Intel® ServerBoardS5500WB

Intel® ServerSystemSR1690WB

Spares/PartsListandConfigurationGuide

A reference guide to assist customers in ordering the necessary components to configure the Intel® Server Board S5500WB and the Intel® Server System SR1690WB.

Revision 1.7

Enterprise Platforms and Services Marketing

Revision History

July ’09 - Rev 1.0 – initial public release of Intel® Server System SR1690WB, retained Intel® Server Board S5500WB product codes, including those for processor and management software.

July’09 – Rev 1.1 – Updated spares and accessories in support of PRA/SRA

Sept’09 – Rev1.2 – Updated MMID for SR1690WBNA and added accessory codes

Sept’09 – Rev1.3 – added VMware vSphere* software information

Nov’09 – Rev1.4 – Remove InfiniBand* IO module support from the list

Dec’09 – Rev1.5 – Add chassis cable management arm kit for AXXHERAIL2

Feb’10 – Rev1.6 – Update new order code and mm# for Server Board, Server System and slim-line DVD/CDR drive accessory

Apr’10 – Rev1.7 – Remove basic slide rail kit AXXBASICRAIL from the list

INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTION WITH INTEL® PRODUCTS. NO LICENSE, EXPRESS OR IMPLIED, BY ESTOPPEL OR OTHERWISE, TO ANY INTELLECTUAL PROPERTY RIGHTS IS GRANTED BY THIS DOCUMENT. EXCEPT AS PROVIDED IN INTEL'S TERMS AND CONDITIONS OF SALE FOR SUCH PRODUCTS, INTEL ASSUMES NO LIABILITY WHATSOEVER, AND INTEL DISCLAIMS ANY EXPRESS OR IMPLIED WARRANTY, RELATING TO SALE AND/OR USE OF INTEL PRODUCTS INCLUDING LIABILITY OR WARRANTIES RELATING TO FITNESS FOR A PARTICULAR PURPOSE, MERCHANTABILITY, OR INFRINGEMENT OF ANY PATENT, COPYRIGHT OR OTHER INTELLECTUAL PROPERTY RIGHT.

Intel products are not intended for use in medical, life saving, life sustaining applications. Intel may make changes to specifications and product descriptions at any time, without notice.

Intel server boards, server chassis, and processors may contain design defects or errors known as errata, which may cause the product to deviate from published specifications. Current characterized errata are available on request.

Intel, Intel Xeon, Pentium, and the Intel logo are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries.

*Other names and brands may be claimed as the property of others.

Copyright © 2010, Intel Corporation

2

Product Overview

Product Overview: The rack-optimized Intel® Server Board S5500WB and Intel® Server System SR1690WB are designed for high-density computing environments where energy efficiency and total cost of ownership are critical. They support up to two Intel® Xeon® processor 5500 series on nextgeneration Intel® microarchitecture, highly scalable DDR3 memory, and expandable PCIe 2.0 I/O.

Product Descriptions – Overview

The Intel® Server Board S5500WB is available to order in 3 different varieties:

1. Intel® Server Board S5500WB - SSI (available in single pack or OEM 10PK).

SSI SKU- this version of the server board is designed to work with an “off the shelf” multi-rail power supply that adheres to the SSI power specification: “Power Supply Design Guideline for 2008 DualSocket Servers and Workstations”. SSI specifications can be viewed at the following web

site: http://ssiforum.org

2. Intel® Server Board S5500WB - 12V(available in single pack or OEM 10PK).

12V SKU – this version of the server board uses specially designed “single rail” power supplies that provide 12V and 5V standby current. The server board has integrated high efficiency voltage regulators that produce other voltages required (e.g. 3.3V, 5V). The board can also supply 5V power needed for hard drives. More details on this can be found in the Technical Product Specification (TPS).

3. Intel® Server System SR1690WB* (An integrated system SKU).

Integrated System – Ships as an integrated system** SKU including the SSI version of the Intel® Server Board S5500WB in a Server Chassis featuring a high efficiency 650-watt power supply, PCIe 2.0 Riser and 4 hot swap HDD carriers which support both 2.5” and 3.5” drives.

*Chassis will not be offered separately

**Customer is required to provide Processors, DDR3 main memory and hard drives seperately to configure a complete, bootable system.

Note: In addition to this document, there is a web based tool to assist customers in selecting components for Intel Server Products available here: http://www.intel.com/go/serverconfigurator

3

Production Order Codes

1.1Board & System Order Codes

Product Code

MM#

UPC



Description









BBS5500WB12VR

905464

00735858208376

Intel® Server Board S5500WB, 12V Power SKU, 10 pack.









S5500WB12VR

905465

00735858208369

Intel® Server Board S5500WB, 12V Power SKU, single







pack/spare.









BBS5500WBR

905462

00735858208352

Intel® Server Board S5500WB, SSI power SKU, 10 pack.









S5500WBR

905463

00735858208345

Intel® Server Board S5500WB, SSI power SKU, single







pack/spare.

SR1690WBR

907330

00735858210980

Intel® Server System SR1690WB including:







1 Intel® Server Board S5500WB







Intel® Server Chassis SR1690WB







4 hot swap HDD carriers (supports both 2.5” & 3.5”)







1 PCI Express 2.0 x8 riser







1 high-efficient non-redundant 650-watt PSU







SATA backplane to connect 4 HDDs







4 dual-rotor system fans







Cabled front panel







2 Intel® Thermal Solution STS100P







Quick Reference Label







Quick Start Users Guide







Resource CD









SR1690WBRNA

905758

00735858210980

Same as SR1690WB but includes North America Power cord

Note that the boards are not shipped with a software CD, while the system does include a CD. The latest drivers and software can be downloaded from http://support.intel.com customers who require an Intel® Deployment Assistant CD may download an .ISO image and burn their own CDs.

1.2Optional System Accessory Order Codes:



Product Code

MM#

UPC



Description

















903445

00735858210997

System maintenance kit accessory for SR1690WB



FSR1690PMKIT







(includes all cables, Front Panel/USB Board, spare air











duct, etc)



FSR1690HDDCAR

903456

00735858211000

Spare HDD carrier for SR1690WB, supports both 2.5”









and 3.5” HDD; MOQ is 5













FSR1690BP

903457

00735858211017

Spare hot swap HDD backplane for SR1690WB – single









pack













FSR1690FAN

903458

00735858211024

Spare system fan kit for SR1690WB (includes one







processor fan and one memory fan)











FSR1690PS

903735

00735858211031

Spare 650-watt PSU for SR1690WB with PM Bus



AXXBASICRAIL

881096

00735858184748



Basic slide rail kit. Does not support Cable Management









Arm













AXXHERAIL2

901082

00735858206549

Full extending Rail Kit, compatible SR1690WB



AXXRACKARM2

901084

00735858206563

Chassis cable management kit, compliant with

4









AXXHERAIL2

AXXSATADVDROM

906872

00735858197663

Slim-line SATA DVD/CD-R drive accessory

AXXSATADVDRWROM

898051

00735858197670

Slim line SATA DVD-RW drive accessory

1.3 Optional Board Accessory Order Codes:











Product Code



MM#

UPC

Description











AXXRMM3



900961

735858206570

Intel Remote Management Module 3











AXX4SASMOD



900946

00735858206372

Intel® SAS Entry RAID I/O Expansion Moduleprovides









four internal ports of pass through SAS, entry-level RAID









0/1/1E, and optional host RAID 5 – requires









AXXRAKSW5

AXXROMBSASMR



901641

00735858208017

Intel® Integrated RAID I/O Expansion Moduleprovides 4









internal ports full featured SAS/SATA RAID 0, 1, 5, 6 and









striping capability for spans 10, 50, 60. Note: optional









backup battery module AXXRSBBU3 must be ordered









separately.

AXXRSBBU3



900954

00735858181853

Intel® RAID Smart Battery for AXXROMBSASMR











AXXGBIOMOD



880518

00735858184779

Dual Gigabit Ethernet Intel® I/O Expansion Module











AXXSASIOMOD



880517

00735858184786

External 4 port SAS Intel® I/O Expansion Module











AXX10GBIOMOD



900962

735858206525

Dual port 10 Gigabit Ethernet Intel® I/O Expansion









Module based on Intel 82598 controller with CX4









connectors

AXX4GBIOMOD2



901359

735858206532

Quad port Gigabit Ethernet Intel® I/O Expansion Module









based on the Intel® 82576EB Gigabit Ethernet Controller

AXXRAKSW5



878958

00735858181860

Intel® RAID Activation Key AXXRAKSW5. Enables Intel®









Embedded Server RAID Technology II, an optional









driver-based RAID 5 capability to on-board SATA ports,









or on AXX4SASMOD. MOQ = 5.

AXXPCIE16RISER



892597

00735858197441

1U PCI Express gen2 riser. Intel has performed basic









validation with this riser and recommends customers do









their own testing when using it with a 3rd party 1U









chassis and the S5500WB server board.

AXXRJ45DB92



881944

735858155212

Serial cable adapter kit. Contains two serial cable









converter dongles (RJ45 to DB9) one for DSD and one









for DCD (Modem). The kit also includes one serial ribbon









cable for cabling 2nd serial port from the baseboard.

1.4Intel® Thermal Solution STS100:

Boxed processors do not include CPU heatsinks, a separate heatsink is required.

Product Code

MM#

UPC

Description









BXSTS100P

900492

00735858205146

Intel® Thermal Solution STS100P – Passive 1U/2U







heatsink for processors up to and including 95W TDP

5

1.5Intel® Xeon® Processor 5500 Series options:













Max



































Boxed Product

Product

Clock

QPI

L3

Memory

# of Cores /



Turbo



UPC Code (Boxed

Processor Name

Code

MM#

Speed

Speed

Cache

Speed

Threads

HT

Boost

Power

Product Only)

Intel® Xeon® Processor X5570

BX80602X5570

901025

2.93 GHz

6.4 GT/s

8MB

1333 MHz

4 / 8

95W

7 35858 20569 6

Intel® Xeon® Processor X5560

BX80602X5560

901026

2.80 GHz

6.4 GT/s

8MB

1333 MHz

4 / 8

95W

7 35858 20570 2

Intel® Xeon® Processor X5550

BX80602X5550

901027

2.66 GHz

6.4 GT/s

8MB

1333 MHz

4 / 8

95W

7 35858 20571 9

Intel® Xeon® Processor E5540

BX80602E5540

901028

2.53 GHz

5.86 GT/s

8MB

1066 MHz

4 / 8

80W

7 35858 20572 6

Intel® Xeon® Processor E5530

BX80602E5530

901029

2.40 GHz

5.86 GT/s

8MB

1066 MHz

4 / 8

80W

7 35858 20573 3

Intel® Xeon® Processor E5520

BX80602E5520

901030

2.26 GHz

5.86 GT/s

8MB

1066 MHz

4 / 8

80W

7 35858 20574 0

Intel® Xeon® Processor L5530

BX80602L5530

903280

2.40 GHz

5.86 GT/s

8MB

1066 MHz

4 / 8

60W

7 35858 20996 0

Intel® Xeon® Processor L5520

BX80602L5520

901033

2.26 GHz

5.86 GT/s

8MB

1066 MHz

4 / 8

60W

7 35858 20575 7

Intel® Xeon® Processor L5518

AT80602002265AB

901505

2.13 GHz

5.86 GT/s

8MB

1066MHz

4 / 8

60W

N/A

Intel® Xeon® Processor L5508

AT80602002697AC

901549

2.00 GHz

5.86 GT/s

8MB

1066MHz

2 / 4

38W

N/A

Intel® Xeon® Processor E5506

BX80602E5506

901031

2.13 GHz

4.8 GT/s

4MB

800 MHz

4 / 4

N/A

N/A

80W

7 35858 20576 4

Intel® Xeon® Processor L5506

BX80602L5506

901023

2.13 GHz

4.8 GT/s

4MB

800 MHz

4 / 4

N/A

N/A

60W

7 35858 20579 5

Intel® Xeon® Processor E5504

BX80602E5504

901032

2.00 GHz

4.8 GT/s

4MB

800 MHz

4 / 4

N/A

N/A

80W

7 35858 20577 1

Intel® Xeon® Processor E5502

BX80602E5502

901022

1.86 GHz

4.8 GT/s

4MB

800 MHz

2 / 2

N/A

N/A

80W

7 35858 20578 8

1.6Intel® Xeon® Processor 5600 Series options:

Processor Name

Clock Speed

QPI Speed

L3

# of Cores /

Power







Cache

Threads















Intel® Xeon® Processor L5609

1.86 GHz

4.8 GT/s

12 MB

4

40

Intel® Xeon® Processor L5618

1.87 GHz

5.86 GT/s

12 MB

4

40

Intel® Xeon® Processor L5638

2 GHz

5.86 GT/s

12 MB

6

60

Intel® Xeon® Processor L5630

2.13 GHz

5.86 GT/s

12 MB

4

40

Intel® Xeon® Processor L5640

2.26 GHz

5.86 GT/s

12 MB

6

60

Intel® Xeon® Processor E5620

2.4 GHz

5.86 GT/s

12 MB

4

80

Intel® Xeon® Processor E5630

2.53 GHz

5.86 GT/s

12 MB

4

80

Intel® Xeon® Processor E5640

2.66 GHz

5.86 GT/s

12 MB

4

80

Intel® Xeon® Processor X5650

2.66 GHz

6.4 GT/s

12 MB

6

95

Intel® Xeon® Processor X5660

2.8 GHz

6.4 GT/s

12 MB

6

95

Intel® Xeon® Processor X5670

2.93 GHz

6.4 GT/s

12 MB

6

95

Intel® Xeon® Processor X5667

3.066 GHz

6.4 GT/s

12 MB

4

95

1.7Intel® RAID Contollers Options:








Product Code

MM#



UPC

MOQ



Description





































00735858

5



Intel® RAID Controller SRCSASLS4I - PCIe x8,









SRCSASLS4I

896952



201353





4P SAS RAID Controller, 128MB embedded





















memory, MD2 Low Profile, half length form factor.















00735858

5



















201346





Intel® RAID Controller SRCSASBB8I - PCIe x8,









SRCSASBB8I

896943









8P SAS RAID Controller, 256MB embedded





















memory, MD2 Low Profile, half length form factor.





































00735858

5



Intel® RAID Controller SASUC8I - PCIe x8, 8P









SASUC8I

900176



205115





SAS Controller with entry-level HW RAID

















0/1/1E/10E, low profile, half-length MD2 compliant









































form factor.

6







00735858

5

Intel® RAID Controller SASWT4I - PCIe x4, 4P



SASWT4I

900267

205108



SAS Controller with entry-level HW RAID







0/1/1E/10E, low profile, half-length MD2 compliant





















form factor.

1.8Intel® System Management Software – Upgrade Order Codes:

The following Intel® System Management Software Upgrade SKUs are offered. Each SKU includes a Certificate of Authenticity (COA) that contains a product key for user to enter to upgrade:

Upgrades available to Microsoft* System Center Essentials 2007

Small Network Edition - This upgrade gives the user the ability to manage up to 5 Windows-based servers OSEs and 15 Windows-based client OSEs.

Standard EditionThis upgrade gives the user the ability to manage up to 10 Windows-based servers OSEs and 50 Windows-based client OSEs.

Upgrade to add 1 or 5 Server Management license - This upgrade gives the user the ability to manage 1 or 5 additional Windows-based server OSE.

Upgrade to add 5 or 20 Client Management licenses - This upgrade gives the user the ability to manage 5 or 20 additional Windows-based client OSEs.

Intel® System Management Software – Upgrade Order Codes:



Product Code



UPC



MM





Description






MOQ























SMS2SSE2SNE

7 35858 19670 3

893177



Upgrade from 90 day trial Edition



1



















to Small Network Edition

























Not included: Software CDs are























not included with upgrade.









SMS2SNE2STD

7 35858 19671 0 893221 Upgrade from Small Network

1



Edition to Standard Edition





Not included: Software CDs are not





included with upgrade.



SMS2SSE2STD

7 35858 19672 7 893170 Upgrade from 90 day trial Edition

1



to Standard Edition





Not included: Software CDs are not





included with upgrade.



7

SMS2CAL1S

7 35858 19675 8

893217

Microsoft® System Center



1







Essentials 2007 Server











Management License (1 Pack)











Not included: Software CDs are not











included with upgrade.

















SMS2CAL5S

7 35858 19676 5

893218

Microsoft® System Center



1







Essentials 2007 Server











Management License (5 Pack)











Not included: Software CDs are not











included with upgrade.

















SMS2CAL5C

7 35858 19673 4

893220

Microsoft® System Center



1







Essentials 2007 Client











Management License (5 Pack)











Not included: Software CDs are not











included with upgrade.

















SMS2CAL20C

7 35858 19674 1

893219

Microsoft® System Center



1







Essentials 2007 Client











Management License (20 Pack)











Not included: Software CDs are not











included with upgrade.

















1.9VMware vSphere* and vCenter* Server SKUs

The following VMware vSphere SKUs are offered when purchasing a qualifying Intel® Server Board or Intel® Server System. Each SKU contains a software product activation code for user to enter to download software and install. As directed on the certificate, the end user must register the product activation code with VMware at http://www.vmware.com/code/intel within 30 days to access VMware Software, Support and Subscription Services.

VMware vSphere* and vCenter* Server SKUs

Essentials

This license activation code gives the user VMware vSphere* 4 Essentials Bundle for 3 hosts (Max 2 processors per host and 6 cores per processor), with 1 year VMware Subscription.

Essentials Plus

This license activation code gives the user VMware vSphere* 4 Essentials Plus Bundle for 3 hosts (Max 2 processors per host and 6 cores per processor), with 1 year VMware Gold Support and Subscription.

Standard

This license activation code gives the user VMware vSphere* 4 Standard for 1 Processor (Max 6 cores per CPU), with 1 year VMware Gold Support and Subscription.

Advanced

8

This license activation code gives the user VMware vSphere* 4 Advanced for 1 Processor (Max 12 cores per CPU), with 1 year VMware Gold Support and Subscription.

Enterprise Plus

This license activation code gives the user VMware vSphere* 4 Enterprise Plus for 1 Processor (Max 12 cores per CPU), with 1 year VMware Gold Support and Subscription.

VMware vCenter* Server Standard for vSphere*

This license activation code gives the user VMware vCenter* Server 4 Standard for vSphere* (Includes Orchestrator and Linked Mode), with 1 year VMware Gold Support and Subscription.

VMware vSphere* and VMware vCenter* Standard – Order Codes:

Product



UPC





MM





Description





MOQ



Code









































VMW4ESS

7 35858 21272 4



904791





Software license activation code certificate

1



















for VMware vSphere* 4 Essentials Bundle for























3 hosts (Max 2 CPUs per host and 6 cores























per CPU) with 1 year VMware Subscription.

























VMW4ESSPLUS

7 35858 21273 1



904792





Software license activation code certificate

1



















for VMware vSphere* 4 Essentials Plus























Bundle for 3 hosts (Max 2 CPUs per host and























6 cores per CPU) with 1 year VMware Gold























Support and Subscription.

























VMW4STD

7 35858 21274 8



904793





Software license activation code certificate

1



















for VMware vSphere* 4 Standard for 1























Processor (Max 6 cores per CPU) with 1 year























VMware Gold Support and Subscription.

























VMW4ADV

7 35858 21275 5



904797





Software license activation code certificate

1



















for VMware vSphere* 4 Advanced for 1























Processor (Max 12 cores per CPU) with 1























year VMware Gold Support and Subscription.

























VMW4ENTPLUS

7 35858 21276 2



904800





Software license activation code certificate

1



















for VMware vSphere* 4 Enterprise Plus for 1























Processor (Max 12 cores per CPU) with 1























year VMware Gold Support and Subscription.

























VMWVCSTD

7 35858 21277 9



904801





Software license activation code certificate

1



















for VMware vCenter* Server 4 Standard























(includes Orchestrator and Linked Mode)























with 1 year VMware Gold Support and























Subscription.

































9
