Intel
Server Systems
SR4850HW4S and SR6850HW4S
Configuration Guide
Rev 3.03
A reference guide to assist customers in ordering components to configure
SAS 3.5” Harwich 800T-based server systems - RoHS compliance w/ server exemption.
SR4850HW4S = Harwich 800T 4U Server SAS 3.5
SR6850HW4S = Harwich 800T 6U Server SAS 3.5
Revisions/Additions in blue font
6/13/2007 SR4850HW4S / SR6850HW4S Configuration Guide Page 1 of 12
1. Table of Contents
1. Table of Contents..................................................................................................................2
2. Revision History....................................................................................................................3
3. Important Notes ....................................................................................................................3
4. System Configuration Options............................................................................................4
5. 4U System Part Configurator: SR4850HW4S.....................................................................5
6. 6U System Part Configurator: SR6850HW4S.....................................................................6
7. Base System SKU Configuration Contents........................................................................7
7.1 Table 1: Base System Product Code Contents........................................................7
8. Complete Product Ordering Code Listings........................................................................8
8.1 Table 2: Base System Codes...................................................................................8
8.2 Table 3: Common System Accessory Codes...........................................................9
8.2.1 Table 4: 4U Unique Accessory Codes for SHW4URM3SA...................................10
8.2.2 Table 5: 6U Unique Accessory Codes for SHW6URM3SA...................................10
8.3 Table 6: Common System Spare Part Codes........................................................10
8.3.1 Table 7: 4U 3.5“ SAS Unique Spare Part Codes for SHW4URM3SA....................11
8.3.2 Table 8: 6U 3.5” SAS Unique Spare Part Codes for SHW6URM3SA....................11
8.4 Table 9: Boxed Processor Codes Reference (Heatsink Included).........................11
8.5 Table 9: Trayed Processor Codes Reference (Requires Heatsink- AHWPROCHS)12
6/13/2007 SR4850HW4S / SR6850HW4S Configuration Guide Page 2 of 12
2. Revision History
Date Rev Modification
Mar 23, 2005
Sept 27, 2005
Apr 24, 2006
Apr 25, 2006
Sept 25, 2006
Oct 25, 2006
Apr 3,2007
1.1 Corrected system DVD from a DVD/CDRW to a DVD-ROM.
2.0 Harwich 800T revisions.
2.7 Harwich 800T MM#s revised, DVD spare
3.0 Harwich 800T SAS MM#s added
3.01 Updated Boxed and Tray Processor Reference Codes
3.02 Updated BHWBASEM MM#
3.02 Updated SHW4URM3SA and SHW6URM3SA MM#
3. Important Notes
1. The SRx850HW4S boardset is ordered and shipped as two separate boards. The two boards are the baseboard and the
memory board. Each system can accommodate up to four memory boards. System SKUs include one memory board in
the base configuration.
2. The 6U server platform SR6850HW4S (product code SHW6URM3SA) comes preconfigured with 1 power supply and an
empty second power supply bay. The second power supply bay must be filled with either a second power supply
(AHW6UPWR) or a power bay fan (AHW6UPWRFAN).
3. Systems will not ship with processors, hard drives, or memory. These parts must be obtained separately from the system.
4. VRMs are not included with the platform.
5. Heat sinks are not included with the platform.
6. Processor thermal blanks must be ordered separately (if no processor is installed).
7. Either a Button Control Panel or Intel
8. Intel® Server Management Professional or Advanced modules must be ordered for installation in the system.
9. The SRx850HW4S memory board supports DDR2 400 SDRAM registered DIMMs.
10. The Intel factory will package board orders into single order packaging and ship to fill customer orders. Each board MM is a
self-contained shipping package of one board.
11. Power cords are not shipped with the system and must be obtained from local suppliers. Please review the power cord
enabling documents on support.intel.com, they cover all the countries that we intend to sell the product and have how to
order the correct cable:
http://support.intel.com/support/motherboards/server/sr6850hw4/sb/cs-020878.htm
http://support.intel.com/support/motherboards/server/sr4850hw4/sb/cs-020879.htm
12. All parts listed below are RoHS compliant with server exemption.
®
Local Control Panel must be ordered for installation in the system.
6/13/2007 SR4850HW4S / SR6850HW4S Configuration Guide Page 3 of 12
4. System Configuration Options
Button Control
Panel
OR
LCD Control
Panel
SR4850HW4S
4U Platform
Mandatory Accessories
OR
IMM
Professional
Optional Accessories
IMM
Advanced
SR6850HW4S
6U Platform
nd
2
Power
Supply
6U Only
OR
Active Fan
Blank
ROMB Key and
Battery
Fibre Channel
Module
Rack Rails and
CMA
Up to 3 additional
memory boards.
Pedestal Kit (6U)
Bezels
6/13/2007 SR4850HW4S / SR6850HW4S Configuration Guide Page 4 of 12
5. 4U System Part Configurator: SR4850HW4S
Mandatory Accessories
Feature Product
IMM Professional
Intel Management Module
(Choose one per System)
Control Panel
(Choose one per System)
Processor
Heat Sinks and Blanks
(All 4 sockets must have Processor + Heatsink
OR
Processor Blank)
Processor VRM
(Use with 3 and 4 processors)
AHWIMMPRO2
IMM Advanced
AHWIMMADV2
Button control panel
AXXBCPMOD2
LCD control panel
AXXLCPMOD2
Processor heat sink
AHWPROCHS
NOTE: Boxed processors include this heat sink.
Processor blank
AHWPROCBLANK
Processor core 10.2 VRM
AHWVRMPM
(one required for each processor used in socket 3 and 4)
Processor cache 9DO VRM
AHWVRMCM
(one per system required for iL3 processor used in socket 3
and 4)
Optional Accessories
Feature Product
Intel® SAS RAID Activation Key
AXXRAK18E
RAID Solutions
Fibre Channel Module
Rack Mount Solutions
Memory board
Front Bezel
Intel® RAID Smart Battery
AXXRSBBU3
(only used with Activation Key above)
Fibre channel module
AHWFCMOD
Rack rails
AXXRAIL3U7U
Cable Management Arm
AXXCMA3U7U
4 DIMM memory board
BHW4DIMMM
4U Front bezel for rack mount
AHW4URBEZEL
6/13/2007 SR4850HW4S / SR6850HW4S Configuration Guide Page 5 of 12
6. 6U System Part Configurator: SR6850HW4S
Mandatory Accessories
Feature Product
IMM Professional
Intel Management Module
(Choose one per System)
Control Panel
(Choose one per System)
Processor
Heat Sinks and Blanks
(All 4 sockets must have Processor + Heatsink
OR
Processor Blank)
Processor VRM
(Use with 3 and 4 processors)
6U Power Supply #2
Second power supply or a power fan.
(Choose one per System)
AHWIMMPRO2
IMM Advanced
AHWIMMADV2
Button control panel
AXXBCPMOD2
LCD control panel
AXXLCPMOD2
Processor heat sink
AHWPROCHS
NOTE: Boxed processors include this heat sink.
Processor blank
AHWPROCBLANK
Processor core 10.2 VRM
AHWVRMPM
(one required for each processor used in socket 3 and 4)
Processor cache 9DO VRM
AHWVRMCM
(one per system required for iL3 processor used in socket 3
and 4)
Power supply module. 6U. 15Amp, 110v/220v.
AHW6UPWR
Power bay fan. 6U.
AHW6UPWRFAN
Feature Product
RAID Solutions
Fibre Channel Module
Rack Mount Solutions
Memory board
Front Bezel
Optional Accessories
Intel® SAS RAID Activation Key
AXXRAK18E
Intel® RAID Smart Battery
AXXRSBBU3
(only used with Activation Key above)
Fibre channel module
AHWFCMOD
Rack rails
AXXRAIL3U7U
Cable Management Arm
AXXCMA3U7U
4 DIMM memory board
BHW4DIMMM
Front bezel for rack mount
AHW6URBEZEL
Front bezel for pedestal mount
AHW6UPBEZEL
6/13/2007 SR4850HW4S / SR6850HW4S Configuration Guide Page 6 of 12
7. Base System SKU Configuration Contents
7.1 Table 1: Base System Product Code Contents
Product Code Description
Intel® Server System SR4850HW4S (Harwich 800T SAS) 4U Rack.
• 1x Baseboard
• 1x Front Panel IO board
• 1x Memory Board (1X4) plus bracket
• 3x Memory Board Filler Baffles
• 0x Intel Management Module (Professional IMM)
• 2x Power Supply Module (15Amp, 208)
• 1x 1/2" DVD-ROM Drive
• 0x Button Control Panel
• 1x SAS 4U Backplane Board
• 1x Rack Faceplate (Granby)
SHW4URM3S
A
SHW6URM3S
A
• 5x HDD Carrier (Black)
• 1x Base Chassis (Granby)
• 0x Power Supply Filler Panel
• 0x Processor Thermal Dummy
• 2x Fan Module
• 1x SATA Cable (Base board to SATA/IDE conversion board)
• 1x Front Panel Cable
• 1x Drive Power Cable (Tape Backup and DVD-ROM)
• 1x Fan Power Cable
• 1x Internal SAS Cable (Base board to SAS Backplane)
• 1x Internal SAS ROMB Module
• 1x Sample Safety Label
• 1x System Serial # Label
• 1x System Packaging
• 1x Rack Handles (Pair)
Intel® Server Platform SR6850HW4S (Harwich 800T SAS) 6U Rack.
• 1x Baseboard
• 1x Front Panel IO board
• 1x Memory Board (1X4) plus bracket
• 3x Memory filler baffles
• 0x Intel Management Module (Professional IMM)
• 1x Power Supply Module (15Amp, 110/208)
• 1x 1/2" DVD-ROM Drive
• 0x Button Control Panel Board
• 1x SAS 6U Backplane Board
• 1x Rack Faceplate (Gilbert)
• 10x HDD Carrier (Black)
• 1x Base Chassis (Gilbert)
• 0x Processor Thermal Dummy
• 6x Fan Module
• 1x SATA Cable (Base board to STAT/IDC conversion board)
• 1x Front Panel Cable (SCSI to Front Panel)
• 1x Drive Power Cable (Tape Backup and DVD-ROM)
• 1x Fan Power Cable
• 1x Internal SAS Cable (Base board to SAS Backplane)
• 1x Internal SAS ROMB Module
• 1x Front Connect Cable (100-pin) (Base board to front panel IO board)
• 1x Sample Safety Label
• 1x System Serial # Label
• 1x System Packaging
• 1x Rack Handles (Pair)
6/13/2007 SR4850HW4S / SR6850HW4S Configuration Guide Page 7 of 12
8. Complete Product Ordering Code Listings
The following table lists all of the product codes applicable to the Harwich platform (sorted by category). Following
the table are individual document sections which provide additional product descriptions for each product code.
8.1 Table 2: Base System Codes
Image Product Code MM /
UPC
SHW4URM3SA 886995
SHW6URM3SA 887385
Intel® Server System SR4850HW4S. 4
Socket, 4U, SAS 3.5"
Intel® Server System SR6850HW4S. 4
Socket, 6U, SAS 3.5"
Description
Qty
Per
1 1
1 1
Min
Order
6/13/2007 SR4850HW4S / SR6850HW4S Configuration Guide Page 8 of 12
8.2 Table 3: Common System Accessory Codes
Image Product Code MM /
AXXRAK18E 877661
BHW4DIMMM 876163
BHW4DIMMMBULK 877532
AHWPROCHS 869848
AHWPROCBLANK 881378
AHWVRMCM 883663
AHWVRMPM 881372
AXXBCPMOD2 881379
AXXLCPMOD2 879578
AHWIMMPRO2 878718
AHWIMMADV2 878719
AXXRAIL3U7U 877762
AXXCMA3U7U 862119
AXXRSBBU3 883471
AHWFCMOD 881842
Cable
Cable
AHWEXTSCSI 869985
AHWINTSCSI 869424
UPC
Description Qty
Intel® SAS RAID Activation Key.
Memory board. 4 DIMM DDR2-400. 1 Pack.
Memory board. 4 DIMM. 8 Pack.
Intel CEK processor heat sink.
Intel CEK processor blank. One required for every
empty processor slot to maintain proper airflow for
cooling.
Processor cache VRM 9DO for Intel® Xeon™
processor MP with iL3 cache. One VRM 9DO supports
both processors three and four. No VRM is required
for processors one and two.
Processor core VRM 10.2 for Intel® Xeon™ processor
MP. A VRM 10.2 is required for each processor three
and four.
Button Control Panel Module.
Intel® Local Control Panel. (LCP)
Intel® Server Management Module Professional. Only
for Intel® Server Platforms SR4850HW4 &
SR6850HW4.
Intel® Server Management Module Advanced. Only for
Intel® Server Platforms SR4850HW4 & SR6850HW4.
Rack rails for 3U-7U chassis. Does not include the
cable management arm. Tooless J-hook design.
Supports both the SR4850HW4 and SR6850HW4.
Rack cable management arm. 3U-7U chassis. Does
not include the rack rails. Supports both the
SR4850HW4 and SR6850HW4.
Intel® RAID Smart Battery.
Intel® Fibre Channel Module (HWFCM).
Cable: Internal cable for External SCSI port.
Cable: Internal cable for 5.25" peripheral bay.
Min
Per
Order
1 5
1 1
1 8
1 1
1 1
1 1
1 1
1 1
1 1
1 1
1 1
1 1
1 1
1 1
1 1
1 1
1 1
6/13/2007 SR4850HW4S / SR6850HW4S Configuration Guide Page 9 of 12
8.2.1 Table 4: 4U Unique Accessory Codes for SHW4URM3SA
Image Product Code MM /
UPC
AHW4UPWR 881373 Power supply module. 4U. 15Amp, 208V. 1 1
Description
AHW4URBEZEL 861922 Rack bezel for SR4850HW4. 1 1
AHW4U3SASKIT 882972
SAS 3.5" Conversion kit for SR4850HW4M (SCSI
conversion to SAS) - Contains Cable, Backplane,
and SAS Module (FHW4UINTSAS,
FHW4U3SASBP, FXXSROMBSAS18E)
8.2.2 Table 5: 6U Unique Accessory Codes for SHW6URM3SA
Image Product Code MM /
AHW6UPEDKIT 881375 SR6850HW4 pedestal conversion kit. 1 1
AHW6UPWR 881376 Power supply module. 6U. 15Amp, 110V/220V. 1 1
AHW6UPWRFAN 881377
UPC
Power bay fan. Mandatory when a second power
supply is not installed in the SR6850HW4.
Description
Qty
Per
Min
Order
1 1
Qty
Per
Min
Order
1 1
AHW6URBEZEL 861924 Rack bezel for SR6850HW4. 1 1
AHW6UPBEZEL 881839 Pedestal bezel for SR6850HW4. 1 1
SAS 3.5" Conversion kit for SR6850HW4M (SCSI
AHW6U3SASKIT 882993
conversion to SAS) - Contains Cable, Backplane,
and SAS Module(FHW6UINTSAS,
FHW6U3SASBP, FXXSROMBSAS18E)
8.3 Table 6: Common System Spare Part Codes
Image Product Code MM /
UPC
FXXSROMBSAS18E 878038 Intel® SAS ROMB Module. 1 5
BHWBASEM 885977 Intel® Server Board SE8501HW4. 1 1
Description
1 1
Qty
Per
Min
Order
Board
Cable
Plastic FHWPCIDIVIDER 871912 PCI Divider assembly. 1 1
SBCEDVD 865263 Optical Drive, DVD-ROM, single pack. 1 1
FHWSATAIDE 870273 SATA to IDE conversion board. 1 1
FHWINTRU 871387
Cable: Intrusion switch for SR4850HW4 and
SR6850HW4.
1 1
6/13/2007 SR4850HW4S / SR6850HW4S Configuration Guide Page 10 of 12
8.3.1 Table 7: 4U 3.5“ SAS Unique Spare Part Codes for SHW4URM3SA
Image Product Code MM /
UPC
Board
Cable
Kit
Fan
Board
Board
Cable
Plastic
Plastic
FHW4U3SASBP 876328 SAS 3.5” 4U backplane for SR4850HW4S. 1 1
FHW4UINTSAS 876302
AHW4U3SASKIT 882972
FHW4UFAN 881380 System fan for the SR4850HW4.
FHW4UFRTPNL 881385 Front IO panel board for SR4850HW4.
FHW4UPDB 881390 Power distribution board for SR4850HW4.
FHW4UFPSATA 871296
FHW4UPROCDUCT 871907 Processor Air Duct for SR4850HW4.
FHW4UPCILATCH 871909 PCI Card hold down latches. Set of 8 for SR4850HW4.
Cable: Internal SAS ROMB to 4U 3.5” SAS BP cable for
SR4850HW4S.
SAS 3.5" Conversion kit for SR4850HW4M (SCSI
conversion to SAS) - Contains (FHW4UINTSAS,
FHW4U3SASBP, FXXSROMBSAS18E)
Cable: Front panel and SATA cable bundle for
SR4850HW4.
Description
Qty
Per
1 1
1 1
1 1
1 1
1 1
1 1
1 1
1 1
8.3.2 Table 8: 6U 3.5” SAS Unique Spare Part Codes for SHW6URM3SA
Image Product Code MM /
UPC
Board
Cable
Kit
Fan
Board
Board
Cable
Plastic
Plastic
FHW6U3SASBP 876358 SAS 3.5” 6U backplane for SR6850HW4S (6U). 1 1
FHW6UINTSAS 876303
AHW6U3SASKIT 882993
FHW6UFAN 869992 System fan for the SR6850HW4 (6U).
FHW6UFRTPNL 881393 Front IO panel board for SR6850HW4 (6U).
FHW6UPDB 881404 Power distribution board for SR6850HW4 (6U).
FHW6UFPSATA 871300 Cable: Front panel and SATA cable bundle
FHW6UPCILATCH 871910 PCI Card hold down latches. Set of 8 for SR6850HW4.
FHW6UPROCDUCT 871911 Processor Air Duct for SR6850HW4.
Cable: Internal SAS ROMB to 6U 3.5” SAS BP cable for
SR4850HW4S.
SAS 3.5" Conversion kit for SR6850HW4M (SCSI
conversion to SAS) - Contains (FHW6UINTSAS,
FHW6U3SASBP, FXXSROMBSAS18E)
Description
Qty
Per
Min
Order
Min
Order
1 1
1 1
1 1
1 1
1 1
1 1
1 1
1 1
8.4 Table 9: Boxed Processor Codes Reference (Heatsink Included)
Category Product Code Description
Boxed Processor BX805507140M 3.4 GHz/16M/800 Dual-Core Intel® Xeon™ processor 7140M series
Boxed Processor BX805507130M 3.2 GHz/8M/800 Dual-Core Intel® Xeon™ processor 7130M series
Boxed Processor BX805507120M 3.0 GHz/4M/800 Dual-Core Intel® Xeon™ processor 7120M series
Boxed Processor BX805507110M 2.6 GHz/4M/800 Dual-Core Intel® Xeon™ processor 7110M series
Boxed Processor BX80560KG3000H 3.00 GHz/4M/800 Dual-Core Intel® Xeon™ processor 7000 sequence
Boxed Processor BX80560KF3000H 3.00 GHz/4M/667 Dual-Core Intel® Xeon™ processor 7000 sequence
Boxed Processor BX80560KG2800F 2.80 GHz/2M/800 Dual-Core Intel® Xeon™ processor 7000 sequence
Boxed Processor BX80560KF2660F 2.66 GHz/2M/667 Dual-Core Intel® Xeon™ processor 7000 sequence
Boxed Processor BX80546KF3333M 64-bit Intel® Xeon™ processor MP with 8MB L3 cache at 3.33 GHz
Boxed Processor BX80546KF3000M 64-bit Intel® Xeon™ processor MP with 8MB L3 cache at 3.0 GHz
Boxed Processor BX80546KF2833H 64-bit Intel® Xeon™ processor MP with 4MB L3 cache at 2.83 GHz
Boxed Processor BX80546KF3660EM 64-bit Intel® Xeon™ processor MP with 1MB L2 cache at 3.66 GHz
Boxed Processor BX80546KF3160EM 64-bit Intel® Xeon™ processor MP with 1MB L2 cache at 3.16 GHz
6/13/2007 SR4850HW4S / SR6850HW4S Configuration Guide Page 11 of 12
8.5 Table 10: Trayed Processor Codes Reference (Requires Heatsink-
AHWPROCHS)
Category Product Code Description
Tray Processor 80550KG096007 3.4 GHz/16M/800 Dual-Core Intel® Xeon™ processor 7140M series
Tray Processor 80550KG0888M 3.2 GHz/8M/800 Dual-Core Intel® Xeon™ processor 7130M series
Tray Processor 80550KF0804M 3.0 GHz/4M/800 Dual-Core Intel® Xeon™ processor 7120M series
Tray Processor 80550KG0644M 2.6 GHz/4M/800 Dual-Core Intel® Xeon™ processor 7110M series
6/13/2007 SR4850HW4S / SR6850HW4S Configuration Guide Page 12 of 12
Mouser Electronics
Authorized Distributor
Click to View Pricing, Inventory, Delivery & Lifecycle Information:
Intel:
AHWPROCHS AHW4UPWR AHW6UPBEZEL AHWPROCBLANK AHW6UPEDKIT
Loading...
