For Husqvarna Parts Call 606-678-9623 or 606-561-4983
Illustrated Parts
List
GTH 2350
(GTHK 2350 A), 954568540
2002-02
I0202005
Repair Parts Manual Ride Mower
www.mymowerparts.com
Page 2
For Husqvarna Parts Call 606-678-9623 or 606-561-4983
TRACTOR - - MODEL NO. GTH2350 (GTHK2350A), PRODUCT NO. 954 56 85-40
SCHEMATIC
AMMETER
(OPTIONAL)
RED
G
IGNITION
SWITCH
BLACK
BROWN
RED
BATTERY
A
RED
FUSE
WHITE
S
B
BLACK
M
A1
A2L
CG
B
RED
WHITE
F
H
E
A
BLACK
D
ORANGE
PTO (DISENGAGED)
BLACK
CLUTCH / BRAKE
BLACK
(PEDAL UP)
RED
BLACK
RED
WHITE
SOLENOID
ELECTRIC CLUTCH
85 86
87
RED
M
STARTER
BLACK
30
BLACK
BLACK
87A
GREEN
SEAT SWITCH
(NOT OCCUPIED)
FUEL
LINE
BLUE
GREEN
BLACK
HOUR
METER
(OPTIONAL)
IGNITION
UNIT
OPERATOR
PRESENCE
RELAY #1
BLACK
SPARK PLUGS
ON TWIN CYL. ENGINES)
BLACK
GAP
(2 PLUGS
IGNITION SWITCH
OFF
CIRCUITPOSITION
M + G + A1
B + A1ON + LIGHTS
B + A1ON
B + S + A1START
“MAKE”
NONE
L + A2
NONE
NONE
WIRING INSULATED CLIPS
NOTE: IF WIRING INSULATED
CLIPS WERE REMOVED FOR
SERVICING OF UNIT, THEY
SHOULD BE REPLACED TO
PROPERLY SECURE YOUR
WIRING.
FUEL SHUT-OFF
CHARGING SYSTEM OUTPUT
15 AMP DC @ 3600 RPM
RED
87
87A
8586
30
RELAY
REMOVABLE
CONNECTIONS
SOLENOID
RED
PTO SWITCH
OFF
C + G, B + H
C + F, B + E, A + DON
NON-REMOVABLE
CONNECTIONS
29
REGULATOR
28 VOLTS AC @ 3600 RPM (REGULATOR DISCONNECTED)
BROWN
YELLOW
ALTERNATOR
HEADLIGHTS
CIRCUITPOSITION
G
FC
E
H
A
D
BLACK
B
www.mymowerparts.com
Page 3
16
For Husqvarna Parts Call 606-678-9623 or 606-561-4983
REPAIR PARTS
TRACTOR - - MODEL NO. GTH2350 (GTHK2350A), PRODUCT NO. 954 56 85-40
ELECTRICAL
22
10
25
48
42
81
79
21
40
33
30
12
8
11
27
26
2
1
12
28
29
50
89
46
30
www.mymowerparts.com
Page 4
For Husqvarna Parts Call 606-678-9623 or 606-561-4983
REPAIR PARTS
TRACTOR - - MODEL NO. GTH2350 (GTHK2350A), PRODUCT NO. 954 56 85-40
ELECTRICAL
KEY PART
NO. NO. DESCRIPTION
1 532 14 49-27 Battery
2 874 76 04-12 Bolt Hex Head 1/4-20 x 3/4
8 532 12 48-86 Tray, Battery
10 532 14 52-11 Bolt, Battery Front 1/4-20 x 7.5 Zinc
11 532 15 01-09 Holddown Battery Front Mount
12 532 14 57-69 Nut, Push Nylon 1.4" Battery Front
16 532 17 61-38 Switch Interlock
21 532 17 56-88 Harness Socket Light w/4152J
22 532 00 41-52 Bulb Light
25 532 17 07-55 Cable, Battery
26 532 10 88-24 Fuse
27 873 51 04-00 Nut Keps Hex 1/4-20
28 532 17 06-97 Cable, Ground
29 532 16 07-84 Switch, Plunger Normal Op Olive
30 532 17 55-66 Switch, Ign
33 532 14 04-01 Key
40 532 17 02-38 Harness Ign.
42 532 15 43-36 Cover, Terminal Red
46 532 16 96-35 Hourmeter Snap-In
48 532 14 08-44 Adapter Ammeter
50 532 17 46-51 Switch, PTO
79 532 17 52-42 Bulbholder Asm
81 532 10 97-48 Relay Asm.
89 532 16 96-39 Bracket Snap-In Hourmeter
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
31
www.mymowerparts.com
Page 5
For Husqvarna Parts Call 606-678-9623 or 606-561-4983
REPAIR PARTS
TRACTOR - - MODEL NO. GTH2350 (GTHK2350A), PRODUCT NO. 954 56 85-40
CHASSIS AND ENCLOSURES
15
14
153
130
25
162
58
17
21
138
141
161
158
37
17
17
28
119
47
17
20
19
2
166
165
20
137
91
17
5
68
35
7
144
7
130
43
34
16
56
36
99
140
148
31
130
18
122
150
122
8
146
6
156
156
30
36
139
32
17
33
45
17
17
17
139
1
159
84
7
143
142
50
17
44
130
152
156
17
130
17
60
17
60
24
86
4
17
39
32
www.mymowerparts.com
17
47
Page 6
For Husqvarna Parts Call 606-678-9623 or 606-561-4983
REPAIR PARTS
TRACTOR - - MODEL NO. GTH2350 (GTHK2350A), PRODUCT NO. 954 56 85-40
CHASSIS AND ENCLOSURES
KEY PART
NO. NO. DESCRIPTION
1 532 18 03-72 Rail, Frame RH
2 532 17 52-82 Drawbar, Gt
4 873 80 07-00 Nut, Lock Hex 7/16 Unc
5 532 17 75-82 Dash, Plastic
6 532 15 78-82 Dash, 1PCS, Lower
7 817 72 04-08 Screw, Thd Cut 1/4-20 x 1/2
8 532 14 51-66 Support, Battery
14 532 17 75-83 Hood Asm., Pnt
15 532 16 18-41 Lens LH
16 532 12 17-94 Cover, Access
17 817 06 06-12 Screw, 3/8-16 x 3/4
18 532 17 75-84 Grille
19 819 13 13-12 Washer 13/32 x 13/16 x 12 Ga.
20 874 76 06-16 Bolt, Fin Hex 3/8-16 x 1
21 873 68 06-00 Nut, Crownlock 3/8-16
24 532 18 10-58 Footrest, RH
25 532 16 18-42 Lens RH
28 532 18 10-57 Footrest, LH
30 532 14 50-52 Saddle
31 532 16 14-19 Bracket Supt 1-pc Vgt Steering
32 532 16 13-27 Bracket, Frame Pivot Lh
33 532 16 13-26 Bracket, Frame Pivot Rh
34 532 17 70-18 Plate Asm Engine Chassis
35 819 11 11-16 Washer 11/32 x 11/16 x 16 Ga.
36 817 06 05-12 Screw 5/16-18 x 3/4
37 532 18 17-20 Fender, Pnt.
39 532 17 52-78 Bracket, Axle Front
43 532 13 69-39 Bracket, Spnsn Front Lh
44 532 13 69-40 Bracket, Spnsn Front Rh
45 532 15 49-13 Bracket Asm., Susp Chassis Rh
47 817 49 06-08 Screw Thdrol 3/8-16 x 1/2
50 532 17 54-76 Bracket, Chassis Front
56 532 15 49-14 Bracket Asm., Susp Chassis Lh
KEY PART
NO. NO. DESCRIPTION
58 532 17 53-15 Bracket Asm., Fender
60 817 06 06-20 Screw 3/8-16 x 1-1/4
68 817 49 05-08 Screw, 5/16-18 x 1/2
84 532 14 29-92 Stop Over Center
86 874 76 07-16 Bolt, Fin Hex 7/16-14 Unc x 1
91 532 18 03-66 Rail, Frame Lh
99 532 17 71-43 Rod Asm. Bypass
119 873 68 06-00 Nut Crownlock 3/8-16 Unc
122 532 16 14-64 Screw Hex WSHD 8-18 x 7/8
130 532 16 48-63 Screw Hw Hd Hi-Lo #13-16 x 3/4
137 874 78 07-16 Bolt Fin Hex 7/16-14 x 1 Gr. 5
138 532 18 17-98 Cupholder
139 532 17 18-73 Bolt Shoulder 5/16-18
140 532 16 38-06 Magnet Stealth
141 532 16 38-05 Striker Plate
142 532 16 18-97 Bracket Dash Stealth RH
143 532 17 75-86 Skirt Grille RH
144 532 16 19-00 Bracket Dash Stealth LH
146 532 17 75-87 Skirt Grille LH
148 532 16 46-55 Extrusion Bumper
150 532 16 12-37 Duct Heat Hood
152 532 17 79-56 Shield, Browning
153 532 17 97-65 Light Box Asm w/Lens
156 817 00 05-12 Screw 5/16-18 x 3/4
158 817 67 06-08 Screw 3/8-16 x 1/2
159 817 00 06-12 Screw Hex Wsh Thdrol 3/8-16 x 3/4
161 532 18 17-87 Consol Fuel Window
162 532 14 24-32 Screw Hex Wsh Hi-Lo 1/4-1/2 Unc
165 532 18 22-54 Bracket Support Fuel Tank
166 873 68 07-00 Nut Crownlock 7/16-14
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
33
www.mymowerparts.com
Page 7
For Husqvarna Parts Call 606-678-9623 or 606-561-4983
REPAIR PARTS
TRACTOR - - MODEL NO. GTH2350 (GTHK2350A), PRODUCT NO. 954 56 85-40
GROUND DRIVE
42
39
40
70
41
89
137
64
73
6
22
94
37
123
46
38
23
133
68
94
56
89
148
111
120
98
89
126
125
124
38
35
152
37
34
131
58
36
29
151
135
77
114
132
77
74
65
53
20
55
117
52
129
147
130
48
120
146
61
117
50
120
114
128
48
143
121
117
2
127
153
142
122
9
7
69
33
3
145
106
107
108
2
1
145
138
3
69
112
33
34
www.mymowerparts.com
Page 8
For Husqvarna Parts Call 606-678-9623 or 606-561-4983
REPAIR PARTS
TRACTOR - - MODEL NO. GTH2350 (GTHK2350A), PRODUCT NO. 954 56 85-40
GROUND DRIVE
KEY PART
NO. NO. DESCRIPTION
1 - - - - - - - Transaxle Hydro Gear
331-3000 (Order Parts From
Transaxle Manufacturer)
2 532 00 70-70 Key 1/4 x 2.5
3 532 00 75-63 Washer
6 876 02 04-12 Pin, Cotter
7 532 14 05-07 Wheel, Hub Assembly
9 532 14 00-80 Bolt, Hub
20 873 94 08-00 Nut
22 532 18 02-35 Lever Asm Shift
23 532 14 08-45 Knob
29 532 17 66-00 Brake, Rod
33 812 00 00-53 Ring E
34 532 07 16-73 Cap, Parking Brake
35 532 13 76-48 Rod, Parking Brake
36 532 14 94-12 Spring, Drive Ground
37 532 12 17-49 Washer 25/32 x 1-1/4 x 16 Ga.
38 532 15 00-35 Nyliner
39 874 32 10-16 Screw, Fin. #10-24 x 1
40 532 17 85-75 Actuator, Interlock VGT
41 873 93 10-00 Nut Centerlock 10-24 Unc
42 532 12 47-82 Cover, Pedal
46 532 14 51-70 Retainer, Spring
48 872 11 06-14 Bolt Rdhd 3/8-16 x 1.3/4 Gr. 5
50 532 13 14-94 Pulley, Idler, Flat
52 532 12 77-83 Pulley, Idler, Grooved
53 532 00 02-07 Washer Hardened
55 532 10 57-06 Bearing, Idler
56 532 16 15-97 V-Belt
58 874 76 07-24 Bolt Fin Hex 7/16-14 x 1-1/2
61 532 14 39-95 Pulley, Transaxle
64 532 17 66-01 Shaft, Brake Pedal
65 532 06 76-09 Bolt, Shoulder
68 532 00 51-42 Pin, Roll
69 532 12 38-00 Washer
70 532 18 17-88 Console Automatic YT/GT
73 874 49 05-48 Bolt Hex Flghd 5/16-18 x 3 Gr5
74 532 14 24-32 Screw Hex Wsh. Hi-Lo 1/4-1/2
KEY PART
NO. NO. DESCRIPTION
77 874 76 07-16 Bolt Fin Hex 7/16-14 x 1
89 873 68 07-00 Nut Crownlock 7/16-14 Unc
94 532 13 38-35 Fastener Christmas Tree
98 532 14 10-04 Bracket Shift
106 532 14 29-18 O-Ring Asm Hydro Gear
107 532 15 47-39 Line Fuel Hydro 15” VGT
108 532 14 29-17 Cap Asm Vent Hydro Gear
111 532 15 62-40 Spacer Shift Lever VGTH
112 532 15 61-04 Washer Nylon High Temp
114 873 80 05-00 Nut Lock Hex W/Ins 5/16-18 Unc
117 873 90 06-00 Nut, Lock Flg. 3/8-16
120 817 06 06-12 Screw 3/8-16 x .75
121 532 17 56-11 Bracket Strap Torque
122 872 01 05-20 Bolt RDHDSQ 5/16-18 Unc x 2-1/2
123 532 17 66-02 Rod Shift
124 532 16 54-92 Bolt Shoulder 5/16-18 x .561
125 532 16 68-80 Screw 5/16-18 x 5/8
126 532 16 60-02 Washer SRRTD 5/16 ID x 1.0 x .125
127 532 17 73-62 Link Control Clutch
128 532 17 66-24 Spring Drive GRND
129 532 17 94-73 Bracket Asm Idler Tensioning
130 819 13 10-16 Washer 13/32 x 5/8 x 16 Ga.
131 876 02 03-12 Pin Cotter 3/32 x 3/4
132 532 17 54-67 Bracket Mtg Hydro 3500 LH VGT
133 532 17 54-68 Bracket Mtg Hydro 3500 RH VGT
135 532 17 73-64 Link Asm Control Hydro 3500
137 532 12 49-49 Nut Lock 5/16-18 NC Thd.
138 532 00 13-70 Washer Thrust 5/8 x 1.10 x 1/32
142 532 17 54-69 Strap Torque HG-3500
145 532 16 31-68 Washer Axle Flange HG-3000
146 532 14 04-62 Fan 7" Hydro
147 532 14 13-22 Washer
148 817 06 06-20 Screw 3/8-16 x 1-1/4
151 874 76 05-14 Bolt Hex 5/16-18 x 7/8
152 532 17 87-05 Bolt Hex 5/16 x 1 W/Patch
153 532 12 47-88 Spring, Retainer
NOTE: All component dimensions given in U. S.
inches 1 inch = 25.4 mm
35
www.mymowerparts.com
Page 9
For Husqvarna Parts Call 606-678-9623 or 606-561-4983
REPAIR PARTS
TRACTOR - - MODEL NO. GTH2350 (GTHK2350A), PRODUCT NO. 954 56 85-40
STEERING ASSEMBLY
34
33
32
26
25
14
45
1
44
21
20
23
22
31
41
6
27
9
8
7
2
6
6
4
14
15
14
8
6
29
14
36
37,39
17
10
15
14
38,40
11
14
3
9
8
12
15
14
13
13
7
3
6
6
5
7
8
42
15
14
14
18
35
19
27
28
6
16
46
47
48
49
50
36
www.mymowerparts.com
Page 10
For Husqvarna Parts Call 606-678-9623 or 606-561-4983
REPAIR PARTS
TRACTOR - - MODEL NO. GTH2350 (GTHK2350A), PRODUCT NO. 954 56 85-40
STEERING ASSEMBLY
KEY PART
NO. NO. DESCRIPTION
1 532 16 66-27 Wheel, Steering
2 532 17 85-57 Axle Asm., Front
3 532 12 48-36 Fitting, Grease
4 532 16 18-49 Spindle Asm, LH
5 532 16 18-48 Spindle Asm., RH
6 532 12 49-31 Bearing, Race Thrust Harden
7 532 12 17-48 Washer 25/32 x 1-5/8 x 16 Ga.
8 812 00 00-29 Ring, Klip #T5304-75
9 532 12 12-32 Cap, Spindle
10 874 78 10-44 Bolt, Fin Hex 5/8-11 x 2-3/4
11 532 13 65-18 Spacer Brg Axle Front 1.570
12 873 90 10-00 Nut, Lock Flange 5/8-11 Unc
13 532 12 17-49 Washer 25/32 x 1-1/4 x 16 Ga.
14 810 04 06-00 Washer, Lock Hvy Hlcl Spr 3/8
15 532 12 47-01 Nut Lock Center 3/8-24 Unf
16 532 14 51-03 Shaft Asm., Steering
17 532 13 73-47 Rod Asm., Tie Ball J Ball Vgt (Inc. Key No. 36-40)
18 532 17 55-72 Draglink, Ball Joint Solid Vgt
19 532 15 60-11 Support Asm., Steering Vgt
20 532 17 75-92 Boot Steering
21 532 15 99-45 Adapter, Wheel Steering
22 532 15 51-05 Bushing, Strg.
23 532 15 29-27 Screw
25 874 78 06-16 Bolt, Fin Hex 3/8-16 x 1 Gr. 5
26 532 16 66-26 Cap , Wheel Steering
27 532 12 49-37 Bearing, Col. Strg.
28 817 00 06-12 Screw 3/8-16 x 3/4
29 532 10 42-39 Bearing, Flange
31 532 13 81-36 Bushing, Nyliner Snap
32 819 11 16-10 Washer 11/32 x 1 x 10 Ga.
33 810 04 05-00 Washer, Lock Hvy Hlcl Spr 5/16
34 874 78 05-12 Bolt, Hex Hd 5/16-18 x 3/4
35 532 13 80-59 Gear, Sector Steering
36 532 13 71-56 Tie Rod
37 873 36 06-00 Jam Nut RH Thread
38 532 10 98-50 Joint Asm. Ball RH Thread
39 873 70 06-00 Nut Hex Jam 3/8-24 UNF LH
40 532 10 98-51 Joint Asm Ball LH
41 532 15 52-46 Bracket Switch Inerlock VGT97
42 817 49 05-08 Screw 5/16-18 x 1/2
44 532 17 75-93 Extension Steering Premium
45 819 13 24-11 Washer 13/32 x 1-1/20 x 11 Ga.
46 819 13 16-10 Washer FLat 13/32 x 1/10 Ga.
47 532 17 94-71 Bracket Asm. Idler
48 817 06 06-12 Screw 3/8-16 x .75
49 532 17 58-20 Pulley Idler Flat
50 873 90 06-00 Nut Lock Flg 3/8-16 Unc
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
37
www.mymowerparts.com
Page 11
For Husqvarna Parts Call 606-678-9623 or 606-561-4983
REPAIR PARTS
TRACTOR - - MODEL NO. GTH2350 (GTHK2350A), PRODUCT NO. 954 56 85-40
ENGINE
25
22
1
83
18
21
15
17
20
28
37
24
84
47
10
80
9
43
41
42
84
12
11
74
82
81
69
62
71
70
35
80
2
29
16
26
27
37
39
KEY PART
NO. NO. DESCRIPTION
1 - - - - - - - Engine Kohler Model No. CV675
(Order parts from engine manufacturer)
2 532 14 97-23 Muffler Side
8 532 12 13-61 Pulley V-Idler
9 532 17 77-48 Keeper Asm. Belt Engine VGT
10 532 17 52-87 Bushing
11 532 17 00-56 Clutch Electric
12 532 14 39-96 Pulley Engine VGT Elect Clutch
15 532 17 91-15 Tank Fuel
16 532 10 92-27 Pad Spacer
17 532 10 60-82 Pad Spacer
18 532 18 18-03 Cap Fuel
20 532 18 29-37 Control Throttle
21 532 16 48-63 Screw Hex Thd Cut 1/4 - 20 X 5/8
22 532 17 81-48 Control Choke
24 811 05 06-00 Washer Ext Tooth 3/8
25 873 92 06-00 Nut Keps 3/8-24 Unf
26 532 12 49-52 Bushing
27 532 13 92-77 Stem Tank Fuel
28 532 00 71-19 Fuel Line
29 532 13 71-80 Spark Arrester Kit
31 532 14 50-06 Clip Push-In Hinged
8
40
SPARK ARRESTER KIT
KEY PART
NO. NO. DESCRIPTION
35 810 01 05-00 Washer
37 532 12 34-87 Clamp Hose
39 817 49 06-36 Screw TT 3/8-16 x 2-1/4 UNC
40 817 49 06-64 Screw TT 3/8-16 x 4 UNC
41 532 12 61-97 Washer 1-1/2 OD X 15/32 ID X .250
42 810 04 07-00 Washer Lock 7/16
43 532 17 99-53 Bolt Hex 7/16-20 X 3.75 Gr. 5
47 532 17 52-88 Bushing
62 532 14 66-29 Shield Heat Muffler
69 - - - - - - - - Gasket (Order from engine mfg.)
70 532 17 55-45 Tube Exhaust LH
71 532 17 55-46 Tube Exhaust RH
74 532 16 22-95 Elbow Street Brass
80 532 16 33-05 Nut Flange M8-1.25
81 532 14 84-56 Tube Drain Oil Easy
82 532 14 83-15 Plug Drain Oil Easy
83 532 17 18-77 Bolt 5/16-18unc X 1-3/4 W/Sems
84 817 06 06-24 Screw 3/8-16 x 1-1/2
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
38
www.mymowerparts.com
Page 12
For Husqvarna Parts Call 606-678-9623 or 606-561-4983
REPAIR PARTS
TRACTOR - - MODEL NO. GTH2350 (GTHK2350A), PRODUCT NO. 954 56 85-40
SEAT ASSEMBLY
1
20
14
8
10
7
20
8
7
16
15
18
13
17
KEY PART
NO. NO. DESCRIPTION
1 532 14 08-40 Seat
2 532 14 05-51 Bracket, Pivot Seat
3 532 14 06-75 Strap, Fender
4 532 12 70-18 Bolt Shoulder 5/16-18 x .62
5 532 14 50-06 Clip, Push In Hinged
6 873 80 06-00 Nut, Crownlock 3/8-16
7 532 12 41-81 Spring, Seat Cprsn
8 532 17 18-77 Bolt 5/16-18 UNC X 3/4
10 532 18 24-93 Pan, Seat
12 532 12 12-46 Bracket, Mounting Switch
13 532 12 12-48 Bushing, Snap
19
12
2
4
5
6
5
37
21
3
KEY PART
NO. NO. DESCRIPTION
14 872 05 04-12 Bolt, Carriage 1/4-20 X 1-1/2
15 532 12 12-49 Spacer, Split
16 532 12 37-40 Spring, Cprsn
17 532 12 39-76 Nut, Lock 1/4 Lge Flg Gr. 5
18 819 17 19-12 Washer 17/32 x 1-3/16 x 12 Ga.
19 532 16 63-69 Knob Seat
20 532 12 42-38 Cap, Spring Seat
21 532 17 18-52 Bolt, Shoulder 5/16-18
37 873 80 05-00 Nut Lock Hx w/Ins. 5/16-18 Unc
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
39
www.mymowerparts.com
Page 13
For Husqvarna Parts Call 606-678-9623 or 606-561-4983
REPAIR PARTS
TRACTOR - - MODEL NO. GTH2350 (GTHK2350A), PRODUCT NO. 954 56 85-40
DECAL
15
9
8
3
7
24
6
4
7
1
10
23
2
KEY PART
NO. NO. DESCRIPTION
1 532 18 23-91 Decal, Replacement Parts
2 532 17 67-75 Decal, Engine
3 532 18 16-62 Decal, Hood, RH
4 532 18 16-63 Decal, Hood, LH
6 532 17 05-63 Decal, Warning
7 532 18 24-09 Decal, Side Panel
8 532 18 08-23 Decal, Dash
9 532 17 68-22 Decal, Fender
10 532 15 71-40 Decal, Danger
WHEELS & TIRES
1
2
6
12
11
3
4
7
10
17
23
13
KEY PART
NO. NO. DESCRIPTION
11 532 18 12-53 Decal, Foot Rest
13 532 16 03-97 Decal, V-Belt Sch
15 532 17 05-64 Decal, Ins. Strg Whl
17 532 14 08-37 Decal, Saddle Brake Parking
23 532 10 62-02 Reflector, Taillight
24 532 14 50-05 Decal, Btry Dngr/Psn
- - 532 16 69-60 Decal, Bypass
- - 532 13 83-11 Decal, Handle Lift (Lift Handle)
- - 532 18 19-17 Footrest Pad Rh
- - 532 18 19-16 Footrest Pad Lh
- - 532 18 06-66 Manual, Owner’s (English)
- - 532 18 06-67 Manual, Owner’s (French)
KEY PART
NO. NO. DESCRIPTION
1 532 05 91-92 Cap, Valve, Tire
2 532 06 51-39 Stem, Valve
3 532 14 45-09 Rim Assembly, Front
4 532 00 81-34 Tube, Front (Service Item Only)
5 532 10 62-30 Tire, Front
5
9
8
6 532 12 49-57 Fitting, Grease
7 532 12 49-59 Bearing, Flange (Front Wheel Only)
8 532 17 50-39 Cap, Hub
9 532 10 55-88 Tire, Rear
10 532 00 71-54 Tube, Rear (Service Item Only)
11 532 14 45-10 Rim Assembly, Rear
12 532 12 48-60 Fitting, Grease
- - 532 14 43-34 Sealant, Tire (10 oz. Tube)
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
40
www.mymowerparts.com
Page 14
For Husqvarna Parts Call 606-678-9623 or 606-561-4983
REPAIR PARTS
TRACTOR - - MODEL NO. GTH2350 (GTHK2350A), PRODUCT NO. 954 56 85-40
LIFT ASSEMBLY
39
40
42
43
38
35
70
73
34
32
31
30
7
8
9
10
80
1
23
23
13
14
41
11
23
76
14
41
13
11
23
23
76
29
4
5
5
4
12
24
75
72
82
2
26
78
3
6
KEY PART
NO. NO. DESCRIPTION
1 532 12 10-06 Rod Asm., Lever
2 532 18 00-45 Shaft Asm., Lift Vgt
3 532 15 91-89 Lever Asm., Lift Rh
4 812 00 00-22 E-Ring Truarc #5133-87
5 819 29 20-16 Washer 29/32 x 1-1/4 x 16 Ga.
6 871 11 06-24 Bolt, Fin Hex 3/8-16 x 1-1/2
7 532 12 56-31 Grip, Handle
8 532 12 45-26 Button, Plunger
9 532 12 23-64 Plunger, Lever Lift
10 532 12 48-74 Spring 2-1/8"
11 532 14 67-04 Link Lift
12 532 16 35-52 Retainer, Spring
13 532 13 98-68 Arm Assembly Suspension Mower
14 532 16 98-65 Bearing
23 532 12 46-70 Retainer, Spring
24 873 35 08-00 Nut, Jam Hex 1/2-13 Unc
26 873 80 08-00 Nut, Lock W/Wsh 1/2-13 Unc
29 532 15 02-33 Trunnion Infin Height
30 532 11 08-07 Nut, Special
31 819 13 10-16 Washer 13/32 x 5/8 x 16 Ga.
KEY PART
NO. NO. DESCRIPTION
32 532 13 71-50 Spring, Compression Inf Hgt
34 532 13 71-67 Rod, Adj Lift
35 532 13 80-57 Knob, Inf 3/8-16 Unc
38 532 15 50-97 Pointer Height Indicator
39 532 12 39-35 Plug, Hole Blk. 1.485/1.515 Dia.
40 817 06 05-16 Screw 5/16-18 x 1
41 873 54 06-00 Nut Crownlock 3/8-24
42 819 11 24-10 Washer 11/32 x 1-1/2 x 10 Ga.
43 532 12 39-34 Scale, Indicator Height
70 532 14 52-12 Nut Hex Flange Lock
72 532 11 04-52 Nut Push Phos & Oil
73 873 35 06-00 Nut, Hex Jam 3/8-16 Unc
75 532 17 58-05 Plate, Asm, Susp, Front
76 532 17 55-60 Pin Flange
78 532 17 56-89 Trunnion, Front, Susp
80 532 12 66-84 Washer 1/4 x 5/8 x .062\
82 532 16 94-84 Retainer Clip
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
41
www.mymowerparts.com
Page 15
For Husqvarna Parts Call 606-678-9623 or 606-561-4983
REPAIR PARTS
TRACTOR - - MODEL NO. GTH2350 (GTHK2350A), PRODUCT NO. 954 56 85-40
MOWER DECK
55
45
44
27
46
39
43
48
48
48
53
52
38
45
50
45
44
56
45
51
59
58
64
60
57
60
30
31
27
28
27
45
30
32
33
114
47
94
95
97
2
25
98
24
2
2
19
2
20
29
2
3
3
29
97
96
94
22
21
19
63
49
31
40
6
6
67
1
45
61
2
36
4
3
45
27
32
33
36
1111
65
66
35
62
45
37
34
5
6
54
6
7
15
14
16
10
9
8
99
42
18
17
13
11
23
42
www.mymowerparts.com
Page 16
For Husqvarna Parts Call 606-678-9623 or 606-561-4983
REPAIR PARTS
TRACTOR - - MODEL NO. GTH2350 (GTHK2350A), PRODUCT NO. 954 56 85-40
MOWER DECK
KEY PART
NO. NO. DESCRIPTION
1 532 18 30-56 Deck Asm., Mower 50"
2 873 68 05-00 Nut, Crownlock 5/16-18
3 872 11 05-06 Bolt RdHd Sqnk 5/16-18 Unc x 3/4
4 532 12 50-74 Runner LH
5 532 13 84-57 Bracket Asm., Sway Bar
6 532 12 46-70 Retainer, Spring
7 532 17 80-24 Bar Sway Deck
8 532 85 08-57 Bolt 3/8-24 x 1.25 Gr. 8 Patched
9 810 03 06-00 Washer, Lock Hvy 3/8 Unplated
10 532 14 02-96 Washer, Hard Blade Mower Vented
11 532 13 73-80 Blade (3 Required)
13 532 13 75-53 Shaft Asm., W/Lower Brg
14 532 13 71-52 Housing, Mandrel 50" Vent
15 532 11 04-85 Bearing, Ball Mandrel
16 532 17 44-93 Stripper, Mower Vented
17 532 10 67-35 Rod, Hinge
18 819 11 10-16 Washer 11/32 x 5/8 x 16 Ga.
19 532 10 53-04 Cap Sleeve
20 532 12 37-13 Spring, Torison Delector
21 532 13 76-07 Bracket, Deflector
22 532 11 04-52 Nut, Push
23 532 11 05-09 Shield, Deflector Mower
24 532 13 63-20 Runner RH
25 819 11 12-16 Washer 11/32 x 3/4 x 16 Ga.
26 872 11 06-06 Bolt RdHd Sht Sqnk
27 819 13 13-16 Washer 13/32 x 13/16 x 16 Ga.
28 532 13 28-23 Spacer, Spring Stop Idler
29 873 80 05-00 Nut, Lock 5/16-18
30 532 17 39-84 Screw Thd Rolling
31 532 17 83-42 Nut, Flg Top Lock Cntr 9/16
32 532 17 34-36 Pulley, Mandrel, Plated
33 532 12 99-63 Washer, Spacer Mower Vented
34 872 14 06-10 Bolt, Carriage 3/8-16 x 1-1/4
35 872 11 06-16 Bolt, Carriage 3/8-16 x 2
36 872 11 06-08 Bolt, Carriage 3/8-16 x 1 Gr. 5
37 532 13 71-66 Stiffener, Arm Idler
38 532 17 39-68 Keeper, Belt Idler
39 532 17 34-38 Pulley, Idler Flat
40 532 17 43-75 Pulley, Driven
KEY PART
NO. NO. DESCRIPTION
42 872 14 05-06 Bolt, Carriage 5/16-18 Unc x 3/4
43 532 13 64-60 Arm, Idler Secondary
44 532 12 20-52 Spacer, Retainer
45 873 68 06-00 Nut, Crownlock 3/8-16 Unc
46 874 76 06-28 Bolt, Fin Hex 3/8-16 Unc x 1-3/4
47 532 13 72-00 Cover, Mandrel RH
48 532 13 77-29 Screw, Thd Roll 1/4-20 x 5/8
49 532 13 65-74 Cover, Mandrel LH
50 532 13 72-72 Arm, Idler Primary
51 532 13 72-73 Spring, Secondary
52 532 18 17-75 Pulley, Idler V Groove
53 532 18 08-07 Shield, Idler
54 532 14 87-63 V-Belt, Mower Primary
55 532 14 49-59 V-Belt, Mower Secondary
56 532 13 86-87 Spring, Primary
57 532 13 65-77 Bar Asm. Wheel Gauge Mower
58 532 13 39-57 Wheel, Gauge
59 532 13 76-44 Bolt, Shoulder
60 532 13 90-31 Pin Clevis
61 532 13 65-73 Bracket Gauge Wheel
62 532 13 39-43 Washer Hardened
63 872 11 06-12 Bolt Carriage 3/8-16 x 1-1/2
64 819 12 14-14 Washer 3/8 x 7/8 x 14 Ga.
65 532 17 39-81 Pulley Idler Flat Mower
66 532 17 39-79 Keeper, Belt Idler Plated
67 873 93 06-00 Nut, Center Lock 3/8-16
94 874 76 05-16 Bolt H 5/16-18 x 1
95 532 17 57-46 Bracket, Asm. Noseroller LH
96 532 17 57-47 Bracket, Asm. Noseroller RH
97 819 17 14-16 Washer 17/32 x 7/8 x 16 Ga.
98 532 13 22-64 Roller, Nose
99 872 11 06-14 Bolt, Carriage 3/8-16 x 1-3/4 Gr. 5
114 532 15 31-83 Reinforcement Mandrel Ring
- - 532 14 36-51 Mandrel Asm (Includes Housing,
Shaft, and Shaft Hardware Only Pulley Not Included)
- - 532 18 12-31 Replacement Mower, Complete
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
43
www.mymowerparts.com
Loading...
