Huawei M635 User Guide

1 Copyright . . . . . . . . . . . . . . . . . . . . . . . . . . 1

2 Getting Started . . . . . . . . . . . . . . . . . . . . . . 4

Your Phone at a Glance . . . . . . . . . . . . . . . . . . . . . . . .4

Keys and Functions. . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Inserting the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Inserting the microSD Card . . . . . . . . . . . . . . . . . . . . .9

Charging the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Status Icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Enabling the Warning Tone Mode. . . . . . . . . . . . . . . .11

3 Text Entry . . . . . . . . . . . . . . . . . . . . . . . . . 12

Entering English . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

Entering Spanish. . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

Entering a Digit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

4 Voice Services. . . . . . . . . . . . . . . . . . . . . . 14

Making a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

Answering a Call. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

5 Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Adding a Contact . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

Searching for a Contact . . . . . . . . . . . . . . . . . . . . . . . 16

6 Messaging . . . . . . . . . . . . . . . . . . . . . . . . 17

Writing and Sending a Message . . . . . . . . . . . . . . . . .17

Reading a Message. . . . . . . . . . . . . . . . . . . . . . . . . . .17

7 @metro App Storesm . . . . . . . . . . . . . . . . . 18

Accessing @metro App Store. . . . . . . . . . . . . . . . . . . 18

Changing Your @metro App Store Settings . . . . . . . . 19

Using On-line Help . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

8 Media Applications . . . . . . . . . . . . . . . . . . 22

Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Music Player . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Playing a Video. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Picture Viewer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Recorder. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

9 Bluetooth® . . . . . . . . . . . . . . . . . . . . . . . . 27

Bluetooth®-based Data Transfer. . . . . . . . . . . . . . . . . 27

Using Bluetooth® Headset . . . . . . . . . . . . . . . . . . . . .27

10 Security . . . . . . . . . . . . . . . . . . . . . . . . . 29

Enabling/Disabling the Phone Lock. . . . . . . . . . . . . . . 29

Locking the Keypad . . . . . . . . . . . . . . . . . . . . . . . . . .29

11 TTY Operation . . . . . . . . . . . . . . . . . . . . . 30

Using the TTY Device . . . . . . . . . . . . . . . . . . . . . . . . .30

Setting the TTY Mode . . . . . . . . . . . . . . . . . . . . . . . . . 30

12 Troubleshooting . . . . . . . . . . . . . . . . . . . . 32

13 Warnings and Precautions. . . . . . . . . . . . . 34

14 Futurewei Technologies, Inc. Limited Warranty

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46

1 Copyright

Copyright © Huawei Technologies Co., Ltd. 2011. All rights reserved.

No part of this document may be reproduced or transmitted in any form or by any means without prior written consent of Huawei Technologies Co., Ltd.

The product described in this manual may include copyrighted software of Huawei Technologies Co., Ltd and possible licensors. Customers shall not in any manner reproduce, distribute, modify, decompile, disassemble, decrypt, extract, reverse engineer, lease, assign, or sublicense the said software, unless such restrictions are prohibited by applicable laws or such actions are approved by respective copyright holders under licenses.

Trademarks and Permissions

, HUAWEI, and are trademarks or registered trademarks of

Huawei Technologies Co., Ltd.

Other trademarks, product, service and company names mentioned are the property of their respective owners.

Notice

Some features of the product and its accessories described herein rely on the software installed, capacities and settings of local network, and may not be activated or may be limited by local network operators or network service providers, thus the descriptions herein may not exactly match the product or its accessories you purchase.

Huawei Technologies Co., Ltd reserves the right to change or modify any information or specifications contained in this manual without prior notice or obligation.

NO WARRANTY

THE CONTENTS OF THIS MANUAL ARE PROVIDED “AS IS”. EXCEPT AS REQUIRED BY APPLICABLE LAWS, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR CONTENTS OF THIS MANUAL.

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO CASE SHALL HUAWEI TECHNOLOGIES CO., LTD BE LIABLE FOR ANY SPECIAL, INCIDENTAL, INDIRECT, OR CONSEQUENTIAL

DAMAGES, OR LOST PROFITS, BUSINESS, REVENUE, DATA, GOODWILL OR ANTICIPATED SAVINGS.

Import and Export Regulations

Customers shall comply with all applicable export or import laws and regulations and will obtain all necessary governmental permits and licenses in order to export, re-export or import the product mentioned in this manual including the software and technical data therein.

2 Getting Started

Your Phone at a Glance

Please read the section "Warnings and Precautions" before using your phone for safety tips and precautions.

1 Earpiece 2 Screen

3 Microphone 4 Data/Charger Port

5 Volume key 6 Speaker

7 Camera 8 Headset jack

Keys and Functions

123 45678

1213

Send key

Left soft

key

Speaker

key

• Make or answer a call.

• Access call logs in standby mode.

• Select the option displayed in the lower left

• Access the main menu in standby mode.

Press and hold to turn on or off the speaker mode.

corner of the screen.

Confirm

key

Navigation

keys

Back key

Right soft

key

End key

Del key

Enter key

Lock key

Confirm a selection.

• Scroll through a menu.

• Access the corresponding functions in standby mode.

Press to go back to the previous screen.

Select the option displayed in the lower right corner of the screen.

• Power on or power off the phone by pressing and holding it.

• End or reject a call.

• Return to the standby mode.

Delete a character in editing mode or delete a selected item in an application.

In text input mode, press this key to enter a linefeed character.

In standby mode, press and hold to lock the keyboard.

Sym key

Space key

Caps key

Fn key

In text input mode, press to display the symbol list.

• In text input mode, press to input a space.

• In standby mode, press and hold to switch between the Vibration mode and the current profile mode.

In text input mode, press the key to switch between "abc/en" mode (lower case), "Abc/En" mode (capitalization of the first letter), and "ABC/EN" mode (upper case).

• In text input mode, press this key and another key to enter the upper character on the other key.

• In text input mode, press the Fn key for two consecutive times, and then press other keys to enter upper characters on the keys. Press the Fn key again to cancel this function.

Inserting the Battery

Inserting the microSD Card

Charging the Battery

Before charging the battery with the wall or car adapter, ensure that the battery is installed in your phone. Do not use a damaged battery or adapter.

1. Connect the adapter to a power outlet.

2. Connect the adapter to the charger connector of the phone. The phone begins charging. Charging starts and the charging icon is displayed in animation. When the charging icon animation stops, it indicates that your phone is fully charged.

3. When the phone is fully charged, disconnect the adapter from the phone and then from the power outlet.

Status Icons

Signal strength Roaming

Call in progress

The memory for messages(text messages or multimedia messages) is full.

New text message received

New emergency message received

Location on microSD card inserted

Alarm clock enabled Bluetooth on

Bluetooth headset connected

New multimedia message received

New voicemail message received

The phone is receiving date through Bluetooth

The phone is sending data through Bluetooth

Battery level

Battery charging

Ringing mode activated

Vibration mode activated

Headset connected - -

Music player playing in the background

Silence mode activated

Ringing and Vibration mode activated

Enabling the Warning Tone Mode

In standby mode, select Menu > Settings > Sound > Warning Tone > On to enable the warning tone mode.

When an error or warning message (for example, the message indicating the battery is fully charged, the battery temperature is too high, or the microSD card memory is full) is displayed on your phone, your phone will play a warning tone.

3 Text Entry

Entering English

When you turn Predictive input on, your phone supports smart text input methods; otherwise, only traditional text input methods are supported. To turn on or off Predictive input, select Menu >

Settings > Phone > Text Input Settings > Predictive Input.

Smart English Input Method

1. Based on the sequence of the word, press the key labeled with the desired letter. Then the phone predicts the commonly used words according to the numeric sequence of key presses.

2. Select the desired word, and press Confirm key or Space key to enter the word.

3. Press Sym key to display the symbol list. Then you can select and enter a symbol.

Note:

The indicator of the current input method is displayed in the upper right corner of the screen. You can press Lock key to change the input method.

Traditional English Input Method

The traditional text input method allows you to enter uppercase or lowercase English letters. You can press the key labeled with the desired letter.

• Press Sym key to display the symbol list. Then you can select

and enter a symbol.

• Press Space key enter a space.

Entering Spanish

You can enter Spanish words using Spanish text input methods. The traditional Spanish input method and the smart Spanish input method are similar to the traditional English input method and the smart English input method. For details, see "Entering English".

Entering a Digit

• In "123" input mode, press the key labeled with your desired

digit.

• In "Abc" and "En" input mode, press Fn key and then press a

number key.

• In any text input mode, except the "123" input mode, press and

hold a number key to enter the digit.

4 Voice Services

Making a Call

Dialing via Keypad

1. In standby mode, enter the phone number.

• To make an international call, press O/+ key to enter the

international long-distance code (+), and then enter the country code or region code, area code, and phone number in sequence.

• To dial an extension number, enter the phone number, press

P/@ key

to insert P or press T/( key to insert T, and then enter

the extension number.

2. Press Send key to dial the number.

3. Press End key or Select End to end the call.

Dialing via Contacts

Select Menu > Contacts, Select a contact, and press Send key to make a call.

Dialing via Call Log

Select Menu > Call Logs or press Send key to select the required number from call logs. Then press Send key to dial the number.

Answering a Call

When there is an incoming call, you can press Send key to answer it, press End key to reject it.

• If the any-key answer function is enabled, you can press any key

except End key and Right soft key to answer an incoming call.

• If the headset auto-answer function is enabled, when the

headset is connected to the phone, the incoming call is answered automatically.
