Ignis TAB User's Manual & Installation Instructions
User’s Manual
Installation Instructions
TAB
Ventless Ethanol Fireplace
www.ignisproducts.com
What’s in the box:
Fireplace Body 1pc
Tempered Side Glass 2pcs
Mounting Bolts 4pcs
Control Tool 1pc
User’s Manual 1pc
Assembling
Unpack the fireplace and accessories. Check the content for completeness and any
damage incurred in transit. Keep children away from packing materials.
Place the fireplace body on a stable surface. Caution: The fireplace must only be
installed or placed on a solid floor of non-flammable material.
Assemble the fireplace with screw studs, rings and caps.
www.ignisproducts.com
Tab - User’s Manual
Operation Instructions
Step 1: Adjust the sliding lid to its widest opening. Fill the burner with the ethanol,
watch carefully untill you reach under the level of the “Max” line. Do not overfill or spill.
CAUTION:
Any spilled ethanol must be immediately removed with an absorbent tissue and
cleaned with water to prevent ignition outside the burner reservoir.
Fuel must be kept in safe distance (min. 1 meter / 40 inches) from the fireplace. Do
not place fuel in front of the fireplace.
Step 2: Use a long match or a long lighter to ignite. When igniting, keep a safe distance
at arm’s length. Do not stand directly over the burner.
CAUTION: Fuel will burn low at first. Please allow 10-15 minutes to reach the optimal
temperature and flame height.
Opening or closing the sliding cover on the burner can adjust the flame.
Avoid drafts for long burning time.
Always maintain a safe distance of at least 1 meter (40 inches) from the fireplace
when the flame is lit.
Extinguishing
CAUTION: Never extinguish the flame with water!
1. Let the fuel burn out completely if possible. This prevents alcohol left in the burner
and deflagration when reigniting.
2. If you wish to extinguish the fire before the fuel has completely burned out. Please
use the control tool to fully close the sliding cover of the burner in a fast motion,
completely extinguish the flame.
3. In case the flame is not extinguished immediately. Repeat the above instructions
until the flame is fully extinguished.
4. Do not touch the fireplace while burning. Please allow at least 20 minutes to cool
down before touching the fireplace after flame is extinguished.
5. It is urgently recommended that you keep a Class B fire extinguisher at hand close
to the device in case of fire.
Refilling
Allow the burner to cool down for at least 20 minutes before refilling.
Warning: Never refill the burner when the fireplace is operating or still hot.
Never pour fuel into a burning flame.
www.ignisproducts.com
Cleaning
1. The burner surfaces must be cleaned regularly. Use warm water and soap.
2. Check the sliding cover of burner for warping or damage before using.
3. Marks can be best removed with a soft cloth and a mixture of lukewarm water
and a small amount of cleaning liquid (ph-neutral). We recommend cleaning the
stainless steel items regularly to prevent contamination.
CAUTION: Never use chemical, steel-wool or scrubbing sponges to clean the fireplace.
These can scratch the surface.
The manufacturer cannot be held responsible for any damages resulting out of improper use and/ or cleaning of the products.
Safety Instructions
• When burning ethanol, water-vapor and carbon dioxide are produced.
• Never leave an open fire unattended at any time!
• In a house of typical construction, that is, one that is not of unusually tight con-
struction due to heavy insulation and tight seals against air infiltration, an adequate supply of air for combustion and ventilation is provided through infiltration.
• The fireplace should not be used in a small room where less than 44m3 (1550ft3)
of air space is provided for each 1000 Btu per hour of fireplace (considering the
maximum burner adjustment).
• Do not use the fireplace in a bathroom, a room where sleeping accommodation is
provided or any other small room.
• Never fill fuel while unit is still burning or hot.
• Fill no more than ¾ full.
• Use only long lighter to ignite. Initial ignition may have a high flame close lid half
way to light.
• Insert burner into fireproof materials only.
• Never install burner into plastic or wood.
• Using a burner with flammable materials is at your own risk.
• Keep out of reach of children.
• This fireplace will produce heat, but should not be used as a main source of heat.
• The fireplace must only be installed on a solid surface of non-flammable material.
Be sure to keep any flammable materials such as drapes/curtains and any decorations at least 4 feet away from fireplace.
• Do not place any items on top of or inside fireplace.
• Do not touch the fireplace while lit or still hot.
• It is extremely dangerous and forbidden to use bio-ethanol car fuel or any other
unapproved fuel.
• Always use a funnel to fill the fireplace with fuel.
