iHome IP98 User Manual
Model iP98
The Home System
For Your iPhone® or iPod
®
Questions? Visit www.ihomeaudio.com
Table of Contents
Quick Start........................................................................................................................................................................1
Controls and Indicators / iP98 Display..........................................................................................................................2
Using the iP98 ...............................................................................................................................................................3-4
Replacing iP98 Backup Batteries ...................................................................................................................................4
Using the Remote Control Unit ......................................................................................................................................5
A Consumer Guide to Product Safety ...........................................................................................................................6
Troubleshooting............................................................................................................................................................7-8
Solucionando problemas...........................................................................................................................................9-10
Warranty Information.....................................................................................................................................................11
A Consumer Guide to Product Safety
This device complies with part 15 of the FCC Rules. Operation is subject to the condition that this
device does not cause harmful interference.
This equipment complies with the limits for a Class B digital device as specified in Part 15 of FCC Rules. These limits
provide reasonable protection against radio and TV interference in a residential area.
However, your equipment might cause TV or radio interference even when it is operating properly. To eliminate interference
you can try one or more of the following corrective measures:
• Reorient or relocate the receiving antenna.
• Increase the distance between the equipment and the radio or TV.
• Use outlets on different electrical circuits for the equipment and the radio or TV.
Consult your dealer or an experienced radio/television technician if the problem still exists.
Modifying or tampering with your system’s internal components can cause a malfunction and might invalidate the system’s
warranty and void your FCC authorization to operate it.
This Class B digital apparatus complies with Canadian ICES-003.
Maintenance
• Place the unit on a level surface away from sources of direct sunlight or excessive heat.
• Protect your furniture when placing your unit on a natural wood and lacquered finish. A cloth or other protective material should
be placed between it and the furniture.
• Clean your unit with a soft cloth moistened only with mild soap and water. Stronger cleaning agents, such as Benzene, thinner
or similar materials can damage the surface of the unit.
quick start
1: power
Attach AC adaptor cable to
DC jack on back of the iP98
and plug the other end into a
wall socket.
NOTE: If you do not have an insert for
your iPhone/iPod, please visit
www.ihomeaudio.com or call iHome toll
free at 877-446-6301 to purchase one.
4: time zone
2: antenna
Snap AM antenna into provided
stand, then plug antenna cable
into socket on back of iP98.
Move antenna 12” away.
Use this insert
For this iPhone / iPod
5: iPhone/
iPod
3: inserts
Select the dock insert for your
iPhone or iPod® model from the
table below and place insert in
dock. Never dock an iPhone/
iPod without an insert in place.
iPhone 3G
insert 15
iPhone 3G
iPod touch 2G
insert 16
iPod touch 2G
nano 4G
insert 17
nano 4G
6: radio
• Move the DST switch on back
of unit to +1 or -1 (adds or
subtracts an hour)
• Press & hold the Time Zone
button on back until the
display flashes
• Turn the Set Wheel to select
your time zone
• Press the Time Zone
button again.
Insert an iPhone or iPod into the
dock with proper insert
(iPhone/iPod must not be in a
skin or case). The iPhone/iPod
will charge while docked.
Press the
to play your iPhone/iPod.
Button on the iP98
1
Press the Radio button and
press again to select AM/FM
band. Turn the Set Wheel to
tune in a station. See page 4 for
programming presets.
Controls and Indicators
Dock
Volume Wheel
Alarm Reset / Power Button
EQ Button
AC Adaptor Jack
FM Antenna
Preset Buttons 1-6
Sleep Button
Clock Adjust Button
+*=T( SPULPUJSVJRHKQ [PTLaVUL +:; HTHU[LUUH
Radio Button
Set Wheel
SPULPU
LX
Play/Pause Button
Alarm 2 Button
Alarm 1 Button
Snooze/Dimmer Button
Time Zone Button
DST switch
Line-in Jack
AM Loop Antenna socket
Time Display
iP98 Display
Sleep Indicator
PM Indicator
Radio / Alarm Time / iPod Display
2
Alarm 1, Alarm 2 Indicators
Wake-to Indicator
Battery Low Indicator
