Huawei F253 User Manual
Sprint Phone Connect
User Guide
Table of Contents |
|
Table of Contents...................................................................................................................... |
i |
Introduction .............................................................................................................................. |
1 |
Package Contents........................................................................................................ |
1 |
Top View....................................................................................................................... |
3 |
Bottom View ................................................................................................................. |
4 |
Installation and Operation........................................................................................................ |
5 |
Installing the Battery..................................................................................................... |
5 |
Installing the Antenna................................................................................................... |
6 |
Installing the Power Adapter ........................................................................................ |
7 |
Connecting your Telephone to Sprint Phone Connect ................................................. |
8 |
Powering on the Device ............................................................................................... |
9 |
Understanding the Indicators ..................................................................................... |
10 |
Making Calls............................................................................................................... |
10 |
Receiving Calls .......................................................................................................... |
11 |
Adjusting the In-Call Volume...................................................................................... |
11 |
Adjusting the In-Call Volume in Standby Mode.................................................... |
11 |
Adjusting the In-Call Volume During a Call.......................................................... |
11 |
General Functions ................................................................................................................. |
13 |
Mounting the Device .................................................................................................. |
13 |
Horizontal Mounting ............................................................................................. |
13 |
Wall Mounting ...................................................................................................... |
13 |
Using Call Waiting...................................................................................................... |
14 |
Making a 3-Way Call .................................................................................................. |
14 |
Using Voice Mail......................................................................................................... |
15 |
Using Call Forwarding................................................................................................ |
15 |
Assistive Communication Devices ............................................................................. |
16 |
Troubleshooting ..................................................................................................................... |
17 |
Why am I not getting a dial tone on my handset?...................................................... |
17 |
Can I create a shortcut to access my voice mail?...................................................... |
17 |
Can I use my telephone answering device instead of voice mail? ............................ |
17 |
Does 911 work on this device? .................................................................................. |
18 |
Does this product work during a power outage?........................................................ |
18 |
How long is the battery life of Sprint Phone Connect?............................................... |
18 |
How does Caller ID (CID) work?................................................................................ |
18 |
Can I adjust the volume on my telephone?................................................................ |
19 |
How to set the TTY mode? ........................................................................................ |
19 |
Why do I get the recording, "Call cannot be completed as dialed?" .......................... |
19 |
Warnings and Precautions..................................................................................................... |
20 |
Introduction
This section introduces you the features of your new device.
Package Contents
Top View
Bottom View
Package Contents
After opening the package, check to make sure that you have all the parts shown below. If any item is missing or broken, please contact service provider.
Sprint Phone Connect |
Antenna |
Battery |
1
Getting Started Poster
Power Adapter |
Getting Started Poster |
Note:
The figures in this document are provided only for your reference. The actual shape and color of the product may differ slightly.
Customer must provide their own home telephone. Home telephone can be either traditional corded phone or cordless phone.
2
Top View
1
3 2
4
5
|
|
11 |
|
9 |
10 |
7 |
8 |
|
6
1 |
Power indicator |
7 |
Telephone port 1 |
2 |
Voice mail indicator |
8 |
Telephone port 2 |
3 |
Battery indicator |
9 |
DC 12V power port |
4 |
Signal indicator |
10 |
USB port* |
5 |
Signal strength indicator |
11 |
Antenna port |
6 |
Power on/off switch |
|
|
3
* Note: Never place a USB-based device into the USB port of the Sprint Phone Connect under any circumstances. Doing so may damage the device and negate its warranty. The port was designed for diagnostic purposes only; it is not intended for customer use.
Bottom View
1 |
2 |
3 |
4 |
1 |
Battery cover |
3 |
Battery port |
2 |
Battery slot |
4 |
Wall-mounting brackets |
4
Installation and Operation
Installing the Battery
Installing the Antenna
Installing the Power Adapter
Connecting your Telephone to Sprint Phone Connect
Powering on the Device
Understanding the Indicators
Making Calls
Receiving Calls
Adjusting the In-Call Volume
Installing the Battery
Remove the battery cover. Carefully insert the battery connection cable into the battery port, ensure that the battery terminals are not reversed. Place the battery in the battery slot and return the battery cover.
5
1
2
Note:
If the ambient temperature exceeds the temperature allowed for charging (–10°C to +50°C), the device stops charging the battery.
Talk time is approximately 2.5 hours and standby time is approximately 30 hours. Actual values will vary with the network environment.
The battery is intended for backup purposes only (in the event of a power failure).
When the power adapter is connected the battery will automatically charge.
When fully charged the battery will automatically stop charging.
Remove the battery if the device is not use for a long time.
Installing the Antenna
Make sure the device is turned off. Align the antenna with the antenna port on the device as illustrated below. Screw the antenna into the port, ensuring that the connection is secure.
6
