Hyundai L17C0D081 Users Manual

Type No. L17C0D081

Click

www.hyundaiQ.com

ImageQuest Q17

Dual Function Monitior

NEXT

User’s Guide

U.S.A.

BACK

U.S.FEDERAL COMMUNICATIONS COMMISSION
RADIO FREQUENCY INTERFERENCE STATEMENT
INFORMATION TO THE USER

NOTE : This equipment has been tested and found to comply with the limits for a

Class B digital device pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that interfer ence will not occur in a particular
installation.
If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:

NEXT

Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet of a circuit different from that to which

the receiver is connected.

Consult the dealer or an experienced radio/TV technician for assistance.

Changes or modification not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
Connecting of peripherals requires the use of grounded shielded signal cables.

DECLARATION OF CONFORMITY

BACK

WE ImageQuest CO., LTD.

Ami-ri Bubal-Eub Ichon-Si Kyungki-Do
467-860 KOREA

declare under our sole responsibility that the product:

Kind of equipment : COLOR MONITOR

Type-Designation : L17C0D081

to which this declaration relates is in conformity with the
following standard(s) or other normative document(s)

Safety : EN 60950 : 1992 + A1, A2, A3, A4, A11
EMC : EN 55022 : 1998, EN 55024 : 1998

EN 61000-3-2 : 1995+A1 : 1998+A2 : 1998
EN 61000-3-3 : 1995

following the provisions of the Low Voltage Directive 73/23/EEC,
93/68/EEC and the EMC Directive 89/336/EEC.

NEXT

Accredited testlaboratory:

TÜV Rheinland

Am Grauen Stein

51105 Köln

KOREA / April. 8, 2002 HONG KI, KIM

(Place and date of issue) (Name and signature of

SEP. 17, 2001

authorized person)

Q17
17" TFT LCD Color Monitor

BACK

Contents

NEXT

1. Introduction ...................................1/22

2. Safety Information ........................1/22

3. Installing the monitor ...................4/22

3-1. Packing List .........................................4/22

3-2. Selecting a suitable location ..............5/22

3-3. Connecting the monitor .....................5/22

USB Hub ..............................................7/22

3-4. Setting the refresh rate ......................8/22

Preset Timing Table ............................9/22

3-5. VESA MOUNTING ..............................10/22

4. Adjusting the picture ..................12/22

4-1. Using the On Screen Display ...........14/22

4-2. Direct access buttons .......................14/22

4-3. OSD Adjustments .............................15/22

5. Display power management ......18/22

Reducing power consumption ..............18/22

6. Troubleshooting ..........................19/22

7. Specifications ..............................22/22

Q17

BACK

1. Introduction

17" TFT LCD Color Monitor

This manual contains instructions for installing and operating ImageQuest Q17.
ImageQuest Q17 is a highly ergonomic color display unit.

• 17" viewable SXGA LCD

• High quality screen re-scaling capability

• Real ColorTMflesh-tone adjustment and digital color control with innovative
color management.

• 100-240V AC input voltage

• VESA DPMS (Display Power Management Signalling)

• VESA DDC1/2B compatibility

• Advanced digital On-Screen-Display controls

• Digital signal input by DVI-1.0 compatibility

• Fast and accurate auto adjustment

• Most advanced image scaling

• Supporting VESA Flat Panel Monitor Physical Mounting Interface

• USB (Universal Serial Bus) hub, Bus-Power mode hub

NEXT

2. Safety Information

This Monitor has been engineered and manufactured to assure your safety.
You can prevent serious electrical shock and other hazards by keeping in mind
the following:

Do not place anything wet on the monitor or the power
cord. Never cover the ventilation openings with any
material and never touch them with metallic or
inflammable materials.

1/22

Q17

BACK

17" TFT LCD Color Monitor

Avoid operating the monitor in extreme heat,
humidity or areas affected by dust.
Temperature : 5~35°C
Humidity : 30~80RH

Be sure to turn the monitor off before plugging the
power cord into the socket. Make sure that the power
cord and the other cords are securely and rightly
connected.

Overloaded AC outlets and extension cords are
dangerous, as are frayed power cords and broken
plugs, which may cause electric shock or fire. Call
your service technician for replacement.

NEXT

Do not use sharp tools such as a pin or a pencil near
the monitor, as they may scratch the LCD surface.

Do not use a solvent, such as benzene, to clean the
monitor, as it will damage the LCD surface.

2/22

Q17

BACK

Cleaning and Maintenance

17" TFT LCD Color Monitor

• To avoid risk of electric shock, do not disassemble the display unit cabinet. The
unit is not user-serviceable. Remember to unplug the display unit from the
power outlet before cleaning.

• Do not use alcohol (methyl, ethyl or isopropyl) or any strong dissolvent. Do not
use thinner or benzene, abrasive cleaners or compressed air.

• Do not wipe the screen with a cloth or sponge that could scratch the surface.

• To clean your antistatic screen, use water and a special microfiber screen
cleaning tissue used in optical lens cleaning, or lightly dampen a soft, clean
cloth with water or a mild detergent.

• If the instructions above do not help in removing stains, contact an authorized
service agent.

NEXT

3/22

Q17

UK

American/Canada

Japan

Australia

Korea

Europe

South Africa

BACK

3. Installing the
monitor

3-1. Packing List

17" TFT LCD Color Monitor

The following items should be found in the packaging.

Power Cord

Signal Cable

DVI-D Cable

(Option)

NEXT

USB Cable

Compact Disc Audio Cable

Above power cord can be changed upon different voltage areas. Please

!

contact your dealer if anything is missing or damaged.
Other power cord except the cord packed in the product or longer than 3m

may affect EMC of the product in operating condition.

4/22

Q17

BACK

3-2. Selecting a suitable

location

3-3. Connecting the

monitor

17" TFT LCD Color Monitor

• Place the monitor at least 30cm from other electrical or heat-emitting
equipment and allow at least 10cm on each side for ventilation.

• Place the monitor in a position where no light shines directly onto or is
reflected on the screen.

• To reduce eye strain, avoid installing the display unit against a bright
background such as a window.

• Position the monitor so that the top of the screen is no higher than eye level.

• Position the monitor directly in front of you at a comfortable reading distance

(around 45 to 90cm)

Before you start cabling your monitor, check that the

!!

power is off on all units. To avoid any possibility of
electric shock, always connect your equipment to
properly earthed outlets.

NEXT

• 15 pin D-sub / DVI-D

1. Insert the other 15-pin/DVI-D signal cable connector into the 15-pin VGA/DVI-D
connection on your computer and screw it down.

2. Plug the power cord connection to connection on the monitor.

3. Plug the other end of the power cord to your computer's main supply or to a
100V-240V earthed electrical outlet.

4. Turn on the monitor using the power switch and check that the power LED is
on. If not, repeat steps 1,2,3 and 4 or refer to the Troubleshooting section of
this guide.

5/22

Q17

BACK

17" TFT LCD Color Monitor

5. Turn on the power to the computer. The picture will appear within about 10
seconds. Adjust the picture to obtain optimum picture quality. See section
Adjusting the picture in this guide for more information.

15 pin D-sub cable (Analog RGB)

NEXT

DVI-D cable (Digital TMDS)

6/22

Q17

LINE OUT

BACK

• USB hub / PC Audio

17" TFT LCD Color Monitor

The USB hub(Bus-powerd mode hub) have 1 upstream port and 2 downstream
ports. The upstream port can be connected to the root hub of host PC or other
downstream port. Two(2) downstream ports allow to connect another USB device
such as USB mouse, joystick, printer etc.

1) The maximum supply current of downstream port is 100mA each when bus-

powered mode hub.

2) To activate the USB hub, your host system should have USB capability.

USB 2 downstream ports

NEXT

7/22

Q17

BACK

• Audio system

17" TFT LCD Color Monitor

This monitor has an audio system including two micro loudspeakers. Each of two
micro loudspeakers has an 1Wrms (max.) output power. This system also supports a
headphone output jack.

This system has been tuned to get a best tone quality which an audio input

!!

level is under 600mVp-p. if the input level is more than 600mVp-p, you must
tune down the audio input as the audio output tone may be distorted.

NEXT

8/22

Q17

Power Switch / LED Indicator

BACK

17" TFT LCD Color Monitor

NEXT

3-4. Setting the refresh

rate

Follow the instructions below to set your refresh rate in Windows 98.

1. Go to the configuration window(Start-Settings-Configuration window).

2. Double click on the ‘Display’ icon.

3. Click on the ‘Settings’ tab.

4. Click on the ‘Advanced’ button.

5. Click on ‘Adapter’ and select 60Hz from the list.

6. Click on ‘Apply’ to accept the selected value.

9/22

Q17
17" TFT LCD Color Monitor

BACK

Preset Timing Table

If the signal from the system doesn't equal to the preset timing mode, adjust

!

the mode with reference to the user guide of videocard because the screen
may not be displayed.

ANALOG R.G.B INPUT

The recommended setting is a resolution of 1280x1024 and a refresh rate of 60Hz.

No.

1
2
3
4
5
6
7
8
9

10
11
12
13
14

Resolution

720

x

400

x

x
x

480

600
600

640
640 x 480
800 x 600
800 x 600
800
800

832 x 624
1024 x 768
1024 x 768
1024 x 768
1152 x 870
1280 x 1024
1280 x 1024

Horizontal Frequency

31.5 KHz

31.5 KHz

37.5 KHz

35.2 KHz

37.9 KHz

48.1 KHz

46.9 KHz

49.7 KHz

48.4 KHz

56.5 KHz

60.0 KHz

68.7 KHz

63.9 KHz

80.0 KHz

Refresh rate

70 Hz
60 Hz
75 Hz
56 Hz
60 Hz
72 Hz
75 Hz
75 Hz
60 Hz
70 Hz
75 Hz
75 Hz
60 Hz
75 Hz

NEXT

10/21

Q17

BACK

Kensington Lock System

17" TFT LCD Color Monitor

DIGITAL R.G.B INPUT

No.

1
2
3
4

* Kensington, Inc.

· Address :

· Tel : · Fax : E-mail :

Resolution

x
x
x
x

480
600
768
1024

640

800
1024
1280

Horizontal Frequency

31.5 KHz

37.9 KHz

48.4 KHz

63.9 KHz

Refresh rate

60 Hz
60 Hz
60 Hz
60 Hz

NEXT

11/22

Q17

BACK

3-5. User’s Environment

17" TFT LCD Color Monitor

With the double-hinge structure in the stand, this display unit is designed to
Support the following user’s environment.

• Without special Mounting Devices for VESA FPMPMI Standard, you can hang
this display unit on the wall by using 4 holes in the bottom side of stand like
the below picture.

• You can adjust the tilt angle and height at your suitable level and can fold the
stand during carriage

NEXT

If you cannot fold the stand and the monitor fully, please pull the monitor a

!!

bit and then follow the above instruction again.

12/22

Q17

BACK

VESA MOUNT’G

17" TFT LCD Color Monitor

• This display unit supports VESA FPMPMI standard for 100mmx100mm screw
mounting by giving 4 screw holes inside the base stand of the unit.

• For buying VESA Flat Panel Monitor Mounting Devices, please contact
following information.

* Ergotron, Inc.

· Address : Ergotron Europe Kuiperbergweg 50 1101 AG Amsterdam The Netherlands

· Tel : [phone] · Fax : [phone]· E-mail : [e-mail]

Desk Mount

NEXT

Wall Mount

13/22

Q17

1280X1024
V:60.0/H:63.9

BRIGHTNESS

BACK

4. Adjusting the picture

17" TFT LCD Color Monitor

You can adjust the screen display by using the buttons located below the
screen.

In case of applying

Analog RGB

Input

NEXT

14/22

Q17

1280X1024
V:60.0/H:63.9

BRIGHTNESS

BACK

17" TFT LCD Color Monitor

In case of applying Digital TMDS Input

NEXT

15/22

Q17

BACK

4-1. Using the On Screen

Display

4-2. Direct access buttons

17" TFT LCD Color Monitor

1. Push the MENU button to call the OSD to the screen. The resolution and
frequency are displayed at the top of the menu box for your information.

2. Push the or button to choose the item you want to adjust. The selected
item is highlighted.

3. Push the SELECT button to adjust the highlighted item.

4. Use the or button to adjust the selection.

5. Push the MENU button to return to the previous menu if you are in a submenu.

6. The display unit automatically saves the new settings in 1 second after your
last adjustments and the menu disappears. You can also push the MENU button
to make the menu disappear.

AUTO ADJUST

At first display a full screen such as Window's back ground.
Push the button SELECT(AUTO) to adjust the shape of screen
automatically.

NEXT

INPUT SELECT

Push the button to choose the input select adjustment after
choosing one of Analog Signal or Digital Signal.
LED Indicator will be displyed with Amber on processing.

MUTE MUTE

Push the button to audio mute on or off.
This button is toggled.

16/22

Q17

BACK

4-3. OSD Adjustments

You can play the movie
file to see how to adjust
the picture image by
clicking each icon or title
hereunder.

17" TFT LCD Color Monitor

The OSD adjustments available to you are listed below.

BRIGHTNESS

Adjust the brightness of the screen.

CONTRAST

Adjust the contrast of the screen.

COLOR CONTROL

Color temperature affects the tint of the image. With lower color
temperatures the image turns reddish and with higher temperatures
bluish.

There are three color settings available: Mode 1(a cool white), Mode 2(a
warm white) or USER. With the USER setting you can set individual values
for red, green and blue.

NEXT

YUV COLOR

In particular, color technology allows users to make the following color
adjustment.

HUE

Adjust the hue of the video image.

FLESH TONE

Adjust the flesh Tone of the video image.

17/22

Q17

BACK

17" TFT LCD Color Monitor

MISCELLANEOUS

RECALL

Recall the saved color data.

OSD TIMER

You can set the displayed time of OSD Menu window on the screen by
using this adjustment.

OSD POSITION

Adjust the OSD menu's horizontal or vertical position on the screen.

VOLUME

Adjust the audio volume level.

MUTE

This menu is used to audio mute on and off.

AUTO ADJUST

You can adjust the shape of screen automatically at the full screen
pattern.

NEXT

LANGUAGE

You can select the language in which adjustment menus are displayed.
The following languages are available: English, French, German,
Italian, Spanish and Japanese.

18/22

Q17

BACK

17" TFT LCD Color Monitor

H/V POSITION

H-POSITION

Adjusts the horizontal position of the entire screen image.

V-POSITION

Adjusts the vertical position of the entire screen image.

CLOCK PHASE

PHASE

Adjust the noise of the screen image.

CLOCK

Adjust the horizontal size of the entire screen image.

INPUT SELECT

This menu used to choose the desired input signal source.
There are two available signal source.

NEXT

• Analog R.G.B : 15 pin D-sub, Analog Signal

• Digital TMDS : 24 pin DVI-D, Digital Signal

In case of applying Digital TMDS Input, the functions of Color Control, Auto

!

Adjust, H/V Position, Clock Phase are not supported.

19/22

Q17

BACK

5. Display power
management

Reducing power
consumption

17" TFT LCD Color Monitor

If the power management function of your computer is enabled, your monitor
turns on and off automatically. You can control power management features from
your computer.

Your computer may have power management features which enable the computer
or monitor to enter a power saving mode when the system is idle. You can
reactivate the system by pressing any key or moving the mouse.

Mode

Normal

off

Unplugged

LED

Green

Orange

Not illuminated

Power consumption

45 W

5 W
0 W

NEXT

The power button does not disconnect the monitor from the mains. The only

!

way to isolate the monitor completely from the mains supply is to unplug the
mains cable.

20/22

Q17

BACK

6. Troubleshooting

17" TFT LCD Color Monitor

If your monitor is not functioning properly, you may be able to solve the problem
by following the suggestions below :

Problem

Blank screen

If the power LED is not lit, push the Soft power switch or check the
AC cord to turn the monitor on. If the display unit is powered
through the computer, check that the computer is switched on.

The display unit might be in standby mode. Push one of the
keyboard keys. Check that the keyboard is properly connected to
the computer.

Check that the signal cable connector is properly connected and that
the connection pins are not bent or damaged. If the connector is
loose, tighten the connector's screws.

Check that the power cable is correctly connected to the display unit
and to the power outlet.

Possible solution

NEXT

Error message:

Video mode not
supported

The display does
not enter power
management
mode

Check the resolution and the frequency on the video port of your
computer.

Compare these values with the data in the Preset Timing Table.

The video signal from the computer does not comply with VESA
DPMS standard. Either the computer or the graphics adapter is not
using the VESA DPMS power management function.

21/22

Q17

BACK

17" TFT LCD Color Monitor

Problem

Color defects

Size, position,
shape or quality
unsatisfactory

Duplicated
images

Image is not
stable

Check that the signal cable connector is properly connected and that
the connection pins are not bent or damaged. Try another color
temperature.

Adjust the picture characteristics as described in the section OSD

Adjustment(4-3).

A problem with your graphics adapter or display unit. Contact your
service representative.

Check that the display resolution and frequency from your PC or
graphic adapter is an available mode for your monitor.
In your PC, you can check through Control panel, Display, Settings.

If the setting is not correct, use your computer utility program to
change the display settings.

Possible solution

NEXT

Message :

No signal

The power LED is a
orange color

Check that the signal cabel connector is properly connected and that
the connection pins are not bent or damaged.
If the connector is loose, tighten the connector’s screws.
Check that the computer is switched on.

To enter a power saving mode. You can reactivate the system by
pressing any key or moving the mouse.

22/22

Q17

BACK

Contacting service

17" TFT LCD Color Monitor

Problem

The power LED is a
orange color

If the above troubleshooting hints do not help you find a solution to the problem,
contact an authorized service agent. If the monitor is sent for service, use the
original package if possible.

Unplug the display unit from the power outlet and contact a service agent when:

LED Indicator can be orange color on changing of video mode or
Input Signal(D-sub/DVI).

Check the Resolution and the frequency on the video part of your
computer. Compare these values with the data in the Preset Timing
Table.

Possible solution

NEXT

• The monitor does not operate normally according to the operating instructions.

• The monitor exhibits a distinct change in performance.

• The monitor has been dropped or the cabinet has been damaged.

• The monitor has been exposed to rain, or water or liquid has been spilled onto

the monitor.

23/22

Q17
17" TFT LCD Color Monitor

BACK

7. Specifications

LCD

Brightness

Response Time

Display area

Number of color

Input signals

Frequency rate

Maximum bandwidth

Maximum resolution

Recommanded resolution

Input voltage
Power consumption
Power management

Plug & Play

OSD menu

Audio system

USB

VESA FPMPMI

Ergonomics,

Safety and EMC

Operating Temperature

Weight

Dimensions (W X H X D mm)

17"viewable, Diagonal, Pixel pitch 0.26 mm, A-Si TFT
250cd/m
25msec

337.92 X 270.336 mm
16,7 million colors
R.G.B Analog, Digital TMDS(DVI-D),
Horizontal : 31.0 to 80.0KHz, Vertical : 56 to 75Hz
135 MHz
Analog RGB : 1280X1024@75Hz
Digital TMDS : 1280X1024@60Hz
1280X1024@60Hz
100-240 VAC
45W
VESA DPMS
VESA DDC 1/2B
BRIGHTNESS, CONTRAST, COLOR CONTROL, YUV COLOR,
MISCELLANEOUS, AUTO ADJUST, LANGUAGE,
H./V. POSITION, CLOCK-PHASE, INPUT SELECT
2ch X 2 watts / Ear Phone Jack
1up X 2down (Bus-Powered Hub)
100 mm X 100 mm screw mounting
TCO, FCC Class B, CE,
cULus, TÜV-GS, SEMKO
5 ~ 35O C

4.8Kg unpacked, 6.0Kg packed
396 X 414 X 200 mm

2

• Specification is subject to change without notice for performance improvement.

24/22
