iLive ISB380 User Manual

Portable Wireless Tailgate Speaker

User’s Guide for Model ISB380 v2425-01

Important Safety Instructions

• Read these Instructions.

• Keep these Instructions.

• Heed all Warnings.

• Follow all instructions.

• Do not use this apparatus near water.

• Clean only with a dry cloth.

• Do not block any ventilation openings. Install in accordance with the
manufacturer’s instructions.

• Do not install near any heat sources such as radiators, heat registers, stoves, or

other apparatus (including ampliers) that produce heat.

• Do not defeat the safety purpose of the polarized or grounding - type plug. A
polarized plug has two blades with one wider than the other. A grounding type
plug has two blades and a third grounding prong. The wide blade or the third

prong are provided for your safety. When the provided plug does not t into

your outlet, consult an electrician for replacement of the obsolete outlet.

• Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.

• Only use attachments/accessories specied by the manufacturer.

• Unplug this apparatus during lightning storms or when unused for long
periods of time.

• Refer all servicing to qualied service personnel. Servicing is required
when the apparatus has been damaged in any way, such as power-supply
cord or plug is damaged, liquid has been spilled or objects have fallen into
the apparatus, the apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.

• Use only with a cart, stand, tripod, bracket, or table specied by
the manufacturer, or sold with the apparatus. When a cart is used,
use caution when moving the cart/apparatus combination to avoid
injury from tip-over.

FCC Warnings

Warning: Changes or modications to this unit not expressly approved by the

party responsible for compliance could void the user’s authority to operate the
equipment.

NOTE: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference in

a residential installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which

can be determined by turning the equipment o and on, the user is encouraged to

try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from
that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Additional Warnings and Precautions

• CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE

OF PLUG TO WIDE SLOT, FULLY INSERT.

• Mains plug is used as disconnect device and it should remain readily operable
during intended use. In order to disconnect the apparatus from the mains
completely, the mains plug should be disconnected from the mains socket
outlet completely.

• WARNING: Shock hazard - Do Not Open.

• CAUTION: Use of controls or adjustments or performance of procedures

other than those specied may result in hazardous radiation exposure.

• WARNING: Changes or modications to this unit not expressly approved by

the party responsible for compliance could void the user’s authority to operate
the equipment.

• WARNING: Do not place this unit directly onto furniture surfaces with any

type of soft, porous, or sensitive nish. As with any rubber compound made

with oils, the feet could cause marks or staining where the feet reside. We
recommend using a protective barrier such as a cloth or a piece of glass
between the unit and the surface to reduce the risk of damage and/or staining.

• WARNING: Do not ingest battery, chemical burn hazard.

• Battery shall not be exposed to excessive heat such as sunshine, re or the
like.

• Lithium batteries, like all rechargeable batteries, are recyclable and should
be recycled or disposed of according to state and local guidelines. They
should never be disposed of in normal household waste and they should never
be incinerated, as they might explode. Contact your local government for
disposal or recycling practices in your area.

Overview

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

ATTENTION

RISQUE D' ÉLECTROCUTION

NE PAS OUVRIR

WARNING: To reduce the risk of electric

shock, do not remove cover (or back). No

user-serviceable parts inside. Refer servicing

to qualied service personnel.

The exclamation point within an equilateral
triangle is intended to alert the user to
the presence of important operating and

maintenance (servicing) instructions in the

literature accompanying the appliance.

The lightning ash with arrowhead symbol,

within an equilateral triangle, is intended to
alert the user to the presence of un-insulated
“dangerous voltage” within the product’s

enclosure that may be of sucient magnitude

to constitute a risk of electric shock to persons.

This symbol indicates that this product
incorporates double insulation between
hazardous mains voltage and user accessible
parts.

WARNING: This product can expose you to
chemicals including lead, which is known to

the State of California to cause cancer. For

more information go to: www.P65Warnings.
ca.gov This product meets and complies with
all Federal regulations.

Features

• Bluetooth 5.0 wireless - range 60 ft.

• Voice prompts announce speaker functions

• Single 8” speaker

• Retractable pull handle and wheels

• LED display

• Digital FM radio with auto scan

• Microphone input

• Microphone echo control

• 3.5mm Line In

• Micro SD and USB media ports - supports MP3
le format

• Built-in rechargeable battery

• Battery life: approx. 2.5 hrs at 50% volume

Includes

• USB cable for battery recharge

• User’s Guide

Carry Handle

Retractable
Pull Handle

Control Panel

1. Echo: Adjust microphone echo eect.

2. Microphone Volume: Adjust microphone

volume level.

3. Display: Shows battery level, FM radio

frequency, audio track info, and source info for
the speaker and microphones.

4. Power/Volume: Turn to power ON and adjust

volume level.

5. Microphone Input: When in use, the

microphone will always be heard, regardless of
the source input.

6. DC Power Input & Charge Indicator LED:

Use to charge the internal battery and power
the speaker.

1 4

7. Micro SD Card Port

8. USB Media Port

9. Mode: Press to change audio source between

Bluetooth, Line In, and FM. Long press to turn
the light On/O.

10. /Tune± : Short press to skip audio

tracks (BLUETOOTH/USB) or radio presets (FM).
Long press to scan for the next available FM
radio station (FM).

11. / Pair/ : Press and hold to begin pairing

to a Bluetooth device (BLUETOOTH). Press to
play or pause tracks (BLUETOOTH, USB).

12. Line In (3.5mm Input)

5 632

Wheels

7

8 9 10 11 12

Sustain for Tomorrow

Charging the Battery

SD Memory Cards & USB Drives

To power the unit or charge the internal battery, connect the DC power input
on the speaker to a standard power outlet using the USB charging cable and a USB
power adapter (not included).

Battery life is approximately 2.5 hours
at 50% volume. Charging Time is
approximately 3-4 hours. While charging
the battery indicator light will display a
red light, and turn o when the battery is
fully charged.

USB Power Adapter
not included

Bluetooth Wireless

Pairing & Playing Audio

After initial pairing, the unit will stay paired unless unpaired manually by the user
or erased due to a reset of the device. If your device should become unpaired or
you nd it is unable to connect, repeat the steps listed here.

1. The speaker will power on in Bluetooth Mode. A voice will say, “Bluetooth,”

and the pairing indicator will ash the word “Blue”. When pairing, remain
within 3 feet of the Bluetooth device.

2. Using the controls on your Bluetooth device, scan for and select ISB380 in

your Bluetooth settings to pair. If your device requests a password, enter the
default password 0 0 0 0 . Refer to the user’s manual for your specic device for
instructions on pairing and connecting Bluetooth devices.

3. When successfully paired, the pairing indicator will turn solid and a voice

will announce the connection.

4. Use the controls on the connected device to select and begin playing audio.

Audio played through the connected Bluetooth device will now be heard
through the speaker. Use the controls on the speaker or the connected
device to play, pause, and adjust volume.

Note: If your device should become unpaired or you nd it is unable to connect, press
& hold the button to enter to Pairing Mode. A voice will announce “Bluetooth is
connecting” and you can connect to the speaker manually.

1. Load a Micro SD memory card or USB drive into the appropriate port.

2. The speaker will automatically switch to SD Card Mode (“SD” on the
display) or USB Mode (“USB” on the display) and begin playing media on the
connected storage device.

3. Use the controls on the speaker to select and play audio from the
connected drive.

Line In

Requires a 3.5mm audio cable.

1. Connect a 3.5mm audio cable to the Line In on the unit and the
audio output/headphone jack on an audio device.

2. Press Mode to switch to Line In Mode (“LINE” on the display).

3. Use the controls on the connected device to select and play audio.

FM Radio

Radio Reception and the 3.5mm Audio Cable (Not included)

An FM receiver is built into the speaker but functions best when a 3.5mm audio
cable is connected to the speaker. Adjust the position of the cable and the speaker
to improve FM radio reception.

Radio Tuning and Saving Station Presets

1. Press the Mode button to switch to FM Radio Mode. The display will show

the station frequency, Ex: 101.1.

2. Press and hold to scan and save radio stations automatically. Radio

stations will be assigned a “Ch” number, Ex: Ch 18.

3. Press to tune the presets

Customer Support

To download this User’s Guide in English, Spanish, or French, or to get answers to frequently asked questions, visit the support section at:

www.iLiveElectronics.com

Para descargar este Manual del Usuario en inglés, español y francés, o para obtener respuestas a preguntas frecuentes, visite la sección de
apoyo en: www.iLiveElectronics.com

Pour télécharger ce guide de l’utilisateur en anglais, espagnol ou français, ou pour obtenir des réponses à des questions fréquemment
posées, consultez la rubrique d’assistance sur: www.iLiveElectronics.com

For Warranty Information and the most up-to-date version of this User’s Guide, go to www.iLiveElectronics.com

Customer Service: 1-888-999-4215 | Email Support: [e-mail] | Email Parts: [e-mail]

Copyright © 2018 Digital Products International (DPI, Inc.) All other trademarks appearing herein are the property of their respective owners.
Specications are subject to change without notice.
