Page 1
OPL
120 - 170 lb NovaStar
TM
Tumble Dryers
Huebsch is the answer.
Page 2
Big Performance Additional Features
Why are 120 and 170 lb Huebsch NovaStarTMcommercial
tumble dryers a good fit for my laundry
?
Extra capacity.
When on-premises laundries are faced with huge
loads and no time to waste waiting for a dryer,
managers turn to Huebsch NovaStar
TM
tumble
dryers for their extra-large cylinders and superior
capacity. NovaStar
TM
models keep productivity in
your laundry high.
Highly efficient.
Huebsch large capacity tumble dryers give you
not only extra capacity, but also superior efficiency
with a high performance heater box. Sealed cylinder
rims and a concentrated airflow pattern ensure no
heat is wasted, helping to keep utility costs down and
the laundry yielding maximum throughput volumes.
Beyond efficiency, what NovaStarTMfeatures help improve
my operation overall
?
Large door openings.
Huebsch is the answer for
fast loading and unloading
with 26.89" door openings.
When your staff is able to
load and unload quickly,
your laundry is able to
keep loads moving. In
addition, the steel con-
struction of our door and heavy-duty hinge ensure
both can handle whatever the staff dishes out.
Huebsch is the answer.
Anybody can sell you laundry equipment and discuss the merits of each nut and bolt. However,
at Huebsch, our priority is answering your questions about how working with us will make your
business easier to run and more profitable.
Customers have selected Huebsch products for their ease of use, supreme durability and because
owning a Huebsch product brings a service and support network that’s unmatched within the industry.
For profitability, reliability and ease of use, Huebsch is the answer.
Page 3
Easy to clean.
A self-cleaning lint screen means fast, efficient lint
removal from the tumble dryer’s large storage area.
The result is consistent fast, efficient drying.
Tangle tamer.
NovaStar
TM
tumble dryers put an end to tangles
by making reversing cylinders standard features.
That means no more wasted time for staff spent
untangling large pieces such as sheets or
table linens.
Excellent Options
What other options make NovaStarTMmodels the right
choice for my operation?
An extra line of defense.
Huebsch offers its Combustion
Auto Response Equipped
(CARE) system as an option
on NovaStar
TM
tumble dryers.
CARE monitors for excessive
cylinder temperatures and sprays water on the
load should it register an abnormally high reading.
A “system active” signal also can be sent to a
property’s alarm system or another device.
A Great Finish
How will these tumble dryers help my laundry deliver
fantastic finished results?
Staying in control.
NovaStar
TM
models can
be equipped with
either Huebsch’s
extremely user-friendly
Micro-Display control
or Dual Digital control.
The Micro-Display
control features four
preset drying cycles and
offers the ability to further customize four additional
programs. This programmability enables you to get
the results you desire every load with no wasteful
overdrying. With the Dual Digital control, operators can
set drying time (0-60 minutes), cool down time (0-15
minutes) and temperature (high, medium, low, no
heat). Additional user-friendly features include a one-
touch cycle repeat, automatic anti-wrinkle extended
tumble and time remaining display.
Unmatched Durability
Commercial laundry equipment is no small expense;
I want peace of mind my equipment will last well into
the future. What sets Huebsch apart from other brands
in terms of reliability?
Quality components.
The NovaStar’s
TM
drive system is built using cast
iron pulleys and permanently sealed bearings. An
all-belt drive system increases reliability. The bottom
line is reliable performance with minimal maintenance.
Not just standing behind our equipment, but
standing beside you and your business.
Our
Made-In-America product
comes with an industry-leading
bond. The entire machine receives
Huebsch’s standard three-year warranty.
In addition, Huebsch has more service representatives
in the field than most brands have in their whole
organization. Huebsch support is further bolstered by
an online component and a help line that
takes 100,000 calls per year.
*Parts only, labor not included. See Huebsch Warranty
Bond for specifics.
L
i
m
i
t
e
d
W
a
r
r
a
n
t
y
*
Y
e
a
r
Micro-Display Control
Dual Digital Control
Page 4
Alliance Laundry Systems, Shepard Street, Ripon, WI 54971 Telephone: 1-800-553-5120
www.huebsch.com
AH11-0134
120 and 170 lb Tumble Dryer Specifications
Models HT120 HT170
Control Options
Micro-Display (OM), Dual Digital (QT) Micro-Display
(OM),
Dual Digital
(QT)
Dry Weight Capacity - lb (kg) 120 (54.4) 170 (77.1)
Width - in (mm) 46 3/8" (1178) 53 1/8" (1349)
Depth - in (mm) 67 15/16" (1725) 68 7/8" (1749)
Height - in (mm) 85 3/4" (2177) 94" (2388)
Cylinder Depth - in (mm) 41" (1041) 42 1/2" (1080)
Cylinder Diameter - in (mm) 44" (1118) 50 3/4" (1289)
Cylinder Volume - cu. ft. (liters) 36.1 (1021) 49.7 (1408)
Door Opening Size - in (mm) 26 7/8" (683) 26 7/8" (683)
Air Outlet Diameter - in (mm) 10" (254) 12" (305)
Airflow - cfm (liters/sec.) 1600 (755) 2450 (1156)
Energy Data Gas Models: Gas Models:
270,000 Btu/hr (79.1 kW) 395,000 Btu/hr (115.7 kW)
Steam Models: Steam Models:
At 100 psi (6.9 bar): 11.7 BHP, At 100 psi (6.9 bar): 18.8 BHP,
405,000 Btu/hr (118.5 kW) 648,000 Btu/hr (189.7 kW)
Electrical Specifications Rev Amps Rev Amps
200-208/240/60/3 7.7 13.5
440/60/3 (Steam only) 3.8 6.4
460-480/60/3 3.9 6.7
380/400-415/50/3 3.8 6.9
Plumbing Connections - in Gas: 3/4" NPT Gas: 1" NPT
Steam: 3/4" NPT inlet/outlet
Steam: 3/4" NPT inlet/1" NPT outlet
Shipping Dimensions Width 48 1/2" (1232) 58" (1473)
Approx. - in (mm) Depth 72" (1829) 74 1/2" (1892)
Height 90" (2286) 99" (2515)
Net Weight - lb (kg) Gas: 1275 (578) Gas: 1575 (714)
Steam: 1375 (624) Steam: 1675 (760)
Shipping Weight - lb (kg) Gas: 1338 (607) Gas: 1667 (756)
Steam: 1446 (656) Steam: 1776 (806)
Agency Approvals
c
CSAus, CE, CSA Star, CSA FlamecCSAus, CE, CSA Star, CSA Flame
Tumble dryer models are made to suit a variety of electrical service characteristics. See your
Huebsch distributor for specifications. For further details on installation, refer to Installation,
Operation and Maintenance instructions supplied with the tumble dryerr. USA and Canada models
are certified by C.S.A International.
For the most accurate information, the installation guide should be used for all design and
construction purposes. Due to continuous product improvements, design and specifications
subject to change without notice. The quality management system of Alliance Laundry Systems’
Ripon facility has been registered to ISO 9001:2000.
Printed in the U.S.A.
©Copyright 2011 Alliance Laundry Systems LLC
