Infiniti Q60 Convertible Quick Reference Guide

2015 Infiniti Q60

Quick Reference Guide

Behind

steering

wheel

3 4 5 6

Behind

steering

wheel

8 9

11 12 13

Behind

steering wheel

INSTRUMENT BRIGHTNESS CONTROL*

TRIP COMPUTER SWITCHES

HEADLIGHT AND TURN SIGNAL CONTROL

LOW TIRE PRESSURE WARNING LIGHT

VEHICLE INFORMATION DISPLAY

WINDSHIELD WIPER AND WASHER SWITCH

TRIP A/B RESET BUTTON*

STEERING WHEEL SWITCHES FOR

AUDIO*/BLUETOOTH

CRUISE CONTROL

PUSH BUTTON IGNITION SWITCH

VEHICLE DYNAMIC CONTROL (VDC) OFF SWITCH*

Behind

steering

wheel

21 2122

TRUNK RELEASE SWITCH

REAR SONAR SYSTEM SWITCH*

TILT AND TELESCOPIC STEERING COLUMN*

INTELLIGENT KEY PORT

HOOD RELEASE*

CONTROL PANEL DISPLAY

AUDIO SYSTEM

AUTOMATIC CLIMATE CONTROLS

FRONT PASSENGER AIR BAG STATUS LIGHT*

CLIMATE CONTROLLED SEAT SWITCHES*

HARD TOP OPEN/CLOSE SWITCH

(CONVERTIBLE MODELS)

*See your Owner’s Manual for information.

new system features

NavTraffic and NavWeather (if so equipped) .........................2

essential information

Tire Pressure Monitoring System (TPMS) ............................3

Loose Fuel Cap .................................................3

Fuel-filler Door .................................................4

Automatic Power Windows .......................................4

Accessing the Front Cup Holders ..................................4

Clock Set/Adjustment ...........................................5

first drive features

INFINITI Intelligent Key System ...................................6

Trunk Lid Release...............................................7

Seat Adjustments...............................................7

Automatic Drive Positioner (if so equipped) .........................8

Seat Belt Guide (Convertible models) ..............................8

Passenger Rear Seat Entry/Exit....................................8

Outside Mirror Control Switch.....................................9

Starting/Stopping the Engine .....................................9

Headlight Control Switch........................................10

Windshield Wiper and Washer Switch .............................11

Automatic Climate Controls......................................11

FM/AM/SiriusXM® Satellite Radio with CD/DVD Player

(with Navigation System) (if so equipped)..........................13

USB (Universal Serial Bus) Connection Port/iPod® Interface ...........14

Conventional (Fixed Speed) Cruise Control .........................14

Intelligent Cruise Control (ICC) System (if so equipped) ..............15

Opening/Closing the Hard Top (Convertible models) .................16

system guide

Trip Computer.................................................17

Bluetooth® Hands-free Phone System .............................17

System Operating Tips........................................17

Bluetooth® System with Navigation (if so equipped) .................18

Bluetooth® System without Navigation (if so equipped) ..............20

Navigation System (if so equipped) ...............................21

DVD Player (if so equipped)......................................22

HomeLink® Universal Transceiver.................................23

Please see your Owner’s Manual for important safety information and system operation limitations.

• A cellular telephone should not be used for any purpose while driving so full attention may be given to vehicle operation.

• Always wear your seat belt.

• Supplemental air bags do not replace proper seat belt usage.

• Children 12 and under should always ride in the rear seat properly secured in child restraints or seat belts according to their age and weight.

• Do not drink and drive.

For more information, refer to the “Safety – Seats, seat belts and

supplemental restraint system (section 1)”, “Monitor, climate, audio, phone and voice recognition systems (section 4)” and “Starting and driving (section 5)” of your Owner’s Manual.

Additional information about your vehicle is also available in your Owner’s Manual, Navigation System Owner’s Manual and at www.InfinitiUSA.com.

To view detailed

instructional videos, go to

www.infinitiownersinfo.mobi/2015/q60

or snap this barcode with an appropriate barcode reader.

new system features

NavTraffic* and NavWeather* (if so equipped)

Your vehicle’s Navigation System is equipped with NavTraffic and NavWeather capabilities.

NavTraffic enables your vehicle’s Navigation System to display real-time traffic conditions, such as accidents or road construction, and may provide a detour to help avoid congestion.

NavWeather tracks nationwide weather information, provides real-time weather reports and automatically alerts you to severe weather conditions around the current vehicle location.

*These features, SiriusXM® Satellite Radio, NavTraffic and NavWeather require an active subscription. Multiple subscriptions may be necessary to activate the various features.

For more information, refer to the “Monitor, climate audio, phone and voice recognition systems (section 4)” of your Owner’s Manual.

essential information

Tire Pressure Monitoring System (TPMS)

A CHECK TIRE PRESSURE warning message will appear in the vehicle information display 1 and the low tire pressure warning light 2 will illuminate when one or more tires are low in pressure and air is needed.

• The tire pressures should be checked when the tires are cold. The tires are considered cold after the vehicle has been parked for 3 hours or more or driven less than 1 mi (1.6 km) at moderate speeds.

After tire pressures are adjusted, drive the vehicle at speeds above 16 MPH (25 km/h). The CHECK TIRE PRESSURE warning message and low tire pressure warning light will extinguish.

When the low tire pressure warning light flashes for 1 minute and then remains on, the TPMS is not functioning properly. Have the system checked by an INFINITI retailer.

Tire pressure rises and falls depending on the heat caused by the vehicle’s operation and the outside temperature. Low outside temperature can lower the temperature of the air inside the tire, which can cause a lower tire inflation pressure. This may cause the low tire pressure warning light to illuminate. If the warning light illuminates, check the tire pressure in your tires.

• Check the tire pressure (including the spare tire) often and always prior to long distance trips.

The Tire and Loading Information label contains valuable information. Please refer to “Technical and consumer information (section 9)”, in your Owner’s Manual for the location of the Tire and Loading Information label.

For more information, refer to the “Instruments and controls (section 2)”, the “Starting and driving (section 5)” and the“Maintenance and do-it-yourself (section 8)” of your Owner’s Manual.

Loose Fuel Cap

A LOOSE FUEL CAP warning message will appear in

the vehicle information display 1 when the fuel-filler cap is not tightened correctly.

To tighten, turn the cap clockwise until a single click

is heard.

The warning message will disappear when the vehicle detects the fuel-filler cap is properly tightened and the reset button 2 is pressed for about 1 second.

If the cap is not properly tightened, the Malfunction Indicator Light

For more information, refer to the “Instruments and controls (section 2)” and the “Pre-driving checks and adjustments (section 3)” of your Owner’s Manual.

may illuminate.

essential information

Fuel-filler Door

The fuel-filler door is located on the passenger’s side of the vehicle.

Unlock the fuel-filler door using one of the following

operations then push and release the left side of

the door to open.

• Push the door handle request switch while

carrying the INFINITI Intelligent Key with you.

• Press the UNLOCK button on the Intelligent Key.

• Push the power door lock switch to the UNLOCK position.

For more information, refer to the “Pre-driving checks and adjustments (section 3)” of your Owner’s Manual.

Automatic Power Windows

Your power windows have an automatic adjusting

function to ensure windows close completely to

help seal against wind noise and weather leaks.

When the front doors are being opened, the windows

automatically lower slightly to avoid contact

between the windows and the side roof panels.

If your vehicle’s battery is discharged or

disconnected, your power window automatic

function will not operate.

Refer to your Owner’s Manual for information to

initialize your power window system.

If the power window functions do not operate

properly after initializing the system, have your

vehicle checked by an INFINITI retailer.

For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual.

Accessing the Front Cup Holders

To open the cup holders, push the lid 1 down

and release.

The flap 2 will fold down when inserting a

large container.

For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual.

Clock Set/Adjustment

DIGITAL CLOCK ADJUSTMENT

To adjust the time and the appearance

of the clock on the display:

1. Press the SETTING button on the control panel.

2. Touch the Others key.

3. Touch the Clock key.

The following settings can be adjusted:

• On-screen Clock: The clock in the upper right corner

of the display can be turned ON or OFF.

• Clock Format (24h): The clock can be set to 12 hours or 24 hours.

• Offset (hour): The time can be adjusted by increasing or decreasing per hour.

• Offset (min): The time can be adjusted by increasing or decreasing per minute.

• Daylight Savings Time: The application of daylight savings time can be turned ON or OFF.

• Time Zone: Adjust the time zone. Choose a time zone from the available list.

Press the BACK button to return to the previous screen.

For more information, refer to the “Monitor, climate, audio, phone and voice recognition systems (section 4)” of your Owner’s Manual.

first drive features

INFINITI Intelligent Key System

The INFINITI Intelligent Key system allows you to lock or unlock the vehicle, open the trunk and start the engine.

It is important to make sure the Intelligent Key is

with you (that is, in your pocket or purse).

The operating range of the Intelligent Key is within

31.5 in (80 cm) from each request switch.

To lock the vehicle, push either door handle request

switch 1 once or press the

To unlock the vehicle, perform one of the following procedures:

• Push either door handle request switch

button 2 on the key fob.

once; the

corresponding door will unlock. Push the door handle request switch

again within 1 minute; all other doors

will unlock, or

• Press the

side door. Press the

To release the trunk lid, press the

1 second. Lift the trunk lid to access the trunk.

To retract the hard top (Convertible models), push and hold the

button 3 on the key fob to unlock the driver’s

button again; all other doors will unlock.

button 4 for more than

HOLD

door handle request switch 1 until the hard top is fully open.

The Intelligent Key can also be used to activate the panic alarm by pressing and holding

the

button 5 for more than 1 second. Once activated, the panic alarm and headlights

will stay on for a period of time.

INFINITI INTELLIGENT KEY BATTERY DISCHARGE

If the battery in the Intelligent Key is almost

discharged, the guide light 6 of the Intelligent

Key port blinks and the Intelligent Key battery

discharge indicator

is displayed in the vehicle

information display.

To start the engine under these circumstances,

insert the Intelligent Key into the key port with the

buttons facing upward and the key ring end toward

you until it latches into place. Then push the

ignition switch to start the engine.

To remove the Intelligent Key from the port, push

the ignition switch to turn the engine off and then

pull the Intelligent Key out of the port.

The Intelligent Key port does not charge the Intelligent Key battery. If you see the low

battery indicator 7, replace the battery in the Intelligent Key.

Do not insert the mechanical key or any other objects into the key port because it will

damage the key port.

For more information, refer to the “Pre-driving checks and adjustments (section 3)”, the “Starting and driving (section 5)” and the “Maintenance and do-it-yourself (section 8)” of your Owner’s Manual.

Trunk Lid Release

Use one of the following methods to open the trunk:

Push the trunk open request switch 1 for more than one second while carrying the INFINITI Intelligent Key with you.

Press the trunk button more than one second.

Push down on the trunk lid release switch 2

located on the instrument panel to the left of the steering wheel.

For more information, refer to the “Pre-driving checks and adjustments (section 3)” of your Owner’s Manual.

on the Intelligent Key for

HOLD

Seat Adjustments

To slide the seat forward or backward, push the

control switch

To recline the seatback, push the switch

forward or backward.

SEAT LIFTER

To adjust the angle of the front seat cushion or height

of the seat, push the front or rear end of the switch

4 up or down.

POWER LUMBAR SUPPORT (driver’s seat)

To adjust the seat lumbar support, push the front or back end of the switch

For more information, refer to the “Safety — Seats, seat belts and supplemental restraint system (section 1)” of your Owner’s Manual.

1 forward or backward.

1 2
