HP XC System 4.x Software User Manual
HP XC System Software
XC User Guide
Version 4.0
HP Part Number: A-XCUSR-40a
Published: February 2009
© Copyright 2003, 2005, 2006, 2007, 2008, 2009 Hewlett-Packard Development Company, L.P.
Confidential computersoftware. Valid license from HP required for possession, use or copying. Consistent with FAR 12.211 and 12.212, Commercial
Computer Software, Computer Software Documentation, and Technical Data for Commercial Items are licensed to the U.S. Government under
vendor's standardcommercial license.The informationcontained hereinis subject to change without notice. The only warranties forHP products
and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as
constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
AMD and AMD Opteron are trademarks or registered trademarks of Advanced Micro Devices, Inc.
Intel , the Intel logo, Itanium , and Xeon are trademarks or registered trademarks of Intel Corporation in the United States and other countries.
Linux is a U.S. registered trademark of Linus Torvalds.
LSF, Platform Computing, and the LSF and Platform Computing logos are trademarks or registered trademarks of Platform Computing, Inc.
Lustre is a trademark of Cluster File Systems, Inc.
Myrinet and Myricom are registered trademarks of Myricom, Inc.
Quadrics and QSNet II are registered trademarks of Quadrics, Ltd.
The Portland Group and PGI are trademarks or registered trademarks of The Portland Group Compiler Technology, STMicroelectronics, Inc.
Red Hat is a registered trademark of Red Hat Inc.
syslog-ng is a copyright of BalaBit IT Security.
SystemImager is a registered trademark of Brian Finley.
TotalView is a registered trademark of Etnus, Inc.
UNIX is a registered trademark of The Open Group.
Table of Contents
About This Document.......................................................................................................11
Intended Audience................................................................................................................................11
New and Changed Information in This Edition...................................................................................11
Typographic Conventions.....................................................................................................................11
HP XC and Related HP Products Information.....................................................................................12
Related Information..............................................................................................................................13
Manpages..............................................................................................................................................16
HP Encourages Your Comments..........................................................................................................17
1 Overview of the User Environment.............................................................................19
1.1 System Architecture........................................................................................................................19
1.1.1 HP XC System Software..........................................................................................................19
1.1.2 Operating System....................................................................................................................19
1.1.3 Node Platforms.......................................................................................................................19
1.1.4 Node Specialization.................................................................................................................20
1.1.5 Storage and I/O........................................................................................................................21
1.1.6 File System...............................................................................................................................21
1.1.7 System Interconnect Network.................................................................................................22
1.1.8 Network Address Translation (NAT)......................................................................................23
1.2 Determining System Configuration Information............................................................................23
1.3 User Environment...........................................................................................................................23
1.3.1 LVS...........................................................................................................................................23
1.3.2 Modules...................................................................................................................................23
1.3.3 Commands..............................................................................................................................24
1.4 Application Development Environment.........................................................................................24
1.4.1 Parallel Applications...............................................................................................................24
1.4.2 Serial Applications..................................................................................................................25
1.5 Run-Time Environment...................................................................................................................25
1.5.1 SLURM....................................................................................................................................25
1.5.2 Load Sharing Facility (LSF).....................................................................................................25
1.5.3 Standard LSF...........................................................................................................................25
1.5.4 How LSF and SLURM Interact................................................................................................26
1.5.5 HP-MPI....................................................................................................................................26
1.6 Components, Tools, Compilers, Libraries, and Debuggers............................................................27
2 Using the System..........................................................................................................29
2.1 Logging In to the System.................................................................................................................29
2.1.1 LVS Login Routing..................................................................................................................29
2.1.2 Using the Secure Shell to Log In.............................................................................................29
2.2 Overview of Launching and Managing Jobs..................................................................................29
2.2.1 Introduction.............................................................................................................................30
2.2.2 Getting Information About Queues........................................................................................30
2.2.3 Getting Information About Resources....................................................................................30
2.2.4 Getting Information About System Partitions........................................................................31
2.2.5 Launching Jobs........................................................................................................................31
2.2.6 Getting Information About Your Jobs.....................................................................................31
2.2.7 Stopping and Suspending Jobs...............................................................................................31
2.2.8 Resuming Suspended Jobs......................................................................................................31
2.3 Performing Other Common User Tasks..........................................................................................31
Table of Contents 3
2.3.1 Determining the LSF Cluster Name and the LSF Execution Host..........................................32
2.4 Getting System Help and Information............................................................................................32
3 Configuring Your Environment with Modulefiles.......................................................33
3.1 Overview of Modules......................................................................................................................33
3.2 Supplied Modulefiles......................................................................................................................34
3.3 Modulefiles Automatically Loaded on the System.........................................................................36
3.4 Viewing Available Modulefiles.......................................................................................................36
3.5 Viewing Loaded Modulefiles..........................................................................................................36
3.6 Loading a Modulefile......................................................................................................................36
3.6.1 Loading a Modulefile for the Current Session........................................................................36
3.6.2 Automatically Loading a Modulefile at Login........................................................................36
3.7 Unloading a Modulefile..................................................................................................................37
3.8 Viewing Modulefile-Specific Help..................................................................................................37
3.9 Modulefile Conflicts........................................................................................................................37
3.10 Creating a Modulefile....................................................................................................................38
4 Developing Applications.............................................................................................39
4.1 Application Development Environment Overview........................................................................39
4.2 Compilers........................................................................................................................................40
4.2.1 MPI Compiler..........................................................................................................................40
4.3 Examining Nodes and Partitions Before Running Jobs..................................................................41
4.4 Interrupting a Job............................................................................................................................41
4.5 Setting Debugging Options.............................................................................................................41
4.6 Developing Serial Applications.......................................................................................................41
4.6.1 Serial Application Build Environment....................................................................................42
4.6.2 Building Serial Applications...................................................................................................42
4.6.2.1 Compiling and Linking Serial Applications...................................................................42
4.7 Developing Parallel Applications....................................................................................................42
4.7.1 Parallel Application Build Environment.................................................................................42
4.7.1.1 Modulefiles......................................................................................................................43
4.7.1.2 HP-MPI............................................................................................................................43
4.7.1.3 OpenMP..........................................................................................................................43
4.7.1.4 Pthreads...........................................................................................................................43
4.7.1.5 Quadrics SHMEM...........................................................................................................43
4.7.1.6 MPI Library.....................................................................................................................44
4.7.1.7 Intel Fortran and C/C++Compilers..................................................................................44
4.7.1.8 PGI Fortran and C/C++ Compilers..................................................................................44
4.7.1.9 GNU C and C++ Compilers.............................................................................................44
4.7.1.10 Pathscale Compilers......................................................................................................44
4.7.1.11 GNU Parallel Make.......................................................................................................44
4.7.1.12 MKL Library..................................................................................................................45
4.7.1.13 ACML Library...............................................................................................................45
4.7.1.14 Other Libraries..............................................................................................................45
4.7.2 Building Parallel Applications................................................................................................45
4.7.2.1 Compiling and Linking Non-MPI Applications.............................................................45
4.7.2.2 Compiling and Linking HP-MPI Applications...............................................................45
4.7.2.3 Examples of Compiling and Linking HP-MPI Applications..........................................45
4.8 Developing Libraries.......................................................................................................................46
4.8.1 Designing Libraries for the CP4000 Platform.........................................................................46
5 Submitting Jobs............................................................................................................49
5.1 Overview of Job Submission...........................................................................................................49
4 Table of Contents
5.2 Submitting a Serial Job Using LSF...................................................................................................49
5.2.1 Submitting a Serial Job with the LSF bsub Command............................................................49
5.2.2 Submitting a Serial Job Through SLURM Only......................................................................50
5.3 Submitting a Parallel Job.................................................................................................................51
5.3.1 Submitting a Non-MPI Parallel Job.........................................................................................51
5.3.2 Submitting a Parallel Job That Uses the HP-MPI Message Passing Interface.........................52
5.3.3 Submitting a Parallel Job Using the SLURM External Scheduler...........................................53
5.4 Submitting a Batch Job or Job Script...............................................................................................56
5.5 Submitting Multiple MPI Jobs Across the Same Set of Nodes........................................................58
5.5.1 Using a Script to Submit Multiple Jobs...................................................................................58
5.5.2 Using a Makefile to Submit Multiple Jobs..............................................................................58
5.6 Submitting a Job from a Host Other Than an HP XC Host.............................................................61
5.7 Running Preexecution Programs....................................................................................................61
6 Debugging Applications.............................................................................................63
6.1 Debugging Serial Applications.......................................................................................................63
6.2 Debugging Parallel Applications....................................................................................................63
6.2.1 Debugging with TotalView.....................................................................................................64
6.2.1.1 SSH and TotalView..........................................................................................................64
6.2.1.2 Setting Up TotalView......................................................................................................64
6.2.1.3 Using TotalView with SLURM........................................................................................65
6.2.1.4 Using TotalView with LSF...............................................................................................65
6.2.1.5 Setting TotalView Preferences.........................................................................................65
6.2.1.6 Debugging an Application..............................................................................................66
6.2.1.7 Debugging Running Applications..................................................................................67
6.2.1.8 Exiting TotalView............................................................................................................67
7 Monitoring Node Activity............................................................................................69
7.1 The Xtools Utilities..........................................................................................................................69
7.2 Running Performance Health Tests.................................................................................................70
8 Tuning Applications.....................................................................................................75
8.1 Using the Intel Trace Collector and Intel Trace Analyzer...............................................................75
8.1.1 Building a Program — Intel Trace Collector and HP-MPI......................................................75
8.1.2 Running a Program – Intel Trace Collector and HP-MPI.......................................................76
8.2 The Intel Trace Collector and Analyzer with HP-MPI on HP XC...................................................77
8.2.1 Installation Kit.........................................................................................................................77
8.2.2 HP-MPI and the Intel Trace Collector.....................................................................................77
8.3 Visualizing Data – Intel Trace Analyzer and HP-MPI....................................................................79
9 Using SLURM................................................................................................................81
9.1 Introduction to SLURM...................................................................................................................81
9.2 SLURM Utilities...............................................................................................................................81
9.3 Launching Jobs with the srun Command.......................................................................................81
9.3.1 The srun Roles and Modes......................................................................................................82
9.3.1.1 The srun Roles.................................................................................................................82
9.3.1.2 The srun Modes...............................................................................................................82
9.3.2 Using the srun Command with HP-MPI................................................................................82
9.3.3 Using the srun Command with LSF........................................................................................82
9.4 Monitoring Jobs with the squeue Command..................................................................................82
9.5 Terminating Jobs with the scancel Command.................................................................................83
9.6 Getting System Information with the sinfo Command...................................................................83
Table of Contents 5
9.7 Job Accounting................................................................................................................................84
9.8 Fault Tolerance................................................................................................................................84
9.9 Security............................................................................................................................................84
10 Using LSF....................................................................................................................85
10.1 Information for LSF.......................................................................................................................85
10.2 Overview of LSF Integrated with SLURM....................................................................................86
10.3 Differences Between LSF and LSF Integrated with SLURM.........................................................88
10.4 Job Terminology............................................................................................................................89
10.5 Using LSF Integrated with SLURM in the HP XC Environment..................................................91
10.5.1 Useful Commands.................................................................................................................91
10.5.2 Job Startup and Job Control...................................................................................................91
10.5.3 Preemption............................................................................................................................91
10.6 Submitting Jobs..............................................................................................................................91
10.7 LSF-SLURM External Scheduler....................................................................................................92
10.8 How LSF and SLURM Launch and Manage a Job........................................................................92
10.9 Determining the LSF Execution Host............................................................................................94
10.10 Determining Available System Resources...................................................................................94
10.10.1 Examining System Core Status............................................................................................95
10.10.2 Getting Information About the LSF Execution Host Node.................................................95
10.10.3 Getting Host Load Information...........................................................................................96
10.10.4 Examining System Queues..................................................................................................96
10.10.5 Getting Information About the lsf Partition.....................................................................96
10.11 Getting Information About Jobs..................................................................................................96
10.11.1 Getting Job Allocation Information.....................................................................................97
10.11.2 Examining the Status of a Job..............................................................................................98
10.11.3 Viewing the Historical Information for a Job......................................................................99
10.12 Translating SLURM and LSF JOBIDs.........................................................................................100
10.13 Working Interactively Within an Allocation..............................................................................101
10.14 LSF Equivalents of SLURM srun Options.................................................................................103
11 Advanced Topics......................................................................................................107
11.1 Enabling Remote Execution with OpenSSH................................................................................107
11.2 Running an X Terminal Session from a Remote Node................................................................107
11.3 Using the GNU Parallel Make Capability...................................................................................109
11.3.1 Example Procedure 1...........................................................................................................111
11.3.2 Example Procedure 2...........................................................................................................111
11.3.3 Example Procedure 3...........................................................................................................112
11.4 Local Disks on Compute Nodes..................................................................................................112
11.5 I/O Performance Considerations.................................................................................................113
11.5.1 Shared File View..................................................................................................................113
11.5.2 Private File View..................................................................................................................113
11.6 Communication Between Nodes.................................................................................................113
11.7 Using MPICH on the HP XC System...........................................................................................113
11.7.1 Using MPICH with SLURM Allocation..............................................................................114
11.7.2 Using MPICH with LSF Allocation.....................................................................................114
A Examples....................................................................................................................115
A.1 Building and Running a Serial Application.................................................................................115
A.2 Launching a Serial Interactive Shell Through LSF.......................................................................115
A.3 Running LSF Jobs with a SLURM Allocation Request.................................................................116
A.3.1 Example 1. Two Cores on Any Two Nodes..........................................................................116
A.3.2 Example 2. Four Cores on Two Specific Nodes....................................................................117
6 Table of Contents
A.4 Launching a Parallel Interactive Shell Through LSF....................................................................117
A.5 Submitting a Simple Job Script with LSF.....................................................................................119
A.6 Submitting an Interactive Job with LSF........................................................................................120
A.7 Submitting an HP-MPI Job with LSF...........................................................................................122
A.8 Using a Resource Requirements String in an LSF Command......................................................123
Glossary.........................................................................................................................125
Index...............................................................................................................................131
Table of Contents 7
List of Figures
4-1 Library Directory Structure...........................................................................................................47
4-2 Recommended Library Directory Structure..................................................................................47
10-1 How LSF and SLURM Launch and Manage a Job........................................................................93
11-1 MPICH Wrapper Script...............................................................................................................114
8 List of Figures
List of Tables
1-1 Determining the Node Platform...................................................................................................20
1-2 HP XC System Interconnects.........................................................................................................22
3-1 Supplied Modulefiles....................................................................................................................34
4-1 Compiler Commands....................................................................................................................40
5-1 Arguments for the SLURM External Scheduler............................................................................54
10-1 LSF with SLURM Job Launch Exit Codes.....................................................................................92
10-2 Output Provided by the bhist Command.....................................................................................99
10-3 LSF Equivalents of SLURM srun Options...................................................................................103
9
List of Examples
5-1 Submitting a Job from the Standard Input....................................................................................50
5-2 Submitting a Serial Job Using LSF ................................................................................................50
5-3 Submitting an Interactive Serial Job Using LSF only....................................................................50
5-4 Submitting an Interactive Serial Job Using LSF and the LSF-SLURM External Scheduler..........50
5-5 Submitting a Non-MPI Parallel Job...............................................................................................52
5-6 Submitting a Non-MPI Parallel Job to Run One Task per Node...................................................52
5-7 Submitting an MPI Job..................................................................................................................53
5-8 Submitting an MPI Job with the LSF-SLURM External Scheduler Option...................................53
5-9 Using the External Scheduler to Submit a Job to Run on Specific Nodes.....................................55
5-10 Using the External Scheduler to Submit a Job to Run One Task per Node..................................55
5-11 Using the External Scheduler to Submit a Job That Excludes One or More Nodes.....................55
5-12 Using the External Scheduler to Launch a Command in Parallel on Ten Nodes.........................55
5-13 Using the External Scheduler to Constrain Launching to Nodes with a Given Feature..............56
5-14 Submitting a Job Script..................................................................................................................56
5-15 Submitting a Batch Script with the LSF-SLURM External Scheduler Option...............................57
5-16 Submitting a Batch Job Script That Uses a Subset of the Allocation.............................................57
5-17 Submitting a Batch job Script That Uses the srun --overcommit Option......................................57
5-18 Environment Variables Available in a Batch Job Script.................................................................58
8-1 The vtjacobic Example Program....................................................................................................76
8-2 C Example – Running the vtjacobic Example Program................................................................76
9-1 Simple Launch of a Serial Program...............................................................................................82
9-2 Displaying Queued Jobs by Their JobIDs.....................................................................................83
9-3 Reporting on Failed Jobs in the Queue.........................................................................................83
9-4 Terminating a Job by Its JobID......................................................................................................83
9-5 Cancelling All Pending Jobs..........................................................................................................83
9-6 Sending a Signal to a Job...............................................................................................................83
9-7 Using the sinfo Command (No Options)......................................................................................83
9-8 Reporting Reasons for Downed, Drained, and Draining Nodes..................................................84
10-1 Examples of LSF Job Launch.........................................................................................................87
10-2 Examples of Launching LSF Jobs Without the srun Command...................................................88
10-3 Job Allocation Information for a Running Job..............................................................................97
10-4 Job Allocation Information for a Finished Job..............................................................................98
10-5 Using the bjobs Command (Short Output)...................................................................................98
10-6 Using the bjobs Command (Long Output)...................................................................................99
10-7 Using the bhist Command (Short Output)....................................................................................99
10-8 Using the bhist Command (Long Output)..................................................................................100
10-9 Launching an Interactive MPI Job...............................................................................................102
10-10 Launching an Interactive MPI Job on All Cores in the Allocation..............................................102
10 List of Examples
About This Document
This document provides information about using the features and functions of the HP XC System
Software. It describes how the HP XC user and programmingenvironments differ from standard
Linux® system environments. In addition, this manual focuses on building and running
applications in the HP XC environment and is intended to guide an application developer to
take maximum advantage of HP XC features and functions by providing an understanding of
the underlying mechanisms of the HP XC programming environment.
An HP XC system is integratedwith several open source software components. Some open source
software components are being used for underlying technology, and their deployment is
transparent. Some open source software components require user-level documentation specific
to HP XC systems, and that kind of information is included in this document, when required.
HP relies on the documentation providedby the open source developersto supply the information
you need to use their product. For links to open source software documentation for products
that are integrated with the HP XC system, see “Supplementary Software Products” (page 13).
Documentation for third-party hardware and software components that are supported on the
HP XC system is supplied by the third-party vendor. However, information about the operation
of third-party software is included in this document if the functionality of the third-party
component differs from standard behavior when used in the XC environment. In this case, HP
XC documentation supersedes information supplied by the third-party vendor. For links to
related third-party Web sites, see “Supplementary Software Products” (page 13).
Standard Linux® administrative tasks or the functions provided by standard Linux tools and
commands are documented in commercially available Linux reference manuals and on various
Web sites. For more information aboutobtaining documentation for standard Linuxadministrative
tasks and associated topics, see the list of Web sites and additional publications provided in
“Related Software Products and Additional Publications” (page 15).
Intended Audience
This document is intended for experienced Linux users who run applications developed by
others, and for experienced system or application developers who develop, build, and run
application code on an HP XC system.
This document assumes that the user understands, and has experience with, multiprocessor
systems and the Message Passing Interface (MPI), and is familiar with HP XC architecture and
concepts.
New and Changed Information in This Edition
• The xcxclus and xcxperf utilities are now described as part of a separate document.
• There are various changes with regard to Platform LSF brand.
Typographic Conventions
This document uses the following typographical conventions:
%, $, or #
audit(5) A manpage. The manpage name is audit, and it is located in
Command
Computer output
A percent sign represents the C shell system prompt. A dollar
sign represents the system prompt for the Korn, POSIX, and
Bourne shells. A number sign represents the superuser prompt.
Section 5.
A command name or qualified command phrase.
Text displayed by the computer.
Intended Audience 11
Ctrl+x A key sequence. A sequence such as Ctrl+x indicates that you
must hold down the key labeled Ctrl while you press another
key or mouse button.
ENVIRONMENT VARIABLE The name of an environment variable, for example, PATH.
[ERROR NAME]
The name of an error, usually returned in the errno variable.
Key The name of a keyboard key. Return and Enter both refer to the
same key.
Term The defined use of an important word or phrase.
User input
Variable
Commands and other text that you type.
The name of a placeholder in a command, function, or other
syntax display that you replace with an actual value.
[ ] The contents are optional in syntax. If the contents are a list
separated by |, you can choose one of the items.
{ } The contents are required in syntax. If the contents are a list
separated by |, you must choose one of the items.
. . . The preceding element can be repeated an arbitrary number of
times.
| Separates items in a list of choices.
WARNING A warning calls attention to important information that if not
understood or followed will result in personal injury or
nonrecoverable system problems.
CAUTION A caution calls attention to important information that if not
understood or followed will result in data loss, data corruption,
or damage to hardware or software.
IMPORTANT This alert provides essential information to explain a concept or
to complete a task
NOTE A note contains additional information to emphasize or
supplement important points of the main text.
HP XC and Related HP Products Information
The HP XC System Software Documentation Set, the Master Firmware List, and HP XC HowTo
documents are available at this HP Technical Documentation Web site:
http://www.docs.hp.com/en/linuxhpc.html
The HP XC System Software Documentation Set includes the following core documents:
HP XC System Software Release Notes
HP XC Hardware Preparation Guide
HP XC System Software Installation Guide
HP XC System Software Administration Guide
12
Describes important, last-minute information about firmware,
software, or hardware that might affect the system. This
document is not shipped on the HP XC documentation CD. It
is available only on line.
Describes hardware preparation tasks specific to HP XC that
are required to prepare each supported hardware model for
installation and configuration, including required node and
switch connections.
Provides step-by-step instructions for installing the HP XC
System Software on the head node and configuring the system.
Provides an overview of the HP XC system administrative
environment, cluster administration tasks, node maintenance
tasks, LSF® administration tasks, and troubleshooting
procedures.
HP XC System Software User's Guide
QuickSpecs for HP XC System Software
Provides anoverview ofmanaging theHP XC user environment
with modules, managing jobs with LSF, and describes how to
build, run, debug, and troubleshoot serial and parallel
applications on an HP XC system.
Provides a product overview, hardwarerequirements, software
requirements, software licensing information, ordering
information, and information about commercially available
software that has been qualified to interoperate with the HP XC
System Software. The QuickSpecs are located on line:
http://www.hp.com/go/clusters
See the following sources for information about related HP products.
HP XC Program Development Environment
The Program Development Environment home page provide pointers to tools that have been
tested in the HP XC program development environment (for example, TotalView® and other
debuggers, compilers, and so on).
http://h20311.www2.hp.com/HPC/cache/276321-0-0-0-121.html
HP Message Passing Interface
HP Message Passing Interface (HP-MPI) is an implementation of the MPI standard that has been
integrated in HP XC systems. The home page and documentation is located at the following Web
site:
http://www.hp.com/go/mpi
HP Serviceguard
HP Serviceguard is a service availability tool supported on an HP XC system. HP Serviceguard
enables some system services to continue if a hardware or software failure occurs. The HP
Serviceguard documentation is available at the following Web site:
http://www.docs.hp.com/en/ha.html
HP Scalable Visualization Array
The HP Scalable Visualization Array (SVA) is a scalable visualization solution that is integrated
with the HP XC System Software. The SVA documentation is available at the following Web site:
http://www.docs.hp.com/en/linuxhpc.html
HP Cluster Platform
The cluster platform documentation describes site requirements, shows you how to set up the
servers and additional devices, and provides procedures to operate and manage the hardware.
These documents are available at the following Web site:
http://www.docs.hp.com/en/linuxhpc.html
HP Integrity and HP ProLiant Servers
Documentation for HP Integrity and HP ProLiant servers is available at the following Web site:
http://www.docs.hp.com/en/hw.html
Related Information
This section provides useful links to third-party, open source, and other related software products.
Supplementary Software Products This section provides links to third-party and open source
software products that are integrated into the HP XC System Software core technology. In the
HP XC documentation, except where necessary, references to third-party and open source
Related Information 13
software components are generic, and the HP XC adjective is not added to any reference to a
third-party or open source command or product name. For example, the SLURM srun command
is simply referred to as the srun command.
The location of each Web site or link to a particular topic listed in this section is subject to change
without notice by the site provider.
• http://www.platform.com
Home page for Platform Computing, Inc., the developer of the Load Sharing Facility (LSF).
LSF with SLURM, the batch system resource manager used on an HP XC system, is tightly
integrated withthe HP XC and SLURM software. Documentation specific to LSF with SLURM
is provided in the HP XC documentation set.
Standard LSF is also available as an alternative resource management system (instead of
LSF with SLURM) for HP XC. This is the version of LSF that is widely discussed on the
Platform Web site.
For your convenience, the following Platform LSF documents are shipped on the HP XC
documentation CD in PDF format:
— Administering Platform LSF
— Administration Primer
— Platform LSF Reference
— Quick Reference Card
— Running Jobs with Platform LSF
LSF procedures and information supplied in the HP XC documentation, particularly the
documentation relating to the LSF integration with SLURM, supersedes the information
supplied in the LSF manuals from Platform Computing, Inc.
The Platform LSF manpages are installed by default. lsf_diff(7) supplied by HP describes
LSF command differences when using LSF with SLURM on an HP XC system.
The following documents in the HP XC System Software Documentation Set provide
information about administering and using LSF on an HP XC system:
— HP XC System Software Administration Guide
— HP XC System Software User's Guide
• https://computing.llnl.gov/linux/slurm/documentation.html
Documentation for the Simple Linux Utility for Resource Management (SLURM), which is
integrated with LSF to manage job and compute resources on an HP XC system.
• http://www.nagios.org/
Home page for Nagios®, a system and network monitoring application that is integrated
into an HP XC system to provide monitoring capabilities. Nagios watches specified hosts
and services and issues alerts when problems occur and when problems are resolved.
• http://oss.oetiker.ch/rrdtool
Home page of RRDtool, a round-robin database tool and graphing system. In the HP XC
system, RRDtool is used with Nagios to provide a graphical view of system status.
• http://supermon.sourceforge.net/
Home page for Supermon, a high-speed cluster monitoring system that emphasizes low
perturbation, high sampling rates, and an extensible data protocol and programming
interface. Supermonworks in conjunction with Nagios to provide HP XC system monitoring.
• http://www.llnl.gov/linux/pdsh/
Home page for the parallel distributed shell (pdsh), which executes commands across HP
XC client nodes in parallel.
14
• http://www.balabit.com/products/syslog_ng/
Home page for syslog-ng, a logging tool that replaces the traditional syslog functionality.
The syslog-ng tool is a flexible and scalable audit trail processing tool. It provides a
centralized, securely stored log of all devices on the network.
• http://systemimager.org
Home page for SystemImager®, which is the underlying technology that distributes the
golden image to all nodes and distributes configuration changes throughout the system.
• http://linuxvirtualserver.org
Home page for the Linux Virtual Server (LVS), the load balancer running on the Linux
operating system that distributes login requests on the HP XC system.
• http://www.macrovision.com
Home pagefor Macrovision®, developer of the FLEXlm™ license management utility, which
is used for HP XC license management.
• http://sourceforge.net/projects/modules/
Web site for Modules, which provide for easy dynamic modification of a user's environment
through modulefiles, which typically instruct the module command to alter or set shell
environment variables.
• http://dev.mysql.com/
Home page for MySQL AB, developer of the MySQL database. This Web site contains a link
to the MySQL documentation, particularly the MySQL Reference Manual.
Related Software Products and Additional Publications This section provides pointers to Web
sites for related software products and provides references to useful third-party publications.
The location of each Web site or link to a particular topic is subject to change without notice by
the site provider.
Linux Web Sites
• http://www.redhat.com
Home page for Red Hat®, distributors of Red Hat Enterprise Linux Advanced Server, a
Linux distribution with which the HP XC operating environment is compatible.
• http://www.linux.org/docs/index.html
This Web site for the Linux Documentation Project (LDP) contains guides that describe
aspects of working with Linux, from creating your own Linux system from scratch to bash
script writing. This site also includes links to Linux HowTo documents, frequently asked
questions (FAQs), and manpages.
• http://www.linuxheadquarters.com
Web site providing documents and tutorials for the Linux user. Documents contain
instructions on installing and using applications for Linux, configuring hardware, and a
variety of other topics.
• http://www.gnu.org
Home page for the GNU Project. This site provides online software and information for
many programs and utilities that are commonly used on GNU/Linux systems. Online
information include guides for using the bash shell, emacs, make, cc, gdb, and more.
Related Information 15
MPI Web Sites
• http://www.mpi-forum.org
Contains the official MPI standards documents, errata, and archives of the MPI Forum. The
MPI Forum is an open group with representatives from many organizations that define and
maintain the MPI standard.
• http://www-unix.mcs.anl.gov/mpi/
A comprehensive site containing general information, such as the specification and FAQs,
and pointers to other resources, including tutorials, implementations, and other MPI-related
sites.
Compiler Web Sites
• http://www.intel.com/software/products/compilers/index.htm
Web site for Intel® compilers.
• http://support.intel.com/support/performancetools/
Web site for general Intel software development information.
• http://www.pgroup.com/
Home page for The Portland Group™, supplier of the PGI® compiler.
Debugger Web Site
http://www.etnus.com
Home page for Etnus, Inc., maker of the TotalView® parallel debugger.
Software RAID Web Sites
• http://www.tldp.org/HOWTO/Software-RAID-HOWTO.html and http://www.ibiblio.org/
pub/Linux/docs/HOWTO/other-formats/pdf/Software-RAID-HOWTO.pdf
A document (in two formats: HTML and PDF) that describes how to use software RAID
under a Linux operating system.
• http://www.linuxdevcenter.com/pub/a/linux/2002/12/05/RAID.html
Provides information about how to use the mdadm RAID management utility.
Additional Publications
For more information about standard Linux system administration or other related software
topics, consider using one of the following publications, which must be purchased separately:
• Linux Administration Unleashed, by Thomas Schenk, et al.
• Linux Administration Handbook, by Evi Nemeth, Garth Snyder, Trent R. Hein, et al.
• Managing NFS and NIS, by Hal Stern, Mike Eisler, and Ricardo Labiaga (O'Reilly)
• MySQL, by Paul Debois
• MySQL Cookbook, by Paul Debois
• High Performance MySQL, by Jeremy Zawodny and Derek J. Balling (O'Reilly)
• Perl Cookbook, Second Edition, by Tom Christiansen and Nathan Torkington
• Perl in A Nutshell: A Desktop Quick Reference , by Ellen Siever, et al.
Manpages
Manpages provide online reference and command information fromthe command line. Manpages
are supplied with the HP XC system for standard HP XC components, Linux user commands,
LSF commands, and other software components that are distributed with the HP XC system.
16
Manpages for third-party software components might be provided as a part of the deliverables
for that component.
Using discover(8) as an example, you can use either one of the following commands to display a
manpage:
$ man discover
$ man 8 discover
If you are not sure about a command you need to use, enter the man command with the -k option
to obtain a list of commands that are related to a keyword. For example:
$ man -k keyword
HP Encourages Your Comments
HP encourages comments concerning this document. We are committed to providing
documentation that meets your needs. Send any errors found, suggestions for improvement, or
compliments to:
docsfeedback@hp.com
Include the document title, manufacturing part number, and any comment, error found, or
suggestion for improvement you have concerning this document.
HP Encourages Your Comments 17
18
1 Overview of the User Environment
The HP XC system is a collection of computer nodes, networks, storage, and software, built into
a cluster, that work together. It is designed to maximize workload and I/O performance, and to
provide the efficient management of large, complex, and dynamic workloads.
This chapter addresses the following topics:
• “System Architecture” (page 19)
• “User Environment” (page 23)
• “Application Development Environment” (page 24)
• “Run-Time Environment” (page 25)
• “Components, Tools, Compilers, Libraries, and Debuggers” (page 27)
1.1 System Architecture
The HP XC architecture is designed as a clustered system with single system traits. From a user
perspective, this architecture achieves a single system view, providing capabilities such as the
following:
• Single user login
• Single file system namespace
• Integrated view of system resources
• Integrated program development environment
• Integrated job submission environment
1.1.1 HP XC System Software
The HP XC System Software enables the nodes in the platform to run cohesively to achieve a
single system view. You can determine the version of the HP XC System Software from the
/etc/hptc-release file.
$ cat /etc/hptc-release
HP XC V#.# RCx PKn date
Where:
#.#
RCx
PKnn
date Is the date (in yyyymmdd format) the software was released.
Is the version of the HP XC System Software
Is the release candidate of the version.
Indicates there was a cumulative patch kit for the HP XC System Software installed.
For example, if PK02 appears in the output, it indicates that both cumulative patch kits
PK01 and PK02 have been installed.
This field is blank if no patch kits are installed.
1.1.2 Operating System
The HP XC system is a high-performance compute cluster that runs HP XC Linux for High
Performance Computing Version 1.0 (HPC Linux) as its software base. Any serial or thread-parallel
applications, or applications built shared with HP-MPI that run correctly on Red Hat Enterprise
Linux Advanced Server Version 3.0 or Version 4.0, also run correctly on HPC Linux.
1.1.3 Node Platforms
The HP XC System Software is available on several platforms. You can determine the platform
by examining the top few fields of the /proc/cpuinfo file, for example, by using the head
command:
1.1 System Architecture 19
$ head /proc/cpuinfo
Table 1-1 presents the representative output for each of the platforms. This output may differ
according to changes in models and so on.
Table 1-1 Determining the Node Platform
Platform
CP3000
CP4000
CP6000
CP300BL
(Blade-only
XC systems)
Note:
Partial Output of /proc/cpuinfo
processor : 0
vendor_id : GenuineIntel
cpu family : 15
model : 3
model name : Intel(R) Xeon(TM)
processor : 0
vendor_id : AuthenticAMD
cpu family : 15
model : 5
model name : AMD Opteron(tm)
processor : 0
vendor : GenuineIntel
arch : IA-64
family : Itanium 2
model : 1
processor : 0
vendor_id : GenuineIntel
cpu family : 15
model : 6
model name : Intel(R) Xeon(TM) CPU 3.73GHz
The /proc/cpuinfo file is dynamic.
1.1.4 Node Specialization
The HP XC system is implemented as a sea-of-nodes. Each node in the system contains the same
software image on its local disk. There are two types of nodes in the system — a head node and
client nodes.
head node The node is installed with the HP XC system software first — it is used to
generate other HP XC (client) nodes. The head node is generally of interest
only to the administrator of the HP XC system.
client nodes All the other the nodes that make up the system. They are replicated from
the head node and are usually given one or more specialized roles to perform
various system functions, such as logging into the system or running jobs.
The HP XC system allows for the specialization of client nodes to enable efficient and flexible
distribution of the workload. Nodes can be assigned one or more specialized roles that determine
how a particular node is used and what system services it provides. Of the many different roles
that can be assigned to a client node, the following roles contain services that are of special interest
to the general user:
login role The role most visible to users is on nodes that have the login role. Nodes
with the login role are where you log in and interact with the system to
perform various tasks. Forexample, once logged in to anode with login role,
you can execute commands, build applications, or submit jobs to compute
nodes for execution. There can be one or several nodes with the login role
in an HP XC system, depending upon cluster size and requirements. Nodes
with the login role are a part of the Linux Virtual Server ring, which
20 Overview of the User Environment
compute role The compute role is assigned to nodes where jobs are to be distributed and
1.1.5 Storage and I/O
The HP XC system supports both shared (global) and private (local) disks and file systems.
Shared file systems can be mounted on all the other nodes by means of Lustre™ or NFS. This
gives users a single view of all the shared data on disks attached to the HP XC system.
SAN Storage
The HP XC system uses the HP StorageWorks Scalable File Share (HP StorageWorks SFS), which
is based on Lustre technology and uses the Lustre File System from Cluster File Systems, Inc.
This is a turnkey Lustre system from HP. It supplies access to Lustre file systems through Lustre
client/server protocols over various system interconnects. The HP XC system is a client to the
HP StorageWorks SFS server.
distributes login requests from users. A node with the login role is referred
to as a login node in this manual.
run. Although all nodes in the HP XC system are capable of carrying out
computations, the nodes with the compute role are the primary nodes used
to run jobs. Nodes with the compute role become a part of the resource pool
used by LSF and SLURM, which manage and distribute the job workload.
Jobs that are submitted to compute nodes must be launched from nodes with
the login role. Nodes with the compute role are referred to as compute nodes
in this manual.
Local Storage
Local storage for each node holds the operating system, a copy of the HP XC System Software,
and temporary space that can be used by jobs running on the node.
HP XC file systems are described in detail in “File System”.
1.1.6 File System
Each node of the HP XC system has its own local copy of all the HP XC System Software files
including the Linux distribution; it also has its own local user files. Every node can also import
files from NFS or Lustre file servers. HP XC System Software uses NFS 3, including both client
and server functionality. HP XC System Software also enables Lustre client services for
high-performance and high-availability file I/O. These Lustre client services require the separate
installation of Lustre software, provided with the HP Storage Works Scalable File Share (SFS).
NFS files can be shared exclusively among the nodes of the HP XC System or can be shared
between the HP XC and external systems. External NFS files can be shared with any node having
a direct external network connection. It is also possible to set up NFS to import external files to
HP XC nodes without external network connections, by routing through a node with an external
network connection. Your systemadministrator can choose to use either the HP XC administrative
network or the HP XC system interconnect for NFS operations. The HP XC system interconnect
can potentially offer higher performance, but only at the potential decrease in the performance
of application communications.
For high-performance or high-availability file I/O, the Lustre file system is available on HP XC.
The Lustre file system uses POSIX-compliant syntax and semantics. The HP XC System Software
includes kernel modifications required for Lustre client services which enables the operation of
the separately installable Lustre client software. The Lustre file server product used on HP XC
is the HP StorageWorks Scalable File Share (SFS), which fully supports the HP XC System
Software.
The SFS also includes HP XC Lustre client software. The SFS can be integrated with the HP XC
so that Lustre I/O is performed over the same high-speed system interconnect fabric used by
1.1 System Architecture 21
the HP XC. So, for example, if the HP XC system interconnect is based on a Quadrics® QsNet
II® switch, then the SFS will serve files over ports on that switch. The file operations are able to
proceed at the full bandwidth of the HP XC system interconnect because these operations are
implemented directly over the low-level communications libraries. Further optimizations of file
I/O can be achieved at the application level using special file system commands – implemented
as ioctls – which allow a program to interrogate the attributes of the file system, modify the
stripe size and other attributes of new (zero-length) files, and so on. Some of these optimizations
are implicit in the HP-MPI I/O library, which implements the MPI-2 file I/O standard.
File System Layout
In an HP XC system, the basic file system layout is the same as that of the Red Hat Advanced
Server 3.0 Linux file system.
The HP XC file system is structured to separate cluster-specific files, base operating system files,
and user-installed software files. This allows for flexibility and ease of potential upgrades of the
system software and keeps software from conflicting with user installed software. Files are
segregated into the following types and locations:
• Software specific to HP XC is located in /opt/hptc
• HP XC configuration data is located in /opt/hptc/etc
• Clusterwide directory structure (file system) is located in /hptc_cluster
Be aware of the following information about the HP XC file system layout:
• Open source software that by default would be installed under the /usr/local directory
is instead installed in the /opt/hptc directory.
• Software installed in the /opt/hptc directory is not intended to be updated by users.
• Software packages are installed in directories under the /opt/hptc directory under their
own names. The exception to this is third-party software, which usually goes in /opt/r.
• Four directories under the /opt/hptc directory contain symbolic links to files included in
the packages:
— /opt/hptc/bin
— /opt/hptc/sbin
— /opt/hptc/lib
— /opt/hptc/man
Each package directory should have a directory corresponding to each of these directories
in which every file has a symbolic link created in the /opt/hptc/ directory.
1.1.7 System Interconnect Network
The HP XC system interconnect provides high-speed connectivity for parallel applications. The
system interconnect network provides a high-speed communications path used primarily for
user file service and for communications within user applications that are distributed among
nodes of the system. The system interconnect network is a private network within the HP XC.
Typically, every node in the HP XC is connected to the system interconnect.
Table 1-2 indicates the types of system interconnects that are used on HP XC systems.
Table 1-2 HP XC System Interconnects
22 Overview of the User Environment
CP6000CP4000CP3000
XXQuadrics QSNet II®
XXMyrinet®
XXXGigabit Ethernet®
XXXInfiniBand®
Additional information on supported system interconnects is provided in the HP XC Hardware
Preparation Guide.
1.1.8 Network Address Translation (NAT)
The HP XC system uses Network Address Translation (NAT) to enable nodes in the HP XC
system that do not have direct external network connections to open outbound network
connections to external network resources.
1.2 Determining System Configuration Information
You can determine various system configuration parameters with a few commands:
Use the following command to display the version of the
HP XC System Software:
Use either of these commands to display the Kernel
version:
Use the following command to display the RPMs:
Use the following command to display the amount of free
and used memory in megabytes:
Use the following command to display the disk partitions
and their sizes:
Use the following command to display the swap usage
summary by device:
Use the following commands to display the cache
information; this is not available on all systems.
1.3 User Environment
This section introduces some general information about logging in, configuring, and using the
HP XC environment.
1.3.1 LVS
The HP XC system uses the Linux Virtual Server (LVS) to present a single host name for user
logins. LVS is a highly scalable virtual server built on a system of real servers. By using LVS, the
architecture of the HP XC system is transparent to end users, and they see only a single virtual
server. This eliminates the need for users to know how the system is configured in order to
successfully log in and use the system. Any changes in the system configuration are transparent
to end users. LVS also provides load balancing across login nodes, which distributes login requests
to different servers.
cat /etc/hptc-release
uname -rcat /proc/version
rpm -qa
free -m
cat /proc/partitions
swapon -s
cat /proc/pal/cpu0/cache_info
cat /proc/pal/cpu1/cache_info
1.3.2 Modules
The HP XC system provides the Modules Package (not to be confused with Linux kernel modules)
to configure and modify the user environment. The Modules Package enables dynamic
modification of auser’s environment by means of modulefiles. Modulefiles provide a convenient
means for users to tailor their working environment as necessary. One of the key features of
modules is to allow multiple versions of the same software to be used in a controlled manner.
A modulefile contains information to configure the shell for an application. Typically, a modulefile
contains instructions that alter or set shell environment variables, such as PATH and MANPATH,
to enable access to various installed software. Many users on a system can share modulefiles,
and users may have their own collection to supplement or replace the shared modulefiles.
1.2 Determining System Configuration Information 23
Modulefiles can be loaded into the your environment automatically when you log in to the
system, or any time you need to alter the environment. The HP XC system does not preload
modulefiles.
See Chapter 3 “Configuring Your Environment with Modulefiles” for more information.
1.3.3 Commands
The HP XC user environment includes standard Linux commands, LSF commands, SLURM
commands, HP-MPI commands, and modules commands. This section provides a brief overview
of these command sets.
Linux commands You can use standard Linux user commands and tools on the HP XC
LSF commands HP XC supports LSF and the use of standard LSF commands, some
SLURM commands HP XC uses the Simple Linux Utility for Resource Management
HP-MPI commands You can run standard HP-MPI commands from the command line.
Modules commands The HP XC system uses standard Modules commands to load and
system. StandardLinux commands are not described in this document,
but you can access Linux command descriptions in Linux
documentation and manpages. Run the Linux man command with the
Linux command name to display the corresponding manpage.
of which operate differently in the HP XC environment from standard
LSF behavior. The use of LSF commands in the HP XC environment
is described in Chapter 10 “Using LSF”, and in the HP XC lsf_diff
manpage. Information about standard LSF commands is available in
Platform LSF documentation, and in the LSF manpages. For your
convenience, the HP XC Documentation CD contains LSF manuals
from Platform Computing, Inc. LSF manpages are available on the HP
XC system.
(SLURM) for system resource management and job scheduling.
Standard SLURM commands areavailable through thecommand line.
SLURM functionality is described in Chapter 9 “Using SLURM”.
Descriptions of SLURM commands are available in the SLURM
manpages. Invoke the mancommand with the SLURM command name
to access them.
Descriptions of HP-MPI commands are available in the HP-MPI
documentation, which is supplied with the HP XC system software.
unload modulefiles, which are used to configure and modify the user
environment. Modules commands are described in “Overview of
Modules”.
1.4 Application Development Environment
The HP XC system provides an environment that enables developing, building, and running
applications using multiple nodes with multiple cores. These applications can range from parallel
applications using many cores to serial applications using a single core.
1.4.1 Parallel Applications
The HP XCparallel application development environment allows parallelapplication processes
to be started and stopped together on a large number of application processors, along with the
I/O and process control structures to manage these kinds of applications.
Full details and examples of how to build, run, debug, and troubleshoot parallel applications
are provided in “Developing Parallel Applications”.
24 Overview of the User Environment
1.4.2 Serial Applications
You can build and run serial applications under the HP XC development environment. A serial
application is a command or application that does not use any form of parallelism.
Full details and examples of how to build, run, debug, and troubleshoot serial applications are
provided in “Building Serial Applications”.
1.5 Run-Time Environment
This section describes LSF, SLURM, and HP-MPI, and how these components work together to
provide the HP XC run-time environment. LSF focuses on scheduling (and managing the
workload) and SLURM provides efficient and scalable resource management of the compute
nodes.
Another HP XC environment features standard LSF without the interaction with the SLURM
resource manager.
1.5.1 SLURM
Simple Linux Utility for Resource Management (SLURM) is a resource management system that
is integrated into the HP XC system. SLURM is suitable for use on large and small Linux clusters.
It was developed by Lawrence Livermore National Lab and Linux Networks. As a resource
manager, SLURM allocates exclusive or unrestricted access to resources (application and compute
nodes) for users to perform work, and provides a framework to start, execute and monitor work
(normally a parallel job) on the set of allocated nodes.
A SLURM system consists of two daemons, one configuration file, and a set of commands and
APIs. The central controller daemon, slurmctld, maintains the global state and directs
operations. A slurmd daemon is deployed to each computing node and responds to job-related
requests, such as launching jobs, signalling, and terminating jobs. End users and system software
(such as LSF) communicate with SLURM by means of commands or APIs — for example,
allocating resources, launching parallel jobs on allocated resources, and terminating running
jobs.
SLURM groups compute nodes (the nodes where jobs are run) together into “partitions”. The
HP XC system can have one or several partitions. When HP XC is installed, a single partition of
compute nodes is created by default for LSF batch jobs. The system administrator has the option
of creating additional partitions. For example, another partition could be created for interactive
jobs.
1.5.2 Load Sharing Facility (LSF)
The LoadSharing Facility (LSF) from Platform Computing, Inc. is a batch system resource manager
that has been integrated with SLURM for use on the HP XC system. LSF for SLURM is included
with the HP XC System Software, and is an integral part of the HP XC environment. LSFinteracts
with SLURM to obtain and allocate available resources, and to launch and control all the jobs
submitted to LSF. LSF accepts, queues, schedules, dispatches, and controls all the batch jobs that
users submit, according to policies and configurations established by the HP XC site administrator.
On an HP XC system, LSF for SLURM is installed and runs on one HP XC node, known as the
LSF execution host.
A complete description of LSF is provided in Chapter 10 “Using LSF”. In addition, for your
convenience, the HP XC Documentation CD contains LSF manuals from Platform Computing.
1.5.3 Standard LSF
Standard LSF is also available on the HP XC system. The information for using standard LSF is
documented in the LSF manuals from Platform Computing. For your convenience, the HP XC
documentation CD contains these manuals.
1.5 Run-Time Environment 25
1.5.4 How LSF and SLURM Interact
In the HP XC environment, LSF cooperates with SLURM to combine the powerful scheduling
functionality of LSF with the scalable parallel job launching capabilities of SLURM. LSF acts
primarily as a workload scheduler on top of the SLURM system, providing policy and
topology-based scheduling for end users. SLURM provides an execution and monitoring layer
for LSF. LSF uses SLURM to detect system topology information, make scheduling decisions,
and launch jobs on allocated resources.
When a job is submitted to LSF, LSF schedules the job based on job resource requirements. LSF
communicates with SLURM to allocate the required HP XC compute nodes for the job from the
SLURM lsf partition. LSF provides node-level scheduling for parallel jobs, and core-level
scheduling for serial jobs. Because of node-level scheduling, a parallel job may be allocated more
cores than it requested, depending on its resource request; the srun or mpirun -srun launch
commands within the job still honor the original request. LSF always tries to pack multiple serial
jobs on the same node, with one core per job. Parallel jobs and serial jobs cannot coexist on the
same node.
After theLSF scheduler allocates theSLURM resources for a job, the SLURM allocation information
is recorded with the job. You can view this information with the bjobs and bhist commands.
When LSF starts a job, it sets the SLURM_JOBID and SLURM_NPROCS environment variables in
the job environment. SLURM_JOBID associates the LSF job with SLURM's allocated resources.
The SLURM_NPROCS environment variable is set to the originally requested number of cores.
LSF dispatches the job from the LSF execution host, which is the same node on which LSF
daemons run. The LSF JOB_STARTER script, which is configured for all queues, uses the srun
command to launch a user job on the first node in the allocation. Your job can contain additional
srun or mpirun commands to launch tasks to all nodes in the allocation.
While a job is running, all resource limits supported by LSF enforced, including core limit, CPU
time limit, data limit, file size limit, memory limit and stack limit. When you terminate a job, LSF
uses the SLURM scancel command to propagate the signal to the entire job.
After a job finishes, LSF releases all allocated resources.
A detailed description, along with an example and illustration, of how LSF and SLURM cooperate
to launch and manage jobs is provided in “How LSF and SLURM Launch and Manage a Job”.
It is highly recommended that you review this information.
In summary, and in general:
LSF Determines WHEN and WHERE the job will run. LSF communicates with SLURM
to determine WHICH resources are available, and SELECTS the appropriate set of
nodes for the job.
SLURM Allocates nodes for jobs as determined by LSF. It CONTROLS task/rank distribution
within the allocated nodes. SLURM also starts the executables on each host as
requested by the HP-MPI mpirun command.
HP-MPI Determines HOW the job runs. It is part of the application, so it performs
communication. HP-MPI can also pinpoint the processor on which each rank runs.
1.5.5 HP-MPI
HP-MPI is a high-performance implementation of the Message Passing Interface (MPI) standard
and is included withthe HP XC system. HP-MPI uses SLURM to launch jobs on an HP XCsystem
— however, it manages the global MPI exchange so that all processes can communicate with
each other.
See the HP-MPI documentation for more information.
26 Overview of the User Environment
1.6 Components, Tools, Compilers, Libraries, and Debuggers
This section provides a brief overview of the some of the common tools, compilers, libraries, and
debuggers available for use on HP XC.
An HP XC system is integrated with several open source software components. HP XC
incorporates a Linux operating system and its standard commands and tools, and maintains the
Linux ABI. In addition, HP XC incorporates LSF and SLURM to launch and manage jobs, and
includes HP-MPI for high-performance, parallel, message-passing applications.
You can use most standard open source compilers and tools on an HP XC system; however, you
must purchase them separately. Several open source and commercially available software
packages have been tested with the HP XC Software. The following lists some of the software
packages that have been tested for use with HP XC. This list provides a sample of what is available
on HP XC and is not intended as a complete list. Some packages listed are actually included as
part of the HPC Linux distribution and as such can be used as part of the HP XC development
environment. The tested software packages include, but are not limited to, the following:
• Intel Fortran 95, C, C++ Compiler Version 7.1, 8.0, 9.0, 9.1 including OpenMP, for Itanium®
(includes ldb debugger)
• gcc version 3.2.3 (included in the HP XC distribution)
• g77 version 3.2.3 (included in the HP XC distribution)
• Portland Group PGI Fortran90, C, C++ Version 5.1, including OpenMP, for CP4000
• Quadrics SHMEM, as part of QsNet II user libraries, on Itanium systems connected with
the Quadrics QsNet II switch (included in the HP XC distribution)
• Etnus TotalView debugger Version 6.4
• gdb (part of the HP XC Linux distribution)
• Intel MKL V6.1 on Itanium
• AMD Math Core Library Version 2.0 on CP4000
• valgrind 2.0.0 (http://valgrind.kde.org) in 32-bit mode only
• oprofile 0.7.1 (http://oprofile.sourceforge.net)
• PAPI 3.2 (http://icl.cs.utk.edu/papi)
• Intel Visual Analyzer/Tracer (formally Pallas Vampir and Vampirtrace performance analyzer
) on Itanium
• GNU make, including distributed parallel make (included in the HP XC distribution)
Other standard tools and libraries are available, and you can most likely used them on HP XC
as you would on any other standard Linux system.
IMPORTANT: Software that is not described in the HP XC QuickSpecs or in the HP XC
documentation set has not been tested with the HP XC System Software. HP does not warrant
the operation of any software that is not specifically identified in the product specification (the
HP XC QuickSpecs) and is not documented in the HP XC documentation set.
1.6 Components, Tools, Compilers, Libraries, and Debuggers 27
28
2 Using the System
This chapter describes the tasks and commands that the general user must know to use the
system. It addresses the following topics:
• “Logging In to the System” (page 29)
• “Overview of Launching and Managing Jobs” (page 29)
• “Performing Other Common User Tasks” (page 31)
• “Getting System Help and Information” (page 32)
2.1 Logging In to the System
Logging in to an HP XC system is similar to logging in to any standard Linux system. You can
only login on nodes that have the login role; those nodes are enabled for logins.
2.1.1 LVS Login Routing
The HP XC system uses the Linux Virtual Server (LVS) facility to present a set of login nodes
with a single cluster name. When you log in to the system, LVS automatically routes your login
request to an available login node on the system. LVS load balances login sessions across the
login nodes and improves the availability of login access. When you log in to the HP XC system,
you do not have to know specific node names to log in, only the HP XC system's cluster name.
2.1.2 Using the Secure Shell to Log In
Secure Shell (ssh) is the preferred method for accessing the HP XC system.
Typically, you access the HP XC system using the ssh command to get a login shell or to execute
commands. For example:
$ ssh user-name@system-name
user-name@system-name's password:
The ssh service also allows file transfer using the scp or sftp commands over the same port as
ssh.
The typical r* UNIX commands, such as rlogin, rsh, and rcp, are not installed on an HP XC
system by default because of their inherent insecurity. The ssh command transfers all login and
password information in an encrypted form instead of the plaintext form used by the r* UNIX
commands (as well as telnet and ftp).
If you want to use ssh without password prompting, you must set up ssh authentication keys.
See ssh(1) for information about using ssh authentication keys.
The Secure Shell is further discussed in “Enabling Remote Execution with OpenSSH” (page 107).
You can bypass the need to enter a login and password each time you log in by updating the
ssh keys. The ssh_create_shared_keys command, used on a one-time basis, updates the
appropriate ssh key files in your $HOME/.ssh directory, provided:
• You have a user account on the HP XC system.
• Yourhome directory is mounted on all the nodes towhich youlog in or on which you launch
jobs.
Ensure that you deny write permission on your home directory to the group and others; otherwise
the ssh command . The following command accomplishes that for you:
$ chmod go -w $HOME
2.2 Overview of Launching and Managing Jobs
This section provides a brief description of some of the many ways to launch jobs, manage jobs,
and get information about jobs on an HP XC system. This section is intended only as a quick
2.1 Logging In to the System 29
overview about some basic ways of running and managing jobs. Full information and details
about the HP XC job launch environment are provided in “Using SLURM”) and the LSF section
of “Using LSF”) of this document.
2.2.1 Introduction
As described in “Run-Time Environment” (page 25), SLURM and LSF cooperate to run and
manage jobson the HP XCsystem, combining LSF's powerful and flexible scheduling functionality
with SLURM's scalable parallel job-launching capabilities.
SLURM is the low-level resource manager and job launcher, and performs core allocation for
jobs. LSF gathersinformation about the cluster from SLURM. When a job is ready to be launched,
LSF creates a SLURM node allocation and dispatches the job to that allocation.
Although you can launch jobs directly using SLURM, HP recommends that you use LSF to take
advantage of its scheduling and job management capabilities. You can add SLURM options to
the LSF job launch command line to further define job launch requirements. Use the HP-MPI
mpirun command and its options within LSF to launch jobs that require MPI'shigh-performance
message-passing capabilities.
When the HP XC system is installed, a SLURM partition of nodes is created to contain LSF jobs.
This partition is called the lsf partition.
When a job is submitted to LSF, the LSF scheduler prioritizes the job and waits until the required
resources (compute nodes from the lsf partition) are available.
When the requested resources are available for the job, LSF creates a SLURM allocation of nodes
on behalf of the user, sets the SLURM JobID for the allocation, and dispatches the job with the
LSF JOB_STARTER script to the first allocated node.
A detailed explanation of how SLURM and LSF interact to launch and manage jobs is provided
in “How LSF and SLURM Launch and Manage a Job” (page 92).
2.2.2 Getting Information About Queues
The LSF bqueues command lists the configured job queues in LSF. By default, bqueues returns
the following information about all queues:
• Queue name
• Queue priority
• Queue status
• Job slot statistics
• Job state statistics
To get information about queues, enter the bqueues as follows:
$ bqueues
For more information about using this command and a sample of its output, see “Examining
System Queues” (page 96)
2.2.3 Getting Information About Resources
The LSF bhosts, lshosts, and lsload commands are quick ways to get information about
system resources. LSF daemons run on only one node in the HP XC system, so the bhosts and
lshosts commands will list one host — which representsall the resources of the HP XC system.
The total number of cores for that host should be equal to the total number of cores assigned to
the SLURM lsf partition.
• The LSF bhosts command provides a summary of the jobs on the system and information
about the current state of LSF.
$ bhosts
30 Using the System
Loading...
