HPE ProLiant DL385
Gen10 Server
ProLiant DL Servers
Digital data sheet
What's new
We enhanced two popular SKUs to address
·
our customers workload needs. P11747-
B21, comes with the popular HPE Smart
Array P408i-a SR Gen10 Controller
providing storage performance our
customers demand.
Additionally, P11809-B21 comes with the
·
HPE Flexible Slot 800W power supply. The
new standard for most of our customer’s;
allowing for richer configurations while still
Overview
Do you need a platform purpose-built to address your High
Performance Computing, virtualized, and memory-centric
workloads? Try something EPYC™. Hewlett Packard Enterprise is
extending the worlds' most secure industry standard servers [1]
to include the HPE ProLiant DL385 Gen10 server, utilizing the
AMD EPYC 7000 Series processors. This platform has been
designed with the security you need and the flexibility you
require to accommodate demanding enterprise workloads. With
up to 64 cores, up to 32 DIMMs, or 4 TB memory capacity and
support for up to 24 NVMe drives, the HPE ProLiant DL385
Gen10 server delivers a low cost virtual machine (VM) with
Digital data sheet Page 2
unprecedented security.
maintaining full redundancy.
The AMD EPYC 7371 is a 16 core, 3.1 GHz
·
CPU with max boost to 3.8 GHz! Perfect for
electronic design automation, high-
frequency-trading w/enterprise
infrastructure, transcoding, web serving and
more!
The AMD EPYC 7261 has 8 core and is 2.5
·
GHz with all core boost to 2.9 GHz. It also
has double the L3 cache over the AMD
EPYC 7251. Perfect for your low core count,
high-frequency requirements!
HPE ProLiant DL385 Gen10 now has
·
multiple vSAN ReadyNode configurations, to
provide you with the most flexible server
options to build your Hyper-Converged
Infrastructure.
HPE InfoSight provides a cloud-based
·
analytics tool that predicts and prevents
problems before your business is impacted.
Features
Security Innovations
HPE ProLiant DL385 Gen10 server has security protection built in across the
server life cycle starting with silicon root of trust. Only Hewlett Packard Enterprise
offers industry standard servers with major firmware anchored directly into the
silicon.
Millions of lines of firmware code run before server operating system boots. What's
more, with Runtime Firmware Validation, enabled by HPE iLO Advanced Premium
Security Edition, the server firmware is checked every 24 hours verifying validity
and credibility of essential system firmware.
Secure Recovery allows server firmware to roll back to the last known good state or
factory settings after detection of compromised code.
The AMD EPYC processor provides several security related features, including
AMD secure processor, secure memory encryption (SME), and secure encrypted
virtualization (SEV). These features are used to help enable key security
functionality including Secure Root of Trust, Secure Run, and Secure Move.
Flexible Design
HPE ProLiant DL385 Gen10 server has an adaptable chassis, including the
modular drive bays that can be configured with up to 30 SFF, up to 19 LFF or up to
24 NVMe drive options along with support for up to 3 double wide GPU options.
HPE Smart Array S100i Software RAID ships standard for embedded m.2 boot, and
the redesigned HPE Smart Array Essential and Performance RAID Controllers for
performance or additional features including the ability to operate in both SAS and
HBA mode.
Along with an embedded 4x1GbE, you have a choice of HPE FlexibleLOM or PCIe
standup adapters which offer a choice of networking bandwidth (1GbE to
4x10GbE) and fabric so you can adapt and grow to changing business needs.
This server supports a wide range of operating systems making it suitable for most
environments.
World-class Performance
HPE ProLiant DL385 Gen10 server supports industry standard technology
leveraging the AMD EPYC 7000 Series Processor with up to 32 cores, 12 Gb SAS
and 4.0 TB of HPE DDR4 SmartMemory.
Supports up to three double wide or five single wide graphic processing units
(GPUs) for workload acceleration.
Proven Industry Leading Services and Ease of Deployment
HPE ProLiant DL385 Gen10 server comes with a complete set of HPE Pointnext
services, delivering confidence, reducing risk, and helping customers realize agility
and stability.
Services from HPE Pointnext simplify all stages of the IT journey. Advisory and
Transformation Services professionals understand customer challenges and design
an optimal solution. Professional Services enables rapid deployment of solutions
Digital data sheet Page 3
and Operational Services provides ongoing support.
Services provided under Operational Services include: HPE Flexible Capacity, HPE
Datacenter Care, HPE Infrastructure Automation, HPE Campus Care, HPE Proactive
Services and multi-vendor coverage.
HPE Financial Services helps you transform to a digital business with financing
option and trade-in opportunities that align to your business goals.
Digital data sheet Page 4
Technical specifications HPE ProLiant DL385 Gen10 Server
Processor family AMD EPYC™ 7000 Series
Processor core available 32 or 24 or 16 or 8, per processor, depending on model
Processor cache 32.00 MB L3 64.00 MB L3
Processor speed 3.2 GHz, maximum depending on processor
Power supply type 2 Flexible Slot power supplies, maximum depending on model
Expansion slots 8 maximum, for detailed descriptions reference the QuickSpecs
Maximum memory 4.0 TB with 128 GB DDR4 [2]
Memory, standard 4 TB with 32 x 128 GB 2666MT/S RDIMMs
Memory slots 32
Memory type HPE DDR4 SmartMemory
Memory protection features ECC
System fan features Hot-plug redundant fans, standard
Network controller HPE 1 Gb 331i Ethernet adapter 4-ports per controller and/or optional FlexibleLOM, depending on model
Storage controller 1 HPE Smart Array S100i and/or 1 HPE Smart Array P408i-a and/or 1 HPE Smart Array P816i-a and/or 1
Minimum dimensions ( H x W x D) 9.73 x 44.54 x 73.02 cm
Weight 14.9 kg
Infrastructure management HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download)
Warranty 3/3/3 - Server Warranty includes three years of parts, three years of labor, three years of on-site support
Drive supported 8 or 12 LFF SAS/SATA/SSD 8, 10, 16, 18 or 24 SFF SAS/SATA/SSD 6 SFF rear drive optional or 3 LFF rear
HPE Smart Array E208i-a, depending on model
HPE iLO Advanced, HPE iLO Advanced Premium Security Edition and HPE OneView Advanced (require
licenses)
coverage. Additional information regarding worldwide limited warranty and technical support is available at:
http://h20564.www2.hpe.com/hpsc/wc/public/home. Additional HPE support and service coverage for your
product can be purchased locally. For information on availability of service upgrades and the cost for these
service upgrades, refer to the HPE website at http://www.hpe.com/support.
drive optional and 2 SFF rear drive optional 24 SFF NVMe optional NVMe support via Express Bay will limit
maximum drive capacity
Digital data sheet Page 5
HPE Pointnext
For additional technical information,
available models and options, please
reference the QuickSpecs
HPE Pointnext leverages our breadth and depth of technical expertise and
innovation to help to accelerate digital transformation. A comprehensive
portfolio that includes—Advisory, Professional, and Operational Services is
designed to help you evolve and grow today and into the future.
Operational Services
HPE Flexible Capacity is a new consumption model to manage on-demand
·
capacity, combining the agility and economics of public cloud with the
security and performance of on-premises IT.
HPE Datacenter Care offers a tailored operational support solution built on
·
core deliverables. It includes hardware and software support, a team of
experts to help personalize deliverables and share best practices, as well as
optional building blocks to address specific IT and business needs.
HPE Proactive Care is an integrated set of hardware and software support
·
including an enhanced call experience with start to finish case management
helping resolve incidents quickly and keeping IT reliable and stable.
HPE Foundation Care helps when there is a hardware or software problem
·
offering several response levels dependent on IT and business requirements.
Advisory Services includes design, strategy, road map, and other services to
help enable the digital transformation journey, tuned to IT and business needs.
Advisory Services helps customers on their journey to Hybrid IT, Big Data, and
the Intelligent Edge.
Professional Services helps integrate the new solution with project
management, installation and startup, relocation services, and more. We help
mitigate risk to the business so there is no interruption when new technology is
being integrated in the existing IT environment.
[1] Based on external firm conducting cyber security penetration testing of a range of server products from a range
of manufacturers, May 2017.
[2] The stated leadership results are published as of 7-03-2018 to SPEC; see
spec.org/power_ssj2008/results/res2018q2/power_ssj2008-20180410-00808.html
© Copyright 2019 Hewlett Packard Enterprise Development LP.The information contained herein is subject to change
without notice.The only warranties for Hewlett Packard Enterprise products and services are set forth in the express
warranty statements accompanying such products and services.Nothing herein should be construed as constituting an
additional warranty.Hewlett Packard Enterprise shall not be liable for technical or editorial errors or omissions contained
herein.
AMD is a trademark of Advanced Micro Devices, Inc. All other third-party trademark(s) is/are property of their respective
owner(s).
Image may differ from actual product
PSN1010268408USEN, August 13, 2019.
