ICRealtime NVR-W104 Specsheet

NVR-W104

4 C H 1 U W i F i N e t w o r k V i d e o R e c o r d e r

For the ultimate in convenience and ease of use this 4 channel WiFi NVR hits the spot. This NVR
features a built-in WiFi router with WPS (WiFI Protected Setup) for one button setup. No more CAT-5
cables running from your cameras to the NVR just mount your cameras and add power and point them
at your wireless NVR. The system is perfect for small offices, restaurants, and homes. ICRealtime
offers multiple cameras that work both inside and outside with this NVR. Welcome to the future of
surveillance.

Features

 Up to 4 channel IP camera inputs
 Max 80Mbps incoming bandwidth
 ONVIF Version 2.4
 Supports 1 SATA HDD up to 4TB, 2 USB2.0
 Supports WPS
 H.264/MJPEG dual codec decoding

Revision 1.2; 09/2015

NVR-W104

Model

NVR-W104

System

Main Processor

Dual-core embedded processor

Operating System

Embedded LINUX

Video & Audio

IP Camera Input

4 channel

Two-way Talk

1 channel Input, 1 channel Output, RCA

Interface

1 HDMI, 1 VGA

Resolution

1920×1080, 1280×1024, 1280×720, 1024×768

Display Split

1/4

OSD

Camera title, Time, Video loss, Camera lock, Motion detection, Recording

Recording

Compression

H.264 / MJPEG

Resolution

5MP (2560×1920) / 3MP (2048×1536) / 1080P (1920×1080) / 720P
(1280×720) / D1 (704×576/704×480)

Record Rate

80Mbps

Bit Rate

48 ~ 8192kbps

Record Mode

Manual, Schedule (Regular (Continuous), MD, Alarm), Stop

Record Interval

1-120 min (default: 60 min), Pre-record: 1-30 sec, Post-record: 10-300 sec

Video Detection

Trigger Events

Recording, PTZ, Tour, Video Push, Email, FTP, Spot, Buzzer & Screen tips

Video Detection

Motion Detection, MD Zones: 396 (22×18), Video Loss & Camera Blank

Playback & Backup

Sync Playback

1/4

Search Mode

Time/Date, MD & Exact search (accurate to second)

Playback Function

Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next
camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection,
Digital zoom

Backup Mode

USB Device / Network

Network

Ethernet

1 RJ-45 port (10/100M/1000M)

Wireless Network

Built-in Wi-Fi module, 2 Wi-Fi Antennas

Network Function

HTTP, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP
Filter, PPPoE, DDNS, FTP, Alarm Server, IP Search

Max. User Access

128 users

Smart Phone

iPhone, iPad, Android, Windows Phone

Storage

Internal HDD

1 SATA port, up to 4TB

USB

2 ports (2 Rear), USB 2.0

General

Power Supply

DC12V, 2A

Power Consumption

10W (without HDD)

Working Environment

14°F ~ 131°F/-10°C ~ 55°C; 10~90%RH; 86~106kpa

Dimensions (W×D×H)

Smart 1U; 8.07”×8.07”×1.57”/205mm×205mm×40mm

Weight

1.1lbs/0.5kg (without HDD)

Specifications
