Huawei H1621 User Manual

User Guide

H1621

Model: H1621

Contents

Unboxing your Phone........................................... 1

Getting to know your phone ....................................... 1

Inserting a SIM card and microSD card ........................1

Charging your phone................................................... 2

Turning your phone on and off.................................... 4

First Use and Initial Setup..................................... 5

Initial setup.................................................................. 5

Connecting to the Internet .......................................... 6

Configuring your fingerprint ID.................................... 7

Getting Started..................................................... 8

Locking and unlocking the screen................................ 8

Touchscreen gestures ..................................................8

Status and notification icons...................................... 10

Home screen ............................................................. 12

Taking a screenshot................................................... 16

Notifications .............................................................. 16

Using fingerprint recognition..................................... 18

Personalizing your phone........................................... 21

Entering text.............................................................. 23

Calls and Contacts.............................................. 25

Making calls .............................................................. 25

Answering or rejecting a call...................................... 28

Functions available during a call................................. 29

Answering a third-party call....................................... 30

Making a conference call........................................... 30

Viewing the call log ................................................... 31

Call settings............................................................... 31

Creating a contact ..................................................... 33

Adding contact details quickly ................................... 33

Importing or exporting contacts ................................ 34

Managing contacts.................................................... 36

Finding a contact....................................................... 38

Viewing contacts from different accounts.................. 39

Adding a contact to your favorites............................. 39

Contact groups..........................................................40

Messaging and Email.......................................... 42

Sending a message.................................................... 42

Replying to a message............................................... 43

Searching for messages .............................................43

i

Deleting threads.........................................................44

Managing messages...................................................44

Adding an email account ...........................................45

Sending an email .......................................................46

Checking your emails .................................................47

Account settings ........................................................48

Camera and gallery ............................................ 49

Accessing the viewfinder............................................49

Taking a photo...........................................................49

Launching the camera from the gallery...................... 50

Capture modes ..........................................................50

Shooting a video........................................................54

Camera settings .........................................................54

Gallery .......................................................................56

Scanning a QR code...................................................58

Music and Video................................................. 60

Adding songs to your phone......................................60

Searching for local music............................................60

Listening to music ......................................................60

Setting a song as the ringtone ...................................62

Playing a video...........................................................62

Accessing the Internet........................................ 63

Connecting to the Internet using mobile data ............63

Connecting to the Internet using Wi-Fi.......................63

Transferring data using Bluetooth ..............................66

Settings.............................................................. 68

Enabling location access.............................................68

Configuring the display settings .................................68

Sound settings ...........................................................70

Changing the screen unlock method..........................71

Airplane mode ...........................................................72

Setting your SIM card PIN ..........................................73

Setting up an account................................................74

Setting the date and time...........................................75

Changing the system language ..................................75

Accessibility Features ......................................... 76

About your phone's accessibility features...................76

TalkBack ....................................................................76

Magnification gestures...............................................79

Using the power button to end a call.........................80

Adjusting the screen response time............................80

Color correction.........................................................80

ii

Appendix............................................................81

About this guide........................................................ 81

Personal Information and Data Security..................... 81

Legal Notice .............................................................. 83

iii

iv

Unboxing your Phone

Micro USB
port

Front camera

Headset jack

Power
button

Volume
button

SIM/

microSD

card tray

Status
indicator

Earpiece

Light sensor

Getting to know your phone

Do not cover the light sensor, as this will affect

some of the phone's functions. Ensure that you

use a screen protector that has a purpose-built

hole for the light sensor.

Inserting a SIM card and

microSD card

Tips:

•

Your phone only supports nano-SIM cards. Contact

your carrier for a new or replacement nano-SIM card.

•

Only use standard nano-SIM cards to avoid

damaging the SIM card tray.

1

•

NJDSP4%

/BOP4*.

Ensure that the card is in the correct position and

keep the card tray level when inserting it into your

phone.

•

Be careful not to hurt yourself or damage your phone

when using the SIM eject pin.

•

Store the SIM eject pin out of the reach of children to

prevent accidental swallowing or injury.

1

Press and hold the power button, and then select

to turn off your phone.

2

To remove the card tray, insert the SIM eject pin

included with your phone into the small hole next to

the card tray.

3

Insert a SIM card or microSD card into the card tray.

4

Insert the card tray back into your phone in the

correct orientation.

Charging your phone

Your phone comes with a long-lasting battery and

efficient power-saving technology. This section

outlines how to care for your battery in order to

maximize its lifespan.

2

Using your battery

•

You can recharge your battery many times, but all

batteries have a limited lifespan. If you notice a

significant deterioration in your phone's battery life,

contact an authorized Huawei service center for a

replacement battery. The battery is built into the

phone and is not removable. Do not attempt to

remove the battery yourself.

•

Your phone may become warm after prolonged use

or when exposed to high ambient temperatures. This

is entirely normal. If your phone becomes hot to the

touch, stop charging it and disable unnecessary

features. Place your phone in a cool location and

allow it to cool down to room temperature. Avoid

prolonged contact with the surface of your phone if

it becomes hot.

•

When charging your phone, only use genuine

Huawei batteries, chargers, and USB cables. Third-

party accessories are a potential safety hazard and

may impair your phone's performance. Avoid using

your phone when it is charging. Do not cover your

phone or the power adapter.

•

Charging times may vary depending on the ambient

temperature and the remaining battery level.

•

A low battery warning will be displayed when the

battery level is low.

•

Your phone will switch off automatically when the

battery is nearly empty.

3

Turning your phone on and off

•

To turn on your phone, press and hold the power

button until your phone vibrates and the screen

turns on.

•

To turn off your phone, press and hold the power

button, and then touch

If your phone does not respond after holding

down the power button for 20 seconds, the

battery may be empty. If so, connect your phone

to a charger to charge the battery.

2 times.

4

First Use and Initial Setup

Initial setup

Ensure that the SIM card is inserted correctly before

using your phone for the first time. Read the Quick

Start Guide for more information on how to set up

your phone.

Press and hold the power button to turn on your

phone, and then follow the onscreen instructions to

complete the initial setup.

1

Select your language and region, and then touch

Next

.

2

Proceed to the

will automatically list available Wi-Fi networks.

Select the network you want to connect to, and then

enter the password to access the Internet.

3

Proceed to the

the content carefully, accept the user terms and

Huawei Privacy Policy, and then touch

4

Follow the onscreen instructions to enable Wi-Fi+.

5

Your phone has a fingerprint sensor. Follow the

onscreen instructions to add your fingerprint. You

also need to set a PIN or password in order to unlock

the screen when your phone fails to recognize your

fingerprint.

6

On the

Begin

and the EMUI interface should launch. You can now

start using your phone.

Wi-Fi settings

Terms and Conditions

Configuration successful

to complete the settings. Wait for a moment

screen. Your phone

screen. Read

Agree

.

screen, touch

5

Connecting to the Internet

Connect to the Internet using Wi-Fi or mobile data to

surf the web, play games, and use instant messaging

applications.

Connecting to a Wi-Fi network

1

Swipe down from the status bar to open the

notification panel.

2

In the

Shortcuts

Wi-Fi settings screen.

3

Turn on the Wi-Fi switch. Your phone will list

available Wi-Fi networks.

4

Select the Wi-Fi network you want to connect to. If

the Wi-Fi network is encrypted, enter the password

when prompted.

Using mobile data

Before using mobile data, ensure that you have

a data plan with your carrier.

1

Swipe down from the status bar to open the

notification panel.

2

In the

data.

Disable mobile data when not required in order

to save battery power and reduce data usage.

tab, touch and hold to open the

Shortcuts

tab, touch to enable mobile

6

Configuring your fingerprint ID

Use the fingerprint sensor to unlock the screen, access

the Safe and App Lock, and authorize payments in

third-party applications.

For added security and to ensure that you can still

access your data if your phone fails to recognize your

fingerprint, you will need to set a backup password

when configuring fingerprint unlock.

1

Open

Settings

Fingerprint management

and touch

2

Select

PIN

or

Password

onscreen instructions to set a screen lock password.

3

Once you have configured the password, touch

fingerprint

4

Place your fingertip on the fingerprint sensor. Press

to add your fingerprint.

down lightly on the sensor until your phone vibrates.

Repeat this step using different parts of your

fingertip until your phone has successfully added

your fingerprint.

5

Once you have added your fingerprint, touch OK.

On the

Fingerprint management

Unlock screen

switch to disable fingerprint unlock.

To delete a fingerprint, select the desired

fingerprint on the

screen, touch

Delete

onscreen instructions.

Fingerprint ID

>

.

, and then follow the

screen, turn off the

Fingerprint management

, and then follow the

New

7

Getting Started

Locking and unlocking the

screen

Locking the screen

•

Press the power button to manually lock the screen.

•

The screen will lock automatically and enter sleep

mode after it has been idle for a certain period to

reduce power consumption and prevent unintended

operations.

To change the screen sleep time, open

Settings

, touch

Display

>

Sleep

select a time.

Your phone will continue to receive messages,

notifications, and incoming calls when the screen is

locked. The status indicator will flash green when you

receive new notifications. When you receive an

incoming call, the screen will turn on and display the

caller information.

Unlocking the screen

When the screen is off, press the power button to

wake the screen. Slide your finger in any direction to

unlock the screen.

Touchscreen gestures

Use simple touchscreen gestures to perform a variety

of tasks, such as open applications, scroll through lists,

and zoom images.

, and then

8

Touch

: Touch an item once.

For example, touch to select

an option or open an

application.

Double touch

target area of the screen

twice in quick succession. For

example, double touch an

image in full screen mode to

zoom in or out.

Touch and hold

hold the target area of the

screen for at least 2 seconds.

For example, touch and hold a

blank area on the home

screen to access the home

screen editor.

Swipe

the screen. For example, in

Notifications

the

left or right on a notification

to dismiss it. Swipe vertically

or horizontally to go to other

home screens, scroll through a

document, and more.

: Touch the

: Touch and

: Swipe your fingers on

tab, swipe

9

Drag

: Touch and hold an

item, and then move it to

another position. For example,

use this gesture to rearrange

applications and widgets on

the home screen.

Spread fingers apart

: Spread

two fingers apart on the

screen. For example, spread

two fingers apart to zoom in

on a picture or web page.

Pinch fingers together

:

Pinch two fingers together on

the screen. For example, pinch

two fingers together to zoom

out on an image.

Status and notification icons

Status icons

Status icons are displayed on the right-hand side of the

status bar. Status icons display information about your

phone's status, such as network connection

information, signal strength, battery level, and time.

Status icons may vary according to your region

or carrier.

10

Signal strength No service

-5&-5&

Connected over

3G network

Connected over

4G/LTE

No SIM card

found

Airplane mode

enabled

Headset inserted

Roaming

Bluetooth

enabled

Vibration mode

enabled

Receiving

location data

Alarm enabled

from GPS

Silent mode

enabled

Battery full

Charging Battery low

Notification icons

Notification icons are displayed on the left-hand side

of the status bar when you receive a new message,

notification, or reminder.

11

Missed calls Call in progress

New emails New messages

Connected over

Wi-Fi

Downloading

data

Upcoming events Uploading data

Synchronizing

data

Login or

synchronization

problem

Connected to a

VPN

USB tethering on

New voicemail

Wi-Fi network

available

Phone memory

full

Synchronization

failed

More

notifications

Home screen

Getting to know your home screen

Your home screens are where you can find your

favorite widgets and all your applications. The

application list has been removed to give you a more

convenient and direct path to your applications.

12

Virtual navigation bar keys

Status bar: Displays notifications and status
icons

Main screen: Displays application icons,
desktop folders, and widgets

Screen position indicator: Indicates
which home screen is displayed

Dock: Displays frequently used applications

Navigation bar: Displays virtual navigation
keys

• Back

: Touch to return to the previous screen or

:

close an application. When entering text, touch to

close the onscreen keyboard.

• Home

• Recent

: Touch to return to the home screen.

: Touch to access the list of recently used

applications, or touch and hold to enable dual

windows mode.

Switching between home screens

Swipe left or right to view the extended home screens.

Touch

Home

to return to the default home screen.

On the home screen, pinch two fingers together or

touch and hold a blank area on the screen to access

the home screen editor. You can:

• Set the default home screen

: Touch at the top

of the home screen to set the chosen home screen as

the default home screen.

13

• Move a home screen

desired location.

• Add a home screen

furthest to the left or right.

• Delete a blank home screen

bottom of a blank screen.

: Drag the home screen to the

: Touch on the home screen

: Touch at the

Automatic screen rotation

When you rotate your phone, some applications will

automatically adjust the screen orientation to make

them easier to use. This feature also lets you use tilt-

controlled applications.

Swipe down from the status bar to open the

notification panel, and then touch

Shortcuts

rotation.

tab to enable or disable automatic screen

Auto-rotate

in the

Organizing applications and widgets on the home screen

Adding a widget to the home screen

Add frequently used widgets to the home screen for

quick access.

On the home screen, pinch two fingers together to

open the home screen editor. Touch

select a widget. Touch and hold the widget and drag it

to a blank area on the home screen.

You must have enough space on the home

screen to add widgets. If there is not enough

sp ace , ad d an oth er h ome scr een or fre e up som e

space.

Widgets

and

14

Moving a widget or icon

On the home screen, touch and hold an application

icon or widget until your phone vibrates. You can then

drag the application icon or widget to the desired

location.

Deleting a widget or icon

On the home screen, touch and hold the application

icon or widget you want to delete until is displayed

at the top of the screen. Drag the unwanted

application icon or widget to .

Creating a folder

Create home screen folders to organize your

applications by type. For example, you can create a

Games folder that contains all of your game

applications.

On the home screen, drag an icon on top of another

icon to create a folder containing both applications. To

rename the folder, open the folder, and then touch the

folder name.

Hiding applications

On the home screen, spread two fingers apart. Touch

Add

, select the applications you want to hide, and

OK

then touch

home screen after they have been hidden.

. Applications will not appear on the

To restore a hidden application to the home

screen, touch

Add

on the hidden

applications screen, deselect the desired

OK

application, and then touch

.

15

Taking a screenshot

Your phone comes with a range of screenshot options.

Capture the entire screen or draw a shape on the

screen to take a partial screenshot.

Using the power and volume down buttons

Press the power and volume down buttons at the same

time to take a full screenshot.

Using the screenshot shortcut switch

Open the notification panel, and then touch in the

Shortcuts

tab to take a full screenshot.

By default, screenshots are saved to the

folder in

Gallery

.

Screenshots

Notifications

Status indicator

The status indicator changes color and flashes to

indicate the following:

•

Steady red (not charging): The battery level is

critically low and the phone will turn off

automatically.

•

Steady red (when charging): The battery level is

critically low.

•

Steady yellow (when charging): The battery level is

medium.

•

Steady green (when charging): The battery is almost

full or already full. Unplug the charger when the

battery level reaches 100%.

•

Flashing green (not charging): You have unread

messages, notifications, or missed calls.

16

Notification panel

Swipe down from the status bar and open the

notification panel to view notifications.

Swipe left on the notification panel to go to the

shortcuts tab.

Back

Swipe up on the screen, or touch

Home

to close the notification panel.

Customize shortcut switches

shortcuts tab, and then touch

shortcut switch to the desired location for easier

access.

or

: Swipe up on the

Edit

. Drag the

Managing notification permissions

Disable notifications for an application to prevent

unnecessary disturbances.

1

Open

Settings

.

2

Touch

Notification panel & status bar

Notification Manager

application.

3

Enable or disable notification settings as desired.

Display notifications in do not disturb mode

Select the desired application in

and then turn on the

Notifications will still be displayed when

priority interruptions

mode.

, and then select the desired

Priority display

is enabled in do not disturb

>

:

Notification center

switch.

Allow only

Notification and status bar settings

Change the notification and status bar settings to

customize how notifications and status reminders are

displayed.

,

17

Settings

Open

panel & status bar

display settings for the notification and status bar.

, and then touch

to configure the drop-down and

Notification

Configuring the drop-down settings for the

notification bar

•

Touch

Drag actions

open the notification panel, your phone will go to

the notifications tab if you have new notifications,

otherwise it will go to the shortcuts tab.

•

Touch

Drag actions

. Swipe down from the left of the status bar

position

to open to the notifications tab, or swipe down from

the right of the status bar to open the shortcuts tab.

•

Turn on the

notification panel when the screen is locked.

You cannot access the notification panel from

the lock screen if you have set a screen lock

password.

>

Smart selection

>

Determine from drag

Notification panel

. When you

switch to access the

Configuring the display content for the

notification and status bar

Turn the

Display network speed

battery percentage

the content that is displayed in the status bar.

Turn off the

notification icons in the status bar.

switches on or off to configure

Show notification icons

, and

Remaining

switch to hide

Using fingerprint recognition

In addition to waking and unlocking the screen, the

fingerprint sensor can also be used to take a photo,

answer an incoming call, and disable an alarm.

18

Adding a fingerprint for the first time

See Configuring your fingerprint ID on page 7 for more

information on configuring fingerprint unlock.

Adding, deleting, or renaming a fingerprint

Add multiple fingerprints to make it easier to unlock

your phone. You can also delete or rename

fingerprints.

1

Open

Settings

.

2

Touch

Fingerprint ID

3

Enter the screen lock password, and then touch

Done

.

4

In the

Fingerprint list

•

Touch

New fingerprint

can add up to five in total.

•

Touch a previously added fingerprint to rename

or delete it.

>

Fingerprint management

section, you can:

to add a fingerprint. You

Accessing Safe with your fingerprint

Use your fingerprint to access your Safe without

entering the password.

1

Open

Settings

.

2

Touch

Fingerprint ID

3

Enter the screen lock password, and then touch

Next

.

>

Fingerprint management

.

.

19

4

Touch

Access safe

instructions to enter your Safe password and enable

fingerprint recognition.

Once you have completed the settings, touch

Safe

. You can now use your fingerprint to access your

Safe.

, and then follow the onscreen

Files

>

Accessing App Lock with your fingerprint

Use your fingerprint to access locked applications.

1

Open

Settings

.

2

Touch

Fingerprint ID

3

Enter the screen lock password, and then touch

Next

.

4

Touch

Access app lock

onscreen instructions to enter your App Lock

password and enable fingerprint recognition.

Touch

Phone Manager

completed the settings, and then use your fingerprint

to view the App Lock status. You can also use your

fingerprint to access locked applications on the home

screen.

>

Fingerprint management

, and then follow the

>

App lock

once you have

Fingerprint sensor touch gestures

Touch or swipe the sensor with any finger to perform

common tasks.

1

Open

Settings

.

2

Touch

Fingerprint ID

3

In the

Touch and hold gesture

switches for features you want to enable.

.

section, turn on

.

20

• Take photo/video

viewfinder, touch and hold the fingerprint sensor

to take a picture.

• Answer call

touch and hold the fingerprint sensor to answer

it.

• Stop alarm

and hold the fingerprint sensor to disable it.

4

In the

Slide gesture

features you want to enable.

• Show notification panel

fingerprint sensor using any finger to open the

notification panel. Tap the sensor twice to clear

all notifications, and swipe up on the sensor to

close the notification panel.

: When using the camera

: When you have an incoming call,

: When your alarm goes off, touch

section, turn on switches for

: Swipe down on the

Personalizing your phone

Changing the theme

Personalize your phone's home screen using a wide

range of themes and wallpapers.

Open

Themes

, select a theme, and then touch

. Touch to mix and match lock screen methods,

wallpapers, application icons, and more.

21

Changing the wallpaper

Set your favorite images or photos as your phone's

wallpaper.

1

Open

Settings

and select

2

Touch

Wallpaper

wallpaper

3

In the

Wallpapers

image, and then follow the onscreen instructions to

set it as the wallpaper.

Turn on the

will change every time you shake your phone. Turn on

Random change

the

Album to display

change the wallpaper at the specified time interval.

You can also open

an image, and then touch >

Wallpaper

set the image as the wallpaper.

, and then touch

or

Home screen wallpaper

or

Shake to change

switch. Configure

. Your phone will automatically

. Follow the onscreen instructions to

Display

Lock screen

Live wallpaper

switch. The wallpaper

Gallery

, touch and hold

.

.

tab, select an

Interval

or

Set as

>

Assigning a ringtone to a contact

Assign a unique ringtone to each contact so that you

can easily tell who is contacting you.

1

Open

Contacts

.

2

Select the desired contact, and then touch

.

ringtone

3

Select the desired ringtone or music file, and then

touch

For more information on how to configure call and

message ringtones and vibration settings, see Sound

settings on page 70.

22

.

Phone

Changing the font size

Enter numbers and symbols

Enter a comma

Touch and hold to open the input options menu

Enter a space
Touch and hold to choose another input method

Backspace

Switch to voice input

Toggle between upper and lower case

Enter a period
Touch and hold to enter symbols

The phone's font size can be increased to make words

easier to read.

Open

Settings

to set the system font size.

, and then touch

size

The

Extra huge

font size will only be displayed

Display

>

Font

in messages, contacts, dialer application and

device setting.

Entering text

Android input method

The Android input method supports a wide range

of languages.

23

Editing text

You can select, cut, copy, and paste text on your

phone.

• Select text

touch

• Copy text

• Cut text

• Paste text

insert the text, and then touch

• Share text

select a sharing method.

: Touch and hold the text to bring up

. Drag or to select more or less text, or

Select all

to select all text.

: Select text and touch

: Select text and touch

: Touch and hold where you want to

: Select text, and then touch

Copy

Cut

Paste

.

.

.

Share

to

24

Calls and Contacts

Making calls

Smart dialing

Enter the name, initials, or number of a contact in the

dialer. Your phone will display matching contacts.

1

Open

Dialer

.

2

Enter the name or initials of a contact in the dialer

(for example, Howard Smith or HS). Your phone will

search your contacts and call log and list the results

above the dialer.

3

From the list, select the contact you want to call.

4

Touch to end the call.

Enabling quick calling

Call people quickly even when the screen is switched

off.

1

Open

Dialer

.

2

Touch >

on the

Press and hold the volume down button for one

second when the screen is off. When you hear the alert

sound, release the volume down button and say the

name of the contact you want to call. The phone will

dial their number.

Settings

>

Quick calling

When using a Bluetooth headset, press and hold

the headset dialing key to enable quick calling.

Quick calling

switch.

and then turn

25

Making a call from Contacts

1

Open

Contacts

.

2

Touch the search bar and enter the name or initials

of the person you want to call. For more information

on searching for contacts, see

Finding a contact on

page 38.

3

Touch the contact number.

Making a call from the call log

View incoming and outgoing calls in the call log and

dial the corresponding numbers.

1

Open

Dialer

.

2

Slide the list up and down to view all calls. Touch the

name or number of the person that you want to call.

Making an emergency call

In the event of an emergency, you can make

emergency calls from your phone, even without a SIM

card. However, you must be in an area with cellular

coverage.

1

Open

Dialer

.

2

Enter the emergency number for your location in the

dialer, and then touch

You can dial an emergency number even when

the screen is locked. On the lock screen, touch

Emergency call

number, and then touch .

The ability to make emergency calls can depend

on local regulations and carriers in your area.

26

.

, enter your local emergency

Poor network reception or environmental

interference may prevent your call from being

connected. Never rely solely on your phone for

essential communication during emergencies.

Speed dialing

Configure speed dialing for people you call frequently.

Simply touch and hold a number key to dial their

number.

1

is the default key for voicemail. It cannot be

used as a speed-dial number.

1

Open

Dialer

.

2

Touch and hold a number key to associate it with a

contact.

3

Return to the dialer and touch and hold a number

key to call the associated contact.

To delete a key association, open the dialer and

touch >

Settings

>

Speed dial

. Select the

contact association you want to remove, and

then touch

Clear assigned number

.

Making an international call

Before making a long-distance call, contact your

carrier to activate an international calling or

roaming service.

1

Open

Dialer

.

2

On the dialer screen, touch and hold the 0 key to

+

symbol, and then enter the country code,

enter a

area code, and phone number.

3

Touch .

27

Answering or rejecting a call

When a call comes in, you can press the volume

button to mute the ringtone.

While the screen is locked:

•

Drag right to answer the call.

•

Drag left to reject the call.

•

Touch to reject the call and send an SMS.

•

Touch to configure a callback reminder.

While the screen is unlocked:

•

Touch to answer the call.

•

Touch to reject the call.

•

Touch to reject the call and send an SMS.

•

Touch to configure a callback reminder.

On the dialer screen, touch >

Reject calls with SMS

text messages.

28

to edit the predefined

Settings

>

Functions available during a call

Mute the call

Start a three-way
call

Enable hands-free
mode

Open the dialer

End call

Display your
contacts

View your notes

Place the current
call on hold

Open Calendar

During a call, your phone will display an in-call menu.

• Hide the in-call menu

Return

. To return to the in-call menu, touch the

: Touch

Home

green status bar at the top of the screen.

• Start a three-way call

: Please contact your carrier

to find out how to use this feature. For more

information, see

Making a conference call on page

30.

• Adjust the volume

: Press the volume up button to

increase the volume, or the volume down button to

decrease the volume.

To end a call using the power button, go to

Dialer

, touch >

Power button ends call

on the

Settings

or

and then turn

switch.

29

Answering a third-party call

Before using this feature, check that you have

subscribed to a call hold service and enabled call

waiting on your phone. For more information on

enabling call waiting, see Enabling call waiting

on page 32. For details, contact your carrier.

1

If you receive an incoming call when in another call,

touch

. You can then answer the incoming call

and hold the other line.

2

Touch to switch between the two calls.

Making a conference call

You can set up a conference call using the multi-party

call feature on your phone. Call one number (or receive

a call), and then call another number to add it to the

conference call.

Conference calling requires network support.

Please ensure you have activated this service. For

details, contact your carrier.

1

Call the first participant.

2

Once the call is connected, touch and then dial

the second participant's number. The first

participant will be placed on hold.

3

When the second call is connected, touch to

start a conference call.

4

To add more people to the call, repeat steps 2 and 3.

5

Touch to end the call.

30

Viewing the call log

The call log is displayed above the dialer. Missed calls

are displayed in red.

Adding a number from the call log

Select a number from the call log and save it to your

contacts.

1

Open

Dialer

.

2

In the call log, touch the icon next to the number

you want to add and do the following:

•

Touch to create a new contact. For more

information, see Creating a contact on page 33.

•

Touch to add the number to an existing

contact.

Clearing the call log

Open

Dialer

. You can:

• Delete one entry

then touch

• Delete multiple entries

log

and select the entries you want to delete. Touch

>

Delete

: Touch and hold a log entry, and

Delete entry

.

.

: Touch >

Delete call

Call settings

Enabling call forwarding

If you are unavailable to take a call, you can configure

your phone to forward calls to another number.

1

Open

Dialer

.

31

2

Touch >

3

Touch

4

Select a forwarding method, enter the destination

number, and then touch

When call forwarding is enabled, your phone will

forward certain calls (such as unanswered calls) to the

number you specified.

Settings

Call forwarding

.

.

Enable

.

Enabling call waiting

Call waiting allows you to take an incoming call when

you are already in a call and switch between the two

conversations.

1

Open

Dialer

.

2

Touch >

3

Touch

waiting

When you receive an incoming call while already in a

call, touch to answer the new call, and to

switch between the two calls.

Settings

.

Additional settings

switch.

and turn on the

Call

Configuring voicemail

Divert calls to your voicemail when your phone is

switched off or unavailable. Callers can leave a voice

message which you can listen to later.

Voicemail must be supported by your carrier.

Please ensure that you have subscribed to this

service. Contact your carrier for information

about their voicemail service.

1

Open

Dialer

.

2

Touch >

32

Settings

3

Touch

Additional settings

4

Touch

Voicemail

enter your voicemail number.

When you receive a voicemail message, the icon is

displayed in the status bar. Dial the voicemail number

to retrieve the message.

.

>

Voicemail number

and then

Creating a contact

The number of contacts you can store on your

phone depends on the size of your phone's

internal storage. The maximum number of SIM

card contacts may vary depending on your SIM

card's storage capacity.

1

Open

Contacts

.

2

Touch . Touch

creating a contact for the first time.

3

Select a location to save the contact from the

options menu.

4

Enter the contact's name, phone number and other

information, and then touch

If you want to save a number from your call log, touch

the icon next to the number you want to save, and

then select or . You can also save phone

numbers or email addresses in

your contacts.

Create a new contact

.

Messaging

if you are

or

Email

to

Adding contact details quickly

Enter contact information on your phone more rapidly.

Simply scan or take pictures of business cards to

automatically add names, phone numbers, and other

information to your contacts.

33

1

Open

Contacts

.

2

Touch

Business cards

3

You can then:

• Take a photo of one card

card on a flat surface and hold the phone in a

landscape orientation. Adjust the viewfinder

frame so that the card fits the guidelines, and

then touch

• Take photos of multiple cards:

mode and follow the onscreen instructions to

photograph multiple cards.

After you have finished scanning or taking photos,

contact information will automatically be saved to

Business cards

>

Scan

.

: Place the business

.

Switch to

Burst

.

Importing or exporting contacts

Your phone supports

standard file format for storing contact information,

including names, addresses, and phone numbers.

Importing contacts from a storage device

1

Open

2

Touch >

storage

.

3

Select one or more

Contacts

Import/Export

.vcf

contact files.

.

>

Import from

.vcf

files, and then touch OK.

VCF

is a

34

Importing contacts from a SIM card

1

Open

Contacts

.

2

Touch >

card

3

Select the contacts you want to import, and then

touch

4

Choose the location to import contacts to. Your

phone will automatically import the contacts.

.

Import/Export

.

>

Import from SIM

Exporting contacts to a storage device

1

Open

Contacts

.

2

Touch >

3

Touch

4

Choose where you want to export the contacts from

and touch

The exported

your phone's internal storage by default. Open

view the exported file.

Import/Export

Export

.

OK

.

.vcf

file is saved to the root directory of

>

Export to storage

Files

to

Exporting contacts to a SIM card

1

Open

Contacts

.

2

Touch >

3

Select the contacts you want to export, and then

touch

4

Touch

Import/Export

.

Continue

>

Export to SIM card

.

.

.

35

Sharing contacts

1

Open

Contacts

.

2

Touch >

3

Select the contacts you want to share, and then

touch

4

Choose your sharing method, and then follow the

onscreen instructions.

Import/Export

.

>

Share contact

.

Managing contacts

Editing a contact

After creating a contact, you can edit their contact

information at any time. This includes adding or

deleting default information such as phone numbers or

email addresses. You can also choose a custom

ringtone and add a birthday, nickname, or photo.

1

Open

Contacts

.

2

Touch and hold the contact you want to edit, and

then touch

3

Touch the contact's photo, and then select


the contact's new information, and then touch

The contact's photo will be displayed when the

contact calls you. Other contact information such as

company name and job title will also be displayed.

Edit

.

or

Choose from Gallery

Add multiple numbers for one contact

a contact from the contact list, and then touch

Edit

>

Add phone number

. Alternatively, enter

.

Take

: Select

.

36

Merging duplicate contacts

When you add contacts to your phone from different

sources, you may end up with duplicate entries. These

duplicate entries can be merged into one to help keep

your contacts organized.

1

Open

Contacts

.

2

Touch >

contacts

3

Select the contacts you want to merge, and then

touch

Organize contacts

.

.

>

Merge duplicate

Deleting contacts

1

Open

Contacts

.

2

Touch >

by batch

3

Select the contacts you want to delete, and then

touch

4

Touch

Organize contacts

.

.

Delete

.

You can also touch and hold a contact you want

to delete. From the popup options menu, select

Delete

to delete that contact.

>

Delete contacts

37

Finding a contact

Search contacts stored on the phone, SIM card, or

linked to an online account.

1

Open

Contacts

For more complete search results, ensure that

Contacts

contacts. On the contacts screen, touch >

Display preferences

contacts

2

On the contact list, use one of the following

methods to find a contact:

•

Swipe the contact list up or down.

•

Slide your finger up or down the index on the

right-hand side of the screen to scroll through

your contacts.

•

Enter the contact's name, initials, phone number,

email address, or other contact information in the

search bar at the top of the contact list. Search

results will be displayed underneath.

3

Select a contact. You can then choose to call them,

send them a text message, or edit their contact

information.

If an error message is displayed or you are

unable to search for a contact, touch >

Organize contacts

index data

.

is configured to display all of your

and then select

All

.

and then select

Rebuild

.

38

Viewing contacts from different

accounts

You can select which contacts to display on your

phone.

1

Open

Contacts

.

2

Touch >

3

Select the account you want to display or customize

the accounts to display.

Hide contact photos, company information and

job title

contacts screen, and then turn on the

switch.

Display preferences

: Touch >

.

Display preferences

Simple layout

on the

Adding a contact to your

favorites

You can add frequently-contacted people to your

favorites to make them easier to find.

1

Open

Contacts

.

2

Touch and hold the contact you want to add to your

favorites, and then touch

the contact to

When viewing contact details, touch to add

the contact to your favorites.

Remove contacts from your favorites

Favorites

contacts that you wish to remove from your favorites,

and then touch .

Favorites

> on the contacts screen. Select the

Add to favorites

.

: Touch

to add

39

Contact groups

Organize friends and family into different groups. You

can send text messages or emails to everyone in a

group. Contacts now also features

Your phone can automatically sort contacts according

to their company or the date you last contacted them,

making it easier to manage contacts and groups.

Creating a group

1

Open

Contacts

.

2

Touch

Groups

and then .

3

Enter the group name (for example Family or Friends)

and then touch

4

Touch . Select the contacts you want to add to

the group, and then touch .

OK

.

Editing a group

Add or remove people from a group or change the

group name.

1

Open

Contacts

.

2

Touch

Groups

edit.

3

Touch and add new members to the group.

4

Touch . You can then:

•

Touch

from the group.

•

Touch

•

Touch

and select the group you want to

Remove members

Delete group

Rename

to edit the group name.

Smart groups

to remove members

to delete the group.

.

40

Sending messages or emails to a group

1

Open

Contacts

.

2

Touch

Groups

send a message or email to.

3

Touch to send a message or to send an email.

and select which group you want to

Deleting a group

1

Open

Contacts

.

2

Touch

Groups

.

3

Touch and hold the group you want to delete, and

then touch

4

Touch

Delete

.

Delete

.

Deleting a group will not remove the contacts in

the group.

41

Messaging and Email

Swipe left or
right to select
attachment
type

Switch to full
screen text
entry

Send

Choose recipients

Add attachment

Sending a message

Spi ce up your message s by addi ng em oticons , ima ges,

videos, music, recordings, and more.

1

Open

Messaging

2

In the list of message threads, touch .

3

Select the recipient box and enter the contact name

or phone number. You can also touch

your contact list and choose a contact or contact

group.

4

Select the text field and enter your message, and

then touch

If you enter more than three lines of text, touch

to switch to full screen text entry. Touch

to add an attachment to your message.

.

to open

.

42

Cancel a message

: You can cancel a message

up to four seconds after it was sent. Touch

Settings

>

, then turn on the

Cancel send

switch. Double touch the message to cancel

sending.

Replying to a message

1

Open

Messaging

2

In the list of message threads, touch a contact name

.

or phone number to view your conversations.

3

Select the text field and enter your message, and

then touch

Reply to a message from the notification

bar

.

: New messages will be displayed in the

notification bar. Touch the button to compose a

reply.

Searching for messages

Use the message search feature to find messages

quickly.

1

Open

Messaging

2

Swipe down on the screen in the list of message

threads to bring up the search bar.

3

Enter one or more keywords. The search results will

be displayed underneath the search bar.

.

43

Deleting threads

Delete unwanted or old threads to tidy up your

message list.

Deleted threads cannot be retrieved, so please

proceed with caution.

1

Open

Messaging

2

In the list of message threads, touch and hold a

thread.

3

Select the threads you want to delete, and then

touch

>

Delete

.

.

Managing messages

Delete unwanted messages, forward messages to

other contacts, copy and paste message content, and

lock messages or add them to your favorites to prevent

them from being deleted by accident.

1

Open

Messaging

2

In the list of message threads, touch a contact name

or phone number to view your conversations.

3

Touch and hold a message. You can:

• Forward the message

message to another contact.

• Delete the message

delete the message. Deleted messages cannot be

retrieved.

• Copy the message

message to the clipboard and paste it elsewhere.

When viewing a message, touch the message

twice to enter full screen text selection view.

44

.

: Touch to forward the

: Touch >

: Touch to copy the

Delete

to

• Add the message to your favorites

>

Copy to Favorites

favorites. When you delete messages, messages

in your favorites will not be affected. In the list of

message threads, touch

your favorite messages.

• Lock the message

message. When you delete messages, locked

messages will not be affected.

to add the message to your

: Touch >

>

Favorites

Lock

: Touch

to view

to lock the

Adding an email account

Adding a personal email account

When adding an account, consult your email service

provider if you are unsure about the account settings.

1

Open

Email

.

2

Choose an email service provider or touch

3

Enter your email address and password, and then

Next

. Touch

touch

email account manually.

4

Follow the onscreen instructions to configure your

account. The system will automatically connect to

the server and check the server settings.

Once the account has been set up, your

displayed.

After adding an email account, touch >

Settings

continue adding other accounts.

Manual setup

>

Add account

in your

Others

to configure an

Inbox

will be

Inbox

to

.

45

Adding an Exchange account

Exchange is an email system developed by Microsoft

for businesses. Some email service providers also

provide Exchange accounts for individuals and

families.

When adding an account, consult your email service

provider if you are unsure about the account settings.

1

Open

Email

.

2

Touch

Exchange

3

Enter your email address, user name, and password.

Touch

4

Follow the onscreen instructions to configure your

account. The system will automatically connect to

the server and check the server settings.

Once the account has been set up, your

displayed.

Next

.

.

Inbox

will be

Sending an email

1

Open

Email

.

2

Touch .

3

Touch

From:

want to use.

4

Enter one or more recipients.

5

Enter your email subject and main body. Touch

and then select the email account you

To Cc or Bcc the email to multiple recipients,

Cc/Bcc:

touch

to add an attachment.

.

46

6

[e-mail]

Recipient

Email body

Add attachment

Send

Subject

Select recipient from
contact list

Touch .

Your email service provider may place a limit on

the size of email attachments. If your

attachments exceed the limit, send the

attachments in separate emails.

Touch >

Save

to save your email as a draft.

Checking your emails

Open

Email

refresh the list of emails.

1

2

3

and then swipe down in your

Open

Email

.

In your

Inbox

, touch in the upper left corner to

select an account.

Touch the email you want to read. You can:

•

Touch to star for future reference.

•

Touch to reply, forward, or delete the email.

•

Touch

Reply…

and enter text to compose a quick

reply.

•

Swipe left or right to read the next or previous

email.

Inbox

to

47

Account settings

Changing email accounts

If you have added multiple email accounts on your

phone, ensure you switch to the right account before

viewing or sending emails.

1

Open

Email

.

2

In your

Inbox

open the account list.

3

Select the desired email account.

Removing an email account

1

Open

2

In your

3

Select the account you want to remove.

4

Touch

After you remove an email account, you will no longer

be able to send or receive emails using that account.

Personalizing your email account

Display contact pictures, choose what to display after

deleting an email, change your signature, set inbox

update frequency, and change email notification

tones.

1

Open

2

In your

choose the desired settings.

, touch in the upper left corner to

Email

.

Inbox

, touch >

Remove account

Email

.

Inbox

, touch >

Settings

> OK.

Settings

.

and then

48

Camera and gallery

Switch flash modes

View images or videos

Take a photo

Apply filter effects

Switch between
rear and front
cameras

View more
options.

Accessing the viewfinder

Open

Camera

to access the viewfinder.

For more information on the camera settings,

see Camera settings on page 54.

Taking a photo

1

On the home screen, touch

2

Frame the scene you want to capture. Let your

camera focus automatically or touch the screen to

Camera

focus on an object.

3

Touch .

If the

GPS tag

switch was enabled when the

photo was taken, the photo can be viewed in

under

Gallery

Map

.

.

49

Launching the camera from the

gallery

1

On the home screen, touch

2

Under

Photos

the viewfinder in half screen mode, and then swipe

down again to launch the camera.

3

Touch to take a photo.

4

Touch

, swipe down on the albums to display

Not all camera features are available in half

screen mode.

Return

to return to gallery.

Gallery

.

Capture modes

Your phone may not feature all of these capture

modes.

• Beauty

: Drag the slider to adjust the beauty level

and apply facial enhancements.

• Panorama

• HDR

excessive lighting conditions.

• All-focus

photos taken in this mode at a later time.

• Watermark

photos.

• Audio note

you take a photo.

• Audio control

under

have your camera take photos for you.

50

: Use this mode to take wider shots.

: Enhance a photo taken under insufficient or

: You can re-adjust the focal point of

: Add various watermarks to your

: You can record a brief audio clip after

: Touch and enable this mode

Settings

. You can issue voice commands to

• Timer

: Touch and enable this mode under

Settings

to set a countdown timer for taking a

photo.

• Touch to capture

mode under

photo.

• Capture smiles

under

Settings

photo when it detects a smile.

• Object tracking

under

Settings

camera will track and stay focused on this object.

• Ultra snapshot

under

Settings

frame the object you want to capture and press the

volume down key twice to take a photo.

: Touch and enable this

Settings

. Touch the screen to take a

: Touch and enable this mode

. The camera will automatically take a

: Touch and enable this mode

. Touch an object on the screen. Your

: Touch and enable this mode

. When the screen is off or locked,

Taking a panoramic photo

1

On the home screen, touch

2

Touch >

shooting mode.

3

Touch to start shooting.

4

Follow the onscreen instructions and move your

phone slowly to capture multiple photos.

5

Touch to stop shooting. The camera

automatically stitches the photos together to create

one panoramic photograph.

Panorama

Camera

.

to switch to panorama

51

Adding watermarks to photos

1

On the home screen, touch

2

Touch >

mode.

3

Touch the or navigation icon or touch

and then select the desired watermark.

4

Drag the watermark to adjust its position.

5

Touch .

Watermark

Camera

.

to switch to watermark

More

Taking a photo using audio control

1

On the home screen, touch

2

Touch > >

3

Touch

Audio control

mode. Then you can:

•

Get your phone to take a photo when you issue a

voice command.

•

Get your phone to take a photo when the

surrounding noise reaches a certain decibel level.

4

Frame the scene you want to capture. Your phone

will take a photo automatically when you issue a

voice command or the surrounding noise reaches a

certain decibel level.

Camera

.

Audio control

to switch to the audio control

.

Object tracking mode

1

On the home screen, touch

Camera

.

2

Touch > .

52

3

Touch

Object tracking

to enable object tracking

mode.

4

Touch an object on the screen. Your camera will

track and stay focused on this object as you're

shooting.

Object tracking mode and smile capture can't be

used at the same time.

All focus mode

1

On the home screen, touch

2

Touch >

3

Touch to take a photo.

4

Go to gallery and select the photo that was taken

using all focus mode.

All-focus

indicates photos that were taken in all focus

Camera

.

to switch to all focus mode.

mode.

5

Touch to enter the all focus editing mode.

6

Touch another area of the photo that you want to

focus on.

7

Touch .

Slow motion recording

You can record videos in slow motion to enjoy fast-

moving scenes in detail, such as falling water droplets

or dance moves.

1

Open

Camera

.

2

Touch >

Slow-mo

.

53

3

Touch to start a video recording.

4

Touch the screen to focus on an object or area

during recording.

5

Touch to end the recording.

Touch the thumbnail to play the recording back

in slow motion.

Shooting a video

1

On the home screen, touch

2

Swipe left or right to select

3

Touch to start recording.

4

While recording, touch an object or a position on the

screen to focus on it. Touch

recording, and touch to resume.

5

Touch to stop recording.

While recording, you can touch to take a still

photo.

Video

Camera

.

to pause

.

Camera settings

On the capture screen, touch > to

configure the following settings:

• Resolution

the video resolution, touch

Resolution:

: Set the camera resolution. To change

> >

on the video capture screen.

54

• GPS tag

: Display the location where the photo or

video was taken.

• Preferred save location

location for your photos and videos.

• Perfect selfie

for automatic facial recognition and customized

portrait enhancement.

• Mute

to legal constraints, this feature is not available in all

countries and regions.

• Audio control

• Timer

• Touch to capture

photo.

• Capture smiles

a photo when it detects a smile.

• Object tracking

focus on. The camera will track and focus on the

selected object.

• Touch & hold shutter button

shutter's touch and hold settings. You can select

Burst shoot

• Volume button function

button settings. You can select

Focus

• Ultra snapshot

twice to take a photo when the screen is off.

• ISO

blurring caused by dark conditions or movement.

• White balance

Adjust the white balance according to the brightness

of the surroundings.

: Enable this function in

: Enable this feature to mute the camera. Due

: Take a photo using voice commands.

: Enable this feature to set a self-timer.

or

: Set a photo's ISO. Increasing the ISO can reduce

: Set the default save

Beauty

mode

: Touch the viewfinder to take a

: The camera will automatically take

: Touch the object you want to

: Configure the

Focus

.

: Configure the volume

Shutter, Zoom

: Press the volume down button

: Adjust a photo's white balance.

, or

55

• Image adjustment

saturation, contrast, and brightness.

: Adjust exposure compensation,

Gallery

Viewing photos

1

On the home screen, touch

2

You can then:

•

Select the

timeline.

•

Select the

grouped according to location.

•

Select the

by album.

Photos

tab and view photos in a

Photos

tab, select and view photos

Albums

Playing a slideshow

1

On the home screen, touch

2

Under

Photos

, touch >

3

Touch the screen to stop the slideshow.

Editing an image

The Gallery application comes with powerful image

editing tools that you can use to bring your photos to

life. For example, you can draw graffiti, add

watermarks, or apply a variety of filters.

1

Open

Gallery

.

2

Touch an image to view it in full-screen mode. Touch

to edit the image.

3

Select an image editing tool. You can:

56

Camera

.

tab and view photos grouped

Gallery

.

Slideshow

.

• Rotate an image

adjust the angle of rotation. Touch

mirror image of the photo.

• Crop an image

example, 16:9). Drag the dotted edges to crop the

image to the desired size.

• Add a filter

• Accentuate colors

that you wish to accentuate.

• Blur an image

the amount of blur.

• Adjust image parameters

the brightness, contrast, saturation, and more to

make your image look more vivid.

• Apply facial enhancement effects

facial enhancement effects to people in an image.

You can choose from various skin and eye

enhancement effects.

• Apply mosaic effects

desired mosaic effect.

• Draw graffiti

• Add a watermark

personalize your photo. You can choose from time,

location, weather, exercise type, and more.

• Add a label

label type and font. You can use labels to record your

mood or thoughts.

: Touch and swipe the screen to

: Touch to select the crop ratio (for

: Touch and select the desired filter.

: Touch and select the colors

: Touch . Drag the slider to adjust

: Touch and then select the

: Touch to select the brush and color.

: Touch to add a watermark and

: Touch and then select the desired

Mirror

to create a

: Touch . You can adjust

: Touch to apply

57

Deleting a photo

1

On the home screen, touch

2

Select the photo you want to delete and then touch

>

Delete

.

Gallery

.

Sharing photos and videos

You can share your photos or videos in various ways.

1

On the home screen, touch

2

Select the photo or video that you want to share.

3

Touch , choose a sharing method, and follow

the onscreen instructions to share your photo or

video.

Gallery

.

Setting a photo as the wallpaper

1

On the home screen, touch

2

Select the photo you want to set as the wallpaper.

3

Touch >

instructions to set the photo as the wallpaper.

Set as

Gallery

.

and follow the onscreen

Scanning a QR code

Scanning a QR code using gallery

1

On the home screen, touch

2

Choose a QR code photo.

3

Touch the photo. Gallery will automatically scan the

QR code.

Gallery

.

58

4

Touch the QR code link to view more information

about the code.

Scanning a QR code using camera

1

On the home screen, touch

2

Frame the QR code using the camera. The camera

will automatically scan the QR code.

3

Touch the QR code link to view more information

about the code.

Camera

.

59

Music and Video

Scan for local music

Shuffle

Browse music by
category

Search local music

Sort songs

Adding songs to your phone

Before you can listen to your music, you need to copy

your songs onto your phone.

To add songs to your phone:

•

Copy songs from your computer using the USB cable.

•

Download songs from the Internet.

Searching for local music

Sort your music by category or search with a keyword

to find your music files quickly.

1

Open

Music

.

2

Touch

Local songs

3

Touch to search for and view your local music.

4

You can choose to organize your music by song

name, artist, album name, or folder. To search for a

specific song, touch

name, artist, or album in the search bar.

Listening to music

1

Open

2

Touch

Local songs

3

Touch the song you want to play.

60

Music

.

and then enter the song

.

.

Using your phone during music playback

Adjust playback

volume

Add song to playlist

Change playback

mode

Add song
to favorites

Menu

•

When a song is playing, touch

Home

to exit the

music playback screen without stopping the song. To

return to the music playback screen, open the

notification panel and touch the song that is playing.

•

Touch the song that is playing to return to the

playback screen. Swipe left or right to view the song

list, album cover, and lyrics.

Lyrics files must be downloaded separately and

saved in .lrc format. The name and file path must

be the same as the music file.

•

On the

My music

screen, touch >

Close

to close

the music player.

Using the playback screen

Touch the playback screen to display or hide the menu

icons.

61

Setting a song as the ringtone

Set your favorite song as the call, notification, or alarm

ringtone.

1

Open

Music

.

2

Touch

Local songs

3

Touch >

You can choose to set the song as the call,

notification, or alarm ringtone.

.

Set as ringtone

next to the song name.

Playing a video

1

Open

Videos

.

2

Touch the video you want to play.

3

Touch to pause the video playback.

Lock the screen

Adjust playback

speed

Using your phone during video playback

•

Swipe left or right to rewind or fast-forward the

video.

•

Swipe up or down on the left side of the screen to

adjust the screen brightness.

•

Swipe up or down on the right side of the screen to

adjust the volume.

62

Accessing the Internet

Connecting to the Internet

using mobile data

Data charges may apply when using mobile data to

access the Internet.

Before using mobile data, ensure that you have

a data plan with your carrier.

1

Open

Settings

.

2

Touch

More

>

Mobile network

3

Turn on the

data.

Mobile data

Disable mobile data when not required in order

to save battery power and reduce data usage.

Connecting to the Internet

using Wi-Fi

You can connect to the Internet using a Wi-Fi access

point or hotspot.

Your personal data and financial information

may be at risk if you connect to insecure public

Wi-Fi networks.

Connecting to a Wi-Fi network

1

Open

Settings

.

2

Touch

Wi-Fi

phone will list available Wi-Fi networks.

and then turn on the

.

switch to enable mobile

Wi-Fi

switch. Your

63

• Search manually for Wi-Fi networks

Scan

. Your phone will scan again for available Wi-

Fi networks.

• Add a Wi-Fi network that is not shown in the

list

: Touch

instructions to configure the Wi-Fi settings and

password.

3

Select the Wi-Fi network you want to connect to:

•

If the Wi-Fi network does not require a password,

your phone will connect automatically.

•

If the network is protected, enter the password

when prompted, and then touch

Once your phone is connected to a Wi-Fi network, it

will display the icon in the status bar. Your phone

will remember Wi-Fi networks that you have used

before and reconnect to them automatically.

Add network…

. Follow the onscreen

: Touch

Connect

.

Connecting to the Wi-Fi network with the strongest signal

When Wi-Fi+ is enabled, your phone will automatically

enable or disable Wi-Fi and connect to the Wi-Fi

network with the best signal.

You may incur additional data charges when

downloading large files or watching online

videos over mobile data. Purchase a suitable

data plan to ensure that you do not incur

excessive data charges. Contact your carrier for

details.

1

Open

Settings

2

Touch

64

the

Wi-Fi+

Wi-Fi+

and touch

>

Wi-Fi+ settings

switch.

More

>

LINK+

and then turn on

.

When Wi-Fi+ is enabled, your phone will automatically

record your Wi-Fi connection history and monitor the

signal strength and your location. This information is

then used to enable or disable Wi-Fi and connect to

the Wi-Fi network with the strongest signal.

• Connect to the network with the best signal

When Wi-Fi signal strength is poor or your current

Wi-Fi network is not reachable, your phone will

automatically connect to another available Wi-Fi

network with a better signal. If no other Wi-Fi

networks are available and your mobile data is

enabled, your phone will use mobile data (data

charges may apply). If the Wi-Fi signal strength

improves, your phone will reconnect to the Wi-Fi

network.

• Automatically turn Wi-Fi on or off

will automatically disable Wi-Fi when you move out

of range of a Wi-Fi hotspot (such as when you leave

home). Wi-Fi will be re-enabled when you return to

the location of a previously used hotspot (such as

when you return home).

• Monitor Wi-Fi network quality

automatically monitor the signal strength of nearby

public hotspots.

: Your phone

: Your phone will

:

65

Transferring data using

Bluetooth

Enabling Bluetooth and pairing your phone with another device

1

Open

Settings

and touch

2

Turn on the

that

automatically list available devices. If the device you

want to pair with is not displayed, check that the

device is discoverable.

3

Select the device you want to pair with and follow

the onscreen instructions.

Turn on Bluetooth

Visibility

is enabled. Your phone will

Sending and receiving files using Bluetooth

Check that both devices are paired before attempting

to transfer files.

• Send files

• Receive files

: Touch and hold the file you want to send

and touch

automatically search for nearby devices. Select the

receiving device.

files using Bluetooth, select

box that appears. Open the notification panel to

view file transfer progress.

Share

>

Bluetooth

: When another device tries to send you

By default, received files are saved to the

bluetooth

folder on your d evice's internal storage.

Bluetooth

switch and ensure

. Your device will

Accept

from the dialog

.

66

Renaming your phone

By default, your phone's model number is used as the

device name when you enable Bluetooth. You can

change the name to something more recognizable.

1

Open

Settings

name

.

2

Rename the phone and touch OK.

and touch

Bluetooth

>

Device

67

Settings

Enabling location access

Enable location-based services to ensure that map,

navigation, and weather applications can access your

location information.

Features may vary depending on your carrier.

1

Open

Settings

.

2

Touch

Advanced settings

then turn on the

3

Three options are available under

• Use GPS, Wi-Fi, and mobile networks

GPS and your phone's Internet connection.

this option for highly accurate positioning.

• Use Wi-Fi and mobile networks

phone's Internet connection. Enable this option

for reduced power consumption and longer

standby times.

• Use GPS only

connection. Enable this option to reduce mobile

data usage.

Configuring the display settings

Configure the display settings to personalize your

phone. For example, you can change the wallpaper,

font size, and screen-off time.

Go to

Settings

configure the following settings:

>

Access my location

: Does not require an Internet

and then touch

Location services

switch.

Location mode

: Uses

: Only uses your

Display

. You can

and

Enable

:

68

• Color temperature

: Adjust the color temperature

for images displayed on your phone. Select a warmer

color temperature for a softer look and a cooler

color temperature for a sharper image. Clear the

Default

check box to manually adjust the color

temperature.

• Wallpaper

: Set the lock screen and home screen

wallpapers.

• Font size

• Daydream

: Set the font size.

: When this feature is enabled and you

have configured

Picture source

and

Duration

phone will automatically display images when it's

being charged and the screen is locked.

• Indicator light

: The status indicator will blink when

you receive incoming calls, messages, or other

notifications.

• Brightness

: Your phone will automatically adjust

the screen brightness according to the ambient

brightness. Clear the

Automatic brightness

check

box to manually adjust the brightness.

• Sleep

: The screen will lock automatically after a

period of inactivity to reduce power consumption.

Sleep

Select

to adjust the screen-off time or disable

the automatic screen lock feature.

• Auto-rotate screen

: If this option is enabled, your

screen's orientation will switch automatically

depending on how you hold your phone when

performing certain operations, such as browsing a

web page, viewing a picture, or writing a message.

The above options may not be available on all

phone models.

, your

69

Sound settings

Change the incoming call and message ringtones or set

the system alert sound and vibration effects.

Go to

Settings

configure the following settings:

• Volume

volume.

• Silent mode

when you receive an incoming call or message, but

the screen will still turn on. If you have also enabled

Vibrate in silent mode

alert you of incoming calls and messages.

You can also enable or disable these features in

the shortcuts tab. Touch to switch between

Sound, Vibration

•

Select a ringtone under

to change the ringtone. You can choose from preset

ringtones or a local music file. Turn on the switch to

enable vibrations when your phone rings.

• Default notification tone

ringtone or a local music file as the notification tone

for messages, emails, and other notifications.

•

Touch the switches under

disable dial pad touch tones, touch sounds, screen

lock sounds, screenshot tones, and haptic feedback.

The above options may not be available on all

phone models.

and then touch

: Adjust the ringtone, media, alarm, and call

: Once enabled, your phone will not ring

, and

Sound

. You can

, your phone will vibrate to

Silent

.

Call ringtone & vibration

: Choose a preset

System

to enable or

70

Changing the screen unlock

method

Set a screen lock password to prevent unauthorized

access to your phone.

Setting a screen unlock pattern

1

Open

Settings

.

2

Touch

Screen lock & passwords

Pattern

.

3

Connect at least four dots to create a screen unlock

pattern, and then release your finger. Draw your

screen unlock pattern again to confirm.

4

Enter a backup PIN containing at least four digits. If

you forget your screen unlock pattern, you can enter

the backup PIN to unlock the screen.

Unlocking the screen with a password

1

Open

Settings

.

2

Touch

Screen lock & passwords

3

You can choose to set a PIN or password:

•

Touch

PIN

least four digits and select

•

Touch

containing at least four characters and select

Done

, and then enter a PIN containing at

Password

.

You can also use your fingerprint to unlock the

screen. Touch

add your fingerprint.

, and then enter a password

Enrol

>

Password

>

>

Password

.

Done

.

in the popup dialog box to

71

Enabling fingerprint unlock

See Using fingerprint recognition on page 18 for more

information on configuring fingerprint unlock.

Removing the screen lock password

1

Open

Settings

.

2

Touch

Screen lock & passwords

3

Enter your screen lock password or unlock pattern,

and then touch

None

.

>

Password

.

Airplane mode

Wireless devices may interfere with an airplane's flight

system. Power off your phone or switch to airplane

mode when you are on a flight.

After you enable airplane mode, all of your phone's

network features will be disabled. You will not be able

to make or receive calls, or use mobile data, Bluetooth

or Wi-Fi. However, you will still be able to play music,

watch videos, and use applications that do not require

an Internet connection.

Use one of the following methods to enable or disable

airplane mode:

•

Swipe down from the status bar to open the

notification panel. In the

Airplane mode

•

Press and hold the power button, and then touch

Airplane mode

•

Open

Settings

mode

switch.

When airplane mode is on, is displayed in the

status bar.

72

Shortcuts

switch.

.

, and then turn on the

tab, turn on the

Airplane

Setting your SIM card PIN

A personal identification number (PIN) is delivered

with your SIM card to protect your phone data. If you

have enabled PIN protection for your SIM card, you will

need to enter the PIN each time you turn on your

phone or insert the SIM card into another phone.

Features may vary depending on your network

carrier.

Before you perform the following operations, make

sure you have received a SIM card PIN from your

carrier.

1

Open

Settings

.

2

Touch

Advanced settings

select the options under

configure the SIM lock settings.

3

Turn on the

4

Enter your PIN, and then touch OK. To change your

PIN, touch

Lock SIM card

Change SIM PIN

•

You will need to enter the PUK code if you

exceed the maximum number of incorrect PIN

attempts. The SIM card will be permanently

locked if the PUK code is entered incorrectly

too many times.

•

Contact your carrier for details about these

limits.

>

Security

, and then

Set up SIM card lock

switch.

.

to

73

Setting up an account

Adding an account

Many applications and online services require you to

create an account in order to access the full range of

features.

1

Open

Settings

.

2

Touch

Accounts

>

Add account

3

Select an account type, and then follow the onscreen

instructions to enter your account information.

•

You must install the corresponding application

before you can add an account for a third-party

application.

•

To add a company account, see Adding an Exchange

account on page 46.

•

To add an email account, see Adding a personal

email account on page 45.

Deleting an account

1

Open

Settings

.

2

Touch

Accounts

, and then select the account type.

3

Select the account that you want to delete, and then

follow the onscreen instructions to delete it.

.

74

Syncing data with your phone

Enable the sync feature to keep all of your phone's

data up-to-date and prevent data loss. You can sync

emails, contacts, and other data from your old phone

or computer.

The type of data that can be synced depends on the

account type. Some applications may not support

syncing for all data types.

The example below illustrates how to sync data for an

email account.

1

Open

Settings

.

2

Touch

Accounts

data

. Follow the onscreen instructions, and then

touch

3

On the

then select the account that you want to sync with

your phone.

4

Touch to syn c your emails.

> , and then select

OK

to turn on the sync data switch.

Accounts

screen, select an account type, and

Auto-sync

Setting the date and time

Features may vary depending on your carrier.

Open

Settings

. Touch

to configure the settings.

& time

Advanced settings

>

Date

Changing the system language

1

Open

Settings

.

2

Touch

Advanced settings

3

Touch

Language & region

desired language.

>

Language & input

, and then select the

.

75

Accessibility Features

About your phone's

accessibility features

Accessibility features make it easier for users with

impaired vision or hearing to use their phone.

TalkBack

Enabling or disabling TalkBack

TalkBack is an accessibility feature designed for

visually impaired users. It provides audible prompts to

help you operate your phone. Once it is enabled, your

phone will issue audible prompts for all content that

you touch, select, or enable. Please enable with

caution.

TalkBack's audible prompts are not available for

all languages.

1

Open

Settings

.

2

Touch

Advanced settings

TalkBack

.

3

Turn on the

enable TalkBack. The audible tutorial will be started

automatically when you enable TalkBack for the first

time. If you need to play the tutorial again, touch

tutorial.

4

Touch , and then select

phone will not issue audible prompts for the content

TalkBack

to access the settings, and then select the

>

Accessibility

switch, and then touch OK to

Explore by touch

>

. Your

76

that you touch unless you turn on

.

touch

Explore by

Using TalkBack to control your phone

After you have enabled TalkBack, use gestures to:

Browse the screen

screen (instead of one). Swipe up or down with two

fingers to scroll through menu lists. Swipe left or right

to move between screens.

Select an item

select it (it will not open). The phone will read out the

content of the selected item.

Open an item

using one finger to confirm your selection from the

previous step.

For example, if you want to open

are required: Touch the

finger, and then touch twice on any part of the screen.

: Use two fingers to swipe the

: Touch an item with one finger to

: Double touch any part of the screen

Settings

Settings

, two steps

icon once using one

Configuring the TalkBack settings

TalkBack settings can be customized to suit your

individual needs.

1

Open

Settings

.

2

Touch

Advanced settings

TalkBack

> .

3

You can adjust the feedback volume, audible

feedback settings, control gestures, and more.

>

Accessibility

>

77

Audible password prompts

This feature provides audible feedback for visually

impaired users. When you enter a password, your

phone will read out the letters as you type. This feature

requires TalkBack to be enabled.

1

Open

Settings

.

2

Touch

Advanced settings

turn on the

Speak passwords

>

Accessibility

switch.

and then

Text To Speech (TTS) output

This feature converts text into speech for visually

impaired users. This feature requires TalkBack to be

enabled.

1

Open

Settings

.

2

Touch

Advanced settings

to-speech output

3

Select the desired speech synthesis engine and voice

speed.

>

.

Accessibility

>

Text-

Captions

In addition to providing audible prompts, TalkBack

also displays captions for hearing-impaired users. This

feature requires TalkBack to be enabled.

1

Open

Settings

.

2

Touch

Advanced settings

Captions

.

3

Turn on the

language, font size, and caption style.

Captions

>

Accessibility

switch, and then configure the

>

78

Magnification gestures

Use magnification gestures to zoom in on a specific

area.

The keyboard and the navigation bar cannot be

magnified.

1

Open

Settings

.

2

Touch

Advanced settings

Magnification gestures

3

Turn on the

• Zoom in

Magnification gestures

: Touch the screen three times in quick

succession to zoom in. Touch the screen three

times again to zoom back out.

will still be enabled when you touch the

gestures

screen three times. Turn off the

switch to disable magnification

gestures

gestures.

• Browse a magnified area

using two or more fingers.

• Adjust the zoom

together or spread them apart. To zoom in,

spread your fingers apart. Pinch your fingers

together to zoom back out.

• Zoom in temporarily

times in quick succession, and then hold your

finger on the screen. Keep your finger on the

screen and swipe to browse a magnified area.

Release your finger to zoom back out.

>

Accessibility

>

.

switch.

Magnification

Magnification

: Swipe the screen

: Pinch two or more fingers

: Touch the screen three

79

Using the power button to end a call

1

Open

Settings

.

2

Touch

Advanced settings

turn on the

Once you have enabled this feature, press the power

button to end a call.

Power button ends call

>

Accessibility

and then

switch.

Adjusting the screen response time

You can adjust the time that it takes for your phone to

respond to gestures, such as touch and hold.

1

Open

Settings

.

2

Touch

Advanced settings

& hold delay

3

Select the desired delay time:

Long

.

.

>

Accessibility

Short, Medium

>

Touch

or

Color correction

Color correction mode adjusts colors to make it easier

for color vision impaired users to distinguish between

different parts of the screen.

Enable this mode with caution, as it may affect

your phone's battery.

1

Open

Settings

.

2

Touch

Advanced settings

turn on the

3

Touch

Correction mode

correction mode.

80

Color correction

>

Accessibility

switch.

and then select a

and then

Appendix

About this guide

All pictures and illustrations in this document are for

your reference only and may differ from the final

product.

Features in this guide are for your reference only.

Some features may not be supported by all phones or

carriers.

Copyright © 2016 Huawei Technologies Co., Ltd. All

rights reserved.

This guide is for reference purposes only and does not

constitute any form of guarantee.

Personal Information and Data

Security

The use of some functions or third-party applications

on your device could result in your personal

information and data being lost or becoming

accessible to others. Several measures are

recommended to help you protect personal and

confidential information.

•

Place your device in a safe area to prevent it from

unauthorized use.

•

Set your device screen to lock and create a password

or unlock pattern to open it.

•

Periodically back up personal information kept on

your SIM card, memory card, or stored in your device

memory. If you change to a different device, be sure

to move or delete any personal information on your

old device.

81

•

If you are worried about viruses when you receive

messages or emails from a stranger, you can delete

them without opening them.

•

If you use your device to browse the Internet, avoid

websites that might pose a security risk to avoid

theft of your personal information.

•

If you use services such as Wi-Fi tether or Bluetooth,

set passwords for these services to prevent

unauthorized access. When these services are not in

use, turn them off.

•

Install or upgrade device security software and

regularly scan for viruses.

•

Be sure to obtain third-party applications from a

legitimate source. Downloaded third-party

applications should be scanned for viruses.

•

Install security software or patches released by

Huawei or third-party application providers.

•

Some applications require and transmit location

information. As a result, a third-party may be able to

share your location information.

•

Your device may provide detection and diagnostic

information to third-party application providers.

Third party vendors use this information to improve

their products and services.

•

If you have concerns about the security of your

personal information and data, please contact

[e-mail].

82

Legal Notice

Copyright © Huawei Technologies Co., Ltd.

2016. All rights reserved.

No part of this manual may be reproduced or

transmitted in any form or by any means without prior

written consent of Huawei Technologies Co., Ltd. and

its affiliates ("Huawei").

The product described in this manual may include

copyrighted software of Huawei and possible

licensors. Customers shall not in any manner

reproduce, distribute, modify, decompile, disassemble,

decrypt, extract, reverse engineer, lease, assign, or

sublicense the said software, unless such restrictions

are prohibited by applicable laws or such actions are

approved by respective copyright holders.

Trademarks and Permissions

, , and are trademarks or

registered trademarks of Huawei Technologies Co.,

Ltd.

Manufactured under license from Dolby Laboratories.

Dolby and the double-D symbol are registered

trademarks of Dolby Laboratories.

Android™ is a trademark of Google Inc.

LTE is a trademark of ETSI.

Bluetooth® word mark and logos are registered

The

trademarks owned by

of such marks by Huawei Technologies Co., Ltd. is

under license.

Bluetooth SIG, Inc.

and any use

83

Other trademarks, product, service and company

names mentioned may be the property of their

respective owners.

Notice

Some features of the product and its accessories

described herein rely on the software installed,

capacities and settings of local network, and therefore

may not be activated or may be limited by local

network operators or network service providers.

Thus, the descriptions herein may not exactly match

the product or its accessories which you purchase.

Huawei reserves the right to change or modify any

information or specifications contained in this manual

without prior notice and without any liability.

Third-Party Software Statement

Huawei does not own the intellectual property of the

third-party software and applications that are

delivered with this product. Therefore, Huawei will not

provide any warranty of any kind for third party

software and applications. Neither will Huawei provide

support to customers who use third-party software

and applications, nor be responsible or liable for the

functions or performance of third-party software and

applications.

Third-party software and applications services may be

interrupted or terminated at any time, and Huawei

does not guarantee the availability of any content or

service. Third-party service providers provide content

and services through network or transmission tools

outside of the control of Huawei. To the greatest

extent permitted by applicable law, it is explicitly

stated that Huawei shall not compensate or be liable

84

for services provided by third-party service providers,

or the interruption or termination of third-party

contents or services.

Huawei shall not be responsible for the legality,

quality, or any other aspects of any software installed

on this product, or for any uploaded or downloaded

third-party works in any form, including but not

limited to texts, images, videos, or software etc.

Customers shall bear the risk for any and all effects,

including incompatibility between the software and

this product, which result from installing software or

uploading or downloading the third-party works.

This product is based on the open-source Android™

platform. Huawei has made necessary changes to the

platform. Therefore, this product may not support all

the functions that are supported by the standard

Android platform or may be incompatible with third-

party software. Huawei does not provide any warranty

or representation in connect with any such

compatibility and expressly excludes all liability in

connection with such matters.

DISCLAIMER

ALL CONTENTS OF THIS MANUAL ARE PROVIDED "AS

IS". EXCEPT AS REQUIRED BY APPLICABLE LAWS, NO

WARRANTIES OF ANY KIND, EITHER EXPRESS OR

IMPLIED, INCLUDING BUT NOT LIMITED TO, THE

IMPLIED WARRANTIES OF MERCHANTABILITY AND

FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN

RELATION TO THE ACCURACY, RELIABILITY OR

CONTENTS OF THIS MANUAL.

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE

LAW, IN NO EVENT SHALL HUAWEI BE LIABLE FOR ANY

SPECIAL, INCIDENTAL, INDIRECT, OR CONSEQUENTIAL

85

DAMAGES, OR LOSS OF PROFITS, BUSINESS, REVENUE,

DATA, GOODWILL SAVINGS OR ANTICIPATED SAVINGS

REGARDLESS OF WHETHER SUCH LOSSES ARE

FORSEEABLE OR NOT.

THE MAXIMUM LIABILITY (THIS LIMITATION SHALL

NOT APPLY TO LIABILITY FOR PERSONAL INJURY TO

THE EXTENT APPLICABLE LAW PROHIBITS SUCH A

LIMITATION) OF HUAWEI ARISING FROM THE USE OF

THE PRODUCT DESCRIBED IN THIS MANUAL SHALL BE

LIMITED TO THE AMOUNT PAID BY CUSTOMERS FOR

THE PURCHASE OF THIS PRODUCT.

Import and Export Regulations

Customers shall comply with all applicable export or

import laws and regulations and be responsible to

obtain all necessary governmental permits and licenses

in order to export, re-export or import the product

mentioned in this manual including the software and

technical data therein.

Privacy Policy

To better understand how we protect your personal

information, please see the privacy policy at

http://consumer.huawei.com/privacy-policy.



86

V100R001_01
