Ihome IB76 User Manual

iB76

Splashproof + Shockproof Wireless Earbuds

rechargeable • sweatproof • flexible earhooks

User Manual

CHARGE

BEFORE

USE

BC

Introduction

Your new iHome Bluetooth stereo ear buds are designed to link with your Bluetooth
enabled smartphone or music player to allow you to wirelessly listen to music and answer
phone calls within the normal 10 meter (33 feet) Bluetooth operating range.

Your ear buds are supplied with 3 sizes of ear cushions to allow you to customize your
ear buds for maximum wearing comfort and stability during all kinds of exercise and
physical activities.

Please review this manual carefully to make sure you are getting the maximum benefit
from all of the features of your new ear buds, and keep this manual for future reference.

What’s Included

Cable Management

iB76 Ste

reo ear buds

with control dongle

USB Charging Cable x 1

Clip x 1

x 2

L

SIZE

Silicon Ear Cushions

M

SIZE

x 2

S

SIZE

x 2

Drawstring Travel

Pouch x 1

PREPARATION FOR USE

1. Controls and Indicators

+ Button (Volume Up / Skip Forward)

1

Multi-Function Control Button ( )

2

Power/Pairing/Charging LED Indicators

3

Microphone

4

– Button (Volume Down / Skip Back)

5

USB Charging Port

6

3/4

1

2

5

2. Charging Your iHome Ear Buds

Your iHome Bluetooth ear buds operate on a built-in rechargeable battery. Although
the battery was fully charged when it left our factory, the battery can lose power even
during periods of non-use. Make sure to charge the battery before using the phone
for the first time.

To charge the battery connect the larger plug of the included

USB charging cable to the powered USB port of a computer or
a USB/AC adapter and then connect the smaller plug to the
USB charging port on side of the control dongle as shown in
the illustration.

The Charging Indicator will glow red while the ear buds are charging. The indicator will
turn off when the ear buds are fully charged and ready to use.

When fully charged the battery should provide up to 7 hours of talk time or music
playing time at a normal listening level. If operated at maximum volume the music
playing time will be reduced. NOTE: While charging, the earbud power will turn off to
conserve battery power and minimize charging time.

3. Wearing Your iHome Ear Buds

The ‘M’ size silicon tips were installed on the ear buds at our factory.

If you wish to change to either the ‘S’ or ‘L’ size tips simply pull the ‘M’ size tips off
the ear buds and replace them with the ‘S’ or ‘L’ size tips. Be
sure to push the ‘S’ or ‘L’ size tips on to the ear buds until they
are firmly seated on the tubes so that the tips do not come off
the ear buds when you remove them from your ears. Using the
proper size tips will insure that you get the best possible seal in
your ear canal and provide the best audio quality.

The recommended usage is to position the cable behind your neck before inserting
the ear buds in your ears. The ear buds should be worn with the control dongle on
your right side.

Note: Noise isolation ear buds like the iB76 are designed to provide a good seal in

your ears and block outside sounds. You should not use noise isolation ear buds in
situations that require you to hear outside warning sounds.

1

6

OPERATING INSTRUCTIONS

1. First Time Power On: Auto Pairing

The first time you power on the earbuds, place only the left ear bud in your left ear so

you can hold the control dongle in your right hand to see the control buttons and the
LED indicator and still hear the confirming voice prompts in your left ear. Once the ear
buds have turned on and paired with your Bluetooth device, insert the right ear bud
in your right ear.

PRESS and HOLD the Multi-Function Button ( ) on the control dongle for about 3
seconds until you hear the “Power On” voice prompt.

The first time the eabuds are powered on they will enter auto-pairing mode, indicated

by flashing red and blue LEDs and a “Pairing” voice prompt.
a) Make sure Bluetooth is enabled on your device (check in Settings or Options).
b) “iHome iB76” will apear on your device’s Bluetooth menu.
c) Select “iHome iB76 to complete pairing. You will hear the voice prompt say “Your

device is connected”. NOTE: If your Bluetooth device asks for a Password or a PIN

to complete the pairing process, enter “0000” on the keypad of your device.
You are now ready to begin streaming music wirelessly from your Bluetooth device to

your iHome iB76 Bluetooth earbuds.

2. Standard Power On: Auto-Linking Mode

After the first time, whenever you power on the earbuds, t

slowly indicating that your earbuds are in Auto-Linking Mode (trying to re-link to a
previously paired device) that is within the normal pairing range of about 33-feet. If
your earbuds do not find a previously paired device that is in range and turned ‘on’
within 3 minutes, they will power OFF to extend the battery life.

he blue LED will flash

3. Manually Pairing Your iHome Earbuds With Your Bluetooth Device

NOTE: Your ear buds must be ‘Off’’ to begin the manual pairing process.

With the ear buds in ‘Off’ mode, PRESS and HOLD the Multi-Function Button ( )

on the control dongle for about 8 seconds. After 3 seconds you will hear the “Power
On” voice prompt, followed after another 5 seconds by the “Pairing” voice prompt
and flashing red and blue LEDs. Release the Multi-Function Button ( ). Follow the
a-c pairing instructions in step 1 above to complete pairing.

4. Power Off

To turn earbuds ‘Off’ at any time, PRESS and HOLD the Multi-Function Button ( ) on

the control dongle for about 3 seconds. You will hear the voice prompt say “Power
Off”. The red LED flashes three times and then the power shuts off.

5. Using Your iHome Bluetooth Ear Buds

The following chart explains the basic functions and operations of your Bluetooth earbuds.

2 3

FuncƟon

Turn ear buds On

Enter Pairing Mode

Pairing

Play / Pause

Skip to next track

Skip to beginning of current track
Skip to beginning of previous track
Increase volume
Decrease volume
Answer an incoming phone call

Answer second call/call waiting

Decline an incoming phone call
End a call
Transfer a call between the

phone and the ear buds

Last number redial

Reset Bluetooth/Clear all paired devices
Turn ear buds Off

Siri/Google Voice function

FCC/IC Information

This device complies with Industry Canada’s licence-exempt RSSs.
Operation is subject to the following two conditions:

(1) This device may not cause interference; and
(2) This device must accept any interference, including interference that may cause undesired

operation of the device.

This device complies with Part 15 of the FCC Rules, operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.

• Warning: Changes or modifications to this unit not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.

• NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

•

Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

CAN ICES-3 (B)/NMB-3(B)
The device meets the exemption from the routine evaluation limits in section 2.5 of RSS 102 and

compliance with RSS-102 RF exposure, users can obtain Canadian information on RF exposure
and compliance.

AcƟon Required

When ear buds are 'Off’, press and hold the MFB for 3 seconds until you hear the
“Power On” voice prompt. The LED indicator flashes blue.

When ear buds are 'Off', press and hold the MFB for 8 seconds until you hear the
“Power On” voice prompt followed by the “Pairing” voice prompt and see the LED
indicator alternately flashing red and blue.
Make sure your Bluetooth device is 'On' and discoverable. When “iHome iB76”
appears on your device’s menu, select it to complete pairing.

Short press the MFB to start playback. Short press to pause playback. Short
press to resume playback.

Short press the "+" button during playback
Short press the " - " button during playback
Short press the " - " button twice during playback

Press and hold the "+" button during playback
Press and hold the " - " button during playback

Short press the MFB when you hear the incoming ring sound. NOTE: Music will
automatically pause when you are answering a call and resume when you end the call.

Short press the MFB to place current call on hold and answer a second call. Short
press again as needed to switch between calls.

Press and hold the MFB for 3 seconds to decline the incoming call.
Short press the MFB to end the call and 'hang up'.

While the call is in progress, press and hold the MFB for 2 seconds. You will hear
a beep indicating to transfer the call between the phone and the ear buds.

When phone is paired with ear buds but no call is in progress, double press the
MFB to redial the last number.

Press and hold both the “+” and the “ – “ buttons for 7 seconds.
Press and hold the MFB for 3 seconds until you hear the “Power Off” voice

prompt. The LED indicator flashes red and then shuts off.

Press and hold the “<<” button for 3-4 seconds

IC: 986B-iB76

FCC ID: EMOiB76

Limited One-Year Warranty Information

iHome Products, a division of SDI Technologies Inc. (hereafter referred to as SDI), warrants
this product to be free from defects in workmanship and materials, under normal use and
conditions, for a period of one (1) year from the date of original purchase.

Should this product fail to function in a satisfactory manner, it is best to first retur n it to the
store where it was originally purchased. Should this fail to resolve the matter and service
still be required by reason of any defect or malfunction during the warranty period, SDI will
repair or, at its discretion, replace this product without charge. This decision is subject to
verification of the defect or malfunction upon delivery of this product to the Factory Service
Center authorized by Customer Service.

If service is required, please call Customer Service at 1-800-288-2792 to obtain a Return
Authorization Number and shipping instructions. A copy of the sales receipt is required to
validate in-warranty coverage.

Disclaimer of Warranty

NOTE: This warranty is valid only if the product is used for the purpose for which it was
designed. It does not cover (i) products which have been damaged by negligence or willful
actions, misuse or accident, or which have been modified or repaired by unauthorized
persons; (ii) cracked or broken cabinets, or units damaged by excessive heat; (iii) damage
to digital media players, CD’s or tape cassettes (if applicable); (iv) the cost of shipping this
product to the Factory Service Center and its return to the owner.

This warranty is valid only in the United States of America and does not extend to owners
of the product other than to the original purchaser. In no event will SDI or any of its affiliates,
contractors, resellers, their officers, directors, shareholders, members or agents be liable
to you or any third party for any consequential or incidental damages, any lost profits, actual,
exemplary or punitive damages. (Some states do not allow limitations on implied warranties
or exclusion of consequential damages, so these restrictions may not apply to you.) This
warranty gives you specific legal rights, and you may also have other rights which vary from
state to state.

Your acknowledgement and agreement to fully and completely abide by the above mentioned
disclaimer of warranty is contractually binding to you upon your transfer of currency (money
order, cashier's check, or credit card) for purchase of your SDI product.

Bluetooth technology is incorporated under license from Bluetooth SIG Inc.
Siri is a trademark of Apple, Inc., registered in the U.S. and other countries.

© 2016 SDI Technologies, Inc. All rights reserved.

Questions? Visit www.ihome.com

Bluetooth is a registered trademark of Bluetooth SIG Inc.

or call 1-800-288-2792 Toll Free

Google Voice is a trademark of Google, Inc.

iB76-112916-A (EN) Printed in China
