IBM 22P6959 User Manual
IBM 8x4x32x8
CD-RW/DVD-ROM
Combinati on Drive
User’ s Guide
OPTIONS
by IBM
Note: Before using this information and the product it supports, read the information
under “Appendix E. Product warranty and notices” on page E-1.
First Edition (May 2001)
© Copyright International Business Machines Corporation 2001. All rights reserved.
US Government Users Restricted Rights – Use, duplication or disclosure restricted by
GSA ADP Schedule Contract with IBM Corp.
Safety: read first
Before installing this product, read the Safety Information.
Antes de instalar este produto, leia as Informações de Segurança.
Pred instalací tohoto produktu si prectete prírucku bezpecnostních instrukcí.
Læs sikkerhedsforskrifterne, før du installerer dette produkt.
Ennen kuin asennat tämän tuotteen, lue turvaohjeet kohdasta Safety
Information.
Avant d’installer ce produit, lisez les consignes de sécurité.
Vor der Installation dieses Produkts die Sicherheitshinweise lesen.
Prima di installare questo prodotto, leggere le Informazioni sulla Sicurezza.
Lees voordat u dit product installeert eerst de veiligheidsvoorschriften.
Les sikkerhetsinformasjonen (Safety Information) før du installerer dette
produktet.
© Copyright IBM Corp. 2001 iii
Antes de instalar este produto, leia as Informações sobre Segurança.
red inštaláciou tohto zariadenia si pečítaje Bezpečnostné predpisy.
Antes de instalar este producto lea la información de seguridad.
Lässäkerhetsinformationen innan du installerar den här produkten.
iv IBM 8x4x32x8 CD-RW/DVD-ROM Combination Drive: User’s Guide
Contents
Safety: read first ....................iii
About this book ....................vii
Registering your option ..................vii
Installation and user’s guide................1-1
Product description ...................1-1
Installationrequirements..................1-2
Beforeyoubegin....................1-2
Handlingprecautions..................1-2
Drive controls and connectors ...............1-3
Installing the drive....................1-4
Step1.Openingthecomputer...............1-4
Step 2. Unpacking the drive ...............1-4
Step 3. Selecting an IDE connector .............1-5
Step4.Mountingthedriveinthebay............1-6
Step5.Attachingthecablestothedrive...........1-6
Step 6. Completing the hardware installation ..........1-7
Step 7. Updating your computer configuration .........1-8
Step 8. Installing the CD-RW and DVD software.........1-8
Step 9. Setting up your computer for DVD video playback .....1-9
Using CD-R and CD-RW discs................1-9
ViewingaDVDmovie..................1-10
DVDregioncodes..................1-10
Care and maintenance ..................1-11
CaringforaCDorDVD................1-11
Caring for the CD-RW / DVD-ROM Combination Drive......1-12
Manually ejecting a disc ................1-12
Appendix A. Product specifications .............A-1
Appendix B. Problem solving ...............B-1
Appendix C. Customizing the device-driver configuration settings C-1
Changing the Auto Insert Notify and DMA parameters for Windows 95,
Windows 98, and Windows Me ..............C-1
Enabling DMA for Windows 2000 ..............C-1
Enabling DMA for Windows NT 4.0..............C-2
Appendix D. Help and service information ...........D-1
WarrantyinformationontheWorldWideWeb..........D-1
Online technical support .................D-1
© Copyright IBM Corp. 2001 v
Telephone technical support ................D-1
Appendix E. Product warranty and notices ..........E-1
IBM Statement of Limited Warranty ..............E-1
Part1-GeneralTerms.................E-1
Part 2 - Country-unique Terms ..............E-4
Trademarks......................E-13
Federal Communications Commission (FCC) statement .......E-13
vi IBM 8x4x32x8 CD-RW/DVD-ROM Combination Drive: User’s Guide
About this book
This manual contains instructions for installing and using the IBM®8x4x32x8
CD-RW/DVD-ROM Combination Drive. The manual is divided into the
following parts:
Part 1: Installation and user’s guide
This guide contains the product description and installation instructions in the
following languages:
v English
v French
v Spanish
v Italian
v Brazilian Portuguese
v Traditional Chinese
v Japanese
Part 2: Appendixes
This section contains device-driver, problem-solving, help and service,
warranty, and notice information.
Note: The illustrations in this manual might be slightly different from your
hardware.
Registering your option
Thank you for purchasing OPTIONS by IBM. Please take a few moments to
register your product and provide us with information that will help IBM to
better serve you in the future. Your feedback is valuable to us in developing
products and services that are important to you, as well as in developing better
ways to communicate with you. Register your option on the IBM Web site at
http://www.ibm.com/pc/register
IBM will send you information and updates on your registered product unless
you indicate on the Web site questionnaire that you do not want to receive
further information.
© Copyright IBM Corp. 2001 vii
viii IBM 8x4x32x8 CD-RW/DVD-ROM Combination Drive: User’s Guide
Installation and user’s guide
This section contains the product description, hardware and software
installation instructions, and operating information for the IBM 8x4x32x8
CD-RW/DVD-ROM Combination Drive.
Product description
This Option by IBM contains a unique multifunction drive that can read and
write CD-R and CD-RW discs, and can also read CD-ROM, DVD-ROM and
DVD-R discs. This kit also includes a CD containing an Online User’s Guide,
MPEG-2 decoding software and CD recording software for Microsoft
Windows®98, Windows 95, Microsoft Windows 2000 Professional, Microsoft
Windows NT
®
4.0 Workstation, and Microsoft Windows Millennium Edition
(Me).
Your option package includes the following:
v One IBM 8x4x32x8x CD-RW/DVD-ROM Combination Drive
v One package of four mounting screws (M3 x 5-mm, slotted)
v One 18-inch IDE cable
v One audio “Y” cable
v One IBM CD-RW & DVD-ROM Software and User’s Guide CD
v One Laser Safety Guide
v One Quick Installation Guide
Contact your place of purchase if an item is missing or damaged. Be sure to
retain your proof of purchase; it might be required to receive warranty service.
See “Appendix D. Help and service information” on page D-1 for technical
support information.
®
Your drive can read many DVD and CD formats, including DVD video, video
CD, and audio CD formats. It can also write most CD-R recordable and
CD-RW rewritable formats. You must install the included MPEG-2 decoding
software to play DVD video files, and you must install the included CD
recording software to write CD-R and CD-RW discs. The drive also reads
multi-session, extended architecture (XA) discs, such as the Kodak Photo CD.
This drive delivers data at up to 32 times the standard CD-ROM drive speed
(32X) for CD-ROM and CD-R media. This drive delivers data at up to 8 times
the standard DVD-ROM drive speed (8X) for DVD media. This drive is
designed for installation in a personal computer that uses integrated drive
electronics (IDE) or enhanced IDE (EIDE) architecture.
© Copyright IBM Corp. 2001 1-1
Installation requirements
Be sure that your computer meets the following system requirements before
installing the drive:
v Minimum microprocessor:
v Minimum RAM: 32 MB
v Windows 98, Windows 95 OSR2, Windows 2000, Windows NT 4.0, or
v An available half high drive bay
v An available IDE connection
v 40 MB available hard drive space
v 700 MB available hard drive space for CD copy function
v Audio solution supporting 44.1 or 48 kHz sampling rate
v Optional stereo speakers
v 2X AGP video with overlay support for MPEG-2 playback
®
– Intel
– Intel Pentium II 233 MHz for MPEG-2 playback
Windows Me operating system
Pentium®133 MHz
Before you begin
Before you install the CD-RW/DVD-ROM Combination Drive, read the
information in this section on handling precautions and on using the drive
controls and connectors.
Handling precautions
Use the following handling precautions to protect your drive:
v Keep the CD-RW/DVD-ROM Combination Drive in the antistatic bag until
you are ready to install the drive. Limit your movement when installing;
movement can cause static electricity buildup.
v Handle the drive with care. Dropping or jarring the drive can damage the
components inside the drive housing.
v Do not force insertion of the IDE or power cables. Doing so might damage
the connector or the drive.
1-2 IBM 8x4x32x8 CD-RW/DVD-ROM Combination Drive: User’s Guide
Drive controls and connectors
ReWr
itablele
The following diagrams show the location and functions of the drive controls
and connectors.
Front view of the drive:
Recordable
ReWr
itab
1Disc drawer
This drawer is where you load and unload a disc.
2Busy indicator
This light comes on when the drive reads from or writes to a disc.
3Emergency eject hole
This hole provides access to the eject mechanism to remove a disc from the
drive.
4Open/Close button
This button opens and closes the disc drawer when you push it.
Installation and user’s guide 1-3
Rear view of the drive
Pin 1
1Audio-out connector
This connector transmits the analog audio signals to an audio adapter.
2Configuration pins
These pins are used to set the drive configuration.
3IDE connector
This connects the CD-RW/DVD-ROM Combination Drive to the IDE cable.
4Power connector
This connects the CD-RW/DVD-ROM Combination Drive to the power cable.
Installing the drive
Follow these steps to install the CD-RW/DVD-ROM Combination Drive:
Step 1. Opening the computer
1. Turn off the computer and all attached devices.
2. Unplug all power cords from the computer and all attached devices.
3. Remove the cover from the computer. Refer to your computer
documentation for instructions on removing the computer cover.
Step 2. Unpacking the drive
1. Before opening the antistatic bag that the drive is packed in, touch the bag
to an unpainted metal surface for at least two seconds. This drains the
static electricity from the package and your body.
2. Remove the drive from the bag.
If you must put the drive down, place the antistatic bag on a flat, padded
surface, such as a magazine, and place the drive on the antistatic bag.
1-4 IBM 8x4x32x8 CD-RW/DVD-ROM Combination Drive: User’s Guide
Step 3. Selecting an IDE connector
Newer computers typically have two IDE connectors. If your computer has
two IDE connectors, use the secondary IDE connector to connect the
CD-RW/DVD-ROM Combination Drive. Typically the secondary IDE connector
is adjacent to the primary IDE connector that connects to your hard disk drive.
The IDE connector you select and the cable position you select will determine
which configuration jumper setting you will use for the drive.
v If you have two IDE connectors, connect the CD-RW/DVD-ROM
Combination Drive to the secondary IDE connector with the IDE cable that
comes with your drive. If the CD-RW/DVD-ROM Combination Drive is the
only device on the secondary IDE connector, you will use the master
configuration setting. If there is another device on the secondary connector
in addition to the CD-RW/DVD-ROM Combination Drive, you will use the
subordinate configuration setting.
v If you must attach the CD-RW/DVD-ROM Combination Drive to the same
IDE connector as a faster device, such as a hard disk drive, use the
subordinate setting for the CD-RW/DVD-ROM Combination Drive and the
master setting for the faster device. In some instances, the hard disk drive
might require a master-with-subordinate-present setting when another
device on the same cable is configured as a subordinate. For further
information on setting configuration jumpers on other devices, refer to the
documentation that came with your computer or with the device in
question.
v Some non-IBM computers support the cable-select setting, where the
position of the device on the cable determines whether a device is master or
subordinate. See the documentation that comes with your computer to
determine if your system supports this setting.
Installation and user’s guide 1-5
Step 4. Mounting the drive in the bay
Attention: Be sure to use the mounting screws in the option package when
you are driving screws directly into the drive. Using screws that are too long
might damage the drive.
You can mount the CD-RW/DVD-ROM Combination Drive horizontally or
vertically in the computer. If you mount the drive vertically, you must secure
any discs that you place into the drive before the drive tray is closed, or the
CD-RW/DVD-ROM Combination Drive will not be able to read the disc
properly.
1. Slide the drive into the bay. Your computer might have specific required
procedures for installing storage devices. For more information on storage
devices, refer to the documentation that comes with your computer.
2. Align the drive-bay screw holes with the threaded holes in the drive
housing or mounting bracket.
3. Thread the screws in loosely to check their position. Two screws are usually
used on each side. Verify that the alignment is correct; then tighten the
screws to secure the drive. Do not overtighten.
Step 5. Attaching the cables to the drive
The following diagram shows where to connect the cables to the drive.
1-6 IBM 8x4x32x8 CD-RW/DVD-ROM Combination Drive: User’s Guide
The following is an illustration of the internal audio cable that comes with
your option package.
1. The internal audio cable has a split-connector end and a single-connector
end. Connect one of the split-connector ends 1to the audio-out connector
on the CD-RW/DVD-ROM Combination Drive. If you have another
CD-ROM, CD-RW or DVD-ROM drive, attach the other split-connector end
to the audio-out connector on this drive. Attach the single-connector end to
your sound adapter.
2. Attach a 40-pin IDE-cable connector 2to the IDE connector on the drive.
Align the cable so that the color-coded edge is closest to the power cable
connector 3. Use the IDE cable that is provided with this option if there
is no cable attached to the IDE connector. The IDE cable can have up to
three connectors. For the best signal quality when you are connecting only
one device to the IDE cable, connect one end of the cable to the IDE
connector, and connect the other end of the cable to the device. Do not use
the middle connector. Use the IDE cable that is provided with this option if
there is no cable attached to the computer IDE connector, or if there is only
one device connector on the computer IDE cable.
If you are connecting two devices to the IDE cable, connect one end of the
cable to the IDE connector, and connect the master and subordinate devices
to the remaining connectors on the other end. Many computers have two
cables for attaching up to four ATA devices. For best performance, attach
fast devices (such as hard disk drives) to the cable that is connected to the
primary IDE connector, and connect the CD-RW/DVD-ROM Combination
Drive or other slower devices (such as CD-ROM drives, tape drives, and
removable media) to the cable that is connected to the secondary IDE
connector.
3. Attach a four-pin power cable 3to the power connector on the
CD-RW/DVD-ROM Combination Drive.
Be sure that the cables will not be pinched or crowded by the computer
cover and that all other cable and power connections are secure.
Step 6. Completing the hardware installation
1. Be sure that the CD-RW/DVD-ROM Combination Drive is securely
mounted and that the connectors are firmly attached.
2. Be sure that the cables do not interfere with the computer cover and that
they do not block the power-supply fan blades or airflow paths.
Installation and user’s guide 1-7
Loading...
