Commercial Front Load Washer Specifications
Convenience and Efficiency
What sets Huebsch front load washers apart from the
competition?
Low water use.
Huebsch front load washers average
just 13.9 gallons of water per cycle.
Best of all, the washer is so efficient
it’s earned an ENERGY STAR
®
rating.
High spin speed.
With a final spin of 1,000 RPM, Huebsch front load
washers exert 300 G-Force on loads to remove more
water, reduce drying times and lower utility consumption.
This is the same G-Force many top-of-the-line large
capacity washer-extractors exert in commercial laundries.
Large, rugged doors.
Our washer’s large 188.6 sq.
in. door opening speeds the
often awkward and timeconsuming tasks of loading
and unloading. In addition,
the solid door features a
durable piano style, steel hinge.
Stainless steel inside and out.
For extra durability, Huebsch front load washers
feature a stainless steel finish option. The stainless
steel strength carries over to the inner and outer tubs
that will stay looking good for years. A fact backed up
with a lifetime warranty on the tubs.
Convenience.
A frontmount supply dispenser
automatically adds detergent,
bleach and softener.
L
i
m
i
t
e
d
W
a
r
r
a
n
t
y
*
Y
e
a
r
Model HFNBC
Speeds
1000, 650, 500
Cycles Heavy, Normal, Perm Press and Delicate
Water Temperatures Hot, Warm, Cold
Stainless Steel Washtub 2.84 cu. ft.
Water Pressure - psi (bar) Fill 20-120 (1.4/8.3)
Wash/Tumble - RPM 41, 50
Distribution/Pump - RPM 90
Spin Speeds - RPM 1000, 650, 500
Activation Push-to-Start
Dispenser Detergent, Liquid Bleach, Liquid Softener
Motor* - HP Variable Speed Induction, 1
Top Finish Stainless Steel, Porcelain
Color Stainless Steel, White
Width - in (mm) 26 7/8" (683)
Depth - in (mm) 28" (711)
Height** - in (mm) 43" (1092)
Work Surface Height** - in (mm) 43" (1092)
Weight - lb (kg) 250 (113)
Agency Approvals
CULUS
* Motor: 1 HP reversing, permanently lubricated with a built-in electronic protector.
** Heights may vary slightly depending on leveling adjustments.
For the most accurate information, the installation guide should be used for all design and
construction purposes. Due to continuous product improvements, design and specifications
subject to change without notice. The quality management system of Alliance Laundry Systems’
Ripon facility has been registered to ISO 9001:2000.
Printed in the U.S.A.
©Copyright 2010 Alliance Laundry Systems LLC
Unmatched Durability
What sets Huebsch apart from other
brands in terms of reliability?
Not just standing behind our
equipment, but standing beside
you and your business.
Our made-in-America product comes with an industryleading bond. The entire machine receives Huebsch’s
standard three-year warranty. In addition, Huebsch has
more service representatives in the field than most
brands have in their whole organization. Huebsch
support is further bolstered by an online component
and a help line that takes 10,000 calls per year.
*Parts only, labor not included. See Huebsch Warranty Bond for specifics.
