HP EliteBook 8460w, XU060UT, ProBook 6460b, EliteBook 8460p Maintenance And Service Manual

HP EliteBook 8460w Mobile Workstation HP EliteBook 8460p Notebook PC HP ProBook 6460b Notebook PC

Maintenance and Service Guide

Bluetooth is a trademark owned by its proprietor and used by Hewlett-Packard Company under license. Intel and Core are trademarks or registered trademarks of Intel Corporation in the United States and other countries. Microsoft, Windows, and Windows Vista are either trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries. SD Logo is a trademark of its proprietor.

The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.

Seventh Edition: March 2012

First Edition: March 2011

Document Part Number: 644152-007

Safety warning notice

WARNING! To reduce the possibility of heat-related injuries or of overheating the computer, do not

place the computer directly on your lap or obstruct the computer air vents. Use the computer only on a hard, flat surface. Do not allow another hard surface, such as an adjoining optional printer, or a soft surface, such as pillows or rugs or clothing, to block airflow. Also, do not allow the AC adapter to contact the skin or a soft surface, such as pillows or rugs or clothing, during operation. The computer and the AC adapter comply with the user-accessible surface temperature limits defined by the International Standard for Safety of Information Technology Equipment (IEC 60950).

iii

iv Safety warning notice

Table of contents

1 Product description ........................................................................................................................................ 1

2 External component identification .............................................................................................................. 10

Display ................................................................................................................................................ 10

Top ..................................................................................................................................................... 13

TouchPad .......................................................................................................................... 13

Lights ................................................................................................................................. 14

Buttons and fingerprint reader ........................................................................................... 16

Keys ................................................................................................................................... 18

Front ................................................................................................................................................... 20

Left ..................................................................................................................................................... 21

Rear .................................................................................................................................................... 22

Right ................................................................................................................................................... 23

Bottom ................................................................................................................................................ 25

3 Illustrated parts catalog ............................................................................................................................... 27

Service tag ......................................................................................................................................... 27

Computer major components ............................................................................................................. 28

Display components ........................................................................................................................... 36

Cable Kit ............................................................................................................................................. 39

Plastics Kit .......................................................................................................................................... 40

Mass storage devices ......................................................................................................................... 41

Miscellaneous parts ............................................................................................................................ 42

Sequential part number listing ............................................................................................................ 43

4 Removal and replacement procedures ....................................................................................................... 56

Preliminary replacement requirements ............................................................................................... 56

Tools required .................................................................................................................... 56

Service considerations ....................................................................................................... 56

Plastic parts ....................................................................................................... 56

Cables and connectors ..................................................................................... 57

Drive handling ................................................................................................... 57

Grounding guidelines ......................................................................................................... 58

Electrostatic discharge damage ........................................................................ 58

Packaging and transporting guidelines ............................................. 59

Workstation guidelines ..................................................................... 59

Equipment guidelines ....................................................................... 60

Component replacement procedures ................................................................................................. 61

Service tag ......................................................................................................................... 61

Computer feet .................................................................................................................... 62

Battery ............................................................................................................................... 63

SIM .................................................................................................................................... 64

Display assembly components (panel, bezel, webcam, microphone) ............................... 65

Bottom door ....................................................................................................................... 70

Smart card reader .............................................................................................................. 71

Optical drive ....................................................................................................................... 72

Upgrade bay ...................................................................................................................... 74

Hard drive .......................................................................................................................... 76

RTC battery ....................................................................................................................... 78

Memory modules ............................................................................................................... 79

WWAN module .................................................................................................................. 81

WLAN module .................................................................................................................... 83

Bluetooth module ............................................................................................................... 88

Modem module .................................................................................................................. 89

Fan ..................................................................................................................................... 90

Heat sink ............................................................................................................................ 91

Processor ........................................................................................................................... 94

Keyboard ........................................................................................................................... 96

Bottom cover ...................................................................................................................... 98

Fingerprint reader board .................................................................................................. 102

Lid switch ......................................................................................................................... 104

Speaker assembly ........................................................................................................... 106

RJ-11 connector cable ..................................................................................................... 108

Display assembly components (cable, antennas, hinges, enclosure) ............................. 110

System board ................................................................................................................... 116

USB 3.0 board ................................................................................................................. 120

ExpressCard assembly .................................................................................................... 121

5 Computer Setup (BIOS) and System Diagnostics ................................................................................... 123

Using Computer Setup ..................................................................................................................... 123

Starting Computer Setup ................................................................................................. 123

Navigating and selecting in Computer Setup ................................................................... 123

Restoring factory settings in Computer Setup ................................................................. 124

Updating the BIOS ........................................................................................................... 125

Determining the BIOS version ......................................................................... 125

Downloading a BIOS update ........................................................................... 125

Using System Diagnostics ................................................................................................................ 126

6 Specifications .............................................................................................................................................. 127

Computer specifications ................................................................................................................... 127

35.6-cm (14.0-in), HD display specifications .................................................................................... 128

35.6-cm (14.0-in), HD+ display specifications .................................................................................. 129

Hard drive specifications .................................................................................................................. 130

DVD±RW and CD-RW SuperMulti DL Combo Drive specifications ................................................. 131

Blu-ray Disc ROM with SuperMulti DVD±R/RW DL Drive ................................................................ 132

Blu-ray BD-R/RE + DVDSM DL Drive .............................................................................................. 133

DVD-ROM Drive specifications ........................................................................................................ 134

Specification information in Device Manager ................................................................................... 135

7 Backup and recovery .................................................................................................................................. 136

Windows 7 ........................................................................................................................................ 136

Backing up your information ............................................................................................ 136

Performing a system recovery ......................................................................................... 137

Using the Windows recovery tools .................................................................. 138

Using f11 recovery tools .................................................................................. 138

Using a Windows 7 operating system DVD (purchased separately) ............... 139

Windows Vista .................................................................................................................................. 140

Backing up your information ............................................................................................ 140

Performing a recovery ..................................................................................................... 141

Using the Windows recovery tools .................................................................. 141

Using f11 recovery tools .................................................................................. 142

Using a Windows Vista operating system DVD (purchased separately) ......... 142

8 Power cord set requirements .................................................................................................................... 144

Requirements for all countries and regions ...................................................................................... 144

Requirements for specific countries and regions ............................................................................. 145

9 Recycling ..................................................................................................................................................... 146

Battery .............................................................................................................................................. 146

Display .............................................................................................................................................. 146

Index ................................................................................................................................................................. 152

vii

viii

1 Product description

Category Description HP ProBook

6460b Notebook PC

HP EliteBook 8460p Notebook PC

HP EliteBook 8460w Mobile Workstation

Product Name HP ProBook 6460p Notebook PC √

HP EliteBook 8460p Notebook PC √

HP EliteBook 8460w Mobile

Workstation

√

Processors Intel® Core™ i7 processor, Quad Core

2860M, 2.50-GHz (Turbo up to 3.60)

processor 8-MB L3 cache, 8 threads

√√

2820M, 2.30-GHz (Turbo up to 3.40)

processor 8-MB L3 cache, 8 threads

√√

2760M, 2.40-GHz (Turbo up to 3.50)

processor 6-MB L3 cache, 8 threads

√√

2720M, 2.20-GHz (Turbo up to 3.30)

processor 6-MB L3 cache, 8 threads

√√

2670M, 2.20-GHz (Turbo up to 3.10)

processor 6-MB L3 cache, 8 threads

√√

2630M, 2.00-GHz (Turbo up to 2.90)

processor 6-MB L3 cache, 8 threads

√√

Intel Core i7 processor, Dual Core

2640M, 2.80-GHz (Turbo up to 3.50)

processor 4-MB L3 cache, 4 threads

√√√

2620M, 2.70-GHz (Turbo up to 3.40)

processor 4-MB L3 cache, 4 threads

√√√

Intel Core i5 processors, Dual Core

(not available with iAMT, Intel QM67 chipset)

2540M, 2.60-GHz (Turbo up to 3.30)

processor 3-MB L3 cache, 4 threads

√√√

2520M, 2.50-GHz (Turbo up to 3.20)

processor 3-MB L3 cache, 4 threads

√√√

2450M, 2.50-GHz (Turbo up to 3.10)

processor 3-MB L3 cache, 4 threads

√√

Category Description HP ProBook

6460b Notebook PC

HP EliteBook 8460p Notebook PC

HP EliteBook 8460w Mobile Workstation

2430M, 2.40-GHz (Turbo up to 3.00)

processor 3-MB L3 cache, 4 threads

√√

2410M, 2.30-GHz (Turbo up to 2.90)

processor 3-MB L3 cache, 4 threads

√√

Intel Core i3 processors, Dual Core

(not available with iAMT, Intel QM67 chipset)

2370M, 2.40-GHz processor 3-MB L3

cache, 4 threads

√

2350M, 2.30-GHz processor 3-MB L3

cache, 4 threads

√

2330M, 2.20-GHz processor 3-MB L3

cache, 4 threads

√√

2310M, 2.10-GHz processor 3-MB L3

cache, 4 threads

√√

Intel Celeron processors

B840, 1.90-GHz processor 2-MB L3

cache, 2 threads

√

B810, 1.60-GHz processor 2-MB L3

cache, 2 threads

√

Chipset Mobile Intel HM65 chipset

(Non-vPro configurations)

√

Mobile Intel QM67 chipset

(vPro configurations)

√

Graphics Intel HD Graphics 3000 (UMA) √√

AMD Radeon™ HD 6470M (discrete) √√

AMD FirePro™ M3900 √

Supports Open GL √

Supports dual-display ports through the

dock

√√√

Panel All display assemblies include 2

wireless local area network (WLAN) antennas

√√√

35.6-cm (14.0-in) HD, anti-glare, LED SVA (1366x768)

√√√

35.6-cm (14.0-in) HD+, anti-glare, LED SVA (1600x900)

√√√

35.6-cm (14.0-in) HD, anti-glare, LED SVA (1366x768) with WWAN

√√√

35.6-cm (14.0-in) HD+, anti-glare, LED SVA (1600x900) with WWAN

√√√

2 Chapter 1 Product description

Category Description HP ProBook

6460b Notebook PC

HP EliteBook 8460p Notebook PC

HP EliteBook 8460w Mobile Workstation

35.6-cm (14.0-in) HD, anti-glare, LED SVA (1366x768) with camera

√√√

35.6-cm (14.0-in) HD+, anti-glare, LED SVA (1600x900) with camera

√√√

35.6-cm (14.0-in) HD, anti-glare, LED SVA (1366x768) with camera and WWAN

√√√

35.6-cm (14.0-in) HD+, anti-glare, LED SVA (1600x900) with camera and WWAN

√√√

Support privacy filter √√√

Memory Two customer-accessible/upgradeable

memory module slots supporting up to 16 GB of RAM

√√√

Supports dual-channel memory √√√

PC3-10600, 1333-MHz, DDR3 √√√

Supports the following configurations:

● 16384 (8192 × 2)

● 8192 (8192 × 1)

● 8192 (4096 × 2)

●

6144 (4096 + 2048)

●

4096 (2048 × 2)

●

4096 (4096 × 1)

●

3072 (2048 + 1024)

● 2048 (2048 × 1)

√√√

Brazil requirements:

● 8192 (4096 × 2)

●

4096 (2048 × 2)

●

4096 (4096 × 1)

● 2048 (2048 × 1)

√

Flash cache Marvell 16-GB module √

Hard drives Supports 9.5-mm, 6.35-cm (2.50-in)

SATA hard drives

√√√

Customer-accessible √√√

Category Description HP ProBook

6460b Notebook PC

HP EliteBook 8460p Notebook PC

HP EliteBook 8460w Mobile Workstation

Supports the following drives:

● 750-GB, 7200-rpm

● 640-GB, 5400-rpm

● 500-GB, 5400-rpm and 7200-rpm

●

320-GB, 5400-rpm and 7200-rpm

●

250-GB, 7200-rpm

√√√

Supports the following solid-state

drives:

●

256-GB

●

160-GB

● 128-GB

● 120-GB

√√√

Upgrade bay Fixed √√√

Customer-accessible √√√

Serial ATA √√√

12.7-mm tray load √√√

Supports “No Drive” option √√√

Supports the following 12.7-mm SATA

optical drives:

● DVD-ROM

●

DVD+/-RW SuperMulti DL

●

Blu-ray ROM DVD+/-RW SuperMulti DL

Supports the following 9.5-mm SATA hard drive:

●

500-GB, 7200-rpm

●

320-GB, 7200-rpm

√√√

Microphone Integrated dual-array microphone

(webcam models only)

√√√

Integrated mono (non-webcam models) √

Audio HD audio √√√

Stereo speakers (2) √√√

Webcam Integrated webcam (720p HD) √√√

Modem 56K V.92 MDC data/fax modem √√√

Modem cable not included √√√

4 Chapter 1 Product description

Category Description HP ProBook

6460b Notebook PC

HP EliteBook 8460p Notebook PC

HP EliteBook 8460w Mobile Workstation

Supports “No Modem” option √√√

Ethernet Intel 82579LM GbE LAN 10/100/1000

network interface card (NIC) with iAMT (vPro models)

√√√

Intel 82579V GbE LAN 10/100/1000

network interface card (non-vPro models)

√

S3/S4/S5 wake on LAN √√√

NIC power down technology √√√

Ethernet cable not included √√√

Wireless Integrated WLAN options by way of wireless module:

Two WLAN antennas built into display

assembly

√

Three WLAN antennas built into display

assembly

√√

Supports “no WLAN” option √√√

Supports the following WLAN formats:

●

Broadcom 802.11 b/g/n, 1×1

●

Broadcom 802.11 a/b/g/n, 2×2

√√√

●

Broadcom 4322, 802.11a/b/g/n, 2×2

√

●

Intel Centrino Wireless-N 1000, 1×2 b/g/n

√

●

Atheros 802.11 a/g/n 3×3 √√

● Intel Centrino Advanced N 6205,

2×2 a/b/g/n

√√

● Intel Centrino Ultimate-N 6300,

3×3 a/b/g/n

√√

Integrated WWAN options by way of wireless module:

Two WWAN antennas built into display

assembly (world-wide 5 band, in WWAN panels only)

√√√

Subscriber identity module (SIM)

security (customer-accessible in battery bay)

√√√

Supports “no WWAN” option √√√

Category Description HP ProBook

6460b Notebook PC

HP EliteBook 8460p Notebook PC

HP EliteBook 8460w Mobile Workstation

Supports the following WWAN

modules:

● Qualcomm Gobi 3000 HSPA/

CDMA with GPS

●

Ericsson 5521 HSPA+

●

HP lt2510 EV-DO/LTE Mobile Broadband Module

√√√

Integrated personal area network (PAN) options by way of Bluetooth® module:

Supports “no PAN” option √√√

Integrated Bluetooth 2.1 √√√

External media card One ExpressCard/54 slot √√√

Integrated Media Card Reader with SD,

MMC support

√√√

Ports Audio-in (stereo microphone) √√√

Audio-out (stereo headphone) √√√

DisplayPort 1.1a √√√

RJ-11 (modem) √√√

RJ-45 (Ethernet, includes link and

activity lights)

√√√

USB 3.0 √√

USB 2.0 (3) √√√

USB 2.0 charging port √√

eSATA/USB 2.0 combo port √√√

VGA (Dsub 15-pin) supporting 1920 ×

1200 external resolution at 75-GHz (hot plug with auto-detect)

√√√

1394a √√√

3-pin AC power √√√

Secondary battery connector √√√

Docking connector √√√

Docking HP Docking Station √√√

HP Advanced Docking Station √√√

Keyboard/pointing devices

Keyboard with DuraKeys √√

Dual point √√√

Spill-resistant design √√√

Full chiclet keyboard √√√

6 Chapter 1 Product description

Category Description HP ProBook

6460b Notebook PC

HP EliteBook 8460p Notebook PC

HP EliteBook 8460w Mobile Workstation

Touchpad includes: on/off button,

supports 2-way scroll with legend, taps enabled by default, 2-finger scrolling and zoom enabled by default

√√√

Power requirements Smart AC adapter with localized cable

plug support (3-wire plug with ground pin, supports 3-pin DC connector):

● 90-W

●

65-W

√√√

9-cell, 3.0-Ah (100-Wh) Li-ion battery √√√

6-cell, 2.8-Ah (62-Wh) Li-ion battery √√√

6-cell, 2.55-Ah (55-Wh) Li-ion battery √

3-cell, 2.8-Ah (31-Wh) Li-ion battery √√√

Supports 9-cell, 73-Wh HP Ultra-

Capacity Extended Life Battery

√√√

Supports 9-cell, 100-Wh HP Extended

Life Battery

√√√

Supports 6-cell, 55-Wh HP Long Life Li-

ion battery

√√√

HP Fast Charge Technology √√√

Security Integrated fingerprint reader √√√

Integrated smart card reader √√√

Security cable slot √√√

Trusted platform module (TPM) V.1.2 √√√

Full volume encryption √√√

Preboot authentication (password,

smart card)

√√√

Operating system Preinstalled:

Windows 7 Professional 32 with

Microsoft® Basics

√√√

Windows 7 Professional with Microsoft

Basics

√√√

Windows 7 Home Premium 64 with

Microsoft Basics

√√√

Windows 7 Home Premium 32 with

Microsoft Basics

√√√

Windows Vista Home Basic 32 with

Microsoft Basics

√√√

Novell™: SuSE Linux™ – SLED 11 √

Category Description HP ProBook

6460b Notebook PC

HP EliteBook 8460p Notebook PC

HP EliteBook 8460w Mobile Workstation

FreeDOS √√√

Preinstalled with Microsoft Office:

Windows 7 Professional 32 with

Microsoft Office 2010 Starter

√√√

Windows 7 Professional 32 with

Microsoft Office 2010 Personal

√√√

Windows 7 Professional 32 with

Microsoft Office 2010 Home & Business

√√√

Windows 7 Professional 32 with

Microsoft Office 2010 Professional

√√√

Windows 7 Professional 64 with

Microsoft Office 2010 Starter

√√√

Windows 7 Professional 64 with

Microsoft Office 2010 Personal

√√√

Windows 7 Professional 64 with

Microsoft Office 2010 Home & Business

√√√

Windows 7 Professional 64 with

Microsoft Office 2010 Professional

√√√

Windows 7 Home Premium 32 with

Microsoft Office 2010 Starter

√√√

Windows 7 Home Premium 32 with

Microsoft Office 2010 Personal

√√√

Windows 7 Home Premium 32 with

Microsoft Office 2010 Home & Business

√√√

Windows 7 Home Premium 32 with

Microsoft Office 2010 Professional

√√√

Windows 7 Home Premium 64 with

Microsoft Office 2010 Starter

√√√

Windows 7 Premium 64 with Microsoft

Office 2010 Professional

√√√

Windows 7 Starter with Microsoft Office

2010 Starter

√√√

Windows 7 Home Basic 32 with

Microsoft Office 2010 Starter

√√√

Windows Vista Basic 32 with Microsoft

Office 2010 Starter

√√√

Windows Vista Basic 32 with Microsoft

Office 2010 Personal

√√√

Windows Vista Basic 32 with Microsoft

Office 2010 Home & Business

√√√

8 Chapter 1 Product description

Category Description HP ProBook

6460b Notebook PC

HP EliteBook 8460p Notebook PC

HP EliteBook 8460w Mobile Workstation

Windows Vista Basic 32 with Microsoft

Office 2010 Professional

√√√

Restore Media:

Windows 7 Professional 64 √√√

Windows 7 Professional 32 √√√

Windows 7 Home Basic 32 √√√

Windows 7 Home Premium 64 √√√

Windows 7 Home Premium 32 √√√

Windows 7 Starter 32 √

DRDVD Windows 7 √√√

DRDVD Windows 7 with WinDVD √√√

Web-only support:

Windows XP Professional 64 √√

Windows XP Professional 32 √

Windows Vista Enterprise 32/64 √√√

Windows Vista Business 32/64 √√√

Windows 7 Enterprise 32/64 √√√

Windows 7 Ultimate 32/64 √√√

Certified:

Microsoft WHQL √√√

Novell: SuSE Linux √√√

Serviceability End-user replaceable parts:

AC adapter √√√

Battery (system) √√√

Hard drive √√√

Memory module √√√

Optical drive √√√

Mini-PCI components (WLAN, WWAN,

SIM)

√√√

Modem √√√

Keyboard √√√

2 External component identification

Display

NOTE: Refer to the illustration that most closely matches your computer.

Component Description

(1) Internal display switch Turns off the display or initiates Sleep if the display is closed

while the power is on.

NOTE: The display switch is not visible from the outside of the

computer.

(2) WLAN antennas (3)* Send and receive wireless signals to communicate with wireless

local area networks (WLAN).

(3) WWAN antennas (2)* Send and receive wireless signals to communicate with wireless

wide-area networks (WWAN).

(4) Internal microphones (2) Record sound.

10 Chapter 2 External component identification

Component Description

(5) Webcam light (select models only) On: The webcam is in use.

(6) Webcam (select models only) Records video and captures still photographs.

To use the webcam, select Start > All Programs > HP > HP Webcam.

(7) Ambient light sensor When activated, the sensor automatically adjusts the display

brightness based on the lighting conditions in your environment.

(8) Keyboard light On: When the keyboard light is activated.

(9) Keyboard light button Used to activate the keyboard light.

*The antennas are not visible from the outside of the computer. For optimal transmission, keep the areas immediately around the antennas free from obstructions. To see wireless regulatory notices, refer to the section of the Regulatory, Safety and Environmental Notices that applies to your country or region. These notices are located in Help and Support.

Component Description

(1) Internal display switch Turns off the display or initiates Sleep if the display is closed

while the power is on.

NOTE: The display switch is not visible from the outside of the

computer.

(2) WLAN antennas (2)* Send and receive wireless signals to communicate with wireless

local area networks (WLAN).

(3) WWAN antennas (2)* (select models only) Send and receive wireless signals to communicate with wireless

wide-area networks (WWAN).

(4) Internal microphone(s) (1 or 2 depending on

model)

Record sound.

(5) Webcam light (select models only) On: The webcam is in use.

Display 11

Component Description

(6) Webcam (select models only) Records video and captures still photographs.

To use the webcam, select Start > All Programs > HP > HP Webcam.

12 Chapter 2 External component identification

Top

TouchPad

NOTE: Your computer may look slightly different from the illustration in this section.

Component Description

(1) Pointing stick (select models only) Moves the pointer and selects or activates items on the

screen.

(2) Left pointing stick button Can be used with the pointing stick and functions like the

left button on an external mouse.

(3) TouchPad on/off button Turns the TouchPad on and off.

(4) TouchPad Moves the pointer and selects or activates items on the

screen.

NOTE: Vertical scrolling is supported on the right edge of

the TouchPad.

(5) Left TouchPad button Functions like the left button on an external mouse.

(6) Right TouchPad button Functions like the right button on an external mouse.

(7) Right pointing stick button Can be used with the pointing stick and functions like the

right button on an external mouse.

Top 13

Lights

NOTE: Refer to the illustration that most closely matches your computer.

Component Description

(1) TouchPad on/off light

●

Amber: The TouchPad is off.

● Off: The TouchPad is on.

(2) Caps lock light On: Caps lock is on.

(3)

Power light ● On: The computer is on.

●

Blinking: The computer is in the Sleep state.

●

Off: The computer is off or in Hibernation.

14 Chapter 2 External component identification

Component Description

(4)

Wireless light

●

White: An integrated wireless device, such as a wireless local area network (WLAN) device and/or a Bluetooth® device, is on.

●

Amber: All wireless devices are off.

(5)

QuickWeb light

●

On: The computer is on.

● Off: The computer is off or in Hibernation.

NOTE: For more information, refer to “HP QuickWeb” in

this guide and to the HP Quickweb software Help

(6)

Mute light ● Amber: Computer sound is off.

●

Off: Computer sound is on.

(7) Num lock light On: Num lock is on.

Top 15

Buttons and fingerprint reader

NOTE: Refer to the illustration that most closely matches your computer.

Component Description

(1) TouchPad on/off button Turns the TouchPad on and off.

16 Chapter 2 External component identification

Component Description

(2)

Power button

●

When the computer is off, press the button to turn on the computer.

●

When the computer is on, press the button briefly to initiate Sleep.

● When the computer is in the Sleep state, press the

button briefly to exit Sleep.

●

When the computer is in Hibernation, press the button briefly to exit Hibernation.

If the computer has stopped responding and Windows® shutdown procedures are ineffective, press and hold the power button for at least 5 seconds to turn off the computer.

To learn more about your power settings:

●

Windows 7—Select Start > Control Panel > System and Security > Power Options.

●

Windows Vista—Select Start > Control Panel > System and Maintenance > Power Options

●

Or refer to the HP Notebook Reference Guide.

(3)

Wireless button Turns the wireless feature on or off but does not establish a

wireless connection.

(4)

QuickWeb button ● When the computer is off or in Hibernation, press the

button to open HP QuickWeb.

●

When the computer is in HP QuickWeb, press the button to open the default Web browser.

NOTE: For more information, refer to “HP QuickWeb” in

this guide and to the HP QuickWeb software Help. If your computer does not have HP QuickWeb software, the button does not perform any action or function.

(5)

Volume mute button Mutes and restores speaker sound.

(6) Fingerprint reader (select models only) Allows a fingerprint logon to Windows, instead of a

password logon.

Top 17

Keys

NOTE: Refer to the illustration that most closely matches your computer.

Component Description

(1) esc key Displays system information when pressed in combination

with the fn key.

(2) Function keys Execute frequently used system functions when pressed in

combination with the fn key.

18 Chapter 2 External component identification

Component Description

(3) fn key Executes frequently used system functions when pressed

in combination with a function key, the num lk key, or the

esc key.

(4)

Start key Displays the Start menu.

(5)

Menu key Displays the active program’s shortcut menu (same as

right-click menu).

(6) Embedded numeric keypad keys Can be used like the keys on an external numeric keypad

when pressed in combination with the fn and num lk keys.

(7) num lk key Enables/disables the embedded numeric keypad when

pressed in combination with the fn key.

Top 19

Front

NOTE: Refer to the illustration that most closely matches your computer.

Component Description

(1) Display release latch Opens the computer.

(2) Wireless light

●

White: An integrated wireless device, such as a wireless local area network (WLAN) device and/or a Bluetooth® device, is on.

●

Amber: All wireless devices are off.

(3) Power light ● On: The computer is on.

●

Blinking: The computer is in the Sleep state.

●

Off: The computer is off or in Hibernation.

(4) Battery light

●

Amber: The computer is connected to external power and the battery is charged from 0 – 90%.

● White: The computer is connected to external power and

the battery is charged from 90 – 99%.

● Blinking amber: A battery that is the only available power

source has reached a low battery level. When the battery reaches a critical battery level, the battery light begins blinking rapidly.

●

Off: The battery is fully charged.

20 Chapter 2 External component identification

Component Description

(5) Hard drive light

●

Blinking turquoise: The hard drive or optical drive is being accessed.

●

Amber: HP 3D DriveGuard has temporarily parked the hard drive.

(6) Speaker Produces SRS Premium sound (select models only).

NOTE: To use the SRS Premium sound software, select Start

> All Programs > SRS Premium Sound.

Left

NOTE: Refer to the illustration that most closely matches your computer.

Component Description

(1)

Power connector Connects an AC adapter.

(2)

1394 port Connects an optional IEEE 1394 or 1394a device, such as

a camcorder.

(3)

– or –

USB or SuperSpeed USB ports (2) Connect optional USB devices.

NOTE: Some models support SuperSpeed USB 3.0

technology. These models show a slightly different icon.

(4)

ExpressCard slot (select models only) Supports optional ExpressCards.

(5) Media Card Reader Supports the following digital card formats:

●

Secure Digital (SD) Card

●

MultiMediaCard (MMC)

(6) Optical drive Reads and writes (select models only) to an optical disc.

(7) Optical drive eject button Ejects the optical drive.

Left 21

Rear

NOTE: Refer to the illustration that most closely matches your computer.

Component Description

(1)

RJ-11 (modem) jack Connects a modem cable.

(2)

External monitor port Connects an external VGA monitor or projector.

(3)

RJ-45 (network) jack Connects a network cable.

22 Chapter 2 External component identification

+ 133 hidden pages

HP EliteBook 8460w, XU060UT, ProBook 6460b, EliteBook 8460p Maintenance And Service Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
