90cm Dual Centre Wok
BUILT-IN COOKTOPS
HCB90CC
With ILVE Gas Cooktops, you can simmer at the lowest
temperatures that your recipe calls for or go to searing
heat instantly. With innite precision heat settings
you’ll have perfect cooking control. Cleaning is easy!
There are fewer food trapping cracks and crevices
allowing for easy wipe maintenance. The trivets, burner
caps and supports are removable and easily cleaned
either in a dishwasher or by hand. A stainless steel
nish ensures this cook top will co-ordinate beautifully
with the design of other ILVE appliances. ILVE have
maintained their core values as a family owned
business and continue to manufacture appliances that
represent the most pure thing in a family – dinner time!
The kitchen is, and should always be, a place and
a time where the family meets and shares.
Pictured: ILVE Brass Burner
20112018
Colour Palette
Stainless Steel
90cm Dual Wok Burners
BUILT-IN COOKTOPS
45*
8
860
830
15
45*
860
15
470
15
8
500
HCB90CC
Model HCB90CC - 90cm H-series Double WOK Burners
FE ATURE
• Precision turn down control with low simmer on each burner
• New front mounted control for easy functional use
• 75% hand built
• Cast iron matt black trivets
• Compact design with maximum cooking space between burners
• Available in Stainless Steel only
• AS304 stainless steel construction
CLEANING & ACCESSORIES
• Deep cooktop pressing designed to retain spillages
• Easy clean removable trivets and burners
• ‘Star’ trivet adaptor for small pots
BURNERS
• Solid Brass burners with high resistance to re and non-stick matt
black nano-technology treatment
• TWIN Triple ring solid brass Innity WOK burner
• One medium-high burner and two simmer burners
SAFETY
• All gas burners tted with ame failure cut out safety devices
• Automatic electronic ignition
15
830
15
MODEL: HCB 90 CC
POWER
Power requirement: 10 AMP power GPO
Total electrical load: 0.6 kW
Total gas consumption: 50 MJ/h
45*
For installation specications, please consult with ILVE. For optimum
installation, we recommend using the actual product as the best guide.
20112018
DISCLAIMER
Eurolinx PTY LTD, trading as ILVE Appliances, is continually seeking ways to improve the design specications, aesthetics and production techniques of its products. As a result
alterations to our products and designs take place continually. Whilst every effort is made to produce information and literature that is up to date, this brochure should not be
regarded as an infallible guide to the current specications, nor does it constitute an offer for the sale of any particular product. Product dimensions indicated in our literature is
indicative only. Actual product only should be used to dene dimension cutouts. Distributors, and retailers are not agents of ILVE Appliances and are not authorized to bind ILVE
Appliances by any express or implied undertaking or representation.
