This document describes the process of installing a DC blade RRU3268 (referred to as RRU
in this document).
Product Versions
The following table lists the product versions related to this document.
About This Document
About This Document
Product Name
DBS3900SRAN6.0 and later versionsV100R004C00 and later
Intended Audience
This document is intended for:
Base station installation engineers
Organization
1 Changes in the RRU3268 Installation Guide
This chapter describes the changes in the RRU3268 Installation Guide.
Solution VersionProduct Version
versions
eRAN2.1 and later versionsV100R003C00 and later
versions
2 Installation Preparations
This chapter describes the reference documents, tools, and instruments that must be ready
before the installation. In addition, it specifies the skills and prerequisites that installation
engineers must have.
3 Information About the Installation
Before installing an RRU, you must be familiar with its exterior, ports, indicators, installation
options and installation clearance requirements.
Issue 10 (2015-12-30)Huawei Proprietary and Confidential
Indicates a potentially hazardous situation which, if not
avoided, could result in equipment damage, data loss,
performance deterioration, or unanticipated results.
NOTICE is used to address practices not related to personal
injury.
Calls attention to important information, best practices and
tips.
NOTE is used to address information not related to
personal injury, equipment damage, and environment
deterioration.
General Conventions
The general conventions that may be found in this document are defined as follows.
Convention
Description
Times New RomanNormal paragraphs are in Times New Roman.
BoldfaceNames of files, directories, folders, and users are in
boldface. For example, log in as user root.
ItalicBook titles are in italics.
Courier New
Examples of information displayed on the screen are in
Courier New.
Command Conventions
The command conventions that may be found in this document are defined as follows.
Convention
Description
BoldfaceThe keywords of a command line are in boldface.
ItalicCommand arguments are in italics.
[ ]Items (keywords or arguments) in brackets [ ] are optional.
{ x | y | ... }Optional items are grouped in braces and separated by
vertical bars. One item is selected.
[ x | y | ... ]Optional items are grouped in brackets and separated by
vertical bars. One item is selected or no item is selected.
{ x | y | ... }
*
Optional items are grouped in braces and separated by
vertical bars. A minimum of one item or a maximum of all
items can be selected.
Issue 10 (2015-12-30)Huawei Proprietary and Confidential
2.2 Tools and Instruments..................................................................................................................................................... 6
2.3 Skills and Requirements for Onsite Personnel............................................................................................................... 8
3 Information About the Installation........................................................................................... 9
3.5 Installation Clearance Requirements of an RRU..........................................................................................................23
3.5.1 Clearance for a Single RRU...................................................................................................................................... 23
3.5.2 Clearances for Three or More RRUs.........................................................................................................................26
3.5.3 Installation Spacing Between RRUs..........................................................................................................................30
4 Unpacking the Equipment.........................................................................................................33
6 (Optional) Installing the Plastic Shells of the RRU..............................................................36
7 Hoisting an RRU and Related Cables onto a Tower............................................................ 38
7.1 Hoisting an RRU onto a Tower.................................................................................................................................... 39
7.2 Hoisting Fiber Optic Cables onto a Tower................................................................................................................... 42
7.3 Hoisting Power Cables onto a Tower........................................................................................................................... 45
8 Installing the RRU.......................................................................................................................48
8.1 Mounting Kits for an RRU........................................................................................................................................... 49
8.2 Installing the RRU on a Pole........................................................................................................................................ 50
8.2.1 Installing a Single RRU.............................................................................................................................................50
8.2.2 Installing Two RRUs................................................................................................................................................. 53
8.2.3 Installing Three or More RRUs................................................................................................................................. 57
8.3 Installing the RRU on U-steel...................................................................................................................................... 62
8.4 Installing the RRU on Angle Steel............................................................................................................................... 67
Issue 10 (2015-12-30)Huawei Proprietary and Confidential
8.5 Installing the RRU on a Wall........................................................................................................................................ 71
8.6 Installing an RRU on an IFS06.....................................................................................................................................77
9.5 Installing an RRU PGND Cable...................................................................................................................................96
9.6 Installing an RRU RF Jumper...................................................................................................................................... 97
9.7 Installing an RRU AISG Multi-Wire Cable and AISG Extension Cable...................................................................101
9.8 Installing an RRU Alarm Cable..................................................................................................................................103
9.9 Opening the Cover Plate of an RRU Cabling Cavity................................................................................................. 105
9.10 Installing an RRU Power Cable................................................................................................................................107
9.11 Installing a CPRI Fiber Optic Cable.........................................................................................................................109
9.12 Closing the Cover Plate of an RRU Cabling Cavity.................................................................................................112
10 Checking the RRU Hardware Installation..........................................................................115
11 Powering On an RRU............................................................................................................. 117
This chapter describes the reference documents, tools, and instruments that must be ready
before the installation. In addition, it specifies the skills and prerequisites that installation
engineers must have.
2 Installation Preparations
2 Installation Preparations
2.1 Reference Documents
Before the installation, you must be familiar with reference documents.
2.2 Tools and Instruments
You must prepare the following tools and instruments before the installation.
2.3 Skills and Requirements for Onsite Personnel
Onsite personnel must be qualified and trained. Before performing any operation, onsite
personnel must be familiar with correct operation methods and safety precautions.
Issue 10 (2015-12-30)Huawei Proprietary and Confidential
Onsite personnel must be qualified and trained. Before performing any operation, onsite
personnel must be familiar with correct operation methods and safety precautions.
Before the installation, pay attention to the following items:
lThe customer's technical engineers must be trained by Huawei and be familiar with the
proper installation and operation methods.
lThe number of onsite personnel depends on the engineering schedule and installation
environment. Generally, only three to five onsite personnel are necessary.
Issue 10 (2015-12-30)Huawei Proprietary and Confidential
Before installing an RRU, you must be familiar with its exterior, ports, indicators, installation
options and installation clearance requirements.
3 Information About the Installation
3.1 RRU Exterior
This section describes the exterior and dimensions of an RRU.
3.2 RRU Ports
This section describes ports on the RRU panels. An RRU has a bottom panel, cabling cavity
panel, and indicator panel.
3.3 RRU Indicators
This section describes six indicators on an RRU. They indicate the running status.
3.4 Installation Scenarios
An RRU can be installed on a pole, U-steel, angle steel, wall, or IFS06. Installation scenarios
must meet heat-dissipation and waterproofing requirements of the RRU.
3.5 Installation Clearance Requirements of an RRU
This section describes the requirements for the installation clearance of a single RRU and
multiple RRUs and the requirements for the installation spacing between RRUs.
Issue 10 (2015-12-30)Huawei Proprietary and Confidential
This section describes the exterior and dimensions of an RRU.
Figure 3-1 shows an RRU.
Figure 3-1 RRU exterior
3 Information About the Installation
Figure 3-2 shows RRU dimensions.
Figure 3-2 RRU dimensions
You can obtain the RRU frequency band and power supply information from the
configuration label on the cover plate and obtain the RRU name from the nameplate on the
side of RRU that accommodates the conversion bracket. Figure 3-3 shows the positions of the
configuration label and nameplate on the RRU.
NOTE
The actual label and nameplate may differ from what is shown in the figure.
Issue 10 (2015-12-30)Huawei Proprietary and Confidential
Alarms are generated. The alarms may be
caused by the faults on the related boards or
ports. Therefore, you need to locate the
fault before deciding whether to replace the
module.
13
RRU3268
Installation Guide
3 Information About the Installation
IndicatorColorStatusMeaning
Steady offNo alarm is generated.
ACTGreenSteady onThe module is running properly with TX
channels enabled or the software is being
loaded without RRU running.
Blinking (on for
1s and off for 1s)
VSWRRedSteady offNo Voltage Standing Wave Ratio (VSWR)
Blinking (on for
1s and off for 1s)
Steady onVSWR alarms are generated on the
Blinking (on for
0.125s and off for
0.125s)
CPRI0Red or
green
Steady greenThe CPRI link is functioning properly.
Steady redAn optical module fails to transmit or
Blinking red (on
for 1s and off for
1s)
The module is running properly with TX
channels disabled.
alarm is generated.
VSWR alarms are generated on the
ANT_TX/RXB port.
ANT_TX/RXA port.
VSWR alarms are generated on the
ANT_TX/RXA and ANT_TX/RXB ports.
receive signals because the optical module
is faulty or the fiber optic cable is broken.
The CPRI link is out of lock because of a
failure in clock lock between two modes or
mismatched data rates over CPRI ports.
CPRI1Red or
green
3.4 Installation Scenarios
An RRU can be installed on a pole, U-steel, angle steel, wall, or IFS06. Installation scenarios
must meet heat-dissipation and waterproofing requirements of the RRU.
Steady offThe optical module cannot be detected, or
the optical module is powered off.
Steady greenThe CPRI link is functioning properly.
Steady redAn optical module fails to transmit or
receive signals because the optical module
is faulty or the fiber optic cable is broken.
Blinking red (on
for 1s and off for
1s)
Steady offThe optical module cannot be detected, or
The CPRI link is out of lock because of a
failure in clock lock between two modes or
mismatched data rates over CPRI ports.
the optical module is powered off.
Issue 10 (2015-12-30)Huawei Proprietary and Confidential
To ensure proper heat dissipation of the RRU, the following requirements must be met:
lThe RRU cannot be installed in an enclosed cabinet without a cooling system.
lThe RRU cannot be installed in an enclosed camouflage box.
lThe RRU cannot be installed in an enclosed equipment room without a cooling system.
lWhen multiple RRUs are installed in centralized mode, the minimum clearance
requirements must be met. For details about the minimum clearance requirements, see
3.5.2 Clearances for Three or More RRUs and 3.5.3 Installation Spacing Between
RRUs.
lRRU mounting kits in assembled installation mode are not allowed in indoor scenarios.
NOTICE
If the RRU is improperly installed, heat dissipation of the RRU deteriorates and the RRU may
not work properly, as shown in Figure 3-5.
3 Information About the Installation
Figure 3-5 Improperly installed RRUs
Method of installation:
lThe installation supports' specifications described in this document are only based on the
exterior and dimensions of the mounting kits. Before installing equipment, assess the
strength and reliability of the installation support to determine whether it can bear the
weight of the equipment.
lTo ensure the heat dissipation of the RRU and waterproofing of the ports at the bottom of
the RRU, the vertical deviation angle of an RRU must be less than or equal to 10
degrees, as shown in Figure 3-6.
lOn a tower, an RRU can be installed on a pole, angle steel, or U-steel. The side-mounted
installation mode (one side instead of the rear of an RRU is mounted on the support) is
recommended for RRUs on the main pole secured on a tower. This installation mode
Issue 10 (2015-12-30)Huawei Proprietary and Confidential
allows multiple RRUs to be installed next to each other at the same level on a pole.
When the horizontal distance between the main and auxiliary poles on a tower is equal to
or greater than 810 mm (23.62 in.), the side-mounted mode is recommended for
installing RRUs on the auxiliary pole to meet the minimum clearance requirements.
Otherwise, the standard mode is recommended for installing RRUs on the auxiliary pole.
Figure 3-6 Requirements for the vertical deviation angle of an RRU
(1) RRU(2) Installation support (pole, U-steel, angle steel, or wall)
Installing an RRU on a Pole
Figure 3-7 shows the diameter of a pole for installing an RRU.
Figure 3-7 Diameter of a pole
Issue 10 (2015-12-30)Huawei Proprietary and Confidential
lThe upper and lower adjustable beams on an IFS06 can be moved up and down to fit for
heights of RRUs.
lThe IFS06 supports at least three RRUs when the ambient temperature is higher than or
equal to the lowest operating temperature of the RRU and at least 5°C (41°F) lower than
the highest operating temperature of the RRU. The IFS06 supports a maximum of six
RRUs when the ambient temperature is higher than or equal to the lowest operating
temperature of the RRU and at least 10°C (50°F) lower than the highest operating
temperature of the RRU.
NOTE
For details about the operating temperature of the RRU, see section "Technical Specifications of
RRUs" in 3900 Series Base Station Technical Description.
NOTICE
The mounting brackets for multiple RRUs cannot be combined when the RRUs are installed
on an IFS06, as shown in Figure 3-16.
Issue 10 (2015-12-30)Huawei Proprietary and Confidential
