INSTRUCTION MANUAL
DS-100
DSC CONTROLLER
i
FOREWORD
Thank you for purchasing this Icom product. The DS-100 DSC
CONTROLLER is designed and built with Icom’s superior tech-
nology and craftsmanship. With proper care this product should
provide you with years of trouble-free operation.
IMPORTANT
READ ALL INSTRUCTIONS carefully and com-
pletely before using the controller.
SAVE THIS INSTRUCTION MANUAL—This in-
struction manual contains important operating instructions for
the DS-100.
EXPLICIT DEFINITIONS
FEATURES
☞
Class D DSC terminal
The DS-100
VHF DSC CONTROLLER is designed as a
‘Class D DSC terminal unit’ for the IC-M501EURO
VHF
MARINE TRANSCEIVER.
☞Self ID indication
The DS-100 does not function when there is no ID is programmed. Therefore, the ID code should be checked in
the Set-up menu.
INSTALLATION NOTES
In all cases, any possible risk of injury depends on the transmitter being activated for long periods. (actual recommendation limits are specified as an average of 6 minutes) Normally
the transmitter is not active for long periods of time. Some
radio licences will require that a timer circuit automatically turn
the transmitter off after 1 – 2 minutes etc.
WORD DEFINITION
RWARNING
Personal injury, fire hazard or electric
shock may occur.
CAUTION
Equipment damage may occur.
NOTE
If disregarded, inconvenience only. No risk
of personal injury, fire or electric shock.
ii
CAUTIONS
RW ARNING! NEVER connect the controller to an AC
outlet. This may pose a fire hazard or result in an electric
shock.
RWARNING NEVER transmit a distress call when
your vessel does not need immediate help. Distress calls can
be used only in times of emergency.
NEVER connect the controller to a power source of more
than 16 V DC. Such a connection will ruin the controller.
NEVER place the controller where normal operation of the
ship may be hindered or where it could cause bodily injury.
NEVER expose the controller to rain, snow or any liquids.
AVOID using or placing the controller in direct sunlight or in
areas with temperatures below –20°C (–4°F) or above +60°C
(+140°F).
KEEP the controller out of the reach of children.
KEEP the antenna cable and DC power cable as far away
as possible from electrical pumps, generators and other electronic instruments to prevent instrument malfunctions.
KEEP the controller and microphone at least 1 meter away
from your vessel’s magnetic navigation compass.
DO NOT operate the controller without running the ves-
sel’s engine. When your vessel’s engine is OFF and the controller is transmitting, the vessel’s battery will soon become
exhausted.
DO NOT use chemical agents such as benzene or alcohol
when cleaning, as they can damage the terminal unit surfaces.
CE Versions of the DS-100 which display the “CE” symbol on
the serial number seal, comply with the essential requirements of the European Radio and Telecommunication Terminal Directive 1999/5/EC.
This warning symbol indicates that this equipment operates in non-harmonised frequency bands and/or may be subject to licensing conditions in the country of use. Be sure to
check that you have the correct version of this radio, or the
correct programming for this radio, to comply with national licensing requirements.
iii
FOREWORD ........................................................................ i
IMPORTANT ........................................................................ i
EXPLICIT DEFINITIONS ...................................................... i
FEATURES .......................................................................... i
WARNING ............................................................................ i
CAUTIONS .......................................................................... ii
T ABLE OF CONTENTS ...................................................... iii
1 PANELDESCRIPTION ............................................... 1-2
■ Front panel .................................................................. 1
■ Function display .......................................................... 2
2 CALL PROCEDURE ................................................... 3–8
■ Distress call/
Simple operation ........................................ 3
■ Distress call/
Regular operation ....................................... 4
■ Entry Position/Time ..................................................... 5
■ Distress call to ship ..................................................... 6
■ Individual call ............................................................... 6
■ Group call .................................................................... 7
■ ALL ships call .............................................................. 7
3 WHEN RECEIVING A CALL .................................... 9–17
■ To receive a DSC call .................................................. 9
■ When receive a distress call ...................................... 10
■ Received message .................................................... 13
4 SET-UP ................................................................... 17–19
■ Select ‘Set-up’ ........................................................... 17
TABLE OF CONTENTS
■ Address ID ................................................................. 17
■ Offset time ................................................................. 19
■ Brightness ................................................................. 19
■ Contrast ..................................................................... 19
■ MMSI check ............................................................... 19
5 CONNECTIONS AND INSTALLATIONS ................ 20–22
■ Connection diagram .................................................. 20
■ Rear panel description .............................................. 21
■ Supplied accessories ................................................ 21
■ Mounting .................................................................... 22
6 VHF MARINE CHANNEL LIST .................................... 23
7 SPECIFICA TIONS AND OPTIONS .............................. 24
■ Specifications ............................................................ 24
■ Options ...................................................................... 24
8 DIMENSIONS ............................................................... 25
9 MB-75 (OPTION) ..................................................... 26-27
■ MB-75 FLUSH MOUNT KIT ...................................... 26
TEMPLATE
1
1
PANEL DESCRIPTION
■ Front panel
q DISTRESS BUTTON
Push and hold for 5 sec. to make a distress call.
w CLEAR SWITCH [CLR]
➥ Push this key to cancel Call repeat.
➥ Push this key to cancel the menu.
e CALL SWITCH [CALL]
➥ Push this key to call subject menu screen.
➥ Push the key to return the start screen.
r ENTER [ENT]
➥ Enters the selected subject and advances the item to in-
dicate the contents.
➥ Push this key to determine the data.
t UP/DOWN/LEFT/RIGHT SWITCHES [Y]/[Z]/[ΩΩ]/[≈≈]
➥ Push [Y]/[Z] to select the menu contents in the selected
item.
➥ Push [Y]/[Z] to adjust brightness and contrast.
➥ Push [Ω]/[≈] to move the cursor position.
y KEYPAD
➥ Input the corresponding number or letters when re-
quired.
➥ Other functions are as follows;
[A/a]–Push this key to toggle the capital letter, small
letter or numerals. ‘A; capital letter’ or ‘a; small letter’
appears in the upper right of the display, depending
on selection.
[BS]–Backspace key.
u FUNCTION DISPLAY
During normal operation the display shows position and
UTC (or Local) time when a GPS receiver is connected.
This is updated each time new GPS data is received.
If no GPS receiver is connected, the position and UTC time
CLR CALL ENT
WATER RESISTANT
1
QZ
3
DEF
2
ABC
4
GHI
6
MNO
5
JKL
7
PRS
9
WXY
8
TUV
A/a
BS
0
-
/ ,
DISTRESS
DSC CONTROLLER ds-100
q
wer
t
y
u
2
1
PANEL DESCRIPTION
must be set in advance. NOTE: If GPS data is interrupted for 30 sec. the “GPS” indi-
cation disappears. The terminal unit retains the most recent
data in such cases.
■ Function display
q GPS INDICATOR
➥ “GPS” appears while GPS receiver is connected.
➥ “GPS’ disappears when no GPS receiver is connected.
➥ “MNL’ appears when the time data and position data are
input manually.
w TIME ZONE INDICATOR
➥ “Local” appears when the offset time data on the ‘Set-up’
menu is entered.
➥ “No time data’ appears when no GPS receiver is con-
nected and no time data is input manually.
e POSITION INDICATOR
➥ Shows the GPS position data.
• “??” may blinks every 2 sec. instead of position data,
when the GPS position data is invalid. In such a case, the
last position data is held up to 23.5 hours.
➥ Shows the manually input position data when no GPS re-
ceiver is connected. “MNL” appears instead of “GPS” at q.
• “??” may blink every 2 sec. instead of position data, 4
-VHF DSC CONTROLLER-
CH 70 WATCHING
GPS:UTC4:45
Lat4559'N
Lon13444'E
w
q
e
2
CALL PROCEDURE
3
■ Distress call/Simple operation
A distress call should be transmitted if, in the opnion of the
Master, the ship or a person is in distress and requires imme diate assistance.
A distress call should include the ship’s position and time.
They are included automatically when a GPS receiver is connected. If no GPS is connected, input them, if possible.
NEVER: USE THE DISTRESS CALL WHEN
YOUR SHIP IS NOT IN AN EMERGENCY. DISTRESS CALL CAN BE USED ONLYWHEN IMMEDIATE HELP IS NEEDED.
q Confirm any distress call is
not being received.
w Lift up the switch cover,
pushing and holding the
[DISTRESS] button for 5
sec. to transmit the distress
call.
• ADSC channel (ch 70) is automatically selected and the distress call is transmitted.
• If you have the time, select the nature of the distress and contents.
• If no GPS is connected, your location and UTC time should be
input.
e After transmitting the call, the transceiver is set to the
phone frequency (ch 16) automatically.
• The controller is still waiting on
ch 70 for an acknowledgment
call.
r When receiving the acknowl-
edgment, reply to the connected station via the
transceiver’s microphone as
described on the page at
right.
NOTE:
• Distress alert (simple operation) contains (default);
Kinds of distress: Undesignated distress
Position data: According to the displayed information.
- GPS or manual input position data held for 23.5 hrs.
• Distress call repeats every 3.5–4.5 min., until receiving an ‘ac-
knowledgement’
• Beep (Pi,Pi) sounds with the max. volume every 1 sec.
• Push [DISTRESS] button to transmit a renewed distress call, if de -
sired.
• Push [CLR] to cancel the ‘Call repeat’ mode.
The ‘cancel acknowledgement’ is automatically transmitted
when the [CLR] key is pushed.
<Push and hold
[DISTRESS] for 5 sec>
Nature of distress:
Undesignated
GPS : UTC 15:22
12°34’N
123°45’W
Distress alert
Completed
Now waiting for
acknowledgemnt
<CLR→Exit>
CALL PROCEDURE
2
4
■ Distress call/Regular operation
Transmit a distress call after selecting the ‘Distress setting’.
NEVER: USE THE DISTRESS CALL WHEN
YOUR SHIP IS NOT IN AN EMERGENCY. DISTRESS CALL CAN BE USED ONLYWHEN IMMEDIATE HELP IS NEEDED.
q Push [CALL], then push [√]
several times to select ‘Distress setting’.
w Push [ENT] to select <Select
a nature>. Push [√] several
times to select the desired
nature, then push [ENT].
• Push [CLR] to Exit the menu.
e Confirm the location data,
then push [ENT] to confirm the time data.
r Confirm the UTC time, then push [ENT] to confirm the time
data.
• If no GPS is connected, your location and UTC time should be
input.
t Lift up the [DISTRESS] switch cover, pushing and holding
the button for 5 sec. to transmit the distress call.
• A DSC channel (ch 70) is automatically selected and the distress call is transmitted.
• If no GPS is connected, your location and UTC time should be
input.
y After transmitting the call, the
transceiver is set to the
phone frequency (ch 16) automatically.
• The controller is still waiting for
an acknowledgment call on ch
70.
u When receiving the acknowl-
edgment, reply to the connected station via the
transceiver’s microphone as
described on the page at
right.
<Select a subject>
Entry position/time
Individual call
Group call
All ships call
Received calls
≈Distress setting
<Select a nature>
Undesignated
Fire,Explosion
Flooding
Collision
Grounding
Capsizing
≈Sinking
Disable adrift
Abandoning ship
Piracy attack
Man overboard
EPIRB emission
<Push and hold
[DISTRESS] for 5 sec>
Nature of distress:
Abandoning ship
GPS : UTC 15:22
12.34’N
123.45’W
2
CALL PROCEDURE
5
NOTE:
• ‘nature of distress’ will be recorded for 10 min. until a distress call
transmits.
• Distress call repeats every 3.5–4.5 min., until receiving an ‘acknowledgement’
• Beep (Pi,Pi) sounds with the max. volume every 1 sec.
• Push [DISTRESS] button to transmit a renewed distress call.
• Push [CLR] to cancel the ‘Call repeat’ mode.
The ‘cancel acknowledgement’ is automatically transmitted
when the [CLR] key is pushed.
■ Entry Position/Time
When no GPS receiver is connected, the ‘Entry
Position/Time’ appears at the top of subject menu.
q Push [CALL], then push [√] to select ‘Entry Position/Time’.
w Push [ENT], then enter the latitude data with key pad.
e Push [Y]/[Z] to select N; north latitude or S; south latitude,
then push [ENT].
• Push [Ω]/[≈] to move the cursor then push [Y]/[Z] to correct
the data
• Push [CLR] to Exit the menu.
• Push [A/a], the push [ENT] to
enter a ‘Null data’.
r Enter the longitude data with
key pad.
t Push [Y]/[Z] to select E;
east longitude or W; west
longitude, then push [ENT].
• Push [Ω]/[≈] to move the cursor then push [Y]/[Z] to correct
the data
• Push [CLR] to Exit the menu.
• Push [A/a], the push [ENT] to
enter a ‘Null data’.
<Input a position>
Latitude
°’N
Longitude
°’E
<A/a"Null data>
<CLR"Exit / ENT"OK>
<Input a Time>
UTC :
<A/a"Null data>
<CLR"Exit / ENT"OK>
CALL PROCEDURE
2
6
y Push UTC time with keypad.
• Push [Ω]/[≈] to move the cursor then push [Y]/[Z] to correct the
data
• Push [CLR] to Exit the menu.
• Push [A/a], then push [ENT] to enter ‘Null data’.
■ Distress call to ships
General DSC call with the ‘distress’ category may be used for
communications after the Distress call, e.g. you want to
change the operating mode, frequency, etc.
■ Individual call
q Push [CALL], then push [√]
several times to select ‘Individual call’ then push [ENT].
w Push [√] several times to se-
lect the desired address,
then push [ENT].
• Enter the 9 digit ID when ‘Manual entry’ is selected.
• Push [CLR] to exit the menu.
e Push [CALL] and [ENT] si-
multaneously to transmit an
Individual call.
r Push [CLR] to stop the call.
<Input an address>
ID:(9digit)
<CLR"Exit / ENT"OK>
<Select an address ID>
≈Manual entry
DS-100 SN10
DS100 SN2
DS100 SN3
<CLR"Exit / ENT"OK>
7
2
CALL PROCEDURE
■ Group call
q Push [CALL], then push [√]
one or more times to select
‘Group call’, then push
[ENT].
w Select the desired address,
then push [ENT].
• Enter the 8 digit address when
‘Manual entry’ is selected.
e Push [CALL] and [ENT] si-
multaneously to transmit a ‘Group call’.
r Push [CLR] to stop the call.
■ All ships call
q Push [CALL], then push [√]
one or more times to select
‘All ships call’, then push
[ENT].
w Select the desired category,
then push [ENT].
e Push [CALL] and [ENT] si-
multaneously to transmit an
All ships call.
r Push [CLR] to stop the call.
<Select a group>
≈Manual entry
ICOM
<CLR"Exit / ENT"OK>
<Select a category>
Safety
≈Urgency
<CLR"Exit / ENT"OK>
<Input an address>
ID:(8digit)
0
<CLR"Exit / ENT"OK>
CALL PROCEDURE
2
8
D When no acknowledgement is received
If no acknowledgement is received, the emergency alarm will
sound continuously. In this case, the controller automatically
tramsmits the distress call again every 3.5 to 4.5 minutes.
• Push [CLR] if you want to stop the alarm.
• A distress relay call may be received after several minutes from another ship if acknowledgement cannot be received from a coast station directly.
CAUTION: DO NOT push [CLR] while waiting for an ac knowledgement, otherwise the distress call repeat will be
canceled, and a distress acknowledgement is automatically transmited with your own MMSI.
Use the [CLR] key only when you want to cancel repeated
transmission.
D After receiving acknowledgement call
The following should be commenced with your voice transmission after receiving a distress acknowledgement from a
coast station (or another ship).
• “MAY DAY”
• “This is .........(your ship name)”
• The 9-digit identity AND the call sign (or other identification of the ship).
• The ship’s position if the DSC distress does not include it.
• The nature of the distress and assistance required.
• Any other information which might facilitate the rescue.
9
3
WHEN RECEIVING A CALL
■ To receive a DSC call
D When receiving a DSC call
You should act in one of the following ways depending on the
received DSC format (or category):
• Wait for a voice transmission on the traffic frequency.
• Transmit an acknowledgement with DSC or voice.
• Transmit a distress relay call (only when the ship in distress requires voice communications).
D Display example and operation
• Monitoring the traffic frequency and ...
Monitor the communication between the calling ship and a
coast station. When no communication is made, contact the
ship using voice transmission.
• Emergency alarm sounds for 2 min., or push [CLR] to
cancel the alarm.
• Monitoring the traffic frequency
The calling station transmits via
voice on the traffic frequency.
• Emergency alarm (or continuous beeps depending
on the category) sounds
until pushing [CLR].
• Transmit an acknowledgement
When the following DSC is received, an ‘acknowledgement’
must be sent back to the calling
station.
• Continuous beeps (or emergency alarm depending on
the category) sounds until
pushing [CLR].
—RCV Individual ACK—
From: ICOM DSC
Able to comply
<CLR"Exit / ENT"OK>
—RCV All ships call—
From: ICOM DSC
Category: Routine
<CLR"Exit / ENT"OK>
When receiving an All ships
calll.
When receiving an Individual
acknowledgement.
■ When receive a Distress call
D When receiving a Distress call
When receiving a distress call,
an alarm (Pi-po) sounds with
max. AF level continuously. And
at the same time, the transceiver’s (IC-M501EURO) operating channel changes to CH
16 automatically.
• Push [CLR] to cancel the
alarm.
D When receiving an individual call
When receiving an individual
call, an alarm (Pi-pi) sounds.
• Push [ENT], then the operating channel changes to
designated channel.
• Push [CLR] to record the
received information, then
the screen goes back to default.
• When the individual ACK function is available
When the individual acknowledgement function* is available
on your controller, push [ENT] to turn to the <Select to comply> screen.
• Select ‘Able to comply’ or ‘Unable to comply’.
• Emergency alarm (or con-
tinuous beeps depending
on the category) sounds
until pushing [CLR].
* ‘Individual acknowledgement’
function: Please ask your
dealer for details.
10
3
WHEN RECEIVING ACALL
—RCV Distress call—
Distress ID:
23456789
Distress time & pos
Time: UTC 12:34
Pos.: Lat 12°34’N
Lon 123°45’W
—RCV Individual call—
From: JHON
<CLR➝Exit/ ENT➝OK>
<Select to comply>
≈Able to comply
Unable to comply
<CLR➝Exit/ ENT➝OK>
WHEN RECEIVE A CALL
11
3
D When receiving an All ships call
When receiving a Routine or
Safety all ships call, an alarm
(Pi-pi) sounds.
When you receive a distress or
Urgency all ships call, an alarm
(Pi-po) sounds with max. AF
level continuously.
• Push [CLR] to cancel the
alarm.
• Push [ENT], then the oper-
ating channel changes to received traffic channel automatically.
• Push [CLR] to record the received information, then the
screen goes back to default.
You must monitor the traffic frequency until you can judge
from the call that your action has been effective and/or assistance is unnecessary.
D When receiving a Position request
When receiving a Position request call, an alarm (Pi-pi)
sounds.
• Push [ENT] to transmit your
own ships longitude and latitude information.
• Push [CLR] to record the
received information, then
the screen goes back to default.
D When receiving a Postion reply
When receiving a Position reply ,
an alarm (Pi-pi) sounds.
• Push [CLR] to record the
received information, then
the screen goes back to default.
—RCV All ships call—
From: 23456789
Category: Routine
<CLR➝Exit/ ENT➝OK>
—RCV Pos request—
From: JHON
To reply, push ENT
<CLR➝Exit/ ENT➝OK>
—RCV Pos reply—
From: Beck
Pos.: Lat 12°34’N
Lon 123°45’W
<CLR➝Exit>
WHEN RECEIVING ACALL
3
12
D When receiving a Distress ACK
When receiving a distress acknowledgement, an alarm (Pipo) sounds with max. AF level
continuously. And at the same
time, the transceiver’s (ICM501EURO) operating channel
changes to CH 16 automatically.
• Push [CLR] to cancel the
alarm.
D When receiving a Distress Relay ACK
When receiving a Distress
Relay acknowledement, an
alarm (Pi-po) sounds with max.
AF level continuously. And at
the same time, the transceiver’s
(IC-M501EURO) operating
channel changes to CH 16 automatically.
• Push [CLR] to cancel the
alarm.
D When receiving a group call
When receiving a Group call,
an alarm (Pi-pi) sounds.
• Push [ENT], then the operating channel changes to
designated channel.
• Push [CLR] to record the
received information, then
the screen goes back to default.
—RCV Distress ACK—
From: Tokyo guard
Distress ID:
Mr.Bean
<CLR➝Exit/ ENT➝OK>
—RCV Group call—
From: DS-100 SN3
Group:Icom Inc
<CLR➝Exit/ ENT➝OK>
—RCV Distress RLY ACK—
From: Tokyo guard
Distress ID:
987654321
<CLR➝Exit/ ENT➝OK>
13
3
WHEN RECEIVING ACALL
■Received message (RCV MSG)
When receiving a DSC call, the received format specifier and
its contents are memorized into the received message (RCV
MSG) memory. Distress calls (including other calls with distress category) are stored separately from other calls.
Up to 20 distress calls can be memorized and up 20 other
categories of calls can be memorized. However, the distress
calls are saved until being erased, while other calls are
erased when the power is turned OFF.
D Distress message
q Push [CALL], then push [√]
one or more times to select
‘Received calls’, then push
[ENT].
w Select a ‘Distress message’,
then push [ENT].
e Select a desired message,
then push [ENT].
• Push [Y] or [Z] to scroll the
message.
• Push [A/a], then push [1] to
clear the message.
<Select a message>
≈Distress message
Other message
<CLR"Exit / ENT"OK>
<Message contents>
Distress ID:
2345678
Piracy attack
Distress time & Pos
Time: UTC 12:34
Pos.: Lat 12°34’N
Lon 123°45’W
<A/a"Data clear>
<Select a message>
≈1:Distress 12:21
2:Distress 11:21
3:Distress 10:21
4:Distress 09:21
<CLR"Exit / ENT"OK>
<Select a subject>
Entry Position/Time
Individual call
Group call
All ships call
≈Received calls
Distress setting
3
14
WHEN RECEIVING ACALL
D Other messages
• Individual call
q Push [CALL], then push [√]
several times to select ‘Received calls’, then push
[ENT].
w Select ‘Other message’, then
push [ENT].
e Select ‘Individual call’, then
push [ENT].
• Push [Y] or [Z] to scroll the
message.
• Push [A/a] to clear the message.
• Group call
q Push [CALL], then push [√]
several times to select ‘Received calls’, then push
[ENT].
w Select ‘Other message’, then
push [ENT].
e Select ‘Group call’, then
push [ENT].
• Push [Y] or [Z] to scroll the
message.
• Push [A/a] to clear the message.
<Select a message>
1:Individual ACK
≈2:Individual call
3:Group call
4:All ships call
5:Distress
6:Distress relay
7:Distress RLY ACK
8:Distress ACK
<CLR"Exit / ENT"OK>
<Message contents>
Routine to group
From: Phil Collins
F3E/G3E simplex
CH78
No information
<Message contents>
Routine to Individual
From: DS-100 SN3
F3E/G3E simplex
CH88
No information
<A/a"Data clear>
<Select a message>
1:Individual ACK
2:Individual call
≈3:Group call
4:All ships call
5:Distress
6:Distress relay
7:Distress RLY ACK
8:Distress ACK
<CLR"Exit / ENT"OK>
3
15
WHEN RECEIVING ACALL
• All ships
q Push [CALL], then push [√]
several times to select ‘Received calls’, then push
[ENT].
w Select ‘Other message’, then
push [ENT].
e Select ‘All ships call’, then
push [ENT].
• Push [Y] or [Z] to scroll the
message.
• Push [A/a] to clear the message.
• Distress
q Push [CALL], then push [√]
several times to select ‘Received calls’, then push
[ENT].
w Select ‘Other message’, then
push [ENT].
e Select ‘Distress’, then push
[ENT].
• Push [Y] or [Z] to scroll the
message.
• Push [A/a] to clear the message.
• Distress relay
q Push [CALL], then push [√]
several times to select ‘Received calls’, then push
[ENT].
w Select ‘Other message’, then
push [ENT].
e Select ‘Distress relay’, then
push [ENT].
• Push [Y] or [Z] to scroll the
message.
• Push [A/a] to clear the message.
<Message contents>
Distress relay
From: DS-100 SN3
Distress ID:
2345678
To all ships
Fire,Explosion
Distress Time & Pos
Time: UTC 12:34
Pos.: Lat 12°34’N
Lon 123°45’W
<A/a"Data clear>
<Message contents>
Routine to group
From: DS-100 SN3
F3E/G3E Simplex
CH88
No Information
<A/a"Data clear>
<Message contents>
Urgency to All ships
From: DS-100 SN3
F3E/G3E simplex
CH 14
<A/a"Data clear>
16
3
WHEN RECEIVING A CALL
• Distress relay acknowledgement
q Push [CALL], then push [√]
several times to select ‘Received calls’, then push
[ENT].
w Select ‘Other message’, then
push [ENT].
e Select ‘Distress RLY ACK’,
then push [ENT].
• Push [Y] or [Z] to scroll the
message.
• Push [A/a] to clear the message.
.• Distress acknowledgement
q Push [CALL], then push [√]
several times to select ‘Received calls’, then push
[ENT].
w Select ‘Other message’, then
push [ENT].
e Select ‘Distress ACK’, then
push [ENT].
• Push [Y] or [Z] to scroll the
message.
• Push [A/a] to clear the message.
<Select a message>
1:Individual ACK
2:Individual call
3:Group call
4:All ships call
5:Distress
6:Distress relay
7:Distress RLY ACK
≈8:Distress ACK
<CLR"Exit / ENT"OK>
<Message contents>
Distress RLY ACK
From: Mr.Comfort
Distress ID:
Mrs.John
Fire,Explosion
Distress Time & Pos
Time: UTC 12:34
Pos.: Lat 12°34’N
Lon 123°45’W
<A/a"Data clear>
<Message contents>
Distress ACK
From: Mr.Fortune
Distress ID:
Mrs.John
Fire,Explosion
Distress Time & Pos
Time: UTC 12:34
Pos.: Lat 12°34’N
Lon 123°45’W
<A/a"Data clear>
<Select a message>
1:Individual ACK
2:Individual call
3:Group call
4:All ships call
5:Distress
6:Distress relay
≈7:Distress RLY ACK
8:Distress ACK
<CLR"Exit / ENT"OK>
17
4
SET-UP
■ Select ‘Set-up’
The following setting/operations available in ‘Set-up’ menu.
• Address ID
• Offset time
• Brightness
• Contrast
• MMSI check
q Push [CALL], then push [√]
several times to select ‘Setup’, then push [ENT].
w Select ‘Set-up’, then push
[ENT].
• ‘Set-up’ menu appears on
the screen.
e Push [CLR] to exit the Set-up
menu.
■ Address ID
A total of 70 address ID can be programmed as “Address ID”
(for ships and coast stations) and “Group ID” (for group station).
• Add an address ID
q Push [∫]/[√] several times to
select ‘Add an address ID’,
then push [ENT].
w Push numeral keys to input
an address ID code, then
push [ENT].
• When a wrong number is input,
push [CLR], then correct the
number again.
e Enter the desired name for
the ID code, then push
[ENT].
• Push [A/a] several times to toggle capital letters, small letters
and numerals.
• Push the corresponding key
one or more times to input the desired character.
• Push [BS] to erase the character.
• Push [Ω] to reverse the cursor position; [≈] ot forward the cursor
position.
r Push [CLR] to exit the screen.
<Select a subject>
Individual ACK
Group call
All ships call
Received calls
Distress setting
≈Set-up
<Select a subject>
≈Address ID
Offset time
Brightness
Contrast
MMSI CHECK
<CLR➝Exit / ENT➝OK>
<Select a subject>
≈Add an address ID
Delete address ID
Add a group ID
Delete a group ID
<CLR➝Exit / ENT➝OK>
<Add an adress ID>a*
ID:(9digit)
Name:(15charactors)
<CLR➝Exit / ENT➝OK>
4
SET-UP
18
• Delete address ID
q Push [√] to select ‘Delete address ID’, then push [ENT].
w Push [∫]/[√] several times to select a desired address ID
that you want to delete, then push [ENT].
• Address ID and name is displayed on the screen.
e Push [ENT] to delete the ad-
dress ID.
• Push [CLR] to exit the
screen.
r Push [CLR] to exit the menu.
• Add a group ID
q Push [∫]/[√] several times to
select ‘Add a group ID’, then
push [ENT].
w Push numeral keys to input
an address ID code, then
push [ENT].
• When a wrong number is input,
push [CLR], then correct the
number again.
e Enter the desired name for the ID code, then push [ENT].
• Push [A/a] several times to toggle capital letters, small letters and
numerals.
• Push the corresponding key one or more times to input the desired character.
• Push [BS] to erase the character.
• Push [Ω] to reverse the cursor position; [≈] or forward the cursor position.
r Push [CLR] to exit the screen.
• Delete a group ID
q Push [√] to select ‘Delete a group ID’, then push [ENT].
w Push [∫]/[√] several times to select a desired address ID
that you want to delete, then push [ENT].
• Address ID and name is displayed on the screen.
e Push [ENT] to delete the address ID.
• Push [CLR] to exit the screen.
r Push [CLR] to exit the menu.
<Add a group ID> a*
ID:(8digit)
0
Name:(15charactors)
<CLR➝Exit / ENT➝OK>
<Delete address ID>
≈DS-100 SN10
DS-100 SN2
DS-100 SN3
DS-100 SN4
<CLR➝Exit/ENT➝OK>
<Delete this ID>
ID:(9digit)
2673500100
Name:(15charactors)
DS-100 SN10
<CLR➝Exit / ENT➝OK>
4
SET-UP
19
■ Offset time
Local time can be used when
the GPS position data is valid
and off set time is input.
q Push [CALL], then push [√]
one or more times to select
‘Set-up’, then push [ENT].
w Select ‘Offset time’, then
push [ENT].
e Push “0; –” or “1; space”, then input the time differences.
r Push [ENT] to determine the time or push [CLR] to exit the
Set-up menu.
■ Brightness
• Adjusting the brightness
q Push [CALL], then push [√] one or more times to select
‘Set-up’, then push [ENT].
w Select ‘Brightness’, then push [ENT].
e Push [Y] or [Z] one or more times (or numeral keys in-
stead) to adjust the brightness.
• Brightness level indication; 1 (dark) to 8 (bright)
r Push [ENT] to determine the brightness or push [CLR] to
exit the Set-up menu.
■ Contrast
• Adjusting the contrast
q Push [CALL], then push [√] one or more times to select
‘Set-up’, then push [ENT].
w Select ‘Contrast’, then push [ENT].
e Push [Y] or [Z] one or more times (or numeral keys in-
stead) to adjust the contrast.
• Contrast level indication; 1 (low) to 8 (high)
r Push [ENT] to determine the brightness or push [CLR] to
exit the Set-up menu.
■ MMSI check
Your ID code can be displayed via the set-up menu.
• Check your ID
q Push [CALL], then push [√] one or more times to select
‘Set-up’, then push [ENT].
w Select ‘MMSI check’, then
push [ENT].
e Your ID code shows on the
display.
r Push [CLR] to exit the Set-up
menu.
<MMSI check>
267350012
<CLR"Exit>
<Offset time>
—09:30
<CLR➝Exit / ENT➝OK>
CONNECTION AND INSTALLA TIONS
5
20
■ Connection diagram
NOTE: Binding the GPS cable, GPS connector and clone
receptacle with the water resistant tape, increases the
water-proofing of the controller.
13.8V DC
GND
u
IC-M501EURO
y
t
r
DS-100
q
e
w
5
21
CONNECTION AND INSTALLA TIONS
■ Rear panel description
q CONNECTION CABLE
Connets to the IC-M501EURO rear DSC controller receptacle.
w RECEIVE ANTENNA CONNECTOR
Connects a marine VHF receiving antenna with a PL-259
plug for emergency frequency signal receiving.
• Receiving frequency : 156.525 MHz
• Keep the emergency frequency signal receiving antenn
away from the marine VHF antenna to avoid interference
from the emitted RF signal.
e CLONE RECEPTACLE
For dealer use only.
r GPS RECEIVER CONNECTOR
Connects a GPS receiver (NMEA0183 ver.2.0) for sending
position data without manual input.
t ANTENNA CONNECTOR (IC-M501EURO)*
Connects a marine VHF antenna with a PL-259 connector
to the transceiver.
y EXTERNAL SPEAKER RECEPTACLE (IC-M501EURO)*
Connects to an external speaker.
u DC POWER CONNECTOR (IC-M501EURO)*
Connects the DC power cable supplied with ICM501EURO, from this connector to an external 12 V DC
power source.
*Refer to the IC-M501EURO instruction manual.
■ Supplied accessories
q Nob bolt (2040 knob bolt) ............................................... 2
w Mounting bracket (2345 Mobile bracket)......................... 1
e Spring washers (M 5 ) .................................................... 2
r Self-tapping screws (A05 x 20)........................................ 2
t Flat washers (M 5)........................................................... 2
y Label (2349 CAUTION seal-R)........................................ 1
5
22
CONNECTION AND INSTALLA TIONS
■ Mounting
The universal mounting bracket supplied with your controller
allows dashboard or overhead mounting. Please read the following instructions carefully.
• Mount the controller securely with bolts and nuts or it may
come loose as a result of wave shocks or vibration.
• Mount the controller so that the face of the controller is at
90 degrees to your line of sight when operating it.
CAUTION!
KEEP the controller at least 1 m away from your ship’s mag-
netic navigation compass.
CHECK the installation angle; the function display may not
be easy-to-read at some angles.
• OVERHEAD MOUNTING
• DASHBOARD MOUNTING (with optional MB-75):
For mounting the DS-100 to a dashboard panel.
6
VHF MARINE CHANNEL LIST
23
ï International channels
Frequency (MHz)
CH
Transmit
156.100 160.700
02
156.150 160.750
156.200 160.800
04
156.250 160.850
156.300 156.300
06
156.350 160.950
07
156.400 156.400
08
156.450 156.450
09
156.500 156.500
10 156.575
Receive
Frequency (MHz)
CH
Transmit
156.550 156.550156.050 160.650
11
156.600 156.600
12
156.650 156.650
13
156.700 156.700
14
156.750 156.750
15
156.800 156.800
16
156.850 156.850
17
156.900 161.500
18
156.950 161.550
19
157.000 161.600
20
Receive
Frequency (MHz)
CH
Transmit
157.050 161.650
21
157.100 161.700
22
157.150 161.750
23
157.200 161.800
24
157.250 161.850
25
157.300 161.900
26
157.350 161.950
27
157.400 162.000
28
156.025 160.625
60
156.075 160.675
61
Receive
Frequency (MHz)
CH
Transmit
156.125 160.725
62
156.175 160.775
63
156.225 160.825
64
156.275 160.875
65
156.325 160.925
66
156.375 156.375
67
156.42501156.425
68
156.47503156.475
69
156.52505156.525
70
156.575
71
Receive
Frequency (MHz)
CH
Transmit
156.625 156.625
72
156.675 156.675
73
156.725 156.725
74
156.875 156.875
77
156.925 161.525
78
156.975 161.575
79
157.025 161.625
80
157.075 161.675
81
157.125 161.725
82
157.175 161.775
83
Receive
Frequency (MHz)
CH
Transmit
157.225 161.825
84
157.275 161.875
85
157.325 161.925
86
157.375 161.975
87
157.425 162.025
88
Receive
24
7
SPECIFICATIONS AND OPTIONS
■ Options
MB-75 FLUSH MOUNTER
For mounting the DS-100 to a panel. Available in black or
white.
CS-DS100 CLONING SOFTWARE
OPC-478 CLONING CABLE
Allows quick and simple setting of vessel name, call sign, ID,
etc. from a PC.
■ Specifications
General
• Operating frequency : 156.525 MHz
• Mode : 16K0G2B
• Operating temperature range : –20°C to +60°C; –4°F to +140°F
• Dimensions : 165(W) × 110(H) × 80(D) mm
(projections not included) 6.5 (W) × 4.33(H) × 3.15(D) in
• Weight : 1 Kg; 2.2 lb
• Receive system : Double-conversion
superheterodyne
• Intermediate frequencies : 1st 21.70 MHz
2nd 450 kHz
• Sensitivity :–10 dBµ typ.
• Intermodulation rejection ratio : More than 68 dB
• Adjacent channel selectivity : More than 73 dB
• Spurious response rejection ratio : More than 73 dB
*Measurement methods according to EN 301 025
25
8
DIMENSIONS
(Unit: mm)
165.0
84.4
110.0
31.4 53.0
25.0
145.0
9
MB-75 (OPTION)
26
■ MB-75 FLUSH MOUNT KIT
The MB-75 is used to mount the DS-100 DSC CONTROLLER flush to a flat surface such as an instrument panel.
• Supplied accessories
Clamps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 sets
• Instructions
q Using the template (p. 29), carefully cut a hole into the in-
strument panel (or wherever you plan to mount the controller).
w Slide the controller through the hole, rear panel first.
9
MB-75
27
e Using the 2 supplied bolts (M5 x 8 mm), attach the clamps
on either side of the DS-100 as shown below.
• Make sure that the clamps align parallel to the DS-100’s
body.
r Tighten the end bolts on the
clamps (rotate clockwise) so
that the clamps press firmly
against the inside of the instrument control panel.
t Tighten the locking nuts (ro-
tate counterclockwise) so that
the DS-100 is securely
mounted in position as below.
y Connect the antenna and con-
trol cable, then return the instrument control panel to it’s
original place.
TEMPLATE
164 (615/32)
149 (5
7
/8)
16 (
5
/
8
)
92 (3
5
/
8
)
4–R11(7/16)
Unit: mm (inch)
Cut here
DECLARATION
OF CONFORMITY
We Icom Inc. Japan
6-9-16, Kamihigashi, Hirano-ku
Osaka 547-0002, Japan
Kind of equipment:
DSC CONTROLLER
This compliances is based on conformity with the following harmonised
standards, specifications or documents:
i)
EN 301 025-2 V0.1.2 (2000-02)
ii) EN 60945 1997
iii) prETS 300 698 December 1996
iv)
v)
Type-designation: ds-100
Signature
Authorized representative name
Place and date of issue
T. Aoki
General Manager
Icom (Europe) GmbH
Himmelgeister straße 100
D-40225 Düsseldorf
Düsseldorf 10th Apr. 2000
Icom (Europe) GmbH
Declare on our sole responsability that this equipment complies the
essential requirements of the Radio and Telecommunications Terminal
Equipment Directive, 1999/5/CE, and that any applicable Essential Test
Suite measurements have been performed.
Version (where applicable):
0560
Count on us!
6-9-16 Kamihigashi, Hirano-ku, Osaka 547-0002 Japan
A-5654H-1EU-q
Printed in Japan
© 2000 Icom Inc.
‘
GER
‘
AUT
‘
GBR
‘
IRL
‘
FRA
‘
NED
‘
BEL
‘
LUX
‘
ESP
‘
POR
‘
ITA
‘
GRE
‘
SWE
‘
DEN
‘
FIN
< Intended Country of Use >
Loading...
