HTC 2Q3F300 User Manual
User guide
HTC Confidential 20170630
For Certification Only
HTC Phone
18 Unboxing and setup
HTC Confidential 20170630
For Certification Only
Unboxing and setup
HTC Phone overview
After taking HTC Phone out of the box, familiarize yourself first with the location of the card tray
and the different button controls.
1. POWER
2. VOLUME buttons
3. Proximity sensor
4. Front camera
5. Notification LED
6. Microphone
7. nano SIM and storage card tray
8. Edge Sense squeeze area
9. BACK
10. HOME / Fingerprint scanner
11. Speaker
12. RECENT APPS
13. USB Type-C™ connector
You need a 4G/LTE™ plan to use your operator's 4G/LTE network for voice calls and data services.
Check with your operator for details.
§ If you want to use a case or screen protector, don’t cover and block the proximity sensor and
Edge Sense area. Purchase a case or screen protector designed for HTC Phone.
§ Don’t disassemble any part of the phone. Don’t try to open the phone or remove the battery by
force. This may damage the phone or its electronics and will invalidate the warranty.
19 Unboxing and setup
HTC Confidential 20170630
For Certification Only
Back panel
1. Main camera with BSI and PDAF
2. LED flash
§ BSI means BackSide Illumination sensor.
§ PDAF means Phase Detection Auto Focus.
Card tray
When inserting the eject tool into the tray eject hole to remove the card tray, do not obstruct the
tray to avoid damaging the eject mechanism inside the slot.
20 Unboxing and setup
HTC Confidential 20170630
For Certification Only
nano SIM card
Use a standard nano SIM card. A modified card that is thicker than the standard nano SIM card will
not fit properly on the tray and may damage the card slot.
Inserting the nano SIM card
1. Hold the phone face up.
2. Insert the tip of the tray eject tool that came with your phone—or a small bent paperclip—
into the tray eject hole.
3. Push the tip all the way into the hole until the tray ejects, and then pull the tray out.
21 Unboxing and setup
HTC Confidential 20170630
For Certification Only
4. Do the following to place your nano SIM card into the tray:
§ Single SIM model: With your nano SIM card's gold contacts facing down, place the card
into the SIM holder of the tray. Make sure to align the cutoff corner to the notch on the
holder.
Place your microSD™ card into the SD holder of the tray. See Inserting the microSD
card on page 23.
5. When reinserting the tray, make sure it is facing up so that your cards don't fall out. Hold the
tray with the outer card holder between your fingers, and then steadily slide the tray all the
way into the slot.
6. Make sure the tray is fully inserted and doesn't protrude from the slot.
22 Unboxing and setup
HTC Confidential 20170630
For Certification Only
Removing the nano SIM card
1. Hold the phone face up.
2. Insert the tip of the tray eject tool or a small bent paperclip into the tray eject hole.
3. Push the tip all the way into the hole until the card tray ejects.
4. Pull the tray out, and then remove the nano SIM card.
5. To reinsert the tray, center it first in the slot, and then slide it all the way in.
6. Make sure the tray is fully inserted and doesn't protrude from the slot.
Storage card
Use a storage card to store your photos, videos, and music. When you need to free up phone storage
space, you can also move certain apps to the storage card, if the apps support this feature.
The storage card is optional and sold separately.
23 Unboxing and setup
HTC Confidential 20170630
For Certification Only
Inserting the microSD card
1. Hold the phone face up.
2. Insert the tip of the tray eject tool that came with your phone—or a small bent paperclip—
into the tray eject hole.
3. Push the tip all the way into the hole until the tray ejects, and then pull the tray out.
4. Place your microSD card—gold contacts facing down and narrow side facing in—into the SD
holder of the tray.
24 Unboxing and setup
HTC Confidential 20170630
For Certification Only
5. When reinserting the tray, make sure it is facing up so that the nano SIM and microSD cards
don’t fall out. Hold the tray with the outer card holder between your fingers, and then
steadily slide the tray all the way into the slot.
6. Make sure the tray is fully inserted and doesn't protrude from the slot.
If it's the first time you insert a microSD card, you'll be prompted to set it up.
Unmounting the storage card
When you need to remove the storage card while HTC Phone is on, unmount the storage card first
to prevent corrupting or damaging the files in the storage card.
If your storage card is used as internal storage and there are apps that were moved to the card,
you will not be able to open these apps after unmounting the card.
1. From the Home screen, tap Settings Storage.
2. Do one of the following:
§ If your storage card appears under Removable storage, tap next to the card name,
and then tap Eject.
§ If your storage card appears under Internal storage, tap the card name, and then tap
Eject.
25 Unboxing and setup
HTC Confidential 20170630
For Certification Only
Removing the microSD card
Make sure to unmount your microSD card before removing it. See Unmounting the storage card
on page 24.
1. Hold the phone face up.
2. Insert the tip of the tray eject tool that came with your phone—or a small bent paperclip—
into the tray eject hole.
3. Push the tip all the way into the hole until the tray ejects.
4. Pull the tray out, and remove the microSD card.
5. To reinsert the tray, center it first in the slot, and then slide it all the way in.
6. Make sure the tray is fully inserted and doesn't protrude from the slot.
