2130XP Air Impact Wrench Exploded Diagram

(Dwg. TP2189XP)

www.irtools.com

Form 04584645

Edition 1

October 2004

2130XP Air Impact Wrench Parts List

Item Part Description Part Number Item Part Description Part Number

* Housing Assembly 2130XP-A40 20 Reverse Valve Assembly 2130-D329

1 Housing --- 21 Reverse Button 2130-75

3 Nameplate/Warning Label --- * Inlet Bushing Assy (Includes 22, 23 & 2 4) 2131-D565

2 Screw, Hammer Case (4 required) 2130-638 22 Inlet Bushing 2131-565

3 Nameplate/Warning Label 2130XP-301 23 Inlet Clip 2131-57

4 Power Regulator Assy 2130-D249 24 Inlet Parts Kit 2131-K303

5 Retaining Ring 2131-6 24A Washer ---

6 Ball Bearing (2 required) 402-22 24B O-Ring, Seal ---

7 Cylinder 2130-3 24C Spring ---

8 Rotor 2131-53 24D Valve ---

9 Vane Pack (set of 6) 2131-42A-6 24E Seat ---

10 End Plate 2131-11 24F Support ---

11 Rear Cap 2130-12 24G Retainer ---

12 Hammer Case Gasket 2130-36 25 Muffler Felt 2130QT-311

* Impact Mechanism Kit (2130XP) 2130-IMK1 26 Inlet Baffle 2130-318

* Impact Mechanism Kit (2130XP-2) 2130-IMK2 * Tune-Up Kit 2130-TK1

12 Hammer Case Gasket --- 5 Retaining Ring ---

13 Hammer (2) --- 6 Ball Bearing (2) ---

14 Hammer Pin (2) --- 9 Vane Pack (set of 6) ---

15 Anvil Assembly --- 12 Hammer Case Gasket ---

16 Hammer Frame --- 18 Trigger Assy ---

* Kit Grease --- 19 Motor Gasket ---

17 Hammer Case Assy 2130-D727A 20 Reverse Valve Assy ---

18 Trigger Assy 2130-D1093 24 Inlet Parts Kit ---

19 Motor Gasket 2130-283 * Inlet Clip Removal Tool 2131-322

* Not Illustrated

Parts and Maintenance

When the life of the tool has expired, it is recomme nded that the tool be disassembled, degreased and parts be se parated by material so that they can be recycled.

Tool repair and maintenance should only be carried out by an authorized Service Cen ter. Refer all communications to the nearest Ingersoll-Rand Office or Distributor.
