HP Z24x G2 User Manual

QuickSpecs
HP DreamColor Z24x G2 24-inch Display
Technical Specifications
c05477860 – DA 15913 - Worldwide — Version 2 — July 19, 2017
Page 1
HP DreamColor Z24x G2 24-inch Display
1.
Programmable hotkey Function buttons
4 programmable hotkey function buttons with 12 mappable functions
2.
Power/LED
Power On/Off
LED: fully powered = white sleep mode = amber sleep timer mode = flashing amber
3.
Cable Management
Effortless routing of cables through the cable management tunnel at the base of the column
QuickSpecs
HP DreamColor Z24x G2 24-inch Display
Technical Specifications
c05477860 – DA 15913 - Worldwide — Version 2 — July 19, 2017
Page 2
Rear
Side
1.
Security Lock Slot
1.
2- USB 3.0
1.
Power Switch
2.
Power Cable Connector
3.
DisplayPort 1.2 (input)
4.
DVI-D
5.
HDMI 1.4
6.
DisplayPort 1.2 (output)
7.
Audio out (analog)
8.
1- USB 3.0 (upstream)
9.
2- USB 3.0 (downstream)
QuickSpecs
HP DreamColor Z24x G2 24-inch Display
Technical Specifications
c05477860 – DA 15913 - Worldwide — Version 2 — July 19, 2017
Page 3
Models: 1JR59A4
Panel
Type
24-inch IPS Gen 2, LED Backlit
Viewable Image Area (diagonal)
60,96 cm (24 in) widescreen; diagonally measured
Panel Active Area (W x H)
52 x 32,56 cm (20.47 × 12.81 in.)
Panel Type
Gen 2 IPS (Gen 2 technology, also called AH-IPS, enables lower power consumption)
Resolution
1920 × 1200 @ 60 Hz
Aspect Ratio
16:10
Viewing Angle (typical)
Up to 178° horizontal/178° vertical (10:1 minimum contrast ratio)
Brightness (typical)*
350 cd/m²
Contrast Ratio (typical)*
1,000:1
Dynamic Contrast Ratio (typical)*
5,000,000:1
Response Time (typical)*
6 ms gray-to-gray
Pixel Pitch
0.270 mm
Backlight Lamp Life (to half brightness)
30,000 hours minimum
Color Support**
10-bit (8+2 FRC), up to 1.07 billion colors
Color Gamut
100% of sRGB, 100% of BT.709, 99% of AdobeRGB, 97% of DCI-P3
*All performance specifications represent the typical specifications provided by HP's component manufacturers; actual performance may vary either higher or lower. ** With the use of FRC technology.
User Controls
On Screen Display (OSD) User Controls
Color Space, Video Input, Image Control, PIP Control, Language, Management, Menu and Message Control, Information, Factory Reset
Monitor Control Buttons or Switches
Master power switch (rear), secondary power, 5 programmable OSD/function buttons
User-Assignable Function Buttons
Yes, 4
Languages
10 (English, Spanish, German, French, Italian, Netherlands, Portuguese, Japanese, T-Chinese and S-Chinese)
Color Management
Factory Color Calibrated
Yes (sRGB, BT.709, Adobe RGB)
Color Space / Subsampling Support
RGB 4:4:4, YCBCR 4:4:4, YCBCR 4:2:2
RGB Channel Adjust
Yes, Gain
User Calibration Support
Host software (Windows or macOS)
External Calibration Instrument Support
X-Rite i1Display Pro, Klein K10-A
Signal Interface/ Performance
Horizontal Frequency
24-80 kHz
Vertical Frequency
24-60 Hz
Native Resolution
1920 × 1200 @ 60 Hz
Preset VESA Graphic Modes (non­interlaced)
640 × 480 @ 60Hz 800 × 600 @ 60 Hz 1024 × 768 @ 60 Hz 1280 × 720 @ 60 Hz 1280 × 960 @ 60 Hz 1280 × 1024 @ 60 Hz 1440 × 900 @ 60 Hz 1600 × 1200 @ 60 Hz 1680 × 1050 @ 60 Hz 1920 ×1080 @ 60 Hz 1920 × 1200 @ 60 Hz
Maximum Pixel Clock Speed
170 MHz
QuickSpecs
HP DreamColor Z24x G2 24-inch Display
Technical Specifications
c05477860 – DA 15913 - Worldwide — Version 2 — July 19, 2017
Page 4
Anti-Glare
Yes
Flicker Free
Yes
Default Color Temperature
D65 (6504K)
Connector Types
DisplayPort™
(1) DisplayPort 1.2 (1 input and 1 output)
HDMI
(1) HDMI 1.4
DVI-D
(1) Single Link
HDCP support
Yes, all video inputs
Audio
(1) Audio out (analog)
USB Port Specifications
USB Version
3.0
USB Hub
Yes
Downstream Ports
4 Ports
Upstream Ports
1 Port
Cables Included Video Cables Included
(1) DVI-D 1,8 m (5.9 ft), (1) DisplayPort 1,8 m (5.9 ft)
USB Cable Included
(1) USB 3.0 1,8 m (5.9 ft)
Power
Power Supply
Internal
Input Power
90 - 265 VAC at 45 - 63 Hz
ENERGY STAR® Power1
18.57 W
Typical Power2
13.5 W
Maximum Power3
54.18 W
Energy Saving/Standby Mode
0.5 W
Power Cable Length
1,9 m (6.2 ft)
Mechanical
Dimensions (W x D x H)
Unpacked w/stand
(highest setting)
55,94 x 23,8 x 52,5 cm (22 x 9.4 x 20.7 in)
Unpacked w/o stand
(head only)
55,94 x 6,65 x 36,5 cm (22 x 2.6 x 14.4 in)
Packaged
66 x 45 x 30,1 cm
(26 x 17.7 x 11.8 in)
Weight
Head Only
4,73 kg (10.4 lb)
Unpacked
6,98 kg (15.4 lb)
Packaged
8,98 kg (19.7 lb)
VIDEO/OTHER INPUTS
POWER
DIMENSIONS AND WEIGHT
QuickSpecs
HP DreamColor Z24x G2 24-inch Display
Technical Specifications
c05477860 – DA 15913 - Worldwide — Version 2 — July 19, 2017
Page 5
Plug and Play
Yes
Color
Black
4-Way Comfort Adjust
Easily adjust the display in height, tilt, swivel and pivot for maximum comfort.
Integrated Quick Release9
An easy-to-use, VESA-compliant, LCD monitor mounting solution that allows you to quickly and securely attach an LCD monitor to a variety of stands, brackets, arms or wall mounts.
Cable Management
Enhanced cable management for easy concealment of power, video and USB cables. Effortless routing of cables through the cable management tunnel at the base of the column.
Detachable Stand
Yes, ships detached
Tilt Range
–5° to + 20° vertical
Swivel Range
45°L to 45°R
Display height adjustment:
Adjustment Range: 151 mm
Minimum (desk to bottom of display): 16 mm
Maximum (desk to bottom of display): 167 mm
Pivot Rotation
Yes
VESA Mounting
Yes, 100 mm with integrated mount
Security Lock-Ready
Yes
Picture-in-Picture, Picture-by-Picture
Yes
Specifications
Temperature - Operating
5° to 35° C (41° to 95° F)
Temperature - Non-operating
–20° to 60° C (-4° to 140° F)
Humidity - Operating
20% to 80% Relative Humidity non-condensing
Humidity - Non-operating
5% to 95%, 38.7° C max wet-bulb
Altitude - Operating
0 to 5,000 m (0 to 16,404 ft)
Altitude – Non-operating
0 to 12,192 m (0 to 40,000 ft)
White LED Backlights
Yes
CCFL Panel
No
Arsenic-Free Display Glass
Yes
Low Halogen4
Yes (except cables)
Mercury-Free Display Backlights
Yes
OPTIONS
(Each sold separately)
HP USB Graphics Adapter Part number NL571AA
Enables connection of up to six simultaneous displays to help you boost productivity and multi-task across several open applications. Use one Adapter to bridge between a notebook or desktop PC and second monitor or use multiple Adapters to connect several displays to each other.
HP Thin Client Mount Kit Part number E5J35AA
Attach your HP Thin Client or USDT PC to the back of select HP Z Displays and maintain optimal ergonomic adjustability with the HP Thin Client Mount Kit. Simply mount an HP Thin Client to the
Kit’s VESA plate, slide it into place on the back of an HP Z24i, Z27i or Z30i IPS Display stand, and you’re ready to go.
MONITOR FEATURES
ENVIRONMENTAL
QuickSpecs
HP DreamColor Z24x G2 24-inch Display
Technical Specifications
c05477860 – DA 15913 - Worldwide — Version 2 — July 19, 2017
Page 6
HP LCD Speaker Bar Part number NQ576AA
Powered directly by the monitor or the PC, the Speaker Bar seamlessly attaches to the monitor's lower bezel to bring full audio support to select HP LCD monitors. Features include dual speakers with full sound range and external jack for headphones. Sold separately.
HP Integrated Work Center Stand
- USDT / Thin Clients Part numbers E8H16AA/AT (black and meteorite), LH526AA/AT (black and silver).8
HP Integrated Work Center Stand - USDT / Thin Clients - The HP Integrated Work Center Stand is designed to help maximize the use of limited desk space without compromising performance or productivity by accommodating an HP Ultra-slim Desktop PC or an HP Thin Client, and most HP 17 to 24-inch1 diagonal LCD monitors, with VESA standard mounting brackets.
HP Integrated Work Center Stand for Small Form Factors v3 Part number F2P06AA7
Maximize your available work space with the stylish and innovative HP Integrated Work Center for Small Form Factors v3 (HP IWC SFF v3), designed to match the newest HP PC designs. Create a customized "all-in-one" solution by combining an HP Small Form Factor (SFF) Business Desktop PC or Workstation with an LED monitor up to 24 diagonal inches.
HP Single Monitor Arm Part number BT861AA
The flexible design of the HP Single Monitor Arm provides a seemingly endless range of display adjustments with an amazing 13 inches of lift, 50 degrees of tilt, and 360 degrees of pan and rotation – all at your fingertips -- helping you stay comfortable and productive throughout the day.
HP Adjustable Dual Display StandPart Number AW664AA
Premium space-saving dual screen solution provides access to more monitor real estate and makes it possible to manage multiple applications simultaneously. Weight adjustable for dual monitors from 17-24”. Rotate displays into portrait/landscape positions.
HP Display and Notebook II StandPart number E8G00AA
Quickly and easily create a comfortable workspace for your notebook or notebook and docking station and an external display with the HP Display and Notebook II Stand, which brings your notebook PC, docking station, and display up off the desk.
HP Adjustable Display Stand Part number AW663AA
Turn your HP Business Notebook into a desktop solution supporting up to a 24 inch display. A dual-hinged, smooth­motion display stand allows for greater depth, height and tilt adjustment for maximum comfort.
HP DisplayPort Cable Kit Part number VN567AA
Connects a DisplayPort connector on an HP Business Desktop computer to a DisplayPort connector on a monitor.
HP Business PC Security Lock KitPart number PV606AA
Attaches to the rear of the PC with a six-foot steel cable that can be used to secure a PC or peripherals such as mice, keyboards, monitors or USB security devices to protect them against unauthorized removal by physically connecting the system to an anchor point.
QuickSpecs
HP DreamColor Z24x G2 24-inch Display
Technical Specifications
c05477860 – DA 15913 - Worldwide — Version 2 — July 19, 2017
Page 7
Eco-Label Certifications & declarations
This product has received or is in the process of being certified to the following approvals and may be labeled with one or more of these marks:
IT ECO declaration US ENERGY STAR® TCO or TCO Certified Edge EPEAT® Gold registered in the United States. See http://www.epeat.net for
registration status in your country
Energy Consumption (in accordance with US ENERGY STAR® test method)
115VAC, 60Hz
230VAC, 50Hz
100VAC, 50Hz
Normal Operation
18.57 W
18.25 W
18.65 W
Sleep
0.48 W
0.52 W
0.47 W
Off
0.23 W
0.28 W
0.23 W
Heat Dissipation*
115VAC, 60Hz
230VAC, 50Hz
100VAC, 50Hz
Normal Operation
63 BTU/hr
62 BTU/hr
63 BTU/hr
Sleep
2 BTU/hr
2 BTU/hr
1 BTU/hr
Off
1 BTU/hr
1 BTU/hr
1 BTU/hr
*NOTE: Heat dissipation is calculated based on the measured watts, assuming the service level is attained for one hour.
Additional Information
This product is in compliance with the Restrictions of Hazardous Substances
(RoHS) directive - 2002/95/EC.
This HP product is designed to comply with the Waste Electrical and Electronic
Equipment (WEEE) Directive – 2002/96/EC.
This product is in compliance with California Proposition 65 (State of California;
Safe Drinking Water and Toxic Enforcement Act of 1986).
This product is in compliance with the IEEE 1680 (EPEAT) standard at the Gold
level, see www.epeat.net
Plastics parts weighing over 25 grams used in the product are marked per ISO
11469 and ISO1043.
This product contains 19.0% post-consumer recycled plastic (by wt.) This product is 98.6% recycle-able when properly disposed of at end of life.
Packaging Materials
External:
PAPER/Corrugated
1265 g
Internal:
PLASTIC/EPS (Expanded Polystyrene)
900 g
PLASTIC/Polyethylene low density
110 g
RoHS Compliance
HP, Inc. is committed to compliance with all applicable environmental laws and regulations,
including the European Union Restriction of Hazardous Substances (RoHS) Directive. HP’s
goal is to exceed compliance obligations by meeting the requirements of the RoHS Directive on a worldwide basis. By July 1, 2006, RoHS substances will be virtually eliminated (virtually = to levels below legal limits) for all HP electronic products subject to the RoHS Directive, except where it is widely recognized that there is no technically feasible alternative (as indicated by an exemption under the EU RoHS Directive).
QuickSpecs
HP DreamColor Z24x G2 24-inch Display
Technical Specifications
c05477860 – DA 15913 - Worldwide — Version 2 — July 19, 2017
Page 8
Material Usage
This product does not contain any of the following substances in excess of regulatory limits (refer to the HP General Specification for the Environment at
http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/gse.pdf):
Asbestos Certain Azo Colorants Certain Brominated Flame Retardants – may not be used as flame retardants in
plastics
Cadmium Chlorinated Hydrocarbons Chlorinated Paraffins Formaldehyde Halogenated Diphenyl Methanes Lead carbonates and sulfates Lead and Lead compounds Mercuric Oxide Batteries Nickel – finishes must not be used on the external surface designed to be
frequently handled or carried by the user.
Ozone Depleting Substances Polybrominated Biphenyls (PBBs) Polybrominated Biphenyl Ethers (PBBEs) Polybrominated Biphenyl Oxides (PBBOs) Polychlorinated Biphenyl (PCB) Polychlorinated Terphenyls (PCT) Polyvinyl Chloride (PVC) – except for wires and cables, and certain retail packaging
has been voluntarily removed from most applications.
Radioactive Substances Tributyl Tin (TBT), Triphenyl Tin (TPT), Tributyl Tin Oxide (TBTO)
Packaging
HP follows these guidelines to decrease the environmental impact of product packaging:
Eliminate the use of heavy metals such as lead, chromium, mercury and cadmium
in packaging materials.
Eliminate the use of ozone-depleting substances (ODS) in packaging materials. Design packaging materials for ease of disassembly. Maximize the use of post-consumer recycled content materials in packaging
materials.
Use readily recyclable packaging materials such as paper and corrugated
materials.
Reduce size and weight of packages to improve transportation fuel efficiency. Plastic packaging materials are marked according to ISO 11469 and DIN 6120
standards.
End-of-life Management and Recycling
Hewlett-Packard offers end-of-life HP product return and recycling programs in many geographic areas. To recycle your product, please go to: http://www.hp.com/go/reuse-
recycle or contact your nearest HP sales office. Products returned to HP will be recycled,
recovered or disposed of in a responsible manner.
The EU WEEE directive (2002/95/EC) requires manufacturers to provide treatment information for each product type for use by treatment facilities. This information (product disassembly instructions) is posted on the Hewlett Packard web site at:
http://www.hp.com/go/recyclers. These instructions may be used by recyclers and other
WEEE treatment facilities as well as HP OEM customers who integrate and re-sell HP equipment.
QuickSpecs
HP DreamColor Z24x G2 24-inch Display
Technical Specifications
c05477860 – DA 15913 - Worldwide — Version 2 — July 19, 2017
Page 9
HP, Inc. Corporate Environmental Information
For more information about HP’s commitment to the environment:
Global Citizenship Report
http://www.hp.com/hpinfo/globalcitizenship/gcreport/index.html
Eco-label certifications
http://www.hp.com/hpinfo/globalcitizenship/environment/productdesign/ecolabe ls.html
ISO 14001 certificates:
http://h20195.www2.hp.com/V2/GetDocument.aspx?docname=c04755842
and
http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/cert.pdf
What’s in the box?
Monitor and Accessories
HP DreamColor Z24x G2 24-inch Display, AC power cord, USB
3.0 cable, DVI-D cable, DisplayPort 1.2 cable
Documentation
DVD documentation kit, factory calibration report
Other
Software included
HP DreamColor Calibration
User Guide Languages
English, Arabic, S. Chinese, T. Chinese, Czech, Danish, Dutch, Finnish, French, German, Greek, Hungarian, Italian, Japanese, Kazakh, Korean, Norwegian, Polish, Brazilian Portuguese, Russian, Slovenian, Spanish, Swedish and Turkish.
Warranty Languages
English, Arabic, S. Chinese, T. Chinese, Czech, Danish, Dutch, Finnish, French, German, Greek, Hungarian, Italian, Japanese, Kazakh, Korean, Norwegian, Polish, Brazilian Portuguese, Russian, Slovenian, Spanish, Swedish and Turkish.
Country of Origin
China
Certification and Compliance
Microsoft WHQL Certification (Windows 10, Windows 8 and Windows 7), ENERGY STAR® 7 Certified, SmartWay Transport Partnership (NA only)
Compatibility
Compatible with platforms using the VESA standard video modes. Recommended for use with HP products.
Service and Warranty
Protected by HP, including a 3 year standard limited warranty. Optional HP Care Pack Services are extended service contracts that extend your protection beyond the standard warranties.6
Zero Bright Dot Policy*
Yes
*The HP Pixel Policy allows no bright sub-pixel defects for this display. For complete details, see http://support.hp.com/us-
en/document/c00288895.
WHAT’S IN THE BOX?
CERTIFICATION AND COMPLIANCE
QuickSpecs
HP DreamColor Z24x G2 24-inch Display
Technical Specifications
c05477860 – DA 15913 - Worldwide — Version 2 — July 19, 2017
Page 10
Copyright © 2017 HP Development Company, L.P.
The information contained herein is subject to change without notice. The only warranties for HP products are set forth in the express limited warranty statements accompanying such products. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
ENERGY STAR is a registered trademark owned by the U.S. Environmental Protection Agency. DisplayPort™ and the DisplayPort™
logo are trademarks owned by the Video Electronics Standards Association (VESA®) in the United States and other countries.
1. ENERGY STAR® power is measured with factory defaults, brightness at ENERGY STAR® level of 200 cd/m
2. Default Power is measured with factory defaults, including factory default brightness and USB ports loaded at 25% of maximum.
3. Maximum Power is measured with monitor at maximum brightness and with USB ports loaded at 100% of maximum.
4. External power supplies, power cords, cables and peripherals are not Low Halogen. Service parts obtained after purchase may not be
Low Halogen.
5. EPEAT® Gold where HP registers commercial display products. See www.epeat.net for registration status in your country.
6. Service levels and response times for HP Care Pack Services may vary depending on your geographic location. Service starts from date
of hardware purchase. Restrictions and limitations apply. See http://www.hp.com/go/cpc for details.
7. 17 to 24-inch diagonal monitors need to meet supported weight limits of 6 to 12.1 lbs. (2.7 to 5.5 kg).
8. The Integrated Work Center Stand has been designed to support 17 to 24-inch diagonal HP LCD monitors from 2.3 kg to 5.2 kg (5.07 lbs
to 11.24 lbs).
9. The HP Quick Release has been designed to support a maximum of up to 24 lbs (10.9 kg) for all devices mounted. Because mounting
surfaces vary widely and the final mounting method and configuration may vary, mounting fasteners are not supplied (other than the VESA-compliant screws). HP recommends that you consult with a qualified engineering, architectural or construction professional to determine the appropriate type and quantity of mounting fasteners required for your application and to ensure that your mounting solution is properly installed to support applied loads.
2
and with no USB loads.
QuickSpecs
HP DreamColor Z24x G2 24-inch Display
Technical Specifications
c05477860 – DA 15913 - Worldwide — Version 2 — July 19, 2017
Page 11
Change Log
V1 to V2
Environmental information added, 19 July 19, 2017
Loading...
