Copyright
This publication, including all photographs, illustrations and software, is protected under international
copyright laws, with all rights reserved. Neither this manual, nor any of the material contained herein, may
be reproduced without written consent of the author.
© Copyright 2013
Disclaimer
The information in this document is subject to change without notice. The manufacturer makes no
representations or warranties with respect to the contents hereof and specifically disclaims any implied
warranties of merchantability or fitness for any particular purpose. The manufacturer reserves the right to
revise this publication and to make changes from time to time in the content hereof without obligation of
the manufacturer to notify any person of such revision or changes.
Trademark Recognition
Kensington is a U.S. registered trademark of ACCO Brand Corporation with issued registrations and
pending applications in other countries throughout the world.
HDMI, the HDMI Logo, and High-Definition Multimedia Interface are trademarks or
registered trademarks of HDMI Licensing LLC in the United States and other countries.
All other produ
ct names used in this manual are the properties of their respective owners and are acknowledged.
— i —
IN134UST/IN136UST User’s Manual
Important Safety Information
Important:
It is strongly recommended that you read this section carefully before using the projector. These
safety and usage instructions will ensure that you enjoy many years of safe use of the projector.
Keep this manual for future reference.
Symbols Used
Warning symbols are used on the unit and in this manual to alert you of hazardous situations.
The following styles are used in this manual to alert you to important information.
Note:
Provides additional information on the topic at hand.
Important:
Provides additional information that should not be overlooked.
Caution:
Alerts you to situations that may damage the unit.
Warning:
Alerts you to situations that may damage the unit, create a hazardous environment, or cause
personal injury.
Throughout this manual, component parts and items in the OSD menus are denoted in bold font as in this
example:
“Push the Menu button on the remote control to open the Main menu.”
General Safety Information
Do not open the unit case. Aside from the projection lamp, there are no user-serviceable parts in
the unit. For servicing, contact qualified service personnel.
Follow all warnings and cautions in this manual and on the unit case.
The projection lamp is extremely bright by design. To avoid damage to eyes, do not look into the
lens when the lamp is on.
Do not place the unit on an unstable surface, cart, or stand.
Avoid using the system near water, in direct sunlight, or near a heating device.
Do not place heavy objects such as books or bags on the unit.
— ii —
Projector Installation Notice
Place the projector in a horizontal position
The tilt angle of the projector should not exceed 15 degrees, nor should the projector be installed in
any way other than the desktop and ceiling mount, otherwise lamp life could decrease dramatically.
Allow at least 50 cm clearance around the exhaust vent.
Ensure that the intake vents do not recycle hot air from the exhaust vent.
When operating the projector in an enclosed space, ensure that the surrounding air temperature
within the enclosure does not exceed operation temperature while the projector is running, and the
air intake and exhaust vents are unobstructed.
All enclosures should pass a certified thermal evaluation to ensure that the projector does not
recycle exhaust air, as this may cause the device to shutdown even if the enclosure temperature is
with the acceptable operation temperature range.
Power Safety
Only use the supplied power cord.
Do not place anything on the power cord. Place the power cord where it will not be in the way of
foot traffic.
Remove the batteries from the remote control when storing or not in use for a prolonged period.
Replacing the Lamp
Preface
Replacing the lamp can be hazardous if done incorrectly. See Replacing the Projection Lamp on page 39
for clear and safe instructions for this procedure. Before replacing the lamp:
Unplug the power cord.
Allow the lamp to cool for about one hour.
Cleaning the Projector
Unplug the power cord before cleaning. See Cleaning the Projector on page 42.
Allow the lamp to cool for about one hour.
Regulatory Warnings
Before installing and using the projector, read the regulatory notices in the Regulatory Compliance section
on page 55.
Important Recycle Instructions:
Lamp(s) inside this product contain mercury. This product may contain other electronic waste that
can be hazardous if not disposed of properly. Recycle or dispose in accordance with local, state, or federal
Laws. For more information, contact the Electronic Industries Alliance at WWW.EIAE.ORG
. For lamp
specific disposal information check WWW.LAMPRECYCLE.ORG.
Symbol Explanations
DISPOSAL: Do not use household or municipal waste collection services for
disposal of electrical and electronic equipment. EU countries require the use
of separate recycling collection services.
– iii –
IN134UST/IN136UST User’s Manual
GS Mark
Associated address:
INFOCUS INTERNATIONAL B.V.
CASABLANCAWEG 14 BLD A4 1047 HP
AMSTERDAM NL
About this manual
This manual is intended for end users and describes how to install and operate the DLP projector.
Wherever possible, relevant information—such as an illustration and its description—has been kept on
one page. This printer-friendly format is both for your convenience and to help save paper, thereby
protecting the environment. It is suggested that you only print sections that are relevant to your needs.
— iv —
Preface
Table of Contents
GETTING STARTED........................................................................................................................................................... 1
PACKING CHECKLIST ........................................................................................................................................................... 1
VIEWS OF PROJECTOR PARTS............................................................................................................................................... 2
Front-right View ............................................................................................................................................................ 2
Top view—On-screen Display (OSD) buttons and LEDs....................................................................................... 3
Rear view....................................................................................................................................................................... 4
Bottom view................................................................................................................................................................... 6
REMOTE CONTROL PARTS ................................................................................................................................................... 7
REMOTE CONTROL OPERATING RANGE ............................................................................................................................... 9
PROJECTOR AND REMOTE CONTROL BUTTONS.................................................................................................................... 9
SETUP AND OPERATION............................................................................................................................................... 10
INSERTING THE REMOTE CONTROL BATTERIES ................................................................................................................. 10
STARTING AND SHUTTING DOWN THE PROJECTOR............................................................................................................. 11
SETTING AN ACCESS PASSWORD (SECURITY LOCK) .......................................................................................................... 12
ADJUSTING THE PROJECTOR LEVEL ................................................................................................................................... 14
ADJUSTING THE FOCUS AND KEYSTONE ............................................................................................................................ 15
ADJUSTING THE VOLUME .................................................................................................................................................. 15
ON-SCREEN DISPLAY (OSD) MENU SETTINGS ...................................................................................................... 16
OSD MENU CONTROLS ..................................................................................................................................................... 16
Navigating the OSD ................................................................................................................................................... 16
SETTING THE OSD LANGUAGE .......................................................................................................................................... 17
OSD MENU OVERVIEW ..................................................................................................................................................... 18
OSD SUB-MENU OVERVIEW ............................................................................................................................................. 19
IMAGE MENU..................................................................................................................................................................... 20
Advanced Features.................................................................................................................................................... 21
Color Manager ............................................................................................................................................................ 22
COMPUTER MENU.............................................................................................................................................................. 23
VIDEO / AUDIO MENU........................................................................................................................................................ 24
Audio ............................................................................................................................................................................ 25
INSTALLATION I MENU ...................................................................................................................................................... 26
Advanced Features.................................................................................................................................................... 27
INSTALLATION II MENU..................................................................................................................................................... 29
Advanced Features.................................................................................................................................................... 30
OSD Menu Setting ..................................................................................................................................................... 31
Peripheral Test ........................................................................................................................................................... 31
Lamp Hour Reset ....................................................................................................................................................... 32
3D ................................................................................................................................................................................. 33
Network........................................................................................................................................................................ 34
Factory Reset.............................................................................................................................................................. 38
Status ........................................................................................................................................................................... 38
MAINTENANCE AND SECURITY.................................................................................................................................. 39
REPLACING THE PROJECTION LAMP................................................................................................................................... 39
Resetting the Lamp.................................................................................................................................................... 41
CLEANING THE PROJECTOR................................................................................................................................................ 42
Cleaning the Projector Mirror:................................................................................................................................... 42
Cleaning the Case...................................................................................................................................................... 43
USING THE PHYSICAL LOCK .............................................................................................................................................. 44
Using the Kensington® Lock ..................................................................................................................................... 44
Using the Security Bar............................................................................................................................................... 44
TROUBLESHOOTING...................................................................................................................................................... 45
COMMON PROBLEMS AND SOLUTIONS ............................................................................................................................... 45
TIPS FOR TROUBLESHOOTING ............................................................................................................................................ 45
LED ERROR MESSAGES..................................................................................................................................................... 46
IMAGE PROBLEMS.............................................................................................................................................................. 46
– v –
IN134UST/IN136UST User’s Manual
LAMP PROBLEMS ............................................................................................................................................................... 47
REMOTE CONTROL PROBLEMS .......................................................................................................................................... 47
HAVING THE PROJECTOR SERVICED .................................................................................................................................. 47
HDMI Q & A .................................................................................................................................................................... 48
SPECIFICATIONS............................................................................................................................................................. 49
SPECIFICATIONS................................................................................................................................................................. 49
PROJECTION DISTANCE VS. PROJECTION SIZE.................................................................................................................... 50
Projection Distance and Size Table......................................................................................................................... 50
TIMING MODE TABLE ........................................................................................................................................................ 51
PROJECTOR DIMENSIONS ................................................................................................................................................... 54
REGULATORY COMPLIANCE....................................................................................................................................... 55
FCC WARNING .................................................................................................................................................................. 55
CANADA ............................................................................................................................................................................ 55
SAFETY CERTIFICATIONS ................................................................................................................................................... 55
APPENDIX I........................................................................................................................................................................ 56
COMMUNICATION .............................................................................................................................................................. 56
— vi —
IN134UST/IN136UST User’s Manual
GETTING STARTED
Packing Checklist
Carefully unpack the projector and check that the following items are included:
EMOTE CONTROL
R
(B
ATTERIES NOT INCLUDED
CD-ROM
HIS USER’S MANUAL)
(T
DLP PROJECTOR
P
OWER CORD VGA CABLE
)
Q
UICK START GUIDE SAFETY & WARRANTY BOOKLET
Contact your dealer immediately if any items are missing, appear damaged, or if the unit does not work. It
is recommended that you keep the original packing material should you ever need to return the equipment
for warranty service.
Caution:
Avoid using the projector in dusty environments.
– 1 –
IN134UST/IN136UST User’s Manual
Views of Projector Parts
Front-right View
13
26
ITEM LABEL DESCRIPTION SEE PAGE
1.
2.
3.
4.
5.
6.
Important:
Ventilation openings on the projector allow for good air circulation, which keeps the projector lamp
cool. Do not obstruct any of the ventilation openings.
Lamp cover Remove cover to replace lamp module
IR receiver Receives IR signal from remote control
Aspheric mirror Reflects images
Lens Projection Lens
Focus ring Focuses the projected image
Function keys
See Top view—On-screen Display (OSD)
buttons and LEDs.
4
5
3
— 2 —
IN134UST/IN136UST User’s Manual
Top view—On-screen Display (OSD) buttons and LEDs
1
2
3
4
5
12
6
7
8
9
10
11
ITEM LABEL DESCRIPTION SEE PAGE
1.
2.
3.
4.
MENU Opens and exits OSD menus
Navigates in the OSD
SOURCE Enter the Source menu
Keystone adjustment (when OSD menu is closed)
Navigates and changes settings in the OSD
Volume adjustment (when OSD menu is closed).
16
16
5.
6.
7.
8.
9.
10.
11.
12.
AUTO Optimizes image size, position, and resolution
LAMP LED
POWER LED
TEMP LED Red Overheating
Enter or confirm highlighted OSD menu items
Navigates and changes settings in the OSD
Volume adjustment (when OSD menu is closed).
Navigates in the OSD
Keystone adjustment (when OSD menu is closed)
Turns the projector On or Off
Red Lamp Fail
Flashing
Amber
Green
Flashing
Green
Error code
Ready to power on (Standby)
Lamp Lit , System stable
Overheating
System initializing, powering on, cooling
down, and error code.
– 3 –
16
46
IN134UST/IN136UST User’s Manual
Rear view
12
3
4
56
89
7
1516
ITEM LABEL DESCRIPTION SEE PAGE
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
Security bar For security purposes
Kensington lock
3D SYNC
AUDIO IN
AUDIO OUT Connect an AUDIO cable to an audio amplifier
MIC Connect a microphone
RS-232 Connect a RS-232 serial port cable for remote control
USB Connect a USB cable from a computer
AC IN Connect a POWER cable
VGA IN – 2 Connect a RGB cable from a computer or component device
VGA IN – 1 Connect a RGB cable from a computer or component device
VGA OUT
13
14
Secure to a permanent object with a Kensington®
Lock system
Connect the 3D IR glasses transmitter
(Note: For Vivitek brand 3D IR glasses only)
Connect an AUDIO cable from the audio device. (Supports audio for
VGA IN-1, VGA IN-2, Composite, and S-video sources.)
Connect a RGB cable to a display
(Loop through only available using VGA IN-1)
12 11
10
44
11
13.
S-VIDEO Connect a S-video cable from a video device
— 4 —
IN134UST/IN136UST User’s Manual
ITEM LABEL DESCRIPTION SEE PAGE
14.
15.
16.
VIDEO Connect a composite cable from a video device
HDMI Connect an HDMI cable from a HDMI device
RJ45 Connect a LAN cable from Ethernet
Note:
If your video equipment has various input sources, it is recommended that you connect the cables
in the following order for the best picture quality : HDMI/DVI, component (thru VGA), Composite.
Warning:
As a safety precaution, disconnect all power to the projector and connecting devices before making
connections.
– 5 –
IN134UST/IN136UST User’s Manual
2
0
1
12221
1
Bottom view
47.
135.51
ITEM LABEL DESCRIPTION SEE PAGE
1.
2.
Note:
When installing, ensure that you use only UL Listed ceiling mounts.
For ceiling installations, use approved mounting hardware and M4 screws with a maximum screw
depth of 12 mm (0.47 inch).
The construction of the ceiling mount must be of a suitable shape and strength. The ceiling mount
load capacity must exceed the weight of the installed equipment, and as an additional precaution
be capable of withstanding three times the weight of the equipment (not less than 5.15 kg) over a
period of 60 seconds.
Tilt adjustor Rotate adjuster lever to adjust angle position
Ceiling support holes
Contact your dealer for information on mounting the projector on a
ceiling
14
— 6 —
Remote Control Parts
IN134UST/IN136UST User’s Manual
12
15
14
3
4
13
12
11
10
89
Important:
1. Avoid using the projector with bright fluorescent lighting turned on. Certain high-frequency
fluorescent lights can disrupt remote control operation.
2. Be sure nothing obstructs the path between the remote control and the projector. If the path
between the remote control and the projector is obstructed, you can bounce the signal off certain
reflective surfaces such as projector screens.
3. The buttons and keys on the projector have the same functions as the corresponding buttons on
the remote control. This user’s manual describes the functions based on the remote control.
5
6
7
– 7 –
IN134UST/IN136UST User’s Manual
ITEM LABEL DESCRIPTION SEE PAGE:
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
Up cursor Navigates and changes settings in the OSD
Enter Changes settings in the OSD
Power Turns the projector on or off
Right cursor Navigates and changes settings in the OSD
Volume + Increases volume
Volume - Decreases volume
Mute Mutes the built-in speaker
Freeze Freeze/unfreezes the on-screen picture
Source Selects the input device
Auto Auto adjustment for frequency, tracking, size, position (RGB only)
Keystone top
Keystone bottom
Corrects keystoning of the image (when it is wider on
top)
Corrects keystoning of the image (when it is wider on
the bottom)
16
11
15
15
13.
14.
15.
Down cursor Navigates and changes settings in the OSD
Left cursor Navigates and changes settings in the OSD
Menu Opens and exits the OSD
16
— 8 —
IN134UST/IN136UST User’s Manual
Remote Control Operating Range
The remote control uses infrared transmission to control the projector. It is not necessary to point the
remote directly at the projector. Provided you are not holding the remote perpendicular to the sides or
the rear of the projector, the remote will function well within a radius of about 7 meters (23 feet) and
15 degrees above or below the projector level. If the projector does not respond to the remote control,
move a little closer.
Projector and Remote Control Buttons
The projector can be operated using the remote control. All operations can be carried out with the
remote control.
– 9 –
IN134UST/IN136UST User’s Manual
Inserting the Remote Control Batteries
Remove the battery compartment
1.
cover by sliding the cover in the
direction of the arrow (A). Pull out the
cover (B).
Insert the battery with the positive
2.
side facing up.
SETUP AND OPERATION
Replace the cover.
3.
Caution:
1. Only use a 3V lithium battery (CR2025).
2. Dispose of used batteries according to local ordinance regulations.
3. Remove the batteries when not using the projector for prolonged periods.
Note:
Batteries are not normally included with InFocus projectors.
— 10 —
Starting and Shutting down the Projector
Connect the power cord to the
1.
projector. Connect the other end to
a wall outlet.
Turn on the connected devices.
2.
Ensure the POWER LED displays a
3.
solid green. Then press the POWER
button
projector.
The projector splash screen displays
and connected devices are
detected.
See Setting an Access Password
(Security Lock) on page 12 if
security lock is enabled.
of the remote to turn on the
IN134UST/IN136UST User’s Manual
If more than one input device is
4.
connected, press the SOURCE
button
scroll among the devices.
(Component is supported using a
RGB to COMPONENT ADAPTER.)
When the “Power Off? Press Power
5.
again” message appears, press the
POWER button. The projector turns
off.
of the remote and use ▲▼ to
VGA 1/VGA 2: Analog RGB
Component: DVD input YCbCr / YPbPr, or
HDTV input YPbPr via HD15 connector
Composite Video: Traditional composite video
HDMI: HDMI, DVI
S-Video: Super video (Y/C separated)
Caution:
Do not unplug the power cord until the POWER LED changes to solid green–indicating the
projector has cooled down.
– 11 –
IN134UST/IN136UST User’s Manual
Setting an Access Password (Security Lock)
You can use the four (arrow) buttons to set a password and prevent unauthorized use of the projector.
When enabled, the password must be entered after you power on the projector. (See Navigating the
OSD on page 16 and Setting the OSD Langua
Important:
Keep the password in a safe place. Without the password, you will not be able to use the projector.
If you lose the password, contact InFocus Support for information on clearing the password.
Press the MENU button to open the
1.
OSD menu.
ge on page 17 for help on using OSD menus.)
Press the ◄► buttons to move to the
2.
Installation I menu.
Press the ▲▼ buttons to select
3.
Advanced.
— 12 —
Press the ▲▼ buttons to select
4.
Security Lock.
Press the ◄► buttons to enable or
5.
disable security lock function.
A password dialog box automatically
appears.
You can use the cursor buttons
6.
▲▼◄►
on IR remote control for password
entry. You can use any combination
including the same arrow five times,
but five characters must be used.
IN134UST/IN136UST User’s Manual
Press the cursor buttons in any order
to set the password. Push the MENU
button to exit the dialog box.
If the Security Lock is enabled, the
7.
user will be prompted to enter a
password when the projector's power
button is pressed.
Enter the password in the order you
set it at step 5. In case you forget the
password, please contact the service
center.
Service center will validate the owner
and help reset the password.
– 13 –
IN134UST/IN136UST User’s Manual
Adjusting the Projector Level
Take note of the following when setting up the projector:
The projector table or stand should be level and sturdy.
Position the projector so that it is perpendicular to the screen.
Ensure the cables are in a safe location. You could trip over them.
To adjust the angle of the picture, turn the tilt-adjuster right or left until the desired angle
has been achieved.
— 14 —
Adjusting the Focus and Keystone
Use the Image-focus
1.
control (on the projector
only) to sharpen the
projected image.
Use the KEYSTONE
2.
buttons the remote
control to correct
trapezoid image issues
(wider top or bottom).
IN134UST/IN136UST User’s Manual
The keystone control
3.
appears on the display.
Adjusting the Volume
Press the Volume +/-
1.
buttons on the remote
control.
The volume control
appears on the display.
Press the MUTE button
2.
to turn off the volume.
(This feature is available
only on the remote).
– 15 –
IN134UST/IN136UST User’s Manual
ON-SCREEN DISPLAY (OSD) MENU SETTINGS
OSD Menu Controls
The projector has an OSD that lets you make image adjustments and change various settings.
Navigating the OSD
4
6
1
2
1
4
2
3
6
5
5
1
1
2
3
You can use the remote control cursor button to navigate and make changes to the OSD.
1. To enter the OSD, press the
MENU button.
2. There are five menus. Press
the ◄► buttons to move
through the menus.
3. Press the ▲▼ buttons to move
up and down in a menu.
4. Press ◄► to change setting
values.
5. Press MENU to close the OSD
or leave a submenu.
Note:
Depending on the video source, not all items in the OSD are available. For example, the
Horizontal/Vertical Position items in the Computer menu can only be modified when connected
to a PC. Items that are not available cannot be accessed and are grayed out.
— 16 —
Setting the OSD Language
Set the OSD language to your preference before continuing.
1. Press the MENU button. Press the ◄► buttons to navigate to Installation I.
2. Press the ▲▼ buttons until Language is highlighted.
IN134UST/IN136UST User’s Manual
3. Press the ◄► buttons until the language you want is highlighted.
4. Press the MENU button twice to close the OSD.
– 17 –
IN134UST/IN136UST User’s Manual
OSD Menu Overview
Use the following illustration to quickly find a setting or determine the range for a setting.
— 18 —
OSD Sub-Menu Overview
IN134UST/IN136UST User’s Manual
Image / Advanced
Color Space
Color
Temperature
Color Manager
Image / Advanced / Color
Manager
Red
Green
Auto, RGB, YUV
Native , Warm ,
Normal , Cold
Hue
Saturation
Gain
Hue
Saturation
Gain
Hue
0 ~ 100
0 ~ 100
0 ~ 100
0 ~ 100
0 ~ 100
0 ~ 100
0 ~ 100
Video / Audio
Installation I /
Advanced
Security Lock
Wall Color
Presentation
Timer
Digital Zoom
Keypad Lock
Logo
Logo Capture
Volume
Mute
Audio Input
Installation II / Advanced /
OSD Menu Setting
0~8
Off , On
Mini, HDMI
Off , On
Off, Light Yellow, Pink, Light
Green, Blue, Blackboard
Installation II /
-10~10
Off , On
Advanced / 3D
Menu Position
Translucent Menu
Menu Display
Installation II / Advanced /
Peripheral Test
3D
3D Sync Invert
3D Format
Center, Down, Up, Left, Right
0%, 25%, 50%, 75%, 100%
10 ~ 20
Remote Control Test
Color Test
USB Test
Off, DLP-Link, IR
On, Off
Frame Sequential, Top/Bottom,
Side-By-Side, Frame Packing
(3D FramePacking HDMI source only)
Blue
Cyan
Magenta
Yellow
White
Saturation
Gain
Hue
Saturation
Gain
Hue
Saturation
Gain
Hue
Saturation
Gain
Red
Green
Blue
0 ~ 100
0 ~ 100
0 ~ 100
0 ~ 100
0 ~ 100
0 ~ 100
0 ~ 100
0 ~ 100
0 ~ 100
0 ~ 100
0 ~ 100
0 ~ 100
0 ~ 100
0 ~ 100
Installation I / Advanced /
Presentation Timer
Timer
Timer Period
Timer Reset
Installation II / Advanced
OSD Menu Setting
Peripheral Test
Lamp Hour Reset
Low Power Mode
3D
Network
Off , On
1~60
On, Off
Installation II /
Advanced / Network
Network State
DHCP
IP Address
Subnet Mask
Gateway
DNS
Apply
Installation II / Status
Connect, Disconnect
Off , On
0~255, 0~255, 0~255, 0~255
0~255, 0~255, 0~255, 0~255
0~255, 0~255, 0~255, 0~255
0~255, 0~255, 0~255, 0~255
Active Source
Video information
Lamp Hours(Normal, Bright)
– 19 –
Software version
IN134UST/IN136UST User’s Manual
Image Menu
Press the MENU button to open the OSD menu. Press the ◄► buttons to move to the Image Menu.
Press the ▲▼ buttons to move up and down in the Image menu. Press ◄► to change setting
values.
ITEM DESCRIPTION
Press the ◄► buttons to set the Display Mode.
Display Mode
Brilliant Color Press the ◄► buttons to adjust the Brilliant Color value.
Brightness Press the ◄► buttons to adjust the display brightness.
Contrast Press the ◄► buttons to adjust the display contrast.
Sharpness Press the ◄► buttons to adjust the display sharpness level.
Gamma Press the ◄► buttons to adjust the gamma correction of the display.
Advanced
Reset Press (Enter) / ► to reset all settings to default values.
Note: Display Mode must be set to "Detail" in order to access the other Image
menu items.
Press
21.
(Enter) / ► to enter the Advanced menu. See Advanced Feature on page
— 20 —
IN134UST/IN136UST User’s Manual
Advanced Features
Press the Menu button to open the OSD menu. Press ◄► to move to the Image menu. Press ▼▲
to move to the Advanced menu and then press Enter or ►. Press ▼▲ to move up and down in the
Advanced menu.
ITEM DESCRIPTION
Color Space
Color Temperature
Color Manager
Press the
(Range: Auto – RGB – YUV )
Press the
(Range: Native – Warm – Normal – Cold )
Press
(Range: Red – Green – Blue – Cyan-Magenta – Yellow – White).
See page 22 for more information on Color Manager.
◄► buttons to adjust the color space.
◄► buttons to adjust the color temperature.
(Enter) / ► to enter the color manager menu.
– 21 –
IN134UST/IN136UST User’s Manual
Color Manager
Press (Enter) / ► to enter the Color Manager sub menu.
ITEM DESCRIPTION
Red
Green
Blue
Cyan
Magenta
Yellow
White
Select to enter the Red Color Manager.
Press the ◄► buttons to adjust the Hue, Saturation, and Gain.
Select to enter the Green Color Manager.
Press the ◄► buttons to adjust the Hue, Saturation, and Gain.
Select to enter the Blue Color Manager.
Press the ◄► buttons to adjust the Hue, Saturation, and Gain.
Select to enter the Cyan Color Manager.
Press the ◄► buttons to adjust the Hue, Saturation, and Gain.
Select to enter the Magenta Color Manager.
Press the ◄► buttons to adjust the Hue, Saturation, and Gain.
Select to enter the Yellow Color Manager.
Press the◄► buttons to adjust the Hue, Saturation, and Gain.
Select to enter the White Color Manager.
Press the ◄► buttons to adjust the Red, Green, and Blue.
— 22 —
IN134UST/IN136UST User’s Manual
Computer Menu
Press the MENU button to open the OSD menu. Press the ◄► buttons to move to the Computer
menu. Press the ▲▼ buttons to move up and down in the computer menu. Press ◄► to change
setting values.
ITEM DESCRIPTION
Horizontal Position Press the ◄► buttons to adjust the display position to left or right.
Vertical Position Press the ◄► buttons to adjust the display position to up or down.
Frequency Press the ◄► buttons to adjust the A/D sampling clock.
Tracking Press the ◄► buttons to adjust the A/D sampling dot.
Auto Image
Press
position.
(Enter) / ► to automatically adjustment for phase, tracking, size and
– 23 –
IN134UST/IN136UST User’s Manual
Video Menu
Press the MENU button to open the OSD menu. Press the ◄► buttons to move to the Video menu.
Press the ▲▼ buttons to move up and down in the Video menu. Press ◄► to change setting values.
Note:
Available settings vary depending on the input source. Others will appear grayed out.
ITEM DESCRIPTION
Video AGC
Video Saturation Press the ◄► buttons to adjust the video saturation.
Video Tint Press the ◄► buttons to adjust the video tint/hue.
Film Mode Press the ◄► buttons to select a different film mode.
Video Overscan Press the ◄► buttons to enable or disable video over scan.
Closed Captioning Press the ◄► buttons to enable or disable closed captioning.
Reset Press (Enter) / ► to reset all settings to default values.
Audio Press (Enter) / ► to o enter the Audio menu. See Audio on page 25.
Note:
Video jagging may occur when playing interlace video. To overcome this issue, open the
Video menu and adjust the Film Mode feature.
Press the ◄► buttons to enable or disable the Automatic Gain Control for video
source.
— 24 —
IN134UST/IN136UST User’s Manual
Audio
Press (Enter) / ► to enter the Audio sub menu.
ITEM DESCRIPTION
Volume Press the ◄► buttons to adjust the audio volume.
Mute Press the ◄► buttons to turn on or off the speaker.
Audio Input Press the ◄► buttons to select audio input.
– 25 –
IN134UST/IN136UST User’s Manual
Installation I Menu
Press the MENU button to open the OSD menu. Press the ◄► buttons to move to the Installation I
menu. Press the ▲▼ buttons to move up and down in the Installation I menu. Press ◄► to change
setting values.
ITEM DESCRIPTION
Language Press the ◄► buttons to change the OSD language.
Blank Screen Press the ◄► buttons to select a different blank screen color.
Projection
Aspect Ratio
Keystone Press the ◄► buttons to adjust the display keystone.
Advanced
Reset Press (Enter) / ► to reset all settings to default values (except Language).
Press the ◄► buttons to choose between different projection methods
(Ceiling, Rear, etc.).
Press the ◄► buttons to adjust the video aspect ratio.
Note: This feature is unavailable when WhiteBoard is being used.
Press
page 27.
(Enter) / ► to access the Advanced menu. See Advanced Features on
— 26 —
IN134UST/IN136UST User’s Manual
Advanced Features
Press the Menu button to open the OSD menu. Press ◄► to move to the Installation I menu. Press
▲▼ to move to the Advanced menu and then press Enter or ►. Press ▲▼ to move up and down in
the Advanced menu. Press ◄► to change setting values.
ITEM DESCRIPTION
Security Lock Press the ◄► buttons to enable or disable the security lock function.
Wall Color
Presentation Timer
Digital Zoom Press the ◄► buttons to adjust the Digital Zoom menu.
Keypad Lock Press the ◄► buttons to enter and enable or disable keys can be work on keypad.
Logo Press the ◄► buttons to enter and select logo.
Logo Capture Press (Enter) / ► to capture screen pattern to Logo.
Press the ◄► buttons to enable or disable the wall color function.
(Off/ Light Yellow/ Pink/ Light Green/ Blue/ Blackboard)
Press
below.
(Enter) / ► to go to the Presentation Timer Menu. See Presentation Timer
– 27 –
IN134UST/IN136UST User’s Manual
Presentation Timer
The Presentation Timer function can indicate the presentation time on the screen to help you achieve
better time management while giving a presentation.
ITEM DESCRIPTION
Timer Press the ◄► buttons to enable or disable the presentation timer.
Timer Period Press the ◄► buttons to select the timer period (1 ~ 60 minutes)
Timer Reset Press (Enter) / ► to reset the timer settings.
— 28 —
IN134UST/IN136UST User’s Manual
Installation II Menu
Press the MENU button to open the OSD menu. Press the ◄► buttons to move to the Installation II
menu. Press the ▲▼ buttons to move up and down in the Installation II menu.
ITEM DESCRIPTION
Auto Source Press the ◄► buttons to enable or disable automatic source detection.
Auto Power Off
(min.)
Auto Power On
Fan Speed
Lamp Mode
Advanced
Factory Reset Press (Enter) / ► to reset all items to factory preset values.
Status
Press the ◄► buttons to enable or disable automatic shutdown of lamp when there is
no signal.
Press the ◄► buttons to enable or disable automatic power On when AC power is
supplied.
Press the ◄► buttons to toggle between Normal and High fan speeds.
Note: It is recommended that the Fan Speed be set to high speed when the altitude of
the environment is higher than 1500m (4021 ft).
Press the ◄► buttons to select the lamp mode for higher brightness or lower
brightness to save lamp life.
Press
30.
Press
Status.
(Enter) / ► to enter the Advanced menu. See Advanced Feature on page
(Enter) / ► to enter the Status menu. See page 38 for more information on
– 29 –
IN134UST/IN136UST User’s Manual
Advanced Features
Press the Menu button to open the OSD menu. Press ◄► to move to the Installation II menu.
Press ▲▼ to move to the Advanced menu and then press Enter or ►. Press ▲▼ to move up and
down in the Advanced menu. Press ◄► to change setting values.
ITEM DESCRIPTION
OSD Menu Setting
Peripheral Test
Lamp Hour Reset
Low Power Mode Press ◄► to turn Low Power Mode on or off.
3D
Network
Press
information on OSD Menu Setting.
Press
information on Peripheral Test.
After replacing the lamp, this item should be reset. See page 41 for more information
on Resetting the Lamp.
Press
settings.
Press
Network settings.
Note:
To enjoy the 3D function, first enable the Play Movie in 3D setting found in your DVD
device under the 3D Disc Menu.
(Enter) / ► to enter the OSD setting menu. See page 31 for more
(Enter) / ► to enter the Peripheral Test menu. See page 31 for more
(Enter) / ► to enter the 3D menu. See page 33 for more information on 3D
(Enter) / ► to enter the Network menu. See page 34 for more information on
— 30 —
IN134UST/IN136UST User’s Manual
OSD Menu Setting
ITEM DESCRIPTION
Menu Position Press the ◄► buttons to select a different OSD location.
Translucent Menu Press the ◄► buttons to select the OSD background translucent level.
Menu Display Press the ◄► buttons to select the OSD timeout delay.
Peripheral Test
ITEM DESCRIPTION
Remote Control
Test
Color Test
Press
Press
testing purposes.
(Enter) / ► to test the IR remote controller for diagnostic purposes.
(Enter) / ► to select different color test patterns. Used for calibration and
USB Test Press (Enter) / ► to test the USB connection with the connected PC.
– 31 –
IN134UST/IN136UST User’s Manual
Lamp Hour Reset
Please refer to Resetting the Lamp on page 41 to reset the lamp hour counter.
— 32 —
IN134UST/IN136UST User’s Manual
3D
ITEM DESCRIPTION
3D Press the ◄► buttons to select Off, DLP-Link or IR.
3D Sync Invert Press the ◄► buttons to turn 3D Sync Invert On or Off.
3D Format Press the ◄► buttons to enable or disable 3D Format.
Note:
1. By default, if no 3D source is detected, the 3D OSD menu items will not be available.
2. When the projector is connected to an appropriate 3D source, the 3D OSD menu items are available
for selection.
3. Use 3D glasses to view a 3D image.
4. You need 3D content from a 3D DVD or 3D media file.
5. You need to enable the 3D source (some 3D DVD content may have a 3D on-off selection feature).
6. You need DLP link 3D or IR 3D shutter glasses. With IR 3D shutter glasses, you need to install a
driver on your PC and connect a USB emitter.
7. The 3D mode of the OSD needs to match the type of glasses (DLP link or IR 3D).
8. Power on the glasses. Glasses normally have a power on -off switch.
Each type of glasses has their own configuration instructions. Please follow the configuration
instructions that come with your glasses to finish the setup process.
– 33 –
IN134UST/IN136UST User’s Manual
Network
ITEM DESCRIPTION
Network State Displays the network connection status.
Press ◄► to turn DHCP On or Off.
DHCP
Note: If you select DHCP Off, complete the IP Address, Subnet Mask, Gateway, and
DNS fields.
IP Address Enter a valid IP address if DHCP is turned off.
Subnet Mask Enter a valid Subnet Mask if DHCP is turned off.
Gateway Enter a valid Gateway address if DHCP is turned off.
DNS Enter a valid DNS name if DHCP is turned off.
Apply Press (Enter) / ► to confirm settings.
— 34 —
IN134UST/IN136UST User’s Manual
For simplicity and ease of operation, the projector provides diverse networking and remote management
features.
The LAN/RJ45 feature allows the projector to be connected to a network and remotely managed. Available
remote management controls include: Power On/Off, Video-Source, Brightness and Contrast settings,
Sound-Mute, etc.
Enter the Projector IP address shown in the SETUP >> Basic >> Lan Control Setting >> Network State menu. Note: DHCP must be on. The LAN/RJ45 Web Control window displays as
follows:
Preparing Email Alerts
1. Make sure that user can access the homepage of LAN RJ45 function by web browser (for example, Microsoft Internet Explorer v6.01/v8.0).
– 35 –
IN134UST/IN136UST User’s Manual
2. From the Homepage of LAN/RJ45, click Alert Mail Settings.
3. By default, the input boxes in Alert Mail Settings are blank.
4. To setup email alerts, input the following:
The SMTP field is the mail server for sending out email (SMTP protocol).
This is a required field.
The To field is the recipient’s email address (for example, the projector administrator). This
is a required field.
The Cc field sends a carbon copy of the alert to the specified email address.
This is an optional field (for example, the projector administrator’s assistant).
The From field is the sender’s email address (for example, the projector administrator).
This is a required field.
Select the alert conditions by checking the desired boxes.
— 36 —
IN134UST/IN136UST User’s Manual
Note: Fill in all fields as specified. Select the desired alert condition and click Submit to
conduct an Email Alert Test. A successful test alerts the designated email accounts. To
create an email alert, you must select alert conditions and enter a correct email address.
Group and Name identify the alerting projector and are located at the button of the alert mail as shown
below:
– 37 –
IN134UST/IN136UST User’s Manual
Factory Reset
Press the ▲▼ buttons to move up and down in the Installation II menu. Select the Factory Reset
sub menu and press
Language and Security Lock).
(Enter) / ► to reset all the menu items to the factory default values (except
Status
Press the ▲▼ buttons to move up and down in the Installation II menu. Select the
Installation II sub menu and press
ITEM DESCRIPTION
Active Source Displays the current active source type.
Video Information
Displays resolution/video information for the RGB source and color standard for the
Video source.
(Enter) / ► to enter the Status sub menu.
Lamp Hours
(Normal, Bright)
Software version Displays the Software version of the projector.
Displays the number of normal and bright hours that the lamp has been used.
— 38 —
IN134UST/IN136UST User’s Manual
MAINTENANCE AND SECURITY
Replacing the Projection Lamp
The projection lamp should be replaced when it burns out. It should only be replaced with a certified
replacement part, which you can order from your local dealer.
Important:
a. The projection lamp used in this product contains a small amount of mercury.
b. Do not dispose this product with general household waste.
c. Disposal of this product must be carried out in accordance with the regulations of your local
authority.
Warning:
Be sure to turn off and unplug the projector at least 30 minutes before replacing the lamp. Failure to
do so could result in a severe burn.
Caution:
In rare cases the lamp bulb may burn out during normal operation and cause glass dust or shards
to be discharged outward from the rear exhaust vent.
Do not inhale or do not touch glass dust or shards. Doing so could result in injury.
Always keep your face away from the exhaust vent so that you do not suffer from the gas and
broken shards of the lamp.
When removing the lamp from a ceiling-mounted projector, make sure that no one is under the
projector. Glass fragments could fall if the lamp has been burned out.
！
IF A LAMP EXPLODES
If a lamp explodes, the gas and broken shards may scatter inside the projector and they may come
out of the exhaust vent. The gas contains toxic mercury.
Open windows and doors for ventilation.
If you inhale the gas or the shards of the broken lamp enter your eyes or mouth, consult a doctor
immediately.
Remove the single screw
1.
on the lamp compartment
cover.
– 39 –
IN134UST/IN136UST User’s Manual
Remove the lamp
2.
compartment cover.
Loosen the two screws
3.
from the lamp module.
Lift the module handle up.
4.
Pull firmly on the module
5.
handle to remove the lamp
module.
Reverse steps 1 to 5 to
6.
install the new lamp
module.
While installing, align the
lamp module with the
connector and ensure it is
level to avoid damage.
Note: The lamp module
must sit securely in place
and the lamp connector
must be connected
properly before tightening
the screws.
— 40 —
IN134UST/IN136UST User’s Manual
Resetting the Lamp
After replacing the lamp, you should reset the lamp hour counter to zero. Refer to the following:
Press the MENU button to open
1.
the OSD menu.
Press the ◄► buttons to move to
2.
the Installation II menu. Press
the cursor button to move down to
Advanced.
Press the ▼▲ buttons to move
3.
down to Lamp Hour Reset.
Press the ► or Enter button.
4.
A message screen appears.
Press the arrow keys in the
5.
following order to reset the lamp
hours: ▼▲◄►
Press the MENU button to return
6.
to Installation II.
– 41 –
IN134UST/IN136UST User’s Manual
Cleaning the Projector
Cleaning the projector to remove dust and grime will help ensure trouble-free operation.
Cleaning the Projector Mirror:
1. Remove dust the lens with a lens blower (available from most camera shops) to prevent
scratching the mirror when it is wiped.
2. Gently wipe the lens with a lens cleaning cloth, or alternately, use a lens cleaning tissue in
conjunction with a small amount of lens cleaning fluid.
Cautions:
1. Always turn the projector off and allow to cool for at least 30 minutes prior to cleaning.
2. Never touch the projector mirror or lens directly by hand.
3. Only use lens cleaning tissues. Rough cloth can damage the lens and mirror.
4. Do not use abrasive cleaners, solvents or other harsh chemical cleaners.
— 42 —
IN134UST/IN136UST User’s Manual
Cleaning the Case
Follow these instructions to clean the projector case:
1. Wipe off dust with a clean dampened cloth.
2. Moisten the cloth with warm water and mild detergent (such as used to wash dishes), and then
wipe the case.
3. Rinse all detergent from the cloth and wipe the projector again.
Caution:
To prevent discoloration or fading of the case, do not use abrasive alcohol-based cleaners.
Warning:
1. Be sure to turn off and unplug the projector at least 30 minutes before cleaning. Failure to do so
could result in a severe burn.
2. Use only a dampened cloth when cleaning. Do not allow water to enter the ventilation openings
on the projector.
3. If a little water gets into the projector interior while cleaning, leave it unplugged in a wellventilated room for several hours before using.
4. If a lot of water gets into the projector interior when cleaning, have the projector serviced.
– 43 –
IN134UST/IN136UST User’s Manual
Using the Physical Lock
Using the Kensington® Lock
If you are concerned about security, attach the projector to a permanent object with the Kensington
slot and a security cable.
Note:
Contact your vendor for details on purchasing a suitable Kensington security cable.
The security lock corresponds to Kensington’s MicroSaver Security System. If you have any
comments, contact: Kensington, 2853 Campus Drive, San Mateo, CA 94403, U.S.A. Tel: 800-5354242, http://www.Kensington.com.
Using the Security Bar
In addition to the password protection function and the Kensington lock, the Security Bar helps
protect the projector from unauthorized removal.
See the following picture.
— 44 —
IN134UST/IN136UST User’s Manual
TROUBLESHOOTING
Common problems and solutions
These guidelines provide tips to deal with problems you may encounter while using the projector. If
the problem remains unsolved, contact your dealer for assistance.
Often after time spent troubleshooting, the problem is traced to something as simple as a loose
connection. Check the following before proceeding to the problem-specific solutions.
Use some other electrical device to confirm that the electrical outlet is working.
Ensure the projector is turned on.
Ensure all connections are securely attached.
Ensure the attached device is turned on.
Ensure a connected PC is not in standby mode.
Ensure a connected notebook computer is configured for an external display.
(This is usually done by pressing a Fn-key combination on the notebook).
Tips for Troubleshooting
In each problem-specific section, try the steps in the order suggested. This may help you to solve the
problem more quickly.
Try to pin point the problem and thus avoid replacing non-defective parts.
For example, if you replace batteries and the problem remains, put the original batteries back and go
to the next step.
Keep a record of the steps you take when troubleshooting: The information may be useful when
calling for technical support or for passing on to service personnel.
– 45 –
IN134UST/IN136UST User’s Manual
LED Error Messages
ERROR CODE MESSAGES
Power On ON OFF OFF
Power Off ON OFF OFF
Cooling Flashing OFF OFF
Over Temperature OFF OFF ON
Thermal Break Sensor error 4 blinks OFF OFF
Lamp error OFF ON OFF
Fan 1 6 blinks 1 blink OFF
Fan 2 6 blinks 2 blinks OFF
Fan 3 6 blinks 3 blinks OFF
Fan 4 6 blinks 4 blinks OFF
Lamp Door Open 7 blinks OFF OFF
DMD error 8 blinks OFF OFF
Color wheel error 9 blinks OFF OFF
In the event of an error, please disconnect the AC power cord and wait for one (1) minute before
restarting the projector. If the POWER or LAMP LEDs continue to blink or the TEMP LED is lit,
contact your service center.
POWER LED
GREEN
LAMP LED
AMBER
TEMP LED
RED
Image Problems
Problem: No image appears on the screen
1. Verify the settings on your notebook or desktop PC.
2. Turn off all equipment and power up again in the correct order.
Problem: The image is blurred
1. Press the Auto button on the remote control or projector.
2. Ensure the projector-to-screen distance is within the specified range.
3. Check that the projector lens is clean.
Problem: The image is wider at the top or bottom (trapezoid effect)
1. Position the projector so it is as perpendicular to the screen as possible.
2. Use the Keystone button on the remote control or projector to correct the problem.
Problem: The image is reversed
Check the Projection setting on the Installation I menu of the OSD.
Problem: The image is streaked
1. Set the Frequency and Tracking settings on the Computer menu of the OSD to the
default settings.
2. To ensure the problem is not caused by a connected PC’s video card, connect to another
computer.
Problem: The image is flat with no contrast
Adjust the Contrast setting on the Image menu of the OSD.
— 46 —
Problem: The color of the projected image does not match the source image.
Adjust the Color Temperature and Gamma settings on the Image menu of the OSD.
Lamp Problems
Problem: There is no light from the projector
1. Check that the power cable is securely connected.
2. Ensure the power source is good by testing with another electrical device.
3. Restart the projector in the correct order and check that the Power LED is on.
4. If you have replaced the lamp recently, try resetting the lamp connections.
5. Replace the lamp module.
6. Put the old lamp back in the projector and have the projector serviced.
Problem: The lamp goes off
1. Power surges can cause the lamp to turn off. Re-plug power cord. When the POWER LED
is on, press the power button.
2. Replace the lamp module.
3. Put the old lamp back in the projector and have the projector serviced.
IN134UST/IN136UST User’s Manual
Remote Control Problems
Problem: The projector does not respond to the remote control
1. Direct the remote control towards remote sensor on the projector.
2. Ensure the path between remote and sensor is not obstructed.
3. Turn off any fluorescent lights in the room.
4. Check the battery polarity.
5. Replace the batteries.
6. Turn off other Infrared-enabled devices in the vicinity.
7. Have the remote control serviced.
Having the Projector Serviced
If you are unable to solve the problem, you should have the projector serviced. Pack the projector in
the original carton. Include a description of the problem and a checklist of the steps you took when
trying to fix the problem: The information may be useful to service personnel. To arrange for service,
contact InFocus Technical Support at http://www.infocus.com/support
.
– 47 –
IN134UST/IN136UST User’s Manual
HDMI Q & A
Q. What is the difference between a “Standard” HDMI cable and a “High-Speed” HDMI
cable?
1. Recently, HDMI Licensing, LLC announced that cables would be tested as Standard or
High-Speed cables.
2. ˙Standard (or “category 1”) HDMI cables have been tested to perform at speeds of 75Mhz
or up to 2.25Gbps, which is the equivalent of a 720p/1080i signal.
3. ˙High Speed (or “category 2”) HDMI cables have been tested to perform at speeds of
340Mhz or up to 10.2Gbps, which is the highest bandwidth currently available over an
HDMI cable and can successfully handle 1080p signals including those at increased color
depths and/or increased refresh rates from the Source. High-Speed cables are also able to
accommodate higher resolution displays, such as WQXGA cinema monitors (resolution of
2560 x 1600).
Q. How do I run HDMI cables longer than 10 meters?
4. There are many HDMI Adopters working on HDMI solutions that extend a cable’s
effective distance from the typical 10 meter range to much longer lengths. These companies
manufacture a variety of solutions that include active cables (active electronics built into
cables that boost and extend the cable’s signal), repeaters, amplifiers as well as CAT5/6 and
fiber solutions.
Q. How can I tell if a cable is an HDMI certified cable?
5. All HDMI products are required to be certified by the manufacturer as part of the HDMI
Compliance Test Specification. However, there may be instances where cables bearing the
HDMI logo are available but have not been properly tested. HDMI Licensing, LLC actively
investigates these instances to ensure that the HDMI trademark is properly used in the
market. We recommend that consumers buy their cables from a reputable source and a
company that is trusted.
For more detail information check http://www.hdmi.org/lear
ningcenter/faq.aspx#49
— 48 —
IN134UST/IN136UST User’s Manual
SPECIFICATIONS
Specifications
Model IN134UST IN136UST
Display type
Native Resolution
Projection distance
Projection screen size
(diagonal)
Projection lens
Throw ratio
Vertical keystone correction
Projection methods
Data compatibility
SDTV/EDTV/ HDTV
Video compatibility
H-Sync
V-Sync
Safety certification
Operation temperature
DMD 0.55" XGA DMD 0.65" WXGA
XGA 1024 x 768 Native WXGA 1280 x 800 Native
371~417mm 336~421mm
4:3 (68"~85”) 16:10 (80”~100”)
Manual Focus
0.437 0.35
+/- 40 degrees
Front, Rear, Desktop/Ceiling (Rear, Front)
VGA, SVGA, XGA, SXGA, UXGA, Mac
480i, 576i, 480p, 576p, 720p, 1080i, 1080p
NTSC/NTSC 4.43, PAL (B/G/H/I/M/N/60), SECAM
15, 31 – 91.4 kHz
24-30 Hz, 47-120 Hz
FCC, UL/cUL, CE, CCC, KC, UL-S, TUV/GS, ECA-PCT, SASO, SABS,
PSB, CECP, NOM, C-Tick
5° ~ 40°C
Dimensions (W x D x H)
AC Input
Power consumption
Lamp
Audio speaker
Input Terminals
Output Terminals
Control Terminals
287.7 mm x 374.5 mm x 160 mm
AC Universal 100 ~ 240V
260W(Eco), <0.5 watt(Stand By) / 290W(Standard), <0.5 watt(Stand By)
230W
10W x2
VGA x 2
Mini jack x 1 (Audio In)
Composite Video x 1
HDMI x 1
S-Video x 1
MIC x 1
VGA x 1 (Loop Thru only for VGA IN-1)
Mini jack x 1 (Audio out)
RS-232C
RJ45
USB (type B)
3D sync
Security
Kensington lock
– 49 –
IN134UST/IN136UST User’s Manual
Projection Distance vs. Projection Size
Projection Distance and Size Table
Diagonal 80" 87" 97" 100"
Distance 282.3+/-20mm 336.3+/-20mm 421.4+/-20mm 445.8+/-20mm
Image Width 1723mm 1869mm 2088mm 2154mm
Image Height 1077mm 1168mm 1305mm 1346mm
H 280+/-50mm 298.5+/-50mm 325.5+/-50mm 336.9+/-50mm
Diagonal 68" 78" 82" 85"
Distance 282.3+/-20mm 371.4+/-20mm 417.35+/-20mm 445.8+/-20mm
Image Width 1382mm 1566mm 1670mm 1727mm
IN136UST
WXGA
16:10
IN134UST
XGA
4:3
Image Height 1036mm 1175mm 1240mm 1295mm
H 301.3+/-50mm 334.8+/-50mm 350.8+/-50mm 363.7+/-50mm
— 50 —
IN134UST/IN136UST User’s Manual
Timing Mode Table
The projector can display several resolutions. The following table outlines the resolutions that can be
displayed by the projector.
SIGNAL RESOLUTION
NTSC
PAL/SECAM
VESA
－
－
720 X 400 31.5 70.1
640 X 480 31.5 60.0
640 X 480 37.9 72.8
640 X 480 37.5 75.0
800 X 600 35.2 56.3
* 800 X 600 37.9 60.3
800 X 600 46.9 75.0
800 X 600 48.1 72.2
800 X 600 53.7 85.1
** 800 X 600 76.3 120.0
H-SYNC
(KHZ)
15.734 60.0 ○
15.625 50.0 ○
V-SYNC
(HZ)
COMPOSITE
S_VIDEO
COMPONENT
－ － －
－ － －
－ － ○ ○
－ － ○ ○
－ － ○ ○
－ － ○ ○
－ － ○ ○
－ － ○ ○
－ － ○ ○
－ － ○ ○
－ － ○ ○
－ － ○ ○
RGB
(ANALOG)
DVI/
HDMI
(DIGITAL)
* 1024 X 768 48.4 60.0
1024 X 768 56.5 70.1
1024 X 768 60.0 75.0
1024 X 768 68.7 85.0
** 1024 X 768 97.6 120.0
1024 X 768 99.0 120.0
1152 X 864 67.5 75.0
* 1280 X 720 45.0 60.0
** 1280 X 720 90.0 120.0
1280 X 768 47.4 60.0
* 1280 X 768 47.8 59.9
* 1280 X 800 49.7 59.8
1280 X 800 62.8 74.9
1280 X 800 71.6 84.9
－ － ○ ○
－ － ○ ○
－ － ○ ○
－ － ○ ○
－ － ○ ○
－ － ○ ○
－ － ○ ○
－ － ○ ○
－ － ○ ○
－ － ○ ○
－ － ○ ○
－ － ○ ○
－ － ○ ○
－ － ○ ○
**
1280 X 800 101.6 119.9
– 51 –
－ － ○ ○
IN134UST/IN136UST User’s Manual
SIGNAL RESOLUTION
*** 1280 X 1024 64.0 60.0
1280 X 1024 80.0 75.0
1280 X 1024 91.1 85.0
*** 1280 X 960 60.0 60.0
1280 X 960 85.9 85.0
*** 1360 X 768 47.7 60.0
*** 1400 X 1050 65.3 60.0
1440 X 900 55.5 59.9
*** 1440 X 900 55.9 59.9
1440 X 900 70.6 75.0
1600 X1200 75.0 60
1680 X 1050 64.7 59.9
H-SYNC
(KHZ)
V-SYNC
(HZ)
COMPOSITE
S_VIDEO
－ － ○ ○
－ － ○ ○
－ － ○ ○
－ － ○ ○
－ － ○ ○
－ － ○ ○
－ － ○ ○
－ － ○ ○
－ － ○ ○
－ － ○ ○
－ － ○ ○
－ － ○ ○
COMPONENT
RGB
(ANALOG)
DVI/
HDMI
(DIGITAL)
Apple
Macintosh
SDTV
EDTV
HDTV
1680 X 1050 65.3 60.0
1920 X 1200RB 74.0 60.0
1920 X 1080 67.5 60.0
640 X 480 35.0 66.7
832 X 624 49.7 74.5
1024 X 768 60.2 74.9
1152 X 870 68.7 75.1
480I 15.734 60.0
576I 15.625 50.0
576P 31.3 50.0
480P 31.5 60.0
720P 37.5 50.0
720P 45.0 60.0
1080I 33.8 60.0
－ － ○ ○
－ － ○ ○
－ － ○ ○
－ － ○ ○
－ － ○ ○
－ － ○ ○
－ － ○ ○
－
－
－
－
－
－
－
○
○
○
○
○
○
○
－ ○
－ ○
－ ○
－ ○
－ ○
－ ○
－ ○
1080I 28.1 50.0
1080P 27.0 24.0
1080P 28.0 25.0
1080P 33.7 30.0
— 52 —
－
－
－
－
○
○
○
○
－ ○
－ ○
－ ○
－ ○
IN134UST/IN136UST User’s Manual
SIGNAL RESOLUTION
1080P 56.3 50.0
1080P 67.5 60.0
O: Frequency supported
—: Frequency not supported
3D note：
“” means the timing can support non-3D and 3D signals with Frame Sequential and TopBottom format.
“” means the timing can support non-3D and 3D signals with Frame Sequential format.
“” means the timing can support non-3D and 3D signals with Top-Bottom format.
Depending on the EDID files and display cards of the 3D source, it is possible the user will not be
able to choose any of the above 3D timings.
The projector's native resolution is 1280 x 800. If the resolution of the source is different than
1280 x 800, the projector may display uneven sized text and lines.
H-SYNC
(KHZ)
V-SYNC
(HZ)
COMPOSITE
S_VIDEO
－
－
COMPONENT
○
○
RGB
(ANALOG)
－ ○
－ ○
DVI/
HDMI
(DIGITAL)
Signal types highlighted yellow can only be displayed in 4:3 mode.
Signal types highlighted in blue may display small amounts of noise. This is because the Video
Sync mode cannot adjust these signals automatically.
The DVD player monitors HDTV time. VG828 is secondary to the DVD player.
RB=Reduced Blacking
– 53 –
IN134UST/IN136UST User’s Manual
Projector Dimensions
374.51
160.0
122.58
— 54 —
IN134UST/IN136UST User’s Manual
REGULATORY COMPLIANCE
FCC Warning
This equipment has been tested and found to comply with the limits for a Class B digital device
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his/her own expense.
Changes or modifications not expressly approved by the parties responsible for compliance could
void the user’s authority to operate the equipment.
Canada
This class B digital apparatus complies with Canadian ICES-003.
Safety Certifications
FCC, UL/cUL, CE, CCC, KC, UL-S, TUV/GS, ECA-PCT, SASO, SABS, PSB, CECP, NOM, C-Tick
– 55 –
IN134UST/IN136UST User’s Manual
APPENDIX I
Communication
The following table describes the serial communication configuration that should be used when
interfacing to the CLI via the serial port.
Windows HyperTerminal or Procomm are two tools that can be used to send CLI commands across
the serial port.
Setting Value
Bits per second 19200
Data bits 8
Parity None
Stop bits 1
Flow control None
Emulation VT100
No Function Command RW Min Max Default Step Parameter
AC Power On
1
(Auto power on)
3 Aspect Ratio ARZ RW 0 4 0 1
4 Auto Image AIM W n/a 1 1 1 1: Enable
5 Auto Off Time AOT RW 0 36 6 1
6 Auto Source ASC RW 0 1 1 1 0: Disable; 1: Enable
7 Blank Screen BLK RW 0 1 0 1 0: Disable; 1: Enable
9 Brightness BRT RW 0 100 50 1 Display Mode=User only
Ceiling
11
(Projection mode)
Closed Captions: Non-
12
Muted
14 Color CLR RW 0 100 50 1
15 Color Space CSM RW 0 2 0 1
APO RW 0 1 0 1
CEL RW 0 3 0 1
CLC RW 0 1 0 1
0: Disable; 1: Enable
0:Fill
1:4:3
2:16:9
3:Letterbox
4:Native
0: Never
1: 5min
2,3…5,
6: 30min (Default 6*5=30)
7,8…35,
36: 180min
0:Front
1:Rear
2:Ceiling
3:Ceiling+Rear
Off
On (CC1)
Video SVideo only = saturation
Display Mode=User only
0:Auto
1:RGB
2:YUV
— 56 —
IN134UST/IN136UST User’s Manual
No Function Command RW Min Max Default Step Parameter
Display Mode=User only
16 Color Temp TMP RW 0 3
17 Contrast CON RW 0 100 50 1 Display Mode=User only
18 Current Source SRC RW 0 4 0 1
21 Digital Zoom DZM RW -10 10 0 5 -10~10
27 Error Condition ERR R n/a n/a n/a n/a
28 Factory Reset RST W n/a 1 1 1 1:Reset
32 Freeze Screen FRZ RW 0 1 0 1 0: Disable
34 Gamma GTB RW 0 4
40 Horz. Position HPS RW x x 0 1
Lamp Hours in High
45
Power (Normal) Mode
Lamp Hours in Low
46
Power (Eco) Mode
47 Lamp Life LIF R n/a 5000 230W lamp life 5000
Lamp Resets (Total
49
number)
62 Lamp Low Power IPM RW 0 1 0 1 1=Normal, 0=Bright
LMO R 0 9999
LME R 0 9999
LMR R 0 9999 0 1
Source
Specific
Source
Specific
0:Native
1
1:Warm
2:Normal
3:Cold
0:VGA1
1:VGA2
5:HDMI
12:Composite
13:S-Video
0:No error
1:Lamp not lit after 5 Attempts
3:Lamp went out unexpectedly
4:Fan failure
5:Overheating
8:DMD error
9:Color wheel
Display Mode=User only
0:PC
1:MAC
1
2:Video
3:Chart
4:B&W
RGB source only
(HPS?) to get range
Displays the numbers of
hours that the lamp has run
in High Power (Normal)
mode.
Displays the numbers of
hours that the lamp has run
in Low Power (Eco) mode.
– 57 –
IN134UST/IN136UST User’s Manual
No Function Command RW Min Max Default Step Parameter
0:English
1:French
2:German
3:Spanish
4: Simp Chinese
5: Trad Chinese
6: Italian
7: Norwegian
8: Swedish
9: Dutch
63 Language LAN RW 0 20 0 1
77 Menu MNU RW 0 1 0 1 0: Clear; 1: Display
79 Menu Navigation NAV W 0 5 n/a 1
81 Menu Transparency TOE RW 0 4 0 5
91 Mute MTE RW 0 1 0 1 0:disable; 1:enable
103 Overscan OVS RW 0 1 0 1 0:disable, 1:enable
104 Phase(Frequency) MSS RW 0 31 x 1 RGB source only
108 Power PWR RW 0 1 0 1
111 Presets PST RW 0 6
114 Projector Firmware Ver. FVS R string
Projector High Power
115
(Normal) Hours
116 Projector Info menu PRI R 1 1 Display Projector Info menu
LTO R 0 9999
source
Specific
10:Russian
11: Finnish
12: Korean
13: Arabic
14: Turkish
15: Japanese
16: Brazilian Portuguese
17: Vietnamese
18:Danish
19:Polish
20: Bahasa Indonesian
21: Persian
0:Menu Key
1:Up Key
2:Down Key
3:Select Key
4:Left Key
5:Right Key
0:0%
1:25%
2:50%
3:75%
4:100%
0:Turn Off
1:Turn On
0:Presentation
1:Bright
2:Game
1
3:Movie
4:TV
5:sRGB
6:User
LX136-445IF-DPXXX
LX176-445IF-DPXXX
Displays the numbers of
hours that the projector has
run in High Power (Normal)
mode over its life (including
all lamps).
— 58 —
IN134UST/IN136UST User’s Manual
No Function Command RW Min Max Default Step Parameter
Displays the numbers of
Projector Low Power
117
(Eco) Hours
118 Projector Model MDL R string IN134UST / IN136UST
119 Projector Resolution NRS R string XGA / WXGA
121 Projector Total Hours LMT R 0 9999 1
123 Reset Lamp Hours LRT RW 1 2 n/a 1
126 Search Screen DSU RW 0 4 0 1
130 Sharpness SHP RW 0 100 50 1
155 System State SYS R 0 18 0 1
158 Tint TNT RW 0 100 50 1
160 Tracking MTS RW -5 5 0 1
162 Vert. Keystone DKV RW -40 40 0 1
164 Vert. Position VPS RW x x 0 1
167 Volume VOL RW 0 8 4 1 0~8
LTE R 0 9999
hours that the projector has
run in Low Power (Eco)
mode over its life (including
all lamps).
Reset Lamp Hour(Status,
MFG:current)
0:Black
1:Red
2.Green
3.Blue
4.White
0: Standby
2: Start Up
12: Cooling
18: Error
RGB source only
-5~5
RGB source only
(VPS?) to get range
(VPS+)
(VPS-)
– 59 –
Loading...
