Husqvarna 4210-G, 4210-GXP, 4210-E, 4210-EXP User Manual
+89*+89(
+89*;3
$1'
+89(;3
8WLOLW\9HKLFOHV
2ZQHUV0DQXDO
NOTICE
The Husqvarna Limited Warranty appears on the last pages of this manual. No other warranties, express or
implied, are contained herein. Please complete and return the warranty registration card included in this manual.
Husqvarna is not liable for errors in this manual or for incidental or consequential damages that result from the
use of the material in this manual.
This manual contains proprietary information that is protected by copyright. All rights are reserved. No part of
this manual may be photocopied, reproduced, or translated to another language without the written consent
of Husqvarna.
The information contained in this document is subject to change without notice.
Husqvarna reserves the right to change specifications and designs at any time without notice and without the
obligation of making changes to units previously sold.
These vehicles do not conform to Federal Motor Vehicle Safety Standards for automobiles or to FMVSS 500
for low-speed vehicles, and are not equipped for operation on public streets, roads, or highways.
Husqvarna Forest and Garden
7349 Statesville Rd.
Charlotte, NC 28269
USA
www.usa.husqvarna.com/huv
2005 Husqvarna 4210-G, 4210-E, 4210-GXP, and 4210-EXP Owner’s Manual Page 1
FOREWORD
Thank you for choosing Husqvarna, a world leader in outdoor products. You have chosen the finest utility
vehicle on the market. Please protect your investment and ensure that your Husqvarna vehicle provides years
of reliable, superior performance by reading and following the maintenance instructions in this manual.
Your comfort and safety are important to us, so we urge you to read and follow the step-by-step operating
instructions and safety precautions in this manual. These instructions must be followed in order to avoid the
risk of severe personal injury. If you rent or loan your vehicle to others, we recommend that you ask them to
read this manual before they operate the vehicle.
Husqvarna products are backed by a customer support system designed to offer you fast, courteous service.
In the event that your Husqvarna vehicle needs repairs or service, we recommend that your local authorized
Husqvarna representative perform them. For the name and address of the Husqvarna representative nearest
you, logon to our web site at www.usa.husqvarna.com. If you would prefer to write to us, direct your letter to:
Husqvarna, Attention: Marketing Services, 7349 Statesville Rd., Charlotte, NC 28269 USA. Your local authorized Husqvarna representative can also provide technical advice, parts, and service manuals.
We hope you will consider this owner’s manual a permanent part of your Husqvarna vehicle. If you sell the
vehicle, please include the manual so that the next owner will have the important operating, safety, and maintenance information it contains. Translated owner’s manuals can be downloaded from the Husqvarna web
site at www.usa.husqvarna.com/huv.
Below is a quick reference table of items that will help you maintain this vehicle. These parts can be purchased from your authorized Husqvarna dealer.
REGULAR MAINTENANCE ITEMS PERIODIC MAINTENANCE ITEMS
Engine Oil Filter (286 cc and 351 cc)
603 00 00-06
Engine Air Filter (286 cc and 351 cc)
603 00 00-04
Engine Fuel Filter (286 cc and 351cc)
603 00 00-08
Battery Terminal Protector Spray
603 00 00-03
Dry Moly Lube
603 00 00-01
Battery (gasoline vehicle)
603 00 00-02
Spark Plug O.H.V. (286 cc and 351 cc)
603 00 00-07
Spring Tune-Up Kit
603 00 00-05
Battery (electric vehicle)
603 00 20-23
Page 2 2005 Husqvarna 4210-G, 4210-E, 4210-GXP, and 4210-EXP Owner’s Manual
TABLE OF CONTENTS
Vehicle Feature Identification – HUV4210-E Electric Vehicle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Vehicle Feature Identification – HUV4210-G Gasoline Vehicle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Safety Details . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
General Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Model Identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Controls and Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Pre-Operation and Daily Safety Checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Driving Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Transporting on a Trailer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Storage – Electric Vehicles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Storage – Gasoline Vehicles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Periodic Service Schedules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Periodic Lubrication Schedules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Vehicle Controller – Electric Vehicles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Batteries – Electric Vehicles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Battery Charger – Electric Vehicles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Battery – Gasoline Vehicles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Engine Oil – Gasoline Vehicles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Fueling Instructions – Gasoline Vehicles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Cleaning the Vehicle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Subsequent Owner Registration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Vehicle Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Warranties . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
2005 Husqvarna 4210-G, 4210-E, 4210-GXP, and 4210-EXP Owner’s Manual Page 3
HUV4210-E ELECTRIC VEHICLE
BATTERY DANGER DECAL
(ON BATTERY CAPS OR ON BODY UNDER SEAT)
TOW SWITCH WARNING DECAL
(ON TOW SWITCH BRACKET UNDER SEAT)
Vehicle Feature Identification
ELECTRICAL COMPONENT DECAL
(ON SPEED CONTROLLER COVER)
SERVICE NOTICE DECAL
(ON BODY UNDER BED)
CHARGER
RECEPTACLE
FORWARD/REVERSE SWITCH
Page 4 2005 Husqvarna 4210-G, 4210-E, 4210-GXP, and 4210-EXP Owner’s Manual
Vehicle Feature Identification
HUV4210-E ELECTRIC VEHICLE
!
WARNING
ROLLOVER OR FALLING OFF MAY CAUSE SERIOUS INJURY OR DEATH
• Before using vehicle, read operating instructions.
• Do not start vehicle until all occupants are seated.
• Operate from driver side only and not on public roads.
• Drive slowly in turns and straight up and down slopes.
• Never operate under the influence of alcohol or drugs.
• Use brakes to reduce speed when coasting downhill.
ONOFF
• Remain seated while moving.
• Hold on to seat handle while moving.
• Two (2) persons per seat maximum.
• Never stand in front of or behind vehicle.
• Do not leave children unattended on vehicle.
• Keep entire body inside vehicle while moving.
OPERATING INSTRUCTIONS
PARK BRAKE PEDAL
BATTERY
CONDITION
INDICATOR
BRAKE PEDAL
LIGHT
SWITCH
SWITCH
ACCELERATOR
PEDAL
KEY
102825501
DRIVER AND PASSENGER WARNING DECAL
BATTERY
WARNING
LIGHT
SERIAL
NUMBER
(UNDER PASSENGER
SEAT ON FRAME)
CRUSH AREA AND BED LATCH DECAL (DRIVER SIDE)
!
WARNING
CRUSH AREA
Can cause severe injury.
Stay clear when closing bed.
PULL LATCH AND
OPEN BED
102831901
CRUSH AREA AND BED LATCH DECAL (PASSENGER SIDE)
!
WARNING
PULL LATCH AND
OPEN BED
CRUSH AREA
Can cause severe injury.
Stay clear when closing bed.
102832001
2005 Husqvarna 4210-G, 4210-E, 4210-GXP, and 4210-EXP Owner’s Manual Page 5
HUV4210-G GASOLINE VEHICLE
OPERATING INSTRUCTIONS
• Read owner’s manual and dash-mounted safety warnings prior to driving.
• Study and understand controls.
TO START ENGINE
• Pla ce shi ft lev er in “N ” – Neut ral po siti on.
• Press brake pedal.
• Turn key switch to “START position and release.
TO OPERATE VEHICLE
• Turn wheels to desired direction and ensure path is clear.
• Engine must be at idle before moving shift lever.
• While vehicle is stopped, and engine is at idle,
place Forward/Reverse switch in desired position:
F – Forward N – Neutral R – Reverse (Buzzer will sound)
• Park brake will release and vehicle will start moving when
accelerator pedal is pressed.
• Slowly press accelerator pedal to increase speed.
• To stop, release accelerator pedal and push brake pedal.
BEFORE LEAVING
• Press park brake pedal until it locks and holds vehicle.
• Place Forward/Reverse switch in NEUTRAL position.
• Turn key to “OFF” position and remove key when not in use.
Vehicle Feature Identification
!
WARNING
ROLLOVER OR FALLING OFF MAY CAUSE SERIOUS INJURY OR DEATH
• Before using vehicle, read operating instructions.
• Do not start vehicle until all occupants are seated.
• Operate from driver side only and not on public roads.
• Drive slowly in turns and straight up and down slopes.
• Never operate under the influence of alcohol or drugs.
• Use brakes to reduce speed when coasting downhill.
ONOFF
START
• Remain seated while moving.
• Hold on to seat handle while moving.
• Two (2) persons per seat maximum.
• Never stand in front of or behind vehicle.
• Do not leave children unattended on vehicle.
• Keep entire body inside vehicle while moving.
OPERATING INSTRUCTIONS
FUEL GAUGE
PARK BRAKE PEDAL
CRUSH AREA AND BED LATCH DECAL (DRIVER SIDE)
102825601
LIGHT
SWITCH
BRAKE PEDAL
!
CRUSH AREA
Can cause severe injury.
Stay clear when closing bed.
KEY
SWITCH
ACCELERATOR
PEDAL
WARNING
PULL LATCH AND
OPEN BED
102831901
102825401
DRIVER AND PASSENGER WARNING DECAL
SERIAL
NUMBER
LOW OIL
WARNING
(UNDER PASSENGER
SEAT ON FRAME)
LIGHT
SERVICE NOTICE DECAL
(ON BODY UNDER BED)
CRUSH AREA AND BED LATCH DECAL (PASSENGER SIDE)
!
WARNING
PULL LATCH AND
OPEN BED
CRUSH AREA
Can cause severe injury.
Stay clear when closing bed.
102832001
Page 6 2005 Husqvarna 4210-G, 4210-E, 4210-GXP, and 4210-EXP Owner’s Manual
Vehicle Feature Identification
HUV4210-G GASOLINE VEHICLE
GASOLINE WARNING DECAL
(ON VEHICLE FRAME NEAR FUEL TANK)
OIL FILL
FUEL SHUT-OFF
FNR
FORWARD/REVERSE
HANDLE
DIODE WIRING DECAL
VALVE
ROTATING PARTS AND
HOT MANIFOLD DECAL
(ON STARTER/GENERATOR)
CHOKE
FRAME GROUND AND
GOVERNOR WARNING DECAL
(ON VEHICLE FRAME NEAR BATTERY)
2005 Husqvarna 4210-G, 4210-E, 4210-GXP, and 4210-EXP Owner’s Manual Page 7
Practice Safety
!
WARNING
Rotating Parts
Safety signs like you see above may at first seem shocking, but their impact is mild
compared with the reality of severe personal injury.
Your safety and satisfaction are of the utmost importance to Husqvarna. That is why
before operating the vehicle, we urge you to review the information in this manual.
Understand and become familiar with the DANGER, WARNING and CAUTION statements and procedures it contains, along with the safety decals that are affixed to your
vehicle.
Take time to understand the language of safety. It is a language that can save your life.
PROPOSITION 65 – STATE OF CALIFORNIA
ý WARNING
This product contains or emits chemicals or substances that have been determined by the state of
California to cause cancer and birth defects or other reproductive harm.
Page 8 2005 Husqvarna 4210-G, 4210-E, 4210-GXP, and 4210-EXP Owner’s Manual
Safety Details
SAFETY DETAILS
ý WARNING
• This owner’s manual should be read completely before attempting to drive or service the
vehicle. Failure to follow the instructions in this manual could result in property damage,
severe personal injury, or death.
It is important to note that some vital statements throughout this manual and on the decals affixed to the vehicle are preceded by the words DANGER, WARNING, or CAUTION. For your protection, we recommend that
you take special notice of these safety precautions. Safety precautions are essential and must be followed.
If any of the operation or warning decals on the vehicle become damaged, have been removed or cannot be
easily read, they should be replaced immediately to avoid possible property damage, personal injury, or
death. Contact your Husqvarna dealer.
ý DAN G ER
• A DANGER indicates an immediate hazard that will result in severe personal injury or death.
ý WARNING
• A WARNING indicates an immediate hazard that could result in severe personal injury or
death.
ý CAUTION
• A CAUTION with the safety alert symbol indicates a hazard or unsafe practice that could
result in minor personal injury.
CAUTION
• A CAUTION without the safety alert symbol indicates a potentially hazardous situation that
could result in property damage.
GENERAL WARNINGS
The following safety statements must be heeded whenever the vehicle is being operated, repaired, or serviced. Vehicle feature identification information is also included on pages 4 through 7. Other specific safety
statements appear throughout this manual and on the vehicle.
ý DAN G ER
• Battery – Explosive gases! Do not smoke. Keep sparks and flames away from the vehicle and
service area. Ventilate when charging or operating vehicle in an enclosed area. Wear a full
face shield and rubber gloves when working on or near batteries.
• Gasoline – Flammable! Explosive! Do not smoke. Keep sparks and flames away from the
vehicle and service area. Service only in a well-ventilated area.
DANGER CONTINUED ON NEXT PAGE...
2005 Husqvarna 4210-G, 4210-E, 4210-GXP, and 4210-EXP Owner’s Manual Page 9
General Warnings
ý DAN G ER
• Do not operate gasoline vehicle in an enclosed area without proper ventilation. The engine
produces carbon monoxide, which is an odorless, deadly poison.
• A Husqvarna vehicle will not provide protection from lightning, flying objects, or other stormrelated hazards. If caught in a storm while driving a Husqvarna vehicle, exit the vehicle and
seek shelter in accordance with applicable safety guidelines for your location.
ý WARNING
• Follow the procedures exactly as stated in this manual, and heed all DANGER, WARNING, and
CAUTION statements in this manual as well as those on the vehicle and battery charger.
• Do not leave children unattended on vehicle.
• Prior to leaving the vehicle unattended or servicing the vehicle, set the park brake, place the
Forward/Reverse handle or switch in the NEUTRAL position, turn the key switch to the OFF
position, and remove the key. Chock the wheels when servicing the vehicle.
• Improper use of the vehicle or failure to properly maintain it could result in decreased vehicle
performance, severe personal injury, or death.
• Any modification or change to the vehicle that affects the stability or handling of the vehicle,
or increases maximum vehicle speed beyond factory specifications, could result in severe
personal injury or death.
• Do not operate the vehicle without an installed front bumper or brush guard that is
specifically designed and approved for use on this vehicle. Instability in the vehicle could
cause serious injury or death (Figure 3 and Figure 4).
• Check the vehicle for proper location of all vehicle safety and operation decals and make sure
they are in place and are easy to read.
• For vehicles with cargo beds, remove all cargo before raising the bed or servicing the vehicle.
If the vehicle is equipped with a prop rod, ensure that it is securely engaged while bed is
raised. Do not close bed until all persons are clear of cargo bed area. Keep hands clear of all
crush areas. Do not drop cargo bed; lower gently and keep entire body clear. Failure to heed
this warning could result in severe personal injury or death.
• Only trained technicians should service or repair the vehicle or battery charger. Anyone doing
even simple repairs or service should have knowledge and experience in electrical and
mechanical repair. The appropriate instructions must be used when performing maintenance,
service, or accessory installation.
Gasoline vehicles:
• To avoid unintentionally starting the vehicle:
- Disconnect battery cables, negative (–) cable first (Figure 1).
- Disconnect the spark plug wire from the spark plug.
• Frame ground – Do not allow tools or other metal objects to contact frame when
disconnecting battery cables or other electrical wiring. Do not allow a positive wire to touch
the vehicle frame, engine, or any other metal component.
Electric vehicles:
• Place Tow/Run switch in the TOW position before disconnecting or connecting the batteries.
Failure to heed this warning could result in a battery explosion or severe personal injury.
• To avoid unintentionally starting the vehicle, disconnect the batteries as shown (Figure 2,
Page 11).
• After disconnecting the batteries, wait 90 seconds for the controller capacitors to discharge.
WARNING CONTINUED ON NEXT PAGE...
Page 10 2005 Husqvarna 4210-G, 4210-E, 4210-GXP, and 4210-EXP Owner’s Manual
General Information
ý WARNING
• Use insulated tools when working near batteries or electrical connections. Use extreme
caution to avoid shorting of components or wiring.
All vehicles:
• Wear safety glasses or approved eye protection when servicing the vehicle or battery charger.
Wear a full face shield and rubber gloves when working on or near batteries.
• Do not wear loose clothing or jewelry such as rings, watches, chains, etc., when servicing the
vehicle or battery charger.
DISCONNECT BATTERY CABLES
BEFORE WORKING ON VEHICLE
AS SEEN FROM
PASSENGER SIDE
OF VEHICLE
FRONT
OF VEHICLE
Remove
negative
cable first.
G
NIN
R
A
W
switch in TOW
Place Tow / Run
N
U
R
W
TO
Place TOW/RUN switch in the TOW
position before disconnecting or
connecting battery cables.
NEG
P
O
FRONT OF
S
VEHICLE
Remove negative (–)
cable first.
4
S
O
NEG
S
O
P
NEG
3
P
NEG
1
P
O
S
2
Figure 1 Gasoline Vehicle Figure 2 Electric Vehicle
GENERAL INFORMATION
This manual features two mode ls: the electric vehicle and the ga soline vehicle. Throughout this manual,
important features unique to each model are highlighted. We urge the owner/operator to read and understand
this manual, and to pay special attention to the features specific to his/her vehicle(s).
FRONT BUMPER AND BRUSH GUARD
The front bumper and brush guard are an important part of the vehicle’s design for correct weight distribution.
These parts are interchangeable , but one o r the oth er must be installe d at all ti mes d uring ve hicle operatio n
to achieve proper balance (Figure 3 and Figure 4). See following WARNING.
ý WARNING
• Do not operate the vehicle without an installed front bumper or brush guard that is
specifically designed and approved for use on this vehicle. Instability in the vehicle could
cause serious injury or death.
2005 Husqvarna 4210-G, 4210-E, 4210-GXP, and 4210-EXP Owner’s Manual Page 11
Model Identification
SERIAL NUMBER
HH0501-583947
7349 STATESVILLE RD.
CHARLOTTE, NC 28269
Figure 3 Bumper Figure 4 Brush Guard
MODEL IDENTIFICATION
The serial number of the vehicles are printed on two bar code decals. (Example: HH0501-583947) (Figure 5).
One is mounted on the frame, under the bed, on the passenger side. There is also a second serial number
decal mounted on the front frame behind the dash. The dash must be removed to view this decal. See fol-
lowing NOTE.
NOTE: Have the vehicle serial number available when ordering parts or making inquiries.
Figure 5 Gas Vehicle Serial Number
Page 12 2005 Husqvarna 4210-G, 4210-E, 4210-GXP, and 4210-EXP Owner’s Manual
Controls and Indicators
CONTROLS AND INDICATORS
See General Warnings on page 9.
ý WARNING
• If renting or loaning the vehicle, make sure the driver is familiar with all controls and
operating procedures before allowing the vehicle to be driven.
• Do not shift the Forward/Reverse handle or switch while the vehicle is moving. To avoid injury
to an unsuspecting passenger or damage to the vehicle, always bring the vehicle to a full stop
before shifting the Forward/Reverse handle or switch.
• Release the accelerator pedal and then press the brake pedal firmly until the vehicle stops. To
avoid unintentionally starting or rolling the vehicle, set the park brake, place the Forward/
Reverse handle or switch in the NEUTRAL position, turn the key switch to the OFF position,
and remove the key when leaving the vehicle.
• Gasoline vehices only: Do not tamper with the governor. Doing so will void the warranty, as
well as damage the engine and other components, and could result in property damage,
personal injury, or death due to unsafe speeds.
KEY SWITCH
Gasoline Vehicles
The key switch is mounted on the dash to the right of the steering column (Figure 6). It has three positions,
OFF, ON and START. To start the vehicle, place the Forward/Reverse handle in the NEUTRAL position and
turn the key past the ON position to the START position and hold until the engine is running smoothly. When
the engine is cold it may be necessary to use the choke. See Choke on page 18. Release the key and it will
return to the ON position and the engine should idle. The engine will continue to idle until the key is turned to
the OFF position. See following WARNING, CAUTION and NOTE.
ý WARNING
• Moving parts! Keep clear of the engine compartment while the engine is running.
CAUTION
• Do not “rev” the engine for long periods of time while the Forward/Reverse handle is in the
NEUTRAL position. Failure to heed this caution could result in damage to the unitized
transaxle.
• Do not shift the Forward/Reverse handle while the accelerator pedal is pressed. Shift the
handle only when the vehicle is at a complete stop. Failure to heed this caution could result in
damage to the unitized transaxle.
2005 Husqvarna 4210-G, 4210-E, 4210-GXP, and 4210-EXP Owner’s Manual Page 13
NOTE: The key can be removed only when the key switch is in the OFF position.
GAS VEHICLE SHOWN
Figure 6 Key Switch
Controls and Indicators
Electric Vehicles
The key switch is mounted on the dash to the right of the steering column. It has two positions, OFF and ON,
which are clearly labeled. See following NOTE.
NOTE: The key can be removed only when the key switch is in the OFF position.
FORWARD/REVERSE CONTROL
Gasoline Vehicles
The Forward/Reverse handle is located on the seat support panel (Figure 7). The handle has three distinct
positions: F (FORWARD), N (NEUTRAL), and R (REVERSE). Rotate the handle towards the driver (FOR-
WARD) to operate the vehicle in the forward direction, or towards the passenger (REVERSE) to operate the
vehicle in reverse. Husqvarna vehicles operate at reduced speed in REVERSE. The engine can be started
only when the handle is in the straight up position (NEUTRAL). The engine must be at idle before shifting the
Forward/Reverse handle. See WARNING and CAUTION on page 13.
Electric Vehicles
The Forward/Reverse rocker switch is located on the seat support panel (Figure 8). The F (FORWARD) and
R (REVERSE) positions are clearly marked. Push down the FORWARD side of the switch to operate the vehi-
cle in the forward direction, or push down the REVERSE side of the switch to operate the vehicle in reverse.
When the rocker switch is positioned in the NEUTRAL position, with neither side down, the vehicle will not
operate if the accelerator pedal is pressed . The reverse buzzer will sound as a warning when the Forward/
Reverse switch is in the REVERSE position. Husqvarna vehicles operate at reduced speed in REVERSE.
Page 14 2005 Husqvarna 4210-G, 4210-E, 4210-GXP, and 4210-EXP Owner’s Manual
Controls and Indicators
F
R
Figure 7 Forward/Reverse Handle – Gas Vehicle Figure 8 Forward/Reverse Rocker Switch – Electric
Vehicle
Figure 9 Accelerator and Brake Pedals
ACCELERATOR PEDAL
The accelerator pedal is the pedal on the right, with the word GO molded into it (Figure 9).
Electric Vehicles
The operation of the accelerator pedal differs from that of an automobile. When the key switch is in the ON
position, and the Forward/Reverse switch is in either the FORWARD or REVERSE position, pressing the
accelerator pedal will automatically release the park brake and start the vehicle moving in the direction
selected (forward or reverse). As the accelerator pedal is pressed, speed will increase until full speed is
reached. When the accelerator is released, power will be cut off and the motor will stop running.
Electric vehicles use a special system, which employs motor braking in some modes of operation. In those
modes, the vehicle operates as follows:
Gasoline Vehicles
After starting the engine with the key switch and placing the Forward/Reverse handle in the FORWARD position, the vehicle should accelerate smoothly to full speed as the accelerator pedal is pressed. When the pedal
is released it should return to the original position and the engine should idle.
2005 Husqvarna 4210-G, 4210-E, 4210-GXP, and 4210-EXP Owner’s Manual Page 15
Loading...
