Intel
®
Intelligent Power Node Manager support
4.1.1.3 New Manageability Features
Intel® S1400/S1600/S2400/S2600 Server Platforms offer a number of changes and additions to
the manageability features that are supported on the previous generation of servers. The
following is a list of the more significant changes that are common to this generation Integrated
BMC based Intel® Server boards:
Sensor and SEL logging additions/enhancements (for example, additional thermal
monitoring capability)
SEL Severity Tracking and the Extended SEL
Revision 1.1 47
Intel order number G34153-003
Platform Management OverviewIntel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS
Embedded platform debug feature which allows capture of detailed data for later
analysis.
Provisioning and inventory enhancements:
o Inventory data/system information export (partial SMBIOS table)
Enhancements to fan speed control.
DCMI 1.1 compliance (product-specific).
Support for embedded web server UI in Basic Manageability feature set.
Enhancements to embedded web server
o Human-readable SEL
o Additional system configurability
o Additional system monitoring capability
o Enhanced on-line help
Enhancements to KVM redirection
o Support for higher resolution
Support for EU Lot6 compliance
Management support for PMBus* rev1.2 compliant power supplies
BMC Data Repository (Managed Data Region Feature)
Local Control Display Panel
System Airflow Monitoring
Exit Air Temperature Monitoring
Ethernet Controller Thermal Monitoring
Global Aggregate Temperature Margin Sensor
Memory Thermal Management
Power Supply Fan Sensors
Energy Star Server Support
Smart Ride Through (SmaRT)/ Closed Loop System Throttling (CLST)
Power Supply Cold Redundancy
Power Supply FW Update
Power Supply Compatibility Check
BMC FW reliability enhancements:
o Redundant BMC boot blocks to avoid possibility of a corrupted boot block resulting
in a scenario that prevents a user from updating the BMC.
o BMC System Management Health Monitoring
4.1.2 Basic and Advanced Features
The bellowing table lists basic and advanced feature support. Individual features may vary by
platform. See the appropriate Platform Specific EPS addendum for more information.
48 Revision 1.1
Intel order number G34153-003
Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPSPlatform Management Overview
Feature
Basic
Advanced
IPMI 2.0 Feature Support
X
X
In-circuit BMC Firmware Update
X
X
FRB 2 X X
Chassis Intrusion Detection
X
X
Fan Redundancy Monitoring
X
X
Hot-Swap Fan Support
X
X
Acoustic Management
X
X
Diagnostic Beep Code Support
X
X
Power State Retention
X
X
ARP/DHCP Support
X
X
PECI Thermal Management Support
X
X
E-mail Alerting
X
X
Embedded Web Server
X
X
SSH Support
X
X
Integrated KVM
X
Integrated Remote Media Redirection
X
Lightweight Directory Access Protocol (LDAP)
X
X
Intel® Intelligent Power Node Manager Support
X
X
SMASH CLP
X
X
Table 11. Basic and Advanced Features
4.1.3 Integrated BMC Hardware: Emulex* Pilot III
4.1.3.1 Emulex* Pilot III Baseboard Management Controller Functionality
The Integrated BMC is provided by an embedded ARM9 controller and associated peripheral
functionality that is required for IPMI-based server management. Firmware usage of these
hardware features is platform dependent.
The following is a summary of the Integrated BMC management hardware features that
comprise the BMC:
400MHz 32-bit ARM9 processor with memory management unit (MMU)
Two independent10/100/1000 Ethernet Controllers with Reduced Media Independent
Interface (RMII)/ Reduced Gigabit Media Independent Interface (RGMII) support
DDR2/3 16-bit interface with up to 800 MHz operation
16 10-bit ADCs
Sixteen fan tachometers
Eight Pulse Width Modulators (PWM)
Chassis intrusion logic
JTAG Master
Eight I2C interfaces with master-slave and SMBus* timeout support. All interfaces are
SMBus* 2.0 compliant.
Parallel general-purpose I/O Ports (16 direct, 32 shared)
Serial general-purpose I/O Ports (80 in and 80 out)
Three UARTs
Platform Environmental Control Interface (PECI)
Revision 1.1 49
Intel order number G34153-003
Platform Management OverviewIntel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS
Six general-purpose timers
Interrupt controller
Multiple Serial Peripheral Interface (SPI) flash interfaces
NAND/Memory interface
Sixteen mailbox registers for communication between the BMC and host
LPC ROM interface
BMC watchdog timer capability
SD/MMC card controller with DMA support
LED support with programmable blink rate controls on GPIOs
Port 80h snooping capability
Secondary Service Processor (SSP), which provides the HW capability of offloading time
critical processing tasks from the main ARM core.
Emulex* Pilot III contains an integrated SIO, KVMS subsystem and graphics controller with the
following features:
4.1.3.1.1 Super I/O (SIO)
The BMC integrates a super I/O module with the following features:
Keyboard Style/BT interface for BMC support
Two Fully Functional Serial Ports, compatible with the 16C550
Serial IRQ Support
Up to 16 Shared GPIO available for host processor
Programmable Wake-up Event Support
Plug and Play Register Set
Power Supply Control
4.1.3.1.2 Graphics Controller
The graphics controller provides the following features:
Integrated Graphics Core with 2D Hardware accelerator
High speed Integrated 24-bit RAMDAC
DDR-2/3 memory interface with 16Mbytes of memory allocated and reported for
graphics memory.
4.1.3.1.3 Remote Keyboard, Video, Mouse, and Storage (KVMS )
The Integrated BMC contains a remote KVMS subsystem with the following features:
USB 2.0 interface for Keyboard, Mouse and Remote storage such as CD/DVD ROM and
floppy
USB 1.1/USB 2.0 interface for PS2 to USB bridging, remote Keyboard and Mouse
Hardware Based Video Compression and Redirection Logic
Supports both text and Graphics redirection
Hardware assisted Video redirection using the Frame Processing Engine
Direct interface to the Integrated Graphics Controller registers and Frame buffer
Hardware-based encryption engine
50 Revision 1.1
Intel order number G34153-003
Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPSPlatform Management Overview
Figure 24. Integrated BMC Hardware
4.2 Server Management Functional Specifications
4.2.1 BMC Internal Timestamp Clock
The BMC maintains an internal timestamp clock that is used by various BMC subsystems, for
example, time stamping SEL entries. As part of BMC initialization after AC power is applied or
the BMC is reset, the BMC initializes this internal clock to the value retrieved from the SSB
component’s RTC from a SMBus* slave read operation. This is the system RTC and is on the
battery power well so it maintains the current time even when there is no AC supplied to the
system.
4.2.1.1 System Clock Synchronization
The BIOS must send the Set SEL Time command with the current system time to the BMC
during system Power-on Self Test (POST). Synchronization during very early POST is
preferred, so that any SEL entries recorded during system boot can be accurately time
stamped. Additionally, during sleep state transitions other than S0 the BIOS will synchronize the
time.
If the time is modified through an OS interface, then the BMC’s time is not synchronized until the
next system reboot.
Revision 1.1 51
Intel order number G34153-003
Platform Management OverviewIntel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS
Code
Reason for Beep
Associated Sensors
1-5-2-1
No CPUs installed or first CPU socket is
empty.
CPU Missing Sensor
1-5-2-4
MSID Mismatch.
MSID Mismatch Sensor.
1-5-4-2
Power fault: DC power is unexpectedly
lost (power good dropout).
Power unit – power unit failure
offset.
1-5-4-4
Power control fault (power good assertion
timeout).
Power unit – soft power control
failure offset.
1-5-1-2
VR Watchdog Timer sensor assertion
VR Watchdog Timer
4.2.2 System Event Log (SEL)
The BMC implements the system event log as specified in the Intelligent Platform Management
Interface Specification, Version 2.0. The SEL is accessible regardless of the system power state
through the BMC's in-band and out-of-band interfaces.
The BMC allocates 95231 bytes (approximately 93 KB) of non-volatile storage space to store
system events. The SEL timestamps may not be in order. Up to 3,639 SEL records can be
stored at a time. Any command that results in an overflow of the SEL beyond the allocated
space is rejected with an “Out of Space” IPMI completion code (C4h).
4.2.3 Sensor Data Record (SDR) Repository
The BMC implements the sensor data record (SDR) repository as specified in the Intelligent
Platform Management Interface Specification, Version 2.0. The SDR is accessible through the
BMC’s in-band and out-of-band interfaces regardless of the system power state The BMC
allocates 65,519 bytes of non-volatile storage space for the SDR.
4.2.4 Field Replaceable Unit (FRU) Inventory Device
The BMC implements the interface for logical FRU inventory devices as specified in the
Intelligent Platform Management Interface Specification, Version 2.0. This functionality provides
commands used for accessing and managing the FRU inventory information. These commands
can be delivered through all interfaces.
The BMC provides FRU device command access to its own FRU device and to the FRU
devices throughout the server. The FRU device ID mapping is defined in the Platform Specific
Information. The BMC controls the mapping of the FRU device ID to the physical device.
4.2.5 BMC Beep Codes
The BMC may generate beep codes upon detection of failure conditions. Beep codes are
sounded each time the problem is discovered (for example, on each power-up attempt), but are
not sounded continuously. Common supported codes are listed in below Table
Additional platform-specific beep codes can be found in the appropriate Platform Specific
Information. Each digit in the code is represented by a sequence of beeps whose count is equal
to the digit.
Table 12. BMC Beep Codes
52 Revision 1.1
Intel order number G34153-003
Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPSPlatform Management Overview
Code
Reason for Beep
Associated Sensors
1-5-1-4
The system does not power on or
unexpectedly powers off and a power
supply unit (PSU) is present that is an
incompatible model with one or more
other PSUs in the system
PS Status
Causal Event
NMI
Signal Generation
Front Panel Diag Interrupt Sensor Event
Logging Support
Chassis Control command (pulse diagnostic
interrupt)
X
–
Front panel diagnostic interrupt button pressed
X
X
Watchdog Timer pre-timeout expiration with
NMI/diagnostic interrupt action
X
X
4.2.6 Diagnostic Interrupt (NMI) Button
The BMC generates an NMI pulse under certain conditions. The BMC-generated NMI pulse
duration is at least 30 ms. Once an NMI has been generated by the BMC, the BMC does not
generate another NMI until the system has been reset or powered down.
The following actions cause the BMC to generate an NMI pulse:
1. Receiving a Chassis Control command to pulse the diagnostic interrupt. This command
does not cause an event to be logged in the SEL.
2. Watchdog timer pre-timeout expiration with NMI/diagnostic interrupt pre-timeout action
enabled.
The following table shows the behavior regarding NMI signal generation and event logging
by the BMC.
Table 13. NMI Signal Generation and Event Logging
4.2.7 BMC Watchdog
The BMC FW is increasingly called upon to perform system functions that are time-critical in
that failure to provide these functions in a timely manner can result in system or component
damage. Intel® S1400/S1600/S2400/S2600 Server Platforms introduce a BMC watchdog
feature to provide a safe-guard against this scenario by providing an automatic recovery
mechanism. It also can provide automatic recovery of functionality that has failed due to a fatal
FW defect triggered by a rare sequence of events or a BMC hang due to some type of HW
glitch (for example, power).
This feature is comprised of a set of capabilities whose purpose is to detect misbehaving
subsections of BMC firmware, the BMC CPU itself, or HW subsystems of the BMC component,
and to take appropriate action to restore proper operation. The action taken is dependent on the
nature of the detected failure and may result in a restart of the BMC CPU, one or more BMC
HW subsystems, or a restart of malfunctioning FW subsystems.
The BMC watchdog feature will only allow up to three resets of the BMC CPU (such as HW
reset) or entire FW stack (such as a SW reset) before giving up and remaining in the uBOOT
code. This count is cleared upon cycling of power to the BMC or upon continuous operation of
Revision 1.1 53
Intel order number G34153-003
Platform Management OverviewIntel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS
the BMC without a watchdog-generated reset occurring for a period of > 30 minutes. The BMC
FW logs a SEL event indicating that a watchdog-generated BMC reset (either soft or hard reset)
has occurred. This event may be logged after the actual reset has occurred. Refer sensor
section for details for the related sensor definition. The BMC will also indicate a degraded
system status on the Front Panel Status LED after an BMC HW reset or FW stack reset. This
state (which follows the state of the associated sensor) will be cleared upon system reset or (AC
or DC) power cycle.
Note: A reset of the BMC may result in the following system degradations that will require a
system reset or power cycle to correct:
1. Timeout value for the rotation period can be set using this parameter; potentially incorrect
ACPI Power State reported by the BMC.
2. Reversion of temporary test modes for the BMC (for example, as set through Set SM Signal
command) back to normal operational modes.
3. FP status LED and DIMM fault LEDs may not reflect BIOS detected errors.
4.3 Sensor Monitoring
4.3.1 Overview
The BMC monitors system hardware and reports system health. The information gathered from
physical sensors is translated into IPMI sensors as part of the “IPMI Sensor Model”. The BMC
also reports various system state changes by maintaining virtual sensors that are not
specifically tied to physical hardware. This section describes the BMC sensors as well as
describing how specific sensor types are modeled. Unless otherwise specified, the term
“sensor” refers to the IPMI sensor-model definition of a sensor.
4.3.2 Core Sensor List for EPSD Platforms Based on Intel® Xeon® Processor
E5 4600/2600/2400/1600/1400 Product Families
Specific server boards may only implement a sub-set of sensors and/or may include additional
sensors. The system-specific details of supported sensors and events are described in the
Appendix of this document. The actual sensor name associated with a sensor number may vary
between server boards or systems.
Sensor Type Codes
Sensor table given below lists the sensor identification numbers and information regarding the
sensor type, name, supported thresholds, assertion and de-assertion information, and a brief
description of the sensor purpose. Refer to the Intelligent Platform Management Interface
Specification, Version 2.0 for sensor and event/reading-type table information.
Sensor Type
The sensor type references the values in the Sensor Type Codes table in the Intelligent
Platform Management Interface Specification Second Generation v2.0. It provides a
context to interpret the sensor.
Event/Reading Type
The event/reading type references values from the Event/Reading Type Code Ranges
and the Generic Event/Reading Type Code tables in the Intelligent Platform
Management Interface Specification Second Generation v2.0. Digital sensors are
specific type of discrete sensors that only have two states.
Event Thresholds/Triggers
54 Revision 1.1
Intel order number G34153-003
Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPSPlatform Management Overview
The following event thresholds are supported for threshold type sensors:
- [u,l][nr,c,nc] upper non-recoverable, upper critical, upper non-critical, lower
non-recoverable, lower critical, lower non-critical uc, lc upper critical, lower critical
Event triggers are supported event-generating offsets for discrete type sensors. The
offsets can be found in the Generic Event/Reading Type Code or Sensor Type Code
tables in the Intelligent Platform Management Interface Specification Second
Generation, Version 2.0, depending on whether the sensor event/reading type is generic
or a sensor-specific response.
Assertion/Deassertion
Assertion and de-assertion indicators reveal the type of events this sensor generates:
- As: Assertion
- De: De-assertion
Readable Value/Offsets
- Readable value indicates the type of value returned for threshold and other non-
discrete type sensors.
- Readable offsets indicate the offsets for discrete sensors that are readable by means
of the Get Sensor Reading command. Unless otherwise indicated, event triggers are
readable. Readable offsets consist of the reading type offsets that do not generate
events.
Event Data
Event data is the data that is included in an event message generated by the associated
sensor. For threshold-based sensors, these abbreviations are used:
- R: Reading value
- T: Threshold value
Rearm Sensors
The rearm is a request for the event status for a sensor to be rechecked and updated
upon a transition between good and bad states. Rearming the sensors can be done
manually or automatically. This column indicates the type supported by the sensor. The
following abbreviations are used in the comment column to describe a sensor:
- A: Auto-rearm
- M: Manual rearm
- I: Rearm by init agent
Default Hysteresis
The hysteresis setting applies to all thresholds of the sensor. This column provides the
count of hysteresis for the sensor, which can be 1 or 2 (positive or negative hysteresis).
Criticality
Criticality is a classification of the severity and nature of the condition. It also controls the
behavior of the front panel status LED.
Standby
Some sensors operate on standby power. These sensors may be accessed and/or
generate events when the main (system) power is off, but AC power is present.
Revision 1.1 55
Intel order number G34153-003
Platform Management OverviewIntel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS
Offset
Description
Event Logging
04h
Sensor failure
Assertion and deassertion
Sensor Name
Per-Processor
Socket
Description
Processor Status
Yes
Processor presence and fault state
Digital Thermal Sensor
Yes
Relative temperature reading by means of PECI
Processor VRD Over-Temperature
Indication
Yes
Discrete sensor that indicates a processor VRD has
crossed an upper operating temperature threshold
Processor Voltage
Yes
Threshold sensor that indicates a processor power-good
state
Processor Thermal Control (Prochot)
Yes
Percentage of time a processor is throttling due to
thermal conditions
4.3.3 BMC System Management Health Monitoring
The BMC tracks the health of each of its IPMI sensors and report failures by providing a “BMC
FW Health” sensor of the IPMI 2.0 sensor type Management Subsystem Health with support for
the Sensor Failure offset. Only assertions should be logged into the SEL for the Sensor Failure
offset. The sensor number of the failed sensor is provided in event data byte 2, as per the IPMI
2.0 Specification. The BMC Firmware Health sensor asserts for any sensor when 10
consecutive sensor errors are read. These are not standard sensor events (that is, threshold
crossings or discrete assertions). These are BMC Hardware Access Layer (HAL) errors like I2C
NAKs or internal errors while attempting to read a register. If a successful sensor read is
completed, the counter resets to zero.
IPMI Sensor Characteristics
1. Event reading type code: 6Fh (Sensor specific)
2. Sensor type code: 28h (Management Subsystem Health)
3. Rearm type: Auto
If this sensor is implemented, then the following sensor-specific offsets are supported.
Table 14. Supported BMC FW Health Sensor Offsets
4.3.4 Processor Sensors
The BMC provides IPMI sensors for processors and associated components, such as voltage
regulators and fans. The sensors are implemented on a per-processor basis.
Table 15. Processor Sensors
4.3.4.1 Processor Status Sensors
The BMC provides an IPMI sensor of type processor for monitoring status information for each
processor slot. If an event state (sensor offset) has been asserted, it remains asserted until one
of the following happens:
1. A Rearm Sensor Events command is executed for the processor status sensor.
2. AC or DC power cycle, system reset, or system boot occurs.
56 Revision 1.1
Intel order number G34153-003
Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPSPlatform Management Overview
Offset
Processor Status
Detected By
0
Internal error (IERR)
Not Supported
1
Thermal trip
BMC
2
FRB1/BIST failure
Not Supported
3
FRB2/Hang in POST failure
BIOS1
4
FRB3/Processor startup/initialization failure (CPU fails to start)
Not Supported
5
Configuration error (for DMI)
BIOS
1
6
SM BIOS uncorrectable CPU-complex error
Not Supported
7
Processor presence detected
BMC
8
Processor disabled
Not Supported
9
Terminator presence detected
Not Supported
The BMC provides system status indication to the front panel LEDs for processor fault
conditions shown in Table 16.
CPU Presence status is not saved across AC power cycles and therefore will not generate a deassertion after cycling AC power.
Table 16. Processor Status Sensor Implementation
Note: Fault is not reflected in the processor status sensor.
4.3.4.1.1 Processor Presence
Upon BMC initialization, which occurs when AC power is applied or the BMC is reset, the
processor presence offset is initialized to the deasserted state and then the BMC checks to see
if the processor is present and sets the presence offset accordingly.
This state is updated at each DC power-on and at system resets. The net effect of this is that
there should be one event logged at BMC startup for processor presence for each installed
processor, assuming the SDR is configured to generate the event. No additional events for
processor presence are expected unless the sensor is manually re-armed using an IPMI
command or a processor is removed or inserted. Note that removal and insertion should only
occur when AC power is removed from the system so it is not expected that a SEL entry will be
seen for this specific occurrence.
4.3.4.2 Processor Population Fault (CPU Missing) Sensor
The BMC supports a Processor Population Fault sensor for monitoring for the condition in which
processor slots are not populated as required by the platform HW to allow power-on of the
system.
At BMC startup, the BMC will check for the fault condition and set the sensor state accordingly.
The BMC also checks for this fault condition at each attempt to DC power-on the system. At
each DC power-on attempt, a beep code is generated if this fault is detected. Please refer Table
9 (BMC Beep Codes) for beep code details.
The following steps are used to correct the fault condition and clear the sensor state:
1. AC power down the server.
2. Install the missing processor into the correct slot.
3. AC power on the server.
Revision 1.1 57
Intel order number G34153-003
Platform Management OverviewIntel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS
Offset
Description
Event Logging
01h
State asserted
Assertion and deassertion
Refer to the applicable platform BMC EPS as to the details of what population rules must be
followed.
4.3.4.3 ERR2 Timeout Monitoring
The BMC supports an ERR2 Timeout Sensor (1 per CPU) that asserts if a CPU’s ERR2 signal
has been asserted for longer than a fixed time period (> 90 seconds). ERR[2] is a processor
signal that indicates when the IIO (Integrated IO module in the processor) has a fatal error
which could not be communicated to the core to trigger SMI. ERR[2] events are fatal error
conditions, where the BIOS and OS will attempt to gracefully handle error, but may not be
always do so reliably. A continuously asserted ERR2 signal is an indication that the BIOS
cannot service the condition that caused the error. This is usually because that condition
prevents the BIOS from running.
When an ERR2 timeout occurs, the BMC asserts/deasserts the ERR2 Timeout Sensor, and
logs a SEL event for that sensor. The default behavior for BMC core firmware is to initiate a
system reset upon detection of an ERR2 timeout. The BIOS setup utility provides an option to
disable or enable system reset by the BMC for detection of this condition.
IPMI Sensor Characteristics
1. Event reading type code: 03h (Generic – digital discrete)
2. Sensor type code: 07h (Processor)
3. Rearm type: Auto
Table 17. Supported ERR2 Timeout Sensor Offsets
4.3.4.4 CATERR Sensor and Market Segment ID (MSID) Mismatch
The BMC supports a CATERR sensor for monitoring the system CATERR signal.
The CATERR signal is defined as having 3 states; high (no event), pulsed low (possibly fatal
may be able to recover), and low (fatal). All processors in a system have their CATERR pins
tied together. The pin is used as a communication path to signal a catastrophic system event to
all CPUs. The BMC has direct access to this aggregate CATERR signal.
The BMC only monitors for the “CATERR held low” condition. A pulsed low condition is ignored
by the BMC.
If a CATERR-low condition is detected, the BMC logs an error message to the SEL against the
CATERR sensor and then queries each CPU to determine if it was due to an MSID mismatch
condition. An MSID mismatch occurs if a processor is installed into a system board that has
incompatible power capabilities. The MSID mismatch condition is indicated in a processor
machine check MSR. If PECI is non-functional (it isn’t guaranteed in this situation), then MSID
mismatch can’t be detected in that case.
If the CATERR is due to an MSID mismatch, then the BMC will log an additional SEL log
against the MSID Mismatch sensor, light the CPU fault LED, emit a beep code, and let the
system hang. Please refer Table 9 (BMC Beep Codes) for beep code details. If no MSID
58 Revision 1.1
Intel order number G34153-003
Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPSPlatform Management Overview
Offset
Description
Event Logging
01h
State asserted
Assertion and deassertion
mismatch is detected, then the default action after logging the SEL entry is to reset the system.
The BIOS setup utility provides an option to disable or enable system reset by the BMC for
detection of this condition.
4.3.4.5 CATERR Sensor
The BMC supports a CATERR sensor for monitoring the system CATERR signal.
The sensor is rearmed on power-on (AC or DC power on transitions). It is not rearmed on
system resets in order to avoid multiple SEL events that could occur due to a potential reset
loop if the CATERR keeps recurring, which would be the case if the CATERR was due to an
MSID mismatch condition.
On EPSD boards, the CATERR signal from each CPU are tied together and routed to the BMC
as one signal. When the BMC detects that this aggregate CATERR signal has asserted, it can
then go through PECI to query each CPU to determine which one was the source of the error
and write an OEM code identifying the CPU slot into an event data byte in the SEL entry. If
PECI is non-functional (it isn’t guaranteed in this situation), then the OEM code should indicate
that the source is unknown.
Event data byte 2 and byte 3 for CATERR sensor SEL events
ED2 - CATERR type.
0: Unknown
1: CATERR
2: CPU Core Error (not supported on EPSD Platforms Based on Intel® Xeon® Processor E5
4600/2600/2400/1600 Product Families)
3: MSID Mismatch
ED3 - CPU bitmap that causes the system CATERR.
[0]: CPU0
[1]: CPU1
[2]: CPU2
[3]: CPU3
IPMI Sensor Characteristics
1. Event reading type code: 03h (Digital discrete)
2. Sensor type code: 07h (Processor)
3. Rearm type: Manual
The following sensor-specific offsets are supported:
Table 18. Supported CATERR Sensor Offsets
4.3.4.6 MSID Mismatch Sensor
The BMC supports a MSID Mismatch sensor for monitoring for the fault condition that will occur
if there is a power rating incompatibility between a baseboard and an a processor
Revision 1.1 59
Intel order number G34153-003
Platform Management OverviewIntel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS
Offset
Description
Event Logging
01h
State asserted
Assertion and deassertion
The sensor is rearmed on power-on (AC or DC power on transitions).
IPMI Sensor Characteristics
1. Event reading type code: 03h (Digital discrete)
2. Sensor type code: 07h (Processor)
3. Rearm type: Manual
The following sensor-specific offsets are supported:
Table 19. Support MSID Mismatch Sensor Offsets
4.4 Thermal and Acoustic Management
The Intel® Server Board S2600IP and Intel® Workstation Board W2600CR offers multiple
thermal and acoustic management features to maintain comprehensive thermal protection as
well as intelligent fan speed control. The features can be adjusted in BIOS interface with path
BIOS > Advanced > System Acoustic and Performance Configuration.
4.4.1 Set Throttling Mode
Select the most appropriate memory thermal throttling mechanism for memory sub-system from
[Auto], [DCLTT], [SCLTT] and [SOLTT].
[Auto] – BIOS automatically detect and identify the appropriate thermal throttling mechanism
based on DIMM type, airflow input, DIMM sensor availability.
[DCLTT] – Dynamic Closed Loop Thermal Throttling: for the SOD DIMM with system airflow
input
[SCLTT] – Static Close Loop Thermal Throttling: for the SOD DIMM without system airflow
input
[SOLTT] – Static Open Loop Thermal Throttling: for the DIMMs without sensor on dimm
(SOD)
The default setting is [Auto].
4.4.2 Altitude
Select the proper altitude that the system is distributed from [300m or less], [301m-900m],
[901m-1500m], [Above 1500m] options. Lower altitude selection can lead to potential thermal
risk. And higher altitude selection provides better cooling but with undesired acoustic and fan
power consumption. If the altitude is known, higher altitude is recommended in order to provide
sufficient cooling. The default setting is [301m – 900m].
4.4.3 Set Fan Profile
[Performance] and [Acoustic] fan profiles are available to select. The Acoustic mode offers best
acoustic experience and appropriate cooling capability covering mainstream and majority of the
add-in cards. Performance mode is designed to provide sufficient cooling capability covering all
kinds of add-in cards on the market. The default setting is [Performance]
60 Revision 1.1
Intel order number G34153-003
Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPSPlatform Management Overview
4.4.4 Fan PWM Offset
This feature is reserved for manual adjustment to the minimum fan speed curves. The valid
range is from [0 to 100] which stands for 0% to 100% PWM adding to the minimum fan speed.
This feature is valid when Quiet Fan Idle Mode is at Enabled state. The default setting is [0].
4.4.5 Quiet Fan Idle Mode
This feature can be [Enabled] or [Disabled]. If enabled, the fan will either stopped or shift to a
lower speed when the aggregate sensor temperatures are satisfied indicating the system is at
ideal thermal/light loading conditions. When the aggregate sensor temperatures not satisfied,
the fan will shift back to normal control curves. If disabled, the fan will never stopped or shift into
lower fan speed whatever the aggregate sensor temperatures are satisfied or not. The default
setting is [Disabled]
Note:
1. The above features may or may not be in effective depends on the actual thermal
characters of a specific system.
2. Refer to System TPS for the board in Intel chassis thermal and acoustic management
3. Refer to Fan Control Whitepaper for the board in third party chassis fan speed control
customization.
4.4.6 Thermal Sensor Input for Fan Speed Control
The BMC uses various IPMI sensors as inputs to FSC. Some of the sensors are actual
physical sensor and some are “virtual” sensors derived from calculation.
The following IPMI thermal sensors are used as input to the fan speed control:
Front Panel Temperature Sensor1
Baseboard Temperature Sensor2
CPU Margin Sensors
DIMM Thermal Margin Sensors
Exit Air Temperature Sensor
PCH Temperature Sensor
On-board Ethernet Controller Temperature Sensors
Add-In Intel SAS/IO Module Temperature Sensors
PSU Thermal Sensor
CPU VR Temperature Sensors
DIMM VR Temperature Sensors
iBMC Temperature Sensor
Global Aggregate Thermal Margin Sensors
Note:
1. For fan speed control in Intel chassis
2. For fan speed control in 3rd party chassis
3. Temperature margin from throttling threshold
4. Absolute temperature
5. PECI value
6. On-die sensor
3,5,6
4, 9
4,6
4, 7
1, 4, 8
3,5
4, 7
4, 7
4, 6
4, 6
3, 8
Revision 1.1 61
Intel order number G34153-003
Platform Management OverviewIntel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS
Offset
Description
Event Logging
00h
Presence detected – Asserted if power supply module is present. Events
are only logged for power supply presence upon changes in the presence
state after AC power is applied (no events logged for initial state).
Assertion and
Deassertion
7. On-board sensor
8. Virtual sensor
9. Available only when PSU has PMBus*
A simplified model is shown as below which gives a high level concept of the fan speed
control structure.
Figure 25. High-level Fan Speed Control Process
4.4.7 Power Supply Status\Health Sensors
The BMC supports one Power Supply Status sensor for each system power supply module. In
order to track problems in which the PSU firmware is not operating to full capacity, an additional
case (degraded condition if the PSU firmware is not operating to full capacity) is added to the
existing Power Supply Status sensor offset definitions. This is handled by assertion of the
“configuration error” offset of the PSU status sensor. These sensors are only supported for
systems that use PMBus*-compliant power supplies.
IPMI Sensor Characteristics
1. Event reading type code: 6Fh (Sensor Specific)
2. Event sensor type code: 08h (Power Supply)
3. Rearm type: Auto
The following sensor-specific offsets are supported.
Table 20. Supported Power Supply Status Sensor Offsets
62 Revision 1.1
Intel order number G34153-003
Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPSPlatform Management Overview
Offset
Description
Event Logging
01h
Power supply failure detected – Asserted if power supply module has failed.
The following codes for failure modes are put into the SEL Event Data 2
byte:
01h - Output voltage fault
02h - Output power fault
03h - Output over-current fault
04h - Over-temperature fault
05h – Fan fault
The SEL Event Data 3 byte will have the contents of the associated
PMBus* Status register to allow for showing multiple conditions for the
event. For example, Data 3 will have the contents of the
VOLTAGE_STATUS register at the time an Output Voltage fault was
detected. Refer to the PMBus Specification for details on specific resister
contents
Assertion and
Deassertion
02h
Predictive failure – Asserted if some condition, such as failing fan, has been
detected that is likely to lead to a power supply module failure.
The following codes for warning modes are put into the SEL Event Data 2
byte:
01h - Output voltage warning
02h - Output power warning
03h - Output over-current warning
04h - Over-temperature warning
05h - Fan warning
06h - Under-voltage warning
07h - Input over-current warning
08h - Input over-power warning
The SEL Event Data 3 byte will have the contents of the associated
PMBus* Status register to allow for showing multiple conditions for the
event. For example, Data 3 will have the contents of the
VOLTAGE_STATUS register at the time an Output Voltage Warning was
detected. Refer to the PMBus Specification for details on specific resister
contents.
Assertion and
Deassertion
03h
Power supply AC lost – Asserted if there is no AC power input to power
supply module.
Assertion and
Deassertion
06h
Configuration error – The following codes for configuration errors are put
into the SEL Event Data 2 byte:
01h - The BMC cannot access the PMBus* device on the PSU but its
FRU device is responding.
02h - The PMBUS_REVISION command returns a version number that
is not supported (only version 1.1 and 1.2 are supported for platforms
covered under this FW EAS).
03h - The PMBus* device does not successfully respond to the
PMBUS_REVISION command.
04h – The PSU is incompatible with one or more PSUs that are
present in the system.
05h –The PSU FW is operating in a degraded mode (likely due to a
failed firmware update).
Assertion and
Deassertion
4.4.8 System Event Sensor
The BMC supports a System Event sensor and logs SEL event for following events.
Revision 1.1 63
Intel order number G34153-003
Platform Management OverviewIntel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS
Offset
Description
Event Logging
02h
OEM code (Undetermined system HW failure)
Assertion and
Deassertion
04h
PEF action
Assertion only
Offset
Description
Event
Logging
Contribution to
system health
00h
Update started
Assertion
OK
01h
Update completed successfully
Assertion
OK
02h
Update failure
Assertion
OK
Table 21. Support System Event Sensor Offsets
For offset 2, OEM code will be logged in event data byte 2 to indicate the type of failure. Only
one value will be supported at this time, but others may be added in the future. The code for this
particular fault will be 0x00 (PECI access failure) and all other values reserved. Upon detection
of the CPU PECI fault condition, the offset shall assert. It shall deassert upon system power
cycle or system reset. Assertion of offset 02h shall contribute a “fatal” condition to the system
status as reflected in the Front Panel system status LED.
4.4.8.1 Update Related SEL Logging
BMC FW will support a single FW Update Status sensor. This sensor is used to generate SEL
events related to update of embedded firmware on the platform. This includes updates to the
BMC, BIOS, and ME FW.
IPMI Sensor Characteristics
1. Event reading type code: 70h (OEM defined)
2. Sensor type code: 2Bh (Version Change)
3. Rearm type: Auto
This sensor is an event-only sensor that is not readable. Event generation is only enabled for
assertion events. Since this is an event-only sensor it should be defined by a type-3 SDR as
defined in the IPMI 2.0 Specification.
Table 22. Supported Firmware Update Status Sensor Offsets
Event Data Bytes
Byte 2: [Bits 7:4] Target of update
0000b = BMC
0001b = BIOS
0010b = ME
0011b = EWS (Embedded Web server)
All other values reserved
[Bits 3:1] Target instance (zero-based)
64 Revision 1.1
Intel order number G34153-003
Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPSPlatform Management Overview
Channel
ID
Interface
Supports
Sessions
0
Primary IPMB
No
1
LAN 1
Yes
2
LAN 2
Yes
3
LAN3
1
(Provided by the Intel® Dedicated Server Management NIC)
Yes
4
Reserved
Yes
5
USB
No
6
Secondary IPMB
No
7
SMM
No
8 – 0Dh
Reserved
–
0Eh
Self 2
–
0Fh
SMS/Receive Message Queue
No
[Bits 0:0] Reserved
Byte 3: Reserved
Note: All reserved bits must be set to zero.
4.5 Platform Management Interface
This chapter describes the supported BMC communication interfaces:
1. Host SMS interface by means of low pin count (LPC)/keyboard controller style (KCS)
interface
2. Host SMM interface by means of low pin count (LPC)/keyboard controller style (KCS)
interface
3. Intelligent Platform Management Bus (IPMB) I2C interface
4. LAN interface using the IPMI-over-LAN protocols
4.5.1 Channel Management
Every messaging interface is assigned an IPMI channel ID by IPMI 2.0. Commands are
provided to configure each channel for privilege levels and access modes. Table 23 shows the
standard channel assignments:
Table 23. Standard Channel Assignments
Notes:
1. Optional hardware supported by the server system.
2. Refers to the actual channel used to send the request.
4.5.2 User Model
The BMC supports the IPMI 2.0 user model. 15 user IDs are supported. These 15 users can be
assigned to any channel. The following restrictions are placed on user-related operations:
Revision 1.1 65
Intel order number G34153-003
Platform Management OverviewIntel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS
ID
Authentication
Algorithm
Integrity Algorithm(s)
Confidentiality
Algorithm(s)
01
RAKP-none
None
None
1
RAKP-HMAC-SHA1
None
None
2
RAKP-HMAC-SHA1
HMAC-SHA1-96
None
3
RAKP-HMAC-SHA1
HMAC-SHA1-96
AES-CBC-128
6
RAKP-HMAC-MD5
None
None
1. User names for User IDs 1 and 2 cannot be changed. These are always “” (Null/blank)
and “root” respectively.
2. User 2 (“root”) always has the administrator privilege level.
3. All user passwords (including passwords for 1 and 2) may be modified.
4. User IDs 3-15 may be used freely, with the condition that user names are unique.
Therefore, no other users can be named “” (Null), “root,” or any other existing user
name.
4.5.3 LAN Interface
The BMC implements both the IPMI 1.5 and IPMI 2.0 messaging models. These provide out-ofband local area network (LAN) communication between the BMC and the network.
Run-time determination of LAN channel capabilities can be determined by both standard IPMI
defined mechanisms.
4.5.3.1 IPMI 1.5 Messaging
The communication protocol packet format consists of IPMI requests and responses
encapsulated in an IPMI session wrapper for authentication, and wrapped in an RMCP packet,
which is wrapped in an IP/UDP packet. Although authentication is provided, no encryption is
provided, so administrating some settings, such as user passwords, through this interface is not
advised. Session establishment commands are IPMI commands that do not require
authentication or an associated session.
The BMC supports the following authentication types over the LAN interface.
1. None (no authentication)
2. Straight password/key
3. MD5
4.5.3.2 IPMI 2.0 Messaging
IPMI 2.0 messaging is built over RMCP+ and has a different session establishment protocol.
The session commands are defined by RMCP+ and implemented at the RMCP+ level, not IPMI
commands. Authentication is implemented at the RMCP+ level. RMCP+ provides link payload
encryption, so it is possible to communicate private/sensitive data (confidentiality).
The BMC supports the cipher suites identified in Table 24.
Table 24. Supported RMCP+ Cipher Suites
66 Revision 1.1
Intel order number G34153-003
Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPSPlatform Management Overview
ID
Authentication
Algorithm
Integrity Algorithm(s)
Confidentiality
Algorithm(s)
7
RAKP-HMAC-MD5
HMAC-MD5-128
None
8
RAKP-HMAC-MD5
HMAC-MD5-128
AES-CBC-128
11
RAKP-HMAC-MD5
MD5-128
None
12
RAKP-HMAC-MD5
MD5-128
AES-CBC-128
Payload Type
Feature
IANA
00h
IPMI message
N/A
01h
Serial-over-LAN
N/A
02h
OEM explicit
Intel (343)
10h – 15h
Session setup
N/A
Note: Cipher suite 0 defaults to callback privilege for security purposes. This may be changed by any
administrator.
For user authentication, the BMC can be configured with ‘null’ user names, whereby
password/key lookup is done based on ‘privilege level only’, or with non-null user names, where
the key lookup for the session is determined by user name.
IPMI 2.0 messaging introduces payload types and payload IDs to allow data types other than
IPMI commands to be transferred. IPMI 2.0 serial-over-LAN is implemented as a payload type.
Table 25. Supported RMCP+ Payload Types
4.5.3.3 RMCP/ASF Messaging
The BMC supports RMCP ping discovery in which the BMC responds with a pong message to
an RMCP/ASF ping request. This is implemented per the Intelligent Platform Management
Interface Specification Second Generation v2.0.
4.5.3.4 BMC LAN Channels
The BMC supports three RMII/RGMII ports that can be used for communicating with Ethernet
devices. Two ports are used for communication with the on-board NICs and one is used for
communication with an Ethernet PHY located on an optional add-in card (or equivalent on-board
circuitry).
4.5.3.4.1 Baseboard NICs
The specific Ethernet controller (NIC) used on a server is platform-specific but all baseboard
device options provide support for an NC-SI manageability interface. This provides a sideband
high-speed connection for manageability traffic to the BMC while still allowing for a
simultaneous host access to the OS if desired.
The Network Controller Sideband Interface (NC-SI) is a DMTF industry standard protocol for the
side band management LAN interface. This protocol provides a fast multi-drop interface for
management traffic.
The baseboard NIC(s) are connected to a single BMC RMII/RGMII port that is configured for
RMII operation. The NC-SI protocol is used for this connection and provides a 100 Mb/s fullduplex multi-drop interface which allows multiple NICs to be connected to the BMC. The
physical layer is based upon RMII, however RMII is a point-to-point bus whereas NC-SI allows 1
Revision 1.1 67
Intel order number G34153-003
Platform Management OverviewIntel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS
master and up to 4 slaves. The logical layer (configuration commands) is incompatible with
RMII.
Multi-port baseboard NICs on some products will provide support for a dedicated management
channel than can be configured to be hidden from the host and only used by the BMC. This
mode of operation is configured by a BIOS setup option.
4.5.3.4.2 Dedicated Management Channel
An additional LAN channel dedicated to BMC usage and not available to host SW is supported
by an optional add-in card. There is only a PHY device present on the add-in card. The BMC
has a built-in MAC module that uses the RGMII interface to link with the card’s PHY. Therefore,
for this dedicated management interface, the PHY and MAC are located in different devices.
The PHY on the card connects to the BMC’s other RMII/RGMII interface (that is, the one that is
not connected to the baseboard NICs). This BMC port is configured for RGMII usage.
In addition to the use of an add-in card for a dedicated management channel, on systems that
support multiple Ethernet ports on the baseboard, the system BIOS provides a setup option to
allow one of these baseboard ports to be dedicated to the BMC for manageability purposes.
When this is enabled, that port is hidden from the OS.
4.5.3.4.3 Concurrent Server Management Use of Multiple Ethernet Controllers
Provided the HW supports a management link between the BMC and a NIC port, the BMC FW
supports concurrent OOB LAN management sessions for the following combination:
Two on-board NIC ports
One on-board NIC and the optional dedicated add-in management NIC.
Two on-board NICs and optional dedicated add-in management NIC.
All NIC ports must be on different subnets for the above concurrent usage models.
MAC addresses are assigned for management NICs from a pool of up to 3 MAC addresses
allocated specifically for manageability. The total number of MAC addresses in the pool is
dependent on the product HW constraints (for example,a board with 2 NIC ports available for
manageability would have a MAC allocation pool of 2 addresses).For these channels, support
can be enabled for IPMI-over-LAN and DHCP.
For security reasons, embedded LAN channels have the following default settings:
IP Address: Static
All users disabled
IPMI-enabled network interfaces may not be placed on the same subnet. This includes the
Intel® Dedicated Server Management NIC and either of the BMC’s embedded network
interfaces.
Host-BMC communication over the same physical LAN connection – also known as “loopback”
– is not supported. This includes “ping” operations.
On baseboards with more than two onboard NIC ports, only the first two ports can be used as
BMC LAN channels. The remaining ports have no BMC connectivity.
68 Revision 1.1
Intel order number G34153-003
Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPSPlatform Management Overview
Maximum bandwidth supported by BMC LAN channels are as follows:
BMC LAN1 (Baseboard NIC port) ----- 100M (10M in DC off state)
BMC LAN 2 (Baseboard NIC port) ----- 100M (10M in DC off state)
BMC LAN 3 (Dedicated NIC) ----- 1000M
4.5.3.5 Dedicated Management NIC MAC Address
For EPSD Platforms Based on Intel® Xeon® Processor E5 4600/2600/2400/1600/1400 Product
Families each server board has either five or seven MAC addresses assigned to it at the Intel
factory. The printed MAC address is assigned to NIC1 on the server board.
If the platform has two NIC built into the main board then there will be five MAC addresses
assigned as follows:
NIC 1 MAC address (for OS usage)
NIC 2 MAC address = NIC 1 MAC address + 1 (for OS usage)
BMC LAN channel 1 MAC address = NIC1 MAC address + 2
BMC LAN channel 2 MAC address = NIC1 MAC address + 3
BMC LAN channel 3 (RMM) MAC address = NIC1 MAC address + 4
If the platform has four NIC built into the main board then there will be seven MAC addresses
assigned as follows:
NIC 1 MAC address (for OS usage)
NIC 2 MAC address = NIC 1 MAC address + 1 (for OS usage)
NIC 3 MAC address = NIC 1 MAC address + 2 (for OS usage)
NIC 4 MAC address = NIC 1 MAC address + 3 (for OS usage)
BMC LAN channel 1 MAC address = NIC1 MAC address + 4
BMC LAN channel 2 MAC address = NIC1 MAC address + 5
BMC LAN channel 3 (RMM) MAC address = NIC1 MAC address + 6.
4.5.3.6 IPV6 Support
In addition to IPv4, Intel® S1400/S1600/S2400/S2600 Server Platforms support IPv6 for
manageability channels. Configuration of IPv6 is provided by extensions to the IPMI Set and
Get LAN Configuration Parameters commands as well as through a Web Console IPv6
configuration web page.
The BMC supports IPv4 and IPv6 simultaneously so they are both configured separately and
completely independently. For example, IPv4 can be DHCP configured while IPv6 is statically
configured or vice versa.
4.5.3.6.1 LAN Failover
The BMC FW provides a LAN failover capability such that the failure of the system HW
associated with one LAN link will result in traffic being rerouted to an alternate link. This
functionality is configurable by IPMI methods as well as by the BMC’s Embedded UI, allowing
for user to specify the physical LAN links constitute the redundant network paths or physical
LAN links constitute different network paths. BMC will support only a all or nothing” approach –
that is, all interfaces bonded together, or none are bonded together.
The LAN Failover feature applies only to BMC LAN traffic. It bonds all available Ethernet
devices but only one is active at a time. When enabled, If the active connection’s leash is lost,
one of the secondary connections is automatically configured so that it has the same IP address
Revision 1.1 69
Intel order number G34153-003
Platform Management OverviewIntel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS
(the next active LAN link will be chosen randomly from the pool of backup LAN links with link
status as “UP”). Traffic immediately resumes on the new active connection.
The LAN Failover enable/disable command may be sent at any time. After it has been enabled,
standard IPMI commands for setting channel configuration that specify a LAN channel other
than the first will return an error code.
Standard IPMI commands for getting channel configuration will return the cached settings for
the inactive channels.
4.5.3.7 BMC IP Address Configuration
Enabling the BMC’s network interfaces requires using the Set LAN Configuration Parameter
command to configure LAN configuration parameter 4, IP Address Source.
4.5.3.8 DHCP BMC Hostname
The BMC allows setting a DHCP Hostname. DHCP Hostname can be set regardless of the IP
Address source configured on the BMC. But this parameter is only used if the IP Address
source is set to DHCP.
4.5.3.9 Address Resolution Protocol (ARP)
The BMC can receive and respond to ARP requests on BMC NICs. Gratuitous ARPs are
supported, and disabled by default.
4.5.3.10 Virtual Local Area Network (VLAN)
The BMC supports VLAN as defined by IPMI 2.0 specifications. VLAN is supported internally by
the BMC, not through switches. VLAN provides a way of grouping a set of systems together so
that they form a logical network. This feature can be used to set up a management VLAN where
only devices which are members of the VLAN will receive packets related to management and
members of the VLAN will be isolated from any other network traffic. Please note that VLAN
does not change the behavior of the host network setting, it only affects the BMC LAN
communication.
LAN configuration options are now supported (by means of the Set LAN Config Parameters
command, parameters 20 and 21) that allow support for 802.1Q VLAN (Layer 2). This allows
VLAN headers/packets to be used for IPMI LAN sessions. VLAN ID’s are entered and enabled
by means of parameter 20 of the Set LAN Config Parameters IPMI command. When a VLAN ID
is configured and enabled, the BMC only accepts packets with that VLAN tag/ID. Conversely, all
BMC generated LAN packets on the channel include the given VLAN tag/ID. Valid VLAN ID’s
are 1 through 4094, VLAN ID’s of 0 and 4095 are reserved, per the 802.1Q VLAN specification.
Only one VLAN can be enabled at any point in time on a LAN channel. If an existing VLAN is
enabled, it must first be disabled prior to configuring a new VLAN on the same LAN channel.
Parameter 21 (VLAN Priority) of the Set LAN Config Parameters IPMI command is now
implemented and a range from 0-7 will be allowed for VLAN Priorities. Please note that bits 3
and 4 of Parameter 21 are considered Reserved bits.
Parameter 25 (VLAN Destination Address) of the Set LAN Config Parameters IPMI command is
not supported and returns a completion code of 0x80 (parameter not supported) for any
read/write of parameter 25.
70 Revision 1.1
Intel order number G34153-003
Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPSPlatform Management Overview
If the BMC IP address source is DHCP, then the following behavior is seen:
If the BMC is first configured for DHCP (prior to enabling VLAN), when VLAN is enabled,
the BMC performs a discovery on the new VLAN in order to obtain a new BMC IP address.
If the BMC is configured for DHCP (before disabling VLAN), when VLAN is disabled, the
BMC performs a discovery on the LAN in order to obtain a new BMC IP address.
If the BMC IP address source is Static, then the following behavior is seen:
If the BMC is first configured for static (prior to enabling VLAN), when VLAN is enabled,
the BMC has the same IP address that was configured before. It is left to the management
application to configure a different IP address if that is not suitable for VLAN.
If the BMC is configure for static (prior to disabling VLAN), when VLAN is disabled, the
BMC has the same IP address that was configured before. It is left to the management
application to configure a different IP address if that is not suitable for LAN.
4.5.3.11 Secure Shell (SSH)
Secure Shell (SSH) connections are supported for one SMASH-CLP session to the BMC.
4.5.3.12 Serial-over-LAN (SOL 2.0)
The BMC supports IPMI 2.0 SOL.
IPMI 2.0 introduced a standard serial-over-LAN feature. This is implemented as a standard
payload type (01h) over RMCP+.
Three commands are implemented for SOL 2.0 configuration.
1. “Get SOL 2.0 Configuration Parameters” and “Set SOL 2.0 Configuration Parameters”:
These commands are used to get and set the values of the SOL configuration parameters.
The parameters are implemented on a per-channel basis.
2. “Activating SOL”: This command is not accepted by the BMC. It is sent by the BMC when
SOL is activated to notify a remote client of the switch to SOL.
3. Activating a SOL session requires an existing IPMI-over-LAN session. If encryption is used,
it should be negotiated when the IPMI-over LAN session is established. Intel® Server Board
S2600IP SOL sessions are supported on serial port A (COM1). Intel® Workstation Board
S2600IP SOL sessions are supported on serial port B (COM2).
4.5.3.13 Platform Event Filter (PEF)
The BMC includes the ability to generate a selectable action, such as a system power-off or
reset, when a match occurs to one of a configurable set of events. This capability is called
Platform Event Filtering, or PEF. One of the available PEF actions is to trigger the BMC to send
a LAN alert to one or more destinations.
The BMC supports 20 PEF filters. The first twelve entries in the PEF filter table are preconfigured (but may be changed by the user). The remaining entries are left blank, and may be
configured by the user.
Table 26. Factory Configured PEF Table Entries
Revision 1.1 71
Intel order number G34153-003
Platform Management OverviewIntel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS
Event
Filter
Number
Offset Mask
Events
1
Non-critical, critical and nonrecoverable
Temperature sensor out of range
2
Non-critical, critical and nonrecoverable
Voltage sensor out of range
3
Non-critical, critical and nonrecoverable
Fan failure
4
General chassis intrusion
Chassis intrusion (security violation)
5
Failure and predictive failure
Power supply failure
6
Uncorrectable ECC
BIOS
7
POST error
BIOS: POST code error
8
FRB2
Watchdog Timer expiration for FRB2
9
Policy Correction Time
Node Manager
10
Power down, power cycle, and reset
Watchdog timer
11
OEM system boot event
System restart (reboot)
12
Drive Failure, Predicted Failure
Hot Swap Controller
Additionally, the BMC supports the following PEF actions:
Power off
Power cycle
Reset
OEM action
Alerts
The “Diagnostic interrupt” action is not supported.
4.5.3.14 LAN Alerting
The BMC supports sending embedded LAN alerts, called SNMP PET (Platform Event traps),
and SMTP email alerts.
The BMC supports a minimum of four LAN alert destinations.
4.5.3.14.1 SNMP Platform Event Traps (PETs)
This feature enables a target system to send SNMP traps to a designated IP address by means
of LAN. These alerts are formatted per the Intelligent Platform Management Interface
Specification Second Generation v2.0. A MIB file associated with the traps is provided with the
BMC firmware to facilitate interpretation of the traps by external software.
The format of the MIB file is covered under RFC 2578.
4.5.3.15 Alert Policy Table
Associated with each PEF entry is an alert policy that determines which IPMI channel the alert
is to be sent. There is a maximum of 20 alert policy entries. There are no pre-configured entries
72 Revision 1.1
Intel order number G34153-003
Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPSPlatform Management Overview
in the alert policy table because the destination types and alerts may vary by user. Each entry in
the alert policy table contains four bytes for a maximum table size of 80 bytes.
4.5.3.15.1 E-mail Alerting
The Embedded Email Alerting feature allows the user to receive e-mails alerts indicating issues
with the server. This allows e-mail alerting in an OS-absent (for example, Pre-OS and OS-Hung)
situation. This feature provides support for sending e-mail by means of SMTP, the Simple Mail
Transport Protocol as defined in Internet RC 821. The e-mail alert provides a text string that
describes a simple description of the event. SMTP alerting is configured using the embedded
web server.
4.5.3.16 SM-CLP (SM-CLP Lite)
SMASH refers to Systems Management Architecture for Server Hardware. SMASH is defined
by a suite of specifications, managed by the DMTF, that standardize the manageability
interfaces for server hardware. CLP refers to Command Line Protocol. SM-CLP is defined by
the Server Management Command Line Protocol Specification (SM-CLP) ver1.0, which is part
of the SMASH suite of specifications. The specifications and further information on SMASH can
be found at the DMTF website (http://www.dmtf.org/).
The BMC provides an embedded “lite” version of SM-CLP that is syntax-compatible but not
considered fully compliant with the DMTF standards.
4.5.3.17 Embedded Web Server
BMC Base manageability provides an embedded web server and an OEM-customizable web
GUI which exposes the manageability features of the BMC base feature set. It is supported
over all on-board NICs that have management connectivity to the BMC as well as an optional
dedicated add-in management NIC. At least two concurrent web sessions from up to two
different users is supported. The embedded web user interface shall support the following
client web browsers:
Microsoft Internet Explorer 7.0*
Microsoft Internet Explorer 8.0*
Microsoft Internet Explorer 9.0*
Mozilla Firefox 3.0*
Mozilla Firefox 3.5*
Mozilla Firefox 3.6*
The embedded web user interface supports strong security (authentication, encryption, and
firewall support) since it enables remote server configuration and control. Embedded web server
uses ports #80 and #443. The user interface presented by the embedded web user interface
shall authenticate the user before allowing a web session to be initiated. Encryption using 128bit SSL is supported. User authentication is based on user id and password.
The GUI presented by the embedded web server authenticates the user before allowing a web
session to be initiated. It presents all functions to all users but grays-out those functions that the
user does not have privilege to execute. (For example, if a user does not have privilege to
power control, then the item shall be displayed in grey-out font in that user’s UI display). The
web GUI also provides a launch point for some of the advanced features, such as KVM and
media redirection. These features are grayed out in the GUI unless the system has been
updated to support these advanced features.
Revision 1.1 73
Intel order number G34153-003
Platform Management OverviewIntel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS
Additional features supported by the web GUI includes:
Presents all the Basic features to the users.
Power on/off/reset the server and view current power state.
Displays BIOS, BMC, ME and SDR version information.
Display overall system health.
Configuration of various IPMI over LAN parameters for both IPV4 and IPV6
Configuration of alerting (SNMP and SMTP).
Display system asset information for the product, board, and chassis.
Display of BMC-owned sensors (name, status, current reading, enabled thresholds),
including color-code status of sensors.
Provides ability to filter sensors based on sensor type (Voltage, Temperature, Fan and
Power supply related)
Automatic refresh of sensor data with a configurable refresh rate.
On-line help.
Display/clear SEL (display is in easily understandable human readable format).
Supports major industry-standard browsers (Microsoft Internet Explorer* and Mozilla
Firefox*).
The GUI session automatically times-out after a user-configurable inactivity period. By
default, this inactivity period is 30 minutes.
Embedded Platform Debug feature - Allow the user to initiate a “diagnostic dump” to a
file that can be sent to Intel for debug purposes.
Virtual Front Panel. The Virtual Front Panel provides the same functionality as the local
front panel. The displayed LEDs match the current state of the local panel LEDs. The
displayed buttons (for example,power button) can be used in the same manner as the
local buttons.
Display of ME sensor data. Only sensors that have associated SDRs loaded will be
displayed.
Ability to save the SEL to a file.
Ability to force HTTPS connectivity for greater security. This is provided through a
configuration option in the UI.
Display of processor and memory information as is available over IPMI over LAN.
Ability to get and set Node Manager (NM) power policies.
Display of power consumed by the server.
Ability to view and configure VLAN settings.
Warn user the reconfiguration of IP address will cause disconnect.
Capability to block logins for a period of time after several consecutive failed login
attempts. The lock-out period and the number of failed logins that initiates the lock-out
period are configurable by the user.
Server Power Control - Ability to force into Setup on a reset.
4.5.3.18 Virtual Front Panel
Virtual Front Panel is the module present as “Virtual Front Panel” on the left side in the
embedded web server when "remote Control" tab is clicked.
Main Purpose of the Virtual Front Panel is to provide the front panel functionality virtually.
Virutal Front Panel (VFP) will mimic the status LED and Power LED status and Chassis ID
alone. It is automatically in sync with BMC every 40 seconds.
For any abnormal status LED state, Virtual Front Panel will get the reason behind the
abnormal or status LED changes and displayed in VFP side.
74 Revision 1.1
Intel order number G34153-003
Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPSPlatform Management Overview
As Virtual Front Panel uses the chassis control command for power actions. It won’t log
the Front button press event since Logging the front panel press event for Virtual Front
Panel press will mislead the administrator.
For Reset from Virtual Front Panel, the reset will be done by a “Chassis control” command.
For Reset from Virtual Front Panel, the restart cause will be because of “Chassis control”
command.
During Power action, Power button/Reset button should not accept the next action until
current Power action is complete and the acknowledgment from BMC is received.
EWS will provide a valid message during Power action until it completes the current Power
action.
The VFP does not have any effect on whether the front panel is locked by “Set Front Panel
Enables” command.
The chassis ID LED provides a visual indication of a system being serviced. The state of
the chassis ID LED is affected by the following actions:
Toggled by turning the chassis ID button on or off.
There is no precedence or lock-out mechanism for the control sources. When a new
request arrives, previous requests are terminated. For example, if the chassis ID button is
pressed, then the chassis ID LED changes to solid on. If the button is pressed again, then
the chassis ID LED turns off.
Note that the chassis ID will turn on because of the original chassis ID button press and
will reflect in the Virtual Front Panel after VFP sync with BMC. Virtual Front Panel won’t
reflect the chassis LED software blinking by the software command as there is no
mechanism to get the chassis ID Led status.
Only Infinite chassis ID ON/OFF by the software command will reflect in EWS during
automatic /manual EWS sync up with BMC.
Virtual Front Panel help should available for virtual panel module.
At present, NMI button in VFP is disabled in Intel® S1400/S1600/S2400/S2600 Server
Platforms. It can be used in future.
4.5.3.19 Embedded Platform Debug
The Embedded Platform Debug feature supports capturing low-level diagnostic data (applicable
MSRs, PCI config-space registers, and so on). This feature allows a user to export this data into
a file that is retrievable from the embedded web GUI, as well as through host and remote IPMI
methods, for the purpose of sending to an Intel engineer for an enhanced debugging capability.
The files are compressed, encrypted, and password protected. The file is not meant to be
viewable by the end user but rather to provide additional debugging capability to an Intel support
engineer.
4.5.3.20 Data Center Management Interface (DCMI)
The DCMI Specification is an emerging standard that is targeted to provide a simplified
management interface for Internet Portal Data Center (IPDC) customers. It is expected to
become a requirement for server platforms which are targeted for IPDCs. DCMI is an IPMIbased standard that builds upon a set of required IPMI standard commands by adding a set of
DCMI-specific IPMI OEM commands. Intel® S1400/S1600/S2400/S2600 Server Platforms will
be implementing the mandatory DCMI features in the BMC firmware (DCMI 1.1 Errata 1
compliance). Please refer to DCMI 1.1 errata 1 spec for details. Only mandatory commands will
be supported. No support for optional DCMI commands. Optional power management and SEL
roll over feature is not supported. DCMI Asset tag will be independent of baseboard FRU asset
Revision 1.1 75
Intel order number G34153-003
Platform Management OverviewIntel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS
Tag. Please refer table DCMI Group Extension Commands for more details on DCMI
commands.
4.5.3.21 Lightweight Directory Authentication Protocol (LDAP)
The Lightweight Directory Access Protocol (LDAP) is an application protocol supported by the
BMC for the purpose of authentication and authorization. The BMC user connects with an LDAP
server for login authentication. This is only supported for non-IPMI logins including the
embedded web UI and SM-CLP. IPMI users/passwords and sessions are not supported over
LDAP.
LDAP can be configured (IP address of LDAP server, port, and so on) from the BMC’s
Embedded Web UI. LDAP authentication and authorization is supported over the any NIC
configured for system management. The BMC uses a standard Open LDAP implementation for
Linux.
Only open LDAP is supported by BMC. Windows and Novel LDAP are not supported.
4.6 BMC Firmware Update
4.6.1 The BMC firmware release Number
The BMC firmware releases are numbered as follows:
AB.CD.XXX
Where:
CD is a two digit number starting with 00 for the first release. This is the number returned in
minor ID in Get Device ID response.
B is major release number (1 for the first major release typically at first production shipment).
A is point release indicator (A=0 means this is a regular official release, A=1 means this is a
point release for limited distribution). A hex representation of “AB” is returned in major ID in Get
Device ID response.
XXX is the build number for internal tracking. This number is returned in OEM bytes of Get
Device ID response.
4.6.2 Boot Recovery Mode
The BMC’s boot block supports firmware transfer updates. The Operational Firmware Transfer
mode preserves several files in the PIA Linux file system. Boot Recovery mode cannot preserve
the files because it does not understand Linux file systems, and treats it as a large binary data
section. This means a Boot Recovery update completely replaces the PIA with the factory
default version: an empty SEL, a default SDR, and default IPMI configuration and user settings.
Boot Recovery mode can successfully complete an update in some situations where the
Operational Firmware Transfer mode will fail. If there is an incompatibility or bug in the
operational code causing it to crash or hang, only a Boot Recovery Mode Update works.
Another example is if the flash layout of the sections changes across an update. Because the
operational Firmware Transfer mode tries to preserve the contents of the PIA section, in this
76 Revision 1.1
Intel order number G34153-003
Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPSPlatform Management Overview
case, it will corrupt the flash where the old PIA section was. Because the Boot Recovery mode
is blindly writing binary data to flash, in this case, it will succeed.
There are two ways to enter Boot Recovery mode:
The Force Firmware Update jumper is asserted when A/C power is applied.
The operational code is corrupt and the boot loader cannot boot.
In the Boot Recovery mode, the BMC only responds to the small set of commands listed above.
Only the KCS SMS interface is supported; USB-based Fast Firmware Update is not supported.
4.6.3 Force Firmware Update Jumper
The Force Firmware Update jumper can be used to put the BMC in Boot Recovery mode for a
low-level update. It causes the BMC to abort its normal boot process and stay in the boot loader
without executing any Linux code.
The jumper is normally in the de-asserted position. The system must be completely powered off
(A/C power removed) before the jumper is moved. After power is re-applied and the firmware
update is complete, the system must be powered off again and the jumper must be returned to
the de-asserted position before normal operation can begin.
There is no boot–block-write protection jumper.
4.6.4 Fast Firmware Update over USB
The BMC supports a Fast Firmware Update mode in addition to the standard KCS SMS
interface. This is a special protocol that goes over the USB connection between the host and
the BMC.
Revision 1.1 77
Intel order number G34153-003
Platform Management OverviewIntel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS
Manageability Hardware
Benefits
Intel® Integrated BMC
Comprehensive IPMI based base manageability
features
Intel® Remote Management Module 4 – Lite
Package contains one module –
1- Key for advance Manageability features.
No dedicated NIC for management
Enables KVM and media redirection from the onboard
NIC
Intel® Remote Management Module 4
Package includes 2 modules –
1 - key for advance features
2 - Dedicated NIC (1Gbe) for management
Dedicated NIC for management traffic. Higher
bandwidth connectivity for KVM and media
Redirection with 1Gbe NIC.
4.7 Advanced Management Feature Support
This section explains the advanced management features supported by the BMC firmware.
4.7.1 Enabling Advanced Management Features
The Advanced management features are to be delivered as part of the BMC FW image. The
BMC’s baseboard SPI flash contains code/data for both the Basic and Advanced features. An
optional add-in card Intel® RMM4 lite is used as the activation mechanism. When the BMC FW
initializes, it attempts to access the Intel® RMM4 lite. If the attempt to access Intel® RMM4 lite is
successful, then the BMC activates the Advanced features.
Advanced manageability features are supported over all NIC ports enabled for server
manageability. This includes baseboard NICs as well as the LAN channel provided by the
optional Dedicated NIC add-in card.
RMM4 is comprised of two boards – RMM4 lite and the optional Dedicated Server Management
NIC (DMN). If the optional Dedicated Server Management NIC is not used then the traffic can
only go through the onboard Integrated BMC-shared NIC and share network bandwidth with the
host system.
Table 27. Enabling Advanced Management Features
4.7.2 Keyboard, Video, Mouse (KVM) Redirection
The BMC firmware supports keyboard, video, and mouse redirection (KVM) over LAN. This
feature is available remotely from the embedded web server as a Java applet. This feature is
only enabled when the Intel® RMM4 lite is present. The client system must have a Java Runtime
Environment (JRE) version 6.0 or later to run the KVM or media redirection applets.
The BMC supports an embedded KVM application (Remote Console) that can be launched from
the embedded web server from a remote console. USB1.1 or USB 2.0 based mouse and
keyboard redirection are supported. It is also possible to use the KVM-redirection (KVM-r)
session concurrently with media-redirection (media-r). This feature allows a user to interactively
use the keyboard, video, and mouse (KVM) functions of the remote server as if the user were
physically at the managed server.
78 Revision 1.1
Intel order number G34153-003
Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPSPlatform Management Overview
KVM redirection console support the following keyboard layouts: English, Dutch, French,
German, Italian, Russian, and Spanish.
KVM redirection includes a “soft keyboard” function. The “soft keyboard” is used to simulate an
entire keyboard that is connected to the remote system. The “soft keyboard” functionality
supports the following layouts: English, Dutch, French, German, Italian, Russian, and Spanish.
The KVM-redirection feature automatically senses video resolution for best possible screen
capture and provides high-performance mouse tracking and synchronization. It allows remote
viewing and configuration in pre-boot POST and BIOS setup, once BIOS has initialized video.
Other attributes of this feature include:
Encryption of the redirected screen, keyboard, and mouse
Compression of the redirected screen.
Ability to select a mouse configuration based on the OS type.
supports user definable keyboard macros.
KVM redirection feature supports the following resolutions and refresh rates:
640x480 at 60Hz, 72Hz, 75Hz, 85Hz, 100Hz
800x600 at 60Hz, 72Hz, 75Hz, 85Hz
1024x768 at 60Hx, 72Hz, 75Hz, 85Hz
1280x960 at 60Hz
1280x1024 at 60Hz
1600x1200 at 60Hz
1920x1080 (1080p),
1920x1200 (WUXGA)
1650x1080 (WSXGA+)
4.7.2.1 Force-enter BIOS Setup
KVM redirection can present an option to force-enter BIOS Setup. This enables the system to
enter F2 setup while booting which is often missed by the time the remote console redirects the
video.
4.7.3 Media Redirection
The embedded web server provides a Java applet to enable remote media redirection. This may
be used in conjunction with the remote KVM feature, or as a standalone applet.
The media redirection feature is intended to allow system administrators or users to mount a
remote IDE or USB CD-ROM, floppy drive, or a USB flash disk as a remote device to the server.
Once mounted, the remote device appears just like a local device to the server, allowing system
administrators or users to install software (including operating systems), copy files, update
BIOS, and so on, or boot the server from this device.
The following capabilities are supported:
The operation of remotely mounted devices is independent of the local devices on the
server. Both remote and local devices are useable in parallel.
Either IDE (CD-ROM, floppy) or USB devices can be mounted as a remote device to the
server.
It is possible to boot all supported operating systems from the remotely mounted device
and to boot from disk IMAGE (*.IMG) and CD-ROM or DVD-ROM ISO files. See the
Tested/supported Operating System List for more information.
Revision 1.1 79
Intel order number G34153-003
Platform Management OverviewIntel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS
Media redirection supports redirection for both a virtual CD device and a virtual
Floppy/USB device concurrently. The CD device may be either a local CD drive or else an
ISO image file; the Floppy/USB device may be either a local Floppy drive, a local USB
device, or else a disk image file.
The media redirection feature supports multiple encryption algorithms, including RC4 and
AES. The actual algorithm that is used is negotiated with the client based on the client’s
capabilities.
A remote media session is maintained even when the server is powered-off (in standby
mode). No restart of the remote media session is required during a server reset or power
on/off. An BMC reset (for example,due to an BMC reset after BMC FW update) will require
the session to be re-established
The mounted device is visible to (and useable by) managed system’s OS and BIOS in both
pre-boot and post-boot states.
The mounted device shows up in the BIOS boot order and it is possible to change the
BIOS boot order to boot from this remote device.
It is possible to install an operating system on a bare metal server (no OS present) using
the remotely mounted device. This may also require the use of KVM-r to configure the OS
during install.
USB storage devices will appear as floppy disks over media redirection. This allows for the
installation of device drivers during OS installation.
If either a virtual IDE or virtual floppy device is remotely attached during system boot, both the
virtual IDE and virtual floppy are presented as bootable devices. It is not possible to present
only a single-mounted device type to the system BIOS.
80 Revision 1.1
Intel order number G34153-003
Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPSPlatform Management Overview
4.8 Intel® Intelligent Power Node Manager (NM)
4.8.1 Overview
Power management deals with requirements to manage processor power consumption and
manage power at the platform level to meet critical business needs. Node Manager (NM) is a
platform resident technology that enforces power capping and thermal-triggered power capping
policies for the platform. These policies are applied by exploiting subsystem knobs (such as
processor P and T states) that can be used to control power consumption. NM enables data
center power management by exposing an external interface to management software through
which platform policies can be specified. It also implements specific data center power
management usage models such as power limiting, and thermal monitoring.
The NM feature is implemented by a complementary architecture utilizing the ME, BMC, BIOS,
and an ACPI-compliant OS. The ME provides the NM policy engine and power control/limiting
functions (referred to as Node Manager or NM) while the BMC provides the external LAN link by
which external management software can interact with the feature. The BIOS provides system
power information utilized by the NM algorithms and also exports ACPI Source Language (ASL)
code used by OS-Directed Power Management (OSPM) for negotiating processor P and T state
changes for power limiting. PMBus*-compliant power supplies provide the capability to
monitoring input power consumption, which is necessary to support NM.
4.8.1.1 Hardware Requirements
NM is supported only on platforms that have the NM FW functionality loaded and enabled on
the Management Engine (ME) in the SSB and that have a BMC present to support the external
LAN interface to the ME. NM power limiting features requires a means for the ME to monitor
input power consumption for the platform. This capability is generally provided by means of
PMBus*-compliant power supplies although an alternative model using a simpler SMBus* power
monitoring device is possible (there is potential loss in accuracy and responsiveness using nonPMBus* devices). The NM SmaRT/CLST feature does specifically require PMBus*-compliant
power supplies as well as additional hardware on the baseboard.
4.8.1.2 Features
NM provides feature support for policy management, monitoring and querying, alerts and
notifications, and an external interface protocol. The policy management features implement
specific IT goals that can be specified as policy directives for NM. Monitoring and querying
features enable tracking of power consumption. Alerts and notifications provide the foundation
for automation of power management in the data center management stack. The external
interface specifies the protocols that must be supported in this version of NM.
4.8.1.3 ME Firmware Update
On server platforms, the ME FW uses a single operational image with a limited-functionality
recovery image. In order to upgrade an operational image, a boot to recovery image must be
performed. Unlike last generation platforms, the ME FW does not support an IPMI update
mechanism except for the case that the system is configured with a dual-ME (redundant) image.
In order to conserve flash space, which the ME FW shares with BIOS, EPSD systems only
support a single ME image. For this case, ME update is only supported by means of BIOS
performing a direct update of the flash component. The recovery image only provides the basic
functionality that is required to perform the update; therefore other ME FW features are not
functional therefore when the update is in progress.
Revision 1.1 81
Intel order number G34153-003
Platform Management OverviewIntel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS
4.8.1.4 SmaRT/CLST
The power supply optimization provided by SmaRT/CLST relies on a platform HW capability as
well as ME FW support. When a PMBus*-compliant power supply detects insufficient input
voltage, an overcurrent condition, or an over-temperature condition, it will assert the SMBAlert#
signal on the power supply SMBus* (that is, the PMBus*). Through the use of external gates,
this results in a momentary assertion of the PROCHOT# and MEMHOT# signals to the
processors, thereby throttling the processors and memory. The ME FW also sees the
SMBAlert# assertion, queries the power supplies to determine the condition causing the
assertion, and applies an algorithm to either release or prolong the throttling, based on the
situation.
System power control modes include:
1. SmaRT: Low AC input voltage event; results in a onetime momentary throttle for each
event to the maximum throttle state
2. Electrical Protection CLST: High output energy event; results in a throttling hiccup mode
with fixed maximum throttle time and a fix throttle release ramp time.
3. Thermal Protection CLST: High power supply thermal event; results in a throttling hiccup
mode with fixed maximum throttle time and a fix throttle release ramp time.
When the SMBAlert# signal is asserted, the fans will be gated by HW for a short period
(~100ms) to reduce overall power consumption. It is expected that the interruption to the fans
will be of short enough duration to avoid false lower threshold crossings for the fan tach
sensors; however, this may need to be comprehended by the fan monitoring FW if it does have
this side-effect.
ME FW will log an event into the SEL to indicate when the system has been throttled by the
SmaRT/CLST power management feature. This is dependent on ME FW support for this
sensor. Please refer ME FW EPS for SEL log details.
4.8.1.4.1 Dependencies on PMBus*-compliant Power Supply Support
The SmaRT/CLST system feature depends on functionality present in the ME NM SKU. This
feature requires power supplies that are compliant with the PMBus Specification, Revision 1.2.
4.9 EU Lot 6 Mode
The European Union has set forth a stringent standby power consumption target for systems
that are used as primary computing devices in office environments. Owing to the fact in office
environments, pedestal servers are being used more and more as workstations and that Value
servers could make their way into Home servers, this solution is being requested for some
pedestal servers. HW support for EU Lot6 will only be available for specific EPSD pedestal
products.
In order to meet the standby power requirements for EU Lot6 it is necessary to remove power to
the BMC, along with other components, when in the S5 state. As this operational mode impacts
system feature support, the user has the option of enabling and disabling this mode from the
BIOS setup screen utility.
BIOS is responsible for enabling/disabling the system hardware for EU Lot6 operation. It notifies
the BMC of the current state with the OEM command Set EULot6 Mode. The BMC saves the
state in persistent store and uses it to control special EU Lot6 internal processing during boot,
sensor monitoring, and so on as needed.
82 Revision 1.1
Intel order number G34153-003
Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPSPlatform Management Overview
Wake-on-LAN (WOL) is not supported in EU Lot6 mode.
4.9.1.1 Impact to System Features
The following system features are lost or impacted when EU Lot6 mode is enabled:
Increased boot time (~15-20s) when system is DC power cycled.
o This is due to the fact that both the BMC and BIOS are booting at the same time
when the system is powered on (to S0 state). BIOS will need to allow extra time
for the BMC to initialize to the point where it can communicate with BIOS.
Note: Even when EU Lot6 is not enabled and the system is AC cycled, this
increased boot time is applicable if a user immediately attempts to power the system
up (for example, pressing the power button), as in this case both the BMC and BIOS
are booting at the same time.
No LAN manageability when on standby, and therefore no remote OOB power on by
BMC.
No support for SOL or KVM for monitoring the entire boot process.
o Since BMC is initializing at the same time as BIOS, it will not be possible to have
an SOL or KVM session established from the beginning of the system boot.
FP status LED will behave differently (it will be off when on standby) rather than showing
fault conditions present at the time the system was powered down.
No beep code due to uninstalled CPU.
No monitoring of any sensors when on standby.
No detection/logging of any ThermTrip faults.
o These result as the system is shut down by HW so BMC will not be available to
detect that they occurred.
Sensor monitoring after DC power-on will be delayed by the time it takes BMC to
initialize its sensor subsystem (~15 to 20s), possibly losing SEL events or failing to
provide correct FP LED status LED indication.
Note: This delay occurs on each AC cycle even when EU Lot6 mode is disabled.
Chassis intrusion not detected when in standby
Revision 1.1 83
Intel order number G34153-003
System Security Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS
5. System Security
5.1 BIOS Password Protection
The BIOS uses passwords to prevent unauthorized tampering with the server setup. Passwords
can restrict entry to the BIOS Setup, restrict use of the Boot Popup menu, and suppress
automatic USB device reordering.
There is also an option to require a Power On password entry in order to boot the system. If the
Power On Password function is enabled in Setup, the BIOS will halt early in POST to request a
password before continuing POST.
Both Administrator and User passwords are supported by the BIOS. An Administrator password
must be installed in order to set the User password. The maximum length of a password is
14 characters. A password can have alphanumeric (a-z, A-Z, 0-9) characters and it is case
sensitive. Certain special characters are also allowed, from the following set:
! @ # $ % ^ & * ( ) - _ + = ?
The Administrator and User passwords must be different from each other. An error message will
be displayed if there is an attempt to enter the same password for one as for the other.
The use of “Strong Passwords” is encouraged, but not required. In order to meet the criteria for
a “Strong Password”, the password entered must be at least 8 characters in length, and must
include at least one each of alphabetic, numeric, and special characters. If a “weak” password is
entered, a popup warning message will be displayed, although the weak password will be
accepted.
Once set, a password can be cleared by changing it to a null string. This requires the
Administrator password, and must be done through BIOS Setup or other explicit means of
changing the passwords. Clearing the Administrator password will also clear the User
password.
Alternatively, the passwords can be cleared by using the Password Clear jumper if necessary.
Resetting the BIOS configuration settings to default values (by any method) has no effect on the
Administrator and User passwords.
Entering the User password allows the user to modify only the System Time and System Date in
the Setup Main screen. Other setup fields can be modified only if the Administrator password
has been entered. If any password is set, a password is required to enter the BIOS setup.
The Administrator has control over all fields in the BIOS setup, including the ability to clear the
User password and the Administrator password.
It is strongly recommended that at least an Administrator Password be set, since not having set
a password gives everyone who boots the system the equivalent of Administrative access.
Unless an Administrator password is installed, any User can go into Setup and change BIOS
settings at will.
In addition to restricting access to most Setup fields to viewing only when a User password is
entered, defining a User password imposes restrictions on booting the system. In order to
simply boot in the defined boot order, no password is required. However, the F6 Boot popup
prompts for a password, and can only be used with the Administrator password. Also, when a
84 Revision 1.1
Intel order number G34153-003
Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS System Security
User password is defined, it suppresses the USB Reordering that occurs, if enabled, when a
new USB boot device is attached to the system. A User is restricted from booting in anything
other than the Boot Order defined in the Setup by an Administrator.
As a security measure, if a User or Administrator enters an incorrect password three times in a
row during the boot sequence, the system is placed into a halt state. A system reset is required
to exit out of the halt state. This feature makes it more difficult to guess or break a password.
In addition, on the next successful reboot, the Error Manager displays a Major Error code 0048,
which also logs a SEL event to alert the authorized user or administrator that a password
access failure has occurred.
5.2 Trusted Platform Module (TPM) Support
The Trusted Platform Module (TPM) option is a hardware-based security device that addresses
the growing concern on boot process integrity and offers better data protection. TPM protects
the system start-up process by ensuring it is tamper-free before releasing system control to the
operating system. A TPM device provides secured storage to store data, such as security keys
and passwords. In addition, a TPM device has encryption and hash functions. The server board
implements TPM as per TPM PC Client Specifications revision 1.2 by the Trusted Computing
Group (TCG).
A TPM device is optionally installed onto a high density 14-pin connector labeled “TPM” on the
server board, and is secured from external software attacks and physical theft. A pre-boot
environment, such as the BIOS and operating system loader, uses the TPM to collect and store
unique measurements from multiple factors within the boot process to create a system
fingerprint. This unique fingerprint remains the same unless the pre-boot environment is
tampered with. Therefore, it is used to compare to future measurements to verify the integrity of
the boot process.
After the system BIOS completes the measurement of its boot process, it hands off control to
the operating system loader and in turn to the operating system. If the operating system is
TPMenabled, it compares the BIOS TPM measurements to those of previous boots to make
sure the
system was not tampered with before continuing the operating system boot process. Once the
operating system is in operation, it optionally uses TPM to provide additional system and data
security (for example, Microsoft Vista* supports Bitlocker drive encryption).
5.2.1 TPM security BIOS
The BIOS TPM support conforms to the TPM PC Client Implementation Specification for
Conventional BIOS and to the TPM Interface Specification, and the Microsoft Windows
BitLocker* Requirements. The role of the BIOS for TPM security includes the following:
Measures and stores the boot process in the TPM microcontroller to allow a TPM
enabled operating system to verify system boot integrity.
Produces EFI and legacy interfaces to a TPM-enabled operating system for using TPM.
Produces ACPI TPM device and methods to allow a TPM-enabled operating system to
send TPM administrative command requests to the BIOS.
Revision 1.1 85
Intel order number G34153-003
System Security Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS
Verifies operator physical presence. Confirms and executes operating system TPM
administrative command requests.
Provides BIOS Setup options to change TPM security states and to clear TPM
ownership.
For additional details, refer to the TCG PC Client Specific Implementation Specification, the
TCG PC Client Specific Physical Presence Interface Specification, and the Microsoft BitLocker*
Requirement documents.
5.2.2 Physical Presence
Administrative operations to the TPM require TPM ownership or physical presence indication by
the operator to confirm the execution of administrative operations. The BIOS implements the
operator presence indication by verifying the setup Administrator password.
A TPM administrative sequence invoked from the operating system proceeds as follows:
1. User makes a TPM administrative request through the operating system’s security software.
2. The operating system requests the BIOS to execute the TPM administrative command
through TPM ACPI methods and then resets the system.
3. The BIOS verifies the physical presence and confirms the command with the operator.
4. The BIOS executes TPM administrative command(s), inhibits BIOS Setup entry and boots
directly to the operating system which requested the TPM command(s).
5.2.3 TPM Security Setup Options
The BIOS TPM Setup allows the operator to view the current TPM state and to carry out
rudimentary TPM administrative operations. Performing TPM administrative options through the
BIOS setup requires TPM physical presence verification.
Using BIOS TPM Setup, the operator can turn ON or OFF TPM functionality and clear the TPM
ownership contents. After the requested TPM BIOS Setup operation is carried out, the option
reverts to No Operation.
The BIOS TPM Setup also displays the current state of the TPM, whether TPM is enabled or
disabled and activated or deactivated. Note that while using TPM, a TPM-enabled operating
system or application may change the TPM state independent of the BIOS setup. When an
operating system modifies the TPM state, the BIOS Setup displays the updated TPM state.
The BIOS Setup TPM Clear option allows the operator to clear the TPM ownership key and
allows the operator to take control of the system with TPM. You use this option to clear security
settings for a newly initialized system or to clear a system for which the TPM ownership security
key was lost.
5.2.3.1 Security Screen
To enter the BIOS Setup, press the F2 function key during boot time when the OEM or Intel logo
displays. The following message displays on the diagnostics screen and under the Quiet Boot
86 Revision 1.1
Intel order number G34153-003
Loading...
