USER GUIDE
5.8 GHz Digital Wireless
Stereo Headphones
NS-HAWHP2
Before using your new product, please read these instructions to prevent any damage.
Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 Safety information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 Setting up your system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 Using your system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 Understanding indicator lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 Maintaining your system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 Legal notices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 ONE-YEAR LIMITED WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Introduction
Congratulations on your purchase of high-quality Insignia 5.8 GHz Wireless Stereo Headphones. This system represents the state of the art in wireless headphone design, and gives you complete freedom while enjoying your music or TV without the limitations of cables.
The system has a maximum transmission range of up to 32.8 feet (10 m). You can use the docking station to recharge the headphones when they are not in use.
The system can be used with your television or other audio components, like your CD/DVD player, home theater system, or even audio output from a computer or MP3 player.
This User Guide explains how to correctly install, operate, and get the best performance from your Insignia Digital Wireless Stereo Headphones. Read this guide carefully before installing your system, and then keep it handy for quick reference.
2 |
www.insigniaproducts.com |
5.8 GHz Digital Wireless Stereo Headphones
Safety information
WARNING: To reduce the risk of fire or electric shock, do not expose this system to rain or moisture.
•Read these instructions.
•Keep these instructions.
•Heed all warnings.
•Follow all instructions.
•Do not use this system near water.
•Clean only with a dry cloth.
•Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
•Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong is provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
•Protect the power cord from being walked on or pinched particularly at plugs, power outlets, and the point where they exit from the system.
•Only use attachments or accessories specified by the manufacturer.
•Unplug this system during lightning storms or when unused for long periods of time.
•Refer all servicing to qualified service personnel. Servicing is required when the system has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the system, the system has been exposed to rain or moisture, does not operate normally, or has been dropped.
•To reduce the risk of fire or electric shock, do not expose this system to rain or moisture.
•The shock hazard marking and associated graphical symbol are provided on the supplied AC adapter.
•The system shall not be exposed to dripping or splashing and objects filled with liquids should not be placed on the system.
•The AC plug or AC adapter is used as the disconnect device. The disconnect device shall remain readily available.
•Excessive sound pressure from headphones can cause hearing loss.
•Batteries (battery pack and batteries installed) should not be exposed to excessive heat such as sunshine or fire.
•Do not place any conductive material on the docking station to avoid short circuits involving the charging pins.
www.insigniaproducts.com |
3 |
NS-HAWHP2
Features
•High-Performance digital wireless audio with adjustable volume control.
•Strong Wireless Signal - 33 ft. (10 m) wireless range (maximum, line-of-sight).
•Easy to Use - Easy setup, built-in rechargeable batteries with convenient docking station.
Package contents
Examine the contents of the box for your digital wireless stereo headphones. The box should contain:
AC adapter
Headphones and docking station
Quick Start Guide
|
|
|
|
|
|
|
|
|
|
|
|
RCA audio cable |
|
3.5 mm-to-RCA |
|||
|
|
|
adapter cable |
||
Note: The RCA audio and 3.5 mm-to-RCA adapter cables are connected together in the box.
4 |
www.insigniaproducts.com |
5.8 GHz Digital Wireless Stereo Headphones
Headphones
Item Description
1Power/Pairing indicator (red/blue):
•Blue - blinks every second if the headphone and docking station are paired.
•Blue and Red - blinks alternately if the headphone and docking station are pairing.
•Red - blinks three times a minute if the headphone batteries are low. Lights when the batteries are charging.
2Headphone
(power) button (on right earpiece). Press and release to turn the headphones on. Press and hold (for more than two seconds) to turn the headphones off.
3Volume Up (+) button. Press to increase the volume.
4Volume Down (–) button. Press to decrease the volume.
5Input source button. Press to change audio sources.
www.insigniaproducts.com |
5 |
NS-HAWHP2
Docking station
Item |
Description |
|
|
1 |
Charging indicator: |
|
• Turns red when the headphones are charging. |
|
• Turns green when the headphones are charged. |
|
Pairing indicator (blue): |
|
• Blinks every second if the headphones and docking station are paired. |
|
• Blinks alternately blue and red if the headphones and docking station |
|
are pairing. |
|
|
2 |
Input source button. Press to switch between audio input sources. |
|
|
3 |
RCA source indicator. Lights when the RCA input source is selected. |
|
|
4 |
Headphones. |
|
|
5 |
OPTICAL source indicator. Lights when the digital optical source is selected. |
|
|
6 |
www.insigniaproducts.com |
5.8 GHz Digital Wireless Stereo Headphones
Docking station back
AUDIO
IN
AUDIO
OUT
DIGITAL
OPTICAL
IN
Item |
Description |
|
|
1 |
AUDIO IN jacks (L and R). Connect a TV or other sound source to |
|
these jacks. |
|
|
2 |
AUDIO OUT jacks (L and R). Optional. Connect to a stereo system or |
|
other audio device. |
|
|
3 |
DIGITAL OPTICAL IN. Connect a digital optical cable to this jack. |
|
|
4 |
DC 5V jack. Connect the AC adapter to this jack. |
|
|
www.insigniaproducts.com |
7 |
NS-HAWHP2
Setting up your system
Step 1- Powering the docking station
CAUTION:
•To avoid risk of fire and to prevent damage, only use the AC adapter supplied with your wireless headphones. Make sure that the AC power outlet matches the AC adapter’s 100-240V before making the connection.
•Connect one end of the AC adapter to the docking station’s DC IN jack and the other end to a power outlet. The PAIRING indicator blinks blue while it searches for a connection.
NOTES:
•Standby mode: Press and hold Input Source for more than 10 seconds to put the docking station in standby mode.
•Normal mode: Press Input Source to turn on the docking station. The indicators turn solid red while the headphones are charging.
AUDIO
IN
AUDIO
OUT
DIGITAL
OPTICAL
IN
DC IN jack
8 |
www.insigniaproducts.com |
