User Manual
Edition: 2013-08-13
Draco
KVM Extender
Model:
K481 Series
IHSE GmbH
Maybachstrasse 11
88094 Oberteuringen
Germany
info@ihse.de
www.ihse.de
Tel. +49 7546-9248-0
Fax +49 7546-9248-48
Draco KVM Extender
Copyright
© 2013. All rights reserved. This information may not be reproduced in any
manner without the prior written consent of the manufacturer.
Information in this document is subject to change without notice.
Trademarks
All trademark and trade names mentioned in this document are
acknowledged to be the property of their respective owners.
Disclaimer
While every precaution has been taken during preparation of this manual,
the manufacturer assumes no liability for errors or omissions. Neither does
the manufacturer assume any liability for damages resulting from the use
of the information contained herein.
The manufacturer reserves the right to change specifications, functions, or
circuitry of the product without notice.
The manufacturer cannot accept liability for damage due to misuse of the
product or due to any other circumstances outside the manufacturer’s
control (whether environmental or installation related). The manufacturer
shall not be liable for any loss, damage, or injury arising directly, indirectly,
incidentally, or consequently from the use of this product.
2 2013-08-13
Contents
Contents
1 About This Manual ....................................................................... 7
1.1 Scope.................................................................................. 7
1.2 Validity ................................................................................ 7
1.3 Cautions and Notes ............................................................ 7
2 Safety Instructions....................................................................... 8
3 Description ................................................................................... 9
3.1 Application .......................................................................... 9
3.2 System Overview .............................................................. 10
3.3 Product Range .................................................................. 11
3.3.1 Part Numbers ...................................................... 11
3.3.2 Chassis ............................................................... 11
3.3.3 KVM Extender Modules ...................................... 12
3.3.4 Upgrade Modules................................................ 13
3.3.5 Devices for free configuration ............................. 14
3.4 Accessories Upgrade Kits ................................................. 15
3.5 Accessories....................................................................... 16
3.6 Device Views .................................................................... 16
3.6.1 2-fold Vario Chassis 474-BODY2/2R .................. 16
3.6.2 2-fold Vario Chassis 474-BODY2N ..................... 17
3.6.3 4-fold Vario Chassis 474-BODY4/4R .................. 18
3.6.4 6-fold Vario Chassis 474-BODY6R ..................... 19
3.6.5 6-fold Vario Chassis 474-BODY6BP................... 20
3.6.6 21-fold Vario Chassis 474-BODY21R ................. 21
3.6.7 Model L- / R481-BHHC ....................................... 22
3.6.8 Model L- / R481-BHHCR..................................... 22
3.6.9 Model L481-BHHCL ............................................ 23
3.6.10 Model L481-BHHCLR ......................................... 23
3.6.11 Model L- / R481-BHHS ....................................... 24
3.6.12 Model L- / R481-BHHSR..................................... 24
3.6.13 Model L481-BHHSL ............................................ 25
2013-08-13 3
Draco KVM Extender
3.6.14 Model L481-BHHSLR ......................................... 25
3.6.15 Model R481-BHHCW.......................................... 26
3.6.16 Model R481-BHHCWR ....................................... 26
3.6.17 Model R481-BHHSW .......................................... 27
3.6.18 Model R481-BHHSWR ....................................... 27
3.6.19 Model L- / R481-BHXC ....................................... 28
3.6.20 Model L- / R481-BHXS ....................................... 28
3.6.21 Model L- / R474-BXH.......................................... 29
3.6.22 Model L- / R474-BXE .......................................... 29
3.6.23 Model L- / R474-BUE.......................................... 29
3.6.24 Model L- / R474-BAX .......................................... 30
3.6.25 Model L- / R474-BAP .......................................... 30
3.6.26 Model L- / R474-BXP .......................................... 31
3.6.27 Model L- / R474-BDX.......................................... 31
3.6.28 Model L- / R474-BAH.......................................... 32
3.6.29 Model L- / R474-BDH.......................................... 32
3.6.30 Model L- / R474-BAE .......................................... 32
3.6.31 Model L- / R474-BDE.......................................... 33
3.6.32 Model L- / R474-BSX .......................................... 33
3.6.33 Model L- / R474-BDD.......................................... 34
3.6.34 Modell L- / R474-BDA ......................................... 34
3.6.35 Modell L- / R474-BXTC....................................... 35
3.6.36 Modell L- / R474-BXTS ....................................... 35
3.7 Status LEDs ...................................................................... 36
3.7.1 Status KVM Extender Module............................. 36
3.7.2 Status Upgrade Module Digital Audio ................. 38
3.7.3 Status Upgrade Module USB-HID....................... 39
3.7.4 Status Upgrade module USB 2.0 embedded ...... 40
3.7.5 Status Upgrade Module USB 2.0 ........................ 41
4 Installation .................................................................................. 42
4.1 Package Contents............................................................. 42
4.2 System Setup.................................................................... 44
4 2013-08-13
Contents
4.2.1 KVM Extender Setup .......................................... 44
4.2.2 Setup of Upgrade Modules ................................. 45
4.3 Example Applications........................................................ 46
4.4 Operating Modes .............................................................. 48
4.5 Overview Upgrade Modules.............................................. 49
5 Configuration.............................................................................. 50
5.1 Transmission Parameters ................................................. 50
5.2 DDC Settings .................................................................... 50
5.3 Command Mode ............................................................... 51
5.4 USB-HID Ghosting............................................................ 53
5.5 Configuration File.............................................................. 54
5.5.1 Parameters for CPU Units................................... 54
5.5.2 Parameters for CON Units .................................. 55
5.5.3 Parameters for CPU und CON Units................... 56
6 Operation .................................................................................... 57
6.1 Download of DDC Information .......................................... 57
6.2 Parallel Operation of redundant CPU Units....................... 57
6.3 Local KVM Switching ........................................................ 59
7 Specifications............................................................................. 60
7.1 Interfaces .......................................................................... 60
7.1.1 HDMI Single Link ................................................ 60
7.1.2 USB-HID ............................................................. 60
7.1.3 PS/2 .................................................................... 61
7.1.4 USB 2.0 (transparent) ......................................... 61
7.1.5 RJ45 (Interconnect) ............................................ 62
7.1.6 Fiber SFP Type LC (Interconnect) ...................... 62
7.1.7 Serial Interface.................................................... 62
7.1.8 Analog Audio Interface........................................ 63
7.1.9 Serial Interface RS422 ........................................ 64
7.1.10 Digital Audio Interface......................................... 65
7.2 Interconnect Cable............................................................ 66
7.2.1 Cat X ................................................................... 66
2013-08-13 5
Draco KVM Extender
7.2.2 Fiber.................................................................... 68
7.3 Supported Peripherals ...................................................... 69
7.3.1 USB-HID Devices ............................................... 69
7.3.2 USB 2.0 Devices ................................................. 69
7.4 Connector Pinouts ............................................................ 70
7.5 Power Supply.................................................................... 74
7.6 Environmental Conditions ................................................. 74
7.7 Size................................................................................... 75
7.8 Shipping Weight................................................................ 76
8 Troubleshooting......................................................................... 77
8.1 General Failures ............................................................... 77
8.2 Blank Screen..................................................................... 78
8.3 USB-HID ........................................................................... 79
8.4 Serial Connection.............................................................. 80
8.5 Analog Audio..................................................................... 80
8.6 Digital Audio...................................................................... 81
8.7 Upgrade Module USB-HID................................................ 82
8.8 USB 2.0 embedded........................................................... 83
8.9 USB 2.0............................................................................. 84
9 Technical Support ...................................................................... 85
9.1 Support Checklist.............................................................. 85
9.2 Shipping Checklist ............................................................ 85
10 Certificates.................................................................................. 86
10.1 CE Declaration Of Conformity........................................... 86
10.2 North American Regulatory Compliance........................... 87
10.3 Product Safety ..................................................................88
10.4 WEEE ............................................................................... 88
10.5 RoHS/RoHS 2................................................................... 88
11 Glossary...................................................................................... 89
Pos: 1 /806-IHSE/Zu diesem Handbuch/ATB_Zu diesem Handbuc h @ 5\mod_1278573163276_6. doc @ 41510 @ 1222 @ 1
6 2013-08-13
About This Manual
1 About This Manual
1.1 Scope
This manual describes how to install your KVM Extender, how to operate it
and how to perform trouble shooting.
1.2 Validity
This manual is valid for all devices listed on the front page. The product
code is printed on the base of the devices.
1.3 Cautions and Notes
The following symbols are used in this manual:
This symbol indicates an important operating instruction that should be
followed to avoid any potential damage to hardware or property, loss of
data, or personal injury.
This symbol indicates important information to help you make the best use
of this product.
This symbol indicates best practice information to show recommended
and optimal ways to use this product in an efficient way.
Pos: 2 /806-IHSE/Sicherheitshinweise/ATB_Sic herheitshinweise @ 5\m od_1278573321245_6. doc @ 41528 @ 1 @ 1
2013-08-13 7
Draco KVM Extender
2 Safety Instructions
To ensure reliable and safe long-term operation of your KVM Extender
please note the following guidelines:
Installation
Only use in dry, indoor environments.
The KVM Extender and the power supply units can get warm. Do not
situate them in an enclosed space without any airflow.
Do not place the power supply directly on top of the device.
Do not obscure ventilation holes.
Only use power supplies originally supplied with the product or
manufacturer-approved replacements. Do not use a power supply if it
appears to be defective or has a damaged chassis.
Connect all power supplies to grounded outlets. In each case, ensure
that the ground connection is maintained from the outlet socket
through to the power supply's AC power input.
Do not connect the link interface to any other equipment, particularly
network or telecommunications equipment.
Take any required ESD precautions.
In order to disconnect the device completely from the electric circuit, all
power cables have to be removed.
Repair
Do not attempt to open or repair a power supply unit.
Do not attempt to open or repair the KVM Extender. There are no
user serviceable parts inside.
Please contact your dealer or manufacturer if there is a fault.
Pos: 3 /806-IHSE/Beschreibung/UEB_Beschreibung @ 5\ mod_1278573379151_6. doc @ 41546 @ 1 @ 1
8 2013-08-13
Description
3 Description
Pos: 4 /806-IHSE/Beschreibung/Verwendungszweck/ 474-xx @ 6\mod_1304579 672848_6.doc @ 50785 @ @ 1
3.1 Application
The KVM Extender is used to increase the distance between a source
(computer, CPU) and its console (keyboard, mouse, and other peripheral
devices).
The KVM Extender is designed for use with Cat X (Twisted Pair)
interconnect cables or fiber interconnect cables.
The KVM Extender with Cat X interconnect cables is unsuitable for
connection between buildings where a fiber optic based product should be
used instead.
The KVM Extender with fiber interconnect cables can also be used with
applications in environments which are difficult in electromagnetical
aspects. Electromagnetical interference can limit the maximum distance
und reliability.
Pos: 5 /806-IHSE/Beschreibung/System-Übersic ht /474-xx @ 6\mod_1304579 735410_6.doc @ 50803 @ @ 1
2013-08-13 9
Draco KVM Extender
3.2 System Overview
The KVM Extender consists of at least one CPU module and one
CON module. The various modules are summarized respectively in a
vario chassis (2-fold, 4-fold or 6-fold) at CPU site and CON site (CPU and
CON unit).
The CPU module is connected directly to the source (computer, CPU)
using the supplied cables.
The CON module is connected to the console (monitor, keyboard and
mouse).
The CPU Unit and the CON modules communicate with each other
through the interconnect cables.
1
2
3
4
5
6
7
System Overview
1 Source (computer, CPU)
2 KVM Extender CPU Unit
3 Interconnect cable
4 KVM Extender CON Unit
5 Console (monitor, keyboard, mouse)
6 Second monitor (option, only with Dual-Head devices)
7 USB-HID devices (option, only with 4x USB-HID devices)
See Chapter 4.3, Page 46 for installation examples.
Pos: 6 /806-IHSE/Beschreibung/Gerätetypen/481- xx @ 9\mod_136782545021 0_6.doc @ 71653 @ 233333 @ 1
10 2013-08-13
Description
3.3 Product Range
3.3.1 Part Numbers
Part numbers for Connections via Cat X or Fiber Cable
All mentioned devices are available in the following versions:
Connection via Cat X cable (x = "C")
Connection via Single-mode fiber cable (x = "S")
High speed connection (3.125 Gbit/s) via Single-mode fiber cable
(x = "X")
Fiber devices can be used with Multi-mode and Single-mode cables (see
Chapter 7.2.2, Page 68).
Part numbers for CPU Unit and CON Unit
The part numbers for the CPU Unit and the CON Unit can be derived from
the part number of the complete device.
CPU Unit: L481
CON Unit: R481
All devices of the K481 series are technically compatible to the devices of
the K474 and K477 series.
3.3.2 Chassis
Model Description
474-BODY2
474-BODY2R
474-BODY2N
474-BODY4
474-BODY4R
Empty chassis for up to 2 boards, 1x external power
supply unit
Empty chassis for up to 2 boards, 1x external power
supply unit, preparation for redundancy for a second
power supply unit (external)
Empty chassis for up to 2 boards, 1x internal power
supply unit, preparation for redundancy for a second
power supply unit (external)
Empty chassis for up to 4 boards, 1x external power
supply unit
Empty chassis for up to 4 boards, 1x external power
supply unit, preparation for redundancy for a second
power supply unit (external)
2013-08-13 11
Draco KVM Extender
Model Description
474-BODY6R
Empty chassis for up to 6 boards, 1x internal power
supply unit, preparation for redundancy for a second
power supply unit (external)
474BODY6BP
474BODY21/4U
Empty chassis for up to 6 boards, active backplane, 2x
internal power supply unit (redundancy)
Empty chassis for up to 21 boards, 1x internal power
supply unit, preparation for redundancy for a second
power supply unit (internal)
3.3.3 KVM Extender Modules
Model Description
L481-BHHx
R481-BHHx
L481-BHHxR
R481-BHHxR
L481-BHHxL
L481BHHxLR
R481-BHHxW
R481BHHxWR
L481-BHXx
R481-BHXx
Single-Head KVM Extender for 1x HDMI Single Link
(up to 1920x1200), 2x USB-HID
Single-Head module for 1x HDMI Single Link
(up to 1920x1200) with 2x USB-HID and redundant
connector for interconnect cables
Single-Head KVM Extender for 1x HDMI Single Link
(up to 1920x1200), 2x USB-HID and local output
Single-Head KVM Extender for 1x HDMI Single Link
(up to 1920x1200), 2x USB-HID, local output and
redundant connector for interconnect cables
Single-Head KVM Extender for 1x HDMI Single Link
(up to 1920x1200), 2x USB-HID, KVM switch for local
workstation
Single-Head KVM Extender for 1x HDMI Single Link
(up to 1920x1200), 2x USB-HID, KVM switch for local
workstation and redundant connector for interconnect
cables
Single-Head KVM Extender for 1x HDMI Single Link (up
to 1920x1200)
12 2013-08-13
Description
3.3.4 Upgrade Modules
Model Description
L474-BXH
R474-BXH
L474-BXE
R474-BXE
L474-BAX
R474-BAX
L474-BAP
R474-BAP
L474-BSX
R474-BSX
L474-BXP
R474-BXP
L474-BDX
R474-BDX
L474-BAH
R474-BAH
L474-BUE
R474-BUE
L474-BAE
R474-BAE
L474-BDH
R474-BDH
L474-BDE
R474-BDE
L474-BDD
R474-BDD
L474-BDA
R474-BDA
L474-BXTx
R474-BXTx
Upgrade module with 2x USB-HID
Upgrade module with 2x USB 2.0
Upgrade module with Analog Audio / Serial
(bidirectional)
Upgrade module with Analog Audio / Serial
(bidirectional) and PS/2
Upgrade module with serial connector (RS422)
Upgrade module with PS/2 (only available with upgrade
module Analog Audio / Serial)
Upgrade module with Digital Audio (unidirectional)
Upgrade module with Analog Audio / Serial
(bidirectional) and 2x USB-HID
Upgrade module with Analog Audio (bidirectional) and
2x USB 2.0
Upgrade module with Analog Audio / Serial
(bidirectional) and 2x USB 2.0
Upgrade module with Digital Audio (unidirectional) and
2x USB-HID
Upgrade module with Digital Audio (unidirectional) and
2x USB 2.0
Upgrade module with Digital Audio (bidirectional)
Upgrade module with Digital Audio (unidirectional) and
Analog Audio / Serial (bidirectional)
USB 2.0 upgrade module with 4x USB 2.0
2013-08-13 13
Draco KVM Extender
3.3.5 Devices for free configuration
Model Description
Pos: 7 /806-IHSE/Beschreibung/Einbauoptionen/ 474-xx @ 6\mod_13045800 08551_6.doc @ 50839 @ 2 @ 1
DRACO
VARIO 2
DRACO
VARIO 2R
DRACO
VARIO 2N
DRACO
VARIO 4
DRACO
VARIO 4R
DRACO
VARIO 6R
DRACO
VARIO 6BP
DRACO
VARIO 21/4U
DRACO
VARIO 21/3U
When using redundant power supply units, there will be a load sharing.
Draco extender for free configuration in a 2-slot vario
chassis, external power supply unit
Draco extender for free configuration in a 2-slot vario
chassis, external power supply unit, preparation for
redundancy for a second external power supply unit
Draco extender for free configuration in a 2-slot vario
chassis, internal power supply unit, preparation for
redundancy of an external power supply unit
Draco extender for free configuration in a 4-slot vario
chassis, external power supply unit
Draco extender for free configuration in a 4-slot vario
chassis, external power supply unit, preparation for
redundancy of a second external power supply unit
Draco extender for free configuration in a 6-slot vario
chassis, internal power supply unit, preparation for
redundancy of an external power supply unit
Draco extender for free configuration in a 6-slot vario
chassis, active backplane, 2x internal power supply unit
(redundancy)
Draco extender for free configuration in a 21-slot 4U
vario chassis, internal power supply unit, preparation for
redundancy for a second external power supply unit
Draco extender for free configuration in a 21-slot 3U
vario chassis, internal power supply unit, preparation for
redundancy for a second external power supply unit
14 2013-08-13
Description
3.4 Accessories Upgrade Kits
Model Description
474-2RMK 19"/1U rack mount kit for 2-fold chassis
Pos: 8 /806-IHSE/Beschreibung/Zubehör/481-xx @ 9\ mod_1367826991670_6.d oc @ 71673 @ 2 @ 4
4742NRMK
474-4RMK 19"/1U rack mount kit for 4-fold chassis
474-6RMK 19"/1U rack mount kit for 6-fold chassis
474-
VPLATE
474-
OPTRED
474-PSU2 Power supply for 2-fold chassis (spare or redundancy)
474-PSU4 Power supply for 4-fold chassis (spare or redundancy)
474-PSU6 Power supply for 6-fold chassis (spare or redundancy)
474-PSU21 Power supply for 6-fold-chassis (spare or redundancy)
474-BLND1 Blind plate 3U/4HP for 2-, 4- and 6-fold chassis
474-BLND2 Blind plate 3U/8HP for 2-, 4- and 6-fold chassis
The KVM Extenders and the provided power supply units can get warm,
for this reason an installation in closed rooms without air circulation is not
allowed. Please note that you will need at least 0.5 U (height unit) for the
ventilation above the extenders, if you mount them into racks.
19"/1U rack mount kit for 2-fold chassis with internal PSU
Fastening strips for screw or snap on for 2-, 4- and 6-fold
chassis
Retrofitting for redundant power supply option (without
power supply) for 2- and 4-fold chassis
2013-08-13 15
Draco KVM Extender
3.5 Accessories
Model Description
026-2A Serial cable 1.8 m (RS232)
247-U1 USB cable 1.8 m (Type A to B)
260-5G International power supply unit 100...240VAC / 5VDC / 3 A
260-5U International power supply unit 100...240VAC / 5VDC / 4 A
436-AA VGA cable 1.8 m (VGA to DVI-I)
436-HD HDMI cable 1.8 m (DVI-D)
436-DVHD Adapter DVI-D male to HDMI female
445-2H DVI-D splitter cable
455-CK Stereo jack cable 1.6 m (3.5 mm Stereo)
455-CR RCA cable 2.5 m (Cinch male connector)
455-CT TOSLINK cable 1.8 m (F05 male connector)
455-CX Mini-XLR cable 1.8 m (3 pole)
Pos: 9 /806-IHSE/Beschreibung/Geräteansichten/ UEB_Geräteansic hten @ 5\mod_12785737378 08_6.doc @ 41654 @ 2 @ 1
3.6 Device Views
Pos: 10 /806-IHSE/Beschreibung/Geräteansichte n/474-xx/2-fac h Vario-Gehäuse 474-BODY2/ 2R @ 6\mod_130458028056 6_6.doc @ 50858 @ 3 @ 1
3.6.1 2-fold Vario Chassis 474-BODY2/2R
CPU and CON Unit
3
1
4
2
Rear View
1 Slot for modules #1
2 Connect to 5VDC power supply (standard)
3 Slot for modules #2
4 Connect to 5VDC power supply (redundancy, optional)
Pos: 11 /806-IHSE/Beschreibung/Geräteansichte n/474-xx/2-fac h Vario-Gehäuse 474-BODY2 N @ 8\mod_1348578478411_6. doc @ 69380 @ 3 @ 1
16 2013-08-13
Description
3.6.2 2-fold Vario Chassis 474-BODY2N
CPU and CON Unit
3
4
Pos: 12 /806-IHSE/zz_Layout/Seitenumbruch @ 8\ mod_1348581820516_0.doc @ 69462 @ @ 1
1
2
Rear View
1 Slot for modules #1
2 Connect to power supply (standard)
3 Slot for modules #2
4 Connect to 5VDC power supply (redundancy)
The 2-fold vario chassis with an internal power supply is not equipped with
a fuse on primary side. Therefore the protection against excessive
currents has to be provided by the electrical installation of the building.
2013-08-13 17
Draco KVM Extender
Pos: 13 /806-IHSE/Beschreibung/Geräteansichte n/474-xx/4-fac h Vario-Gehäuse 474-BODY4/ 4R @ 6\mod_130458035909 8_6.doc @ 50876 @ 3 @ 1
3.6.3 4-fold Vario Chassis 474-BODY4/4R
CPU and CON Unit
Pos: 14 /806-IHSE/zz_Layout/Seitenumbruch @ 8\ mod_1348581820516_0.doc @ 69462 @ @ 1
4
1
5
2
6
3
Rear View
1 Slot for modules #3
2 Slot for modules #1
3 Connect to 5VDC power supply (standard)
4 Slot for modules #4
5 Slot for modules #2
6 Connect to 5VDC power supply (redundancy, optional)
For operation with three KVM Extender CON modules and a USB 2.0
CON module in a 4-fold vario chassis, an external power supply unit at the
second 5VDC connector is explicitly necessary. In this case, redundancy
is inapplicable.
18 2013-08-13
Description
Pos: 15 /806-IHSE/Beschreibung/Geräteansichte n/474-xx/6-fac h Vario-Gehäuse 474-BODY6 R @ 6\mod_1304580442488_6. doc @ 50894 @ 3 @ 1
3.6.4 6-fold Vario Chassis 474-BODY6R
CPU and CON Unit
Pos: 16 /806-IHSE/zz_Layout/Seitenumbruch @ 8\ mod_1348581820516_0.doc @ 69462 @ @ 1
6
1
7
2
8
3
5
4
Rear View
1 Slot for modules #5
2 Slot for modules #3
3 Slot for modules #1
4 Connect to power supply (standard)
5 Connect to 5VDC power supply (standard)
6 Slot for modules #6
7 Slot for modules #4
8 Slot for modules #2
For operation with KVM Extender modules in a 6-fold vario chassis, an
external power supply unit at the 5VDC connector is explicitly necessary.
In this case, redundancy is inapplicable.
The 6-fold vario chassis is not equipped with a fuse on primary side.
Therefore the protection against excessive currents has to be provided by
the electrical installation of the building.
2013-08-13 19
Draco KVM Extender
Pos: 17 /806-IHSE/Beschreibung/Geräteansichte n/481-xx/6-fac h Vario-Gehäuse 474-BODY6B P @ 9\mod_1367827188730_6. doc @ 71694 @ 3 @ 4
3.6.5 6-fold Vario Chassis 474-BODY6BP
CPU and CON Unit
Front View
1 Connect to power supply 1
2 Connect to power supply 2 (redundancy)
3 Grounding
Rear View
1 Slot for modules #5
2 Slot for modules #3
3 Slot for modules #1
4 Slot for modules #6
5 Slot for modules #4
6 Slot for modules #2
Pos: 18 /806-IHSE/Beschreibung/Geräteansichte n/474-xx/21-fac h Vario-Gehäuse 474-BODY 21R @ 8\mod_1348579151346_ 6.doc @ 69400 @ 3 @ 1
123
45
1
2
6
3
20 2013-08-13
Description
3.6.6 21-fold Vario Chassis 474-BODY21R
CPU and CON Unit
Pos: 19 /806-IHSE/zz_Layout/Seitenumbruch @ 8\ mod_1348581820516_0.doc @ 69462 @ @ 1
1
Rear View
1 Slots for modules #1 - #21
2
1
Front View
1 Connect to power supply 2
2 Locking for power supply 2 (redundancy)
3 Locking for power supply 1 (standard)
4 Connect to power supply 1
3
4
2013-08-13 21
Draco KVM Extender
Pos: 20 /806-IHSE/Beschreibung/Geräteansic hten/481-xx/Typ L- / R481-BHHC @ 9\mod_1367828248520_6.doc @ 71714 @ 3 @ 4
3.6.7 Model L- / R481-BHHC
CPU Module CON Module
3412
Rear View Rear View
1 Service port
2 Connect to interconnect cable
3 To CPU: USB-HID
4 To CPU: HDMI
Pos: 21 /806-IHSE/Beschreibung/Geräteansichte n/481-xx/Typ L- / R481-BHHCR @ 9\mod_13739676616 62_6.doc @ 77531 @ 3 @ 4
3.6.8 Model L- / R481-BHHCR
CPU Module CON Module
3
Rear View Rear View
1 Service port
2 Connect to interconnect cable 1
3 Connect to interconnect cable 2
4 To CPU: USB-HID
5 To CPU: HDMI
Pos: 22 /806-IHSE/Beschreibung/Geräteansichte n/481-xx/Typ L481-B HHCL @ 9\mod_136782840239 8_6.doc @ 71734 @ 3 @ 4
2
451
3
21
4
1 Service port
2 Connect to interconnect cable
3 Connect to USB-HID devices
4 Connect to HDMI monitor
3
2
451
1 Service port
2 Connect to interconnect cable 1
3 Connect to interconnect cable 2
4 Connect to USB-HID devices
5 Connect to HDMI monitor
22 2013-08-13
Description
3.6.9 Model L481-BHHCL
CPU Module
43512
Rear View
1 Service port
2 Connect to interconnect cable
3 To CPU: USB-HID
4 To CPU: HDMI
5 Local output: HDMI
Pos: 23 /806-IHSE/Beschreibung/Geräteansichte n/481-xx/Typ L481-B HHCLR @ 9\mod_137396788618 2_6.doc @ 77552 @ 3 @ 4
3.6.10 Model L481-BHHCLR
CPU Module
3
4561
Rear View
1 Service port
2 Connect to interconnect cable 1
3 Connect to interconnect cable 2
4 To CPU: USB-HID
5 To CPU: HDMI
6 Local output: HDMI
Pos: 24 /806-IHSE/Beschreibung/Geräteansichte n/481-xx/Typ L- / R481-BHHS @ 9\mod_13678287426 82_6.doc @ 71754 @ 3 @ 1
2
2013-08-13 23
Draco KVM Extender
3.6.11 Model L- / R481-BHHS
CPU Module CON Module
3412
Rear View Rear View
1 Service port
2 Connect to interconnect cable
3 To CPU: USB-HID
4 To CPU: HDMI
Pos: 25 /806-IHSE/Beschreibung/Geräteansichte n/481-xx/Typ L- / R481-BHHSR @ 9\mod_13739680901 13_6.doc @ 77573 @ 3 @ 4
3.6.12 Model L- / R481-BHHSR
CPU Module CON Module
3
4512
Rear View Rear View
1 Service port
2 Connect to interconnect cable 1
3 Connect to interconnect cable 2
4 To CPU: USB-HID
5 To CPU: HDMI
Pos: 26 /806-IHSE/Beschreibung/Geräteansichte n/481-xx/Typ L481-B HHSL @ 9\mod_136783082113 6_6.doc @ 71774 @ 3 @ 1
3
21
4
1 Service port
2 Connect to interconnect cable
3 Connect to USB-HID devices
4 Connect to HDMI monitor
3
2
451
1 Service port
2 Connect to interconnect cable 1
3 Connect to interconnect cable 2
4 Connect to USB-HID devices
5 Connect to HDMI monitor
24 2013-08-13
Description
3.6.13 Model L481-BHHSL
CPU Module
312 4 5
Rear View
1 Service port
2 Connect to interconnect cable
3 To CPU: USB-HID
4 To CPU: HDMI
5 Local output: HDMI
Pos: 27 /806-IHSE/Beschreibung/Geräteansichte n/481-xx/Typ L481-B HHSLR @ 9\mod_137396823908 3_6.doc @ 77594 @ 3 @ 4
3.6.14 Model L481-BHHSLR
CPU Module
3
45612
Rear View
1 Service port
2 Connect to interconnect cable 1
3 Connect to interconnect cable 2
4 To CPU: USB-HID
5 To CPU: HDMI
6 Local output: HDMI
Pos: 28 /806-IHSE/Beschreibung/Geräteansichte n/481-xx/Typ R481-B HHCW @ 9\mod_13678325175 25_6.doc @ 71794 @ 3 @ 4
2013-08-13 25
Draco KVM Extender
3.6.15 Model R481-BHHCW
CON Module
142 53
Rear View
1 Service port
2 Connect to interconnect cable
3 Connect to USB-HID devices
4 Connect to HDMI monitor
5 Local input: HDMI
Pos: 29 /806-IHSE/Beschreibung/Geräteansichte n/481-xx/Typ R481-B HHCWR @ 9\mod_13739744084 59_6.doc @ 77615 @ 3 @ 4
3.6.16 Model R481-BHHCWR
CON Module
3
4561
Rear View
1 Service port
2 Connect to interconnect cable 1
3 Connect to interconnect cable 2
4 Connect to USB-HID devices
5 Connect to HDMI monitor
6 Local input: HDMI
Pos: 30 /806-IHSE/Beschreibung/Geräteansichte n/481-xx/Typ R481-B HHSW @ 9\mod_13678330271 94_6.doc @ 71814 @ 3 @ 1
2
26 2013-08-13
Description
3.6.17 Model R481-BHHSW
CON Module
14253
Rear View
1 Service port
2 Connect to interconnect cable
3 Connect to USB-HID devices
4 Connect to HDMI monitor
5 Local input: HDMI
Pos: 31 /806-IHSE/Beschreibung/Geräteansichte n/481-xx/Typ R481-B HHSWR @ 9\mod_13739745242 09_6.doc @ 77636 @ 3 @ 4
3.6.18 Model R481-BHHSWR
CON Module
3
45612
Rear View
1 Service port
2 Connect to interconnect cable 1
3 Connect to interconnect cable 2
4 Connect to USB-HID devices
5 Connect to HDMI monitor
6 Local input: HDMI
Pos: 32 /806-IHSE/Beschreibung/Geräteansichte n/481-xx/Typ L- / R481-BHXC @ 9\mod_13678338390 59_6.doc @ 71834 @ 3 @ 4
2013-08-13 27
Draco KVM Extender
3.6.19 Model L- / R481-BHXC
CPU Module CON Module
231
Rear View Rear View
1 Connect to interconnect cable
2 Service Port
3 To CPU: HDMI
Pos: 33 /806-IHSE/Beschreibung/Geräteansichte n/481-xx/Typ L- / R481-BHXS @ 9\mod_136783394559 1_6.doc @ 71854 @ 3 @ 1
3.6.20 Model L- / R481-BHXS
CPU Module CON Module
231
Rear View Rear View
1 Connect to interconnect cable
2 Service Port
3 To CPU: HDMI
The video only modules without USB-HID connection are only meant for
the use with basic extender modules.
Pos: 34 /806-IHSE/zz_Layout/Seitenumbruch @ 8\ mod_1348581820516_0.doc @ 69462 @ @ 1
231
1 Connect to interconnect cable
2 Service Port
3 Connect to HDMI monitor
231
1 Connect to interconnect cable
2 Service Port
3 To CPU: HDMI
28 2013-08-13
Description
Pos: 35 /806-IHSE/Beschreibung/Geräteansichte n/474-xx/Typ L- / R474-BXH @ 6\mod_13045835076 45_6.doc @ 50984 @ 3 @ 1
3.6.21 Model L- / R474-BXH
CPU Module CON Module
1
Rear View Rear View
1 To CPU: USB-HID 1 Connect to USB-HID devices
Pos: 36 /806-IHSE/Beschreibung/Geräteansichten/ 474-xx/Typ L- / R474-BXE @ 7\mod_1331 798896275_6.doc @ 58110 @ 3 @ 1
3.6.22 Model L- / R474-BXE
CPU Module CON Module
1
Rear View Rear View
1 To CPU: USB 2.0 1 Connect to USB 2.0 devices
Pos: 37 /806-IHSE/Beschreibung/Geräteansichte n/474-xx/Typ L- / R474-BUE @ 7\mod_13317990387 17_6.doc @ 58130 @ 3 @ 1
3.6.23 Model L- / R474-BUE
CPU Module CON Module
1
Rear View Rear View
1 To CPU: USB 2.0 1 Audio IN
When using USB audio within a KVM matrix, instant switching is not
possible due to the deregistration and registration process of the USB.
Pos: 38 /806-IHSE/Beschreibung/Geräteansichten/ 474-xx/Typ L- / R474-BAX @ 6\mod_1304 583540285_6.doc @ 51002 @ 3 @ 1
1
1
1
2 3
2 Audio OUT
3 Connect to USB 2.0 devices
2013-08-13 29
Draco KVM Extender
3.6.24 Model L- / R474-BAX
CPU Module CON Module
1
3
2
Rear View Rear View
1 Connect to serial (D-Sub 9)
2 Audio IN
3 Audio OUT
Pos: 39 /806-IHSE/Beschreibung/Geräteansichten/ 474-xx/Typ L- / R474-BAP @ 9\mod_1362 472648439_6.doc @ 71250 @ 3 @ 4
3.6.25 Model L- / R474-BAP
CPU Module CON Module
Rear View Rear View
1 Connect to serial (D-Sub 9)
2 Audio IN
3 Audio OUT
4 To CPU: PS/2 mouse
5 To CPU: PS/2 keyboard
Pos: 40 /806-IHSE/Beschreibung/Geräteansichten/ 474-xx/Typ L- / R474-BXP @ 8\mod_1348 579797358_6.doc @ 69420 @ 3 @ 1
1
3
2
45
123
1 Connect to serial (D-Sub 9)
2 Audio IN
3 Audio OUT
123
1 Connect to serial (D-Sub 9)
2 Audio IN
3 Audio OUT
4 Connect to PS/2 mouse
5 Connect to PS/2 keyboard
45
30 2013-08-13
Description
3.6.26 Model L- / R474-BXP
CPU Module CON Module
1
234
Rear View Rear View
1 Connect to local PS/2 mouse
2 Connect to local PS/2 keyboard
3 To CPU: PS/2 mouse
4 To CPU: PS/2 keyboard
The upgrade module L- / R474-BXP is only available in combination with
the upgrade modules L- / R474-BAX and –BAH. A separate slot is
required for each module.
Pos: 41 /806-IHSE/zz_Layout/Seitenumbruch @ 8\ mod_1348581820516_0.doc @ 69462 @ @ 1
Pos: 42 /806-IHSE/Beschreibung/Geräteansichte n/474-xx/Typ L- / R474-BDX @ 6\mod_13045835778 01_6.doc @ 51020 @ 3 @ 1
3.6.27 Model L- / R474-BDX
CPU Module CON Module
Rear View Rear View
1 S/PDIF input (RCA)
2 AES/EBU input (Mini-XLR)
3 S/PDIF input (TOSLINK)
Pos: 43 /806-IHSE/Beschreibung/Geräteansichte n/474-xx/Typ L- / R474-BAH @ 6\mod_13045836117 85_6.doc @ 51038 @ 3 @ 1
1
3
2
1 Connect to PS/2 mouse
2 Connect to PS/2 keyboard
1
3
2
1 S/PDIF output (RCA)
2 AES/EBU output (Mini-XLR)
3 S/PDIF output (TOSLINK)
1
2
2013-08-13 31
Draco KVM Extender
3.6.28 Model L- / R474-BAH
CPU Module CON Module
1
3
2
4
Rear View Rear View
1 Connect to serial (D-Sub 9)
2 Audio IN
3 Audio OUT
4 To CPU: USB-HID
Pos: 44 /806-IHSE/Beschreibung/Geräteansichte n/474-xx/Typ L- / R474-BDH @ 6\mod_130458364645 7_6.doc @ 51056 @ 3 @ 1
3.6.29 Model L- / R474-BDH
CPU Module CON Module
1
3
2
4
Rear View Rear View
1 S/PDIF input (RCA)
2 AES/EBU input (Mini-XLR)
3 S/PDIF input (TOSLINK)
4 To CPU: USB-HID
Pos: 45 /806-IHSE/Beschreibung/Geräteansichten/ 474-xx/Typ L- / R474-BAE @ 7\mod_1331 799164939_6.doc @ 58150 @ 3 @ 1
3.6.30 Model L- / R474-BAE
CPU Module CON Module
123
4
1 Connect to serial (D-Sub 9)
2 Audio IN
3 Audio OUT
4 Connect to USB-HID devices
1
3
2
4
1 S/PDIF output (RCA)
2 AES/EBU output (Mini-XLR)
3 S/PDIF output (TOSLINK)
4 Connect to USB-HID devices
1
3
2
4
123
4
Rear View Rear View
1 Connect to serial (D-Sub 9)
2 Audio IN
3 Audio OUT
4 To CPU: USB 2.0
Pos: 46 /806-IHSE/Beschreibung/Geräteansichte n/474-xx/Typ L- / R474-BDE @ 8\mod_13485802724 66_6.doc @ 69440 @ 3 @ 1
1 Connect to serial (D-Sub 9)
2 Audio IN
3 Audio OUT
4 Connect to USB 2.0 devices
32 2013-08-13
Description
3.6.31 Model L- / R474-BDE
CPU Module CON Module
1
3
2
4
Rear View Rear View
1 S/PDIF input (RCA)
2 AES/EBU input (Mini-XLR)
3 S/PDIF input (TOSLINK)
4 To CPU: USB 2.0
Pos: 47 /806-IHSE/Beschreibung/Geräteansichten/ 474-xx/Typ L- / R474-BSX @ 9\mod_1362 472913267_6.doc @ 71270 @ 3 @ 4
3.6.32 Model L- / R474-BSX
CPU Module CON Module
1
Rear View Rear View
1 Connect to serial (D-Sub 9) 1 Connect to serial (D-Sub 9)
Pos: 48 /806-IHSE/zz_Layout/Seitenumbruch @ 8\ mod_1348581820516_0.doc @ 69462 @ @ 1
1
3
2
1 S/PDIF output (RCA)
2 AES/EBU output (Mini-XLR)
3 S/PDIF output (TOSLINK)
4 Connect to USB 2.0 devices
1
4
2013-08-13 33
Draco KVM Extender
Pos: 49 /806-IHSE/Beschreibung/Geräteansichte n/474-xx/Typ L- / R474-BDD @ 6\mod_130458369642 6_6.doc @ 51074 @ 3 @ 1
3.6.33 Model L- / R474-BDD
CPU Module CON Module
1
3
2
5
4
6
Rear View Rear View
1 S/PDIF input (RCA)
2 AES/EBU input (Mini-XLR)
3 S/PDIF input (TOSLINK)
4 S/PDIF output (RCA)
5 AES/EBU output (Mini-XLR)
6 S/PDIF output (TOSLINK)
Pos: 50 /806-IHSE/Beschreibung/Geräteansichte n/474-xx/Typ L- / R474-BDA @ 6\mod_13045837534 26_6.doc @ 51092 @ 3 @ 1
3.6.34 Modell L- / R474-BDA
CPU Module CON Module
Pos: 51 /806-IHSE/zz_Layout/Seitenumbruch @ 8\ mod_1348581820516_0.doc @ 69462 @ @ 1
1
Rear View Rear View
1 S/PDIF input (RCA)
2 AES/EBU input (Mini-XLR)
3 S/PDIF input (TOSLINK)
4 Connect to serial (D-Sub 9)
5 Audio IN
6 Audio OUT
3
2
5
4
1
3
2
1 S/PDIF output (RCA)
2 AES/EBU output (Mini-XLR)
3 S/PDIF output (TOSLINK)
4 S/PDIF input (RCA)
5 AES/EBU input (Mini-XLR)
6 S/PDIF input (TOSLINK)
6
1
3
2
1 S/PDIF output (RCA)
2 AES/EBU output (Mini-XLR)
3 S/PDIF output (TOSLINK)
4 Connect to serial (D-Sub 9)
5 Audio IN
6 Audio OUT
5
4
6
5
4
6
34 2013-08-13
Description
Pos: 52 /806-IHSE/Beschreibung/Geräteansichte n/474-xx/Typ L- / R474-BXTC @ 6\mod_13045837845 82_6.doc @ 51110 @ 3 @ 1
3.6.35 Modell L- / R474-BXTC
CPU Module CON Module
12
3
Rear View Rear View
1 Service port
2 Connect to interconnect cable
3 To CPU: USB 2.0
Pos: 53 /806-IHSE/Beschreibung/Geräteansichte n/474-xx/Typ L- / R474-BXTS @ 6\mod_1304583818 676_6.doc @ 51128 @ 3 @ 1
3.6.36 Modell L- / R474-BXTS
CPU Module CON Module
3
Pos: 54 /806-IHSE/zz_Layout/Seitenumbruch @ 8\ mod_1348581820516_0.doc @ 69462 @ @ 1
12
Rear View Rear View
1 Service port
2 Connect to interconnect cable
3 To CPU: USB 2.0
It is only allowed to use one USB 2.0 CON module per chassis.
12
3
4
1 Service port
2 Connect to interconnect cable
3 Connect to USB 2.0 devices
12
3
4
1 Service port
2 Connect to interconnect cable
3 Connect to USB 2.0 devices
2013-08-13 35
Draco KVM Extender
Pos: 55 /806-IHSE/Beschreibung/Diagnose LEDs/ UEB_Diagnose_LEDs @ 6\mod_1304 584004723_6.doc @ 51146 @ @ 1
3.7 Status LEDs
Pos: 56 /806-IHSE/Beschreibung/Diagnose LEDs/481- xx/Diagnose KVM-E xtender-Modul @ 9\mod_1367 834480876_6.doc @ 71875 @ 3 @ 4
3.7.1 Status KVM Extender Module
The KVM Extender module is fitted with a multi color LED on both sides
for overall status indication and with two further LEDs on the back side for
indication of the connection status.
CPU Module CON Module
3
21
3
21
Rear View
Rear View
LED 1 and 2: Connection Status
Pos. LED Status Description
Failure LED
(green)
Status LED
(green)
Off Connection available 1
On or
Flashing
Connection failure (flashing for about
20 s following a connection failure)
Flashing No connection via interconnect cable 2
On Connection available
21
21
12
12 34
3
3
34
36 2013-08-13
Description
LED 3: USB and Video Status
LED color Description
Red Device ready
Violet
Green Connection and video signal available
Light Blue
LED 4: Locally Connected Source Status
LED color Description
Green
Light Blue
Pos: 57 /806-IHSE/Beschreibung/Diagnose LEDs/474- xx/Diagnose Zusatz modul Digital-Audio @ 6\mod_1304584173301_ 6.doc @ 51201 @ 3 @ 1
Connection and USB signal (interconnect) available
Connection, USB and video signal available
(operating status)
Video signal of locally connected source (computer,
CPU) available
Video and USB signal switched from locally
connected source (computer, CPU)
2013-08-13 37
Draco KVM Extender
3.7.2 Status Upgrade Module Digital Audio
The upgrade module digital audio is fitted with a further multi-color LED on
the rear side for indication of the connection status:
CPU Module CON Module
Rear View Rear View
LED 1: Digital Audio Status
LED color Description
Red No signal
Light Blue CPU Unit: S/PDIF signal (RCA) available
Violet CPU Unit: AES/EBU signal (Mini-XLR) available
Blue CPU Unit: S/PDIF signal (TOSLINK) available
Green CON Unit: Signal available
Pos: 58 /806-IHSE/Beschreibung/Diagnose LEDs/474- xx/Diagnose Zusatz modul USB-HID @ 6\mod_130458 4220145_6.doc @ 51219 @ 3 @ 1
1
1
38 2013-08-13
Description
3.7.3 Status Upgrade Module USB-HID
The upgrade module USB-HID is fitted with three further LEDs on the rear
side for indication of the connection status:
CPU Module CON Module
Rear View Rear View
Pos. LED Status Description
1, 2
3
Pos: 59 /806-IHSE/Beschreibung/Diagnose LEDs/474- xx/Diagnose Zusatz modul USB 2.0 embedded @ 7\mod _1331803265129_6.doc @ 58231 @ 3 @ 1
1
23
Device LED
(orange)
Status LED
(orange)
23
1
Off
No USB-HID device or not supported
USB device connected
Flashing
USB-HID device active
fast
On
USB-HID device ready or KVM
Extender in command mode
Off No power supply voltage
CPU Unit: KVM Extender in
command mode or no connection
CON Unit: Keyboard in command
mode
Flashing
slowly
Flashing
CON Unit: KVM Extender in command
mode or no connection
Operating status
fast
2013-08-13 39
Draco KVM Extender
3.7.4 Status Upgrade module USB 2.0 embedded
The upgrade module USB 2.0 embedded is fitted with three further LEDs
on the rear side for indication of the connection status:
CPU Module CON Module
Rear View Rear View
Pos. LED Status Description
2
3
Pos: 60 /806-IHSE/Beschreibung/Diagnose LEDs/474- xx/Diagnose Zusatz modul USB 2.0 @ 6\mod_13045842 54816_6.doc @ 51237 @ 3 @ 1
1
23
Status LED
(green)
Status LED
(green)
Status LED
(green)
Off No USB 2.0 device connected 1
Flashing
slowly
Off
Flashing
slowly
On
Off
On
23
1
USB 2.0 device connected
No connection to source (computer,
CPU) available
Connection to source (computer,
CPU) available
No USB 2.0 device connected
Connection to source (computer,
CPU) available
USB 2.0 device(s) connected
No connection between CON and CPU
module
Connection between CON and CPU
module available
40 2013-08-13
Description
3.7.5 Status Upgrade Module USB 2.0
The upgrade module USB 2.0 is fitted with a multi color LED on both sides
for overall status indication and with two further LEDs on the back side for
indication of the connection status.
CPU Module CON Module
Pos: 61 /806-IHSE/Installation/UEB_Installa tion @ 5\mod_1278574971589 _6.doc @ 41768 @ 1 @ 1
12
3
3
12
Rear View Rear View
Pos. LED Status Description
Failure LED
(green)
Status LED
(green)
Off Connection available 1
On or
Flashing
Connection failure (flashing for about
20 s following a connection failure)
Off No connection via interconnect cable 2
On Connection available
LED 3: USB 2.0 Status
LED color Description
Red
Device ready
Green
Only connection available, no USB 2.0 signal
Green /
light blue
Connection available, no USB 2.0 device
connected
flashing
Light blue
Connection and USB 2.0 signal available
(operating status)
12
12
3
3
2013-08-13 41
Draco KVM Extender
4 Installation
Pos: 62 /806-IHSE/Installation/Lieferumfang pr üfen/481-xx @ 9\mod_136 7838010040_6.doc @ 71895 @ 2 @ 1
4.1 Package Contents
Your extender package contains the following items:
KVM Extender:
KVM Extender pair (CPU Unit and CON Unit) in the vario chassis
1x (redundancy 2x) 5VDC international power supply unit per KVM
Extender unit
1x (redundancy 2x) country specific power cord
Quick Setup
HDMI cable (1.8 m, HDMI male-to-male)
USB cable (1.8 m, type A to type B)
Additional content for upgrade module Analog Audio / Serial:
Serial cable (1.8 m, D-Sub 9 male connector)
Stereo jack cable (1.6 m, 3.5 mm male connector)
Additional content for upgrade module serial (RS422):
Serial cable (1.8 m, D-Sub 9 male connector)
Additional content for upgrade module Digital Audio:
RCA cable (2.5 m, Cinch male connector)
TOSLINK cable (1.8 m, F05 male connector)
42 2013-08-13
Installation
Additional content for upgrade module USB-HID:
USB cable (1.8 m, USB type A to type B)
Additional content for upgrade module PS/2:
2x PS/2 cable (1.8 m, 6-pole connector)
Additional content for upgrade module USB 2.0 embedded:
USB cable (1.8 m, USB type A to type B)
Additional content for upgrade module USB 2.0:
USB cable (1.8 m, USB type A to type B)
If anything is missing, contact your dealer.
Pos: 63 /806-IHSE/zz_Layout/Seitenumbruch @ 8\ mod_1348581820516_0.doc @ 69462 @ @ 1
2013-08-13 43
Draco KVM Extender
Pos: 64 /806-IHSE/Installation/System anschließ en/474-xx @ 6\mod_130 4584542160_6.doc @ 51273 @ 233 @ 1
4.2 System Setup
First time users are recommended to setup the system with the CPU Unit
and the CON Unit in the same room as a test setup. This will allow you to
identify and solve any cabling problems, and experiment with your system
more conveniently.
Please verify that interconnect cables, interfaces, and handling of the
4.2.1 KVM Extender Setup
devices comply with the requirements (see Chapter 7, Page 60).
1. Switch off all devices.
CON Unit Installation
2. Connect your monitor(s), keyboard and mouse to the CON Unit.
3. Connect the CON Unit with the interconnect cable(s).
4. Connect the 5VDC power supply to the CON Unit.
CPU Unit Installation
5. Connect the source (computer, CPU) with the supplied cables to the
CPU Unit. Please ensure the cables are not strained.
6. Connect the CPU Unit to the interconnect cable(s).
7. Connect the 5VDC power supply to the CPU Unit.
8. Power up the system.
To power up the system, the following sequence is recommended:
Monitor – CON Unit – CPU Unit – source.
The basic module with VGA / DVI-I input is connected as mentioned
above. For a complete and detailed description of the setup and
configuration of the VGA option, see the manual of the Media- / DVIConverter K238-5V (Download
).
44 2013-08-13
Loading...
