C223s
CDMA 1X Digital Mobile Phone
User Guide
Copyright © 2007 Huawei Technologies Co.,Ltd. All rights reserved.
and other trademarks are the property of Huawei Technologies Co., Ltd. All other trademarks
and trade names mentioned in this manual are the property of their respective holders. The information
in this manual is subject to change without notice. Every effort has been made in the preparation of this
manual to ensure accuracy of the contents, but all statements, information, and recommendations in
this manual do not constitute the warranty of any kind, express or implied. For any question of this
document, call the service hotline for details.
Huawei Technologies Co.,Ltd.
Huawei Industrial Base, Bantian, Longgang, Shenzhen 518129, People's Republic of China
Tel: +86-755-28780808 Global hotline: +86-755-28560808
Email: mobile@huawei.com
Website: www.huawei.com
1 Getting to Know Your Phone
Your Phone
1
2
3
4
6
8
5
7
9
12
1
10
11
Note
z There are two C223s models. One has a removable
user identity module (R-UIM) and the other does
not.
z This manual describes the C223s with the R-UIM. If
a function is marked with "'", it indicates that this
function is only available in the C223s with the
R-UIM. But the remaining functions are supported
by both the C223s models.
Appearance Descriptions
1
Earpiece
2
Screen
3
Navigation keys
4
Soft keys
5
OK key
6
Dialing key
7
End/Power key
–
–
Press to write mess age.
Press to view the calendar.
Press to access the inbox.
Press
z
z
z
z
z
z
z
to view the name list.
When the phone is closed, before
it is in the battery saving mode,
press
enable or disable the keyguard.
Select the option displayed on the
lower corner of the screen.
and to
Confirm a selection.
Access the FM screen.
Access the Call Records screen.
Make or answer a call.
Power on or off the phone (by
pressing and holding it).
2
z
End or reject a call.
z
Return the Idle screen.
8
Number keys
9
* key
10
# key
11
Speaker
12
Charger interface
z
Press and hold 1 to access Voice
Mail.
z
Press and hold 2–9 to speed dial a
phone number.
z
Press and hold 0 access the FM.
Enable or disable the vibration mode
(by pressing and holding it).
Enable the phone lock (by pressing
and holding it).
–
–
Screen Icons
Icon Meaning Icon Description
Signal strength
Phone lock
New voice mail
Non-service
New Message
Urgent message
High urgent message
Calling in roaming
CDMA 1X
Silence mode
Vibration
Alarm clock
Call privacy
Battery level
Roaming
Calling
Headset
3
2 Menu Tree
Messages Phonebook Call Records
1 Write Message
2 Inbox
3 Outbox
4 Draftbox
5 Voice Mail
6 Delete All
7 Settings
Extras
1 Alarms
2 Calendar
3 Calculator
4 Stopwatch
5 Time Zone
6 Games
7 FM
1 Search
2 Add New
3 Groups
4 Speed Dial
5 Delete All
'Copy All
6
7Options
Sound
1 Volume
2 Alert Mode
3 Ring Tone
4 Alarm Tone
5 SMS Receive Tone
6 SMS Send Tone
7 Other Tones
1 Missed Calls
2 Answered Calls
3 Dialed Calls
4 Delete All
5 Call Duration
Settings
1 Display
2 Time
3 Call
4 Language
5 Security
6 Factory Restore
7 Keyguard
4
3 Getting Started
Installing the Battery
To install the battery, do as follows.
1
2
3
① ② ③
Removing the Battery
To remove the battery, do as follows.
1
2
① ②
"'"Installing/Removing the UIM Card
After removing the battery, do as follows to install or remove the
UIM card.
5
