Basic Gestures
System Navigation
Phone Clone
Lock and Unlock Your Screen
Get Familiar with the Home Screen
Notication and Status Icons
Shortcut Switches
Home Screen Widgets
Set Your Wallpaper
Screenshots&Screen Recording
View and Clear Notications
Adjust Sound Settings
Enter Text
Split-screen Mode and Floating Window
Show Date and Time When the Screen Is O
Power On and O or Restart Your Device
Charging
1
4
5
7
8
9
11
12
13
13
19
20
22
22
26
27
28
Smart Features
HiVoice
AI Lens
HiTouch
Easy Projection
Multi-screen Collaboration
Huawei Share
Switch Audio Channels Between Devices
Camera and Gallery
Launch Camera
Take Photos
Shoot in Portrait, Night, and Wide Aperture Modes
Master AI
Zoom to Take Photos
Super Macro
Take Panoramic Photos
Take Black and White Photos
AR Lens
Light Painting
Take HDR Photos
Moving Pictures
30
34
38
39
43
50
53
55
56
58
61
63
64
65
66
66
68
69
70
i
Add Stickers to Photos
Documents Mode
Underwater Mode
Take High-Resolution Photos
Pro Mode
Record Videos
AI Movie Eects
4K HD Videos
Slow-Mo Recording
Time-Lapse Photography
Dual-View Mode
Leica Colors
Filters
Use the Camera with Other Devices
Adjust Camera Settings
Manage Gallery
Smart Photo Categorisation
Huawei Vlog Editor
Huawei Vlogs
Highlights
Reduce volume, then enable Flip to mute ringtone and Raise to lower volume.
Set the Default Volume
Go to Settings > Sounds & vibration, then you can set the volume for the following
items:
• Media (video, games, music, and more)
• Ringtones
• Alarms
• Calls
21
Use a Shortcut to Switch Between Ring, Vibrating, or Mute Mode
Essentials
1 Swipe down from the status bar to open the
again to show all shortcuts.
2 Touch the
modes.
Sound, Silent, or Vibration icon to switch between dierent
notication panel, then swipe down on it
Enter Text
Edit Text
You can select text displayed on your screen, copy or cut it to the clipboard, then paste it
somewhere else. You can also share it in multiple ways.
1 Touch and hold the text until
In some apps, what happens after you touch and hold the text may dier. For example, if
you touch and hold a sent or received message, an option menu will be displayed, and
will appear only after you touch Select text.
appears.
2 Drag
and to select the text you need, or touch Select all to select all text.
3 Touch Copy or Cut as needed.
4 Touch and hold the space where you want to paste the text until Paste appears, then
touch Paste.
Split-screen Mode and Floating Window
Multi-Window
Multi-Window allows you to open apps in split screens or in a
multitasking.
oating window for
22
Essentials
Enable Split-screen Mode from the Multi-Window Dock
• Enable Split-screen mode:
1 Open an app and swipe inward from the left or right edge and hold to bring up the
Multi-Window dock.
23
Essentials
2 Drag an app icon out of the Multi-Window dock.
• Switch the split-screen panes: Touch and hold or at the top of a split-screen pane
until the pane shrinks. Then drag the pane to the other side of the screen to switch them.
• Exit Split-screen mode: Drag or in the middle of the split screen line horizontally
or vertically until either pane disappears.
• Support for Split-screen mode varies by app.
• The screen of a single app can't be split into two.
• Split-screen mode applies only to two apps at any given time.
Display the Floating Window from the Multi-Window Dock
While playing a game, you can also chat with your friend in a oating window, without
having to exit the game.
• Display the oating window:
1 Swipe inward from the left or right edge and hold to bring up the Multi-Window dock.
24
Essentials
2 Touch an app icon in the Multi-Window dock to open the app in a oating window.
• Relocate the oating window: Drag the oating window to the desired location.
• Display in full screen: Touch on the oating window to display the content in the
window in full screen.
• Close the oating window: Touch on the oating window to close it.
The size of the oating window cannot be adjusted.
Switch Between Split-screen and Floating Window
• Switch from Split-screen mode to oating window: Touch and hold a split-screen pane, then
drag it to the left or right when in Portrait mode, or drag it downwards in Landscape mode.
• Switch from oating window to Split-screen mode: Touch and hold the bar at the top of the
oating window, then drag it to the upper/lower part of the screen when in Portrait mode,
or to the left or right when in Landscape mode.
Drag and Drop Between Apps with Multi-Window
Use the Multi-Window feature to easily drag and drop images, text, and documents between
apps.
• Drag and drop an image: When taking notes with Notepad, open Files, select the photo
you want to add, and drag it into the Notepad editor.
• Drag and drop text: When sending a message with WeChat, open Notepad, touch and hold
the text you want to send, and drag it to the text input box in WeChat.
25
Essentials
• Drag and drop a document: When writing an email, open Files, select the document you
want to attach, and drag it into the email editor.
Not all apps fully support drag-and-drop with Multi-Window.
Add, Move, or Remove an App from the Multi-Window Dock
• Add an app: In the Multi-Window dock, touch , touch the app you want to add from
Suggested or More apps, then touch Done.
• Move an app: In the Multi-Window dock, touch
, drag the desired app to any location
in the dock, then touch Done.
• Remove an app: In the Multi-Window dock, touch , touch in the upper right corner
of the icon of the app you want to remove, then touch Done.
Disable Multi-Window
Multi-Window is enabled by default. To disable it, go to Settings > Accessibility features
> Multi-Window, then disable Multi-Window dock.
Show Date and Time When the Screen Is O
Always On Display
With Always On Display enabled, the lock screen will show the date, time, and more when
the screen is
o.
Enable Always on Display
1 Go to Settings > Home screen & wallpaper > Always On Display > Always On
Display, and enable Always On Display.
2 Set the Start and End according to your preferences.
Set Clock Style for Always on Display
You can customise the clock style for Always On Display according to your preferences.
26
Essentials
1 On the Always On Display screen, touch Clock style, and swipe across to view the
available clock styles.
2 Select a preferred clock style, and touch .
Power On and
Power On and
Power Your Device On and O
To power o your device, press and hold the Power button for a few seconds, touch Power
o and Touch to power o.
To power on your device, press and hold the Power button for a few seconds until your device
vibrates and displays the logo.
Restart Your Device
Restart your device on a regular basis to clear the cache and keep the device in an optimal
O or Restart Your Device
O or Restart Your Device
state. A restart can sometimes resolve the issue when your device encounters a problem.
Just press and hold the Power button for a few seconds, then touch Restart and Touch to
restart.
27
Essentials
Force Restart Your Device
If your device isn't working or won't turn o normally, you can force restart it.
Just press and hold the Power button for 10 seconds or longer.
Charging
Charge Your Device
Your device will alert you when it is running out of power. Please make sure to charge your
device in time to prevent it from turning
o automatically when the power runs out.
Precautions for Charging
• Charge your device using the standard adapter and USB cable that came with your device.
Using other chargers or USB cables may cause repeated restarts, slow charging,
overheating, or other undesirable eects.
• Your device will automatically run a safety check when a charger or other device is
connected to the USB port. If moisture is detected in the USB port, your device will
automatically activate safety measures and stop charging. Disconnect your device from the
USB port and wait until the USB port is dry.
• The time required to fully charge the battery depends on the ambient temperature and age
of the battery.
• Batteries have a limited number of charge cycles. When the battery life becomes noticeably
shorter, go to an authorised Huawei Customer Service Centre to replace the battery.
• Do not cover your device or charger during charging.
• Your device may heat up when you have been using it for an extended period of time,
especially in high temperatures. In this case, stop charging, disable some features, and
move your device to a cool place.
• Please do not use your device while it is charging.
• If your device does not respond after you press and hold the Power button, the battery may
have run out. Charge for 10 minutes and then power it on.
Using the Charger that Came with Your Device
1 Use the USB cable that came with your device to connect your device and the adapter.
2 Plug the adapter into a power socket.
Charging Your Device With a PC
1 Connect your device to a PC or other device using a USB cable.
2 When the Use USB to dialog box is displayed on your device, touch Charge only.
If another option has been set previously, the dialog box will not pop up. Swipe down
from the status bar to open the notication panel, touch Settings, then select Chargeonly.
28
Overview of Battery Icons
You can check the battery level from the battery icon on the device screen.
Battery IconBattery Level
Less than 4% battery remaining
Charging, less than 10% battery remaining
Charging, 10% to 90% battery remaining
Charging, at least 90% battery remaining
If 100% is displayed next to the battery icon, or a charging complete
message is displayed on the lock screen, the battery is fully charged.
Reverse Charging with an OTG Cable
Essentials
On-The-Go (OTG) is a USB transmitting technology that allows a device to directly access
les on a USB ash drive or digital camera, or connect to an external device such as a
keyboard or mouse, with the help of an OTG cable.
You can use your device to charge other devices using an OTG cable.
1 Connect your device with the device to be charged using an OTG cable.
2 When the Use USB to dialog box is displayed on your device, touch Reverse charge.
If another option has been set previously, the dialog box will not pop up. Swipe down
from the status bar to open the
Reverse charge.
notication panel, touch Settings, and then select
3 Follow the onscreen instructions on the device to be charged to start charging.
29
Smart Features
HiVoice
HiVoice
You can use HiVoice to interact with Huawei devices (such as smartphones, tablets) hands-
free.
Countries and Regions Where HiVoice Can Be Used
Currently, you can communicate with HiVoice in English, French, and Spanish in the UK,
France, Spain, Chile, Mexico, and Colombia.
To set your country and region, and the system language you want to use, go to
> System & updates > Language & input > Language and region. HiVoice can only be
woken up if you select one of the above countries.
You can select a language for communicating with HiVoice from the settings menu by
touching in full screen in HiVoice. Currently, only English, French, and Spanish are
supported.
Wake Up or Disable HiVoice
There are multiple ways to wake up HiVoice, depending on the device model you use. For
example:
Press and hold the Power button for 1 second to wake up HiVoice
Before using this method, go to
with Power button, and enable Wake with Power button.
To wake up HiVoice, press and hold the Power button for 1 second.
Settings > Accessibility features > HiVoice > Wake
Settings
If you press and hold the Power button for 3 seconds, your device will power o.
Disable Wake with Power button if you do not need this method.
Say the wakeup word to wake up HiVoice
You need to record your wakeup word before using this method.
Go to Settings > Accessibility features > HiVoice > Voice wakeup, then enable Voice
wakeup. Follow the onscreen instructions to enrol your wakeup voice command.
To wake up HiVoice, say the wakeup word loudly.
Disable Voice wakeup if you do not need this method.
30
Smart Features
You cannot wake up HiVoice when your device is in a call.
You cannot wake up HiVoice with the wakeup word when your device is making an audio
or screen recording. However, you can still use the Power button to wake up HiVoice.
When Can I Interact With HiVoice?
HiVoice can be in an idle, listening, or thinking state. It only takes commands when it is
listening.
• Idle: HiVoice does not take voice commands in this state.
• Listening: HiVoice can communicate with you in this state.
• Thinking: HiVoice is carrying out your commands and doesn't take new commands in this
state.
Check HiVoice Skills
After waking up HiVoice, swipe up on the screen to enter full-screen mode. Touch
to
view HiVoice skills.
Make Calls and Send SMS Messages
You can use voice commands to make calls and send SMS messages hands-free.
Make Calls with Voice Commands
To make calls with voice commands, wake up HiVoice and give a command. For example:
• "Call Mom"
• "Call the police"
• "Call Dad"
Send SMS Messages with Voice Commands
To send SMS messages with voice commands, wake up HiVoice and give a command. For
example:
• "I want to send a message"
• "Send a message"
• "Send Dad a message saying the party is tomorrow"
Translate with HiVoice
Use HiVoice to translate your speech or text inputs to easily overcome language barriers.
1 Wake up HiVoice and say "Voice translation".
2 This will bring up the voice translation screen where you can say or enter the content you
want to translate.
3 HiVoice will display the translation results in real time and read them out for you.
31
Smart Features
Face-to-Face Translation
You can use HiVoice as your personal interpreter when travelling abroad or attending
international conferences.
1 Wake up HiVoice and say "Open face to face translation" to bring up the Face-to-face
translation screen.
2 There will be two buttons on the screen, one for you and one for the other party. Both of
you can touch and hold the button on your respective side and speak, then release the
button.
3 HiVoice will display the translation results in real time and read them out for you.
Query Weather with Voice Commands
To check the weather, simply wake up HiVoice and say:
• "What's the weather like today?"
• "What's the weather forecast for tomorrow?"
• "What's the temperature today?"
• "Will it be windy today?"
• "Is it going to rain tomorrow?"
Set Alarms with Voice Commands
To set, turn
example:
Set an alarm
• "Wake me up at 8 AM tomorrow"
• "Set an alarm for 10 PM tonight"
• "Set a weekday alarm for 7 AM"
Turn
• "Cancel my 7 AM alarm for tomorrow"
o an alarm
Check an alarm
o, or check an alarm, simply wake up HiVoice and give a command. For
• "Show my alarms"
Set Calendar Events with Voice Commands
To create or check Calendar events, wake up HiVoice and give a command. For example:
Add an event
• "Schedule a meeting for 9 tomorrow morning"
• "Set a meeting for 2 o'clock tomorrow afternoon"
Check an event
• "What's my schedule for tomorrow morning?"
• "Do I have any appointments on Monday?"
32
Smart Features
• "Do I have anything scheduled tomorrow at 9 AM?"
Set Reminders with Voice Commands
To create or check your reminders, wake up HiVoice and give a command. For example:
Create a reminder
• "Remind me I'm meeting John for
• "Remind me to pick up my package at 8 this evening"
coee tomorrow at 3"
Check a reminder
• "Do I have any reminders today?"
• "Show me all my reminders"
Open Camera, Tools, or Apps with Voice Commands
HiVoice allows you to quickly access Camera, tools or other apps on your device with voice
commands.
Access Camera with Voice Commands
To access your Camera, wake up HiVoice and give a command. For example:
• "I want to take a photo"
• "Take a photo"
Access Apps and Tools with Voice Commands
To access Torch, Calculator, or other tools with voice commands, wake up HiVoice and give a
command. For example:
Use Torch
• "Turn on the torch"
• "Turn
o the torch"
Use Calculator
• "Calculator"
• "Open the calculator"
Currently, only built-in apps and tools can be opened with HiVoice.
Change System Settings with Voice Commands
To set up the system voice commands, wake up HiVoice and give a command. For example:
• Wireless network: "Turn on Wi-Fi", or "Turn
• Mobile network: "Turn on mobile network", or "Disable 4G"
o Wi-Fi"
• Airplane mode: "Turn on Airplane mode", or "Turn
• Bluetooth: "Turn on Bluetooth", or "Turn
• Brightness adjustment: "Increase the brightness", "Lower the brightness", "Enable auto-
o Bluetooth"
o Airplane mode"
brightness", or "Disable auto-brightness"
33
Smart Features
• Comfort mode: "Turn on Eye comfort mode", or "Turn o Eye comfort mode"
• Volume adjustment: "Turn the volume up", "Turn the volume down", or "Turn the volume
up to max"
• Power saving: "Enable Power Saving mode", or "Disable Power Saving mode"
• Do Not Disturb: "Enable Do Not Disturb", or "Disable Do Not Disturb"
Search with HiVoice
If you want to use the browser to search for something, wake up HiVoice and give a voice
command, such as:
• Search for new Huawei products
• Use Google search for polar bear
• Search for
nance websites on Google
AI Lens
Access AI Lens
There are multiple ways to access AI Lens.
From Camera
Open the camera and select Photo mode. Touch to access AI Lens.
34
Smart Features
From the Search Bar
While the device is unlocked, swipe down on the screen to display the search bar. Then, touch
to access AI Lens.
35
Smart Features
From the Lock Screen
When the device is locked, swipe up from the bottom of the screen. Touch
the device to access AI Lens.
, then unlock
36
Smart Features
Scan Codes
AI Lens can read QR codes and instantly direct you to the relevant app.
1 Open the camera, touch , then touch .
2 Position the QR code within the frame and wait for it to be recognised.
Scan to Translate
AI Lens has an Instant translation feature that can help you quickly translate text, such as
road signs, menus, or even descriptions on a medicine or cosmetic bottle.
1 Open the camera, touch
, then touch .
2 Select the source and target languages from the language list.
3 Align the text you want to translate, and wait for it to be translated.
Scan to Shop
AI Lens has a Shopping feature that lets you scan products when you are out shopping or
reading a fashion magazine and gives you purchase recommendations for similar items
online.
1 Open the camera, touch , then touch .
37
2 Position the target object within the viewnder. You will receive purchase
Smart Features
recommendations once the object has been recognised. You can also touch
photo, which will be recognised automatically.
to take a
HiTouch
Convenient Shopping
When you see an item on your device that you would like to buy, you can use HiTouch to
quickly search for the item and compare prices across multiple shopping platforms before
making the purchase.
Touch and Hold with Two Fingers for Convenient Shopping
1 Go to Settings > Accessibility features > HiTouch and enable HiTouch.
2 When you see an item on your device that you would like to buy, touch and hold the
screen with two ngers spread slightly apart.
3 Adjust the position and size of the identication box.
4 After the object is identied, links to the item on dierent shopping platforms will then be
displayed.
38
5 Touch the links to view product details and make a purchase.
Easy Projection
Wireless Projection
You can connect your device to an external display (for example, a TV) wirelessly.
Smart Features
1 Based on the model and functions of your external display, do the following:
•If the external display supports Miracast, enable wireless projection on it.
•If not, use a wireless HDMI adapter to connect your device and external display. Ensure
that the wireless HDMI adapter is connected to a power supply.
To check whether your external display supports Miracast and how to enable wireless
projection on it, consult the user guide or customer service of the external display
manufacturer.
2 Swipe down from the status bar to open the
Wi-Fi.
3 Swipe down further on the
will now search for the external display or the wireless HDMI adapter.
notication panel to enable Wireless Projection. Your device
notication panel, then touch to turn on
39
Smart Features
Alternatively, go to Settings > More connections > Easy Projection and enable
Wireless Projection.
4 Touch the name of the external display or the wireless HDMI adapter on the search result
list to start projecting.
Wired Projection
You can connect your device to an external display (for example, a TV) using a wired
connection.
It is recommended that you purchase the accessories recommended or specied by Huawei
from authorised sources.
Projection Using a Type-C Cable
1 Prepare a Type-C cable.
Use a Type-C to HDMI, Type-C to DP, or Type-C to MiniDP cable depending on your
external display.
2 Connect the Type-C end to your device and the other end to the external display.
40
Smart Features
3 On the external display, set the corresponding HDMI, DP, or MiniDP input as the signal
source.
Projection Using a Docking Station
If you need to connect your device to an external display and use a wired mouse and
keyboard, use a docking station with a USB port.
1 Prepare a docking station.
Multiple types of ports are available on a docking station. If your external display supports
HDMI and you need to use a wired mouse and keyboard, use a docking station with at
least one HDMI port and two USB ports.
2 Connect your device and the external display through the docking station, then connect
the wired mouse and keyboard to the docking station.
41
Smart Features
3 On the external display, set the corresponding HDMI, DP, or MiniDP input as the signal
source.
Desktop Mode
For enhanced work eciency, project your device's content onto an external display, swipe
down from the status bar to open the notication panel, then enable DESKTOP MODE.
In DESKTOP MODE, the display of your device will be arranged in a desktop layout, and
operations on your device won't aect what's on the external display. For example, you can
edit a document on the external display while chatting on your device. You don't need to
worry about missing notications, calls, or messages, as a red dot will appear on the
notication panel on the external display to keep you informed.
Use Your Device as a Touchpad
Swipe down from the status bar to open the notication panel, then touch TOUCHPAD. You
can now do the following:
• Use gestures as instructed to simulate mouse commands.
• When no external keyboard is connected, click the text input box on the external display to
bring out the onscreen keyboard to input text.
42
Smart Features
If an external keyboard is connected, the onscreen keyboard will not be available. In this
case, you need to use the external keyboard to input text.
Project Your Device to an External Display to Facilitate Your Work
In DESKTOP MODE, you can use the following features:
• Multiple windows: Open more than one window at a time to multitask.
• File management: Save les to the desktop, create les or folders, and rename or delete
les.
• Quick search: Search for documents, multimedia les, and apps using the start menu search
box.
• Create app shortcuts: From the start menu, touch and hold an app and then drag it to the
desktop to create a shortcut. You can also right-click an app icon and select the option to
create an app shortcut on the desktop.
• Audio output: Touch the audio output icon on the status bar, then select the external
display or your Device as the audio output device.
• App projection: Touch and hold an app icon on your device to view the projection options.
You can now project and open the app on the external display.
• Highlighter: Use the highlighter feature to mark projected content using the touchpad.
Exit Desktop Mode
Swipe down from the status bar to open the
notication panel, then touch PHONE MODE.
Multi-screen Collaboration
Connect Your Device to a Computer
When you connect your device to a Huawei/Honor laptop, the device screen will be displayed
in a window on the laptop screen, allowing you to easily operate your device while on your
laptop.
Connect Your Device and Computer with a Tap
1 Make sure that your computer is marked with a Huawei Share icon
or Magic-link icon
.
2 On your computer, enable Wi-Fi. Open PC Manager and agree to the End User Licence
Agreement (EULA).
•To connect with a tap, PC Manager must be version 9.0 or later. To establish a
connection for Multiscreen, PC Manager must be version 10.0 or later.
•To check the version of PC Manager, go to > About. To update it, go to >
Check for updates.
43
Smart Features
3 Swipe down from the status bar on your device to open the notication panel, swipe
down further to display all shortcut switches, and enable NFC, Wi-Fi, and Bluetooth.
4 Tap the NFC area at the back of your device against the Huawei Share icon or Magic-link
icon on your computer and hold it there until your device vibrates or plays a notication
sound.
5 Follow the onscreen instructions on your device and computer to complete the
connection.
Connect Your Device and Computer via Bluetooth
1 On your device, swipe down from the status bar to open the
to enable Bluetooth.
notication panel, and touch
2 On the computer, open PC Manager (version 10.0 or later), select My Phone, and go to
Connect > Search. Your computer will start searching for your device. Make sure that your
device is placed near your computer.
To check the version of PC Manager, go to > About. To update it, go to >
Check for updates.
3 Follow the onscreen instructions on your device and computer to complete the
connection.
Connect Your Device and Computer by Scanning a QR Code
1 On your computer, open PC Manager (version 10.0 or later), select My Phone, and go to
Connect > Scan.
To check the version of PC Manager, go to > About. To update it, go to >
Check for updates.
2 Ensure that your device is connected to the Internet, and use it to scan the QR code on
your computer screen.
3 Follow the onscreen instructions on your device and computer to complete the
connection.
Connect Your Device to Computer with a Cable for Multi-Screen Collaboration
Use a USB cable to connect your device to a computer, and the device screen will be
displayed in a window on the computer screen.
1 Use a USB cable to connect your device to a computer.
2 On your device, touch CONNECT in the Use USB to dialog box.
3 On the computer, open PC Manager (version 10.1 or later).
To check the version of PC Manager, go to > About. To update it, go to >
Check for updates.
4 Accept the connection on your device.
If you have cancelled the connection on your device and want to re-establish the
connection, go to Connect > Wired connection in PC Manager.
44
Smart Features
Disconnect Your Device from Computer
You can disconnect your device from computer using any of the following methods:
• On your computer, open PC Manager, and go to My Phone > Disconnect.
• On your device, swipe down from the status bar to open the notication panel and touch
DISCONNECT.
• If connected via USB cable, remove the cable to disconnect your device from the computer.
Transfer Files Between Your Device and Computer
After connecting your device to a Huawei/Honor computer, you can transfer les between
them to make your work life more convenient and ecient.
Drag to Transfer Files Between Your Phone and Computer
After your phone is connected with your computer, you can drag les (such as pictures,
videos, audio les, texts, oce documents, and compressed packages) using a mouse to
transfer them between your phone and computer.
• Transfer les from your phone to your computer:
Open Gallery in the phone window on your computer, click and hold a picture or video,
select one or more les, click and hold the selected les again, wait for an icon for dragging
les to display, then drag them to a folder on your computer.
Open Files in the phone window on your computer, then drag les to a folder on your
computer in the way described above.
You can also drag pictures or text to documents that are open on your computer. For
example, drag a photo or text from Notepad in the phone window across to an Oce
document open on your computer, then continue editing it on your computer.
• Transfer les from your computer to your phone:
Go to Gallery > Albums in the phone window on your computer, select pictures or
videos in batches from a local folder on your computer, then drag them across to Albums.
Open
Files in the phone window on your computer, select les in batches from a local
folder on your computer, then drag them across to Files. By default, les transferred from
your computer will be saved in the Huawei Share folder in Files. If a specic folder in Files
has been opened, the les will be saved in it.
You can also drag pictures or text to documents that are open on your phone. For example,
drag a picture on your computer to a Notepad item open on your phone, then continue
editing it on your phone.
Transfer Files Between Your Device and Computer with a Tap
You can quickly transfer les between your device and a computer with a single tap without
the hassle of using cables or third-party apps.
45
Smart Features
Currently, this feature is only supported by Huawei/Honor laptops marked with the Huawei
Share icon or Magic-link icon and installed with PC Manager.
Share Pictures and Videos with One Tap
• Share pictures and videos from your device to computer:
1 Select one or more pictures or videos in Gallery on your device.
2 Tap the NFC area on the back of your device against the Huawei Share or Magic-link
icon on the computer, and hold it there until your device vibrates or plays a
sound. The selected pictures or videos will be transferred to your computer.
If you want to identify, copy, or save text in the received picture on the computer, click the
picture to display the image viewer, then click
• Share pictures from your computer to device:
1 Right-click an individual picture
Viewer.
le on your computer, and open it with Huawei Image
to identify text and generate a text le.
notication
2 Exit Gallery or return to the home screen on your device, tap it against your computer
(as instructed above), and the picture opened on your computer will be transferred to
your device.
PC Manager must be version 9.0 or later.
46
Smart Features
Record Your Computer Screen with One Tap
Ever wanted to show o your gaming skills or share video clips from your computer, but
never found a convenient way to do so? With a shake and a tap, what is shown on your
computer will be projected and synced to your device for recording.
1 Shake your device, then immediately tap its NFC area against the Huawei Share icon or
Magic-link icon on the computer, and hold it there until your device vibrates or plays a
notication sound. The computer screen will then be projected to your device and the
recording will start. You can record for a maximum of 60 seconds.
2 Touch on your device to stop the recording. The screen recording will be saved to
Gallery.
• This feature is currently supported on Intel-based laptops only.
• This feature works with PC Manager 9.1 or later.
Share Files with One Tap
47
Smart Features
• From your device to computer:
1 On your device, use Microsoft Oce to open the le you want to share.
2 Tap the NFC area on the back of your device against the Huawei Share or Magic-link
icon on the computer, and hold it there until your device vibrates or plays a notication
sound. The le opened on your device will be transferred to your computer.
• From your computer to device:
1 On your computer, use Microsoft Oce to open the le you want to share.
2 After exiting Microsoft Oce or returning to the home screen on your device, tap it
against your computer (as instructed above), and the le opened on your computer will
be transferred to your device.
This feature works with PC Manager 9.1 or later.
Access Device Apps and Files on Your Computer
Once your device is connected to your Huawei/Honor computer, you can access apps and
les from your device on your computer without the hassle of having to frequently switch
between the two devices.
Navigate the Device Window on Your Computer
Open/Exit an app and browse web pages in the window
48
Smart Features
• Open an app: Click an app in the window to open it.
• Browse pages: Scroll the mouse wheel to browse web pages and switch between screens of
your device displayed in the window.
• Exit an app: Press the ESC key on the computer keyboard to exit the app opened in the
window.
Use the keyboard to quickly process messages on your device
• Input text: Use the computer input method to enter text in the window, such as for sending
SMS messages and creating emails.
• Copy and paste text: Press Ctrl+C on the computer keyboard to copy text and press Ctrl+V
to paste it in the window.
• Quickly send messages: Press Ctrl+Enter to quickly send the message that you have edited
in the window, such as for sending Facebook and Twitter messages.
Always display the device window at the front
Click at the top of the window to pin it at the front of the computer screen. Click it
again to unpin the window from the front.
Share Clipboard Content Between Your Device and Computer
1 Open PC Manager (version 9.1 or later) on the computer, go to My Phone > Enable, then
follow the onscreen instructions to allow the computer to access data on your device. If
Enabled is displayed on the screen, it means that this feature is already enabled by d
fault.
2 Text copied from your device can then be pasted to the computer, and vice versa.
Click the PC Manager icon in the lower right corner of the computer screen, and select
Clipboard to view the text that you have copied.
Answer Voice or Video Calls to Your Device Using a Computer
Once your device is connected to a computer for multi-screen collaboration, you can directly
answer voice and video calls using the computer without the hassle of switching between the
two devices.
After answering calls on apps, such as WhatsApp and Skype, in the device window on the
computer, the voice will be played from the computer or the audio output device (such as a
headset or speaker) connected to it.
Use Apps on a Computer to Open Files on Your Device
Once your device is connected to a computer for multi-screen collaboration, you can use the
apps on the computer to directly open and edit les on your device.
• Documents: You can use an oce app on your computer, such as Microsoft Oce.
• Pictures: You can use an app for viewing or editing pictures on your computer, such as
Photoshop.
49
Smart Features
• Audio and video les: You can use an audio and video player on your computer, such as
Windows Media Player.
• Web pages: You can use a browser on your computer, such as Internet Explorer.
• Compressed les: You can use a decompression app on your computer, such as WinRAR.
View Device
Notications on Computers
Once your device is connected to a computer for multi-screen collaboration, notications
received on your device will be displayed in the Message Centre of PC Manager from where
you can view and manage them.
1 Click the PC Manager icon in the lower right corner of the computer screen.
2 Open the device
on the computer screen.
notications displayed in Message and view them in the device window
Huawei Share
Huawei Share
Huawei Share is a wireless sharing technology that allows you to quickly transfer images,
videos, documents, and other types of
to discover nearby devices that supports Huawei Share and Wi-Fi Direct to transfer les
without using mobile data.
les between devices. This technology uses Bluetooth
Enable or Disable Huawei Share
You can enable or disable Huawei Share in either of the following ways:
• Swipe down from the status bar to open the
notication panel, then touch to enable
or disable Huawei Share. Touch and hold the toggle to enter the Huawei Share settings
screen.
• Go to Settings > More connections > Huawei Share, and enable or disable Huawei
Share.
Enabling Huawei Share automatically turns on Wi-Fi and Bluetooth.
Quickly Share Files Between Your Devices with Huawei Share
You can use Huawei Share to quickly share les between Huawei devices. The recipient can
preview the les before they are sent, then view the full content of the les once they have
been received. For example, the recipient can view received pictures or videos in Gallery.
50
Smart Features
1 On the receiving device, enable Huawei Share.
2 On the sending device, touch and hold to select the les you want to share, then touch
. Touch Huawei Share, then touch the icon of the receiving device to send the les.
These steps may be dierent if you are sharing les directly from an app.
3 On the receiving device, touch Accept to accept the transfer.
To view the received
Categories tab.
Received pictures or videos can also be found in Gallery > Albums > Huawei Share.
Share Files Between Your Device and Computer with Huawei Share
You can use Huawei Share to quickly and easily share les wirelessly between your device
and a computer (Windows or macOS).
les, go to Files, then go to Internal storage > Huawei Share on the
51
Smart Features
1 Make sure your device and computer are connected to the same Wi-Fi network.
2 On your device, go to the Huawei Share settings screen and enable Huawei Share and
Computer Share.
3 Make a note of the name displayed next to Name shown on computers and the user
name and password under Verication.
4 On the computer, go to:
•Windows: This PC (Computer) > Network.
•macOS: Finder > Go to > Network.
Currently, this feature is only available on Macs running macOS 10.8 to 10.14.
5 On your computer, double-click the name of your device and enter the user name and
password noted down previously.
6 Open a shared folder on your device, such as the Internal storage or Album folder to view,
edit, or copy
Changes made to les in the shared folders on your computer will be automatically
synced to your device and vice versa.
les from your device to your computer or vice versa.
One-Touch Printing with Huawei Share
When a printer that supports Huawei Share is nearby, you can use Huawei Share to nd the
printer and print out pictures or PDF les stored on your device.
52
Smart Features
1 Depending on the type of printer, ensure the following:
•Wi-Fi capable printers: The printer must be powered on and connected to the same
network as your device.
•Wi-Fi Direct capable printers: The printer must be powered on and have Wi-Fi Direct
enabled.
•Bluetooth capable printers: The printer must be powered on and discoverable via
Bluetooth.
2 On your device, preview the le to be printed, then go to Share > Huawei Share.
3 Once the printer has been discovered, touch its name on your device, and adjust the
settings on the preview screen. Then, touch PRINT to print.
If you are connecting a Bluetooth printer to your device for the rst time, nd the printer
on your device, touch the printer name, then press and hold the Power button on the
printer for about 1 second to conrm the connection.
For a list of supported printers, touch Help on the Huawei Share sharing screen, select
Printers, then touch What printers are supported?.
Switch Audio Channels Between Devices
53
Smart Features
Switch Audio Channels Between Devices
When playing music or videos through your earphones, you can quickly switch the playback
to another device without having to unplug your wired earphones or disconnect your
Bluetooth earphones.
1 Connect your wired earphones or Bluetooth audio devices (such as Bluetooth earphones,
speaker, or in-car kit) to your device.
2 After pairing is successful, you will see the Current audio output device card when
swiping down the
audio output devices that are currently available.
Select the device you want to switch the audio to.
When non-Type-C wired earphones are connected to your device, the audio output
channel of your device is switched from This device to wired earphones.
notication panel on your device. Touch on the card to display the
54
Camera and Gallery
Launch Camera
Launch Camera
There are multiple ways to open the Camera app.
From the Home Screen
From the home screen, open
From the Lock Screen
When the screen is locked, turn on the screen, then swipe up on the camera icon in the lower
right corner to open the camera.
Using Ultra Snapshot
When enabled, simply double-press the Volume down button to open the camera when the
screen is o.
Camera.
55
Camera and Gallery
1 Open Camera.
2 Go to > Ultra Snapshot and select Open Camera or Take a snapshot.
3 You can now open the camera or take a snapshot without unlocking your screen.
Take Photos
Take Photos
1 Open Camera.
2 You can then:
•Focus: Touch the location you want to focus on.
56
Camera and Gallery
To adjust focus and metering separately, touch and hold the viewnder and drag the
respective frame or ring to the desired location.
•Adjust brightness: Touch the viewnder. When the symbol appears next to the
focus frame, drag it up or down.
•Zoom in or out: On the viewnder, pinch in or out, or drag the zoom slider.
•Select a camera mode: Swipe up, down, left, or right across the camera mode options.
•Turn the ash on or o: Touch and select (Auto), (On), (O), or
(Always on).
These features may not be available in some camera modes.
3 Touch to take a photo.
Take Burst Photos
Use Burst mode to take a sequence of photos in quick succession so you can choose the best
one.
Burst shooting is only available when using the rear camera.
1 Open
2 Touch and hold
When shooting, you'll see a counter, which indicates how many photos you've taken so
far.
Camera and select Photo mode.
or press and hold one of the Volume buttons to take a burst photo.
3 Lift your nger to stop shooting.
Once you have nished, select photos you want to keep from the burst.
1 Open
2 Touch a burst photo (which will be tagged with
Gallery.
), then touch .
3 Swipe through the burst photos, select the ones you want to keep, then touch and
follow the onscreen instructions.
4 To delete the whole burst photo, touch and hold to select the photo, then touch .
Take Timed Photos
The camera timer allows you to set a time delay so you can get into position after you have
touched the shutter button.
1 Open
2 Go to
Camera.
> Timer and select a delay option.
57
Camera and Gallery
3 Return to the viewnder and touch the shutter button. Your device will take a photo when
the countdown ends.
Use Audio Control to Take Photos
You can use your voice to take photos without having to touch the shutter button.
1 Open
2 Go to
Camera.
> Audio control, enable Audio control, and select an audio control option.
3 Go back to the viewnder, then say your command to take a photo.
Shoot in Portrait, Night, and Wide Aperture Modes
Shoot in Portrait, Night, and Wide Aperture Modes
Use Portrait Mode to Shoot Portraits
Portrait mode lets you apply beauty and lighting eects to your photos to shoot stunning
portraits.
1 Open Camera and select Portrait mode.
58
Camera and Gallery
2 Frame your subject within the viewnder.
To take a sele, touch .
3 You can then:
•Enable beauty eect: Touch and drag the slider to adjust beauty settings. A larger
value will produce a more pronounced beauty eect.
To disable the beauty eect, drag the setting to its lowest value, or touch .
•Set lighting eect: Touch and select an eect to your liking.
4 Touch to take a photo.
Take Night Shots
Night mode solves the issues caused by low light and night shooting to give your photos
sharper details and brighter colours.
You can also use Night mode when shooting backlit subjects and scenes with owing water,
such as waterfalls, to create a better contrast or a smooth, silky water eect.
1 Open Camera and select Night mode.
59
Camera and Gallery
2 If you are using the rear camera, touch on the viewnder to adjust the ISO sensitivity
or to adjust the shutter speed.
3 Keep your device steady and touch .
4 Your device will adjust the exposure time based on the ambient brightness. Keep your
device steady.
Do not stop shooting before the countdown nishes or your photos may come out blurry.
Use the Front Camera to Take Night Portraits
To take a sele at night or when there is not enough light, you can use the front camera in
Night mode.
In a dim environment, you can turn on the ash to get an illuminated photo of your face.
1 Open
2 Touch
•Touch the ash icon at the top.
This allows you to select
•Touch and adjust the beauty level.
Camera and select Night mode.
to switch to the front camera. Then you can:
(Auto), (O), or (Always on).
3 Keep your device steady and touch .
Shoot Wide Aperture Photos and Videos
Wide aperture mode allows you to shoot photos and videos where the background is blurred
while your subject remains in sharp focus.
60
Camera and Gallery
1 Open Camera and select Aperture mode.
2 Touch where you want to focus. For best results, your device needs to be within 2 meters
(about 7 ft.) of your subject.
3 Touch in the viewnder and drag the slider to adjust aperture settings. A smaller
aperture value will create a more blurred background.
4 Touch the shutter button to shoot a photo or video. When recording, touch the viewnder
to adjust the focus.
Edit Background Blur in Wide Aperture Photos
You can adjust the focus and background blur after you've taken a wide aperture photo.
1 Go to Gallery > Albums > Camera.
2 Touch a photo tagged with , then touch at the top of the photo.
3 Follow the instructions to touch the photo to re-focus. Drag the slider at the bottom to
adjust the aperture.
4 Touch to save the settings.
Master AI
61
Camera and Gallery
Master AI
Master AI is a pre-installed camera feature that helps you take better photos by intelligently
identifying objects and scenes and optimising the camera settings accordingly.
Master AI is able to identify a variety of scenes, such as stages, beaches, blue skies, greenery,
and text. It only works with the rear camera.
1 Open Camera and select Photo mode.
2 Touch
to ensure that Master AI is enabled.
3 Frame the subject in the viewnder. Once Master AI identies what you are shooting, it
will automatically recommend a mode (such as portrait, greenery, or text).
4 To disable the recommended mode, touch
disable Master AI.
Use Moon Mode
next to the mode text or touch to
62
Camera and Gallery
1 Open Camera and select Photo mode.
2 Touch
to ensure that Master AI is enabled.
3 Aim the camera at the moon and spread your ngers on the viewnder to adjust the
zoom to 10x or more.
When your device detects the moon, it will automatically enter Moon mode.
4 Touch
Moon mode can only identify the moon if it is at least half full. Moon mode may not be
triggered if the moon is shrouded by clouds.
to take a photo.
Zoom to Take Photos
Take Photos with Various Zoom Settings
The zoom capabilities of your device's camera allow you to capture more of a scene, or
distant vistas.
Take Wide-Angle Photos
63
Camera and Gallery
1 Open Camera and select Photo mode.
2 Touch to ensure that Master AI is enabled.
3 Aim the camera at the object you want to take a photo of. The camera will automatically
recommend Wide mode if it detects a building. Touch Wide to have a wider angle of
view.
You can also drag the zoom slider in the viewnder, or pinch in or out to adjust the zoom
level. A smaller value will result in a wider angle of view.
4 Touch to take a photo.
Take Photos from Far Away
1 Open
Camera and select Photo mode.
2 Aim the camera at the distant object you want to take a photo of. Drag the zoom slider,
or pinch in or out to adjust the zoom level.
3 In the viewnder, touch where you want to focus. When the camera is in focus, touch .
Super Macro
Super Macro
Super macro mode makes it easier to shoot close-ups of small objects, such as dew drops
and leaves, as well as other everyday objects, to bring out details easily missed by the naked
eye.
64
Camera and Gallery
1 Open Camera, then enter Super macro mode using either of the following methods:
•Automatic: Move your camera close to the subject and hold your device steady. When
your camera is close enough, it will automatically focus. If is enabled, the screen
will display Super macro.
If it is not displayed, keep a distance of 2.5–10.0 cm (about 1.0–3.9 in) from the
subject.
•Manual: In the viewnder, drag the zoom slider to lower than 1x, or go to Camera >
More to switch to Super macro.
2 Touch to take a photo.
Take Panoramic Photos
Take Panoramic Photos
Add breadth to your landscape or group photos with the Panorama feature. The camera
takes multiple photos of objects within your eld of view and stitches them together into a
single panoramic photo.
65
Use the Rear Camera to Take Panoramic Photos
1 Go to Camera > More and select Panorama mode.
2 Touch at the bottom of the viewnder to set the pan direction.
Camera and Gallery
3 Point the camera at your starting point, then touch
to start shooting.
4 Slowly move the camera in the direction of the arrow displayed on the screen. Keep your
device steady and the arrow on the centre line the entire time.
5 Touch when you are nished.
Use the Front Camera to Take Panoramic Seles
1 In Panorama mode, touch to switch to the front camera.
2 Point the camera at the centre of your shot, then touch to take the rst photo.
3 Turn the camera to the left and right slowly as instructed. When the two frames on the
viewnder overlap, the camera will automatically take the second and third photos.
After the three photos are taken, the camera will automatically combine them into a
panoramic photo.
Take Black and White Photos
Take Black and White Photos
Black and white photography removes distracting colours to help you focus more on form,
shape, and texture.
1 Open
Camera.
2 Go to More > Monochrome and select one of the following modes based on your subject
and scene:
•Normal: This mode suits all kinds of subjects.
•Aperture: This mode blurs the background and lends greater emphasis to the subject.
•Portrait: This mode blurs the background and lets you adjust the beauty
•Pro: This mode allows you to adjust the camera settings, including the metering mode,
sensitivity, and shutter speed.
3 Touch
to take a photo.
eect.
AR Lens
66
Camera and Gallery
AR Lens
Use AR lens to make your photos fun and stand out.
Use 3D Qmoji to Create Your Own Qmojis
1 Go to Camera > More and select AR lens.
2 Touch 3D Qmoji and select an animated Qmoji. The Qmoji will then mimic and act out
your facial expressions accordingly.
3 Touch to enable or disable the background.
4 Touch to enable Qmoji, then look straight at the front camera.
5 Touch and hold
to start recording.
6 After the recording is complete, add text or directly save the Qmoji. The Qmoji will be
saved to Gallery in GIF format.
Use 3D Qmoji to Record Videos
1 Touch 3D Qmoji and select an animated Qmoji. The Qmoji will then mimic and act out
your facial expressions accordingly.
67
2 Touch to enable or disable the background.
3 Touch to disable Qmoji, then look straight at the front camera.
Camera and Gallery
4 Touch
to start recording
5 Touch to nish recording.
Light Painting
Light Painting
Light painting helps you capture light trails by allowing the shutter to stay open for a longer
time. No manual aperture and shutter adjustment is involved.
Just choose from the available options depending on the subjects and light conditions. To
reduce camera shake, a tripod is recommended to steady your device.
Capture Car Light Trails in Trac Trails Mode
Trac trails mode lets you create artistic photos of car tail lights at night.
68
Camera and Gallery
1 Go to Camera > More > Light painting > Trac trails.
2 Find a spot where you'll see the light trails created by cars from a distance. Ensure that
car headlights do not point directly at the camera, as this can overexpose the image.
3 Touch to start shooting. Observe the shot in the viewnder. When the exposure is just
right, touch
Capture Light Drawings in Light Grati Mode
Light grati lets you create patterns or write words by moving a light source in front of the
camera.
to nish shooting.
1 Go to Camera > More > Light painting > Light grati.
2 In a dark environment without distracting light sources, move a suitably bright light
source of an appropriate colour, such as a small torch or glow stick, in front of the
camera. Avoid exaggerated body movement as this may aect the shooting results.
3 Touch to start shooting. Observe the shot in the viewnder. When the exposure is just
right, touch to nish shooting.
Capture Rivers and Waterfalls in Silky Water Mode
Silky water lets you capture silky smooth photographs of waterfalls and rivers.
1 Go to
Camera > More > Light painting > Silky water.
2 This feature works best when taking photos of a stream or waterfall where the water is
owing heavily.
3 Touch to start shooting. Observe the shot in the viewnder. When the exposure is just
right, touch to nish shooting.
Capture the Beauty of the Stars in Star Track Mode
Star track lets you use your camera to capture the movement of the stars in the night sky.
1 Go to
Camera > More > Light painting > Star trails.
2 For best results, choose a clear night in a location free of light pollution and with an
unobstructed view of the sky.
3 Touch to start shooting. Observe the shot in the viewnder. When the exposure is just
right, touch to nish shooting.
Take HDR Photos
69
Camera and Gallery
Take HDR Photos
When shooting photos with backlighting or a high light contrast, High Dynamic Range (HDR)
mode can help you improve light and shadow eects in your photos, giving your photos
sharper details.
Use HDR with the Rear Camera
1 Go to Camera > More and select HDR.
2 Steady your device, with the help of a tripod if necessary.
3 Touch to take a photo.
Moving Pictures
Moving Pictures
Moving pictures capture a second of movement and sound before you touch the shutter
button, and a second after.
Take Moving Pictures
Go to
Play Moving Pictures
Moving pictures are saved in JPG format in Gallery.
Go to Gallery > Albums > Camera, touch a moving picture, then touch at the top of
the picture to view it.
The moving picture will automatically stop after a complete playback. You can also touch the
screen to stop the playback.
Share Moving Pictures
You can share moving pictures with Huawei or Honor devices using various methods, such as
Camera > More > Moving picture and touch to take a photo.
Wi-Fi Direct, Bluetooth, or Huawei Share.
Go to
want to share, then touch to share them.
If you share moving pictures to third-party apps or incompatible devices, moving pictures will
be displayed as static images.
Gallery > Albums > Camera, touch and hold to select the moving pictures you
Add Stickers to Photos
70
Camera and Gallery
Add Stickers to Photos
Add a watermark, such as time, location, weather, or mood, to spice up your photo.
1 Go to Camera > More > Stickers.
If this mode is not there, touch and then download Stickers.
2 Touch
viewnder.
and select a watermark. The selected watermark will be displayed in the
3 Drag the watermark to change its position. You can also edit the text of some types of
watermarks.
4 Touch
to take a photo.
Documents Mode
Documents Mode
Images shot at an angle always
take a perfectly straight photo of a document, use Documents mode.
The camera will automatically adjust skewed images shot in Documents mode.
Shoot Photos in Documents Mode
1 Go to Camera > More, then touch Documents.
suer from the problem of perspective. If you aren't able to
If the option is not present, touch , then download Documents.
2 Frame the document you want to shoot within the
viewnder, then touch .
3 The camera will automatically identify the text area within the viewnder and unskew the
image.
Adjust the Text Area
If you nd the skew correction provided by Documents mode unsatisfactory, you can also
manually adjust the text area.
This is only available for photos taken in Documents mode.
1 Go to Gallery > Albums > Camera, then touch the photo you wish to adjust.
2 Touch above the photo.
3 Drag the four corners to customise the correction area. Then touch
.
Underwater Mode
71
Camera and Gallery
Underwater Mode
• Before placing your device in water, make sure that it is in a waterproof case and that
the case is closed tight.
• Don't keep your device underwater for extended periods of time.
1 Go to Camera > More, then enable Underwater.
2 Now you can:
•Press the Volume up button to take a photo.
•Press and hold the Volume up button to take a burst photo.
•Press the Volume down button to record a video. During recording, press the Volume
up button to pause and the Volume down button to stop.
•Press the Power button to turn
camera.
o the screen, and press it again to activate the
3 When you are nished, follow the onscreen instructions to exit the camera.
Take High-Resolution Photos
Take High-Resolution Photos
Take high-resolution photos if you would like to print them later or display them on a large
screen.
1 Go to Camera > More, then touch High-res.
2 Frame your subject within the viewnder, then touch where you want to focus.
High-res does not allow you to zoom in or out, or adjust the aspect ratio.
3 Touch to take a photo.
It may take longer to take a photo in High-res mode. Keep your device steady when the
photo is being taken.
72
Camera and Gallery
Pro Mode
Pro Mode
Pro mode gives you full control over focus mode, metering, exposure compensation, and
more when shooting, so that the photos and videos will look more professional.
Some of the above settings are not available when you shoot videos in Pro mode.
1 Open Camera and select Pro mode.
2 Customise camera settings to shoot unique and professional-looking photos. You can also
shoot high-quality videos by touching .
•Adjust the metering mode: Touch M and select a metering mode.
73
Camera and Gallery
Metering ModeDescription
Measures the light in the whole frame. Applicable
Matrix
when shooting natural landscapes.
Places more emphasis on light levels at the centre of
Centre
the screen. Applicable when shooting portraits.
Concentrates on the light in a small area of the
Spot
•Adjust the ISO sensitivity: Touch ISO and drag the slider.
screen, such as the subject's eyes.
In low-light conditions, increase the ISO sensitivity. In well-lit environments, lower the
ISO sensitivity to avoid image noise.
•Adjust the shutter speed: Touch S and drag the slider.
The shutter speed aects the amount of light allowed to enter the camera lens. When
you are shooting stationary scenes or portraits, lower the shutter speed. When you are
shooting moving scenes or objects, increase the shutter speed.
•Adjust EV exposure compensation: Touch EV and drag the slider.
Increase the EV value in low-light conditions and lower the value in well-lit
environments.
•Adjust the focus: Touch AF and select a focus mode.
Focusing ModeApplicable Scenario
AF-S (single)Stationary subjects
AF-C (continuous)Moving subjects
MF (manual)Touch the subject on which you want to focus.
•Adjust the colour cast: Touch WB and select a mode.
When shooting in bright sunlight, select . In low-light environments, select .
Touch to adjust the colour temperature.
•Use high resolution: Touch
to take a photo with the highest possible resolution.
When this feature is enabled, the camera does not allow you to zoom in or out.
•Save RAW format photos: RAW format records more detail and allows you to have a
wider range of post-processing options. On the Pro mode screen, touch to enable
RAW.
Afterwards, photos that you take will be saved in RAW and standard formats. The RAW
format photos will be saved to the RAW photo album in Gallery.
RAW format photos take up more storage space than standard format photos. Make
sure that your device has sucient storage space.
74
Camera and Gallery
•Enable AF assist light: For better focus in low-light environments, touch to enable
AF assist light.
3 Touch the shutter button to shoot a photo or video.
Record Videos
Record Videos
1 Open
Camera and select Video mode.
2 Adjust the following settings:
•Zoom in or out: On the viewnder, pinch or spread two ngers, or drag the zoom
slider.
•Focus: Touch the location you want to focus on. Touch and hold the viewnder to lock
the exposure and focus.
•Turn the
turn it o.
•Adjust the beauty eect: Touch and drag the slider to adjust beauty settings.
•Adjust the video resolution and frame rate: Go to > Video resolution and select
the desired resolution. A higher resolution will result in a higher quality video with a
larger le size.
Touch Frame rate to select a frame rate.
ash on or o: Touch , then touch to keep the ash on, or to
•Select a video format that saves on storage space: Touch and enable Ecient
video format.
When this feature is enabled, your device will use a video format that takes up less
storage space. However, this may result in other devices being unable to play the video.
Please exercise caution when selecting this option.
3 Touch to start recording.
While recording, touch and hold or to smoothly zoom in or out.
Touch
to take a photo while recording.
4 Touch to pause and to end the recording.
AI Movie Eects
75
Camera and Gallery
AI Movie Eects
Use AI movie eects to add unique artistic eects to your videos without the need for post-
processing.
1 Open Camera and select Video mode.
2 Switch to the rear camera, touch
, and select a special eect.
3 Go to > Video resolution and select 21:9 to give your video a cinematic character.
4 Touch to start recording.
While recording, touch to take a photo with the selected special eect.
5 Touch to end the recording.
4K HD Videos
4K HD Videos
Both the front and rear cameras of your device support 4K Ultra HD video recording.
76
Camera and Gallery
1 Open Camera and select Video mode.
2 Go to > Video resolution and select [16:9] 4K.
Beauty mode and non-Leica lters do not support 4K recording, and will be automatically
disabled when you select the 4K resolution.
3 Return to the Video screen and touch to record a video.
A higher resolution will result in a higher quality video, but will also take up more
storage space.
Slow-Mo Recording
Slow-Mo Recording
Use Slow-mo mode to capture
based on how slow you want your footage to appear.
• 32x super slow-mo: When the camera detects a moving object in the viewnder, it will
record an epic, super slow motion video. This mode is suitable for shooting super high
speed motions, such as bubble popping and water splashing.
• 4x or 8x slow-mo: You can customise the overall shooting length and the length of the
slow-mo portion. This mode is suitable for shooting breakdowns of fast movements, such
as diving and kicking a football.
eeting moments in detail. Adjust the slow motion speed
Shoot Slow-Mo Videos at 32x
1 Go to Camera > More, then touch Slow-mo.
2 Ensure that the speed is 32X and motion detection is enabled (
top of the screen).
3 Frame your subject in the
detects a moving object in the viewnder, it will record an epic, super slow motion video.
viewnder, then touch to start recording. When the camera
should display at the
77
Camera and Gallery
To record a video manually, touch to disable motion detection, then touch to start
recording.
Shoot Slow-Mo Videos
1 Go to Camera > More, then touch Slow-mo.
2 Touch and select a speed.
3 Touch
to start recording.
4 Touch to end the recording.
Adjust the Slow-Mo Portion in Slow-Mo Videos
The length of the slow-mo portion in slow motion videos can be adjusted.
This feature is only available for slow motion videos recorded at 4x or 8x.
1 Go to Gallery > Albums > Camera and select a slow motion video.
2 Touch to play the video. During playback, touch the video to bring up the editing
area.
3 Drag the slider to adjust the portion you want to be played back in slow motion.
4 Touch
5 When you are
to adjust the volume of the background music and the brightness.
nished, go to > Save slow-mo le to save your edits.
Time-Lapse Photography
Time-Lapse Photography
You can use Time-lapse to capture images slowly over several minutes or even hours, then
condense them into a short video. This allows you to capture the beauty of change –
blooming owers, drifting clouds, and more.
78
Camera and Gallery
1 Go to Camera > More, then touch Time-lapse.
2 Place your device in position. To reduce camera shake, use a tripod to steady your device.
3 By default, Auto mode is enabled. To manually adjust camera settings, touch Auto. Then
you can:
•Touch
blooming owers at 1800x.
A video recorded at a higher speed will play faster.
•Touch to set the recording duration.
•Touch to adjust the metering mode, shutter speed, ISO, and more.
4 Touch
recording.
The recorded video is automatically saved to Gallery.
to adjust the recording speed. For example, record trac trails at 15x or
to start recording. If no recording duration is set, touch to end the
Dual-View Mode
Dual-View Mode
The Dual-view feature splits the recording screen into two views, allowing you to watch the
regular view side by side with a zoomed-in view.
79
Camera and Gallery
1 Go to Camera > More, then touch Dual-view.
2 Frame your subject in the viewnder, then touch to start recording.
The regular view and the zoomed-in view display side by side on the screen, with the
zoomed-in area being the centre of the regular view. You can adjust the zoom level by
pinching or spreading two ngers on the zoomed-in view.
3 Touch to end the recording.
Leica Colors
Leica Colours
1 Open Camera and switch to the rear camera.
2 Touch
smooth.
at the top of the viewnder, then select Leica standard, Leica vivid, or Leica
3 Touch the shutter button to shoot a photo or video.
Not all camera modes support Leica colours.
Filters
Filters
1 Open Camera and select Photo or Video mode.
2 Touch
Some devices do not have the icon.
or and select a lter.
3 Touch the shutter button to shoot a photo or video.
80
Camera and Gallery
Use the Camera with Other Devices
Use a Bluetooth Snorkeling Case to Take Photos Underwater
When using a dedicated Bluetooth snorkeling case, you can quickly launch the camera when
you are swimming or diving, and easily take photos, zoom in or out, and switch between
modes.
• Purchase a dedicated Bluetooth snorkeling case from an ocial channel.
• Before using your device underwater, refer to the snorkeling case user guide to ensure
that the case is fully sealed.
• Refer to the depth and duration limits of the snorkeling case. Do not use your device in
deep water for an extended period of time.
1 Swipe down from the status bar to open the notication panel, then touch to enable
Bluetooth on your device.
2 Refer to the snorkeling case user guide to enable Bluetooth on the case, and place the
case close to your device.
3 Your device will automatically detect the snorkeling case and prompt you to connect to it.
4 After the connection is set up, install the snorkeling case according to the instructions and
ensure that the case is airtight. Double-press the Power button to enter Underwater
mode. You can then:
•Take a photo: Press the shutter button.
•Take a burst photo: Press and hold the shutter button.
•Zoom: Move the zoom joystick.
•Switch between photo and video modes: Double-press the Power button.
•Pause/Resume recording: Press the shutter button when recording.
81
Camera and Gallery
•End recording: Double-press the Power button.
•Switch between the front and rear cameras: Press the Power button three times.
•Turn the screen on or
•Disable Bluetooth on the snorkeling case: Press and hold the Power button for 2
seconds.
o: Press the Power button.
5 After you have nished shooting, take your device out of the water and follow the
onscreen instructions to exit Underwater mode.
Adjust Camera Settings
Adjust Camera Settings
You can adjust the camera settings to take photos and videos more quickly.
The following features may not be available in some camera modes.
Adjust the Aspect Ratio
1 Open Camera and touch to access the Settings screen.
2 Touch Aspect ratio to select an aspect ratio (for example, 1:1 or 4:3).
This feature is not available in some modes.
Enable Location Tag
Enable Location tag to tag your location in photos and videos.
Swipe up on a photo or video in Gallery to view its shooting location.
Add Device Watermarks to Photos
Enable Add watermark. Photos and videos shot with the rear camera will have a device
watermark added.
Use the Assistive Grid to Compose Your Photos
Use the assistive grid to help you line up the perfect shot.
82
Camera and Gallery
1 Go to Camera > .
2 Enable Assistive grid.
3 Grid lines will appear in the viewnder. Place the subject of your photo at one of the
intersecting points, then touch the shutter button.
Enable Mirror Reection
When using the front camera, touch to enable or disable Mirror reection.
Mute the Shutter Sound
Enable Mute as needed.
Capture Smiles
Enable Capture smiles. The camera will take a photo automatically when it detects a smile
in the viewnder.
Use the Horizontal Level for Better Compositions
1 Touch
to access the Settings screen.
2 Enable Horizontal level to display a horizontal guiding line on the viewnder.
When the dotted line overlaps with the solid line, it indicates that the camera is parallel
with the horizontal level.
Manage Gallery
View Photos and Videos
In Gallery, you can view, edit, and share your photos and videos, as well as browse the clips
automatically generated from them.
83
Camera and Gallery
View by Shooting Time
Your photos and videos are stored in Gallery and can be viewed by time, location,
category, or album.
On the Photos tab, pinch two ngers on the screen to switch to the monthly view and spread
them to enter the daily view.
View by Album
You can view photos and videos by album on the Albums tab.
Some photos and videos are stored in default albums. For example, videos recorded with the
camera are saved in the Camera album. Screenshots and screen recordings are saved in the
Screenshots album.
84
Camera and Gallery
View by Category
Gallery intelligently sorts photos into categories, allowing you to quickly sift through large
albums by category.
Touch a category album on the Discover tab (such as food, portrait, or scenery) to view
photos in that album.
View Details About Photos and Videos
1 Touch a photo or video to view it in Full screen mode. Touch the screen again to hide the
menu.
2 In Full screen mode, you can check the following:
•Basic information: Swipe up on the photo or video to view basic information.
•Shooting details: Touch
storage path, resolution, and size.
and view shooting details in the popup box, including the
Search for Photos
Quickly locate a photo by searching with keywords in Gallery.
1 Open Gallery, then touch the search box.
85
Camera and Gallery
2 Enter a keyword (such as "food", "scenery", or "ower").
3 Photos related to that keyword will be displayed. Touch a suggested keyword or enter
more keywords for more precise results.
Edit Photos and Videos
Gallery oers a wide range of editing features for photos and videos.
Basic Editing
1 Open
Gallery, touch the thumbnail of the photo you want to edit, then touch Edit to
access the editing features.
•Crop: Touch and drag the grid or its corners to select which part you want to keep.
You can also select a xed ratio and drag the corners of the grid to crop the photo.
•Rotate: Touch and drag the angle wheel to the desired orientation.
You can also touch Rotate to rotate your photo or Mirror to ip it.
•Add ltereects: Touch to select a lter.
86
Camera and Gallery
•Adjust photo eects: Touch to adjust the brightness, contrast, saturation, and
other qualities of the photo.
•Other: Touch to edit the photo in other ways, such as colour splash, blur, doodle,
or adding a text element.
2 Touch
Add Stickers to Photos
to save your edits and touch to save the photo.
1 Touch a photo, then go to Edit > > Stickers.
2 Select a type of sticker, such as Time, Location, Weather, or Mood.
3 Select a sticker and drag it to change its position. You can also edit the text of some types
of stickers.
4 Touch to save your edits and touch to save the photo.
Pixelate Photos
1 Touch a photo, then go to Edit >
> Mosaic.
2 Select a mosaic style and size to cover parts of the photo.
3 To remove the mosaic, touch Eraser and wipe it o the photo.
4 Touch to save your edits and touch to save the photo.
Rename Photos
1 In Gallery, touch the photo thumbnail you want to rename.
2 Go to
> Rename and enter a new name.
3 Touch OK.
Edit Videos
87
Camera and Gallery
1 Go to Gallery > Albums > Videos and touch the video you want to edit.
2 Touch
•Select a video template: Touch
•Crop the video: Touch , then drag the slider at both ends of the video clip to select
which part you want to keep. Touch to preview the cropped video.
•Adjust the frame and video resolution: Touch , then touch Frame to select a frame,
and Resolution to select a video resolution.
•Edit background music: Touch and choose from preset background music or your
locally saved music.
. Then you can:
.
A higher resolution will result in a higher quality video, but will also take up more
storage space.
To turn
•Add lter eects: Touch to select a lter. Drag the slider to adjust the lter eect.
o the original video sounds, touch .
88
Camera and Gallery
•Edit the intro and outro: Touch to select an intro and outro. After the preview is
complete, touch the screen to edit the text content and style of the intro.
3 When you are nished, touch to export the video.
The edited videos are saved in the Video Editor album, and the original video is left
unchanged.
Share Photos and Videos
There are several ways to share photos and videos from Gallery.
1 Open
Gallery.
2 Use either of the following methods:
•Share a single photo or video: Touch the photo or video, then touch .
•Share multiple photos or videos: In an album, touch and hold to select multiple photos
and videos, then touch
.
Manage Gallery
Organise photos and videos into albums to easily sift through them.
Add Albums
1 Open Gallery, then touch Albums.
2 Touch Add album, then name the album.
3 Touch OK.
4 Select the photos or videos you want to add.
Move Photos and Videos
1 Open an album, then touch and hold to select the photos and videos you want to move.
2 Touch
> Move to select the desired album.
3 Once the items are moved, they will no longer be in their original album.
The All photos and Videos albums show all photos and videos stored on your device.
Moving items across albums will not aect the view in these albums.
Delete Photos and Videos
Touch and hold to select the items you want to delete, then go to > Delete.
The All photos, Videos, and Camera albums cannot be deleted.
Deleted photos and videos will be temporarily moved to the Recently deleted album before
being permanently deleted after 30 days.
89
Camera and Gallery
To permanently delete a photo or video manually, touch and hold its thumbnail in the
Recently deleted album, then go to > Delete.
Recover Deleted Photos and Videos
In the Recently deleted album, touch and hold to select the items you want to recover, then
touch to restore them to their original albums.
If the original album has been deleted, a new one will be created.
Add Photos and Videos to Favorites
Open a photo or video, then touch .
The item will appear in both its original album and the My favourites album.
Hide Albums
System albums such as Camera, Videos, My favourites, and Screenshots cannot be
hidden.
From the Albums tab, go to > Hide albums and toggle the switches on for albums that
you want to hide.
90
Camera and Gallery
Hidden albums and the photos and videos in them are hidden from view in Gallery.
Block Albums
To prevent third-party app albums from displaying in Gallery, block these albums.
1 On the Albums tab, touch Others.
2 Touch an album, and if is displayed at the top, go to > Block.
Move photos and videos you want to block to blocked albums.
Blocked albums cannot be viewed in any apps other than Files.
3 To unblock an album, go to Others, touch View blocked albums, then touch Unblock
next to the album.
Only some albums in Others can be blocked.
Smart Photo Categorisation
Smart Photo Categorisation
Gallery automatically sorts your photos into categories such as portraits, locations, scenery,
and food, so you can quickly nd what you're looking for.
91
Camera and Gallery
Open Gallery, then touch the Discover tab to view your photos organised into
categories.
To remove a photo from an album, touch and hold to select the photo, then touch (or
for portraits).
Not all photos can be removed from the category albums.
View and Set People Albums
Once you have taken a sucient number of photos, Gallery will automatically create People
albums of individuals or groups by identifying faces in your photos. This will happen when
your device is charging and the screen is o.
You can name your People albums and set the relationship of individuals with you.
Group photo albums require a specic number of photos that contain 2 to 10 faces that have
already been named in People albums.
1 Go to Gallery > Discover and view the generated People albums.
2 Touch an album, go to > Edit > Add name, then set the name and relationship (such
as Baby or Mom).
Once you have nished, you can nd a People album by entering the name or relationship in
the search bar.
Huawei Vlog Editor
Huawei Vlog Editor
The Huawei Vlog editor automatically creates Huawei Vlogs, such as Spotlight Reels,
Highlights videos, and People albums, with added background music from your photos and
videos.
You can also select photos and videos yourself to create your own Huawei Vlogs.
Either way, you can edit and share your Huawei Vlogs at the touch of a
nger.
Create a Video Clip with Photos and Videos
92
Camera and Gallery
1 Go to Gallery > Photos.
2 Touch and hold to select photos and videos, then go to
You can then:
•Select a video template: Touch
•Edit video materials: Touch
video materials.
If you have selected a video, you can also touch
drag the sliders at both ends to trim the video.
•Edit background music: Touch and choose from preset background music or music
les on your device.
•Add lter eects: Touch to select a lter. Drag the slider to adjust the lter eect.
.
to adjust the video frame or length, or add or delete
> Video to create a video clip.
on the video timeline, and then
•Edit the intro and outro: Touch to select an intro and outro. After the preview is
complete, touch the intro text to edit its content and style.
93
Camera and Gallery
3 When you are nished, touch to save the video and follow the onscreen instructions
to export it.
View Spotlight Reels
Spotlight Reel analyses your videos to create highlight clips of people and objects in them
and presents them to you with background music.
1 Go to Gallery > Albums > Videos.
2 Touch a video, then swipe up on the video. Touch a person's face or Best cut to view the
created Spotlight Reel.
If a clip has not yet been generated, touch GET STARTED to create one.
3 During playback, touch the video to edit the template, background music, lter, intro and
outro, and more.
This feature works automatically when your device is charging and the screen is o. It
only works on local videos between 10 seconds and 3 minutes long.
Share Spotlight Reels
1 Go to Gallery > Albums > Video Editor, where you'll
nd all your exported videos.
2 Touch and hold to select the videos you want to share, then touch .
94
Huawei Vlogs
People Album Videos
Gallery automatically creates People albums by identifying faces in photos.
View, edit, and share the videos generated in these People albums.
View Huawei Vlogs
Camera and Gallery
1 Go to
Gallery > Discover and touch a people album.
2 Touch on the album cover.
Edit People Album Videos
Apply special eects,lters, and background music to make your videos stand out.
1 Touch to play the video. During playback, you can:
•Select a video template: Touch .
•Edit video clips: Touch to adjust the video frame or length, or add or delete video
clips.
•Edit background music: Touch
locally saved music.
•Add ltereects: Touch to select a lter. Drag the slider to adjust the ltereect.
and choose from preset background music or your
•Edit the intro and outro: Touch to select an intro and outro. After the preview is
complete, touch the intro text to edit its content and style.
2 When you are nished, touch to save the video and follow the onscreen instructions
to export it.
Share People Album Videos
The exported videos are saved in Gallery > Albums > Video Editor.
Touch and hold to select videos you would like to share, then touch .
Highlights
95
Camera and Gallery
Highlights
Gallery automatically creates Highlights albums from your best photos and videos based on
time, location, and theme information, and even generates a short video clip so you can
instantly relive the good times.
• To start using Highlights, go to Camera > and enable Location tag.
• Highlights albums are created automatically when your device is charging, the screen is
turned o, and the battery is at least 50% charged. This process may take some time.
Highlights albums will not be created if there are fewer than 10 photos or videos in Gallery.
View Highlights Videos
1 Go to Gallery > Highlights and touch an album.
2 Touch to play the video.
Edit Highlights Videos
1 When you are watching a Highlights video, touch the video to select a preset template at
the bottom of the screen.
2 To make even more customisations, you can:
96
Loading...
+ hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
