Intel BP710A User Manual

Yukka Beach

User Guide

ContEnts

1 Getting Started ............................................................................................. 3

1.1 Your Tablet .................................................................................3

1.2 Tablet Buttons ............................................................................4

1.3 Tablet Slots, Ports & Jacks ........................................................... 4

1.4 Charge the Battery.......................................................................5

1.4.1 Battery Tips .............................................................................................. 5

1.5 Turn on the Tablet .......................................................................5

1.6 Sleep & Wake ............................................................................6

1.7 Tips on Using the Touchscreen .....................................................6

2 Home Screen & Basic Features ..................................................................... 7

2.1 Customizing Your Home Screen ....................................................7

2.2 Status & Notiﬁcation Icons ...........................................................8

2.2.1 Status Icons ............................................................................................. 9

2.2.2 Notiﬁcation Icons ...................................................................................... 9

2.3 Search .....................................................................................10

2.4 Securing your Tablet .................................................................. 10

2.5 Using the App Launcher ............................................................11

2.6 Using the Play Store ..................................................................11

3 Taking Photos & Videos ............................................................................. 12

3.1 View Your Pictures & Video .........................................................13

4 Connections .............................................................................................. 15

4.1 Using Wi-Fi .............................................................................15

4.2 Wireless Bluetooth® Connection ..................................................15

4.3 Transferring Files between your Tablet & Computer .......................16

4.4 Connecting to Virtual Private Networks ........................................16

4.5 Sharing Your Tablet’s Data Connection ........................................16

4.5.1 Share your Tablet’s Data Connection via USB Tethering .............................. 16

5 Accounts ................................................................................................... 17

6 Changing Tablet Settings ............................................................................ 18

6.1 Wireless & Networks ..................................................................18

6.2 Device ......................................................................................18

6.3 Personal ...................................................................................19

6.4 System .....................................................................................20

7 Safety, Regulatory & Legal ......................................................................... 21

PAGE : 2

1 GEttinG stArtEd

Congratulations on your new tablet purchase.

This guide will help you quickly come up to speed on the important features of your tablet.

1.1 Your tAblEt

Keep in mind your tablet has:

• Fast Processor: Featuring the Intel® Atom™ processor that enables fast web browsing, super-responsive apps, and effortless multi-tasking, so that enjoying the things you love to do has never been easier.

• Intelligent Camera: Featuring an advanced 2MP HD camera that lets you capture images quickly - up to 5 photos a second - so you’ll never miss the best shot, even in challenging environments.

• Great Entertainment: Easily create and share HD-quality video, and with super-smooth playback, your tablet becomes a personal theatre you can take with you anywhere.

NOTE: Screen images and icons are simulated for the purpose of this guide. Actual displays may vary. Instructions in this guide may change depending on the software version on your tablet.

2.0MP Rear-Facing Camera

Speaker

3.5mm Audio Jack

Speaker

1.0 GEttinG stArtEd

Micro SD Card Slot

USB/Power Port

PAGE : 3

1.2 tAblEt buttons

Volume

Power Button

Back

VGA Front-Facing Camera

Home

Recent

On-screen buttons

Power button

Volume

Press to go back to the previous screen or to close a

menu or dialog box.

Press to return to the center panel of the Home

screen.

Press to view recently used apps. Swipe side-to-side

to see all available apps. Click on an app to launch it.

TIP: Press and hold to launch the Search function.

Press and hold to turn your tablet on. To turn the tablet off, press and hold then follow the instructions onscreen.

When your tablet is on, press to wake your tablet or put it into sleep mode.

Press on the top to increase the volume or on the bottom to decrease the volume.

TIP: Press either top or bottom to silence an incoming call.

1.3 tAblEt slots, Ports & JACks

3.5 mm audio jack

USB/Power port

Micro SD Card slot

Plug in headphones or other audio device.

Connect USB cord to tablet and power adapter to charge the tablet.

NOTE: You can plug the USB cord into tablet and connect to your PC.

Insert a micro SD card for additional media storage.

1.0 GEttinG stArtEd

PAGE : 4

1.4 ChArGE thE bAttErY

1.5 turn on thE tAblEt

Before using your tablet for the ﬁrst time, charge the tablet for three hours.

To charge the battery:

1. Attach one end of the USB cord to the tablet’s micro-USB port and the

other end to the plug.

2. Plug the tablet into the wall.

1.4.1 bAttErY tiPs

For the best battery life, let your battery drain down to 15% or less (indicated by the battery very low icon in the status bar) before recharging, and do not leave your tablet plugged in after it is fully charged.

To make your charge last as long as possible:

• Change the screen timeout rate and display brightness (see Display Settings).

• Disable Wi-Fi when not in use (see Wireless & Networks Settings).

NOTE: For optimal charging, please use the USB cable and charger provided with the tablet.

To turn on the tablet:

• Hold down the power button to turn the tablet on.

TIP: One press puts your tablet into Sleep mode. Pressing and holding allows you to choose Silent mode or Airplane mode.

To turn the tablet off:

• Hold down the power button and touch Power Off.

Hold down the power button to turn the phone on.

1.0 GEttinG stArtEd

Connect this end to

phone’s USB port.

Plug into wall.

Connect this end to plug.

Hold down the power button, then touch Power off to turn the phone off.

PAGE : 5

1.6 slEEP & WAkE

When your tablet is on, you can put the tablet in sleep mode and lock your tablet. Your tablet will go into sleep mode if left idle, to save battery life.

1.7 tiPs on usinG thE touChsCrEEn

• Do not use sharp tools, such as pens or a stylus, on the touchscreen—these might scratch the screen.

You can wake and unlock your tablet when you’re ready to use it.

To put the tablet in sleep mode:

• Brieﬂy press the power button.

Your tablet goes into sleep mode, without disrupting any running application, download, or phone call.

NOTE: If you press and hold the power button for too long, you will see the power off menu.

To wake the tablet:

1. Press the power button.

2. Place your ﬁnger on and slide it all the way to the right.

3. Your tablet’s screen will resume display.

NOTE: If your tablet is secured, you must enter your password, pin, or pattern to wake it. See Securing Your Tablet for more details.

TIP: You can go directly to the Camera app by sliding the lock to on the left after waking your tablet.

• Do not allow the touchscreen to come in contact with other electrical devices. Electrostatic discharges can cause the touchscreen to malfunction.

• Do not allow the touchscreen to get wet. The touchscreen may malfunction in humidity or when exposed to water.

• For the best performance, before using the device, remove the screen protection ﬁlm and tap the screen with your ﬁngertip.

1.0 GEttinG stArtEd

When the phone is in sleep mode, and you want to wake the phone, press the power button and then drag the lock to the right.

PAGE : 6

2 homE sCrEEn & bAsiC FEAturEs

The Home screen is a gateway to all of your tablet’s applications and features, and displays whenever you turn on your tablet.

TIP: To move an icon, touch and hold the icon, then drag it to a new location.

To open the Home screen:

• Open the Home screen at any time by pressing the button.

The Home screen is split into ﬁve panels, with the center panel displayed when the Home screen opens.

To scroll the Home screen:

• Slide the screen to the left or right.

2.1 CustomizinG Your homE sCrEEn

You can easily customize your Home screen by changing the background picture (or wallpaper).

To customize your Home screen:

• Touch and hold an empty space on the Home screen, then touch the type of

item you want to add and follow the prompts.

The following types of items are available:

• Gallery allows you to choose photos on your tablet to set as the background

image for your screen.

• Live Wallpapers are animated background images for your screen.

• SocialGallery allows you to choose the tablet screen’s background image from photos on your tablet, including photos from apps such as Instagram.

TIP: The bar at the bottom of the screen indicates which one of the ﬁve panels is displayed.

Touch Google to search the web via text input tray.

Touch the microphone to search the web via voice input.

Touch and hold to change the wallpaper.

Touch an app to open it.

Swipe left or right to see more panels.

Touch to view all apps.

• Wallpapers are static background images for your screen.

2.0 homE sCrEEn & bAsiC FEAturEs

PAGE : 7
