HP XZ940UT Quickspecs

1.

(1) external 5.25" drive bay

6.

(3) PCIe x1 slots, (1) PCIe x16 slot, (1) miniPCI slot

2.

300 Watt Power Supply

7.

USB Scroll Mouse

3.

Rear I/O includes: (4) USB 2.0 ports, RJ-45 Ethernet Port,
DVI-D and VGA video Ports, microphone jack, audio in/out
jacks (5.1 channel audio out)

8.

HP USB Standard Value Keyboard

4.

Front I/O includes: (2) USB 2.0 ports, dedicated headphone
Port, microphone jack

9.

HP Monitor

5.

(1) internal 3.5" hard drive bay

QuickSpecs

HP Pro 3400 Microtower Business PC

HP Pro 3400 Microtower Business PCHP Pro 3400 Microtower Business PC

HP Pro 3400 Microtower Business PC

Overview (availability varies by configuration and by country)

DA - 14119 North America — Version 3 — August 29, 2011

Page 1

At A Glance

At A GlanceAt A Glance

At A Glance

Genuine Windows® 7 Professional Edition (32- and 64-bit), Genuine Windows 7 Ultimate Edition (64-bit), Genuine Windows
7 Home Premium Edition (64-bit), Genuine Windows 7 Home Basic Edition (64-bit), Genuine Windows 7 Starter Edition (32­bit), FreeDOS, or RedFlag Linux
Choice of Intel® Celeron™, Intel Pentium™ and Intel Core™ i3, Intel Core i5, and Intel Core i7 next generation processors
Integrated graphics (Intel HD Graphics, Intel HD 2000 Graphics, Intel HD 3000 Graphics) based on processor
Intel H61 Express Chipset
Up to 8 GB DDR3 SDRAM system memory available standard (depending on model)
Up to 1 TB 3.0 Gb/s SATA hard drive
SuperMulti DVD Drive or DVD ROM Drive
Integrated Realtek RTL8171E Gigabit Ethernet Controller
(10) USB 2.0 ports, including (2) Front, (4) rear, (4) Internal
DVI-D and VGA video ports
HP Wireless NIC 802.11b/g/n Mini Card (1x1) (optional)

5.1 audio channels
Protected by HP Services. Terms and conditions vary by country. Certain restrictions and exclusions apply.

QuickSpecs

HP Pro 3400 Microtower Business PC

HP Pro 3400 Microtower Business PCHP Pro 3400 Microtower Business PC

HP Pro 3400 Microtower Business PC

Overview (availability varies by configuration and by country)

DA - 14119 North America — Version 3 — August 29, 2011

Page 2

Processors

ProcessorsProcessors

Processors
(Availability
list is subject to change)

Intel Celeron (dual-core) Processors

Intel Celeron (dual-core) ProcessorsIntel Celeron (dual-core) Processors

Intel Celeron (dual-core) Processors
Intel Celeron G540 Processor (2.5 GHz, 2 MB cache, 2C/2T)
Intel Celeron G530 Processor (2.4 GHz, 2 MB cache, 2C/2T)
Intel Pentium Processors

Intel Pentium ProcessorsIntel Pentium Processors

Intel Pentium Processors
Intel Pentium G860 Processor (3.0 GHz, 3 MB cache, 2C/2T)
Intel Pentium G850 Processor (2.9 GHz, 3 MB cache, 2C/2T)
Intel Pentium G840 Processor (2.8 GHz, 3 MB cache, 2C/2T)
Intel Pentium G630 Processor (2.7 GHz, 3 MB cache, 2C/2T)
Intel Pentium G620 Processor (2.6 GHz, 3 MB cache, 2C/2T)
Intel Core i3 Processors

Intel Core i3 ProcessorsIntel Core i3 Processors

Intel Core i3 Processors
Intel Core i3-2130 Processor (3.4 GHz, 6 MB cache, 2C/4T, Turbo, HD 2000 Graphics)
Intel Core i3-2120 Processor (3.3 GHz, 6 MB cache, 2C/4T, Turbo, HD 2000 Graphics)
Intel Core i3-2105 Processor (3.1 GHz, 6 MB cache, 2C/4T, Turbo, HD 3000 Graphics)
Intel Core i3-2100 Processor (3.1 GHz, 6 MB cache, 2C/4T, Turbo, HD 2000 Graphics)
Intel Core i5 Processors

Intel Core i5 ProcessorsIntel Core i5 Processors

Intel Core i5 Processors
Intel Core i5-2500 Processor (3.3 GHz, 6 MB cache, 4C/4T, Turbo, HD 2000 Graphics)

Up to 3.7 GHz with Intel Turbo Boost Technology
Intel Core i5-2400 Processor (3.1 GHz, 6 MB cache, 4C/4T, Turbo, HD 2000 Graphics)

Up to 3.4 GHz with Intel Turbo Boost Technology
Intel Core i5-2320 Processor (3.0 GHz, 6 MB cache, 4C/4T, Turbo, HD 2000 Graphics)

Up to 3.3 GHz with Intel Turbo Boost Technology
Intel Core i5-2310 Processor (2.9 GHz, 6 MB cache, 4C/4T, Turbo, HD 2000 Graphics)

Up to 3.2 GHz with Intel Turbo Boost Technology
Intel Core i5-2300 Processor (2.8 GHz, 6 MB cache, 4C/4T, Turbo, HD 2000 Graphics)

Up to 3.1 GHz with Intel Turbo Boost Technology
Intel Core i7 Processors

Intel Core i7 ProcessorsIntel Core i7 Processors

Intel Core i7 Processors
Intel Core i7-2600 Processor (3.4 GHz, 8 MB cache, 4C/8T, Turbo, HD 2000 Graphics)

Up to 3.8 GHz with Intel Turbo Boost Technology

NOTE:

NOTE:NOTE:

NOTE:

Intel processor numbers are not a measure of performance. Processor numbers differentiate

features within each processor family, not across different processor families.

QuickSpecs

HP Pro 3400 Microtower Business PC

HP Pro 3400 Microtower Business PCHP Pro 3400 Microtower Business PC

HP Pro 3400 Microtower Business PC

Standard Features (availability varies by configuration and by country)

DA - 14119 North America — Version 3 — August 29, 2011

Page 3

Operating System

Operating SystemOperating System

Operating System

Preinstalled

PreinstalledPreinstalled

Preinstalled

Genuine Windows 7 Professional Edition (32-bit)

*

Genuine Windows 7 Professional Edition (64-bit)

*

Genuine Windows 7 Ultimate Edition (64-bit)

*

Genuine Windows 7 Home Premium Edition (64-bit)

*

Genuine Windows 7 Home Basic Edition (64-bit)

*

Genuine Windows 7 Starter Edition** (32-bit)

*

FreeDOS
RedFlag Linux

* System may require upgraded and/or separately purchased hardware and/or a DVD drive to install the
Windows 7 software and take full advantage of Windows 7 functionality. See

http://www.microsoft.com/windows/windows-7/

for details.
** Restrictions exist for this operating system. It is not available in some countries and is not compatible
with some CPUs. Please check for availability.

Chipset

ChipsetChipset

Chipset

Intel H61 Express Chipset

Graphics

GraphicsGraphics

Graphics
Integrated

Integrated Integrated

Integrated

Intel HD Graphics

Processor

ProcessorProcessor

Processor

Number

NumberNumber

Number

Core

CoreCore

Core
Freq.

Freq.Freq.

Freq.

Max. Turbo

Max. TurboMax. Turbo

Max. Turbo

Boost

BoostBoost

Boost

Integrated Graphics

Integrated GraphicsIntegrated Graphics

Integrated Graphics

G540

2.5 GHz

Intel HD Graphics

G530

2.4 GHz

Intel HD Graphics

G860

3.0 GHz

Intel HD Graphics

G850

2.9 GHz

Intel HD Graphics

G840

2.8 GHz

Intel HD Graphics

G630

2.7 GHz

Intel HD Graphics

G620

2.6 GHz

Intel HD Graphics

i7-2600

3.4 GHz 3.8 GHz

Intel HD 2000 Graphics

i5-2500

3.3 GHz 3.7 GHz

Intel HD 2000 Graphics

i5-2400

3.1 GHz 3.4 GHz

Intel HD 2000 Graphics

i5-2320

3.0 GHz 3.3 GHz

Intel HD 2000 Graphics

i5-2310

2.9 GHz 3.2 GHz

Intel HD 2000 Graphics

i5-2300

2.8 GHz 3.1 GHz

Intel HD 2000 Graphics

i3-2130

3.4 GHz

Intel HD 2000 Graphics

i3-2120

3.3 GHz

Intel HD 2000 Graphics

i3-2105

3.1 GHz

Intel HD 3000 Graphics

i3-2100

3.1 GHz

Intel HD 2000 Graphics

QuickSpecs

HP Pro 3400 Microtower Business PC

HP Pro 3400 Microtower Business PCHP Pro 3400 Microtower Business PC

HP Pro 3400 Microtower Business PC

Standard Features (availability varies by configuration and by country)

DA - 14119 North America — Version 3 — August 29, 2011

Page 4
