Operator’s Manual

ST 224

Please read the owner's manual carefully and make sure you

understand the instructions before using the machine.

English

IMPORTANT

Safe Operation Practices for Walk-Behind Snow Throwers

This snow thrower is capable of amputating hands and feet and throwing objects.

Failure to observe the following safety instructions could result in serious injury.

Look for this symbol to point out im por tant safety precautions. It means CAUTION!!! BE COME ALERT!!! YOUR SAFE TY IS IN VOLVED.

WARNING: Always disconnect spark plug wire and place it where it can not con tact plug in order to pre vent ac ci den tal start ing when setting up, trans port ing, ad just ing or making re pairs.

WARNING: This snow thrower is for use on sidewalks, driveways and other ground level surfaces. Caution should be exercised while using on sloping surfaces. Do not use snow thrower on surfaces above ground level such as roofs of residences, garages, porch es or other such structures or buildings.

Training

1. Read, understand and follow all instructions on the machine and in the manual(s) before operating this unit. Be thoroughly familiar with the controls and the proper use of the equipment. Know how to stop the unit and disengage the controls quickly.

2. Never allow children to operate the equipment. Never allow adults to operate the equipment without proper instruction.

3. Keep the area of operation clear of all persons, particularly small children.

4. Exercise caution to avoid slipping or falling, especially when operating the snow thrower in reverse.

Preparation

1. Thoroughly inspect the area where the equipment is to be used and remove all doormats, sleds, boards, wires, and other foreign objects.

2. Disengage all clutches and shift into neutral before starting the engine (motor).

3. Do not operate the equipment without wearing adequate winter garments. Avoid loose fitting clothing that can get caught in moving parts. Wear footwear that will improve footing on slippery surfaces.

4. Handle fuel with care; it is highly flammable (a) Use an approved fuel container. (b) Never add fuel to a running engine or hot engine. (c) Fill fuel tank outdoors with extreme care. Never fill

fuel tank indoors.

(d) Never fill containers inside a vehicle or on a truck

or trailer bed with a plastic liner. Always place containers on the ground, away from your vehicle, before filling.

(e) When practical, remove gas-powered equipment

from the truck or trailer and refuel it on the ground. If this is not possible, then refuel such equipment on a trailer with a portable container, rather than from a gasoline dispenser nozzle.

WARNING: Snow throwers have ex posed rotating parts, which can cause severe injury from contact, or from material thrown from the discharge chute. Keep the area of operation clear of all persons, small children and pets at all times including startup.

CAUTION: Muffler and other engine parts become extremely hot during operation and remain hot after engine has stopped. To avoid severe burns on contact, stay away from these areas.

WARNING: Engine exhaust, some of its con stit u ents, and certain vehicle com po nents contain or emit chem icals known to the State of Cal i for nia to cause can cer and birth defects or oth er re pro duc tive harm.

(f) Keep the nozzle in contact with the rim of the fuel

tank or container opening at all times, until refueling is complete. Do not use a nozzle lock-open device.

(g) Replace gasoline cap securely and wipe up spilled

fuel.

(h) If fuel is spilled on clothing, change clothing im-

mediately.

5. Use extension cords and receptacles as specified by the manufacturer for all units with electric drive motors or electric starting motors.

6. Adjust the collector housing height to clear gravel or crushed rock surface.

7. Never attempt to make any adjustments while the engine (motor) is running (except when specifically recommended by manufacturer).

8. Always wear safety glasses or eye shields during operation or while performing an adjustment or repair to protect eyes from foreign objects that may be thrown from the machine.

9. Use ear protectors to avoid damage to hearing.

Operation

1. Do not put hands or feet near or under rotating parts. Keep clear of the discharge opening at all times.

2. Exercise extreme caution when operating on or crossing gravel drives, walks, or roads. Stay alert for hidden hazards or traffic.

3. After striking a foreign object, stop the engine (motor), remove the wire from the spark plug, disconnect the cord on electric motors, thoroughly inspect the snow thrower for any damage, and repair the damage before restarting and operating the snow thrower.

4. If the unit should start to vibrate abnormally, stop the engine (motor) and check immediately for the cause. Vibration is generally a warning of trouble.

5. Stop the engine (motor) whenever you leave the operating position, before unclogging the collector/impeller housing or discharge chute, and when making any repairs, adjustments or inspections.

6. When cleaning, repairing or inspecting the snow thrower, stop the engine and make certain the collector/ impeller and all moving parts have stopped. Disconnect the spark plug wire and keep the wire away from the plug to prevent someone from accidentally starting the engine.

7. Do not run the engine indoors, except when starting the engine and for transporting the snow thrower in or out of the building. Open the outside doors; exhaust fumes are dangerous.

8. Exercise extreme caution when operating on slopes.

9. Never operate the snow thrower without proper guards, and other safety protective devices in place and working.

10. Never direct the discharge toward people or areas where property damage can occur. Keep children and others away.

11. Do not overload the machine capacity by attempting to clear snow at too fast a rate.

12. Never operate the machine at high transport speeds on slippery surfaces. Look behind and use care when operating in reverse.

13. Disengage power to the collector/impeller when snow thrower is transported or not in use.

14. Use only attachments and accessories approved by the manufacturer of the snow thrower (such as wheel weights, counterweights, or cabs).

15. Never operate the snow thrower without good visibility or light. Always be sure of your footing, and keep a firm hold on the handles. Walk; never run.

16. Never touch a hot engine or muffler.

Clearing a Clogged Discharge Chute

Hand contact with the rotating impeller inside the discharge chute is the most common cause of injury associated with snow throwers. Never use your hand to clean out the discharge chute. To clear the chute:

1. SHUT THE ENGINE OFF!

2. Wait 10 seconds to be sure the impeller blades have stopped rotating.

3. Always use a clean-out tool, not your hands.

Maintenance and Storage

1. Check shear bolts and other bolts at frequent intervals for proper tightness to be sure the equipment is in safe working condition.

2. Never store the machine with fuel in the fuel tank inside a building where ignition sources are present such as hot water heaters, space heaters, or clothes dryers. Allow the engine to cool before storing in any enclosure.

3. Always refer to operator’s manual for important details if the snow thrower is to be stored for an extended period.

4. Maintain or replace safety and instruction labels, as necessary.

5. Run the machine a few minutes after throwing snow to prevent freeze-up of the collector/impeller.

CONGRATULATIONS on your purchase of a new snow thrower. It has been designed, engineered and man u fac tured to give best possible dependability and per for mance.

Should you experience any problem you cannot easily remedy, please contact your nearest authorized service center. We have competent, well-trained tech ni cians and the proper tools to service or repair this unit.

Please read and retain this manual. The instructions will enable you to assemble and maintain your snow thrower prop er ly. Always observe the “SAFETY RULES”.

SERIAL NUMBER: ___________________________

DATE OF PURCHASE: _______________________

THE MODEL AND SERIAL NUMBERS WILL BE FOUND ON A DECAL ATTACHED TO THE REAR OF THE SNOW THROWER HOUSING.

YOU SHOULD RECORD BOTH SERIAL NUMBER AND DATE OF PURCHASE AND KEEP IN A SAFE PLACE FOR FUTURE REFERENCE.

TABLE OF CONTENTS

PRODUCT SPECIFICATIONS

Gasoline Capacity 0.71 Gallons (2,7 Liters) and Type: Unleaded Regular only

Oil Type SAE 30 (above 50°F) (API SG–SL): SAE 5W-30 or 10W-30 (32° to 50°F)

SAE 5W-30 (below 32°F)

Oil Capacity: 32 Ounces (0,9 Liters)

Spark Plug: F6RTC Gap: 0.030" (0,762 mm)

CUSTOMER RESPONSIBILITIES

• Read and observe the safety rules.

• Follow a regular schedule in maintaining, caring for and using your snow thrower.

• Follow the instructions under “Maintenance” and “Stor age” sec tions of this own er’s manual.

SAFETY RULES ........................................................ 2-3

PRODUCT SPECIFICATIONS ...................................... 3

CUSTOMER RESPONSIBILITIES ................................ 3

ASSEMBLY / PRE-OPERATION ............................... 5-6

OPERATION ............................................................ 7-12

MAINTENANCE SCHEDULE ..................................... 13

MAINTENANCE ..................................................... 13-14

SERVICE AND AD JUST MENTS ........................... 15-18

STORAGE ................................................................... 19

TROU BLE SHOOT ING ................................................ 20

WARRANTY ........................................................... 21-24

PARTS PACKED SEPARATELY IN CARTON

(1) MULTI-

WRENCH

(180684)

(2) FLAT WASHERS

(585690901)

(6) SHEAR BOLTS 1/4-20 x 1-3/4

(585511801)

SAFTEY

IGNITION KEY (S)

(443059)

(6) LOCKNUTS

1/4-20

(73800400)

(3) KNOB

581697501

(2) CARRIAGE BOLTS

5/16-18 x 2 1/4”

(585690801)

(2) HANDLE KNOBS

(189713)

(1) LOCKNUT 3/8

(585691001)

(1) CABLE

GUIDE

(581897301)

(1) LOCKNUT

5/16-18

(585691501)

(1) LOCKNUT

1/4-20

(585691401)

(1) CARRIAGE BOLT

5/16-18 x 5/8

(585832001)

(1) SHOULDER

BOLT 1/4-20

(585832201)

(1) SPRING

(184505)

ASSEMBLY / PRE-OPERATION

Read these instructions and this manual in its entirety before you attempt to assemble or operate your new snow thrower. Reading the entire manual will familiarize you with the unit, which will assist you in assembly, operation and maintenance of the product.

Your new snow thrower has been as sem bled at the factory with the ex cep tion of those parts left unassembled for shipping purposes. All parts such as nuts, washers, bolts, etc., necessary to com plete the as sem bly have been placed in the parts bag. To ensure safe and proper operation of your snow thrower, all parts and hard ware you assemble must be tightened se cure ly. Use the correct tools as nec es sary to ensure proper tightness.

REMOVE SNOW THROWER FROM CAR TON

1. Remove all accessible loose parts and parts boxes from carton.

2. Cut down all four corners of carton and lay panels flat.

3. Remove the two (2) screws securing the auger housing to the pallet and remove additional steel brackets from skid plate if equipped.

4. Remove all packing materials.

5. Remove plastic ties securing the snow thrower to the pallet.

6. Remove snow thrower from carton and check carton thor ough ly for ad di tion al loose parts.

HOW TO SET UP YOUR SNOW THROWER

Store the extra shear bolts, nuts and multi-wrench provided in parts bag.

NOTE: The multi-wrench may be used for assembly of the chute rotator head to snow thrower and making ad just ments to the skid plates.

UNFOLD UPPER HANDLE (See Figs. 1-3)

1. Raise upper handle to the operating position.

2. Adjust the handle height to desired position using the appropriate mounting holes and tighten lower handle knobs securely.

MOUNTING

HOLES

HANDLE

KNOB

FIG. 2

3. Install the additional carriage bolts, washers and handle knobs that are supplied in the bag of parts to secure upper handle to lower handle.

FIG. 1

UPPER HANDLE

CARRIAGE BOLT

HANDLE

KNOB

LOWER HANDLE

WASHER

FIG. 3

ASSEMBLY / PRE-OPERATION

INSTALL DISCHARGE CHUTE / CHUTE ROTATOR HEAD (See Fig. 4 and 5)

NOTE: The multi-wrench provided in your parts bag may

be used to install the chute rotator head.

1. Place discharge chute assembly on top of chute base with discharge opening toward front of snow thrower.

2. Position chute rotator head over chute bracket. If nec es sary, rotate chute assembly to align square and pin on un der side of chute rotator head with holes in chute brack et.

3. With chute rotator head and chute bracket aligned, po si tion chute rotator head on pin and threaded stud of mounting bracket.

4. Install locknut and cable guide on threaded stud and tighten securely.

CHUTE ROTATOR HEAD

LOCKNUT

CABLE GUIDE

INSTALL CHUTE DEFLECTOR REMOTE CONTROL (See Figs. 6 and 7)

1. Install remote cable bracket to discharge chute with 5/16-18 carriage bolt and 5/16-18 locknut as shown. Tighten securely.

2. Install remote cable eyelet to chute deflector with 1/4-20 shoulder bolt and 1/4-20 locknut as shown. Tighten nut securely. Eyelet will be loose on shoulder bolt.

3. Install spring hooks between hex nuts on chute rotator head and into hole in chute deflector as shown.

1/4-20 SHOULDER BOLT

1/4-20 LOCK NUT

CABLE EYELET

SPRING

HOOK BE TWEEN HEX NUTS ON CHUTE ROTATOR HEAD

CHUTE

DE FLEC TOR

5/16-18

CARRIAGE

BOLT

THREADED

STUD

CHUTE BRACKET

ALIGN BEFORE

TIGHTENING LOCKNUT

FIG. 4

ROTATOR HEAD

MOUNT ING

BRACKET

5. Place rotator cables through cable guide and secure cables to the lower handle using the double clip.

ROTATOR CABLES

DOUBLE CLIP

ROTATOR CABLES

FIG. 5

CABLE GUIDE

REMOTE

CABLE

BRACKET

5/16-18 LOCKNUT

FIG. 6

4. Install all 3 control lever knobs by pressing them down onto the control levers.

KNOB KNOB

CONTROL LEVER

FIG. 7

CHECK TIRE PRESSURE

The tires on your snow thrower were overinflated at the factory for shipping purposes. Correct and equal tire pres sure is important for best snow throwing performance.

• Reduce tire pressure to 14-17 PSI.

OPERATION

KNOW YOUR SNOW THROWER

READ THIS OWNER'S MANUAL AND ALL SAFETY RULES BEFORE OPERATING YOUR SNOW THROWER. Compare the illustrations with your snow thrower to familiarize yourself with the location of various controls and adjustments. Save this manual for future reference.

These symbols may appear on your snow thrower or in literature supplied with the product. Learn and understand their meaning.

DANGER

OR WARNING

READ AND FOLLOW ALL SAFETY INFORMATION

AND INSTRUCTIONS BEFORE USE OF THIS PRODUCT.

KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE.

IGNITION KEY. INSERT

TO START AND RUN

DANGER

DO NOT PLACE HANDS NEAR BLADES

REMOVE SPARK PLUG WIRE BEFORE PERFORMING MAINTENANCE

CHOKE CLOSED

(START)

OPERATE AT A SAFE DISTANCE FROM OTHER PEOPLE

PRIMER

READ OPERATORS MANUAL

WATCH FOR THROWN OBJECTS

EAR PROTECTION

RECOMMENDED

READ OPERATORS MANUAL

DO NOT OPERATE ON STEEP SLOPES

WATCH FOR THROWN OBJECTS

OPERATE AT A SAFE DISTANCE FOR OTHER PEOPLE

RECOIL START CHOKE OPEN

DANGER

IGNITION KEY. PULL

(RUN)

DANGER, KEEP FEET AWAY

OUT TO STOP

DISENGAGED

ENGAGED

TRACTION

DRIVE CONTROL

TRACTION

DRIVE CONTROL

STEER LEFT STEER RIGHT

SNOW

DISCHARGE

SNOW DISCHARGE

DANGER, KEEP HANDS AWAY

FORWARD

DOWN

CHUTE DEFLECTOR

REVERSE

ROTATE LEFT ROTATE RIGHT

CHUTE

ROTATION

OPERATION

MUF FLER

GAS O LINE FILLER CAP

CHOKE CON TROL

ON / OFF SWITCH

PRIM ER

SAFETY IGNITION KEY

FUEL SHUT-OFF VALVE

RECOIL STARTER HANDLE

CLEAN-OUT TOOL

POWER CORD

CHUTE DE FLEC TOR

DISCHARGE CHUTE

PLUG

ELECTRIC

START

BUTTON

LIGHT

AUGER CONTROL LEVER

DISCHARGE CHUTE CONTROL LEVER

DRIVE SPEED

CON TROL LEVER

DEFLECTOR

REMOTE

CONTROL

LEVER

TRACTION

DRIVE

CONTROL

LEVER

HANDLE KNOB

NOTE: ITEMS ABOVE

ARE SHOWN IN

THEIR TYPICAL

LOCATION ON THE

ENGINE. ACTUAL

LOCATION MAY VARY

WITH THE ENGINE

ON YOUR UNIT.

AU GERS

FIG. 8

SKID PLATE

MEETS A.N.S.I. SAFETY REQUIREMENTS

Our snow throwers conform to the standards of the American National Standards Institute.

Safety ignition key - must be inserted for the engine to start and run. Remove when snow thrower is not in use.

Electric start button - used for starting the engine.

Recoil (auxiliary) starter handle - used for start ing en gine.

Primer - pumps additional fuel from the carburetor to the

cylinder for use when starting a cold engine.

Choke Control - used for starting a cold engine.

ON / OFF switch - used to STOP the engine.

Fuel shut off valve - used for shutting off the fuel flow to

the engine.

Drive speed control lever - used to select forward or reverse motion and speed of snow thrower.

Traction drive control lever - used to engage powerpro pelled for ward or reverse motion of snow thrower.

Auger control lever - used to engage auger motion (throw snow).

Discharge chute control lever - used to change the di rec tion the snow is thrown.

Deflector remote control lever - used to change the dis tance the snow is thrown.

Skid plate - used to adjust height of scraper bar from the ground.

MUF FLER

OPERATION

The operation of any snow thrower can result in foreign objects thrown into the eyes, which can result in severe eye damage. Always wear safety glasses or eye shields while operating

your snow thrower or performing any ad just ments or repairs. We recommend standard safe ty glasses or a wide vision safety mask worn over spectacles.

HOW TO USE YOUR SNOW THROWER

Know how to operate all controls before adding fuel or

attempting to start the engine.

STOPPING

TRACTION DRIVE

• Release traction drive control lever to stop the forward

or reverse movement of the snow thrower.

AUGER

• Release the auger control lever to stop throwing snow.

ENGINE

1. Move ON / OFF switch to “OFF” position.

2. Remove (do not turn) safety ignition key to prevent

unauthorized use.

NOTE: Never use choke to stop engine.

TO USE FUEL SHUT-OFF VALVE (See Fig. 9)

The fuel shut-off valve is located beneath the fuel tank on the engine. Always op er ate the snow thrower with the fuel shut-off valve in the OPEN position.

TO CONTROL SNOW DISCHARGE (See Fig. 11)

WARNING: If the discharge chute or au ger become clogged, shut-off en gine and wait for all moving parts to stop. Use the clean-out tool, NOT YOUR HANDS, to un clog the chute and/or auger.

The DIRECTION in which snow is to be thrown is controlled by the discharge chute control lever.

• To change the discharge chute position, pull backward on discharge chute control lever and move lever left or right until chute is in desired position. Be sure lever springs back and locks into desired position.

The DISTANCE that snow is thrown is controlled by the position of the chute deflector. Set the deflector low to throw snow a short distance; set the deflector higher to throw snow farther.

• Push right on chute deflector control lever and move lever forward to lower the deflector and decrease the distance. Move lever back to raise the deflector and increase the distance. Be sure lever springs back and locks into desired position.

OFF

OPEN

FIG. 9

TO USE CHOKE CON TROL (See Fig. 10)

The choke con trol is located on the en gine. Use the choke control when ev er you are starting a cold en gine. Do not use to start a warm en gine.

• To engage choke, rotate lever clockwise to “FULL” position.

CHOKE CONTROL

CHOKE

TRUCTIONS

CONTROL

DISCHARGE CHUTE CONTROL LEVER

CHUTE DEFLECTOR REMOTE CONTROL LEVER

FIG. 11

TO THROW SNOW (See Fig. 12)

The auger rotation is controlled by the auger control lever located on the right side handle.

• Squeeze auger control lever to handle to engage the auger and throw snow.

• Release the auger control lever to stop throwing snow.

AUGER

CONTROL

LEVER

FIG. 10

FIG. 12

+ 19 hidden pages
