Hyundai HSL850-7 User Manual

HYUNDAI SKID STEER LOADERS

HYUNDAI

SKID STEER LOADERS

I Photo may include optional equipment.

HSL850-7_new_en 26-03-2008 16:26 Pagina 1

New

HYUNDAI SKID STEER LOADER

I Photo may include optional equipment.

HSL850-7_new_en 26-03-2008 16:26 Pagina 2

2

An ideal arrangement of components ensures easy access and
convenience for maintenance.

Easy & fast engine access

Engine and battery have good and
fast accessibility with a swing-out
tailgate. The radiator can be
cleaned easily because of
removable oil cooler..

Centralized fuse box for
easy inspection

Spark arresting muffler Quick attachment device

Quick attachment device provides
fast cycle times and easy operation.

Double safety canopy

Safer service when canopy is tilted
with double locking system.

Boom locking system

Boom cylinder locking bar is
provided for safer service.

Tilting canopy
for easy access

By removing two nuts the tilting
canopy can be lifted (assisted with
a gas spring) and locked, in order to
have an easy access of hydraulic /
hydrostatic components.

Level gauge
for Hydraulic oil

HSL850-7_new_en 26-03-2008 16:26 Pagina 3

3

Environmental Friendly Engine Self levelling control system (option)

KUBOTA V3300DI ENGINE

Market approved quality of Kubota V3300DI engine ensures incomparable
performance, durability and additional value to the machine. The engine
output of 50 kW (68 HP) is enough to suit any work, even with special
attachments requiring high power.

Easy access for maintenance

Because of the full open type canopy and the control valve on the upper
position, the relief valve and all pipes are highly accessible for maintenance.

This self levelling control system for lifting operations will maintain
the level of bucket automatically for more efficient load handling jobs.
When raising the loader boom, the bucket positioning valve directs
the oil from the boom cylinder to the bucket cylinder. With this optional
item the operator can concentrate more on maneuvering and lifting
tasks with faster cycle times.

Environmental Friendly Engine Self levelling control system (option)

HSL850-7_new_en 26-03-2008 16:26 Pagina 4

4

Comfortable & Safe

To maximize productivity, the ROPS/FOPS canopy is designed for operator’s comfort, excellent visibility and a
high level of safety. Wide entrance with handles and non slip foot steps are provided for operator
convenience.

Powerful &
Comfortable Operation

Joystick levers

Simultaneous Control of
Travel & attachment

Reliable safety device

A double safety gear prevents
sudden accidents. The safety
lever will stop all functions when
the operator is not seated; the
hydraulic line will be cut off
when the key is removed. The
parking brake is engaged by
raising the safety bar.

Centralized switches Centralized dashboard Multi-purpose storage box ROPS / FOPS Canopy

ROPS : Roll Over Protective Structure
FOPS : Falling Object Protective Structure

Increased front visibility Foot rest

HSL850-7_new_en 26-03-2008 16:26 Pagina 5

5

Q

D

B

I

J

H

K

G

E

A

O

N

L

M

P

C

F

HSL850-7

840 (1,852)
1,685 (3,715)
3,290 (7,253)

Kubota V3300DI

50 (68)

48.5 (66)
2,400

12-16.5,12PR

11.6 (7.2)

67.0 (17.70)
175 (2,538)

3,470 (136.6)

1,830 (72.0)
2,000 (78.7)
1,500 (59.1)
1,100 (43.3)

2,840 (111.8)

205 (8.1)
2,080 (81.9)
1,300 (51.2)
1,660 (65.4)

28

o

3,080 (121.3)

2,410 (94.9)

45

o

510 (20.1)

27

o

1,894 (74.6)

0.37 (13.1)
83 (22)
57 (15)

DIMENSIONS

SPECIFICATIONS

Standard and optional equipment may vary. Contact your Hyundai dealer for more information. The machine shown may vary according to International standards.
All US measurement rounded off to nearest pounds or inches. Materials and specifications are subject to change without notice.

Rated operating capacity

Tipping load

Model

Gross output

Net output

Rated speed

Coolant

Steering controls

Loader controls

Tires (standard)

Max. travel speed

Pump flow

Max. pressure

A Length (with bucket)

B Width (without bucket)

C Height overhead cab

D Track width

E Wheelbase

F Length (without bucket)

GGround clearance

H Turning radius (with bucket)

I Turning radius (front tire)

J Turning radius (rear-end corner)

K Rear-end inclination angle

L Bucket pivot max. height

M Dumping clearance at max. height

N Dump angle

O Reach at max. height

P Roll-back angle on ground

Q Bucket width

Bucket capacity (heaped)

Fuel tank

Hydraulic tank

kg (lb)

kg (lb)

kg (lb)

-

kW (HP)

kW (HP)

rpm

-

­2 Levers

-

-

km/h (mph)

l

/min (gpm)

bar (psi)

mm (in)

mm (in)

mm (in)

mm (in)

mm (in)

mm (in)

mm (in)

mm (in)

mm (in)

mm (in)

-

mm (in)

mm (in)

-

mm (in)

-

mm (in)

m

3

(ft3)

l

(USgal)

l

(USgal)

DESCRIPTION UNIT

STANDARD EQUIPMENT

OPTIONAL EQUIPMENT

Hand throttle lever

Direct cooling system

Dual element aircleaner

MCV 3-SPOOL

Joystick levers

“Bow tie” drive chain

Canopy (ROPS/FOPS)

Vandalism Protection

Spark arresting muffler

Seat bar & seat belt

Pre-cleaner

Self levelling control system

Master switch

Back-up alarm

Enclosure Cabin (ROPS / FOPS)

Air-conditioning & heater

Defroster

Fenders

Side mirrors

Directional indicators

Foot control

PLEASE CONTACT

ENGINE

GENERAL

HYDRAULICS

D

I

M

E

N

S

I

O

N

S

P
E
R
F
O
R

M

A

N

C
E

Operating weight

Water

www.hyundai.eu EN - 2007. 03 Rev 0
