Iiyama TF1015MC-B2 User Manual

Thank you very much for choosing the iiyama LCD monitor. We recommend that you take a few minutes to read this comprehensive manual carefully before installing and switching on the monitor. Please keep this manual in a safe place for your future reference.
ENGLISH
ENGLISH
CE MARKING DECLARATION OF CONFORMITY
This LCD monitor complies with the requirements of the EC/EU Directive 2014/30/EU “EMC Directive”, 2014/35/EU “Low Voltage Directive”, 2009/125/EC “ErP Directive” and 2011/65/EU “RoHS Directive”. The electro-magnetic susceptibility has been chosen at a level that gives correct operation in residential areas, business and light industrial premises and small-scale enterprises, inside as well as outside of the buildings. All places of operation are characterised by their connection to the public low voltage power supply system.
IIYAMA CORPORATION: Wijkermeerstraat 8, 2131 HA Hoofddorp, The Netherlands
Model No. : PLF1015, PLF1515, PLF2215, PLF2415
ENGLISH
We recommend recycling of used product. Please contact your dealer or iiyama service center. Recycle information is obtained via the Internet, using the address: http://www.iiyama.com You can access the Web page of diff erent countries from there.
We reserve the right to change specifi cations without notice.
All trademarks used in this user manual are the property of their respective owners.
ENGLISH
TABLE OF CONTENTS
FOR YOUR SAFETY ............................................................................1
SAFETY PRECAUTIONS................................................................1
SPECIAL NOTES ON LCD MONITORS .........................................3
CUSTOMER SERVICE ................................................................... 3
CLEANING ...................................................................................... 3
BEFORE YOU OPERATE THE MONITOR ..........................................4
FEATURES......................................................................................4
CHECKING THE CONTENTS OF THE PACKAGE ........................5
WALL MOUNTING .......................................................................... 6
BUILT-IN EQUIPMENT ....................................................................6
ROTATING THE DISPLAY ..............................................................6
CONTROLS AND CONNECTORS..................................................7
SPECIAL NOTES ...........................................................................8
CONNECTING YOUR MONITOR ................................................. 11
COMPUTER SETTING .................................................................13
OPERATING THE MONITOR .............................................................14
ADJUSTMENT MENU CONTENTS ..............................................16
SCREEN ADJUSTMENTS ............................................................20
POWER MANAGEMENT FEATURE .............................................23
TROUBLE SHOOTING ......................................................................24
RECYCLING INFORMATION .............................................................25
APPENDIX ........................................................................................26
SPECIFICATIONS : ProLite TF1015MC-B2 ..................................26
SPECIFICATIONS : ProLite TF1515MC-B2 ..................................27
SPECIFICATIONS : ProLite TF2215MC-B2 ..................................28
SPECIFICATIONS : ProLite TF2415MC-B2 ..................................29
DIMENSIONS : ProLite TF1015MC ..............................................30
DIMENSIONS : ProLite TF1515MC ..............................................30
DIMENSIONS : ProLite TF2215MC ..............................................31
DIMENSIONS : ProLite TF2415MC ..............................................31
DIMENSIONS : L-BRACKET.........................................................32
COMPLIANT TIMING : ProLite TF1015MC ...................................33
COMPLIANT TIMING :
ProLite TF1515MC / ProLite TF2215MC / ProLite TF2415MC .....33
FOR YOUR SAFETY
SAFETY PRECAUTIONS
WARNING
STOP OPERATING THE MONITOR WHEN YOU SENSE TROUBLE
If you notice any abnormal phenomena such as smoke, strange sounds or fumes, unplug the monitor and contact your dealer or iiyama service center immediately. Further use may be dangerous and can cause fi re or electric shock.
NEVER REMOVE THE CABINET
High voltage circuits are inside the monitor. Removing the cabinet may expose you to the danger of fi re or electric shock.
DO NOT PUT ANY OBJECT INTO THE MONITOR
Do not put any solid objects or liquids such as water into the monitor. In case of an accident, unplug your monitor immediately and contact your dealer or iiyama service center. Using the monitor with any object inside may cause fi re, electric shock or damage.
INSTALL THE MONITOR ON A FLAT, STABLE SURFACE
The monitor may cause an injury if it falls or is dropped.
DO NOT USE THE MONITOR NEAR WATER
Do not use where water may be splashed or spilt onto the monitor as it may cause fi re or electric shock.
OPERATE UNDER THE SPECIFIED POWER SUPPLY
Be sure to operate the monitor only with the specifi ed power supply. Use of an incorrect voltage will cause malfunction and may cause fi re or electric shock.
ENGLISH
CORRECT USE OF THE AC ADAPTER
Use only the AC Adapter provided by iiyama. Any deviation from this by using another type of adapter may result in damage to the accessory and the monitor by fi re or electric shock.
DO NOT DISASSEMBLE THE AC ADAPTER
Disassembling the AC Adapter may expose you to the danger of fi re or electric shock.
PROTECT THE CABLES
Do not pull or bend the AC adapter, the power cable and signal cable. Do not place the monitor or any other heavy objects on the cables. If damaged, the cables may cause fi re or electric shock.
ADVERSE WEATHER CONDITIONS
It is advisable not to operate the monitor during a heavy thunder storm as the continual breaks in power may cause malfunction. It is also advised not to touch the plug in these circumstances as it may cause electric shock.
FOR YOUR SAFETY 1
CAUTION
INSTALLATION LOCATION
Do not install the monitor where sudden temperature changes may occur, or in humid, dusty or smoky areas as it may cause fi re, electric shock or damage. You should also avoid areas where the sun shines directly on the monitor.
DO NOT PLACE THE MONITOR IN A HAZARDOUS POSITION
The monitor may topple and cause injury if not suitably located. Please also ensure that you do not place any heavy objects on the monitor, and that all cables are routed such that children may not pull the cables and possibly cause injury.
MAINTAIN GOOD VENTILATION
Ventilation slots are provided to keep the monitor from overheating. Covering the slots may cause
ENGLISH
fi re. To allow adequate air circulation, place the monitor at least 10 cm (or 4 inches) from any walls. Do not remove the tilt stand when operating the monitor. Ventilation slots on the back of the cabinet will be blocked and the monitor may overheat if the stand is removed. This may cause fi re or damage. Operating the monitor on its back, side, upside down or on a carpet or any other soft material may also cause damage.
DISCONNECT THE CABLES WHEN YOU MOVE THE MONITOR
When you move the monitor, turn off the power switch, unplug the monitor and be sure the signal cable is disconnected. If you do not disconnect them, it may cause fi re or electric shock.
UNPLUG THE MONITOR
If the monitor is not in use for a long period of time it is recommended that it is left unplugged to avoid accidents.
HOLD THE PLUG WHEN DISCONNECTING
To disconnect the AC adapter, the power cable or signal cable, always pull it by the plug. Never pull on the cable itself as this may cause fi re or electric shock.
DO NOT TOUCH THE PLUG WITH WET HANDS
Pulling or inserting the plug with wet hands may cause electric shock.
WHEN YOU INSTALL THE MONITOR ON YOUR COMPUTER
Be sure the computer is strong enough to hold the weight of the monitor, otherwise, you may damage your computer.
REMARK FOR 24/7 USAGE
This product is not specifi cally designed for 24/7 usage in all environments.
OTHERS
ERGONOMIC RECOMMENDATIONS
To eliminate eye fatigue, do not operate the monitor against a bright background or in a dark room. For optimal viewing comfort, the monitor should be just below eye level and 40-60 cm (16-24 inches) away from your eyes. When using the monitor over a prolonged time, a ten minute break every hour is recommended as looking at the screen continuously can cause eye strain.
2 FOR YOUR SAFETY
SPECIAL NOTES ON LCD MONITORS
The following symptoms are normal with LCD monitors and do not indicate a problem.
NOTE
When you fi rst turn on the LCD monitor, the picture may not fi t in the display area

because of the type of computer that is used. In this case, adjust the picture position to the correct position. You may fi nd slightly uneven brightness on the screen depending on the desktop

pattern you use. Due to the nature of the LCD screen, an afterimage of the previous screen may

remain after switching the image, when the same image is displayed for hours. In this case, the screen is recovered slowly by changing the image or turning off the Power Switch for some hours.
CUSTOMER SERVICE
ENGLISH
NOTE
CLEANING
WARNING
NOTE
CABINET
TOUCH SCREEN
If you have to return your unit for service and the original packaging has been

discarded, please contact your dealer or iiyama service center for advice or replacement packaging.
If you drop any materials or liquids such as water into the monitor when cleaning,

unplug the power cable immediately and contact your dealer or iiyama service center.
To protect the Touch screen surface, do not scratch or rub the screen with a hard

object. Never use any of the following strong solvents. These will damage the cabinet and

the Touch screen surface.
Abrasive cleaner Wax Solvent
Touching the cabinet with any product made from rubber or plastic for a long time

may cause degeneration or loss of paint on the cabinet.
Stains can be removed with a cloth lightly moistened with a mild detergent solvent. Then wipe the cabinet with a soft dry cloth.
Touch screen surface may be cleaned using a soft clean cloth moistened with mild window glass commercial cleaners or 50/50 mixture of water and IPA(ISO-propyl­alcohol). Don’t use acid or alkaline solvent to clean the surface of the panel (or screen).
FOR YOUR SAFETY 3
BEFORE YOU OPERATE THE MONITOR
FEATURES
Supports Resolutions up to 1280 × 800 : ProLite TF1015MC
Supports Resolutions up to 1024 × 768 : ProLite TF1515MC
Supports Resolutions up to 1920 × 1080 : ProLite TF2215MC / ProLite TF2415MC
High Contrast 1300:1 (Typical) / Brightness 500cd/m2 (Typical: without Touch
panel) : ProLite TF1015MC
High Contrast 800:1 (Typical) / Brightness 350cd/m
panel) : ProLite TF1515MC
High Contrast 1000:1 (Typical) / Brightness 350cd/m
ENGLISH
panel) : ProLite TF2215MC
High Contrast 3000:1 (Typical) / Brightness 350cd/m
panel) : ProLite TF2415MC
Digital Character Smoothing
Automatic Set-up
Plug & Play VESA DDC2B Compliant

Windows
Power Management (VESA DPMS Compliant)
VESA Mounting Standard (100mm×100mm) Compliant
IP65 Standard Compliant (Only front face)
Anti fi ngerprint fi nish
®
XP/Vista/7/8/8.1/10 Compliant
2
(Typical: without Touch
2
(Typical: without Touch
2
(Typical: without Touch
Windows8/8.1/10 touch environment
Basic touch operations can be performed under Windows 8/8.1/10. However, please be informed that full touch functionality and normal operational performance are not guaranteed.
4 BEFORE YOU OPERATE THE MONITOR
CHECKING THE CONTENTS OF THE PACKAGE
The following accessories are included in your package. Check to see if they are enclosed with the monitor. If anything is missing or damaged, please contact your local iiyama dealer or regional iiyama offi ce.
Power Cable*
DisplayPort Cable
L-Bracket (2pairs: ProLite TF1015MC, 4pairs: ProLite TF1515MC / ProLite TF2215MC, 6pairs:
1

AC Adapter* USB Cable

ProLite TF2415MC)
Bracket Screw (M4×6 8pcs: ProLite TF1015MC, M4×6 16pcs: ProLite TF1515MC / ProLite
TF2215MC, M4×6 24pcs: ProLite TF2415MC) Touch Panel Driver Disk (CD-ROM)*

Quick Start Guide
CAUTION
*1 1. TO USERS IN 120V AREA
The rating of the Power Cable enclosed in 120V area is 10A/125V. If you are using
a power supply higher than this rating, then a power cable with a rating of 10A/250V must be used. However, all guarantees and warranties are void for any problems or damage caused by a power cable or AC adapter not supplied by iiyama.
2. Applicable AC Adapter AC Adapter Type Name : ADP-36PH B (DELTA ELECTRONICS, INC.)
3. An approved power cable greater or equal to H05VVF, 3G, 0.75mm used.
2
This CD-ROM contains the touch screen driver software.
* Install the Touch Panel Driver Disk after connecting the computer to the monitor
with USB Cable. For the details, see Readme fi le in the Touch Panel Driver Disk.
1
2
HDMI Cable
External control pad
Safety Guide
2
must be
ENGLISH
BEFORE YOU OPERATE THE MONITOR 5
WALL MOUNTING
WARNING
ENGLISH
BUILT-IN EQUIPMENT
WARNING
ROTATING THE DISPLAY
When you use with the wall mounting, in consideration of thickness of the mounting stage, tighten the M4 Screw with washer which “L” length is 8mm to fasten the monitor. Using the screw longer than this may cause electric shock or damage because it may contact with the electrical parts inside the monitor.
This product is not designed for the purpose of being used in high temperature environment. If the product is placed in an external cabinet, you need to design cooling fans and vents to keep the temperature low enough to fit in the product temperature specifi cation.
Mounting Stage
L
Screw
Chassis
It is designed to be compatible in both landscape and portrait modes.
A
A
Portrait
6 BEFORE YOU OPERATE THE MONITOR
Landscape
A
Portrait
Not AvailableAvailable
A
CONTROLS AND CONNECTORS
External control
pad
<Front> <Back>
Menu Button (MENU)
Scroll Up / Brightness Button ( )
Scroll Down / Contrast Button ( )
Select Button (SELECT)
Power Switch ( )
External control pad Connector (RJ45)
USB Connector (USB)
VGA Connector (VGA)
HDMI Connector (HDMI)
DisplayPort Connector (DP)
Connector for AC Adapter( : Direct current) (DC)
Headphone Connector (AUDIO OUT)
ENGLISH
BEFORE YOU OPERATE THE MONITOR 7
SPECIAL NOTES
L-Brackets and screws are necessary to install an open frame monitor.
The L-Brackets are designed to be mounted to specific wall types and
CAUTION
As shown in fi gure below, tighten Bracket A to B using the screws supplied.
(ProLite TF1015MC: 2pairs of 2 pcs, ProLite TF1515MC / ProLite TF2215MC: 4pairs of 2 pcs, ProLite TF2415MC: 6pairs of 2 pcs)
ENGLISH
Attach the L-bracket( ) to the back of the
recess, where the monitor is to be attached, and fi x it with screws.
(Customer’s screws: ProLite TF1015MC:
4 pcs, ProLite TF1515MC / ProLite TF2215MC: 8 pcs, ProLite TF2415MC: 12 pcs)
<Mount size>
ProLite TF1015MC ProLite TF1515MC
hardware, in accordance with the installation instructions.
Using L-Bracket or screws other than those specified in the installation
instructions may damage the monitor.
Screwx 2
Bracket A
Bracket B
Bracket A
Back of the recess
Screwx 2
L-Bracket
271.0
259.5±0.3
Two options to apply the mount: "A" = M4 threaded screw holes "B" = holes without screw thread
8 BEFORE YOU OPERATE THE MONITOR
R12.75±0.3 x4
120”B”
100”A”
182.2±0.3
311.6
288.6±0.4
R11.8±0.3 x4
96.7
98”B”
93.9
78”A”
Two options to apply the mount: "A" = M4 threaded screw holes "B" = M4 holes without screw thread
78”A” 98”B”
361.7±0.4
384.8
ProLite TF2215MC ProLite TF2415MC
542.55
517.0
200.0
R8.5 x4
60
594.7
573.7±0.2
225
60 “A/B” x6
R10.0±0.2 x4
Two options to apply the mount: "A" = M4 threaded screw holes "B" = M4 holes without screw thread
200.0
312.0
337.5
Two options to apply the mount: "A" = M4 threaded screw holes "B" = M4 holes without screw thread
Attach the monitor from the front side of the recess and fi x with the screws.
(Screws: ProLite TF1015MC: 4 pcs, ProLite TF1515MC / ProLite TF2215MC: 8 pcs, ProLite TF2415MC: 12 pcs)
ProLite TF1015MC ProLite TF1515MC
Screwx 2 x 4
L-Bracket
L-Bracket
Screwx 2 x 2
L-Bracket
ProLite TF2215MC ProLite TF2415MC
60
L-Bracket
366.6
345.6±0.2
ENGLISH
L-Bracket
Screwx 2 x 4
L-Bracket
L-Bracket
Screwx 2 x 6
L-Bracket
L-Bracket
L-Bracket
BEFORE YOU OPERATE THE MONITOR 9
NOTE
ENGLISH
You will need a screwdriver to mount the L-Bracket.
L-Brackets and screws are necessary to install an open frame monitor. For details
regarding the operating temperature and humidity conditions, see specifi cation of this User Manual.
The position of the L-bracket can be either
20.0mm
0 mm or 20.0 m m from the front of the monitor depending on which screw holes you choose for mounting it.
Front of the Monitor
Screw holes for mounting the chassis
10 BEFORE YOU OPERATE THE MONITOR
CONNECTING YOUR MONITOR
Ensure that both the computer and the monitor are switched off . Connect the computer to the monitor with the signal cable. Connect the computer to the monitor with the USB Cable. Connect the monitor cable to the External control pad. Connect the AC Adapter to the monitor and the Power Cable to the AC Adapter fi rst and then
connect to the power source. Turn on your monitor and computer.
NOTE
The signal cables used for connecting the computer and monitor may vary with the
type of computer used. An incorrect connection may cause serious damage to both the monitor and the computer. The cable supplied with the monitor is for a standard connector. If a special cable is required please contact your local iiyama dealer or regional iiyama offi ce.
For connection to Macintosh computers, contact your local iiyama dealer or regional
iiyama offi ce for a suitable adaptor.
Make sure you tighten the fi nger screws at each end of the Signal Cable.
The Class I pluggable equipment Type A must be connected to protective earth.
The socket-outlet shall be installed near the equipment and shall be easily accessible.
Excessive sound pressure from ear-/headphones can cause hearing damage/hearing
loss.
[Example of Connection]
<Back>
ENGLISH
External
control pad
(Accessory)
USB Cable (Accessory)
Power Cable (Accessory)
AC Adapter (Accessory)
VGA Cable (Not included)*
HDMI Cable (Accessory)
DisplayPort Cable (Accessory)
Computer
* VGA cable is not supplied with the monitor. If you use low quality VGA cable, it may cause a result
of electro-magnetic interference. Please contact the iiyama Support Centre in your country if you wish to connect the monitor via the VGA input.
BEFORE YOU OPERATE THE MONITOR 11
[Fitting and Removal of Cable Cover]
Put a piece of soft cloth on the table beforehand to prevent the monitor from being scratched. Lay the monitor fl at on a table with front face down.
< Removal >
Remove the screw of the cable cover and
remove the cable cover from the monitor.
Screw
Cable Cover
ENGLISH
< Fitting >
Connect the cables, place the cable cover and
fi x it fi rmly using a screw.
Screw
12 BEFORE YOU OPERATE THE MONITOR
COMPUTER SETTING
Signal Timing
Change to the desired signal timing listed on page 33: COMPLIANT TIMING.
Windows XP/Vista/7/8/8.1/10 Plug & Play
The iiyama LCD monitor complies with DDC2B of VESA standard. The Plug & Play function runs
on Windows XP/Vista/7/8/8.1/10 by connecting the monitor to DDC2B compliant computer with the Signal Cable supplied.
For installation on Windows XP: The monitor Information File for iiyama monitors may be
necessary for your computer and obtained via the Internet, using the address:
http://www.iiyama.com
NOTE
Procedure for turning ON the Power Switch
Turn ON the monitor fi rst, and then the computer.
Touch screen driver software

Touch screen driver software and system may not start when you start your computer while
touching the screen.
Touch screen driver software may not run due to the power saving function depending on the
BIOS of your computer. In this case, set the power saving function to off .
TOUCH support operation system

Microsoft Windows XP (64 bit and 32 bit) Microsoft Windows Vista (64 bit and 32 bit) Microsoft Windows 7 (64 bit and 32 bit) Microsoft Windows 8 / 8.1 / 10 (64 bit and 32 bit) Microsoft Windows CE 6.0 / net (4.x / 5.0) Kernel 2.6.24 upward & 3.x.x / 4.x.x Not support earlier versions.
Default mouse*
Touch digitizer*
Windows7 gestures*
For additional information on how to download the driver for your touch screen monitor,

please access the internet site noted above. Monitor Drivers are not required in most cases for Macintosh or Unix operating

systems. For further information, please contact your computer dealer fi rst for advice.
Mac OS X (Intel CPU) / 10.11 El Capitan / 10.12 Sierra
Windows8/8.1/10 Windows7*5Windows7*
1
2
3
4
Vista XP
ENGLISH
Default mouse*
Touch digitizer*
Windows7 gestures*
*1 Default mouse (click, drag, double-click and right-click)
2
Touch digitizer (click, drag /selection, double-click, right-click, fl ick and visual feedback)
*
3
Digitizer with Windows7 touch gestures
*
4
*
Windows 7 - Starter and Home Basic version
5
Windows 7 - Home Premium, Professional, Enterprise and Ultimate versions
*
1
2
2K Windows CE XP Embedded Mac OSX Linux
3
BEFORE YOU OPERATE THE MONITOR 13
OPERATING THE MONITOR
To create the best picture, your iiyama LCD monitor has been preset at the factory with the COMPLIANT TIMING shown on page 33. You are also able to adjust the picture by following the button operation shown below. For more detailed adjustments, see page 20 for SCREEN ADJUSTMENTS.
Press the MENU Button to start the On Screen Display feature. There are additional Menu items which can be switched by using the
Picture Advanced
Contrast
Brightness
H-Position
ENGLISH
Select the Menu item which contains the adjustment icon relating to the adjustment
V-Position
Phase
Clock
Auto Adjust
you want to make. Use the SELECT Button to highlight the desired adjustment icon.
Use the / Buttons to make the appropriate adjustment or setting.
Press the MENU Button to leave the menu, and the settings you just made would be automatically saved.
For example, to correct for vertical position, select Menu item of Picture. Then, select V-Position by using the SELECT Button. Use the
/ Buttons to change the vertical position settings. The vertical position of the
overall display should be changing accordingly while you are doing this.
OSD
/ Buttons.
Option
Option
Picture Advanced
OSD
V-Position
Press the MENU Button lastly, it ends, all changes are saved in the memory.
NOTE
When button operations are aborted during adjustment, On-Screen Display disappears when the

time set for the OSD Timeout has passed.
MENU button can be used to return previous menu item.
Any changes are automatically saved in the memory when the On Screen Display

disappears. Turning off the power should be avoided while using the Menu. Adjustments for H/V-Position, Clock and Phase are saved for each signal timing. Except for these

adjustments, all other adjustments have only one setting which applies to all signal timings.
14 OPERATING THE MONITOR
LOCK MODE:
Direct

Simultaneously press the MENU button and the VGA, HDMI or DisplayPort. * The OSD menu is not displayed when the OSD is locked. Press the MENU button and the
button simultaneously again.
The following OSD menu is displayed.
button when an image is displayed through
Adjustment Item Problem / Option
POWER
OSD
TOUCH FANCTION DISABLE:

ON: Pressing and holding of the MENU Button and the SELECT Button at the same time when
the Menu is not displayed, massage "TOUCH DISABLE" will appear on the top right corner.
OFF: Pressing and holding of the MENU Button and the SELECT Button at the same time for
about 5 seconds when the Menu is not displayed, till "TOUCH DISABLE" disappears.
Active Inactive Active Inactive
The POWER SWITCH is Locked. The POWER SWITCH is Unlocked. The OSD menu is Locked. The OSD menu is Unlocked.
ENGLISH
OPERATING THE MONITOR 15
ADJUSTMENT MENU CONTENTS
Direct
Direct
Direct
Picture Advanced
Contrast
Brightness
H-Position
V-Position
Phase
Clock
Auto Adjust
OSD
Option
ENGLISH
Adjustment Item Problem / Option Button to Press
Contrast
Brightness*
H-Position*
V-Position*
Phase*
Clock*
Auto Adjust*
1
*
Adjust the Brightness when you are using the monitor in a dark room and feel the screen is too bright.
2
*
See page 20 for SCREEN ADJUSTMENTS.
3
*
For best results, use the Auto Adjust in conjunction with the adjustment pattern. See page 20 for
SCREEN ADJUSTMENTS.
4
Only Analog Input.
*
1
4
4
2,4
2,4
3,4
Too dull Too intense
Too dark Too bright
Too left Too right
Too low Too high
To correct fl ickering text or lines
Too narrow Too wide
Adjust H/V-Position, Clock and Phase automatically.
You can skip the Menu items and directly display an adjustment scale by using the following button operations.
Contrast: Press the

Brightness: Press the

16 OPERATING THE MONITOR
Button when the Menu is not displayed.
Button when the Menu is not displayed.
Advanced
Option
Picture Advanced
Color Temp
Red
Green
Blue
Sharpness
OSD
User
Adjustment Item Problem / Option Button to Press
5500
6500 7500
Color Temp
User
Greenish white Reddish white Yellowish white Bluish white9300 Red Green Blue
Too weak Too strong
You can change the picture quality from 0 to 100 (soft to sharp).
Sharpness
Press the numerical order. Press the picture quality in reverse numerical order. Adjust the picture quality at resolutions of less 1280
Button to change the picture quality in
Button to change the
x 800(ProLite TF1015MC) / 1024 x 768(ProLite TF1515MC) / 1920 x 1080(ProLite TF2215MC / ProLite TF2415MC). You can change the picture quality.
ENGLISH
OPERATING THE MONITOR 17
OSD
Option
Picture Advanced
OSD Timeout
OSD Position
OSD H-Position
OSD V-Position
Touch Switch
OSD
User
Normal
Adjustment Item Problem / Option Button to Press
OSD Timeout
ENGLISH
You can set the OSD display duration time between 5 and 60 seconds.
You can set the OSD position.
OSD Position
User (Upper left / Lower left / Upper right / Lower right / Center)
OSD H-Position
OSD V-Position
Touch Switch *
OSD is too left OSD is too right
OSD is too low OSD is too high
Normal Glove Through-Glass
Normal touch (with bare hands or stylus device) Touch with gloved hand (Supports thickness +2mm)
Touch through glass (Supports thickness +6mm)
* Please turn on the power and set the Touch Switch after the monitor installation is completed. Turning on the power and setting the Touch Switch before the monitor installation may cause
misalignment or malfunction of the touch calibration.
18 OPERATING THE MONITOR
Direct
Direct
Option
Option
Picture Advanced
Reset
Language
Source Select
DisplayMode
Factory
OSD
English
VGA
Adjustment Item Problem / Option Button to Press
Reset
Language
Source Select
However it will automatically be selected when just one source is using.
NOTE
In Power Management Mode input switching is disabled. Input source is fi xed, not selected automatically when VGA, HDMI and DisplayPort which are selected.
Display Mode
Factory
No
Yes
English Français French Deutsch Italiano Italian
Auto
VGA HDMI
Return to Menu.
Factory-preset data is restored.
English
Español Spanish
Japanese
German
繁中
Traditional Chinese Simplifi ed Chinese
Search for an available input source and select automatically.
Select the analog input. Select the digital(HDMI) input.
Select the digital(DisplayPort) input. DP
Displays information regarding the current input signal coming from the graphic card in your computer.
NOTE
See your graphic card user guide for more information about changing the resolution and refresh.
This function is for service personnel only and therefore the operation is not available.
ENGLISH
You can skip the Menu items and directly display an option setting screen by using the following button operations.
Source Select : Pressing and holding of the SELECT Button for about 5 seconds when the Menu

is not displayed.
By pressing the SELECT Button during power management mode, the Source
Selected menu will be displayed.
OPERATING THE MONITOR 19
SCREEN ADJUSTMENTS
Adjust the image by following the procedure below to get the desired picture when selecting Analog input.
The screen adjustments described in this manual are designed to set image position and minimize
fl icker or blur for the particular computer in use. ProLite TF1015MC is designed to provide the best performance at resolution of 1280 × 800, but can
not provide the best at resolutions of less than 1280 × 800 because the picture is automatically stretched to fi t the full screen. It is recommended to operate at resolution of 1024 × 768 in normal use. ProLite TF1515MC is designed to provide the best performance at resolution of 1024 × 768, but can
not provide the best at resolutions of less than 1024 × 768 because the picture is automatically stretched to fi t the full screen. It is recommended to operate at resolution of 1024 × 768 in normal use.
ProLite TF2215MC / ProLite TF2415MC are designed to provide the best performance at resolution
of 1920 × 1080, but can not provide the best at resolutions of less than 1920 × 1080 because the picture is automatically stretched to fi t the full screen. It is recommended to operate at resolution of
ENGLISH
1920 × 1080 in normal use.
Displayed text or lines will be blurred or irregular in thickness when the picture is stretched due to
the screen enlargement process.
It is preferable to adjust the image position and frequency with the monitor controls, rather than
the computer software or utilities.
Perform adjustments after a warm-up period of at least thirty minutes.
Additional adjustments may be required after the Auto Adjust depending on the resolution or signal timing.
The Auto Adjust may not work correctly when displaying the picture other than the screen
adjustment pattern. In this case, manual adjustments are required.
There are two ways to adjust the screen. One way is automatic adjustment for H/V-Position, Clock and Phase. The other way is performing each adjustment manually. Perform the Auto Adjust first when the monitor is connected to a new computer, or resolution is changed. If the screen has a fl icker or blur, or the picture does not fi t in the display area after performing the Auto Adjust, manual adjustments are required. Both adjustments should be made by using the screen adjustment pattern (Test.bmp) obtained via the IIYAMA web site (http://www.iiyama.com).
Adjust the image by following the procedure below to get the desired picture. This manual explains adjustment under Windows® OS.
Display the picture at the optimum resolution.
Enter the Test.bmp (screen adjustment pattern) to wallpaper.
NOTE
[Adjustment pattern]
Consult the appropriate documentation for doing this.
Set the display position to center in the wallpaper setting dialogue box. If you use
Microsoft
®
PLUS! 95/98 cancel the setting of “Stretch desktop wallpaper to fit the
screen”.
Zebra pattern
20 OPERATING THE MONITOR
Color bar
Picture frame
Press the SELECT Button. (Auto Adjust)
Adjust the image manually by following procedure below when the screen has a fl icker or
blur, or the picture does not fi t in the display area after performing the Auto Adjust.
Adjust the V-Position so that the top and bottom of the picture frame will fi t to the display
area.
1) Adjust the H-Position so that the left side of the picture frame will move to the left edge of the display area.
ENGLISH
2) Stretch the right side of the picture frame to the right edge of the display area by
adjusting the Clock.
NOTE
When the left side of the picture frame moves apart from the left edge of the display
area during the Clock adjustment, adjust steps 1) and 2).
Another way to make the Clock adjustment is to correct the vertical wavy lines in the
zebra pattern.
The picture may fl icker during the Clock, H/V-Position adjustment.
In case the picture frame is bigger or smaller than the data display area after the
Clock adjustment, repeat steps from
.
OPERATING THE MONITOR 21
Adjust the Phase to correct horizontal wavy noise, fl icker or blur in the zebra pattern.
In case the strong fl icker or blurs remain on a part of the screen, repeat steps
NOTE
because the Clock may not be adjusted correctly. If the fl icker or blurs still remain,
ENGLISH
set the refresh rate of computer to low (60Hz) and repeat steps from
Adjust the H-Position after the Phase adjustment if the horizontal position moves
again.
during the adjustment.
Adjust the Brightness and Color to get the desired picture after you complete the Clock
and Phase adjustments.
Put back your favorite wallpaper.
and
22 OPERATING THE MONITOR
POWER MANAGEMENT FEATURE
0 1.2W 100 %
POWER CONSUMPTION
NORMAL MODE
POWER MANAGEMENT MODE
When your computer is not in use, the power management feature will automatically reduce the power consumption of your monitor. To use the feature, the monitor needs to be connected to a VESA DPMS compliant computer. There is a power management step the monitor takes as described below. The power management function, including any timer settings is confi gured by the operating system. Check your operating system manual for information on how this can be confi gured.
Power Management Mode

When the H-sync signal / V-sync signal / H and V sync signals from the computer are off , the monitor enters into Power Management Mode which reduces the power consumption to less than 1.2W. The screen becomes dark. From Power Management Mode, the image reappears in several seconds when either the keyboard or the mouse are touched again.
Even when using the power management mode, the monitor consumes electricity. Turn
NOTE

off the Power Switch whenever the monitor is not in use, during the night and weekends, to avoid unnecessary power consumption. It is possible that the video signal from the computer may be on while the H or V sync

signal is missing. In this instance, the POWER MANAGEMENT feature may not work properly.
ENGLISH
OPERATING THE MONITOR 23
TROUBLE SHOOTING
If the monitor fails to operate correctly, please follow the steps below for a possible solution.
1. Perform the adjustments described in OPERATING THE MONITOR, depending on the problem you have. If the monitor does not get a picture, skip to 2.
2. Consult the following items if you cannot fi nd an appropriate adjustment item in OPERATING THE MONITOR or if the problem persists.
3.
If you are experiencing a problem which is not described below or you cannot correct the problem, discontinue using the monitor and contact your dealer or iiyama service center for further assistance.
Problem Check
The AC Adapter is fi rmly seated in the connector.
The picture does
not appear.
ENGLISH
The screen is not
synchronized.
The screen
position is not in the center.
The screen is too
bright or too dark.
The screen is
shaking.
The touch
screen shows no response.
The touch position
does not deviate.
The Power Cable is fi rmly seated in the socket of the AC Adapter.
The Power Cable is fi rmly seated in the socket.

The Power Switch is turned ON.

The AC socket is live. Please check with another piece of equipment.

If the blank screen saver is in active mode, touch the keyboard or the mouse.

Increase the Contrast and/or Brightness.

The computer is ON.

The Signal Cable is properly connected.

The signal timing of the computer is within the specifi cation of the monitor.

If the monitor is in power management mode, touch the keyboard or the mouse.

The Signal Cable is properly connected.

The signal timing of the computer is within the specifi cation of the monitor.

The video output level of the computer is within the specifi cation of the monitor.

The signal timing of the computer is within the specifi cation of the monitor.

The video output level of the computer is within the specifi cation of the

monitor.
The power voltage is within the specifi cation of the monitor.

The signal timing of the computer is within the specifi cation of the monitor.

The USB Cable is fi rmly seated in the socket.

Touch screen driver software is installed.

The calibration function set up correctly.

24 TROUBLE SHOOTING
RECYCLING INFORMATION
For better environment protection please don't dispose your monitor. Please visit our web site: www.iiyama.com for monitor recycling.
ENGLISH
RECYCLING INFORMATION 25
APPENDIX
Design and specifi cations are subject to change without prior notice.
SPECIFICATIONS : ProLite TF1015MC-B2
Technology Projected capacitive 10pt touch
Touch Screen
Light transmission Communication system Surface fi nish Anti fi ngerprint coating
Size Category 10.1"
Panel technology
ENGLISH
LCD Panel
Size Diagonal: 10.1" (25.7cm) Pixel pitch 0.1695mm H × 0.1695mm V
Brightness
Contrast ratio 1300 : 1 (Typical) Viewable angle Horizontal : 170 degrees, Vertical: 170 degrees (Typical)
Response time 25ms (Black, White, Black Typical) Display Colors Approx.16.2M Sync Frequency Horizontal: 31.4-49.7kHz, Vertical: 60Hz Maximum Resolution 1280 × 800, 1.0 MegaPixels Input Connector VGA, HDMI, DisplayPort Plug & Play VESA DDC2B Input Sync Signal Separate sync: TTL, Positive or Negative
Input Video Signal
Headphone connector ø 3.5mm mini jack (Stereo) External control pad Connector RJ45 Maximum Screen Size 216.96mm W × 135.60mm H / 8.5" W × 5.3" H Power Source 12VDC, 1A AC Adapter (accessory) Input: 100-240VAC 50/60Hz
Power Consumption*
1
Dimensions / Net Weight
Environmental Considerations
Approvals CB, CE, TÜV-Bauart, CU, cULus, IP65*
90% USB
MVA
2
500cd/m
(Typical: without Touch panel),
450cd/m2 (Typical: with Touch panel)
TM
Analog: 0.7Vp-p (Standard), 75
Positive

Digital: HDMI, DisplayPort
10W typical, Power management mode: 1.2W maximum Energy Effi ciency Class: A
260.5 × 183.5 × 39.5mm / 10.3 × 7.2 × 1.5" (W×H*
1.4kg / 3.1lbs (Excluding the AC Adapter) Operating:
Storage:
Temperature Humidity Temperature Humidity
0 to 40°C / 32 to 104°F 20 to 80% (No condensation)
-20 to 60°C / -4 to 140°F 10 to 90% (No condensation)
3
×D)
2
*
NOTE
* *
26 APPENDIX
1
USB peripherals is not connected.
2
IP65 Standard Compliant : Only front face
3
Excluding the Cable cover.
SPECIFICATIONS : ProLite TF1515MC-B2
Technology Projected capacitive 10pt touch
Touch Screen
Light transmission Communication system Surface fi nish Anti fi ngerprint coating
Size Category 15"
Panel technology Size Diagonal: 15" (38cm) Pixel pitch 0.297mm H × 0.297mm V
LCD Panel
Brightness
Contrast ratio 800 : 1 (Typical) Viewable angle Horizontal : 160 degrees, Vertical: 150 degrees (Typical)
Response time 8ms (Black, White, Black Typical) Display Colors Approx.16.2M Sync Frequency Horizontal: 31.4-60.0kHz, Vertical: 56-75Hz Maximum Resolution 1024 × 768, 0.8 MegaPixels Input Connector VGA, HDMI, DisplayPort Plug & Play VESA DDC2B Input Sync Signal Separate sync: TTL, Positive or Negative
Input Video Signal
Headphone connector ø 3.5mm mini jack (Stereo) External control pad Connector RJ45 Maximum Screen Size 304.1mm W × 228.1mm H / 12.0" W × 9.0" H Power Source 12VDC, 1.5A AC Adapter (accessory) Input: 100-240VAC 50/60Hz
Power Consumption*
1
Dimensions / Net Weight
Environmental Considerations
Approvals CB, CE, TÜV-Bauart, CU, cULus, IP65*
1
*
NOTE
USB peripherals is not connected.
2
IP65 Standard Compliant : Only front face
*
90% USB
TN
2
350cd/m
(Typical: without Touch panel),
315cd/m2 (Typical: with Touch panel)
TM
Analog: 0.7Vp-p (Standard), 75

Positive
Digital: HDMI, DisplayPort
16W typical, Power management mode: 1.2W maximum Energy Effi ciency Class: A
364.0 × 291.0 × 41.5mm / 14.3 × 11.5 × 1.6" (W×H×D)
2.9kg / 6.4lbs (Excluding the AC Adapter) Operating:
Storage:
Temperature Humidity Temperature Humidity
0 to 40°C / 32 to 104°F 20 to 80% (No condensation)
-20 to 60°C / -4 to 140°F 10 to 90% (No condensation)
2
ENGLISH
APPENDIX 27
SPECIFICATIONS : ProLite TF2215MC-B2
Technology Projected capacitive 10pt touch
Touch Screen
Light transmission Communication system Surface fi nish Anti fi ngerprint coating
Size Category 22"
Panel technology Size Diagonal: 21.5" (54.6cm) Pixel pitch 0.24795mm H × 0.24795mm V
LCD Panel
ENGLISH
Brightness
Contrast ratio 1000 : 1 (Typical) Viewable angle Horizontal: 178 degrees, Vertical: 178 degrees (Typical)
Response time 14ms (Black, White, Black Typical) Display Colors Approx.16.7M Sync Frequency Horizontal: 31.4-82.0kHz, Vertical: 56-75Hz Maximum Resolution 1920 × 1080, 2.1 MegaPixels Input Connector VGA, HDMI, DisplayPort Plug & Play VESA DDC2B Input Sync Signal Separate sync: TTL, Positive or Negative
Input Video Signal
Headphone connector ø 3.5mm mini jack (Stereo) External control pad Connector RJ45 Maximum Screen Size 476.064mm W × 267.786mm H / 18.7" W × 10.5" H Power Source 12VDC, 2A AC Adapter (accessory) Input: 100-240VAC 50/60Hz
Power Consumption*
1
Dimensions / Net Weight
Environmental Considerations
Approvals CB, CE, TÜV-Bauart, CU, cULus, IP65*
90% USB
IPS
2
350cd/m 315cd/m
Analog: 0.7Vp-p (Standard), 75
(Typical: without Touch panel),
2
(Typical: with Touch panel)
TM
Positive

Digital: HDMI, DisplayPort
19W typical, Power management mode: 1.2W maximum Energy Effi ciency Class: A
520.0 × 315.0 × 42.5mm / 20.5 × 12.5 × 1.7" (W×H×D)
4.4kg / 9.7lbs (Excluding the AC Adapter) Operating:
Storage:
Temperature Humidity Temperature Humidity
0 to 40°C / 32 to 104°F 20 to 80% (No condensation)
-20 to 60°C / -4 to 140°F 10 to 90% (No condensation)
2
*
NOTE
*
28 APPENDIX
1
USB peripherals is not connected.
2
IP65 Standard Compliant : Only front face
SPECIFICATIONS : ProLite TF2415MC-B2
Technology Projected capacitive 10pt touch
Touch Screen
Light transmission Communication system Surface fi nish Anti fi ngerprint coating
Size Category 23.8"
Panel technology Size Diagonal: 23.8" (60.5cm) Pixel pitch 0.2745mm H × 0.2745mm V
LCD Panel
Brightness
Contrast ratio 3000 : 1 (Typical) Viewable angle Horizontal: 178 degrees, Vertical: 178 degrees (Typical)
Response time 16ms (Black, White, Black Typical) Display Colors Approx.16.7M Sync Frequency Horizontal: 31.4-82.0kHz, Vertical: 56-75Hz Maximum Resolution 1920 × 1080, 2.1 MegaPixels Input Connector VGA, HDMI, DisplayPort Plug & Play VESA DDC2B Input Sync Signal Separate sync: TTL, Positive or Negative
Input Video Signal
Headphone connector ø 3.5mm mini jack (Stereo) External control pad Connector RJ45 Maximum Screen Size 527.04mm W × 296.46mm H / 20.7" W × 11.7" H Power Source 12VDC, 2.5A AC Adapter (accessory) Input: 100-240VAC 50/60Hz
Power Consumption*
1
Dimensions / Net Weight
Environmental Considerations
Approvals CB, CE, TÜV-Bauart, CU, cULus, IP65*
90% USB
VA
2
350cd/m 315cd/m
Analog: 0.7Vp-p (Standard), 75
(Typical: without Touch panel),
2
(Typical: with Touch panel)
TM
Positive

Digital: HDMI, DisplayPort
25W typical, Power management mode: 1.2W maximum Energy Effi ciency Class: A
575.0 × 347.0 × 42.5mm / 22.6 × 13.7 × 1.7" (W×H×D)
5.8kg / 12.8lbs (Excluding the AC Adapter) Operating:
Storage:
Temperature Humidity Temperature Humidity
0 to 40°C / 32 to 104°F 20 to 80% (No condensation)
-20 to 60°C / -4 to 140°F 10 to 90% (No condensation)
2
ENGLISH
NOTE
1
*
USB peripherals is not connected.
2
IP65 Standard Compliant : Only front face
*
APPENDIX 29
DIMENSIONS : ProLite TF1015MC
260.5mm/10.3”
255.5mm/10.1”
91.5mm/3.6”
ENGLISH
DIMENSIONS : ProLite TF1515MC
364.0mm/14.3”
357.5mm/14.1”
147.0mm/5.8”
178.0mm/7.0”
183.5mm/7.2”
284.5mm/11.2”
291.0mm/11.5”
39.5mm/1.5”
41.5mm/1.6”
70.25mm/2.7”
31.75mm/1.2”
120.0mm/4.7”31.75mm/1.2”
4xM4 SCREW HOLE (VESA MOUNT)
122.0mm/4.8”
87.0mm/3.4”
120.0mm/4.7”
120.0mm/4.7”
100.0mm/3.9”
69.5mm/2.7”
55.0mm/2.2”
169.5mm/6.7”
120.0mm/4.7”
100.0mm/3.9”
69.5mm/2.7”
57.5mm/2.2”
169.5mm/6.7”
70.25mm/2.7”
36.5mm/1.4”
100.0mm/3.9”
80.25mm/3.1”
122.0mm/4.8”
89.5mm/3.5”
100.0mm/3.9”
30 APPENDIX
84.0mm/3.3”
4xM4 SCREW HOLE (VESA MOUNT)
132.0mm/5.2”
DIMENSIONS : ProLite TF2215MC
520.0mm/20.5”
515.5mm/20.3”
157.5mm/6.2”
DIMENSIONS : ProLite TF2415MC
575.0mm/22.6”
568.5mm/22.4”
173.5mm/6.8”
42.5mm/1.7”
310.5mm/12.2”
315.0mm/12.5”
42.5mm/1.7”
150.0mm/5.9”
47.5mm/1.9”
220.0mm/8.6”
47.5mm/1.9”
85.0mm/3.3”
113.5mm/4.5”
55.0mm/2.2”
4xM4 SCREW HOLE (VESA MOUNT)
120.0mm/4.7”
220.0mm/8.6” 150.0mm/5.9”
100.0mm/3.9”
69.5mm/2.7”
100.0mm/3.9”
169.5mm/6.7”
210.0mm/8.3”
165.0mm/6.5”
100.0mm/3.9”
69.5mm/2.7”
85.0mm/3.3”
120.0mm/4.7”
102.5mm/4.0”
ENGLISH
118.5mm/4.7”
347.0mm/13.7”
340.5mm/13.4”
120.0mm/4.7”
113.5mm/4.5”
55.0mm/2.2”
169.5mm/6.7”
4xM4 SCREW HOLE
(VESA MOUNT)
100.0mm/3.9”
237.5mm/9.3”
APPENDIX 31
DIMENSIONS : L-BRACKET
ProLite TF1015MC

1.0 mm
Screw holes for fixing the bracket
7.0mm
<Bracket A>
90.0 mm
135.0 mm
          
4.2 mm
M4
<Bracket B>
Screw holes for fixing the bracket
22.0mm
60.0 mm
90.0 mm
135.0 mm
25.2mm
34.0mm
1.6 mm
1.0 mm
M4
12.0mm
120.0 mm
ENGLISH
7.3mm
ProLite TF1515MC / ProLite TF2415MC

1.0 mm
7.0mm
7.3mm
ProLite TF2215MC

Screw holes for
1.0 mm fixing the bracket
7.0mm
80.0 mm
Screw holes for mounting the monitor
<Bracket A>
Screw holes for fixing the bracket
90.0 mm
135.0 mm
120.0 mm
80.0 mm
Screw holes for mounting the monitor
<Bracket A>
180.0 mm
240.0 mm
8.0mm
8.0mm
M4
14.0mm
M4
5.5mm
          
1.6 mm
1.0 mm
M4
12.0mm
14.0mm
M4
11.4mm
4.2 mm
M4
M4
          
2.0 mm
M4
12.0mm
1.0 mm
4.2 mm
M4
Screw holes for mounting the chassis
120.0 mm
<Bracket B>
Screw holes for fixing the bracket
22.0mm
60.0 mm
90.0 mm
135.0 mm
Screw holes for mounting the chassis
78.0 mm
98.0 mm
<Bracket B>
137.5 mm
180.0 mm
240.0 mm
23.0mm
20.0mm
25.2mm
34.0mm
20.0mm
Screw holes for fixing the bracket
25.2mm
35.0mm
6.65mm
Screw holes for mounting the monitor
32 APPENDIX
220.0 mm
Screw holes for
M4
14.0mm
M4
8.35mm
200.0 mm
mounting the chassis
20.0mm
COMPLIANT TIMING : ProLite TF1015MC
Video Mode
640 × 480 31.469kHz 59.940Hz 25.175MHz
800 × 600 37.879kHz 60.317Hz 40.000MHz 1024 × 768 48.363kHz 60.004Hz 65.000MHz 1280 × 800 49.702kHz 59.910Hz 83.500MHz
Horizontal
Frequency
Vertical
Frequency
Dot Clock
COMPLIANT TIMING : ProLite TF1515MC / ProLite TF2215MC / ProLite TF2415MC
Video Mode
640 × 480
800 × 600
1024 × 768
1280 × 1024
1280 × 800 49.702kHz 59.910Hz 83.500MHz *
1680 × 1050 65.290kHz 60.000Hz 146.250MHz * 1920 × 1080 66.590kHz 59.930Hz 138.500MHz *
Horizontal
Frequency
31.469kHz 59.940Hz 25.175MHz
37.500kHz 75.000Hz 31.500MHz
37.861kHz 72.809Hz 31.500MHz
35.156kHz 56.250Hz 36.000MHz
37.879kHz 60.317Hz 40.000MHz
46.875kHz 75.000Hz 49.500MHz
48.077kHz 72.188Hz 50.000MHz
48.363kHz 60.004Hz 65.000MHz
56.476kHz 70.069Hz 75.000MHz
60.023kHz 75.029Hz 78.750MHz
63.981kHz 60.020Hz 108.000MHz *
79.976kHz 75.025Hz 135.000MHz *
Vertical
Frequency
Dot Clock
ENGLISH
NOTE
*
Not compliant to ProLite TF1515MC.
APPENDIX 33
M198B22
Loading...
