Hustler Turf 50 User Manual
Hustler Model 50
22” Walk Behind
Greens Mower
Owner’s Manual
111132_0409
•••••••
Hustler Turf Equipment
•••••
P.O. Box 7000
•••
Hesston, Kansas
•
67062-2097
IMPORTANT: This engine is not equipped with a spark arrester muffler. It is a violation of California Public Resource Code
Sec t ion 4442 to use or operate this engine o n any forest-covered, b rush-covered, or grass-covered unimpro ved land. Ot her
states or federal areas may ha ve similar laws.
The Engine Owner’s Manual provide s information regarding t he U.S. Enviro nmental Prote ctio n Agency ( EPA) and the
Califo rnia Emission Control Reg ulation of emissio n sys tems, maintenance and warranty.
Keep Eng ine Owner’s Manual with your unit. Should the Engine Owner’s Manual become damaged or illegible, re-
place immediatel y. Replacements may be ordered per the information found i n t he Product I nf ormation se ction of the
ow ner’s ma nual.
The engine exha ust from this product
cont ain s che mi cal s kno wn to the State
of California to cause cancer, birth
defects or other reproductive harm.
WARNING:
NOTICE OF REQUIREMENT OF SPARK ARRESTER MUFFLER
This equipment may create sparks that can start fires around dry vegetation. California Public Resources Code Section 4442.6 provides that it is unl awful to use or operate an intern al combustion engine on any forest-covered,
brush-covered, or grass-c overed land unless the engine is equippe d with a spark arrester mainta ined in eff ective
working order. A spark arrester is a device constructed of nonflammable materials specifically for the purpose of
removing and retaining carbon and other flammable particles over 0.0232 of an inch in size from the exhaust flow of
an internal combustion engine that uses hydrocarbon fuels or whi ch is qualified an d rated by the United States Forest Service. Ot her sta tes or federal areas may have similar laws. The Operator Should Contact Local Fire Agencies
For Laws or Regulati ons Relating t o Fire Prevention Requirements. THIS EQU IPMENT DOES NOT H AVE A
SPARK ARRESTER AND YOU R SHOULD C ONTACT YOUR AUTHORIZED HUSTLER DEALER FOR THE PURCHASE OF A SPAR K ARRESTER.
Inspect spark arrester daily; replace every 500 hours or as needed.
The En gine Owner’s Ma nual pro vides i nformation regarding the U.S. Environmental Protection Agency
(EPA) and the California Emission Control Regulation of emission systems, maintenance and warranty.
Keep Engine Owner’s Manual with your unit. Should the Engine Owner’s Manual become damaged or illegible, replac e immediately. Replacements may b e ordered per th e information found in t he Product Inf ormation sectio n o f the owner’s m anual.
The engine exha ust from this product
cont ain s che mi cal s kno wn to the State
of California to cause cancer, birth
defects or other reproductive harm.
WARNING:
GENERAL INFORMATION
This manual applies to the following Hustler equipment
line:
Hustler Model 50 (22”)
Walk Behind Greens Mower
To the new owner
The purpose of this manual is to assist owners and operators in
maintaining and operating the Hustler Model 50 Greens Mower.
Please read it carefully; information and instructions furnished
can help you achieve years of dependable performance.
A separate Engine Owner’s Manual is included with your
owner’s packet which contains additional engine information
that will not be repeated in this manual. You are urged to read it
before attempting any operation or repair of the engine.
It is the owner’s responsibility to make certain that the
operators and mechanics read and understand this manual and
all decals before operating this machine. It is also the owner’s
responsibility to make certain that the operators and mechanics
are qualified and physically able individuals, properly trained in
the operation of this equipment. All operator and mechanics
must become familiar with the safe operation of the equipment,
operator controls and safety signs.
Never let children or untrained people operate or service the
equipment. Local regulations may restrict the age of the
operator.
IMPORTANT: For more detailed maintenance and adjust-
ment information refer to the proper parts manual for your
machine. Refer to the “Product Literatur e” section of this manual for ordering information.
The owner/user can prevent and is responsible for accidents or
injuries occurring to themselves, other people or property.
Using this manual
General operation, adjustment and maintenance guidance is
outlined for both the experienced and novice Hustler user.
Operating conditions vary considerably and cannot all be
addressed individually. Through experience, however, operators
should find no difficulty in developing good operating skills
suitable to most conditions.
Directions used in this manual, for example RIGHT or LEFT,
refer to directions when seated on tractor facing forward, unless
otherwise stated.
Photographs and illustrations used were current at the time of
printing, but subsequent production changes may cause your
machine to vary slightly in detail. Hustler Turf Equipment
reserves the right to redesign and change the machine as deemed
necessary, without notification. If a change has been made to
your machine which is not reflected in this owner’s manual, or
the parts manual, see your Hustler dealer for current information
and parts.
Warranty registration
The Delivery and Warranty Registration form must be
completed and signed to validate your warranty protection. As
the new equipment owner, you are expected to see that the form
is completed and forwarded to Hustler Turf Equipment at time
of delivery.
Be sure to register the machine plus each attachment that
displays a model and serial identification number plate with
Hustler Turf Equipment.
IMPORTANT: Any unauthorized modification, alteration,
or use of non-approved attachments voids the warranty and
releases Hustler Turf Equipment from any liability arising from
subsequent use of this equipment.
Model and serial number
Tractor model and serial numbers are found on the serial
identification plate, located on the rear of the frame directly
below the engine.
These numbers are required on the Warranty Registration
form. They will also assure you of the correct service parts
when replacement becomes necessary.
Parts and service
Use original Hustler replacement parts only. These parts are
available through your local Hustler dealer. To obtain prompt,
efficient service, always provide the following information
when ordering parts:
1. Correct part description.
2. Correct model number.
3. Correct serial number.
All warranty repair and service must be handled through an
authorized Hustler dealer. Arrangements should be made
through your local service center.
111132_0409 1-1
1-2 111132_0409
HUSTLER MODEL 50 (22”) WALK BEHIND GREENS MOWER
THREE YEAR LIMITED WARRANTY
WHAT IS COVERED BY THIS WARRANTY
Hustler Turf Equipment, makes the following warranty to the
original purchaser only:
a. Three Year: Hustler Turf Equipment Model 50 (22”)
Walk Behind Greens Mowers are warranted for three
(3) years from date of delivery on all materials and
workmanship.
If the Purchaser discovers within this warranty period a
defect in materials or workmanship:
O He must promptly notify Hustler Turf Equipment, or
an authorized dealer, in writing of the defect. In no
event shall such notification be received by Hustler
Turf Equipment, or an authorized dealer later than
thirty-six (36) months from date of delivery.
O Within a reasonable time after such notification, Hus-
tler Turf Equipment, will correct any defect in material or workmanship on the Hustler Turf Equipment,
by repairing or replacing part(s) with either new or
used replacement parts.
O Such repair, including parts and labor shall be at the
expense of Hustler Turf Equipment, and,
b. The engine is covered by a two (2) year limited
warranty, by the engine manufacturer, to the original
owner (commercial or residential) only, and,
WHO MUST PERFORM THE WARRANTY SERVICE
All warranty service will be performed by dealers authorized by
Hustler Turf Equipment. Service calls and/or transportation
expense of the product to and from the authorized dealer, for
warranty work, will be paid by the owner of the product. For
warranty service contact an authorized dealer or write Hustler
Turf Equipment, 200 South Ridge Road, Hesston, Kansas
67062, or call 1-620-327-4911.
WHAT IS NOT COVERED BY THIS WARRANTY
Hustler Turf Equipment, does not warranty:
O Some product, components or parts not manufactured
by Hustler Turf Equipment
O Repairs made by unauthorized persons
O Damage caused by use of the Hustler Turf Equipment
for purposes other than those for which it was
designed
O Damages caused by disasters such as fire, flood,
wind, and lightening
O Damages caused by neglect, abuse, abnormal use,
improper or unreasonable use, accident, negligence or
misuse
O Repairs or replacement resulting from the use of
unauthorized parts, accessories or attachments
O Repairs or replacement as the result if any alterations
or modifications, in the determination of Hustler Turf
Equipment, which adversely affects the operation,
performance or durability of the equipment.
O Hustler Turf Equipment which has the serial number
removed or made illegible
O Depreciation or damage caused by normal wear, lack
of reasonable and proper maintenance, failure to fol-
low the product’s owner’s manual operating, maintenance and adjustment instructions or other
operational instructions provided by Hustler Turf
Equipment.
O Normal maintenance parts and service including, but
not limited to, filters, fuel, lubricants, tune-up parts,
belts, reels, bedknife, reel sharpening, bearings, brake
adjustments
O Repairs necessary due to improper fuel, contaminates
in the fuel system, or failure to properly prepare the
fuel system prior to any period of non-use over three
months
DISCLAIMER OF WARRANTY
The foregoing warranties are in lieu of all other warranties,
expressed or implied, including but not limited to the
implied warranties of merchantability and fitness for a particular purpose. However, if the Hustler Turf Equipment is
purchased as a consumer product, any implied warranty of
merchantability or fitness for a particular purpose is limited
to the duration of this limited warranty. Some states do not
allow limitations on how long an implied warranty lasts, so
the above limitation may not apply to you. This warranty
gives you specific legal rights, and you may also have other
rights which vary from state to state.
LIMITATION OF REMEDIES
In no case shall Hustler Turf Equipment, be liable for any special, incidental, or consequential damages based upon breach of
warranty, breach of contract, negligence, strict liability in tort,
or any other legal theory.
Such damages include, but are not limited to:
O Loss of profits
O Loss of savings or revenue
O Loss of use of Hustler Turf Equipment or any associ-
ated equipment
O Cost of capital
O Cost of any substitute equipment, facilities, services
or downtime
O The claims of third parties including customers, and
injury to property
Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you.
TIME LIMIT
Any action for breach of warranty must be commenced within
twenty-five (25) months following delivery of the goods in a
residential application. Any action for breach of warranty
must be commenced within 120 days follow ing delivery of the
goods in a rental application.
NO OTHER WARRANTIES
Unless modified in writing, signed by both parties, and
approved by the President of Hustler Turf Equipment, this
agreement is understood to be the complete and exclusive agreement between the parties, superseding all prior agreements, oral
or written, and all other communications between the parties
relating to the subject matter of this agreement. No employee of
111251_0409 1-3
Hustler Turf Equipment, or any other party is authorized to
make any warranty in addition to those made in this agreement.
ALLOCATION OF RISKS
This agreement allocates the risks of product failure between
Hustler Turf Equipment, and the purchaser. This allocation is
recognized by both parties and is reflected in the price of the
goods.
OWNER'S RESPONSIBILITY
You must maintain your Hustler Turf Consumer Product following the maintenance procedures described in your owner's manual. Such routine maintenance, whether performed by a dealer
or by you, is at your expense.
This machine like any other powered equipment is potentially dangerous unless properly operated. Any operator
must be cautious and keep safety in mind at all times. Any
operator, prior to using the Hustler Turf Equipment, should thoroughly familiarize himself with the owner's manual regarding
operation and safety of the machine, as well as all safety warnings on the machine itself.
WARRANTY REGISTRATION
1. Dealers must register the unit on-line at
www.Hustlerdealer.com or by filling out the Warranty
registration form, provided in the owner’s packet. If
using the Warranty registration form it MUST be
completed and signed by the authorized dealer and
original purchaser.
2. For validation, the completed Warranty registration form
MUST be forwarded to Hustler Turf Equipment, within
ten (10) days following date of purchase.
3. The date of purchase constitutes delivery.
1-4 111251_0409
602057
SAFETY PRECAUTIONS
602058
602060
727453CE
This safety alert symbol is used to call attention to a message
intended to provide a reasonable degree of PERSONAL
SAFETY for operators and other persons during the normal
operation and servicing of this equipment.
DANGER – denotes immediate hazards which WILL result
in severe personal injury or death.
WARNING – denotes a hazard or unsafe practice which
COULD result in severe personal injury or death.
This manual uses two other words to highlight informati on.
IMPORTANT calls attention to special mechanical information
and NOTE: emphasizes general information worthy of special
attention.
All operators should read this manual, or be instructed abou t
safe operating and maintenance procedures. This is the owner ’s
responsibility.
Improper use or maintenance by the operator or owner
can result in injury. To reduce the potential for injury,
comply with these safety instructions and always pay
attention to the safety alert V symbol, which means
DANGER or WARNING - “personal safety instructions.”
personal injury or death.
Incorrect usage of this machine may result in severe
injury. Personnel operating and maintaining it should be
trained in the proper use and should read the manuals
completely and thoroughly before attempting to set-up,
operate, adjust, or service this machine.
It is the owner’s responsibility to make certain that the
operators and mechanics read and understand this manual and
all decals before operating this machine. It is also the owner’s
responsibility to make certain that the operators and mechanics
are qualified and physically able individuals, properly trained in
the operation of this equipment. All operators and mechanics
must become familiar with the safe operation of the equipment,
operator controls and safety signs. Local regulations may
restrict the age of the operator.
The owner should also ensure that the operator/mechanic
know that they are responsible for their own safety as well as the
safety of other persons within the vicinity. Remember, the
operator is responsible for accidents or hazards occurring to
other people or their property.
Failure to comply with the instructions may result in
Safety and Instruction Decals
V Specific safety warning decals are located on the equipment near the immediate areas of potential hazards. These decals should
not be removed or obliterated. Replace them if they become non-readable.
The following illustrations show the various safety decals that are located on the machine. A brief explanation is shown to h elp the
operator understand the meanings of these decals.
Disengage
Read Owner’s Manual and decals before
attempting to operate this machine.
WARNING:
Hot surface!
• Avoid skin contact
with hot surface
Traction
drive
engaged
Engage
• Keep hands, feet and clothing away.
• Keep shields or covers in
place while machine is in
operation.
Cutting reel
engaged
111132_0409 2-1
DANGER:
Rotating pulleys and belts!
602059
STOP
602058
STOP
STOP
Read Operator’s Manual
before attempting to
operate this machine.
Read Operator’s Manual
before servicing this machine.
• Disconnect spark plug
before servicing.
• Always maintain a
safe distance from
people and pets
when mowing.
WARNING:
Thrown
objects!
• Keep hands, feet and
clothing away.
• Keep shields and covers
in place while machine is
in operation.
DANGER:
Rotating reel knife!
Cutting hazard!
• Keep grass
catcher in place
while machine is
in operation
• Stop engine and
mower reel before
servicing this
machine.
WARNING:
Falling!
• Before and while backing,
look behind and down for
small children and obstacles.
• Traverse across slopes.
• Avoid driving the machine
straight up and down slopes.
A
G
D
A. Fast
B. Slow
C. Park brake
D. Read Operator’s Manual before attempting to operate this
machine.
E. Read Operator’s Manual before attempting to service this
machine. Disconnect spark plug before servicing
F. Wear ear protection, eye protection and safety shoes when
operating this equipment.
G. Service brake
C
B
E
F
2-2 111132_0409
WARNING:
Fire!
Read owner’s manual before
operating
• Do not smoke while refueling.
• Do not remove the fuel tank cap or fill with engine running or
while the engine is hot.
• Allow engine to cool before storing machine inside a building.
• Store away from open flame or spark if there is fuel in tank.
• Clean up any gasoline spills.
WARNING:
Carbon monoxide
poisoning
• Never run the engine in an enclosed area
unless exhaust is vented to the outside.
Exhaust gases contain carbon monoxide
which is an odorless and deadly poison.
WARNING
601908
Operation of this equipment may create sparks
that can start fires around dry vegetation. A spark
arrestor may be required. The operator should
contact local fire agencies for laws or regulations
relating to fire prevention requirements.
FAILURE TO FOLLOW SAFE OPERATING MAY RESULT IN INJURY.
1. Read operator’s manual.
2. Keep guards and safety devices in place and working.
3. Wait for all movement to stop before servicing machine.
4. Keep hands and clothing away from rotating blades and belts.
WARNING
AVOID INJURY FROM ROTATING BLADES
1. Keep hands and feet away from rotating blades.
2. Shut off engine before servicing or lubricating.
111132_0409 2-3
2-4 111132_0409
SLOPE GUIDE
E (15o)
D (10
o
)
C (5
o
)
Line B
Line A
Slope Guide Lines
Use this diagram when determining the degree of slope to be mowed.
1. Hold this sheet of paper in front of you. Make sure that Line A is horizontal.
2. Align Line B with a vertical surface such as pole, tree or building.
3. Fold the paper along the slope guide lines (C, D or E).
4. Align the closest slope guide line with the ground slope. This will give you a close estimation of the ground slope
111132_0409 2-5
Loading...
