Icom HM-162E User Manual

INSTRUCTIONS
REMOTE-CONTROL MICROPHONE
HM-162E
Thank you for purchasing the HM-162E
REMOTE
-
CONTROL MICROPHONE
TM
is a remote control microphone for use with the IC-M603 or else.
Please read the connected transceiver’s instruction manual carefully before installation and operation. These instructions are just described the remote­control operations only.
q BUSY/TRANSMIT INDICATOR
BBUUSSYY
” appears when receiving a signal or when the
squelch opens.
TTXX
” appears while transmitting.
w RX SPEAKER INDICATOR
Appears during the RX speaker mode.
e SCRAMBLER INDICATOR
SSCCRRAAMM
” appears when an optional voice scrambler is acti-
vated.
r SCAN INDICATOR
PPRRII--SSCCAANN 1166
” appears during Priority scan; “
NNOORR--
MMAALL SSCCAANN
” appears during Normal scan.
DDUUAALL 1166
” appears during dualwatch; “
TTRRII 1166
” ap-
pears during tri-watch.
t SELECTOR STATUS INDICATOR
Indicates the [SELECTOR] active status; “
[[VVOOLL]]
” appears when [SELECTOR] functions as the
audio volume.
[[SSQQLL]]
” appears when [SELECTOR] functions as the
noise squelch controller.
[[DDIIAALL]]
” appears when [SELECTOR] functions as the
channel selector.
y POSITION INDICATOR
Shows the GPS position data.
•“
????
” may blink every 2 sec. instead of position data when the GPS position data is invalid. In this case, the last position data is held for up to 23.5 hours.
•“
????
” may blink every 2 sec. instead of position data 4 hours after the position data is input manually, up until 23.5 hours have past.
NNoo PPoossiittiioonn
” appears when no GPS receiver is con-
nected and no position data is input manually.
u TIME ZONE INDICATOR
LLooccaall
” appears when the offset time data in the ‘Set
up’ menu is entered.
NNoo TTiimmee
” appears when no GPS receiver is connected
and no time data is input manually.
i CHANNEL COMMENT INDICATOR
Channel comment appears, if programmed.
o CHANNEL NUMBER READOUT
Indicates the selected operating channel number.
!0 KEY LOCK INDICATOR
Appears while the Key Lock function is in use.Blinks while the All Key Lock function is in use.
!1 LOW BATTERY INDICATOR
“” blinks when the battery voltage drops to approx. 10 V
DC or below.
!2 CALL CHANNEL INDICATOR
CCAALLLL
” appears when the call channel is selected.
!3 CHANNEL GROUP INDICATOR
Indicates whether an International “
IINNTT
,” U.S.A. “
UUSSAA
,”
DSC “
DDSSCC
” or ATIS “
AATTIISS
” channel is selected.
• Depending on the connected transceiver’s version.
!4 DUPLEX INDICATOR
Appears when a duplex channel is selected.
• Duplex channel has a different TX and RX frequency.
!5 TAG CHANNEL INDICATOR
Appears when a tag channel is selected.
!6 POWER INDICATOR
2255WW
” appears when high power is selected.
11WW
” appears when low power is selected.
BUSYBUSY-25W25W------INTINT------CALLCALL
LOC-LOC- -- -- DUPDUP
SCRAMSCRAM--TAGTAG NORMALNORMAL-SCANSCAN
-3434°34.506N34.506N
123123°23.236W23.236W LocalLocal----1:101:10- - CALLINGCALLING
RXRX
[VOL]
q w e
y
u
r t
!6 !4!5 !3 !2
o
!0
!1
i
Accessories included with the HM-162E: Qty.
q Connection cable (OPC-1540*: 6 m; 20 ft) ....................... 1
w Mounting base .................................................................. 1
e Connector cap .................................................................. 1
r Microphone hanger .......................................................... 1
t Screws (M3 × 16; tapping) ............................................... 5
*: OPC 1540 has external speaker leads as illustrated at right.
(Yellow: Audio, Black: Speaker ground)
Icom, Icom Inc. and the logo are registered trademarks of Icom Incorporated (Japan) in the United States, the United Kingdom, Germany, France, Spain, Rus­sia and/or other countries. COMMANDMIC III is a trademark of Icom Incorporated (Japan) in the United states.
These instructions are described when the HM-162E is connected to the IC-M603. Some operations or indications may be dif­ferent as these instructions depending on the connecting transceiver.
x Function display
z HM-162E supplied accessories
qwe
r
t
Yellow
Black
1
The optional HM-162E remotely controls the transceiver and provides an optional Intercom function.
q DISTRESS KEY [DISTRESS]
Push for 5 sec. transmit a Distress call.
w TRANSMIT POWER KEY [H/L]
Push to toggle high or low power.
• Some Channels are set to low power only.
While pushing this key, other keys perform secondary
functions.
While pushing this key, turn power ON to toggle the All key
Lock function ON or OFF.
•“ ” blinks while the All key Lock function is in use.
• Only [PWR] ([CLR]/[MENU]), [DISTRESS] and [PTT] are functional when the All key Lock function is in use.
e PTT SWITCH [PTT]
Push and hold to transmit; release to receive.
r SELECTOR DIAL [SELECTOR]
Rotate to adjust the audio level
, or select the items in DSC
menu, Set mode settings in set mode, etc.
Rotate to select the noise squelch level or operating chan-
nel after pushing
[VOL/SQL•MONI ].
Rotate to adjust the brightness of the LCD and key back-
light while pushing [H/L].
Checks TAG channels or changes scanning direction dur-
ing scan.
Rotate to adjust the audio level during in hailer mode.Rotate [SELECTOR] then push [ENT] to adjust the audio
level during in RX Speaker mode.
t ENTER KEY [ENT]
Push to fix the selected contents, or select Set mode set-
tings, etc.
Push for 1 sec. to indicate the GPS information of the con-
nected transceiver.
• No information appears when GPS receiver is not con­nected to the transceiver.
y CLEAR•POWER KEY [CLR•PWR]
While HM-162E’s power is OFF, push this key and
[MENU] for 1 sec. to turn the power ON.
• The connected transceiver power is also turned ON, if it’s OFF.
While HM-162E’s power is ON;
While pushing this key, push [MENU] to turn the HM­162E power OFF.
• The connected transceiver power is also turned OFF de­pending on the transceiver’s Set mode setting.
Push to clear the entered function, exit Set mode, etc.
u DSC MENU KEY [MENU]
Push to toggle the DSC menu ON or OFF.While pushing [CLR], push this key to turn the HM-162E
power ON and OFF.
i SCAN KEY [SCAN•TAG]
Push to start and stop Normal or Priority scan when TAG
channels are programmed.
Push for 1 sec. to set (or clear) the displayed channel as a
TAG (scanned) channel.
While pushing [H/L], push for 3 sec. to clear or set all TAG
channels in the selected channel group.
o CHANNEL/DUALWATCH/TRI-WATCH KEY
[DIAL•DW ]
Push to select the regular channels.Push for 1 sec. to start Dualwatch or Tri-watch.Push to stop Dualwatch or Tri-watch when either is acti-
vated.
Move the cursor backward while in the channel comment
programming condition.
While pushing [H/L], push to select the desired channel
groups in sequence.
• Depending on the connected transceiver’s version, this function is not available.
!0 CHANNEL 16/CALL CHANNEL KEY [16•C]
Push to select Channel 16. Push for 1 sec. to select call channel.
• “CALL” appears when call channel is selected.
Push for 3 sec. to enter call channel programming condi-
tion when call channel is selected.
While pushing [H/L], push to enter the channel comment
programming condition.
While turning power ON, push to enter Set mode.Advance the cursor while in channel comment program-
ming condition.
!1 VOLUME/SQUELCH•MONITOR/LOCK KEY
[
VOL/SQL•MONI
]
Push to select the volume, channel or squelch setting con-
dition.
After pushing this key, rotate [SELECTOR] to set the
audio level, channel selection or squelch level.
Push for 1 sec. to turn the monitor function ON. While pushing [H/L], push this to toggle the (microphone)
Key Lock function ON or OFF.
•“ ” appears while the (microphone) Key Lock function is in
use.
[PWR] ([CLR]/[MENU]), [PTT], [VOL/SQL], [H/L] and [DIS- TRESS] still function when the (microphone) Key Lock func­tion is turned ON.
!2 INTERCOM KEY [IC]
Push to toggle the Intercom function ON or OFF. Calls the transceiver when pushed and held while in In-
tercom mode.
While pushing [H/L], activates an optional Voice scram-
bler function when it’s installed into the transceiver.
•“
SSCCRRAAMM
” appears when the Voice scrambler function is
turned ON.
•Voice scrambler function is available depending on the con­nected transceiver or transceiver’s version.
• The optional Voice scrambler function cannot be used on Channel 16 and 70.
!3 HAILER/RX SPEAKER KEY [HAIL•RX ]
Push to turn the hailer mode ON or OFF.Push for 1 sec. to turn the RX Speaker mode ON or OFF.While pushing [H/L], push to turn the automatic foghorn
function ON or OFF.
é
L
GRP
L
é
L
Top keys
Back side
o i u y
!0
!1 !2 !3
w
q
r
t
e
c Panel description
2
q Push [PWR] to turn power ON. w Set the audio and squelch levels.
Push
[VOL/SQL•MONI ] for 1 sec. to activate the moni-
tor function.
Rotate [SELECTOR
VOL
] to adjust the audio output level.
Push
[VOL/SQL•MONI ]
to cancel the monitor function
.
Push
[VOL/SQL•MONI ]
several times, then rotate [SE-
LECTOR
SQL
] to adjust the squelch level.
e While pushing [H/L], push [DIAL•DW ] to change the
channel group, if desired.
r Push [DIAL•DW ] once, then rotate [SELECTOR
DIAL
]
to select the desired channel.
• When receiving a signal, “
BBUUSSYY
” appears and audio is emit-
ted from the speaker.
• Further adjustment of the audio level may be necessary.
t Push [H/L] to select the output power, if necessary.
•“
11WW
” appears when low power is selected.
• Choose low power for short range communications, choose high power for longer distance communications.
• Some channels are for low power only.
y Push and hold [PTT] to transmit, then speak into the micro-
phone.
•“
TTXX
” appears.
• Channel 70 cannot be used for transmission other than DSC.
u Release [PTT] to receive.
IMPORTANT: To maximize the readability of your transmit-
ted signal (voice), pause a few sec. after pushing [PTT], hold the microphone 5 to 10 cm from your mouth and speak at a normal voice level.
GRP
GRP
L
L
L
The HM-162E has a selector dial, which works various func­tions.
Each pushing
[VOL/SQL] changes [SELECTOR]’s action.
• Selector status indicator shows “
[[VVOOLL]]
,” “
[[SSQQLL]]
” or
[[DDIIAALL]]
” when [SELECTOR] functions
as an audio vol-
ume, squelch controller or channel selector, respectively.
Pushing
[DIAL] changes [SELECTOR]’s action to channel
selector.
• “
[[DDIIAALL]]
” appears.
Pushing
[ENT] or [CLR] returns [SELECTOR]’s action to the
audio volume when
[[SSQQLL]]
” or “
[[DDIIAALL]]
” is indicated on the
display
.
• Even if [ENT] or [CLR] hasn’t been pushed, [SELECTOR]’s action returns to the audio volume automatically after 5 sec. of inactivity.
After these instructions describe [SELECTOR] as follow:
[SELECTOR
VOL
] : Functions as the audio volume.
[SELECTOR
SQL
] : Functions as the squelch controller.
[SELECTOR
DIAL
]: Functions as the channel selector.
[SELECTOR] : Functions as the any other selector
or controller.
v Selector’s action
b Channel selection
n Receiving and transmitting
m Lock functions
DD
Channel 16
q Push [16•C] to select Channel 16. w Push [DIAL] to return to the con-
dition before selecting Channel 16, (or rotate [SELECTOR
DIAL
]
to select an other channel.
DD
Call channel
q Push [16•C] for 1 sec. to select
call channel.
w Push [DIAL] to return to the con-
dition before selecting call chan­nel, (or rotate [SELECTOR
DIAL
]
to select an other channel.
DD
International and other channel group’s channels (U.S.A., DSC, ATIS—depending on the
connected transceiver’s version)
q Push [DIAL•DW ] to select a regular channel. w While pushing [H/L], push [DIAL•DW ] to select a chan-
nel group.
• Depending on the connected transceiver’s version, channel group selection is not available.
e Push [DIAL•DW ] then rotate [SELECTOR
DIAL
] to se-
lect a channel.
•“
DDUUPP
” appears for duplex channels.
BUSY
25W
---
INT
---CALL
LOCAL--
DUP
SCRAM
--TAG
NORMAL-SCAN
34"34.206N
123"23.236W
UTC
10:10
TELEPHONE
[VOL]
BUSY
25W
---
USA
---CALL LOCAL--DUP SCRAM----
TAG
NORMAL-SCAN
34"34.206N
123"23.236W
UTC
10:10
---
CCG
[VOL]
GRP
GRP
GRP
BUSY-25W25W------INTINT---CALL---CALL
LOCAL--DUPLOCAL--DUP SCRAMSCRAM----TAGTAG NORMAL-SCANNORMAL-SCAN
-34"34.206N34"34.206N
123"23.236W123"23.236W
----UTCUTC-10:1010:10-CALLINGCALLING
[DIAL][DIAL]
for 1 sec.
C16
Push
BUSY-25W25W------INTINT---CALL---CALL
LOCAL--DUPLOCAL--DUP SCRAMSCRAM----TAGTAG NORMAL-SCANNORMAL-SCAN
-34"34.206N34"34.206N
123"23.236W123"23.236W
----UTCUTC-10:1010:10- - CALLINGCALLING
[DIAL][DIAL]
C16
Push
The Lock function electronically locks keys and switches to prevent accidental changes and function access from the mi­crophone.
All keys, switches and controllers on the transceiver are functional.
DD
Activating the Lock function
While pushing [H/L], push
[VOL/SQL•MONI ]
to turn the
Lock function ON or OFF.
•“ ” appears.
• Only [PWR] ([CLR]/[MENU]),
[DISTRESS], [PTT], [H/L], [VOL/SQL•MONI ]
and [SE-
LECTOR] are functional.
DD
Activating the All Key Lock function
While pushing [H/L], turn the
power ON by pushing [PWR] to turn the All Key Lock function ON or OFF.
•“ ” blinks.
• Only [PWR] ([CLR]/[MENU]), [DISTRESS] and [PTT] are func­tional.
é
BUSY-25W25W------INTINT------CALLCALL
LOCAL--LOCAL--DUPDUP SCRAMSCRAM--TAG--TAG NORMAL-SCANNORMAL-SCAN
-34"34.206N34"34.206N
123"23.236W123"23.236W
----UTCUTC-10:1010:10- - INTLINTL
[CH-][CH-]
Blinks
L
é
L
BUSY-25W25W------INTINT---CALL---CALL
LOCAL--LOCAL--DUPDUP SCRAMSCRAM--TAG--TAG NORMAL-SCANNORMAL-SCAN
-34"34.206N34"34.206N
123"23.236W123"23.236W
----UTCUTC-10:1010:10- - INTLINTL
[CH-][CH-]
Appears
3
-25W LOCAL-­SCRAM NORMAL-SCAN
-34"34.206N
123"23.236W
----UTC
---
DUP
--TAG
[VOL]
-10:10
International channels
INT
---CALL
-TELEPHONE
-25W
---
TAG
[VOL]
-10:10
USA
---
LOCAL--DUP SCRAM NORMAL-SCAN
-34"34.206N
123"23.236W
----UTC
U.S.A. channels
---CALL
CCG
Loading...
+ 5 hidden pages
