H P D e s k W r i t e r 6 6 0 C P r i n t e r M o d e l N u m b e r a n d D e s c r i p t i o n
Model Number and Description
HP DeskWriter 660C Printer
Printer Name Model Number Status Description
HP DeskWriter 660C C2165A Available
worldwide
Fast black and color personal
printer for Macintosh computers
H P D e s k W r i t e r 6 6 0 C P r i n t e r F r o n t V i e w
Access Door
Resume Button & Light
Print Cartridge Cradles
Card Guide
IN Tray
Paper Width Adjuster
Paper Length Adjuster
Power Button & Light
Output Tray Assembly
Envelope Feed Slot
Front View
H P D e s k W r i t e r 6 6 0 C P r i n t e r R e a r V i e w
Rear View
Interface Port
Power Module Socket
H P D e s k W r i t e r 6 6 0 C P r i n t e r O r d e r i n g P r i n t e r O p t i o n s
Ordering Printer Options
Localized Printer Options
User’s
Region or
Country
Argentina Spanish C2165A AC8 9100-5129 C2165-60218
Asia, North English C2165A ART 9100-5346 C2165-60202
Asia-Pacific English C2165A ARS 9100-5131 C2165-60202
Australia English C2165A ABG 9100-5127 C2165-60202
Brazil Portuguese C2165A AC4 9100-5124 C2165-60216
Brazil-2 Portuguese C2165A AIZ 9100-5346 C2165-60216
Canada-French French C2165A ABC 9100-5124 C2165-60208
Caribbean English C2165A ARV 9100-5346 C2165-60200
Denmark Danish/English C2165A ABY 9100-5132 C2165-60205
Europe-Dutch Dutch C2165A ACU 9100-5132 C2165-60206
Europe-English English C2165A ABB 9100-5132 C2165-60202
Europe-French French C2165A ACS 9100-5132 C2165-60208
Europe-German German C2165A ACT 9100-5132 C2165-60209
Europe-Italian Italian C2165A ARP 9100-5132 C2165-60212
Finland Finnish/English C2165A ABX 9100-5132 C2165-60207
India English C2165A ACJ 9100-5128 C2165-60202
Japan Japanese C2165A ABJ 9100-5130 C2165-60213
Latin America Spanish C2165A ABM 9100-5124 C2165-60218
Mexico Spanish C2165A AR9 9100-5125 C2165-60218
Norway Norwegean/English C2165A ABY 9100-5132 C2165-60214
Portugal Portuguese C2165A AB9 9100-5132 C2165-60216
South Africa English C2165A ACQ 9100-5128 C2165-60202
South America Spanish C2165A AKV 9100-5346 C2165-60218
Spain Spanish C2165A ABE 9100-5132 C2165-60218
Sweden Swedish C2165A ABS 9100-5132 C2165-60219
Taiwan English C2165A ARB 9100-5124 C2165-60220
Turkey English 9100-5132 C2165-60221
United Kingdom English C2165A ABU 9100-5131 C2165-60202
United States English C2165A ABA 9100-5124 C2165-60200
Documentation
Language
Printer
Option
Numbers
Power
Module
Part Numbers
User’s
Documentation
Kit Part Numbers
H P D e s k W r i t e r 6 6 0 C P r i n t e r O r d e r i n g P r i n t e r O p t i o n s
Available Power Modules
Region or Country Power Requirements Power Module Part Number
Argentina 220V/50 Hz 9100-5129 (C2179A)
Australia 240V/50 Hz 9100-5127 (C2181A)
Brazil, Philippines 220V/50 Hz 9100-5391
Canada 120V/60 Hz 9100-5124 (C2175A)
Caribbean 220V/50 Hz 9100-5346
China 220V/50 Hz 9100-5129 (C2179A)
Europe (Except U.K.) 230V/50 Hz 9100-5132 (C2176A)
Hong Kong 220V/50 Hz 9100-5348
Japan 100V/50/60 Hz 9100-5130 (C2178A)
Korea 220V/60 Hz 9100-5126 (C2182A)
Mexico 120V/60 Hz 9100-5124 (C2175A)
South Africa 220V/50 Hz 9100-5128 (C2180A)
U. K. 240V/50 Hz 9100-5131 (C2177A)
U. S. 120V/60 Hz 9100-5124 (C2175A)
H P D e s k W r i t e r 6 6 0 C P r i n t e r I t e m s I n c l u d e d
Items Included
HP DeskWriter 660C Printer
Power Module
User's Guide
Printer software
on diskette
One black print cartridge
One color print cartridge
H P D e s k W r i t e r 6 6 0 C P r i n t e r F o n t s I n c l u d e d
Fonts Included
Scalable TrueType® Fonts For Macintosh
H P D e s k W r i t e r 6 6 0 C P r i n t e r P a r t N u m b e r s
Part Numbers
Item Description Part Number
Interface Cables Macintosh RS-422 Serial Cable 92215S
Macintosh AppleTalk Network Cable 92215N
Print Cartridges Black Inkjet Print Cartridge 51629A
Color Inkjet Print Cartridge 51649A
Media Premium Transparency Film (U.S. letter, 50 sheets) C3834A
Premium Transparency Film (U.S. letter, 20 sheets) C3828A
Premium Transparency Film (European A4, 50 sheets) C3835A
Premium Transparency Film (European A4, 20 sheets) C3832A
Premium Glossy Paper (U.S. letter, 50 sheets) C3836A
Premium Glossy Paper (U.S. letter, 10 sheets) C3833A
Premium Glossy Paper (European A4, 50 sheets) C3837A
Premium Glossy Paper (European A4, 10 sheets) C3831A
Premium InkJet Paper (U.S. letter, 200 sheets) 51634Y
Premium InkJet Paper (European A4, 200 sheets) 51634Z
H P D e s k W r i t e r 6 6 0 C P r i n t e r U s e r R e p l a c e a b l e C o m p o n e n t s
User Replaceable Components
Access Door
Base Foot
Paper Tray
Description Part Number
Access Door (Top Cover) Assembly C2164-67816
Base Foot Assembly C2162-60098
Paper Tray Assembly C2164-67807
H P D e s k W r i t e r 6 6 0 C P r i n t e r H o s t / S y s t e m R e q u i r e m e n t s
Host/System Requirements
QuickDraw Operation
System 7.0 or later
68020 16 MHz or faster processor, 68040 25 MHz recommended
At least 4 MB of RAM, 8 MB recommended
At least 10 MB free hard disk space
QuickDraw GX Operation
System 7.5 or later
68020 16 MHz or faster processor, 68040 25 MHz recommended
At least 8 MB of RAM, 12 MB is recommended
At least 10 MB free hard disk space
H P D e s k W r i t e r 6 6 0 C P r i n t e r D r i v e r I n s t a l l a t i o n
Driver Installation
For the printer to operate properly, a printer driver must be installed in your
computer. Refer to “Printer Driver Information\Installing the Printer Driver”
for more detailed information.
H P D e s k W r i t e r 6 6 0 C P r i n t e r I n t e r f a c e S p e c i f i c a t i o n s
Interface Specifications
The HP DeskWriter 660C Printer has an 8-pin mini-DIN interface
connector port. This connector port is compatible with RS-422-A serial,
AppleTalk, and high-speed externally-clocked serial mode
communication. The printer automatically determines if it is connected to
an AppleTalk network or directly to a Macintosh printer port.
Communication Modes and Supported Protocols
Category Macintosh I/O Connector
Communication Modes RS-422 Serial (57.6 Kbaud)
AppleTalk (230.4 Kbaud)
High-Speed Externally-Clocked Serial
Mode
Macintosh Protocols Serial Pacing Protocol (SPP)
AppleTalk Transaction Protocol (ATP)
AppleTalk Link Access Protocol (ALAP)
Datagram Delivery Protocol (DDP)
Echo Protocol (EP)
Name Binding Protocol (NBP)
Printer Access Protocol (PAP)
Routing Table Maintenance Protocol (RTMP)
Note For a complete description of your printer’s interface, see
“Printer Interface Information.”
H P D e s k W r i t e r 6 6 0 C P r i n t e r P r o d u c t P e r f o r m a n c e S p e c i f i c a t i o n s
Product Performance Specifications
The HP DeskWriter 660C prints a 600x300 dot size. Dots are placed on a
600x300 grid. Depletion is used to remove approximately 10% of the dots
to prevent laying too much ink on the page.
In the Best mode, the paper advances at 600 DPI increments and places
dots on a true 600x600 grid. Depletion in the Best mode removes
approximately 43% of the dots.
Resolution determinations are made in the Macintosh and sent to the
printer.
Print Speed
EconoFast Mode Normal Mode Best Mode
Black Print Speed 14 pages per minute 2.5 pages per minute 1 page per minute
Color Print Speed 10.6 minutes per page 1.5 minutes per page 3 minutes per page
1. Approximate figures. Exact speed will vary depending upon the system configuration, software
program, and document complexity.
Resolution
EconoFast Mode Normal Mode Best Mode
Black Resolution 300 x 300 DPI 600 x 300 DPI 600 x 600 DPI
Color Resolution
Plain Paper & Premium Papers 300 x 300 DPI 300 x 300 DPI 300 x 300 DPI
Glossy Paper and
Transparency Film
(black and color)
N/A 600 x 300 DPI 600 x 300 DPI
Note DPI is measured in addressable raster points per inch.
H P D e s k W r i t e r 6 6 0 C P r i n t e r P a p e r H a n d l i n g S p e c i f i c a t i o n s
Paper Handling Specifications
Category Specification
Paper Grain Long Grain Only
Paper 60 to 135 g/m2 (16 to 36 lb.)
Envelopes 75 to 90 g/m2 (20 to 24 lb.)
Cards 110 to 200 g/m2 (29 to 53 lb., 61 to 110 lb. index
max.; 8.5 pt max thickness)
2
Labels
IN Tray Capacity Up to 100 Sheets (<1/2 in.)
OUT Tray Capacity Up to 50 Sheets
Multiple Envelopes
Card Capacity Up to 30 Cards
1. Envelope capacity is dependent on the manufacturer, type of envelope and its construction.
2. Use only U.S. letter or A4 size sheets. Use only Avery paper labels specifically designed for use
with HP InkJet Printers.
1
Up to 25 Sheets of Avery Paper Labels
Up to 20 Envelopes (<1/2 in.)
Note The HP DeskWriter 660 Printer works well with most types of
paper although variables in paper composition may affect
print quality and paper handling. Bond paper, such as
letterhead, gives excellent quality. Paper should be tested to
ensure best performance.
H P D e s k W r i t e r 6 6 0 C P r i n t e r P a p e r H a n d l i n g S p e c i f i c a t i o n s
Supported Media/Sizes
Category Specification
US Letter 215.9 x 279.4 mm (8.5 x 11 in.)
US Legal 215.9 x 355.6 mm (8.5 x 14 in.)
U.S. Executive 184.1 x 266.7 mm ( 7.25 x 10.5 in.)
ISO & JIS A4 210 x 297 mm (8.27 x 11.69 in.)
ISO & JIS A5 148.5 x 210 mm (5.83 x 8.27 in.)
ISO & JIS B5 182 x 257 mm (7.17 x 10.12 in.)
U.S. No. 10 Envelope
U.S. A2 Envelope (5.5) 111 x 146 mm (4.375 x 5.75 in.)
European DL Envelope
European C6 Envelope
U.S. 4 x 6 Card 101.6 x 152.4 mm (4 x 6 in.)
U.S. 5 x 8 Card 127 x 203.2 mm (5 x 8 in.)
European A6 Card 105 x 148.5 mm (4.13 x 5.83 in.)
Japanese Hagaki Postcard 100 x 148 mm (3.94 x 5.83 in.)
Custom Size (user defined)
Width 127 to 216 mm (5 to 8.5 in.)
Length 148 to 356 mm (5.83 to 14 in.)
1. To minimize print skew, use envelopes with rectangular flaps rather than triangular flaps.
1
1
1
104.7 x 241.3 mm (4.12 x 9.5 in.)
110 x 220 mm (4.33 x 8.66 in.)
114 x 162 mm (4.49 x 6.38 in.)
H P D e s k W r i t e r 6 6 0 C P r i n t e r P r i n t a b l e A r e a S p e c i f i c a t i o n s
Printable Area Specifications
U.S. Paper and Transparency
Page Size Top Margin Bottom Margin
U.S. Executive
184.1 x 266.7 mm
(7.25 x 10.5 in.)
U.S. Letter
215.9 x 279.4 mm
(8.5 x 11 in.)
U.S. Legal
215.9 x 355.6 mm
(8.5 x 14 in.)
6.6 mm
(0.26 in.)
6.6 mm
(0.26 in.)
6.6 mm
(0.26 in.)
14.9 mm
(0.59 in.)
14.9 mm
(0.59 in.)
14.9 mm
(0.59 in.)
Left and Right
Margins
6.4 mm
(0.25 in.)
6.4 mm
(0.25 in.)
6.4 mm
(0.25 in.)
H P D e s k W r i t e r 6 6 0 C P r i n t e r P r i n t a b l e A r e a S p e c i f i c a t i o n s
International Paper and Transparency
Left and Right
Page Size Top Margin Bottom Margin
International A4
210 x 297 mm
(8.27 x 11.69 in.)
International A5
148.5 x 210 mm
(6.00 x 8.27 in.)
International B5
182 x 257 mm
(7.17 x 10.12 in.)
6.6 mm
(0.26 in.)
6.6 mm
(0.26 in.)
6.6 mm
(0.26 in.)
14.9 mm
(0.59 in.)
21.3 mm
(0.84 in.)
14.9 mm
(0.59 in.)
Margins
6.4 mm
(0.25 in.)
6.4 mm
(0.25 in.)
6.4 mm
(0.25 in.)
H P D e s k W r i t e r 6 6 0 C P r i n t e r P r i n t a b l e A r e a S p e c i f i c a t i o n s
Envelopes
Left and Right
Envelope Size Top Margin Bottom Margin
U.S. #10 Envelope
104.7 x 241.3 mm
(4.12 x 9.5 in.)
International DL
110 x 220 mm
(4.33 x 8.66 in.)
International C6
114 x 162 mm
(4.49 x 6.38 in.)
26 mm
(0.84 in.)
26 mm
(0.84 in.)
26 mm
(0.84 in.)
6.6 mm
(0.29 in.)
6.6 mm
(0.29 in.)
6.6 mm
(0.29 in.)
Margins
3.2 mm
(0.125 in.)
3.2 mm
(0.125 in.)
3.2 mm
(0.125 in.)
H P D e s k W r i t e r 6 6 0 C P r i n t e r P r i n t a b l e A r e a S p e c i f i c a t i o n s
Cards
Left and Right
Card Size Top Margin Bottom Margin
U.S. 4 x 6
101.6 x 152.4 mm
(4 x 6 in.)
U.S. 5 x 8
127 x 203.2 mm
(5 x 8 in.)
International A6
105 mm x 148.5 mm
(4.13 x 6.00 in.)
Japanese Hagaki
Postcard
100 mm x 148 mm
(3.94 x 5.83 in.)
6.6 mm
(0.26 in.)
6.6 mm
(0.26 in.)
6.6 mm
(0.26 in.)
6.6 mm
(0.26 in.)
0.84 mm
(21.3 in.)
0.84 mm
(21.3 in.)
0.84 mm
(21.3 in.)
0.84 mm
(21.3 in.)
Margins
6.4 mm
(0.25 in.)
6.4 mm
(0.25 in.)
6.4 mm
(0.25 in.)
6.4 mm
(0.25 in.)
H P D e s k W r i t e r 6 6 0 C P r i n t e r P h y s i c a l S p e c i f i c a t i o n s
Physical Specifications
Weight: 5.3 Kg (11.6 lb.)
H P D e s k W r i t e r 6 6 0 C P r i n t e r E l e c t r i c a l S p e c i f i c a t i o n s
Electrical Specifications
Category Specification
Input Voltage
Frequency
100 VAC 50/60 Hz (±3 Hz)
120 VAC 60 Hz (±3 Hz)
127 VAC 60 Hz (±3 Hz)
220 VAC 50 Hz (±3 Hz)
230 VAC 50 Hz (±3 Hz)
240 VAC 50 Hz (±3 Hz)
Maximum Power Consumption
Powered Off (plugged in) 2 Watts
Powered On (non-printing) 4.5 Watts
Powered On (printing state) 12 Watts
1. Power modules are available for each listed input voltage.
1
100 VAC, 120 VAC, 127 VAC, 220 VAC,
230 VAC, or 240 VAC (±10%)
H P D e s k W r i t e r 6 6 0 C P r i n t e r E n v i r o n m e n t a l S p e c i f i c a t i o n s
Environmental Specifications
Category Specification
Temperature
Operating 5 to 40° C (41 to 104° F)
Non-Operating (storage) –40 to 60° C (–40 to 140° F)
Relative Humidity 10 to 80% RH non-condensing
Recommended
Operating
Conditions for
Best Print Quality
Noise Levels per ISO
9296
Sound Power, L
Sound Pressure, L
1. Bystander positions.
wAd
pAm
1
15 to 35° C (59 to 95° F),
20 to 80% RH non-condensing
Best Mode
6.0 B(A)
46 dB(A) 50 dB(A) 51 dB(A)
Normal Mode
6.3 B(A)
EconoFast
Mode
6.5 B(A)
H P D e s k W r i t e r 6 6 0 C P r i n t e r S a f e t y a n d E M I S p e c i f i c a t i o n s
Safety and EMI Specifications
Category Specification
Safety Certifications
Power Module UL, CSA, TUV, SEMKO, NEMKO, SEV, SECV,
FIMKO, DEMKO, NOM
Printer with Power Module UL, CSA, TUV, ETL
EMI Certifications
Printer with Power Module FCC Class B, when used with a Class B
computing device (USA), EMC Directive
89/336/EEC (European Community), VCCI
(Japan), SABS (South Africa)
H P D e s k W r i t e r 6 6 0 C P r i n t e r R e l i a b i l i t y S p e c i f i c a t i o n s
Reliability Specifications
Category Specification
Mechanism Life 60,000 pages
Mean Time Between Failures (MTBF) 20,000 hours
Printer Usage Rate
Power On Per Year 2,000 hours
Printed Pages Per Year 12,000 pages
Black Pages Per Month 1,000 pages total maximum
Color Pages Per Month 160 pages total maximum
H P D e s k W r i t e r 6 6 0 C P r i n t e r P a c k a g i n g S p e c i f i c a t i o n s
Packaging Specifications
Weight = 8.137 kg (17.94 lb.)
Loading...
