q Unscrew 1 nut A, and remove 2 knobs B, C.
w Unscrew 2 screws D.
e Take off the chassis unit in the direction of the arrow.
r Unplug the connector E from the chassis unit.
A
Chassis unit
E
D
*B
C
*: IC-F14/F15/F16/F3018 only
2. REMOVING THE MAIN UNIT
q Unscrew 2 nuts F, and remove the top plate G.
w Unsolder 5 points H, and remove the shield cover.
e Unscrew 2 screws I, and remove the side plate J.
r Unscrew 7 screws K.
t Unsolder 4 points L, and take off the main unit in the
direction of the arrow.
Shield cover
H
H
I
K
L
L
J
K
K
Main unit
G
F
Chassis unit
3 - 1
Page 7
SECTION 4. CIRCUIT DESCRIPTION
4-1 RECEIVER CIRCUITS
4-1-1 ANTENNA SWITCHING CIRCUIT
The antenna switching circuit functions as a low-pass filter
while receiving and a resonator circuit while transmitting.
This circuit does not allow transmit signals to enter the
receiver circuits.
Received signals enter the antenna connector (CHASSIS;
J1) and pass through the low-pass filter (L1–L3, C2–C5,
C175, C176). The filtered signals are passed through the
λ type antenna switching circuit (D5, D6, L6, L7) and
1⁄4
then applied to the RF circuit.
4-1-2 RF CIRCUIT
The RF circuit amplifies signals within the range of frequency coverage and filters out-of-band signals.
The signals from the antenna switching circuit pass through
the bandpass filter (D4, D8, L8, L9). The filtered signals are
amplified at the RF amplifier (Q2) and then passed through
the another bandpass filter (D9, D10, L11) to suppress
unwanted signals. The filtered signals are applied to the 1st
mixer circuit.
D4, D8–D10 employ varactor diodes, that are controlled by
the CPU via the D/A converter (IC8), to track the bandpass
filter. These varactor diodes tune the center frequency of an
RF passband for wide bandwidth receiving and good image
response rejection.
4-1-3 1ST MIXER AND 1ST IF CIRCUITS
The 1st mixer circuit converts the received signal into fixed
frequency of the 1st IF signal with the PLL output frequency. By changing the PLL frequency, only the desired
frequency passes through a crystal filter at the next stage
of the 1st mixer.
The RF signals from the bandpass filter are mixed with
the 1st LO signals, where come from the RX VCO circuit
via the attenuator (R26–R28), at the 1st mixer circuit (Q3)
to produce a 46.35 MHz 1st IF signal. The 1st IF signal is
passed through a monolithic filter (FI1) in order to obtain
selection capability and to pass only the desired signal.
The filtered signal is applied to the 2nd IF circuit after being
amplified at the 1st IF amplifier (Q4).
4-1-4 2ND IF AND DEMODULATOR CIRCUITS
The 2nd mixer circuit converts the 1st IF signal into a 2nd
IF signal. The double-conversion superheterodyne system
(which convert receive signals twice) improves the image
rejection ratio and obtains stable receiver gain.
The 1st IF signal from the IF amplifier (Q4) is applied to
the 2nd mixer section of the FM IF IC (IC1, pin 16), and
is mixed with the 2nd LO signal to be converted into a
450 kHz 2nd IF signal.
The FM IF IC (IC1) contains the 2nd mixer, 2nd local oscillator, limiter amplifier, quadrature detector, active filter and
noise amplifier circuits. A 2nd LO signal (45.9 MHz) is produced at the PLL circuit by tripling it’s reference frequency
(15.3 MHz).
The 2nd IF signal from the 2nd mixer (IC1, pin 3) passes
through the ceramic filter (FI2) to remove unwanted heterodyned frequencies. It is then amplified at the limiter
amplifier section (IC1, pin 5) and applied to the quadrature
detector section (IC1, pins 10, 11) to demodulate the 2nd
IF signal into AF signals.
The demodulated AF signals are output from pin 9 (IC1) as
“DET” signal, and are then applied to the AF circuit.
2ND IF AND DEMODULATOR CIRCUITS
87
Active
filter
"SQLC" signal from the
D/A converter IC
(IC8, pin 2)
To D/A converter IC
(IC8, pin 1)
AF signal "DET"
to the AF circuit
FM
detector
X1
Noise
AMP
Limiter
AMP
5
2nd IF filter
450 kHz
Noise
detector
RSSI
FI2
Noise
comparator
3
Mixer
45.9 MHz
2
Q19
×3
X2
15.3 MHz
IC1 TA31136FN
11109
12
"RSSI" signal to the CPU (IC13, pin 63)
R5V
13
"NOIS" signal to the CPU (IC13, pin 53)
16
1st IF signal from the IF amplifier (Q4)
4 - 1
Page 8
4-1-5 AF AMPLIFIER CIRCUIT
The AF amplifier circuit amplifies the demodulated AF signals to drive a speaker.
The AF signals from the FM IF IC (IC1, pin 9) pass through
the high-pass filter (IC6, pins 3 and 1) to suppress unwanted harmonic components. The signals pass through the
RX mute switch (Q34) which is controlled by “RMUT” signal from the CPU (IC13, pin 56), and are then applied to
another high-pass filter (IC6, pins 13 and 14). The filtered
signals pass through the low-pass filter (IC6, pins 6 and
7) via the analog switch (IC10, pins 1 and 2). The signals
are applied to the analog switch (IC10, pin 10) again, and
are then applied to the AF power amplifier (IC12, pin 4) via
the AF volume (R226). The amplified AF signals are output
from pin 10, and are then applied to the internal speaker
which is connected with J1 via the [SP] jack.
4-1-6 RECEIVE MUTE CIRCUITS
• NOISE SQUELCH
A squelch circuit cuts out AF signals when no RF signals
are received. By detecting noise components in the AF signals, the squelch circuit switches the AF mute switch.
Some noise components in the AF signals from the FM IF
IC (IC1, pin 9) are applied to the D/A converter (IC8, pin
1) as “DET” signal, and are then output from pin 2. The
signals are applied to the active filter section in the FM IF
IC (IC1, pin 8). The active filter section filters and amplifies
noise components. The amplified signals are converted into
the pulse-type signals at the noise detector section and
output from pin 13 as “NOIS” signal.
The “NOIS” signal from the FM IF IC is applied to the CPU
(IC13, pin 53). Then the CPU analyzes the noise condition
and outputs the AF mute control signal from the CPU (pin
56) as “RMUT” signal. The signal is applied to the RX mute
switch (Q34) to control the AF signal muting.
• CTCSS AND DTCS
The tone squelch circuit detects tone signals and opens the
squelch only when receiving a signal containing a matched
subaudible tone (CTCSS or DTCS). When tone squelch is
in use, and a signal with a mismatched or no subaudible
tone is received, the tone squelch circuit mutes the AF signals even when noise squelch is open.
A portion of the “DET” signals from the FM IF IC (IC1, pin
9) passes through the low-pass filter (IC7, pins 10 and 8)
to remove AF (voice) signals, and are then applied to the
amplifier (IC7, pin 12). The amplified signals are applied to
the CTCSS or DTCS decoder inside of the CPU (IC13, pin
60) as the “CDEC” signal. The CPU outputs AF mute con-
trol signal, and is then applied to the RX mute switch (Q34)
and analog switch (IC10, pins 12 and 13) to control AF signals muting as “RMUT” signal.
4-2 TRANSMITTER CIRCUITS
4-2-1 MICROPHONE AMPLIFIER CIRCUIT
The microphone amplifier circuit amplifies audio signals
within +6 dB/octave pre-emphasis characteristics from the
microphone to a level needed for the modulation circuit.
The AF signals from the microphone are passed through
the microphone mute switch (Q35), and are then applied
to the amplifier (IC6, pins 9 and 8) via the high-pass filter
(IC6, pins 13 and 14). The amplified signals are applied to
the analog switch (IC10, pin 4), and outputs from pin 3. The
signals pass through the low-pass filter (IC6, pins 6 and
7), then applied to the analog switch (IC10, pin 9) again.
The signals are applied to the D/A converter (IC8, pin 4).
The converted signals output from pin 3, and applied to the
modulation circuit (D18) as “MOD” signal.
ANALOG SWITCHING CIRCUITS
"DET" AF signal
from FM IF IC (IC1, pin 9)
IC6 B
LPF
D/A converter
"CTCSS/DTCS" signal from
D/A conveter IC (IC8, pin 10)
"TONE" signal from CPU (IC13) via low-pass
filters (IC5 A / IC5 B pin 7)
2
3
9
10
8
IC6 A
HPF
Analog SW
IC8
(IC10)
MUTE
1
IC6 C
4
11
D18
FM mod.
Q34
RX
AMP
IC6 D
HPF
AF
volume
R226
to TX VCO circuit
(Q13, D16, D17)
IC12
AF
AMP
Q35
MIC
MUTE
Microphone
Speaker
4 - 2
Page 9
4-2-2 MODULATION CIRCUIT
The modulation circuit modulates the VCO oscillating signal
(RF signal) using the microphone audio signals.
The AF signals from the D/A converter (IC8, pin 3) change
the reactance of varactor diode (D18) to modulate the oscillated signal at the TX VCO circuit (Q13, D16, D17). The
modulated VCO signal is amplified at the buffer amplifiers
(Q12, Q10) and is then applied to the drive amplifier circuit
via the T/R switch (D14).
The CTCSS/DTCS signals (“CENC0”, “CENC1”, ”CENC2”)
from the CPU (IC13, pins 23–25) pass through the low-pass
filter (IC5, pins 12 and 14) via 3 registers (R191–R193) to
change its wave form. Then the signals are applied to the
D/A converter (IC8, pin 9). The output signals from the D/A
converter (IC8, pin 10) pass through the low-pass filter (IC6,
pins 6 and 7) to be mixed with “MOD” signal at the filter (IC6),
and are then applied to the D/A converter again (IC8, pin 4).
4-2-3 DRIVE/POWER AMPLIFIER CIRCUITS
The drive/power amplifier circuits amplify the VCO oscillating signal to an output power level.
The modulated RF signal from the TX VCO circuit passes
through the T/R switch (D14), and is amplified at the predrive (Q9), drive (Q8) and power (Q7) amplifiers to obtain
5 W of RF power (at 7.2 V DC).
4-2-4 APC CIRCUITS
The APC circuit (IC2, D1) protects drive and power amplifiers from the reflected signal, and selects output power of
HIGH, LOW2 or LOW1.
The power detector (D1) detects transmit output power and
converts it into DC voltage. The DC voltage is at a minimum
level when the antenna impedance is matched to 50 Ω, and
increased when mismatched.
The detected voltage is applied to the differential amplifier (IC2, pin 3), and the “T2” signal from the D/A converter
(IC8, pin 23), controlled by the CPU (IC13), is applied to the
other input for reference. When antenna impedance is mismatched, the detected voltage exceeds the power setting
voltage. Then the output voltage of the differential amplifier
(IC2, pin 4) controls the input current of the pre-drive (Q9),
drive (Q8) and power (Q7) amplifiers to reduce the output
power.
The amplified signal passes through the power detector (D1),
antenna switch (D2) and low-pass filter (L1–L3, C2–C5,
C175, C176), and is then applied to the antenna connector
(CHASSIS unit; J1).
The bias current of the pre-drive (Q9), drive (Q8) and power
(Q7) amplifiers are controlled by the APC circuit.
APC CIRCUITS
VCC
T5V
Q8
Driver
AMP
RF signal
from Buffer AMP
T2
TMUT
+
Differential
AMP
–
Q9
YGR
AMP
IC2
Powe r
AMP
Q7
LPF
D1
ANT
SW
D2
LPF
to ANT unit
4 - 3
Page 10
4-3 PLL CIRCUITS
4-3-1 PLL CIRCUIT
A PLL circuit provides stable oscillation of the transmit
frequency and receive 1st LO frequency. The PLL output
compares the phase of the divided VCO frequency to the
reference frequency. The PLL output frequency is controlled
by the divided ratio (N-data) of a programmable divider.
The PLL circuit contains the TX/RX VCO circuits (TX: Q13,
D16, D17, D21; RX: Q14, D19, D20, D22). The oscillated
signal is amplified at the buffer amplifiers (Q11, Q12) and
then applied to the PLL IC (IC4, pin 8) after being passed
through the low-pass filter (L32, C206–C208).
The phase detected signal outputs from pins 15 and 16, and
is then applied to the charge pump (Q39, Q40). The signal
passes through the loop filter (C146, C147, C149, R95–
R97), and is then applied to the TX and RX VCO circuits as
a lock voltage.
The PLL IC contains a prescaler, programmable counter,
programmable divider and phase detector, etc. The entered
signal is divided at the prescaler and programmable counter
section by the N-data ratio from the CPU. The divided signal
is detected on phase at the phase detector using the reference frequency.
If the oscillated signal drifts, its phase changes from that of
the reference frequency, causing a lock voltage change to
compensate for the drift in the oscillated frequency.
4-3-2 VCO CIRCUIT
The VCO circuit contains a separate RX VCO (Q14, D19,
D20) and TX VCO (Q13, D16, D17). The oscillated signal
is amplified at the buffer amplifiers (Q10, Q12) and is then
applied to the T/R switch (D14 for TX, D15 for RX). Then the
receive 1st LO (RX) signal is applied to the 1st mixer circuit
(Q3) and the transmit (TX) signal to the pre-drive amplifier
(Q9).
A portion of the signal from the buffer amplifier (Q12) is fed
back to the PLL IC (IC4, pin 8) via the buffer amplifier (Q11)
and low-pass filter (L32, C206–C208) as the comparison
signal.
PLL CIRCUITS
"LVIN" signal to the CPU
(IC13, pin 64)
45.9 MHz 2nd LO
signal to the FM IF IC
(IC1, pin 2)
Buffer
Q18
Tripler
Q19
Loop
filter
Charge
Pump
Q39, Q40
3
RX VCO
Q14, D19, D20, D22
TX VCO
Q13, D16, D17, D21
15
Phase
detector
16
Programmable
divider
2
Programmable
counter
Buffer
Q12
IC4 MB15A02
Prescaler
Shift register
1
Buffer
Q10
Buffer
Q11
X2
15.3 MHz
D15
to 1st mixer circuit
D14
to transmitter circuit
LPF
8
14
SCK
15
SO
16
PLST
4 - 4
Page 11
4-4 OTHER CIRCUITS
LED CONTROL CIRCUITS
The LED control circuit is composed of the CPU (IC13),
LED driver (Q32) and LED (DS1).
The CPU outputs “RLED” and “TLED” signals from the pins
42 and 43. The signals are applied to the LED driver (Q32,
pins 3 and 1). The driver outputs LED control signals to the
LED (DS1).
CONDITIONCOLOR
RECEIVING (2/5-TONE CODE)ORANGE
LOW BATTERY
(Nearly exhausted)
LOW BATTERY
(Almost exhausted)
CLONINGORANGE
RECEIVING/SQUELCH OPENGREEN
TRANSMITTINGRED
RED
RED
(Lighting)
(Blinks Slowly)
(Blinks Fast)
(Blinking)
(Lighting)
(Lighting)
4-5 POWER SUPPLY CIRCUIT
VOLTAGE LINE
4-6 PORT ALLOCATION
4-6-1 D/A CONVERTER IC (IC8)
Pin Port
number name
11
23
22
14
15
BAL
T2
T1
LVA
REF
Outputs the modulation balance level
control signal. The signal is applied to
the buffer amplifier (IC7, pin 3).
Outputs the bandpass filter tuning
•
signal during receive. The output
signal is applied to the bandpass
filters (D9, D10).
• Outputs the TX power control signal
during transmit. The output signal is
applied to the APC amplifier (IC2,
pin 1).
Outputs the bandpass filter tuning
signal. The output signal is applied to
the bandpass filters (D4, D8).
Outputs the PLL lock voltage control
signal. The output signal is applied to
the buffer amplifier (IC7, pin 3).
Outputs the reference oscillator
correcting voltage. The voltage is applied
to the buffer amplifier (IC7, pin 5).
Description
LINE
VCC
+5V
S5V
R5V
T5V
DESCRIPTION
The voltage from the connected battery pack.
Common 5 V converted from the VCC line at
the +5 regulator circuit (IC9). The output voltage
is supplied to the D/A converter (IC8), analog
SW (IC10) and so on.
Common 5 V converted from the VCC line at
the S5 regulator circuit (Q23–Q25). The output
voltage is supplied to the ripple filter (Q17), PLL
IC (IC4), etc.
Receive 5 V converted from the S5V line at the
R5 regulator circuit (Q22). The output voltage
is supplied to the tripler (Q19), FM IF IC (IC1),
IF amplifier (Q4), VCO switch (Q15, Q16), 1st
mixer (Q3), etc.
Transmit 5 V converted from the S5V line at the
T5 regulator circuit (Q21). The output voltage
is supplied to the pre-drive (Q9), APC amplifier
(IC2).
4 - 5
Page 12
4-6-2 CPU (IC13)
Pin
number
Port
name
1TEMP
2BATV
7RES
13SENC0
14SENC1
16DUSE
17BUSY
18AFON
19SENC2
20SENC3
21CBI0
22CBI1
23CENC0
24CENC1
25CENC2
26CBI2
27CBI3
28SCK
29SO
30BEEP
31ESDA
32ESCL
33UNLK
34PLST
36NWC
37DAST
38S5C
39T5C
40R5C
Description
Input port for the transceiver’s
internal temperature detecting
signal.
Input port for the detect signal for
connecting battery pack’s voltage.
Input port for power reset signal.
Output single tone encoder
signal.
Outputs DTSC LPF control
signal.
Outputs AF power amplifier
control signal.
Output single tone encoder
signal.
Input ports for ritary selectoir.
Output CTCSS/DTCS signals.
Input ports for ritary selectoir.
Outputs serial clock signal to the
PLL IC (IC4, pin 9), D/A convertor
(IC6, pin 7), etc.
Outputs serial data to the PLL IC
(IC6, pin 8) and D/A convertor
(IC6, pin 8).
Outputs beep audio signals.
I/O port for data signals from/to
the EEPROM (IC15, pin 5).
Outputs clock signal to the
EEPROM (IC15, pin 6).
Input port for unlock signal from
PLL IC.
Outputs strobe signals to the PLL
IC (IC4, pin 11).
Output/input port for wide/narrow
control signal.
• Outputs strobe signals to the
D/A convertor (IC8, pin 6).
• Input port for the connecting
battery type detect signal.
Outputs power save control
signal.
Outputs T5 regurator control
signal.
Low: While transmitting
Outputs R5 regurator control
signal.
Low: While receivinging
Pin
number
Port
name
Description
42RLED Outputs receiving LED control signal.
43TLED
Outputs transmitting LED control
signal.
44OPT3
45OPT1
I/O ports for option unit.
46OPT2
Input port for the PTT switch detection
47PTT
48SI
49CLI
50CLO
53NOIS
signal.
Low : While the PTT switch is pushed.
Serial Bus inputport.
Input port for the cloning data signal.
Outputs the cloning data signal.
Input port for the noise signal from the
FM IF IC (MAIN unit; IC1, pin 13).
54CIRQ Input port for option unit detection.
55CCS Outputs chip select signal.
56TMUT Outputs transmit mute signal.
57RMUT
Input port for AF mute signal from the
RX circuit.
58MMUT Outputs MIC mute signal.
59REMO Inputs key signal from remote mic.
60CDEC
61SDEC
Input port for CTCSS/DTCS signal
from the amplifier (IC5, pin 8).
Input port for single tone decode
signal from the LPF (IC5, pin 8).
62KEY Inputs key input signal.
63RSSI
64LVIN
Input port for the S-meter signal from
the FM IF IC (IC1, pin 12).
Input port for the PLL lock voltage
.
4 - 6
Page 13
SECTION 5. ADJUSTMENT PROCEDURE
5-1 PREPARATION
¤ REQUIRED EQUIPMENTS
EQUIPMENT
Adjustment
Software
Audio Generator
RF Power Meter
(terminated type)
Frequency Counter
Modulation
Analyzer
SYSTEM REQUIREMENTS
• Microsoft® Windows® 98/SE/ME/2000/XP
• RS232C/USB port
"CS-F14 ADJ" (Revision 1.0 or later)
Frequency range : 300–3000 Hz
Output level : 1–500 mV
Measuring range :
Frequency range : 100–300 MHz
Impedance : 50
SWR : Less than 1.2 : 1
Frequency range : 0.1–300 MHz
Frequency accuracy
Input level : Less than 1 mW
Frequency range : 30–300 MHz
Measuring range : 0 to ±10 kHz
SPECIFICATION
1–6 W
Ω
: ±1 ppm or better
EQUIPMENTSPECIFICATION
JIG cable
(see the page 5-3)
Attenuator
Standard Signal
Generator (SSG)
AC MillivoltmeterMeasuring range : 10 mV to 10 V
Oscilloscope
External Speaker
Modifi ed OPC-478U/UC (USB type) or
OPC-478 (RS-232 type)
Power attenuation : 30 dB
Capacity : More than 6 W
Frequency range : 0.1–300 MHz
Output level : 0.1 mV to 32 mV
(–127 to –17 dBm)
Frequency range : DC–20 MHz
Measuring range : 0.01–20 V
Input impedance : 8
Capacity : More than 5 W
Ω
BEFORE STARTING SOFTWARE ADJUSTMENT
Clone adjustment freqencies, TX power, CTCSS frequency,
DTCS code and IF bandwidth into the transceiver using with
the CS-F14 CLONING SOFTWARE before starting adjustment.
See the next page for detail.
CAUTION!: BACK UP the originally programmed memory
data in the transceiver before programming
the adjustment frequencies.
When program the adjustment frequencies
into the transceiver, the transceiver’s memory
data will be overwritten and lose original
memory data at the same time.
Microsoft, Windows and Windows Vista are either registered
trademarks or trademarks of Microsoft Corporation in the
United States and/or other countries.
5 - 1
Page 14
¤ ADJUSTMENT CHANNELS
Create "icf" file/files for adjustment as below, then clone it into the transceiver before starting adjustment.
<For IC-F14/F15/F16/F3018>
q Create the icf file "F14 ADJ CH.icf."
“F14 ADJ CH.icf”
w Clone the icf file into the transceiver.
<For IC-F14S/F15S/F16S>
q Assigne MR-CH3/MR-CH4 to the [Upper]/[Lower] keys.
w Create five icf files as below.
“ADJ CH FREQ.icf”
“ADJ CH TXPWR.icf”
“ADJ CH AudioMOD.icf”
“ADJ CH ToneMOD.icf”
5 - 2
“ADJ CH RX.icf”
Page 15
CONNECTION
(
AC millivoltmeter
Standard signal generator
0.1 µV to 32 mV
(–127 dBm to –17 dBm)
DO NOT transmit while
an SSG is connected to
the antenna connector.
FM
deviation meter
Attenuator
20 dB / 30 dB
RF power meter
0.1–10 W/50 Ω
Frequency
counter
to the antenna connector
OPC-478
(RS-232C type)
To [SP]
To [MIC]
to USB port
OPC-478U
(USB type)
OPC-478UC
(USB type)
To [SP] connector
JIG cable
Audio generator
to RS-232C port
PC
to USB port
SINAD meter
JIG CABLE
(
To [SP] jack
3-conductor 3.5(d) mm plug
JIG cable
Speaker (8 Ω)
( SP + )
(SP − )
(GND)
OPC-478/U/UC
(CLONE)
5 - 3
Page 16
P STARTING SOFTWARE ADJUSTMENT
(1) Connect the transceiver and PC with OPC-478/U/UC and JIG CABLE (see the previous page).
(2) Turn the transceiver power ON.
(3) Boot up Windows, and click the program group 'CS-F14 ADJ’ in the ‘Programs’ folder of the [Start] menu, then CS-F14 ADJ’s
window appears.
(4) Click ‘Connect’ on the CS-F14’s window, then IC-F14’s up-to-date condition appears as below.
(5) Set or modify adjustment value as specified in following guidances.
ADJUSTMENT WINDOW
(
NOTE: The above screen is an example.
Each transceiver has its own specific values for each setting.
5 - 4
Page 17
5-2 FREQUENCY ADJUSTMENT
1) Select an adjustment item using cursor or [↑] / [↓] keys of the PC’s keyboard.
2) Set or modify the adjustment value as specifi ed using [←] / [→] keys of the PC’s keyboard, then push the [ENTER] key.
ADJUSTMENTADJUSTMENT CONDITIONOPERATION
PLL LOCK
VO LTAGE
-Preparation-
-AdjustRX
TX3 • CH. (16CH/2CH) : CH.1/CH.1
LOCK
VO LTAGE
VERIFICATION
RX
TX2 • CH. (16CH/2CH) : CH.2/CH.2
REFERENCE
FREQUENCY
1
<For IC-F14S/F15S/F16S only>
Clone the "ADJ CH FREQ.icf" into the transceiver.
2 • Connect an RF Power Meter to
the antenna.
2 • CH. (16CH/2CH) : CH.1/CH.1
• Receiving
• Transmitting
1
<For IC-F14S/F15S/F16S only>
• Monitoring lock voltage at the "LVIN"
in the "ADJUSTMENT WINDOW"
(see the previous page), adjust the
[RX LVA] using [←] / [→] keys on the
PC’s keyboard.
or
• Set the [RX LVA] to "179", then
push the [ENTER] key.
• Monitoring lock voltage at the "LVIN"
in the "ADJUSTMENT WINDOW"
(see the previous page), adjust the
[TX LVA] using [←] / [→] keys on the
PC’s keyboard.
or
• Set the [TX LVA] to "179", then push
the [ENTER] key.
Clone the "ADJ CH FREQ.icf" into the transceiver.
• CH. (16CH/2CH) : CH.2/CH.2
• Receiving
• Transmitting
1
2 • CH. (16CH/2CH) : CH.1/CH.1
• Transmitting
–
• Verify the lock voltage at the "LVIN"
in the "ADJUSTMENT WINDOW"
(see the previous page).
• Connect an RF Power Meter to the
antenna.
1) Adjust the frequency using [←] / [→]
keys on the PC’s keyboard.
2) Push the [ENTER] key to store the
adjust value.
–––
ADJUSTMENT
ITEM
[RX LVA]
[TX LVA]
[LVIN]
–
[REF]
(at the "LVIN"
(at the [RX/TX
173.9000 MHz
VALUE
3.5 V
item)
or
"179"
LVA])
0.9–1.5 V
(Verify)
3.0–4.0 V
(Verify)
–
5 - 5
Page 18
5-3 TRANSMIT ADJUSTMENT
1) Select an adjustment item using cursor or [↑] / [↓] keys of the PC’s keyboard.
2) Set or modify the adjustment value as specifi ed using [←] / [→] keys of the PC’s keyboard, then push the [ENTER] key.
ADJUSTMENTADJUSTMENT CONDITIONOPERATION
TRANSMIT
OUTPUT
POWER
-Preparation-
1
<For IC-F14S/F15S/F16S only>
Clone the "ADJ CH TXPWR.icf" into the transceiver.
–
• Connect an RF Power Meter to the
antenna connector.––
ADJUSTMENT
ITEM
VALUE
-Adjustment-Hi2 • CH. (16CH/2CH) : CH.3/CH.1
L23 • CH. (16CH/2CH) : CH.4/CH.2
L14 • CH. (16CH/2CH) : CH.5/CH.3
DEVIATION
-Preparation-
-AdjustmentWIDE
MIDDLE*4 • CH. (16CH/2CH) : CH.6/CH.1
NARROW5 • CH. (16CH/2CH) : CH.7
• Transmitting
• Transmitting
• Transmitting
1
<For IC-F14S/F15S/F16S only>
Clone the "ADJ CH AudioMOD.icf" into the transceiver.
• Connect a Modulation Analyzer
to the antenna connector
through an Attenuator.
2• Connect an Audio Generator
to the MIC line through the JIG
cable.
3 • CH. (16CH/2CH) : CH.5/CH.2
• Transmitting
• Transmitting[MOD Ratio]
• Transmitting[MOD N]
1) Adjust the transmit output power
using [←] / [→] keys on the PC’s
keyboard.
2) Push the [ENTER] key to store the
adjust value.
• Set the Modulation Analyzer as;
HPF : OFF
LPF : 20 kHz
De-emphasis : OFF
Detector : (P-P)/2
• Set the Audio Generator as;
Modulation : 1 kHz
Level : 40 mV rms
Wave form : Sine wave
1) Adjust the deviation using [←] / [→]
keys on the PC’s keyboard.
2) Push the [ENTER] key to store the
adjust value.
[Power (Hi)]5.0 W
[Power (L2)]
[Power (L1)]
––
––
[MOD Ratio]
2.0 W
1.0 W
±4.05–4.15
kHz
±3.15–3.25
kHz
±2.05–2.15
kHz
MODULATION
BALANCE
-Preparation-
-AdjustmentNARROW
MIDDLE*3 • CH. (16CH/2CH) : CH.8/CH.1
WIDE4 • CH. (16CH/2CH) : CH.9/CH.2
CTCSS/DTCS
DEVIATION
-Preparation-
-Adjustment-2 • CH. (16CH/2CH) :
*: F15/S only
1
<For IC-F14S/F15S/F16S only>
Clone the "ADJ CH ToneMOD.icf" into the transceiver.
• Connect a Modulation Analyzer
to the antenna connector
through an attenuator.
• Connect an Oscilloscope to
the Detect terminal of the
Modulation Analyzer.
2 • CH. (16CH/2CH) : CH.8/CH.1
• Transmitting
• Transmitting
• Transmitting
1
<For IC-F14S/F15S/F16S only>
Clone the "ADJ CH ToneMOD.icf" into the transceiver.
• Connect a Modulation Analyzer
to the antenna connector
through an attenuator.
CH.10/CH.3
• Transmitting
• Set the Modulation Analyzer as;
HPF : OFF
LPF : 20 kHz
De-emphasis : OFF
Detector : (P-P)/2
–––
1) Adjust the waveform using [←] / [→]
keys on the PC’s keyboard.
2) Push the [ENTER] key to store the
adjust value.
• Set the Modulation Analyzer as;
HPF : OFF
LPF : 20 kHz
De-emphasis : OFF
Detector : (P-P)/2
1) Adjust the deviation using [←] / [→]
keys on the PC’s keyboard.
2) Push the [ENTER] key to store the
adjust value.
––
[BAL N]
[BAL Ratio]
[BAL Ratio]
––
[CTCSS/DTCS]
Square
waveform
Flat
±0.66–0.70
kHz
5 - 6
Page 19
5-2 RECEIVE ADJUSTMENT
1) Select an adjustment item using cursor or [↑] / [↓] keys of the PC’s keyboard.
2) Set or modify the adjustment value as specifi ed using [←] / [→] keys of the PC’s keyboard, then push the [ENTER] key.
ADJUSTMENTADJUSTMENT CONDITIONOPERATION
RECEIVE
SENSITIVITY
-Preparation-
-Adjustment-2 • CH. (16CH/2CH) :
SQUELCH
-Preparation-
-Adjustment-2 • CH. (16CH/2CH) :
1
<For IC-F14S/F15S/F16S only>
Clone the "ADJ CH RX.icf" into the transceiver.
• Connect an SSG to the
antenna connector.
CH.11/CH.1
• Receiving
CONVINIENT: [BPF (T1)] and [BPF (T2)] can be adjusted at same time as below.
2 • CH. (16CH/2CH) :
• Receiving
1
<For IC-F14S/F15S/F16S only>
CH.11/CH.1
• Set the SSG as;
Frequency : 136.1000 MHz
Level : +20 dB
Modulation : 1 kHz
Deviation : 3.5 kHz
1) Select the item [BPF (T1)], then
push the [ENTER] key.
2) Select the item [BPF (T2)], then
push the [ENTER] key.
• Select the item [BPF ALL], then
push the [ENTER] key.
Clone the "ADJ CH RX.icf" into the transceiver.
• Connect an SSG to the
antenna connector.
CH.12/CH.2
• Receiving
• Set the SSG as;
Frequency : 155.0000 MHz
Level : –14 dB
Modulation : 1 kHz
Deviation : 3.5 kHz
1)
Decrease the adjustment value
[SQL] to close the squelch once,
then increase the value to open the
squelch.
2) Select the item [SQL], then push
the [ENTER] key to store the adjust
value.
μ
μ
ADJUSTMENT
ITEM
––
[BPF (T1)]
[BPF (T2)]
[BPF ALL]
––
[SQL]
(Automatic
adjustment)
(Automatic
adjustment)
(Automatic
adjustment)
VALUE
5 - 7
Page 20
SECTION 6. PARTS LIST
[MAIN UNIT]
REF PARTS
NO. NO.
IC1 1110003201 S.IC TA31136FNG (EL) B 51.8/19
IC2 1110002751 S.IC TA75S01F (TE85R,F) T 68.9/21
IC4 1140005991 S.IC MB15A02PFV1-G-BND-ERE1 T 38.3/35.7
IC5 1110005340 S.IC NJM12902V-TE1-#ZZZB T 29.7/11.6
IC6 1110005320 S.IC NJM13403V-TE1-#ZZZB T 16/34.6
IC7 1110005340 S.IC NJM12902V-TE1-#ZZZB T 29.9/34.6
IC8 1190000350 S.IC M62363FP-650C T 40.3/15.2
IC9 1110005350 S.IC NJM2870F05-TE1-#FZZB B 84.2/14.2
IC10 1130011770 S.IC CD4066BPWR T 22.9/34.6
IC12 1110001811 S.IC TA7368FG (5,ER) T 89.6/13.6
IC13 1140012721 S.IC HD6433687C73FPV T 12.5/14.3
IC14 1110006260 S.IC BD5242G-TR T 6.6/5.9
IC15 1130011540 S.IC BR24L16FV-WE2 B 16/11.6
Q1 1560000841 S.FET 2SK1829 (TE85R,F) T 75/39.5
Q2 1580000731 S.FET 3SK293 (TE85L,F) B 77.8/37.9
Q3 1580000800 S.FET 3SK324UG-TL-E B 66.2/37.9
Q4 1530003311 S.TR 2SC5107-O (TE85R,F) B 51.4/23.1
Q6 1590003230 S.TR UNR9113J-(TX) T 71.7/19.1
Q7 1560001232 S.FET RD07MVS2-T112 T 82.6/27
Q8 1560001241 S.FET RD01MUS1-T113 T 76.1/27.6
Q9 1530003421 S.TR 2SC5110-O (TE85R,F) T 70.7/34.4
Q10 1530003311 S.TR 2SC5107-O (TE85R,F) T 59.4/36.3
Q11 1530003311 S.TR 2SC5107-O (TE85R,F) B 56.8/36.4
Q12 1530003311 S.TR 2SC5107-O (TE85R,F) T 59.1/31.6
Q13 1530002920 S.TR 2SC4226-T1 R25 T 54.1/32.3
Q14 1530002920 S.TR 2SC4226-T1 R25 T 54.1/34.8
Q15 1590001400 S.TR XP1214 (TX) B 56.5/32.6
Q16 1590003290 S.TR UNR9213J-(TX) B 59.1/32.6
Q17 1530002851 S.TR 2SC4116-BL (TE85R,F) T 55.5/44.1
Q18 1560000541 S.FET 2SK880-Y (T5RICOM,F) B 51.5/39.2
Q19 1530002851 S.TR 2SC4116-BL (TE85R,F) T 43.3/29.9
Q20 1560001360 S.FET 2SK3019 TL T 27.7/29.4
Q21 1510000920 S.TR 2SA1577 T106 Q T 71.9/16.4
Q22 1510000920 S.TR 2SA1577 T106 Q T 24.9/25.9
Q23 1520000460 S.TR 2SB1132 T100 R T 81.1/15.1
Q24 1590001190 S.TR XP6501-(TX) .AB T 76.5/15.1
Q25 1590003230 S.TR UNR9113J-(TX) T 75.7/11.7
Q26 1590003290 S.TR UNR9213J-(TX) T 49.6/18.4
Q27 1590003290 S.TR UNR9213J-(TX) T 24.8/16.7
Q28 1590003430 S.TR UNR911HJ-(TX) B 63.8/10.8
Q29 1590003270 S.TR UNR9210J-(TX) B 36.1/9.4
Q30 1510001080 S.TR 2SA2048 TLR T 91.9/8.5
Q31 1590001190 S.TR XP6501-(TX) .AB T 91.4/5.2
Q32 1590003020 S.TR XP4216-(TX) T 16.5/23.5
Q33 1590003230 S.TR UNR9113J-(TX) T 19.9/22.5
Q34 1560001360 S.FET 2SK3019 TL T 11.6/31.9
Q35 1560001360 S.FET 2SK3019 TL T 9.5/30.5
Q39 1530002060 S.TR 2SC4081 T106 R B 39.1/42.7
Q40 1510000510 S.TR 2SA1576A T106R B 39.1/40
Q41 1590003290 S.TR UNR9213J-(TX) B 59.7/11.9
D1 1790001790 S.DIO RB876W TL B 93.6/17.6
D2 1750000581 S.DIO 1SV307 (TPH3,F) B 91.5/31.1
D4 1750000721 S.VCP HVC375BTRF-E B 80.3/33.4
D5 1750000581 S.DIO 1SV307 (TPH3,F) B 87.6/33.4
D6 1790001260 S.DIO MA2S077-(TX) B 86.7/35.9
D8 1750000721 S.VCP HVC375BTRF-E B 83/33.4
D9 1750000711 S.VCP HVC350BTRF-E B 73.6/37.7
D10 1750000711 S.VCP HVC350BTRF-E B 72.3/37.7
D14 1790001260 S.DIO MA2S077-(TX) T 65.8/35.3
D15 1790001260 S.DIO MA2S077-(TX) T 65.8/36.7
D16 1750000771 S.VCP HVC376BTRF-E T 55.1/28.8
D17 1750000771 S.VCP HVC376BTRF-E T 53.7/28.8
D18 1720000471 S.VCP 1SV239 (TPH3,F) B 49.6/28.2
D19 1750000771 S.VCP HVC376BTRF-E T 53.6/37.8
D20 1750000771 S.VCP HVC376BTRF-E T 50.9/37.5
D21 1750000721 S.VCP HVC375BTRF-E T 49.2/31.5
D22 1750000721 S.VCP HVC375BTRF-E T 49.2/34.9
D23 1790001250 S.DIO MA2S111-(TX) T 70.5/40.4
D24 1790001250 S.DIO MA2S111-(TX) T 41.5/39.2
D26 1790001790 S.DIO RB876W TL B 36.1/7.3
D27 1750000520 S.DIO DAN222TL B 21.3/6.5
D28 1790001260 S.DIO MA2S077-(TX) B 8.5/11.2
D29 1750000940 S.DIO ISS400 TE61 B 21.5/4.2
D30 1790001260 S.DIO MA2S077-(TX) T 28.6/42.4
X1 6070000191 S.DCR CDBKB450KCAY24-R0 T 54.4/20
X2 6050011940 S.XTL CR-783 (15.3 MHz) T 36.9/28.9
X3 6050011720 S.XTL CR-764 (19.6608 MHz) B 12/5.9
L1 6200012780 S.COL 0.30-1.4-6TL 27.2N <COMO> B 94.9/40.3
L2 6200012470 S.COL 0.30-1.7-7TL 45.3N <COMO> B 94.6/36.2
L3 6200012910 S.COL 0.35-1.6-8TL 45.5N <COMO> B 94.6/31.9
L4 6200012470 S.COL 0.30-1.7-7TL 45.3N <COMO> B 92.5/25.7
L5 6200012390 S.COL 0.30-0.92-3TR 5.8N <COMO> B 89.8/19.8
L6 6200012470 S.COL 0.30-1.7-7TL 45.3N <COMO> B 89.5/36.5
L7 6200007871 S.COL ELJRF 39NJFB B 86.8/37.7
L8 6200008090 S.COL LQW2BHN68NJ03L B 83.9/35.2
L9 6200008090 S.COL LQW2BHN68NJ03L B 79.6/35.2
DESCRIPTION
M.
H/V
LOCATION
[MAIN UNIT]
REF PARTS
NO. NO.
L10 6200007750 S.COL LQW2BHN56NJ03L B 76.4/35
L11 6200007750 S.COL LQW2BHN56NJ03L B 70.6/37.8
L12 6200008090 S.COL LQW2BHN68NJ03L B 64/40.2
L13 6200007850 S.COL ELJNC R82K-F B 66.8/33.9
L15 6200002861 S.COL NLV25T-4R7J T 93.2/31.7
L16 6200012400 S.COL 0.30-0.91-4TL 8.6N <COMO> B 86.2/20.8
L17 6200013100 S.COL 0.45-1.5-5TL 18.3N <COMO> B 81.2/20.8
L18 6200005701 S.COL ELJRE 22NGFA T 79/22.5
L19 6200010401 S.COL ELJRE 39NJFA T 73/32.9
L20 6200003590 S.COL EXCCL3225U1 B 81.5/17.6
L21 6200011031 S.COL ELJRF R10JFB T 59.2/38.6
L22 6200011031 S.COL ELJRF R10JFB T 59.9/29.8
L23 6200011031 S.COL ELJRF R10JFB B 55.9/38.3
L24 6200003640 S.COL MLF1608E 100K-T T 49.3/27.5
L25 6200007760 S.COL LQW2BHN82NJ03L T 50.1/29.3
L26 6200008090 S.COL LQW2BHN68NJ03L T 48.5/38
L27 6200007170 S.COL MLF1608A 3R3K-T B 52.2/30.9
L28 6200007170 S.COL MLF1608A 3R3K-T B 52.2/35.5
L31 6200011021 S.COL ELJRF 82NJFB B 83.4/38.7
L32 6200007881 S.COL ELJRF 33NJFB B 55.9/42.3
L33 6200004480 S.COL MLF1608D R82K-T T 43.4/25.9
L35 6200003540 S.COL MLF1608D R22K-T T 41.7/31.8
L37 6200003640 S.COL MLF1608E 100K-T T 53.7/39.1
L38 6200008090 S.COL LQW2BHN68NJ03L T 57.9/27.7
L39 6200007720 S.COL LQW2BHN33NJ03L T 55.9/38
L42 6200007170 S.COL MLF1608A 3R3K-T B 48.5/34.1
L43 6200007170 S.COL MLF1608A 3R3K-T B 48.5/30.9
R1 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k) B 93.6/20.2
R2 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 73.3/19.4
R3 7030005530 S.RES ERJ2GEJ 100 X (10 ) T 66.7/22.8
R4 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 75.3/21.1
R5 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 73.3/21.1
R6 7030005070 S.RES ERJ2GEJ 683 X (68 k) T 66.7/17.7
R7 7030005310 S.RES ERJ2GEJ 124 X (120 k) T 68/17.7
R8 7030005110 S.RES ERJ2GEJ 224 X (220 k) T 71.3/21.1
R9 7030004980 S.RES ERJ2GEJ 101 X (100 ) T 70.3/23.9
R10 7030005030 S.RES ERJ2GEJ 152 X (1.5 k) B 73.2/19.9
R11 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 82.3/34.7
R12 7030005530 S.RES ERJ2GEJ 100 X (10 ) T 77.1/36.7
R13 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 80.6/34.7
R14 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 80.6/35.7
R15 7030005310 S.RES ERJ2GEJ 124 X (120 k) B 79.8/39
R16 7030008280 S.RES ERJ2GEJ 271 X (270 ) B 74.8/39.9
R17 7030004970 S.RES ERJ2GEJ 470 X (47 ) B 74.8/33.9
R18 7030005530 S.RES ERJ2GEJ 100 X (10 ) T 79.9/36.7
R19 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 78.8/37.7
R20 7030008370 S.RES ERJ2GEJ 561 X (560 ) B 72.9/40.4
R21 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 72.2/38.9
R22 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 70.2/38.9
R23 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 71.2/38.9
R24 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 64.6/38
R25 7030005080 S.RES ERJ2GEJ 823 X (82 k) B 68/37.8
R26 7030005000 S.RES ERJ2GEJ 471 X (470 ) B 68.5/40.1
R27 7030005000 S.RES ERJ2GEJ 471 X (470 ) B 66/41.7
R28 7030005530 S.RES ERJ2GEJ 100 X (10 ) B 66/40.8
R29 7030005590 S.RES ERJ2GEJ 680 X (68 ) B 64.2/35.1
R30 7030005000 S.RES ERJ2GEJ 471 X (470 )
[RUS-02], [RUS-05] only B 67.7/35.7
R31 7030007250 S.RES ERJ2GEJ 220 X (22 ) B 64.2/32.1
R32 7030010040 S.RES ERJ2GEJ-JPW B 66.1/31.1
R33 7030007270 S.RES ERJ2GEJ 151 X (150 )
[RUS-02], [RUS-05] only B 55.7/24.8
R34 7030008300 S.RES ERJ2GEJ 184 X (180 k) B 52.5/25.2
R35 7030004980 S.RES ERJ2GEJ 101 X (100 ) B 50.5/25.2
R36 7030008410 S.RES ERJ2GEJ 392 X (3.9 k) T 52.5/15.5
R37 7030009140 S.RES ERJ2GEJ 272 X (2.7 k) T 50.7/16.3
R38 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 46.5/21
R39 7030004970 S.RES ERJ2GEJ 470 X (47 ) B 55.8/22.3
R40 7030005030 S.RES ERJ2GEJ 152 X (1.5 k) B 56.2/21.1
R42 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 51.8/15.4
R43 7030005000 S.RES ERJ2GEJ 471 X (470 ) B 47.5/15.4
R44 7030006610 S.RES ERJ2GEJ 394 X (390 k) B 54.8/15.4
R45 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 52.8/13.7
R46 7030007290 S.RES ERJ2GEJ 222 X (2.2 k) B 53.8/13.7
R48 7030005010 S.RES ERJ2GEJ 681 X (680 ) B 51.5/25.2
R50 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 66.3/38
R51 7030003670 S.RES ERJ3GEYJ 823 V (82 k) B 97.3/41
R52 7030003350 S.RES ERJ3GEYJ 181 V (180 ) T 93.1/34.9
R53 7030007250 S.RES ERJ2GEJ 220 X (22 ) T 80.2/22.9
R54 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 81.5/21.8
R55 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 79/20.8
R57 7030005590 S.RES ERJ2GEJ 680 X (68 ) T 74.3/23.9
R58 7030005060 S.RES ERJ2GEJ 333 X (33 k) T 72.3/23.9
R59 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 71.3/23.9
R61 7030005530 S.RES ERJ2GEJ 100 X (10 ) T 71.4/36.2
R62 7030004980 S.RES ERJ2GEJ 101 X (100 ) T 68.7/32.3
R63 7030005000 S.RES ERJ2GEJ 471 X (470 ) T 68.1/35.2
R65 7030007290 S.RES ERJ2GEJ 222 X (2.2 k) T 68.7/33.9
R67 7030004980 S.RES ERJ2GEJ 101 X (100 ) T 65.6/34.1
R68 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 65.6/33.1
R69 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 61.4/36.1
R70 7030004980 S.RES ERJ2GEJ 101 X (100 ) B 57.7/39.3
R71 7030005310 S.RES ERJ2GEJ 124 X (120 k) T 58.1/38.6
R72 7030009320 S.RES ERJ2GEJ 4R7 X (4.7 ) T 59.9/34.4
R75 7030005110 S.RES ERJ2GEJ 224 X (220 k) B 58.6/37
R76 7030004980 S.RES ERJ2GEJ 101 X (100 ) B 57.7/38.3
DESCRIPTION
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
6 - 1
M.
S.=Surface mount
H/V
LOCATION
Page 21
[MAIN UNIT]
REF PARTS
NO. NO.
R77 7030004980 S.RES ERJ2GEJ 101 X (100 ) B 57.5/30.5
R78 7030005310 S.RES ERJ2GEJ 124 X (120 k) T 58.2/33.4
R79 7030008340 S.RES RR0510P-182-D (1.8 k) T 53.7/36.6
R80 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 56.5/30.5
R81 7030010040 S.RES ERJ2GEJ-JPW T 51.7/35.3
R82 7030009320 S.RES ERJ2GEJ 4R7 X (4.7 ) T 51.7/32.8
R83 7030008340 S.RES RR0510P-182-D (1.8 k) T 53.6/30.5
R84 7030011000 S.RES RR0510P-392-D (3.9 k) T 50.4/32.8
R85 7030011000 S.RES RR0510P-392-D (3.9 k) T 50.4/34.5
R86 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 47.5/26.9
R87 7030008370 S.RES ERJ2GEJ 561 X (560 ) B 54.6/34.1
R88 7030008370 S.RES ERJ2GEJ 561 X (560 ) B 54.6/32.4
R89 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 50.8/36.8
R90 7030005110 S.RES ERJ2GEJ 224 X (220 k) B 47.5/25.2
R91 7030005060 S.RES ERJ2GEJ 333 X (33 k) B 46.5/23.5
R92 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 46.5/25.2
R93 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 39.8/39.4
R94 7030005100 S.RES ERJ2GEJ 154 X (150 k) T 43.3/37.7
R95 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 50.8/35.8
R96 7030009270 S.RES ERJ2GEJ 821 X (820 ) B 49.4/36.3
R97 7030008280 S.RES ERJ2GEJ 271 X (270 ) B 47/36.8
R98 7030007290 S.RES ERJ2GEJ 222 X (2.2 k) T 53.7/44
R100 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 53.6/38.3
R101 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 51.4/42.3
R102 7030005700 S.RES ERJ2GEJ 274 X (270 k) T 32.3/27.8
R103 7030005160 S.RES ERJ2GEJ 105 X (1 M) T 32.3/29.8
R104 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 30.6/29.8
R105 7030005100 S.RES ERJ2GEJ 154 X (150 k) T 30.6/28.8
R106 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 38.1/31.4
R107 7030004970 S.RES ERJ2GEJ 470 X (47 ) B 55.9/43.3
R108 7030005070 S.RES ERJ2GEJ 683 X (68 k) T 44.9/21
R109 7030008300 S.RES ERJ2GEJ 184 X (180 k) T 43.9/21
R110 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 6.1/27.6
R111 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 29.3/28.9
R113 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) B 47/31.7
R115 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 40.5/32
R116 7030007060 S.RES ERJ2GEJ 684X (680 k) T 43.4/32.7
R117 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 35.3/40.1
R118 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 37/40.1
R121 7030005110 S.RES ERJ2GEJ 224 X (220 k) T 77.1/35.7
R122 7030008290 S.RES ERJ2GEJ 183 X (18 k) T 77.1/38.7
R123 7030009290 S.RES ERJ2GEJ 562 X (5.6 k) T 75.7/37.2
R124 7030005170 S.RES ERJ2GEJ 474 X (470 k) T 72.7/40.4
R125 7030005230 S.RES ERJ2GEJ 334 X (330 k) T 73.2/38.9
R131 7510001730 S.TMR ERTJOEP 473J T 40.9/28.1
R132 7030010080 S.RES ERJ2RHD 104 X (100 k) T 40.9/27.1
R133 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 84.2/14.1
R134 7030007290 S.RES ERJ2GEJ 222 X (2.2 k) T 76.2/16.9
R135 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 24.5/24
R136 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 22.5/24
R137 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 69.8/14.7
R138 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 69.8/16.7
R140 7030010040 S.RES ERJ2GEJ-JPW T 37.1/20.3
R141 7030005000 S.RES ERJ2GEJ 471 X (470 ) T 37.1/9.8
R142 7030005000 S.RES ERJ2GEJ 471 X (470 ) T 42.9/9.8
R143 7030007340 S.RES ERJ2GEJ 153 X (15 k) T 37.1/22.8
R144 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 46.5/13.7
R145 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 33.4/18.1
R146 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 31.6/18.1
R147 7030007350 S.RES ERJ2GEJ 393 X (39 k) T 33.4/16.1
R148 7030005080 S.RES ERJ2GEJ 823 X (82 k) T 31.6/16.1
R149 7030006610 S.RES ERJ2GEJ 394 X (390 k) T 33.4/12.9
R150 7030008300 S.RES ERJ2GEJ 184 X (180 k) T 33.4/11.9
R151 7030005030 S.RES ERJ2GEJ 152 X (1.5 k) T 33.4/13.9
R152 7030005220 S.RES ERJ2GEJ 223 X (22 k) T 32.3/41.1
R153 7030005220 S.RES ERJ2GEJ 223 X (22 k) T 32.3/40.1
R154 7030005220 S.RES ERJ2GEJ 223 X (22 k) T 30.6/40.1
R155 7030007300 S.RES ERJ2GEJ 332 X (3.3 k) T 28.6/41.1
R156 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 28.6/40.1
R157 7030007290 S.RES ERJ2GEJ 222 X (2.2 k) T 26.9/39.1
R159 7030008010 S.RES ERJ2GEJ 123 X (12 k) T 16/28.8
R160 7030004980 S.RES ERJ2GEJ 101 X (100 ) B 7.1/31.5
R161 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 14.3/26.8
R162 7030005290 S.RES ERJ2GEJ 682 X (6.8 k) T 9/32.6
R163 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 14.3/29.8
R164 7030008410 S.RES ERJ2GEJ 392 X (3.9 k) T 12.6/27.8
R165 7030008410 S.RES ERJ2GEJ 392 X (3.9 k) T 10/34.4
R166 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 12.6/36.1
R167 7030009290 S.RES ERJ2GEJ 562 X (5.6 k) T 16/29.8
R168 7030005000 S.RES ERJ2GEJ 471 X (470 ) T 13/39.2
R169 7030005100 S.RES ERJ2GEJ 154 X (150 k) T 15.4/39.9
R170 7030008010 S.RES ERJ2GEJ 123 X (12 k) T 12.6/29.8
R171 7030005100 S.RES ERJ2GEJ 154 X (150 k) T 11.6/36.1
R172 7030005700 S.RES ERJ2GEJ 274 X (270 k) T 17.4/39.9
R173 7030005310 S.RES ERJ2GEJ 124 X (120 k) T 19.4/26.8
R174 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 19.4/28.8
R175 7030005110 S.RES ERJ2GEJ 224 X (220 k) T 19.4/27.8
R176 7030005310 S.RES ERJ2GEJ 124 X (120 k) T 17.7/27.8
R177 7030005060 S.RES ERJ2GEJ 333 X (33 k) T 17.7/28.8
R178 7030007270 S.RES ERJ2GEJ 151 X (150 ) T 19.4/30.7
R179 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 11.4/17
R180 7030005160 S.RES ERJ2GEJ 105 X (1 M) T 24.7/40.1
R181 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 21.1/40.1
R182 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 24.7/39.1
R183 7030006020 S.RES RR0510P-682-D (6.8 k) B 17.6/39.5
R184 7030008250 S.RES RR0510P-562-D (5.6 k) B 17.6/41.2
R185 7030005100 S.RES ERJ2GEJ 154 X (150 k) B 18.6/41.2
R186 7030005310 S.RES ERJ2GEJ 124 X (120 k) T 19.4/29.8
R187 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 9.2/18.2
R190 7030007280 S.RES ERJ2GEJ 331 X (330 ) T 34.7/21.6
R191 7030008300 S.RES ERJ2GEJ 184 X (180 k) T 18/4.1
R192 7030005720 S.RES ERJ2GEJ 563 X (56 k) T 18/5.1
R193 7030005220 S.RES ERJ2GEJ 223 X (22 k) T 18/6.1
R194 7030005220 S.RES ERJ2GEJ 223 X (22 k) T 23.9/10.9
DESCRIPTION
M.
H/V
LOCATION
[MAIN UNIT]
REF PARTS
NO. NO.
R195 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 19.7/4.1
R196 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 23.9/11.9
R197 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 23.9/12.9
R198 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 25.7/12.9
R200 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 25.7/14.9
R201 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 23.9/14.9
R206 7030005110 S.RES ERJ2GEJ 224 X (220 k) T 13.4/4.1
R207 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 13.4/5.1
R208 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 15.6/5.1
R209 7030005220 S.RES ERJ2GEJ 223 X (22 k) T 15.6/6.1
R210 7030008010 S.RES ERJ2GEJ 123 X (12 k) T 15.6/4.1
R211 7030005070 S.RES ERJ2GEJ 683 X (68 k) T 27.1/4.1
R212 7030005070 S.RES ERJ2GEJ 683 X (68 k) T 27.1/5.1
R213 7030005070 S.RES ERJ2GEJ 683 X (68 k) T 27.1/6.1
R214 7030005070 S.RES ERJ2GEJ 683 X (68 k) T 29/7.1
R215 7030005070 S.RES ERJ2GEJ 683 X (68 k) T 30.8/6.1
R220 7030004980 S.RES ERJ2GEJ 101 X (100 ) B 16.1/22.5
R221 7030004980 S.RES ERJ2GEJ 101 X (100 ) B 66.5/13.7
R222 7030005060 S.RES ERJ2GEJ 333 X (33 k) B 64.4/8.7
R222 7030005220 S.RES ERJ2GEJ 223 X (22 k)
[EUR-02] only B 64.4/8.7
R223 7030005060 S.RES ERJ2GEJ 333 X (33 k) B 61.7/11.1
R224 7030005000 S.RES ERJ2GEJ 471 X (470 ) B 75.5/10.3
R225 7030004980 S.RES ERJ2GEJ 101 X (100 ) B 33.9/6.8
R226 7210003061 VAR TP76N00N-15F-A103-2251A
R227 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 95/14
R228 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 94.5/15.2
R229 7030005530 S.RES ERJ2GEJ 100 X (10 ) T 86.4/10.1
R230 7030005530 S.RES ERJ2GEJ 100 X (10 ) T 86.3/16.4
R231 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 90.6/2.8
R232 7030007300 S.RES ERJ2GEJ 332 X (3.3 k) T 93.2/4.3
R233 7030007300 S.RES ERJ2GEJ 332 X (3.3 k) T 92.6/2.8
R234 7030005100 S.RES ERJ2GEJ 154 X (150 k) B 23/6.4
R235 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 20.3/4.2
R236 7030005230 S.RES ERJ2GEJ 334 X (330 k) B 23/4.2
R237 7030009290 S.RES ERJ2GEJ 562 X (5.6 k) T 21.1/39.1
R238 7410001140 S.ARY EXB28V104JX B 40.9/9.7
R240 7030005590 S.RES ERJ2GEJ 680 X (68 ) T 99.7/13.1
R241 7030010040 S.RES ERJ2GEJ-JPW [2CH] only T 39.4/7.1
R242 7030010040 S.RES ERJ2GEJ-JPW [2CH] only T 41.4/7.1
R251 7030008010 S.RES ERJ2GEJ 123 X (12 k) B 5.9/9.1
R252 7030005530 S.RES ERJ2GEJ 100 X (10 ) B 13.7/9.1
R254 7030008010 S.RES ERJ2GEJ 123 X (12 k) B 9.3/10.1
R255 7030008010 S.RES ERJ2GEJ 123 X (12 k) B 7.6/10.1
R256 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 6/8.5
R257 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 9/22.1
R258 7410001140 S.ARY EXB28V104JX T 6.6/20.6
R259 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 21.6/22.1
R260 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 20.1/24.7
R261 7410001130 S.ARY EXB28V102JX T 19.4/19.9
R262 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 21.3/13.9
R263 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 21.3/12.9
R264 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 21.3/10.9
R265 7410001130 S.ARY EXB28V102JX T 19.7/9.2
R266 7030007340 S.RES ERJ2GEJ 153 X (15 k) T 5.7/18.8
R271 7030005160 S.RES ERJ2GEJ 105 X (1 M) B 9.5/39.5
R272 7030005160 S.RES ERJ2GEJ 105 X (1 M) B 10.5/39.5
R273 7030005160 S.RES ERJ2GEJ 105 X (1 M) B 11.5/39.5
R274 7030005070 S.RES ERJ2GEJ 683 X (68 k) B 14.5/39.5
R275 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 12.5/39.5
R276 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 7.5/39.5
R277 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 8.5/39.5
R278 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 13.5/39.5
R280 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 16.4/35.8
R284 7030004980 S.RES ERJ2GEJ 101 X (100 ) B 16/26.2
R287 7030007280 S.RES ERJ2GEJ 331 X (330 ) T 18.5/24.7
R288 7030005030 S.RES ERJ2GEJ 152 X (1.5 k) T 14.7/22.7
R291 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 5.9/12.5
R292 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 7.6/12.5
R293 7030008290 S.RES ERJ2GEJ 183 X (18 k) T 61.4/43.4
R294 7030005600 S.RES ERJ2GEJ 273 X (27 k) T 60.4/43.4
R295 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 95.1/43.4
R301 7030004980 S.RES ERJ2GEJ 101 X (100 ) B 37.1/41.2
R302 7030004980 S.RES ERJ2GEJ 101 X (100 ) B 37.1/43.1
R303 7030009290 S.RES ERJ2GEJ 562 X (5.6 k) B 36.1/41.2
R304 7030009290 S.RES ERJ2GEJ 562 X (5.6 k) B 36.1/43.1
R305 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 36.1/39.5
R306 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 35.1/41.2
R307 7030003350 S.RES ERJ3GEYJ 181 V (180 ) T 94.4/34.9
R308 7030005310 S.RES ERJ2GEJ 124 X (120 k) B 64.2/38.1
R309 7030005100 S.RES ERJ2GEJ 154 X (150 k) B 62.5/38.1
R310 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 62.2/40.8
R312 7030010040 S.RES ERJ2GEJ-JPW B 30.1/33.8
C2 4030017620 S.CER ECJ0EC1H100C B 94.5/38.5
C3 4030017410 S.CER ECJ0EC1H240J B 96.5/36.2
C4 4030017380 S.CER ECJ0EC1H050B B 92.7/36.2
C5 4030017650 S.CER ECJ0EC1H270J B 96.3/33.9
C6 4030017460 S.CER ECJ0EB1E102K B 92.8/33.9
C7 4030017460 S.CER ECJ0EB1E102K B 93.5/29.5
C8 4030017390 S.CER ECJ0EC1H180J B 93.3/28.2
C9 4030017640 S.CER ECJ0EC1H150J B 93.3/23.2
C10 4030017460 S.CER ECJ0EB1E102K B 93.3/22.1
C11 4030009990 S.CER C1608 CH 1H 200J-T B 91.7/21.9
C12 4030007090 S.CER C1608 CH 1H 470J-T B 89.8/21.7
C13 4030010000 S.CER C1608 CH 1H 510J-T B 87.9/20.9
C14 4030011530 S.CER C1608 CH 1H 110J-T B 90.7/33.4
C15 4030017460 S.CER ECJ0EB1E102K B 93.6/16
C16 4030017400 S.CER ECJ0EC1H220J B 89.6/34.6
C17 4030017630 S.CER ECJ0EC1H120J B 85.1/36.7
C18 4030017380 S.CER ECJ0EC1H050B B 85.1/38.7
C19 4030017460 S.CER ECJ0EB1E102K B 85.1/37.7
C20 4030017430 S.CER ECJ0EC1H101J B 85.1/33.4
DESCRIPTION
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
6 - 2
M.
S.=Surface mount
H/V
LOCATION
Page 22
[MAIN UNIT]
REF PARTS
NO. NO.
C22 4030017550 S.CER ECJ0EC1H1R5B B 81.7/37.7
C23 4030018860 S.CER ECJ0EB0J105K T 74.7/37.2
C24 4030017460 S.CER ECJ0EB1E102K T 82.3/35.7
C25 4030017580 S.CER ECJ0EC1H060C B 83.4/37.7
C26 4030017430 S.CER ECJ0EC1H101J B 78.2/33.4
C27 4030017460 S.CER ECJ0EB1E102K T 78.8/35.7
C28 4030017370 S.CER ECJ0EC1H3R5B B 80/36.7
C29 4030017370 S.CER ECJ0EC1H3R5B B 80/37.7
C30 4030016930 S.CER ECJ0EB1A104K T 77.1/39.7
C31 4030016930 S.CER ECJ0EB1A104K T 78.8/38.7
C32 4030017460 S.CER ECJ0EB1E102K B 76.8/39.9
C33 4030017420 S.CER ECJ0EC1H470J B 75.8/39.9
C36 4030017460 S.CER ECJ0EB1E102K B 74.8/35.6
C37 4030016790 S.CER ECJ0EB1C103K B 75.8/37.7
C38 4030017570 S.CER ECJ0EC1H040B B 74.8/37.7
C39 4030017460 S.CER ECJ0EB1E102K B 73.7/35.6
C40 4030017550 S.CER ECJ0EC1H1R5B B 72.9/39.4
C41 4030017580 S.CER ECJ0EC1H060C B 68.5/39.2
C42 4030017460 S.CER ECJ0EB1E102K T 68.9/38.5
C43 4030017460 S.CER ECJ0EB1E102K T 68.9/39.5
C44 4030017380 S.CER ECJ0EC1H050B B 69/37.8
C45 4030017460 S.CER ECJ0EB1E102K B 72.2/35.6
C46 4030017420 S.CER ECJ0EC1H470J B 62.2/39
C47 4030017460 S.CER ECJ0EB1E102K B 62.2/39.9
C48 4030016790 S.CER ECJ0EB1C103K B 64.2/37.1
C49 4030017630 S.CER ECJ0EC1H120J B 66/39.9
C50 4030017460 S.CER ECJ0EB1E102K B 64.2/36.1
C51 4030017460 S.CER ECJ0EB1E102K B 66.1/32.1
C52 4030017590 S.CER ECJ0EC1H070C B 66.1/35.7
C53 4030016790 S.CER ECJ0EB1C103K B 64.2/33.1
C54 4030017460 S.CER ECJ0EB1E102K B 64.2/34.1
C55 4030017570 S.CER ECJ0EC1H040B B 64.2/31.1
C56 4030017400 S.CER ECJ0EC1H220J B 64.3/23.8
C57 4030017460 S.CER ECJ0EB1E102K T 64.1/36.6
C58 4030017460 S.CER ECJ0EB1E102K B 53.9/24.3
C59 4030017460 S.CER ECJ0EB1E102K B 49.5/25.2
C60 4030016790 S.CER ECJ0EB1C103K B 52.5/26.9
C61 4030017430 S.CER ECJ0EC1H101J B 49.5/22.7
C62 4030017510 S.CER ECJ0EC1H680J
[RUS-02], [RUS-05] only B 47.5/17.6
C63 4030017420 S.CER ECJ0EC1H470J B 46.5/20.4
C64 4030016790 S.CER ECJ0EB1C103K T 49.6/16.3
C65 4030017460 S.CER ECJ0EB1E102K B 46.5/18.6
C66 4030017460 S.CER ECJ0EB1E102K B 47.5/13.7
C67 4030017460 S.CER ECJ0EB1E102K B 53.4/22.6
C68 4030017430 S.CER ECJ0EC1H101J B 51.8/13.7
C69 4030017430 S.CER ECJ0EC1H101J B 53.8/15.4
C70 4030017430 S.CER ECJ0EC1H101J B 54.8/13.7
C71 4030016930 S.CER ECJ0EB1A104K B 52.8/15.4
C72 4030017460 S.CER ECJ0EB1E102K T 69.8/18.7
C73 4030017460 S.CER ECJ0EB1E102K B 73.2/21.5
C74 4030017460 S.CER ECJ0EB1E102K T 66.7/19.4
C75 4550006250 S.TAN TEESVA 1A 106M8R B 53.3/11.7
C76 4030016930 S.CER ECJ0EB1A104K T 66.7/21.1
C77 4030017460 S.CER ECJ0EB1E102K T 65.7/22.8
C78 4030017460 S.CER ECJ0EB1E102K T 74.3/21.1
C79 4030016930 S.CER ECJ0EB1A104K T 72.3/21.1
C80 4030016930 S.CER ECJ0EB1A104K T 68/18.7
C81 4030017490 S.CER C1608 JB 1A 105K-T B 78.6/19.2
C82 4030017460 S.CER ECJ0EB1E102K B 78.8/21.5
C83 4030017460 S.CER ECJ0EB1E102K T 80.2/21.2
C84 4030017730 S.CER ECJ0EB1E471K T 81.5/20.8
C85 4030017460 S.CER ECJ0EB1E102K T 77.4/23.2
C86 4030017430 S.CER ECJ0EC1H101J T 79.1/24.2
C87 4030017650 S.CER ECJ0EC1H270J T 77.4/24.2
C88 4030017460 S.CER ECJ0EB1E102K T 75.3/23.9
C89 4030016790 S.CER ECJ0EB1C103K T 73.3/23.9
C90 4030017460 S.CER ECJ0EB1E102K T 69.7/32.3
C91 4510008660 S.ELE EEE0JA220SR B 69.7/20.3
C92 4030017430 S.CER ECJ0EC1H101J T 74.2/31.3
C93 4030017650 S.CER ECJ0EC1H270J T 68.1/36.2
C94 4030017420 S.CER ECJ0EC1H470J T 69.3/23.9
C95 4030017460 S.CER ECJ0EB1E102K T 67.7/33.9
C96 4030017460 S.CER ECJ0EB1E102K T 70.7/32.3
C97 4030017420 S.CER ECJ0EC1H470J T 71.8/32.3
C99 4030017460 S.CER ECJ0EB1E102K T 65.6/32.1
C100 4030017620 S.CER ECJ0EC1H100C B 60.4/36.1
C101 4030017460 S.CER ECJ0EB1E102K T 91.7/34.1
C102 4030017590 S.CER ECJ0EC1H070C T 59.9/33.4
C103 4030017360 S.CER ECJ0EC1H030B B 58.6/35.3
C104 4030017460 S.CER ECJ0EB1E102K T 58.2/29.8
C105 4030017460 S.CER ECJ0EB1E102K B 55/37
C106 4030017420 S.CER ECJ0EC1H470J B 70.6/34.8
C107 4030017460 S.CER ECJ0EB1E102K T 60.2/38.6
C108 4030016790 S.CER ECJ0EB1C103K T 73.1/35.2
C109 4030017460 S.CER ECJ0EB1E102K B 57.7/40.3
C110 4030017730 S.CER ECJ0EB1E471K B 56.5/28.8
C111 4030017460 S.CER ECJ0EB1E102K B 56.6/34.4
C113 4030017540 S.CER ECJ0EC1HR75B T 56.5/33.8
C114 4030017660 S.CER ECJ0EC1H330J T 51.7/34.3
C115 4030017660 S.CER ECJ0EC1H330J T 56.5/34.8
C116 4030017460 S.CER ECJ0EB1E102K T 56.5/35.8
C118 4030017530 S.CER ECJ0EC1H0R5B T 56.5/32.8
C119 4030017460 S.CER ECJ0EB1E102K T 56.5/29.8
C120 4030017430 S.CER ECJ0EC1H101J T 56.5/30.8
C121 4030017390 S.CER ECJ0EC1H180J T 51.7/31.8
C122 4030017660 S.CER ECJ0EC1H330J T 56.5/31.8
C123 4030017510 S.CER ECJ0EC1H680J T 51.7/30.8
C124 4030017440 S.CER ECJ0EC1H221J T 52.2/29.3
C126 4030017660 S.CER ECJ0EC1H330J T 51.7/36.3
C127 4030017420 S.CER ECJ0EC1H470J T 50/38.9
C129 4030017340 S.CER ECJ0EC1H010B T 48/29.4
C132 4030016930 S.CER ECJ0EB1A104K B 47.5/23.5
C133 4030017400 S.CER ECJ0EC1H220J T 50.4/31.1
DESCRIPTION
M.
H/V
LOCATION
[MAIN UNIT]
REF PARTS
NO. NO.
C134 4030017390 S.CER ECJ0EC1H180J T 50.4/36.1
C135 4030017460 S.CER ECJ0EB1E102K B 51.4/43.3
C137 4030016790 S.CER ECJ0EB1C103K T 57.3/44
C138 4030017420 S.CER ECJ0EC1H470J B 52.8/32.7
C139 4030016930 S.CER ECJ0EB1A104K B 57.5/28.8
C140 4030016930 S.CER ECJ0EB1A104K T 43.3/35.9
C141 4030017460 S.CER ECJ0EB1E102K B 53.6/39.3
C143 4030017460 S.CER ECJ0EB1E102K B 51.4/41.3
C144 4030017460 S.CER ECJ0EB1E102K T 42.9/21
C145 4030017460 S.CER ECJ0EB1E102K T 44.9/22.7
C146 4550000270 S.TAN TEESVA 1E 474M8R B 50.5/32.3
C147 4550004040 S.TAN TEESVA 0J 685M8R B 49.2/39.8
C148 4550006250 S.TAN TEESVA 1A 106M8R T 50.3/43.7
C149 4550000270 S.TAN TEESVA 1E 474M8R B 47.1/39.8
C150 4030018860 S.CER ECJ0EB0J105K T 43.9/22.7
C151 4030016930 S.CER ECJ0EB1A104K T 43.3/39.4
C152 4030017420 S.CER ECJ0EC1H470J T 35.3/41.1
C153 4030017420 S.CER ECJ0EC1H470J T 37/41.1
C154 4030017420 S.CER ECJ0EC1H470J T 37.8/39.1
C155 4030017460 S.CER ECJ0EB1E102K T 44.3/37.7
C156 4030017460 S.CER ECJ0EB1E102K T 39.5/32
C157 4030017620 S.CER ECJ0EC1H100C T 38.1/32.4
C158 4030016930 S.CER ECJ0EB1A104K T 36.1/31.4
C159 4030017460 S.CER ECJ0EB1E102K T 36.1/32.4
C160 4030016930 S.CER ECJ0EB1A104K B 6.6/28.9
C161 4030017620 S.CER ECJ0EC1H100C T 43.4/33.8
C162 4030017500 S.CER ECJ0EC1H560J T 43.9/28.1
C163 4030017570 S.CER ECJ0EC1H040B T 42.5/27.6
C164 4030017590 S.CER ECJ0EC1H070C T 43.9/27.1
C165 4030016790 S.CER ECJ0EB1C103K T 43.4/31.7
C166 4030017360 S.CER ECJ0EC1H030B T 43.2/24.7
C167 4030016930 S.CER ECJ0EB1A104K B 55.8/23.3
C168 4030016930 S.CER ECJ0EB1A104K B 56.5/19.8
C169 4030016930 S.CER ECJ0EB1A104K B 56.5/18.6
C171 4030017460 S.CER ECJ0EB1E102K T 91.7/35.7
C172 4030017460 S.CER ECJ0EB1E102K B 85.7/18.9
C174 4030017530 S.CER ECJ0EC1H0R5B B 92.5/19.1
C175 4030017550 S.CER ECJ0EC1H1R5B B 94.5/33.9
C176 4030017640 S.CER ECJ0EC1H150J B 94.8/30
C182 4030017460 S.CER ECJ0EB1E102K T 65.2/39.3
C183 4030017620 S.CER ECJ0EC1H100C T 66.5/39.3
C184 4030017460 S.CER ECJ0EB1E102K T 80.6/37.7
C185 4030016930 S.CER ECJ0EB1A104K T 40.9/30.1
C186 4030016930 S.CER ECJ0EB1A104K T 77.1/37.7
C188 4030017460 S.CER ECJ0EB1E102K B 47.5/20.4
C190 4030017380 S.CER ECJ0EC1H050B T 51/38.9
C191 4030017570 S.CER ECJ0EC1H040B T 52/38.9
C192 4030017360 S.CER ECJ0EC1H030B T 53.6/27.1
C193 4030017360 S.CER ECJ0EC1H030B T 55.3/27.1
C194 4030017380 S.CER ECJ0EC1H050B T 51.2/27.5
C195 4030017570 S.CER ECJ0EC1H040B T 52.2/27.5
C200 4030017420 S.CER ECJ0EC1H470J T 27.2/27.3
C201 4030018860 S.CER ECJ0EB0J105K T 28.2/27.3
C202 4030016930 S.CER ECJ0EB1A104K B 47/30.7
C203 4030017460 S.CER ECJ0EB1E102K B 47/29.7
C205 4030017620 S.CER ECJ0EC1H100C B 55.9/39.3
C206 4030017630 S.CER ECJ0EC1H120J B 55.9/40.3
C207 4030017620 S.CER ECJ0EC1H100C B 55.9/41.3
C208 4030017630 S.CER ECJ0EC1H120J B 54.2/42.3
C209 4030017460 S.CER ECJ0EB1E102K B 54.2/43.3
C211 4030018860 S.CER ECJ0EB0J105K T 32.3/26.8
C213 4030016930 S.CER ECJ0EB1A104K T 30.6/27.8
C221 4030016930 S.CER ECJ0EB1A104K T 26.8/31.6
C222 4030016930 S.CER ECJ0EB1A104K B 18.9/33.7
C223 4030016930 S.CER ECJ0EB1A104K B 29.7/9
C224 4030016930 S.CER ECJ0EB1A104K T 40.9/29.1
C225 4030017460 S.CER ECJ0EB1E102K B 83/11.6
C226 4550005980 S.TAN TEESVA 1A 475M8R B 81.2/13.5
C227 4030016790 S.CER ECJ0EB1C103K B 86.9/13
C228 4510008540 S.ELE EEE1CA100SR B 89.4/15.7
C229 4030017460 S.CER ECJ0EB1E102K B 85.7/17.9
C230 4030016930 S.CER ECJ0EB1A104K B 85.7/16.9
C231 4030016790 S.CER ECJ0EB1C103K T 74.4/13.3
C232 4030017730 S.CER ECJ0EB1E471K T 76.2/13.3
C233 4030016790 S.CER ECJ0EB1C103K T 24.5/23
C234 4030017460 S.CER ECJ0EB1E102K T 24.2/27.8
C235 4030016790 S.CER ECJ0EB1C103K T 69.8/15.7
C236 4030017460 S.CER ECJ0EB1E102K T 69.8/17.7
C237 4510008660 S.ELE EEE0JA220SR B 76/15.5
C238 4030017460 S.CER ECJ0EB1E102K T 78.5/16.9
C241 4030016930 S.CER ECJ0EB1A104K T 35.3/9.8
C242 4030016930 S.CER ECJ0EB1A104K T 44.7/9.8
C243 4030016790 S.CER ECJ0EB1C103K T 40.5/9.8
C244 4030017460 S.CER ECJ0EB1E102K B 46.5/15.4
C251 4030016970 S.CER ECJ0EB1C223K T 33.4/17.1
C252 4030017740 S.CER ECJ0EB1E821K T 29.9/16.1
C253 4030017740 S.CER ECJ0EB1E821K T 33.4/14.9
C254 4030016930 S.CER ECJ0EB1A104K T 33.4/10.9
C255 4030016950 S.CER ECJ0EB1A473K B 34.5/12.1
C256 4030016940 S.CER ECJ0EB1A393K T 30.6/41.1
C257 4030016930 S.CER ECJ0EB1A104K T 32.3/39.1
C258 4030017790 S.CER ECJ0EB1E682K T 30.6/39.1
C260 4030017730 S.CER ECJ0EB1E471K T 28.6/39.1
C261 4030016930 S.CER ECJ0EB1A104K T 26.9/40.1
C264 4510008540 S.ELE EEE1CA100SR B 69.7/15.5
C265 4030017460 S.CER ECJ0EB1E102K B 64.8/12.4
C266 4030016930 S.CER ECJ0EB1A104K B 63.4/8.7
C269 4030017720 S.CER ECJ0EB1H331K T 11.6/37.8
C270 4030016950 S.CER ECJ0EB1A473K T 14.3/28.8
C271 4030016950 S.CER ECJ0EB1A473K T 14.3/27.8
C272 4030016950 S.CER ECJ0EB1A473K T 9.5/28.8
C273 4030016950 S.CER ECJ0EB1A473K T 12.6/28.8
C274 4030016950 S.CER ECJ0EB1A473K T 10/32.6
C275 4030016970 S.CER ECJ0EB1C223K T 11.6/34.4
DESCRIPTION
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
6 - 3
M.
S.=Surface mount
H/V
LOCATION
Page 23
[MAIN UNIT]
REF PARTS
NO. NO.
C276 4030016950 S.CER ECJ0EB1A473K T 12.6/34.4
C277 4030016930 S.CER ECJ0EB1A104K T 12.6/37.8
C278 4030017430 S.CER ECJ0EC1H101J T 16.4/39.9
C279 4030018910 S.CER C1608 JB 0J 475K-T T 36.8/21.6
C280 4030018110 S.CER ECJ0EB1H272K T 21.1/27.8
C281 4030017780 S.CER ECJ0EB1E472K T 17.7/26.8
C282 4030017710 S.CER ECJ0EC1H181J T 17.7/29.8
C283 4030018900 S.CER ECJ0EB0J474K T 19.4/31.7
C284 4030016930 S.CER ECJ0EB1A104K T 22.9/39.1
C285 4030016930 S.CER ECJ0EB1A104K T 22.9/40.1
C286 4030017460 S.CER ECJ0EB1E102K B 16.6/41.2
C287 4550006250 S.TAN TEESVA 1A 106M8R B 22.1/40.7
C288 4030017460 S.CER ECJ0EB1E102K B 18.6/39.5
C289 4030016930 S.CER ECJ0EB1A104K B 19.5/30.2
C290 4030017920 S.CER ECJ0EB1A683K T 27.5/16.1
C291 4030016780 S.CER ECJ0EB1C153K T 25.7/10.9
C292 4030016930 S.CER ECJ0EB1A104K T 25.7/13.9
C293 4030017740 S.CER ECJ0EB1E821K T 25.7/11.9
C294 4030016930 S.CER ECJ0EB1A104K T 23.9/13.9
C295 4030018110 S.CER ECJ0EB1H272K T 29/5.1
C296 4030018240 S.CER ECJ0EB1E562K T 29/6.1
C297 4030017710 S.CER ECJ0EC1H181J T 27.1/7.1
C298 4030018090 S.CER ECJ0EB1C822K T 30.8/7.1
C299 4030017510 S.CER ECJ0EC1H680J T 30.8/5.1
C300 4030017450 S.CER ECJ0EB1E271K T 18.4/39.9
C304 4030017460 S.CER ECJ0EB1E102K B 57.7/11.4
C305 4030017460 S.CER ECJ0EB1E102K T 11.3/24.3
C306 4030017460 S.CER ECJ0EB1E102K B 61.7/12
C307 4030017460 S.CER ECJ0EB1E102K B 61.7/10.2
C308 4030017460 S.CER ECJ0EB1E102K T 75.7/9.8
C309 4030017460 S.CER ECJ0EB1E102K B 75.5/11.3
C310 4030016930 S.CER ECJ0EB1A104K T 21.3/11.9
C311 4030017460 S.CER ECJ0EB1E102K B 65.4/8.7
C312 4030017420 S.CER ECJ0EC1H470J B 74.5/6.1
C313 4030017420 S.CER ECJ0EC1H470J B 33.9/7.8
C314 4030017460 S.CER ECJ0EB1E102K T 86.6/3.3
C315 4030017460 S.CER ECJ0EB1E102K T 93.2/5.9
C316 4030016930 S.CER ECJ0EB1A104K T 91.6/2.8
C317 4550007080 S.TAN TEESVA 1C 106M8R B 93/11.3
C318 4030016930 S.CER ECJ0EB1A104K T 90.4/10.1
C319 4030016930 S.CER ECJ0EB1A104K T 89.6/3.7
C320 4030017730 S.CER ECJ0EB1E471K T 88.6/3.7
C321 4030017460 S.CER ECJ0EB1E102K B 19.3/4.2
C322 4030016950 S.CER ECJ0EB1A473K T 94/14
C323 4030016950 S.CER ECJ0EB1A473K T 88.1/10.1
C324 4030017420 S.CER ECJ0EC1H470J T 85.2/14.1
C325 4550006250 S.TAN TEESVA 1A 106M8R T 89.4/17.6
C326 4510008900 S.ELE EEEFC0J101P B 87.8/8.9
C335 4030018860 S.CER ECJ0EB0J105K B 54.6/22.6
C339 4030016930 S.CER ECJ0EB1A104K B 5.9/17.2
C340 4030016930 S.CER ECJ0EB1A104K B 9.3/12.5
C341 4030016930 S.CER ECJ0EB1A104K B 5.9/10.1
C342 4030017630 S.CER ECJ0EC1H120J B 18.3/4.2
C343 4030017580 S.CER ECJ0EC1H060C B 5.6/4.2
C344 4030017640 S.CER ECJ0EC1H150J B 7.6/9.1
C345 4030016930 S.CER ECJ0EB1A104K B 11/11.2
C346 4030016930 S.CER ECJ0EB1A104K B 11/10.1
C347 4030016790 S.CER ECJ0EB1C103K T 8.9/6.3
C348 4030016930 S.CER ECJ0EB1A104K T 6/10
C349 4030016930 S.CER ECJ0EB1A104K T 21.3/14.9
C350 4030017460 S.CER ECJ0EB1E102K T 59.4/43.4
J1 6510021901 S.CNR BM02B-ASRS-TF (LF) (SN) T 86.6/6.8
J2 6450001680 CNR HSJ1122-010010
J3 6450002250 CNR HSJ1456-010320
J4 6510018430 S.CNR AXN330C038P B 11.8/30.6
J5 6510021901 S.CNR BM02B-ASRS-TF (LF) (SN)
[RUS-02], [RUS-05] only T 50.4/11.7
F1 5210000830 S.FUS ERBFE3R00U T 98/14.8
DS1 5040002670 S.LED CL-165HR/YG T 102.8/12.4
MC1 7700002750 MIC EM9745P-38-G <HOR>
S1 2260002840 SW SKHLLFA010
S2 2260002800 S.SW SW-167 (SKQTLAE010) B 99.4/44.2
S3 2260002800 S.SW SW-167 (SKQTLAE010) B 60.9/44.2
S4 2250000490 ECR TP70TF5163-15.9F-2775
[16CH] only
EP2 6910015600 S.BEA ACZ1005Y-241 (240) T 77.4/22.2
EP3 6910015370 S.BEA ACZ1005Y-102-T T 34.7/32
EP4 6910015370 S.BEA ACZ1005Y-102-T B 55.5/30.5
EP6 6910015370 S.BEA ACZ1005Y-102-T T 44.3/35.9
DESCRIPTION
M.
H/V
LOCATION
[CONNECT UNIT]
REF PARTS
NO. NO.
C501 4030017460 S.CER ECJ0EB1E102K T 8.3/5.3
C502 4030016930 S.CER ECJ0EB1A104K T 9.3/5.3
J501 6910016390 CNR IMSA-9230B-1-02Z145-PT1
DESCRIPTION
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
M.
H/V
LOCATION
6 - 4
Page 24
• BC-160 (Optional)
[MAIN UNIT]
REF ORDER
NO. NO.
IC1 1110006480 S.IC NJM2801U1-0543-TE1 B 10.2/62.3
IC2 1110003071 S.IC uPC494GS-E1-A B 13/36.7
IC3 1140012301 S.IC uPD789112AMC-534-5A4-A B 19.1/19.6
IC4 1110002700 S.IC NJM2904M-TE1 B 35.1/13.8
Q1 1530002060 S.TR 2SC4081 T106 R B 37.3/63.9
Q2 1550000090 S.FET RSQ035P03TR B 37.3/60.9
Q3 1530002060 S.TR 2SC4081 T106 R B 35.8/19.3
Q4 1530002060 S.TR 2SC4081 T106 R B 41.6/18.3
Q5 1590000430 S.TR DTC144EUA T106 B 23.7/26.6
Q6 1530002060 S.TR 2SC4081 T106 R B 22.5/58.2
D1 1730002350 S.ZEN MA8110-M (TX) B 17.6/60.5
D2 1750000550 S.DIO 1SS355 TE-17 B 34.8/64.4
D3 1750001110 S.DIO SM240A-T B 44.4/56
D4 1160000070 S.DIO DAN202K T146 B 26.9/20.6
D5 1750000550 S.DIO 1SS355 TE-17 B 27.2/15
X1 6060000790 S.CER CSTCR4M91G B 10.3/17.7
L1 6190001640 S.COL SLF12555T-101M1R1 B 35.3/52.7
L2 6200002611 S.COL NLV25T-R47J B 20.8/28.2
R2 7030000460 S.RES MCR10EZHJ 4.7 k B 20.3/58.6
R3 7030003410 S.RES ERJ3GEYJ 561 V (560) B 37.3/65.8
R4 7030003200 S.RES ERJ3GEYJ 100 V (10) B 34.6/61.1
R5 7030009580 S.RES ERJ8RSJ R12V B 31.8/73
R6 7030000540 S.RES MCR10EZHJ 22 k B 30.1/26.8
R7 7030000380 S.RES MCR10EZHJ 1 k B 30.1/29.6
R8 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) B 39.5/18.4
R9 7030003600 S.RES ERJ3GEYJ 223 V (22 k) B 13.8/30.5
R10 7030000740 S.RES MCR10EZHJ 1 M B 25.8/34.9
R11 7030000540 S.RES MCR10EZHJ 22 k B 24.8/37.8
R12 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 10.8/30.5
R13 7030003600 S.RES ERJ3GEYJ 223 V (22 k) B 19.3/34.5
R14 7030003770 S.RES ERJ3GEYJ 564 V (560 k) B 21/34.5
R15 7030003650 S.RES ERJ3GEYJ 563 V (56 k) B 21/40.3
R16 7030003770 S.RES ERJ3GEYJ 564 V (560 k) B 19.3/40.3
R17 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 22.7/40.3
R18 7030003410 S.RES ERJ3GEYJ 561 V (560) B 8.6/43.5
R19 7030003620 S.RES ERJ3GEYJ 333 V (33 k) B 16.7/42.1
R20 7030000560 S.RES MCR10EZHJ 33 k B 28.1/40.4
R21 7030000380 S.RES MCR10EZHJ 1 k B 26.3/28.6
R22 7030000440 S.RES MCR10EZHJ 3.3 k B 24/11.4
R23 7030000460 S.RES MCR10EZHJ 4.7 k B 24/8.8
R24 7030000260 S.RES MCR10EZHJ 100 (101) B 20.3/11.4
R25 7030000260 S.RES MCR10EZHJ 100 (101) B 20.3/8.8
R26 7030000500 S.RES MCR10EZHJ 10 k B 30.5/22
R27 7030007220 S.RES ERA3YED 202V (2 k) B 30.2/19.6
R28 7030011200 S.RES ERA3YEB 303V (30 k) B 30/18.1
R29 7030011190 S.RES ERA3YEB 103V (10 k) B 26.9/16.6
R30 7030005871 S.RES ERA3YKD 104V (100 k) B 40.4/15.1
R31 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 29.8/15.9
R32 7030005341 S.RES ERA3YED 332V (3.3 k) B 43.4/11.1
R33 7030000500 S.RES MCR10EZHJ 10 k B 31.7/9.8
R34 7030000740 S.RES MCR10EZHJ 1 M B 42.1/14.4
R35 7030003440 S.RES ERJ3GEYJ 102 V (1 k) B 40.4/12.2
R36 7030000460 S.RES MCR10EZHJ 4.7 k B 34.7/23.8
R37 7030005501 S.RES ERA3YKD 124V (120 k) B 33.6/21.3
R38 7030005671 S.RES ERA3YKD 393V (39 k) B 30.1/25.1
R39 7030000010 S.RES MCR10EZHJ JPW B 28.1/42.2
R40 7030000010 S.RES MCR10EZHJ JPW B 27.7/8.4
R41 7030000010 S.RES MCR10EZHJ JPW B 34.6/9.2
R42 7030008240 S.RES ERJ12YJ0R00U B 38.9/7.4
R43 7030000010 S.RES MCR10EZHJ JPW B 30.1/33.3
R44 7030000010 S.RES MCR10EZHJ JPW B 28.1/33.3
R45 7030000010 S.RES MCR10EZHJ JPW B 29.1/38
R46 7030000010 S.RES MCR10EZHJ JPW B 29.1/36.1
R47 7030000010 S.RES MCR10EZHJ JPW B 43.9/18.3
R48 7030008240 S.RES ERJ12YJ0R00U B 43/28.9
R49 7030000010 S.RES MCR10EZHJ JPW B 23.5/5.7
R50 7030008240 S.RES ERJ12YJ0R00U B 34.1/38.2
R51 7030000010 S.RES MCR10EZHJ JPW B 23.9/34.9
R52 7030000010 S.RES MCR10EZHJ JPW B 24.7/32
R53 7030008240 S.RES ERJ12YJ0R00U B 38.6/33.1
R54 7030000010 S.RES MCR10EZHJ JPW B 34.4/33
R55 7030000010 S.RES MCR10EZHJ JPW B 32/60.1
R56 7030000010 S.RES MCR10EZHJ JPW B 42.1/41.5
R57 7030000010 S.RES MCR10EZHJ JPW B 37.2/41.5
R58 7030000010 S.RES MCR10EZHJ JPW B 24.9/57
R59 7030000010 S.RES MCR10EZHJ JPW B 27.6/49.3
R60 7030000010 S.RES MCR10EZHJ JPW B 16.3/58.3
R61 7030000010 S.RES MCR10EZHJ JPW B 4.9/31.7
R62 7030000010 S.RES MCR10EZHJ JPW B 39.1/41.5
R63 7030000010 S.RES MCR10EZHJ JPW B 31.4/43.6
R64 7030000010 S.RES MCR10EZHJ JPW B 40.1/38.7
R65 7030000010 S.RES MCR10EZHJ JPW B 4.9/49.5
R66 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 8.2/13.6
R67 7030000100 S.RES MCR10EZHJ 4R7 (4.7) B 10.2/45.1
C1 4030006900 S.CER C1608 JB 1H 103K-T B 44.5/70.7
C2 4030006900 S.CER C1608 JB 1H 103K-T B 48.2/73.5
C3 4030006860 S.CER C1608 JB 1H 102K-T B 44.5/67.8
DESCRIPTION
M.
H/V
LOCATION
[MAIN UNIT]
REF ORDER
NO. NO.
C4 4030006900 S.CER C1608 JB 1H 103K-T B 32.9/69.7
C5 4030006900 S.CER C1608 JB 1H 103K-T B 32.9/71.1
C6 4510008540 S.ELE EEE1CA100SR B 17.5/63.8
C7 4030011600 S.CER C1608 JB 1E 104K-T B 13.4/60.8
C8 4030006900 S.CER C1608 JB 1H 103K-T B 9.2/58.7
C9 4030011600 S.CER C1608 JB 1E 104K-T B 13.4/63.8
C10 4510009150 S.ELE EEE1EA470WP B 43.6/62.8
C11 4030006900 S.CER C1608 JB 1H 103K-T B 35.8/67.9
C12 4030006900 S.CER C1608 JB 1H 103K-T B 32.4/67.9
C13 4510009150 S.ELE EEE1EA470WP B 26.5/62.8
C14 4510008660 S.ELE EEE0JA220SR B 34.3/28
C15 4510008660 S.ELE EEE0JA220SR B 40.8/23.8
C16 4030006860 S.CER C1608 JB 1H 102K-T B 12.3/30.5
C17 4030011600 S.CER C1608 JB 1E 104K-T B 19.3/37.4
C18 4030006900 S.CER C1608 JB 1H 103K-T B 21/37.4
C19 4030006900 S.CER C1608 JB 1H 103K-T B 13.1/42.2
C20 4030009980 S.CER C1608 JB 1H 152K-T B 8.6/42.1
C21 4030011600 S.CER C1608 JB 1E 104K-T B 9.5/21.9
C22 4030006900 S.CER C1608 JB 1H 103K-T B 19/25.5
C23 4030006900 S.CER C1608 JB 1H 103K-T B 26.9/23.2
C24 4030006900 S.CER C1608 JB 1H 103K-T B 26.9/18
C25 4030004760 S.CER C2012 JF 1H 104Z-T B 33.2/17.5
C26 4030006900 S.CER C1608 JB 1H 103K-T B 41.9/11.1
C27 4030006900 S.CER C1608 JB 1H 103K-T B 29.5/12.6
C28 4030006900 S.CER C1608 JB 1H 103K-T B 30.1/23.7
J1 6510024940 CNR HEC2305-016250
DS1 5040002740 LED RT3-03HRYG
DESCRIPTION
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V
M.
LOCATION
S.=Surface mount
6 - 5
Page 25
SECTION 7. MECHANICAL PARTS
[CHASSIS PARTS]
REF ORDER
NO. NO.
J1 6910015910 ANT CONNECTOR 104 1
J2 6910015860 IMSA-6277S-O2A-G 1
S1 2260002870 AS-243-A13 [2CH] only 1
SP1 2510001061 K036NA500-67 1
W1 8900009640 OPC-963 1
W2 8900009640 OPC-963 [2CH] only 1
1-1-32, Kamiminami, Hi r ano-ku, Osaka 547-0003, J apan
Phone : +81 (06) 6793 5302
F ax : +81 (06) 6793 0013
URL : http://ww w .icom.c o .jp/ w o r ld/ind e x.html
<Co r po r ate Headqua r ters>
2380 116th A v e n ue N.E., Bell e vu e , W A 98004, U . S .A.
Phone : +1 (425) 454-8155 F ax : +1 (425) 454-1509
URL : http://ww w .icomame r ica.com
E-mail : sales@icomame r ica.com
<Customer Se r vice>
Phone : +1 (425) 454-7619
Glen w ood Centre #150-6165
High w a y 17 Delta, B . C ., V4K 5B8, Canada
Phone : +1 (604) 952-4266 F ax : +1 (604) 952-0090
URL : http://ww w .icomcanada.com
: in f o@icomcanada.com
E-mail
Unit 1 / 103 Garden Road, Cl a yton VIC 3168 A ust r alia
Phone : +61 (03) 9549-7500 F ax : +61 (03) 9549-7505
URL : http://ww w .icom.net.au
E-mail : sales@icom.net.au
146A Har r is Road, East T amaki,
A u c kland, N e w Zealand
Phone : +64 (09) 274 4062 F ax : +64 (09) 274 4708
URL : http://ww w .icom.c o .nz
E-mail : inqui r ies@icom.c o .nz
10C07, Long silver Mansion, No.88, Yong Ding
Road, Haidian Dist r ict, Beijing, 100039, China
Phone : +86 (010) 5889 5391/5392/5393
F ax : +86 (010) 5889 5395
E-mail : bjicom@bjicom.com
URL : http://ww w .bjicom.com
Com m unication Equipment
Himmelgeister St r . 100, D-40225 Dusseldor f , Ge r ma n y
Phone : +49 (0211) 346047 F ax : +49 (0211) 333639
URL : http://ww w .icomeurop e .com
E-mail : in f o@icomeurop e .com
Ctra. Rubi, No. 88 Bajos A 08174, Sant Cugat del Valles, Barcelona, Spain
Phone : +34 (93) 590 26 70 F ax : +34 (93) 589 04 46
URL : http://ww w .icomspain.com
E-mail : icom@icomspain.com
Unit 9, Sea St., He r ne B a y , K ent, CT6 8L D , U .K.
Phone : +44 (01227) 741741 F ax : +44 (01227) 741742
: http://ww w .ico m uk.c o .uk
URL
E-mail : in f o@ico m uk.c o .uk
Zac de la Plain e
1 Rue B r indejonc des Moulinais BP 5804
31505 T oulouse Ced e x, F r ance
Phone : +33 (5) 61 36 03 03 F ax : +33 (5) 61 36 03 00
URL : http://ww w .icom-f r anc e .com
E-mail : icom@icom-f r anc e .com
6F N o .68, Sec . 1 Cheng- T eh Road, T aipei, T ai w an, R. O . C .
Phone : +886 (02) 2559 1899 F ax : +886 (02) 2559 1874
URL : http://ww w .asia-icom.com
E-mail : sales@asia-icom.com
81-850 Sopot, ul. 3 Maja 54, Poland
Phone : +48 (58) 550 7135 F ax : +48 (58) 551 0484
E-mail : icompolska@icompolska.com.pl
Page 33
1-1-32, Kamiminami, Hirano-ku, Osaka 547-0003, Japan
