Huebsch is the answer.
OPL
50 - 75 lb LoadStar
and 55 lb DryStar
Tumble Dryers
TM
TM
Page 2
Huebsch is the answer.
L
i
m
i
t
e
d
W
a
r
r
a
n
t
y
*
Y
e
a
r
Anybody can sell you laundry equipment and discuss the merits of each nut and bolt. However,
at Huebsch, our priority is answering your questions about how working with us will make your
business easier to run and more profitable.
Customers have selected Huebsch products for their ease of use, supreme durability and because
owning a Huebsch product brings a service and support network that’s unmatched within the industry.
For profitability, reliability and ease of use, Huebsch is the answer.
Big Performance Additional Features
Why are 50 and 75 lb Huebsch LoadStarTMcommercial
tumble dryers a good fit for my laundry
Extra capacity.
TM
Huebsch LoadStar
offer the sizable capacity to effectively meet the
needs of most medium and large scale laundries.
Highly efficient.
Huebsch large capacity tumble dryers give you
not only extra capacity, but also superior efficiency
with a high performance heater box. Sealed
cylinder rims and a concentrated airflow pattern
help to keep utility costs down and the laundry
yielding maximum throughput volumes.
50 and 75 lb tumble dryers
?
Beyond efficiency, what LoadStarTMfeatures help improve
my operation overall
Large door openings.
Huebsch is the answer for fast loading and
unloading with 26
you’re able to load and unload quickly, your
laundry is able to keep loads moving.
Easy to clean.
A self-cleaning lint
screen means fast,
efficient lint removal
from the tumble
dryer’s large
storage area.
?
7
/8" door openings. When
Page 3
Excellent Options
L
i
m
i
t
e
d
W
a
r
r
a
n
t
y
*
Y
e
a
r
Better Results, Small Package
What other options make LoadStarTMmodels the
right choice?
An extra line of defense.
Huebsch offers its Combustion
Auto Response Equipped (C.A.R.E.)
system as an option on LoadStar
and DryStarTMtumble dryers.
C.A.R.E. monitors for excessive
cylinder temperatures and sprays water on the load
should it register an abnormally high reading.
A “system active” signal also can be sent to a
property’s alarm system or another device.
Tangle tamer.
A reversing option (offered on 3 phase models) is
particularly useful for laundries washing sheets or
large table linens. The reversing cylinder helps elimi-
nate tangling of such items, saving employees
valuable time.
TM
How can my laundry add drying capacity without taking
up more precious floor space?
New 55 lb DryStarTMfeatures increased capacity.
While Huebsch’s newest tumble dryer offers five
more pounds of capacity than a 50 lb tumble dryer
it’s 4" narrower, enabling it to fit easily through a
standard 36" door opening. It’s also more than
a foot shorter.
A perfect blend of speed and efficiency.
Laundries benefit from the
tumble dryer’s axial airflow
process, which helps it out-
perform many competing
50 lb radial airflow tumble
dryers in both speed
and efficiency.
A Great Finish
How will these tumble dryers help my laundry deliver
fantastic finished results?
Staying in control.
TM
TM
models
and
Micro-Display control or Dual
LoadStar
DryStar
can be equipped
with either Huebsch’s
extremely user-friendly
Digital control. The Micro-Display control features
four preset drying cycles and offers the ability to
further customize programs. This programmability
enables you to get the results you desire every load
with no wasteful overdrying. With the Dual Digital
control, operators can set drying time (0-60 minutes),
cool down time (0-15 minutes) and temperature
(high,medium, low, no heat). Additional user-friendly
features include a one-touch cycle repeat, auto-
matic anti-wrinkle extended tumble and time
remaining display.
Unmatched Durability
Commercial laundry equipment is no small expense;
I want peace of mind my equipment will last well into
the future. What sets Huebsch apart from other brands
in terms of reliability?
Not just standing behind our equipment, but
standing beside you and your business.
Our made-in-America product
comes with an industry-leading
bond. The entire machine receives
Huebsch’s standard three-year warranty.
In addition, Huebsch has more service representatives
in the field than most brands have in their whole
organization. Huebsch support is further bolstered by
an online component and a help line
that takes 100,000 calls per year.
*Parts only, labor not included. See Huebsch
Warranty Bond for specifics.
Page 4
50, 55 and 75 lb Tumble Dryer Specifications
Models HT050 HT055 HT075
Control Options
Dry Weight Capacity - lb (kg) 50 (22.7) 55 (24.9) 75 (34)
Width - in (mm) 38 5/8" (981) 34 1/2" (876) 38 5/8" (981)
Depth - in (mm) 48 1/4" (1226) 53 5/8" (1362) 54 1/4" (1378)
Height - in (mm) Gas & Electric: 76 5/8" (1946) 66 3/4" (1695) Gas & Electric: 76 5/8" (1946)
Cylinder Depth - in (mm) 30" (762) 35" (889) 36" (914)
Cylinder Diameter - in (mm) 37" (940) 33" (838) 37" (940)
Cylinder Volume - cu. ft. (liters) 18.6 (528) 17.3 (491) 22.4 (634)
Door Opening Size - in (mm) 26 7/8" (683) 26 7/8" (683) 26 7/8" (683)
Air Outlet Diameter - in (mm) 8" (203) 8" (203) 8" (203)
Airflow - cfm (liters/sec.) 750 (354) 50 Hz: 600 (283) 50 Hz: 750 (354)
Energy Data Gas Models: Gas Models: Gas Models:
Electrical Specifications
100/200-220/60/1 N/A 9.8/4.9 N/A
120/208-240/60/1 N/A 9.2/6.5 N/A
120/60/1 9.3 N/A 13.8
200-208/240/60/1 5.1/5.1 N/A 7.6/7.6
200-208/240/60/3 2.8/2.8 4.0/3.9 3.8/3.8
380/60/3 1.6 N/A 1.8
440/60/3 (Steam only) 1.4 N/A 1.9
460-480/60/3 1.4 N/A 1.9
100/200/50/1 N/A 10.0/6.2 N/A
230-240/50/1 6.3 5.5 6.7
200/50/3 3.3 N/A 3.5
230-240/50/3 3.1 N/A 3.5
380/50/3 N/A 2.0 N/A
400-415/50/3 N/A 2.0 N/A
380/400-415/50/3 1.6/1.6 N/A 1.8/1.8
Plumbing Connection - in (mm) Gas Models: 1/2" - NPT Gas Models: 1/2" - NPT Gas Models: 1/2" - NPT
Shipping Dimensions Width 41 1/2" (1054) 35 1/2" (902) 41 1/2" (1054)
Approx. - in (mm) Depth 52 1/8" (1323) 59" (1499) 56 3/8" (1433)
Net Weight - lb (kg) 545 (247) 435 (197) 615 (279)
Shipping Weight - lb (kg) 602 (273) 476 (216) 677 (307)
Agency Approvals
Micro-Display (OM), Dual Digital (QT) Micro-Display
Steam: 80" (2032) Steam: 80" (2032)
60 Hz: 700 (330) 60 Hz: 920 (434)
50 Hz: 130,000 Btu/hr (38.1 kW) 50 Hz: 102,000 Btu/hr (29.9 kW) 50 Hz: 165,000 Btu/hr (48.3 kW)
60 Hz: 130,000 Btu/hr (38.1 kW) 60 Hz: 112,000 Btu/hr (32.8 kW) 60 Hz: 165,000 Btu/hr (48.3 kW)
Steam Models: Steam Models: Steam Models:
At 100 psi (6.9 bar): 5.1 BHP N/A At 100 psi (6.9 bar): 6.1 BHP
Electric Models: Electric Models: Electric Models:
30 kW 27 kW 30 kW
Non-Rev Non-Rev Non-Rev
Steam Models: 3/4" - NPT Steam Models: N/A Steam Models: 3/4" - NPT
Height 81" (2057) 72" (1829) 81" (2057)
CSAus, CE, CSA Star, CSA FlamecCSAus, CE, CSA Star, CSA FlamecCSAus, CE, CSA Star, CSA Flame
c
(OM),
Dual Digital
(QT)
Micro-Display
(OM),
Dual Digital
(QT)
AH10-0577
Tumble dryer models are made to suit a variety of electrical service characteristics. See your Huebsch distributor for specifications. For further
details on installation, refer to Installation, Operation and Maintenance instructions supplied with the tumble dryer. USA and Canada models
are certified by C.S.A International.
For the most accurate information, the installation guide should be used for all design and construction purposes. Due to continuous
product improvements, design and specifications subject to change without notice. The quality management system of Alliance Laundry
Systems’ Ripon facility has been registered to ISO 9001:2000.
