Huawei F317 User Manual
F317
User Guide
1 Getting to know your F317
Front view
The figures in this guide are provided for your reference only.
1 Left
function
key
2 Navigation
keys
Access the main menu in standby mode.
Select the option displayed in the lower left corner of
the screen.
Access the main menu by pressing the OK key in
standby mode.
Access a shortcut menu by pressing the corresponding
navigation key in standby mode.
Adjust the volume by pressing the navigation keys
during a call.
2
3 Right
function
key
4 Call key
5 End key
6 Hands-free
key
7 Number
and symbol
keys
Select the option displayed in the lower right corner of the
screen.
Make or answer a call.
View the call log in standby mode.
End or reject a call.
Press and hold this key to power the phone on or off.
Return to the standby mode.
Make or answer a call without lifting the handset in
standby mode.
In the hands-free mode, cancel the dialing when dialing
a number or end the current call.
Enter numbers, letters, and symbols.
Access voicemail by pressing and holding 1 key in
standby mode.
Speed-dial a user-assigned phone number by pressing
and holding 2~9 key in standby mode.
Press # key to switch between text input methods in
editing mode.
Press * key to display the symbol list in editing mode.
3
Back and side view
1
2
3
4
5
6
7
1 Power jack 2 Battery cover
3 Coiled cord jack on main
unit
5 Battery container 6 Battery cord jack
7 Wall-mounting brackets
4 SIM card slot
2 Screen icons
Full reception
Calling
Alarm clock
Unread message
Powered by the power
adapter
4
Full battery
No service
Hands-free mode
Unopened voicemail
message
3 Installation
Ensure that F317 is powered off and disconnected from the power adapter.
Installing the SIM card
Ensure that the golden contacts of the SIM card are facing downward and that the
beveled edge of the SIM card is properly aligned with that of the SIM card slot. Then
check that the SIM card is fully inserted.
Do not frequently remove the SIM card when using F317.
Installing the battery
Ensure that the battery is correctly installed.
5
When new phones are delivered, the battery power is low. Therefore, charge the
screen of F317 may not function when you charge the battery again. This is normal
phone for a while and then power on the phone the first time you use it.
If the phone will not be used for a long time, remove the battery from the phone.
Connecting the power adapter
When you use F317, it is recommended that you connect the power adapter to F317.
If the battery has not been used for a long time or the battery is exhausted, the
After the battery is being charged for a while, you can power on the phone for use
The battery supplies power for only a limited period. Ensure that the battery has
been fully charged before putting it in use.
4 Powering on
Press and hold until the screen lights up to power on the phone.
Press and hold to power off the phone.
5 Calling
Making a call
1. In standby mode, press the number keys to enter a phone number.
6
