HTC 601HT User Manual
User guide
HTC 601HT
2 Basics
About this guide
In this user guide, we use the following symbols to indicate useful and important
information:
This is a note. A note often gives additional information, such as what happens
when you choose to do or not to do a certain action. A note also provides
information that may only be applicable to some situations.
This is a tip. A tip gives you an alternative way to do a particular step or
procedure, or lets you know of an option that you may find helpful.
This indicates important information that you need in order to accomplish a
certain task or to get a feature to work properly.
This provides safety precaution information, that is, information that you need
to be careful about to prevent potential problems.
Some apps may not be available in all regions or with your mobile operator.
HTC Confidential
CE/FCC Certification
HTC Confidential
CE/FCC Certification
HTC Confidential
CE/FCC Certification
HTC Confidential
1 Important note on recoverable data
Important note on
recoverable data
Files and other data that have been deleted, cleared, removed, or erased from your
device may still be recoverable by third-party data recovery software. Even a factory
reset may not permanently erase all data from your mobile device, including personal
information.
HTC Confidential
CE/FCC Certification
HTC Confidential
CE/FCC Certification
HTC Confidential
CE/FCC Certification
HTC Confidential
2 Features you'll enjoy
Features you'll enjoy
What's special with Camera
Enjoy taking great camera shots on HTC Phone. The Camera app has a simple
interface, neatly organized to make it faster for you to switch modes and change your
settings.
Lean and clean camera interface
The camera interface groups related capture modes together—such as photo capture
modes—so that you can quickly find the mode you want, and puts modes and their
settings side by side for easy access.
HTC Confidential
CE/FCC Certification
Without having to open the slideout menu, you can easily switch back to Photo or
Video mode from other modes by tapping
also just tap
to quickly switch between the front and main camera.
HTC Confidential
See Taking photos and videos.
CE/FCC Certification
or
below the shutter button. You can
HTC Confidential
CE/FCC Certification
HTC Confidential
3 Features you'll enjoy
Two ways to adjust exposure
Tap the screen, and then drag your finger up or down to manually adjust the
exposure. Or turn on the Touch autoexposure option in the camera settings so you can
simply tap the screen to automatically set the exposure.
See Quickly adjusting the exposure of your photos.
Anti-shake lens
HTC Confidential
Optical Image Stabilization (OIS) reduces blur from hand movements while you shoot.
You'll get sharper, brighter photos with more clarity, even in low light.
CE/FCC Certification
Selfies
Capture awesome selfies with the front facing camera. See Selfies.
Live Makeup – Before taking your selfie, use Live Makeup to smoothen your skin.
See Applying skin touch-ups with Live Makeup.
HTC Confidential
Instant selfie shots – Flash a smile, and the camera instantly captures your
smiling face. Or, just say "Cheese!" See Taking selfies automatically and Taking
selfies with voice commands.
Enjoy taking wide-angle selfies with family or friends and with a panoramic
scenery behind you. See Taking a panoramic selfie.
CE/FCC Certification
HTC Confidential
CE/FCC Certification
HTC Confidential
4 Features you'll enjoy
Capture video in 3D Audio or high res audio
HTC Phone has four highly-sensitive omnidirectional microphones that capture
positional sound in your video recordings. This means that you can record sound in
360 degrees for immersive audio that’s just like being there. Or, you can record video
with 24-bit high resolution audio. See Recording video in 3D Audio or high resolution
audio.
Pro level capabilities
Pro mode gives you professional level control over your photography. Capture RAW
photos and take full control over your camera settings. See Taking a RAW photo and
Manually adjusting camera settings .
The camera captures RAW photos in DNG format. The RAW file provides more image
information for post processing in the Google Photos™ app or a graphics program on
your computer.
Hyperlapse
Hyperlapse lets you speed up the action up to 12 times, and select sections of the
video to change its speed. See Recording a Hyperlapse video.
HTC Confidential
Immersive sound
CE/FCC Certification
Discover audio bliss on HTC Phone through its earphones. Easily connect wireless
speakers to your phone.
HTC USonic
Experience music tuned to your ears. When you plug in the HTC USonic earphones to
HTC Phone, they will scan your ears to determine the audio output level that best suits
you. This tuning process happens almost instantly. The earphones can also dynamically
adjust audio based on sound levels around you.
See Tuning your HTC USonic earphones for details.
HTC Confidential
CE/FCC Certification
The HTC USonic earphones can only be used with HTC Phone and other
compatible HTC phones supporting HTC USonic.
HTC Confidential
CE/FCC Certification
HTC Confidential
5 Features you'll enjoy
Record audio in high res quality
Enable high res quality audio in Voice Recorder to make crystal clear audio recordings.
See Enabling high resolution audio recording for details.
HTC Connect
Simply swipe up the screen with three fingers to stream music or video from HTC
Phone to your speakers or TV. Control the volume and playback with your phone! You
can even enjoy your favorite music on multiple speakers. See What is HTC Connect?.
Fingerprint sensor
You can use the fingerprint scanner on HTC Phone to quickly wake up and unlock your
phone with your fingerprint.
HTC Confidential
CE/FCC Certification
HTC Confidential
You can register up to 5 fingerprints. See Fingerprint scanner.
CE/FCC Certification
Truly personal
Designed with you in mind, HTC Phone is filled with innovations that help it to adapt to
your life.
HTC Confidential
CE/FCC Certification
HTC Confidential
6 Features you'll enjoy
Themes
Make HTC Phone more personal by customizing how it looks with your own photos
and then mix and match with different sets of icons, sounds, color schemes, and more.
Image showing different themes.
More wallpaper types, such as Multiple wallpapers and Apps screen wallpapers, are
also in store!
See What is HTC Themes? for more details.
Freestyle home screen
HTC Confidential
If you want to take designing your Home screen to the next level, try the Freestyle
home screen layout for zero-grid limitations and fun stickers to replace your app icons.
CE/FCC Certification
HTC Confidential
CE/FCC Certification
Image showing the Freestyle layout.
HTC Confidential
CE/FCC Certification
HTC Confidential
7 Features you'll enjoy
HTC BlinkFeed
Get your favorite topics, news, social media, and more conveniently delivered to
one place on your phone. Even get suggestions for places to eat! You can also play
embedded videos right on HTC BlinkFeed™. See What is HTC BlinkFeed?.
HTC Confidential
CE/FCC Certification
Boost+
Use the Boost+ app to help you optimize your phone's performance by allocating
resources, removing junk files, stopping irregular app activities, and uninstalling the
apps you don't use.
You can also set this app to help extend battery life while you're playing your favorite
game on HTC Phone.
HTC Confidential
CE/FCC Certification
Image showing HTC Boost plus.
See About Boost+.
HTC Confidential
CE/FCC Certification
HTC Confidential
8 Features you'll enjoy
Android 7.0 Nougat
Android™ 7.0 Nougat brings new features that make working with apps and settings
even more convenient.
Multi-tasking made easy
Aside from flipping through running apps, there are faster ways to use the RECENT
APPS button
Want to watch a video while chatting at the same time? Use the split-screen
view to display two running apps side by side.
Quickly switch to the previous app with a double tap.
For details, see Multi-tasking.
Enhanced notifications
See incoming information on a notification without having to open an app. If you
received a new message, you can directly send a reply right from the notification. See
Notifications panel.
for switching between apps.
HTC Confidential
CE/FCC Certification
Improved settings
Limit how much mobile data your phone uses. When you turn Data Saver on,
apps in the background won't be able to use the data connection unless you've
set these apps to access mobile data. See Data Saver.
Use the Quick Settings bar to toggle Wi-Fi® and other quick settings on and off.
See Using Quick Settings.
No more navigating back to the main settings screen by screen. There's a
HTC Confidential
slideout menu that you can open anytime to directly access the main settings.
See Getting to know your settings.
At the top of the Settings screen, see suggestions for how to get more out of
your phone.
Aside from changing the font size, you can also adjust the display size of items
such as icons and images. See Adjusting the display size.
CE/FCC Certification
HTC Confidential
CE/FCC Certification
HTC Confidential
9 Unboxing and setup
Unboxing and setup
HTC Phone overview
After taking HTC Phone out of the box, familiarize yourself first with the location of the
card tray and the different button controls.
Dual SIM card support varies by phone model, region, and country.
HTC Confidential
CE/FCC Certification
HTC Confidential
CE/FCC Certification
1. POWER 7. nano SIM and storage card tray
2. VOLUME buttons 8. BACK
3. Microphone 9. USB Type-C™ connector
4. Front camera 10. HOME / Fingerprint scanner
5. Proximity sensor 11. RECENT APPS
6. Notification LED 12. HTC BoomSound™ Hi-Fi edition speakers
You need a 4G/LTE™ plan to use your operator's 4G/LTE network for voice calls
and data services. Check with your operator for details.
HTC Confidential
CE/FCC Certification
HTC Confidential
10 Unboxing and setup
If you want to use a case or screen protector, don’t cover and block the
proximity sensor. Purchase a case or screen protector designed for HTC
Phone.
Avoid liquid or dust from entering the microphone hole to prevent damage to
the microphone.
Don’t disassemble any part of the phone. Don’t try to open the phone or
remove the battery by force. This may damage the phone or its electronics
and will invalidate the warranty.
Back panel
HTC Confidential
CE/FCC Certification
1. Microphone
2. Main camera with OIS and PDAF
3. Dual LED flash
HTC Confidential
CE/FCC Certification
OIS stands for Optical Image Stabilization.
PDAF stands for Phase Detection AutoFocus.
HTC Confidential
CE/FCC Certification
HTC Confidential
11 Unboxing and setup
Card tray
When inserting the eject tool into the tray eject hole to remove the card tray, make
sure not to press on the tray to avoid damaging the eject mechanism inside the slot.
Also, if you want to use a protective case, make sure to buy a case that's designed for
HTC Phone and that doesn't block the tray.
nano SIM card
On HTC Phone, use a standard nano SIM card.
Inserting a modified card that is thicker than the standard nano SIM card may cause
the card to not fit properly or damage the card slot.
HTC Confidential
CE/FCC Certification
HTC Confidential
CE/FCC Certification
HTC Confidential
CE/FCC Certification
HTC Confidential
12 Unboxing and setup
Inserting the nano SIM card
1. Hold the phone face up.
2. Insert the tip of the tray eject tool that came with your phone—or a small bent
paperclip—into the tray eject hole.
3. Push the tip all the way into the hole until the tray ejects, and then pull the tray
out.
4. Do the following to place your nano SIM card into the tray:
Single SIM model: With your nano SIM card's gold contacts facing down, place
the card into the SIM holder of the tray. Make sure to align the cuto corner to
the notch on the holder.
HTC Confidential
CE/FCC Certification
HTC Confidential
Place your microSD™ card into the SD holder of the tray. See Inserting the
microSD card.
CE/FCC Certification
HTC Confidential
CE/FCC Certification
HTC Confidential
13 Unboxing and setup
Dual SIM model: With the gold contacts facing down, place your nano SIM cards
into the SIM 1 and SIM 2 holders of the tray. Make sure to align the cuto corners
to the notches on the holders.
Dual SIM model: By default, SIM 1 will connect to the 4G LTE/3G network,
and SIM 2 will connect to 3G/2G. To find out how to set the preferred card for
connecting to 4G LTE, see Managing your nano SIM cards with Dual network
manager.
SIM 2 and SD are labeled on the same holder in the tray. Either place your
second nano SIM card or a microSD card into this holder. Both cards can’t be
inserted at the same time.
HTC Confidential
5. When reinserting the tray, make sure it is facing up so that your cards don't fall
out. Hold the tray with the outer card holder between your fingers, and then
steadily slide the tray all the way into the slot.
CE/FCC Certification
Dual SIM model:
HTC Confidential
CE/FCC Certification
HTC Confidential
6. Press on the cover that's attached to the tray to close it tightly.
CE/FCC Certification
HTC Confidential
14 Unboxing and setup
Removing the nano SIM card
Make sure to switch off HTC Phone before removing the card.
1. Hold the phone face up.
Insert the tip of the tray eject tool or a small bent paperclip into the tray eject
hole.
2. Push the tip all the way into the hole until the card tray ejects.
3. Pull the tray out, and then remove the nano SIM card.
4. To reinsert the tray, center it first in the slot, and then slide it all the way in.
HTC Confidential
5. Press on the cover that's attached to the tray to close it tightly.
Storage card
CE/FCC Certification
Use a storage card to store your photos, videos, and music.
When you need to free up phone storage space, you can also move certain apps to the
storage card, if the apps support this feature.
The storage card is optional and sold separately.
HTC Confidential
Inserting the microSD card
1. Hold the phone face up.
2. Insert the tip of the tray eject tool that came with your phone—or a small bent
paperclip—into the tray eject hole.
CE/FCC Certification
HTC Confidential
CE/FCC Certification
HTC Confidential
15 Unboxing and setup
3. Push the tip all the way into the hole until the tray ejects, and then pull the tray
out.
Dual SIM model: SIM 2 and SD are labeled on the same holder in the tray. Remove your
second nano SIM card when you want to use your microSD card. Both cards can’t be
inserted at the same time.
HTC Confidential
4. Place your microSD card—gold contacts facing down and narrow side facing in—
into the SD holder of the tray.
CE/FCC Certification
HTC Confidential
CE/FCC Certification
HTC Confidential
CE/FCC Certification
HTC Confidential
16 Unboxing and setup
5. When reinserting the tray, make sure it is facing up so that the nano SIM and
microSD cards don’t fall out. Hold the tray with the outer card holder between
your fingers, and then steadily slide the tray all the way into the slot.
6. Press on the cover that's attached to the tray to close it tightly.
If it's the first time you insert a microSD card, you'll be prompted to set it up.
HTC Confidential
CE/FCC Certification
Unmounting the storage card
When you need to remove the storage card while HTC Phone is on, unmount the
storage card first to prevent corrupting or damaging the files in the storage card.
If your storage card is used as internal storage and there are apps that were
moved to the card, you will not be able to open these apps after unmounting
the card.
1. From the Home screen, tap
2. Do one of the following:
HTC Confidential
If your storage card appears under Removable storage, tap
card name, and then tap Eject.
CE/FCC Certification
If your storage card appears under Internal storage, tap the card name, and
then tap
> Eject.
> Settings > Storage.
next to the
HTC Confidential
CE/FCC Certification
HTC Confidential
17 Unboxing and setup
Removing the microSD card
Make sure to unmount your microSD card before removing it. See Unmounting
the storage card.
1. Hold the phone face up.
2. Insert the tip of the tray eject tool that came with your phone—or a small bent
paperclip—into the tray eject hole.
3. Push the tip all the way into the hole until the tray ejects.
4. Pull the tray out, and remove the microSD card.
After removing the microSD card, make sure that you insert the empty tray back into
the slot.
HTC Confidential
Charging the battery
CE/FCC Certification
Before you turn on and start using HTC Phone, it is recommended that you charge the
battery.
If the battery has been discharged for several days, you may need to charge
HTC Phone for several minutes before powering it on.
Use only the adapter and the USB Type-C cable that came with HTC Phone
HTC Confidential
to charge the battery. When the battery power is too low, make sure to
use the power adapter to charge, not the USB cable connection with your
computer.
1. Insert the small end of the USB Type-C cable into the USB Type-C connector.
CE/FCC Certification
HTC Confidential
CE/FCC Certification
2. Insert the other end of the USB Type-C cable into the power adapter.
3. Plug in the power adapter to an electrical outlet to start charging the battery.
HTC Confidential
18 Unboxing and setup
As a safety precaution, the battery may stop charging to avoid overheating.
Avoid charging the battery in hot environments.
When you're using the web browser and charging the battery, HTC Phone
may become warmer. This is normal.
To conserve energy, unplug the power adapter from the electrical outlet after
you finish charging.
Switching the power on or off
Switching the power on
Press the POWER button until HTC Phone vibrates.
When you turn on HTC Phone for the first time, you’ll need to set it up.
Switching the power off
1. If the display is off, press the POWER button to turn it back on.
2. Press and hold the POWER button for a few seconds.
3. Tap Power off on the options menu.
HTC Confidential
Choosing which nano SIM card to connect to
CE/FCC Certification
the 4G LTE network
When you have two nano SIM cards inserted on your phone, only one card can
connect to the faster 4G LTE network. The other card will connect to the 3G/2G
network.
You can set which card you want to connect to the 4G LTE network.
HTC Confidential
1. From the Home screen, tap
2. Tap Preferred data network.
3. Choose the card you want to connect to the 4G LTE network.
Managing your nano SIM cards with Dual
network manager
CE/FCC Certification
> Settings > Dual network manager.
Dual SIM card support varies by phone model, region, and country.
From the Home screen, tap
either slot on or off, change the slot names, and more.
> Settings > Dual network manager. You can turn
CE/FCC Certification
HTC Confidential
HTC Confidential
19 Unboxing and setup
Setting up HTC Phone for the first time
When you switch on HTC Phone for the first time—or after you've done a factory
reset—you’ll be asked to set it up.
You can enable TalkBack to navigate by voice feedback before selecting the
language. Press and hold two fingers on the screen until you hear a message
saying that accessibility mode is enabled.
Walk through the on-device setup to choose your Internet connection, sign in to your
Google® Account, set up device protection for HTC Phone, and more.
Use Android Backup Service if you've used it to back up your old phone before. On
the screen that asks you which device to restore from, tap the name of your old phone
model. Tap
to proceed.
Otherwise, tap Don't restore.
If you have content such as media files and data that you need to transfer from an old
phone, see Ways of transferring content from your previous phone.
to choose the type of items you want to restore, and then tap Restore
Some features that need to connect to the Internet such as location-based
services and auto-sync of your online accounts may incur extra data fees.
To avoid incurring data fees, disable these features under Settings. For more
information on location services, see Turning location services on or off.
HTC Confidential
Adding your social networks, email accounts,
CE/FCC Certification
and more
You can sync contacts, calendars, and other information from your social networks,
email accounts, and online services on HTC Phone.
Depending on the account type, signing in to your online accounts lets you sync
updates between HTC Phone and the Web.
HTC Confidential
1. From the Home screen, tap
2. Tap
.
CE/FCC Certification
3. Tap the account type you want to add.
4. Follow the onscreen instructions to enter your account information.
In Settings > Accounts & sync, tap the Auto sync On/Off switch to turn
automatic sync of all your accounts.
You can add several Google Accounts.
> Settings > Accounts & sync.
HTC Confidential
CE/FCC Certification
HTC Confidential
20 Unboxing and setup
Syncing your accounts
1. From the Home screen, tap > Settings > Accounts & sync.
2. Tap the Auto syncOn/Off switch to turn automatic sync of all your accounts on
or off.
3. To manually sync individual accounts, tap an account type, and then tap
Sync now on the Account settings screen.
On the Account settings screen, you can also change the sync settings for an
account.
Removing an account
Remove accounts from HTC Phone if you no longer use them.
Removing an account does not remove accounts and information from the online
service itself.
1. From the Home screen, tap
2. Tap an account type.
If you've signed into multiple accounts under an account type, tap the account to
remove.
3. Tap
HTC Confidential
Some personal data may be retained by the third-party app after you have
removed the account from HTC Phone.
> Remove account.
CE/FCC Certification
Fingerprint scanner
>
> Settings > Accounts & sync.
You can quickly wake up and unlock the HTC Phone using your fingerprint.
You can add up to 5 fingerprints.
When setting up and using the fingerprint scanner, follow these tips:
HTC Confidential
Make sure your finger and the fingerprint scanner are dry and clean.
Use the entire pad of your finger, including the sides and tip.
When recording your fingerprint, touch the scanner until it vibrates.
The fingerprint scanner has 360° readability—you can touch a recorded finger at
any angle to the scanner to turn on the screen or unlock the HTC Phone.
You may not be able to set the fingerprint scanner to unlock HTC Phone, if
you've signed in to an Exchange ActiveSync® account that requires you to set
a different screen lock option (such as password). Check with your Exchange
Server administrator if your Exchange ActiveSync account supports the
fingerprint scanner.
CE/FCC Certification
HTC Confidential
CE/FCC Certification
HTC Confidential
21 Unboxing and setup
Adding a fingerprint the first time
1. From the Home screen, tap , and then tap Settings > Fingerprint scanner.
2. Tap Add fingerprint.
If you haven't already set up a lock screen pattern, PIN, or password, you'll be asked to
set one up. See Setting a screen lock.
3. Tap Start.
4. Choose which finger or thumb to use, touch the scanner until it vibrates, then lift
your finger or thumb.
5. Repeatedly touch the scanner until the fingerprint has been successfully
recorded. You'll get the best results if you hold your finger in the same direction
when touching the scanner.
6. After you've successfully recorded your fingerprint, tap Done.
You can now use your fingerprint to wake up and unlock your HTC Phone.
You'll need to input your backup lock screen pattern, PIN, or password if the
scanner doesn't identify your fingerprint after five attempts. You'll only have 10
additional attempts before your data is deleted from the HTC Phone.
Adding, removing, or editing fingerprints
HTC Confidential
1. From the Home screen, tap , and then tap Settings > Fingerprint scanner.
2. Enter your pattern, PIN, or password.
3. Do any of the following:
CE/FCC Certification
Tap Add fingerprint to add another fingerprint.
Tap a recorded fingerprint to rename or delete it.
Tap Reset fingerprint scanner to delete all recorded fingerprints.
Select Wake up screen if you want to be able to tap the fingerprint scanner
to wake up and unlock the screen.
HTC Confidential
CE/FCC Certification
HTC Confidential
CE/FCC Certification
HTC Confidential
22 Your first week with your new phone
Your first week with your
new phone
HTC Sense Home
After you've turned on and set up HTC Phone for the first time, you'll see the Home
screen.
Swipe right and you'll find HTC BlinkFeed. You can customize HTC BlinkFeed to
show posts from your social networks, headlines from your favorite news media,
and more. For details, see What is HTC BlinkFeed?.
Swipe left and you’ll discover space for adding your favorite widgets, apps, and
more so they’re just a tap away. You can also add panels. For details, see Adding
or removing a widget panel.
You can change the apps on the launch bar at the bottom of the Home screen.
See Launch bar.
HTC Confidential
While you're in another screen or app, press HOME to return to the last Home
screen you visited.
CE/FCC Certification
Sleep mode
Sleep mode saves battery power by putting HTC Phone into a low power state while
the display is off.
It also stops accidental button presses when HTC Phone is in your bag.
Switching to Sleep mode
To turn off the display and switch to Sleep mode, briefly press the POWER button. You
can also double-tap the lock screen.
HTC Phone also automatically goes into Sleep mode when it’s left idle for a while.
You can change the time before HTC Phone sleeps by setting the screen timeout. For
details, see Setting when to turn off the screen.
HTC Confidential
CE/FCC Certification
HTC Confidential
Waking up from Sleep mode
Press the POWER button.
Use Motion Launch™ to wake up and unlock your phone directly to an app or
screen. See Motion Launch.
CE/FCC Certification
HTC Confidential
23 Your first week with your new phone
Lock screen
Swipe up on the lock screen to unlock the screen.Or, press and hold the
fingerprint sensor.
Tap twice on a notification to go directly to the related app.
Swipe left or right on the notification to remove it.
Press and hold a notification to mute or block notifications from the related app.
Tap More settings to customize the notification settings.
If you don't want notification content to appear on the lock screen, go to Settings >
Sound & notification > On the lock screen, and then tap Don't show notifications at all.
If you want to set up a screen lock or Smart lock, see Setting a screen lock for
details.
Motion gestures
Use motion gestures to mute HTC Phone, lower the ring volume, and more.
Lift phone to auto answer a call
HTC Confidential
To automatically answer an incoming call, lift the phone and look at the screen first to
see who's calling before you hold it to your ear.
You can turn this feature on or off. In Settings > Call, select or clear Auto answer calls.
CE/FCC Certification
Flip to mute
HTC Confidential
CE/FCC Certification
HTC Confidential
If your phone is facing up when a call comes in, turn the phone over to mute it.
If you go to Settings and then tap Sound & notification > Flip to mute, you can set
your phone to:
CE/FCC Certification
HTC Confidential
24 Your first week with your new phone
Mute once Mute only once after flipping the phone. While the phone is still
facing down, it will ring again when there are other incoming
calls.
Mute always After flipping the phone to mute a call, keep it always muted
while it's still facing down when there are other incoming calls.
Pick up to lower volume
HTC Confidential
In a business meeting or restaurant, pick HTC Phone up when a call comes in to lower
CE/FCC Certification
the ring volume automatically.
You can turn this feature on or off. Go to Settings, tap Sound & notification, and then
select or clear Quiet ring on pickup.
HTC Confidential
CE/FCC Certification
HTC Confidential
CE/FCC Certification
HTC Confidential
25 Your first week with your new phone
Increase ring volume automatically while
phone is in your pocket or bag
Pocket mode makes HTC Phone recognize when your phone is in your bag or pocket
and raise the ring volume so that you can hear it in noisy environments.
You can turn this feature on or off. Go to Settings, tap Sound & notification, and then
HTC Confidential
CE/FCC Certification
select or clear Pocket mode.
Rotate HTC Phone for a better view
HTC Confidential
CE/FCC Certification
For many screens, you can automatically change the screen orientation from portrait
to landscape by turning HTC Phone sideways.
When entering text, you can turn HTC Phone sideways to bring up a bigger keyboard.
CE/FCC Certification
HTC Confidential
HTC Confidential
26 Your first week with your new phone
Touch gestures
Use touch gestures to get around the Home screen, open apps, scroll through lists,
and more.
Tap
HTC Confidential
Tap the screen with your finger when you want to select onscreen items such as
application and settings icons, or press onscreen buttons.
CE/FCC Certification
Press and hold
HTC Confidential
CE/FCC Certification
HTC Confidential
CE/FCC Certification
To open the available options for an item (for example, a contact or link in a webpage),
just press and hold the item.
HTC Confidential
27 Your first week with your new phone
Swipe or slide
Quickly swipe your finger horizontally across the screen to go to other Home screen
panels. Swipe vertically to scroll through a list, document, and more.
HTC Confidential
Drag
CE/FCC Certification
HTC Confidential
CE/FCC Certification
Press and hold your finger with some pressure before you start to drag. While
dragging, don't release your finger until you have reached the target position.
HTC Confidential
CE/FCC Certification
HTC Confidential
28 Your first week with your new phone
Flick
Flicking the screen is similar to swiping, except that you need to swipe your finger
in light, quicker strokes, such as when moving right and left on the Home screen, or
flicking through a contacts or message list.
Press and flick
HTC Confidential
CE/FCC Certification
HTC Confidential
CE/FCC Certification
On the Home screen, you can easily move a widget or icon from one screen to
another.
HTC Confidential
Press and hold the widget or icon with one finger, and flick the screen to the new
location with another finger.
CE/FCC Certification
HTC Confidential
Loading...
